Husqvarna BMP 335 User manual

BMP 335
EN Operator's manual 2-21
ES-MX Manual de usuario 22-43
FR-CA Manuel d’utilisation 44-65

Contents
Introduction..................................................................... 2
Safety..............................................................................5
Operation........................................................................ 9
Maintenance................................................................. 14
Troubleshooting............................................................ 18
Transportation, storage and disposal........................... 18
Technical data BMP335...............................................20
Introduction
Owner responsibility
WARNING: Processing of concrete and
stone by methods such as cutting, grinding
or drilling, especially during dry operation,
generates dust that comes from the material
being processed, which frequently contains
silica. Silica is a basic component of sand,
quartz, brick clay, granite and numerous
other minerals and rocks. Exposure to
excessive amount of such dust can cause:
Respiratory disease (affecting your ability
to breathe), including chronic bronchitis,
silicosis and pulmonary fibrosis from
exposure to silica. These diseases may be
fatal;
Skin irritation and rash.
Cancer according to NTP* and IARC* */
National Toxicology Program, International
Agency for Research on Cancer.
Take precautionary steps:
Avoid inhalation of and skin contact with
dust, mist and fumes.
Wear and ensure that all bystanders
wear appropriate respiratory protection such
as dust masks designed to filter out
microscopic particles. (See OSHA 29 CFR
Part 1926.1153)
To minimize dust emissions, use water
to bind the dust, when feasible. If dry
operation is necessary, use an appropriate
dust extractor.
It is the owner’s/employer’s responsibility that the
operator has sufficient knowledge about how to use the
product safely. Supervisors and operators must have
read and understood the Operator’s Manual. They must
be aware of:
• The product’s safety instructions.
• The product’s range of applications and limitations.
• How the product is to be used and maintained.
National/Local regulations could restrict the use of this
product. Find out what regulations are applicable where
you work before you start using the product.
Product description
The product is a pedestrian-controlled scarifier operated
by an electric motor.
Intended use
The product is used to make the surfaces rough, and
to remove layers and road marks. The product can be
used on surfaces such as concrete, asphalt, stone and
steel.
The product is used in commercial operations by
professional operators.
Do not use the product for other tasks.
21838 - 003 - 09.02.2023

Product overview
3
1
14
10
11
7
9
14
8
5
2
15
12
13
4
6
1. Lift lever
2. Depth adjustment wheel
3. Control panel
4. Lifting eye
5. Power plug
6. Electrical enclosure with main switch
7. Drive system pedal
8. Water connection
Note: If water is necessary for your operation,
speak to a Husqvarna service agent for more
information.
9. Connector for dust extractor
10. Direction pointer
11. Front wheel
12. Type plate
13. Side cover
14. Hole for tie-down strap
15. Operator's manual
1838 - 003 - 09.02.2023 3

Control panel overview
9
3 4
10 11 12 13 14
8
7
6
5
2
1
15
1. Indicator for depth adjustment
2. Manual depth indicator
3. Joystick for forward and rearward movement of the
left drive wheel
4. Joystick for forward and rearward movement of the
right drive wheel
5. Steering lock
6. Lock for depth adjustment wheel
7. Lift lever
8. Depth adjustment wheel
9. Tracking control
10. Speed adjustment
11. ON/OFF buttons for drive motor
12. Emergency stop button
13. Ammeter
14. ON/OFF buttons for drum motor
15. Operator presence control (OPC)
Symbols on the product
Warning: This product can be dangerous
and cause serious injury or death to the
operator or others. Be careful and use the
product correctly.
High voltage.
Keep all parts of your body away from hot
surfaces.
Lifting point.
Keep hands away from rotating parts.
Read the manual carefully and make
sure that you understand the instructions
before you use the product.
Use an approved respiratory protection.
Use approved hearing protection.
41838 - 003 - 09.02.2023

Use approved eye protection.
Use approved protective gloves.
Use approved protective boots.
This product is in compliance with
applicable EU directives.
Note: Other symbols/decals on the product refer to
special certification requirements for some markets.
Type plate
13
11
10
12
21 3 4
6
5
8
9
7
1. Product number
2. Product weight
3. Rated power
4. Rated voltage
5. Enclosure
6. Rated current
7. Frequency
8. Maximum slope angle
9. Manufacturer
10. Scannable code
11. Production year
12. Model
13. Serial number
Product liability
As referred to in the product liability laws, we are not
liable for damages that our product causes if:
• the product is incorrectly repaired.
• the product is repaired with parts that are not
from the manufacturer or not approved by the
manufacturer.
• the product has an accessory that is not from the
manufacturer or not approved by the manufacturer.
• the product is not repaired at an approved service
center or by an approved authority.
Safety
Safety definitions
Warnings, cautions and notes are used to point out
specially important parts of the manual.
WARNING: Used if there is a risk of
injury or death for the operator or bystanders
if the instructions in the manual are not
obeyed.
CAUTION: Used if there is a risk of
damage to the product, other materials or
the adjacent area if the instructions in the
manual are not obeyed.
Note: Used to give more information that is necessary
in a given situation.
General safety instructions
WARNING: Read the warning
instructions that follow before you use the
product.
• This product is a dangerous tool if you are not
careful or if you use the product incorrectly. This
product can cause serious injury or death to the
operator or others. Before you use the product,
you must read and understand the contents of this
operator’s manual.
• Save all warnings and instructions.
1838 - 003 - 09.02.2023 5
