Husqvarna S 138C User manual

S 138C
EN Operator's manual 6-18
BG Ръководство за експлоатация 19-34
CS Návod k použití 35-47
DA Brugsanvisning 48-61
DE Bedienungsanweisung 62-77
EL Οδηγίες χρήσης 78-93
ES Manual de usuario 94-107
ET Kasutusjuhend 108-120
FI Käyttöohje 121-133
FR Manuel d'utilisation 134-148
HR Priručnik za korištenje 149-161
HU Használati utasítás 162-175
IT Manuale dell'operatore 176-189
JA 取扱説明書 190-202
LT Operatoriaus vadovas 203-216
LV Lietošanas pamācība 217-230
NL Gebruiksaanwijzing 231-244
NO Bruksanvisning 245-257
PL Instrukcja obsługi 258-272
PT Manual do utilizador 273-286
RO Instrucţiuni de utilizare 287-300
RU Руководство по эксплуатации 301-316
SK Návod na obsluhu 317-330
SL Navodila za uporabo 331-343
SR Priručnik za rukovaoca 344-357
SV Bruksanvisning 358-370
TR Kullanım kılavuzu 371-383
UK Посібник користувача 384-399

8
7
6
5
2
1
13
10
4
3
9
11
12
1
2 3 4 5 6 7
8 9 10 11 12 13
14 15 16 17
18

19 20
21 22
23 24
25 26

27 28
29 30
31 32
33 34

35 36
A
B
C
37
A
B
C
38
39

Contents
Introduction..................................................................... 6
Safety..............................................................................8
Assembly...................................................................... 14
Operation...................................................................... 14
Maintenance................................................................. 15
Troubleshooting............................................................ 16
Transportation, storage and disposal........................... 16
Technical data.............................................................. 16
Declaration of Conformity............................................. 18
Introduction
Product description
The product is a pedestrian-controlled electrical
dethatcher. The product removes thatch from the lawn
and loosens the soil to let air and water into the lawn.
The thatch is collected in a grass catcher or is released
on to the lawn. The product has 2 types of dethatcher
equipment.
Dethatcher equipment
Refer to
To replace the dethatcher equipment on page
15
for information on how to replace the dethatcher
equipment.
Blade tines
The blade tines remove thatch and cut the grass roots
vertically. Use the blade tines on slopes, terraces and in
soils that have a high quantity of clay. The blade tines let
the water go down into the lawn and prevent that water
collects on the surface
(Fig. 19)
Spring tines
The spring tines carefully remove dead grass and thatch
from the lawn with no damage to the grass roots.
(Fig. 20)
Intended use
Use the product to remove thatch and moss and to
loosen the soil in private gardens. Do not use the
product for other tasks.
Product overview
(Fig. 1)
1. Motor brake handle
2. Upper handle
3. Start inhibitor
4. Power socket
5. Lower handle
6. Cable clamp
7. Grass catcher
8. Rear cover
9. Dethatcher cover
10. Adjustment knob for the work depth
11. Spring tines
12. Hex key
13. Operator's manual
Symbols on the product
(Fig. 2) Warning: Not careful or
incorrect use can result
in injury or death for the
operator or others.
(Fig. 3) Read the operator's
manual and make sure
that you understand the
instructions before you
use this product.
(Fig. 4) Look out for thrown
objects and ricochets.
(Fig. 5) Keep persons and
animals at a safe
distance from the work
area.
(Fig. 6) WARNING - Keep
hands and feet away
from the tines.
62368 - 002 -

(Fig. 7) Disconnect the product
from electrical outlet
before you do
maintenance on the
product. Tines continue
to rotate after the motor
is switched off.
(Fig. 8) Electrical shock hazard.
(Fig. 9) Warning: Do not operate
the product across the
power cord as this
can result in electrical
shock or damage to the
product.
(Fig. 10) This product has
protection against
splashing water.
(Fig. 11) This product is
in accordance with
applicable EC directives.
(Fig. 12) This product conforms
to the applicable UK
regulations.
(Fig. 13) Noise emission to the
environment label as per
EU and UK directives
and regulations, and
New South Wales
legislation "Protection
of the Environment
Operations (Noise
Control) Regulation
2017". The guaranteed
sound power level of the
product is specified in
Technical data on page
16 and on the label.
(Fig. 14) Double insulation.
(Fig. 18) Recycle this
product at a re-
cycling location
for electrical
and electronic
equipment. (Ap-
plies to Europe
only)
(Fig. 15) Start procedure: loosen
start inhibitor, push
motor brake handle
down.
(Fig. 16) Release the motor brake
handle to stop.
(Fig. 17) Scannable code.
Note: Other symbols/decals on the product refer to
certification requirements for some markets.
Product damage
We are not responsible for damages to our product if:
• the product is incorrectly repaired.
• the product is repaired with parts that are not
from the manufacturer or not approved by the
manufacturer.
• the product has an accessory that is not from the
manufacturer or not approved by the manufacturer.
• the product is not repaired at an approved service
center or by an approved authority.
2368 - 002 - 7

Safety
Safety definitions
Warnings, cautions and notes
are used to point out specially
important parts of the manual.
WARNING: Used if
there is a risk of
injury or death for the
operator or bystanders
if the instructions in the
manual are not obeyed.
CAUTION: Used if there
is a risk of damage to the
product, other materials
or the adjacent area if
the instructions in the
manual are not obeyed.
Note: Used to give more
information that is necessary in
a given situation.
General safety instructions
WARNING: Read the
warning instructions that
follow before you use the
product.
•This product is dangerous if
used incorrectly or if you are
not careful. Injury or death can
occur if you do not obey the
safety instructions.
•This product produces an
electromagnetic field during
operation. This field may
under some circumstances
interfere with active or passive
medical implants. To reduce
the risk of serious or fatal
injury we recommend persons
with medical implants to
consult their physician and the
medical implant manufacturer
before operating this product.
•Always be careful and use
your common sense. If you
are not sure how to operate
the product in a special
situation, stop and speak to
your Husqvarna dealer before
you continue.
•Keep in mind that the operator
will be held responsible for
accidents that involve other
persons or their property.
•Keep the product clean. Make
sure that you can clearly read
signs and decals.
•Never allow children or
people unfamiliar with these
instructions to use the
appliance. Local regulations
may restrict the age of the
operator
82368 - 002 -

•Always monitor a person, with
decreased physical capacity or
mental capacity, that uses the
product. A responsible adult
must be there at all times.
•Do not use the product if
you are tired, ill, or under
the influence of alcohol, drugs
or medicine. This has a
negative effect on your vision,
alertness, coordination and
judgment.
•Do not use the product if it is
defective.
•Do not change this product or
use it if it is possible that it has
been changed by others.
Work area safety
WARNING: Read the
warning instructions that
follow before you use the
product.
•Remove objects such as
branches, twigs and stones
from the work area before you
use the product.
•Objects that hit against the
dethatcher equipment can
eject and cause damage to
persons and objects. Keep
bystanders and animals at
a safe distance from the
product.
•Never use the product in bad
weather such as fog, rain,
strong winds, intense cold and
risk of lightning. To use the
product in bad weather or
in moist or wet locations is
tiring. Bad weather can cause
dangerous conditions, such as
slippery surfaces.
•Look out for persons, objects
and situations that can prevent
safe operation of the product.
•Look out for obstacles, such
as roots, stones, twigs, pits
and ditches. Long grass can
hide obstacles.
•To operate the product on
slopes can be dangerous. Do
not use the product on ground
that slopes more than 15°.
•Operate the product across
the face of slopes. Do not
move up and down.
•Be careful when you go near
hidden corners and objects
that prevent a clear view.
Work safety
WARNING: Read the
warning instructions that
follow before you use the
product.
WARNING: Stop the
product, disconnect the
2368 - 002 - 9

power cord and make
sure that the tines have
come to a complete stop
before you touch the
dethatcher equipment.
•Use this product to remove
thatch and moss from grass
lawns only. It is not permitted
to use it for other tasks.
•Use personal protective
equipment. Refer to Personal
protective equipment on page
11 .
•Do not operate the product in
rain or wet conditions. The risk
of electrical shock increases if
water enters the product.
• Do not operate the product
with a damaged power cord.
•Do not operate the
product unless the dethatcher
equipment and all covers
are attached correctly. An
incorrectly attached dethatcher
equipment can come loose
and cause personal injury.
•Make sure that the dethatcher
equipment does not hit objects
such as stones and roots.
This can do damage to the
dethatcher equipment and
bend the motor shaft. A bent
axle causes heavy vibration
and a very high risk that
the dethatcher equipment
becomes loose.
•If the dethatcher equipment
hits an object or if vibrations
occur, stop the product
immediately. Stop the motor
and disconnect the power
cord. Examine the product for
damages. Repair damages or
let an authorised service agent
do the repair.
•Never attach the motor brake
handle permanently to the
handle when the motor is
started.
•Put the product on a stable,
flat surface and start it.
Make sure that the dethatcher
equipment does not hit the
ground or other objects.
•Always stay behind the
product when you operate it.
•Let all the wheels stay on
the ground and keep 2 hands
on the handle when you
operate the product. Keep
your hands and feet away
from the rotating dethatcher
equipment.
•Do not tilt the product when
the motor is started.
•Be careful when you pull the
product rearward.
•Never lift up the product when
the motor is started. If you
must lift the product, first stop
10 2368 - 002 -
