Huvitz CRK-8800 User manual

PRODUCT
Auto
Ref/
Keratomet
er SERVICE MANUAL
DOC No. SCS-I-8RK-009
PREPARE
REVIEW CONFIRM
DATE 2014.07.23
MODEL
CR/CRK 8800,7000P
REVISION
DATE
REVISON PD align USE 2014.07.23
Fault Faulty part Cause
Action
What When
1.
How to align PD

PRODUCT
Auto
Ref/
Keratomet
er SERVICE MANUAL
DOC No. SCS-I-8RK-009
PREPARE
REVIEW CONFIRM
DATE 2014.07.23
MODEL
CR/CRK 8800,7000P
REVISION
DATE
REVISON PD align USE 2014.07.23
1. PD align
1-1) Place PD ruler on the chin rest 1-2) Enter to engineer mode
[PRINT] -> Press [3]and[6] same time
1-3Select “9. PD setup”
1-4) Find base point of the ruler (select
one of right eye position
1-5) Press “ZERO” one time 1-6) Press joystick button once

PRODUCT
Auto
Ref/
Keratomet
er SERVICE MANUAL
DOC No. SCS-I-8RK-009
PREPARE
REVIEW CONFIRM
DATE 2014.07.23
MODEL
CR/CRK 8800,7000P
REVISION
DATE
REVISON PD align USE 2014.07.23
1-7) Find base position + 60mm a
nd press joystick button
（Ex：40(base)+60 = 100）
1-8) Press “CALC” 1-9) Using-(DEC) and +(INC)
make “Slit pitch” same with “C
alc Pitch”
◈When “Calc Pitch” is smaller
than 0.670, Make “Slit Pitch”
as 0.670
1-10) Press “SAVE” then press “EXIT” 1-11) Press “SAVE” again
