Huvitz HOCT-1F/1 User manual

OPTICAL COHERENCE
TOMOGRAPHY
HOCT-1F/1
SERVICE MANUAL

1-------------------------------------------------------------------------------------Optical Coherence Tomography HOCT-1F / 1
■IMPORTANT NOTICE
This product may malfunction due to electromagnetic waves caused by portable personal
telephones, transceivers, radio-controlled toys, etc. Be sure to avoid having objects such
as, which affect this product, brought near the product.
The information in this publication has been carefully checked and is believed to be
entirely accurate at the time of publication. HUVITZ assumes no responsibility, however,
for possible errors or omissions, or for any consequences resulting from the use of the
information contained herein.
HUVITZ reserves the right to make changes in its products or product specifications at
any time and without prior notice, and is not required to update this documentation to
reflect such changes.
■Revision History
Revision
Date
Approval
Description
A
${appDate1}
${app1}
First issued
W2ARAA-17-00002
(2018/01/10)
©2018 HUVITZ Co., Ltd.
38, Burim-ro 170beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14055, Republic of Korea
All rights reserved.
Under copyright laws, this manual may not be copied, in whole or in part, without the prior written consent of
HUVITZ Co., Ltd.

Optical Coherence Tomography HOCT-1F / 1------------------------------------------------------------------------------------- 2
CONTENT
1. SAFETY PRECAUTIONS.............................................................................................................................................4
1.1 Overview ...............................................................................................................................................................4
2. Symbol Information ....................................................................................................................................................5
2.1 Usage Precautions ...............................................................................................................................................7
2.2 Environmental Considerations ...........................................................................................................................10
2.3 Safety Precautions .............................................................................................................................................12
3. INTRODUCTION.........................................................................................................................................................14
3.1 System Outline................................................................................................................................................14
3.2 Intended Use...................................................................................................................................................14
3.3 Classification ...................................................................................................................................................14
3.4 Contraindications ............................................................................................................................................14
3.5 Patient requirements.......................................................................................................................................14
3.6 Operating Principles .......................................................................................................................................15
3.7 Applied Standard List......................................................................................................................................15
4. System Overview ......................................................................................................................................................16
4.1 Configuration and Functions ..............................................................................................................................16
4.2 Optical System....................................................................................................................................................19
4.3 Electrical construction diagram ..........................................................................................................................22
5. Checking and Testing ...............................................................................................................................................30
5.1 OCT checking .....................................................................................................................................................30
5.2 Fundus checking ................................................................................................................................................37
5.3 Alignments & Focusing Test ...............................................................................................................................41
6. Installation Procedure ..............................................................................................................................................45
6.1 System installation..............................................................................................................................................45
6.2 Operation Software.............................................................................................................................................48
6.3 SETUP Mode ......................................................................................................................................................50
7. Maintenance...............................................................................................................................................................53
7.1 After operation ....................................................................................................................................................53
7.2 Cleaning..............................................................................................................................................................55
7.3 Replacement of consumables and fuse ............................................................................................................56
7.4 How to pack the device ......................................................................................................................................57

3-------------------------------------------------------------------------------------Optical Coherence Tomography HOCT-1F / 1
8. Exploded Diagram.....................................................................................................................................................59
8.1 COVER ASSY.....................................................................................................................................................59
8.2 UNCOVER ASSY ...............................................................................................................................................60
8.3 BASE ASSY........................................................................................................................................................61
8.4 PC BOX ASSY....................................................................................................................................................62
8.5 MOVING BASE ASSY........................................................................................................................................63
8.6 HEAD REST ASSY.............................................................................................................................................64
8.7 LCD ASSY ..........................................................................................................................................................65
9. Troubleshooting ........................................................................................................................................................66
10. Replacement ............................................................................................................................................................71
10.1 SMPS ................................................................................................................................................................71
10.2 PC MOTHER BOARD ......................................................................................................................................74
10.3 LCD PANEL ......................................................................................................................................................79
11. Calibration ................................................................................................................................................................85
11.1 System Calibration............................................................................................................................................85
11.2 Device Calibrator ..............................................................................................................................................88
12. Specifications and Accessories............................................................................................................................91
12.1 Standard Accessories.......................................................................................................................................91
12.2 Specifications....................................................................................................................................................92
12.3 Drawings of System..........................................................................................................................................93
13. EMC Information .....................................................................................................................................................94
14. Service Information ................................................................................................................................................96

Optical Coherence Tomography HOCT-1F / 1------------------------------------------------------------------------------------- 4
1. SAFETY PRECAUTIONS
1.1 Overview
Safety is everyone’s responsibility. The safe use of this instrument is largely dependent upon the installers,
users, operators, and managers. It is prerequisite to read and understand these specifications before
installing, using, cleaning, fixing or revising. Fully understanding the whole instructions must be the first
priority. For this reason, the following safety notices have been placed appropriately within the text of this
manual to highlight safety related information or information requiring special emphasis. All users,
operators, and maintainers must be familiar with and pay particular attention to all signs of Warnings and
Cautions.
“Warning” indicates the presence of a hazard that could result in severe personal injury, death or
substantial property damage if ignored.
“Caution” indicates the presence of a hazard that could result in minor injury, or property
damaged if ignored.
This is used to emphasize essential information.
Be sure to read this information to avoid operating the device incorrectly.
!
!
!
WARNING
CAUTION
NOTE

5-------------------------------------------------------------------------------------Optical Coherence Tomography HOCT-1F / 1
2. Symbol Information
The International Electro technical Commission (IEC) has established a set of symbols for medical electronic
equipment which classify a connection or warn of any potential hazards. The classifications and symbols are shown
below.
I and O on power switch represent ON and OFF
Respectively.
Type B Isolated patient connection.
This symbol identifies a safety note. Ensure you understand the
function of this control before using it. Control function is described in
the appropriate User’s or Service Manual.
Identifies the point where the system safety ground is fastened to the
chassis. Protective earth connected to conductive parts of Class I
equipment for safety purposes.
Indicates the Manufacturer
Indicates the date of manufacture
Authorized Representative in the European Community
Temperature Limitation
Keep DRY
Warning: Crushing or insert of hand
UL Mark
CE Mark
Class I Laser Product

Optical Coherence Tomography HOCT-1F / 1------------------------------------------------------------------------------------- 6
CE for RoHS
RoHS Directive Compliance 2011/65/EU
WEEE
indicating separate collection for electrical and electronic equipment

7-------------------------------------------------------------------------------------Optical Coherence Tomography HOCT-1F / 1
2.1 Usage Precautions
This instrument has been developed and tested according to safety standards as well as national and international
standards. This guarantees a very high degree of safety for this device. HUVITZ is legally required to inform the users
of all the information regarding safety. Observance of the instructions is the requirement for the safety. Therefore,
please read carefully all instructions before switching on this instrument. For more detailed information, please contact
our Customer Service Department or one of our local agencies.
.
For use of equipment in rated voltage less than 125Vac, minimum 6A, Type SJT or SVT, 18/3AWG, 10A, max
3.0m long: One end with Hospital Grade Type, NEMA 5-15P Other end with appliance coupler. For use of
equipment in rated voltage less than 250Vac, minimum 6A, Type SJT or SVT, 18/3AWG, 10A, max 3.0m long:
One end terminated with blade attachment plug(HAR) Type, NEMA 6-15P.
Use instrument that comply with IEC60601-1 in the patient environment.[The figure below show]
If and instrument that does not comply with IEC 60601-1 is to be used, use an isolation transformer.
If a person handling a conductive part of the system comes into contact with a patient at the same time, hazard
may occur due to leakage current exceeding the value specified in the applicable standard. Be careful not to
touch patients when connecting or removing the power plug or cable connectors.
!
CAUTION
!
CAUTION

Optical Coherence Tomography HOCT-1F / 1------------------------------------------------------------------------------------- 8
During the Anterior segment image operation, pull the joystick toward the operator before adjusting the
alignment. Move the body to align patient’s eye. Move the body slowly while watching patient’s eye and body,
because working distance is just 15mm that the front lens is very close to patient's eye.
This instrument includes lithium battery. This hazardous materials need to be disposed of properly to limit
environmental pollution. please contact to the professional waste disposal company
!
CAUTION
!
CAUTION

9-------------------------------------------------------------------------------------Optical Coherence Tomography HOCT-1F / 1
The equipment is a Class I LED Product. The LED used for the equipment is safe under expected use
conditions including situation such as looking into the LED using optical equipment.
However, observe the following precautions when using the equipment
Do not direct LED beams to human eyes when unnecessary.
Do not look into the objective lens for a prolonged time..
Class 3R invisible LED radiation when Optical system subassembly open.
Avoid exposure to the beam.
The longer the duration of exposure and the greater the number of pulses, the greater the risk of
ocular damage. Exposure to light from this instrument when operated at maximum output will
exceed the safety guideline after 9.9 x 107 sec for Retina IR, 5.3 x 107 sec for Working dot(Manual
Focusing), 4.1 x 107 sec for Kerato ring(Auto / Manual Tracking), 9.5 x 107 sec for Kerato
focus(Auto/Manual Tracking), 1.0 x 108 sec for Split focus(Optimizing), 9.1 x 105 sec for external
fixation lamp, 4.8 x 107 sec for SLD Laser(OCT scanning), 1,936,114 pulses for the light source of
fundus image capture
Note 1: The exposure time and number of pulses from all light sources is cumulative and additive.
Note 2: If the intensity of any of the light sources is reduced to 50% of the maximum intensity, the exposure time or
number of pulses for that light source to reach the exposure guideline is doubled. This linear relationship can be
used to determine the time to reach the exposure guideline for the combination of light sources at various intensity
settings.
Note 3: The weighted retinal radiant exposure guideline is 10 J/cm2
<Spectrum output of all light source during measurement (maximum light intensity)>
<Relationship between fundus flash level and maximum light intensity>
!
CAUTION

Optical Coherence Tomography HOCT-1F / 1------------------------------------------------------------------------------------- 10
2.2 Environmental Considerations
Avoid the following environments for operation or storage:
Where the instrument is exposed to water vapor.
Don’t operate the instrument with wet hands Indoor use only.
Where the instrument is exposed to direct sunlight.
A place where the equipment can be exposed to direct ultraviolet.
Where there are big changes in temperature.
Optimal temperature range for normal operation is from 10C to 35C
(Humidity : 30 ~ 90%).
Where there is hot equipment nearby.
Where the humidity is extremely high or there is a ventilation problem.
Where the instrument is exposed to excessive shocks or vibrations.
Where the instrument is exposed to chemical material or explosive gas.
Be cautious so that things like dust and metal do not fall inside the instrument.
Don’t disassemble or open the product. HUVITZ does not take responsibility for the
possible problems

11 -------------------------------------------------------------------------------------Optical Coherence Tomography HOCT-1F / 1
Be careful not to block the fan of the instrument.
Don’t plug the AC power cable into the outlet unless all parts of the instrument are
completely connected. Otherwise, it will cause severe damage on the instrument.
Pull out the power cable with holding the plug, not the cord.
To avoid risk of electric shock, this equipment must only be connected to supply
mains with protective earth.
For the normal operation of the instrument, please keep the ambient temperature is 10℃ ~ 35℃, humidity is 30% ~
90% and atmospheric pressure is 800 ~ 1060hpa. For the Transportation of the instrument, please keep the ambient
temperature is -40℃ ~ 70℃, humidity is 10% ~ 95% and atmospheric pressure is 500 ~ 1060hpa. For the Storage
of the instrument, please keep the ambient temperature is -10℃ ~ 55℃, humidity is 10% ~ 95% and atmospheric
pressure is 700 ~ 1060hpa. Avoid environments where the equipment is exposed to excessive shocks or vibrations.

Optical Coherence Tomography HOCT-1F / 1------------------------------------------------------------------------------------- 12
2.3 Safety Precautions
1. This is an electric medical device. Use is limited to doctors or persons qualified by the law of each country
2. Do not make a diagnosis base on a single captured image. Doctors are responsible for making the final diagnosis
based on the present and past medical records of the patient such as captured images. Without sufficient
information, proper diagnosis may not be made.
3. When instrument is send back to A/S center for repair or maintenance, or before authorized service man is arrived
at the place for repair or maintenance, wipe the surfaces of the instrument (especially, the areas that come into
contact with the patient) with a clean cloth dampened with rubbing alcohol.
4. This equipment must not be used in an area that is in danger of explosions and in the presence of flammable,
explosive, or volatile solvent such as alcohol, benzene or similar chemicals.
5. Do not place or store this instrument in humid area. Do not expose the device to water splashes, dripping water,
or sprayed water. Do not place containers with fluids, liquids, or gases on top of this instrument.
6. The instrument must be operated by a trained and qualified person or under his or her supervision.
7. Repair of this instrument must be conducted by HUVITZ’s service technicians or other authorized persons.
8. Maintenance by users must observe the User’s Manual and Service Manual. Any additional maintenance may
only be performed by HUVITZ’s service technicians or other authorized persons.
9. Manufacturers are responsible for the safety, reliability, and performance of this instrument only when the
following requirements are fulfilled.
(1) When the instrument has been installed in a proper area, following the manual.
(2) When the instrument has been operated and maintained according to the manual and service manual.
10. Manufacturers are not responsible for the damages caused by unauthorized alterations. Such tampering will forfeit
any rights to receive services during the term of guarantee.
11. This instrument must be connected with the accessories supplied by HUVITZ. If you are to use other accessories,
their safety or usability must be checked and proved by their manufacturers or HUVITZ.
12. Only those who have undergone proper training and instructions are authorized to install, use, operate, and
maintain this instrument.
13. Keep the User’s Manual and Service Manual in a place easily accessible at all times for persons operating and
maintaining the equipment.
14. Do not apply excessive force to cable connections. If the cable does not connect easily, make sure that the
connector (plug) is appropriate for the receptacle (socket). If you caused any damage to a cable connector(s) or
receptacle(s), let the damage(s) be repaired by an authorized service technician.
15. Please do not pull on any cable. Always grab the plug when disconnecting cables.

13 -------------------------------------------------------------------------------------Optical Coherence Tomography HOCT-1F / 1
16. Before you use, check the exterior of the instrument and its conditions.
17. Do not block any ventilation outlet necessary for proper heat dissipation.
18. If smoke, sparks or any abnormal noise or smell is noticed coming from the instrument, please switch the power
off immediately and pull out the plug.
19. When you carry this product, please use a hand cart. If you want to move the product to other area, please
contact customer service center.
20. To avoid the risk of electric shock, this instrument must only be connected to protective earth.
21. Do not place the instrument where it is difficult to operate the disconnecting device. (disconnecting device: power
cable)
22. The equipment may be impaired if it is used in a manner not specified by the manufacturers or manual.
23. External equipment intended for connection to signal input, signal output or other connectors of this instrument,
shall comply with relevant IEC Standard (e.g., IEC60950 for IT equipment and IEC60601-1 series for medical
electrical equipment). In addition, all such combination-system-shall comply with the standard IEC60601-1
harmonized national standard or the combination. If, in doubt, contact qualified technician or your local
representative. The operator should not touch the patient and accessible male parts of the SIP/SOP connectors
simultaneously.
24. When you carry this product, please hold on left(A) and right(B) bottom of the product.
.

Optical Coherence Tomography HOCT-1F / 1------------------------------------------------------------------------------------- 14
3. INTRODUCTION
3.1 System Outline
The Huvitz Optical Coherence Tomography HOCT-1F, HOCT-1 is a non-contact, high-resolution tomographic and
bio-microscopic imaging device. It is indicated for in-vivo viewing, axial cross-sectional and three dimensional
imaging, color fundus imaging(HOCT-1F only) and measurement of posterior ocular structures, including the retina,
retinal nerve fiber layer, ganglion cell plus inner plexiform layer, ganglion cell complex, macula, optic nerve head. It
is also indicated for in-vivo viewing, axial cross-sectional and three dimensional imaging of anterior ocular
structures, including the cornea
3.2 Intended Use
The HOCT-1F, HOCT-1 is intended for use as a diagnostic device to aid in the check and management of ocular
diseases such as macular holes, cystoid macular edema, diabetic retinopathy, aged related macular degeneration,
and so on, which are occurred at a macular, an optic disk, an inner structure of retina, and a cornea
3.3 Classification
•Classification of product : Class II according to Annex IX (Rule 10) of the Medical Device Directive 93/42/EEC as
amended by 2007/47/EC
•Resistance against electric shock : Class I (earthed)
•Protection class against electric : Type B(Head rest, chinrest paper)
•Classification of Laser Product : Class 1 (laser based on IEC 60825-1:2014 Standard)
3.4 Contraindications
- Patients who are hypersensitive to light.
- Patients who recently underwent photodynamic therapy
- Patients taking medication that causes photosensitivity
3.5 Patient requirements
The patient who undergoes and examination by this instrument must maintain concentration for a few minutes
and adhere to the following instructions;
- After his/her face to the chinrest, forehead rest.
- Keep the eye open
- Understand and follow instructions when undergoing an examination.
If the patient does not conform to these conditions, it is not possible to take a picture correctly

15 -------------------------------------------------------------------------------------Optical Coherence Tomography HOCT-1F / 1
3.6 Operating Principles
3.6.1 Fundus image
The anterior of an eye is illuminated by IR light, the posterior of an eye is illuminated by an infrared light and a white
LED, of which lightings are emitted by the fundus illumination optical system. The fundus observation/photography
optical system forms and makes an image with image sensors, which images are observed and manipulated with
the display panel.
3.6.2 The anterior segment/fundus tomogram
Formation of anterior chamber cross-sectional image, retinal cross-sectional image, and fundus image
To form retinal cross-sectional images (OCT images) and fundus images (OCT Phase Fundus images), the system
main body scans light over the eye to obtain interference light. The obtained interference light is dispersed into
individual wavelengths and detected by the line image sensor. The detected light is converted to signals, and then
computed to form images. With the anterior segment adapter (optional), a fundus tomogram can be formed
3.7 Applied Standard List
•IEC/EN 60601-1: MEDICAL ELECTRICAL EQUIPMENT
–Part 1: General requirements for safety
•IEC/EN 60601-1-2: Medical electrical equipment Part1: General requirements for safety
- Collateral Standard: Electromagnetic Compatibility-Requirements and tests
•ISO15004-1: Ophthalmic instruments
- Fundamental requirements and test methods
General Requirements applicable to all Ophthalmic instrument
•ISO15004-2: Ophthalmic instruments-Fundamental requirements and test methods
–Part 2: Light hazard protection
•ISO 10940: Ophthalmic instruments - Fundus Cameras
•ISO 16971: Ophthalmic instruments - Optical Coherence Tomography for the posterior segment of the human
eye

Optical Coherence Tomography HOCT-1F / 1------------------------------------------------------------------------------------- 16
4. System Overview
4.1 Configuration and Functions
■ Front View
No
Part
Name
Description
1
Display
LCD
Monitor for displaying captured image and user interface icon.
2
Body
Chinrest button
Button for moving chinrest up and down.
3
Joystick
Joystick for aligning body to patient’s eye.
Button for capturing image.
4
User Lock
Lock for fixing body to base frame.
5
OPT button
Button for optimizing OCT signal
6-1
6-2
Align index mark
Mark for indicating center of body and base.
7
Base
Power button
Button for turning power of internal PC on/off.
When the power is on, white light is lit.
9-1
Power switch
Switch for power on/off.
9-2
Power inlet
Inlet for connecting power cable.
10
Headrest
Eye level mark
Mark for indicating base height of patient’s eye.
11
Body
Heat vent
Window for emitting internal heat.

17 -------------------------------------------------------------------------------------Optical Coherence Tomography HOCT-1F / 1
■ Rear View

Optical Coherence Tomography HOCT-1F / 1------------------------------------------------------------------------------------- 18
No
Part
Name
Description
1
Headrest
Forehead rest
Rubber for fix patient’s head.
2
External LED
External LED for fixing patient’s eyes.
3
Chinrest
For fixing patient’s chin.
4-1
Body
Objective lens
Lens for passing illumination light from body and
reflected light from patient’s eye.
4-2
Mirering Focus LED
LEDs for checking working distance.
5
Headrest
Objective lens cap
Cap for protecting objective lens.
8
Base
External port
Port for communicating internal or external device.
8-1
RS-232 port
Port for communicating internal PC board and main
board.
8-2
RGB port
Port for external display device.
8-3
DP port
Port for communicating external DP device.
8-4
LAN port
Port for external network (2 ports)
8-5
USB port
Port for internal or external USB device (4 ports)
■ Bottom View
No
Part
Name
Description
1
Base
Packing lock
Lock for fixing body and base during transportation. (2 points)

19 -------------------------------------------------------------------------------------Optical Coherence Tomography HOCT-1F / 1
4.2 Optical System
②
③
○
24
○
19
⑩
⑨
⑥
⑤
⑧
⑦
⑮
⑬
○
17
⑪
④
○
18
○
16
⑭
○
25
○
23
○
22
○
21
○
20
○
29
○
30
○
36
○
34
○
33
○
35
○
32
⑫
○
27
○
28
○
26
①
○
31
①
②
⑥
⑦
