Husqvarna AUTOMOWER 210 C User manual

HUSQVARNA AUTOMOWER™
210 C
QUICK GUIDE
www.automower.com
115 03 17-26
5STA RTING A N D STO PPING AUTOMOWE R™
See chapters 4.1 and 4.2 in the Operator’s Manual.
STARTI NG
1. Open the control panel cover by pressing the STOP button.
2. Set the main switch to ON position.
3. Enter the PIN code, confi rm with the YES button.
4. Close the cover.
STOPPING
Press the STOP button.
USE
Automower is recommended for lawns up to 500 m² / 0.12
acre. The size of the working area the mower can handle
depends on how much it is used. The larger the lawn the
more occasions per week Automower can work.
2
3
4
41. Connect the loop generator/charger charging cable to the
mower’s charger contact. The boundary loop must be
connected to a mains connected loop generator/charger.
2. Set the main switch to ON position.
3. Select and enter a four digit PIN code. All combinations
except 0000 are permitted.
4. Press the YES button.
5. Confi rm the selected PIN code by re-entering the PIN
code.
6. Press the YES button.
When you have selected a PIN code, the mower and loop
generator/charger are linked to each other and the mower can
be operated.
LINKING AUTOMOWER™ TO THE LOOP GEN E R ATOR/C HARGER
See chapter 3.7 in the Operator’s Manual
1
2
3
AUTOMOWER is a trademark owned by Husqvarna AB. Copyright © 2006 HUSQVARNA. All rights reserved.

30 cm
Zone 1
Zone 2
30 cm / 12” 35 cm / 14”
10 cm / 4”
0 cm / 0”
G ET TI NG STA RTE D WITH
HU SQVAR NA AUTOMOWE R™
31. Open the connector and run the wire ends in the recesses
on each connector.
2. Press the connector together using a pair of pliers.
3. Cut off any surplus boundary wire.
Cut 1-2 cm / 0.5” above the connector.
4. Attach the connector to the contact pin on the loop
generator/charger.
1
2
PL AC E M E NT AN D CO N NECTION OF LOO P G E N E R ATO R /C H A RGE R
AND C H A RGI N G OF BATTERY
PL AC I NG T H E BOU NDARY W I R E
See 3.4 in the Operator’s Manual
1. Run the boundary wire ensuring it
forms a loop around the work area.
See chapters 3.2 and 3.3 in the Operator’s Manual.
1. The loop generator/charger must be placed where it is well
ventilated and is not exposed to direct sunlight.
2. Connect the loop generator/charger’s power cord to a
mains wall socket. The 120V transformer (USA) is for
indoor use only.
3. Connect the charger cable from the loop generator/charger
to the charger contact on the mower. The green indicator
lamp Battery should now now be lit with a steady light.
Loop generator/charger Boundar y wire and
coupler
Clinchers Connector Measurement gauge
CO N NECTING TH E BO U N DARY WI R E
See chapter 3.5 in the Operator’s Manual
2
1
4
3
2
3
1. Catch but ton to open the cutting
height adjustment cover
2. STOP but ton
3. Charger contact
4. Connection to boundar y wire
5. LED for performance inspection
of boundar y wire
6. Indicator lamps
7. Keypad
1
2
3
4
5
6
7
ZONE CLAS SIFICATION
If the mowing results in the garden are uneven due to the
shape of the garden, for example because of a long passage,
you have the option of dividing up your garden into zones.
When the mower is placed in zone 1, it will not mow in zone
2 and vice versa. Move the mower between the zones to
maintain even mowing results.
