Huvitz HDR-7000 User manual

------------------------------------------------------------------ HDR-7000 Operator’s Manual 1
Operator’s Manual
Digital Refractor HDR-7000
ОсОО «МЕДОФФ» www.medoff.net

2 HDR-7000 Operator’s Manual ------------------------------------------------------------------
IMPORTANT NOTICE
This product may malfunction due to electromagnetic waves caused by portable
personal telephones, transceivers, radio-controlled toys, etc. Be sure to avoid
having objects such as, which affect this product, brought near the product.
The information in this publication has been carefully checked and is believed to be
entirely accurate at the time of publication. HUVITZ assumes no responsibility,
however, for possible errors or omissions, or for any consequences resulting from
the use of the information contained herein.
HUVITZ reserves the right to make changes in its products or product
specifications at any time and without prior notice, and is not required to update
this documentation to reflect such changes.
© 2008 HUVITZ Co., Ltd.
689-3, Geumjeong-dong, Gunpo-si, Gyeonggi-do,
435-862, Republic of Korea
All rights are reserved.
Under copyright laws, this manual may not be copied, in whole or in part, without
the prior written consent of HUVITZ Co., Ltd.
ОсОО «МЕДОФФ» www.medoff.net

------------------------------------------------------------------ HDR-7000 Operator’s Manual 3
CONTENTS
1. Introduction............................................................................................................ 9
1.1. Outline of the Instrument ..................................................................................... 9
1.2. Classification...................................................................................................... 10
1.3. Certification........................................................................................................ 10
2. Safety Information ............................................................................................... 11
2.1. Introduction ........................................................................................................ 11
2.2. Safety Symbols.................................................................................................. 12
2.3. Environment Factors.......................................................................................... 13
2.4. Safety Precaution .............................................................................................. 15
3. Features................................................................................................................ 19
4. Notes for Using the Instrument .......................................................................... 21
5. Configurations ..................................................................................................... 22
5.1. Digital Refractor ................................................................................................. 22
5.1.1. Detail Explanation...................................................................................... 23
5.2. Junction Box (JB)............................................................................................... 24
5.2.1. Detail Explanation...................................................................................... 25
5.3. Operation Panel (OP) ........................................................................................ 26
5.3.1. Detail Explanation: Front side.................................................................... 27
5.3.2. Detail Explanation: Rear side .................................................................... 28
5.4. Various Accessories........................................................................................... 29
5.4.1. Accessories for Digital Refractor ............................................................... 29
ОсОО «МЕДОФФ» www.medoff.net

4 HDR-7000 Operator’s Manual ------------------------------------------------------------------
5.4.2. Accessories for Operation Panel and Junction Box...................................30
5.4.3. Optional accessories..................................................................................31
5.5. System Installation .............................................................................................32
6. Basic Operations..................................................................................................33
6.1. Operation of the Keypad Buttons .......................................................................33
6.2. Operation of the Touch Screen Buttons .............................................................44
7. Menu Selection.....................................................................................................50
7.1. Test Result .........................................................................................................51
7.2. System Config....................................................................................................58
7.3. Edit program.......................................................................................................59
7.4. Edit Test .............................................................................................................60
7.5. Edit Message .....................................................................................................61
7.6. Gallery................................................................................................................62
8. Configuring the System.......................................................................................63
8.1. Button operations...............................................................................................64
8.2. Description of Options........................................................................................66
8.2.1. Page 1 - LENS & DATA MANIPULATION (1).............................................66
8.2.2. Page 2 - LENS & DATA MANIPULATION (2).............................................67
8.2.3. Page 3 – TEST & DATA MANIPULATION (1) ............................................69
8.2.4. Page 4 – TEST & DATA MANIPULATION (2) ............................................71
8.2.5. Page 5 - TEST ENVIRONMENT................................................................73
8.2.6. Page 6 - PRINT OPTION...........................................................................74
9. Editing User-Designable Program & Test ..........................................................77
ОсОО «МЕДОФФ» www.medoff.net

------------------------------------------------------------------ HDR-7000 Operator’s Manual 5
9.1. Editing User-Designable Program ..................................................................... 77
9.2. Editing User-Designable Unit Test..................................................................... 88
10. Editing Messages ................................................................................................ 95
10.1. Introduction ........................................................................................................ 95
10.2. How to Use Virtual Keyboard............................................................................. 96
10.3. Editing Program Name .................................................................................... 100
10.4. Editing Test Name............................................................................................ 101
10.5. Editing Guide Message ................................................................................... 102
10.6. Editing Shop Name.......................................................................................... 104
11. Examination Modes ........................................................................................... 105
11.1. Why Examination Mode is Important? ............................................................. 107
11.1.1. Scenario .................................................................................................. 107
11.2. Data Duplication .............................................................................................. 110
11.3. Warnings on Mode............................................................................................111
11.4. Measuring Near and Far Vision....................................................................... 112
11.5. Other Temporal Examination Modes ............................................................... 115
11.5.1. PRESET Mode ........................................................................................ 115
11.5.2. AUX OFF Mode ....................................................................................... 116
11.5.3. ADD OFF Mode....................................................................................... 117
11.5.4. PRISM OFF Mode ................................................................................... 118
12. Standard Program & Functions........................................................................ 119
12.1. Starting the System-Providing STANDARD Program ...................................... 119
12.1.1. Adjustment of the SPH-CYL-AXIS Values for Right Eye ......................... 120
ОсОО «МЕДОФФ» www.medoff.net

6 HDR-7000 Operator’s Manual ------------------------------------------------------------------
12.1.2. Jackson Cross Cylinder Test(AXIS) for Right Eye ...................................121
12.1.3. Jackson Cross Cylinder Test(CYL) for Right Eye ....................................122
12.1.4. Red/Green Test for Right Eye ..................................................................123
12.1.5. Checking The Visual Acuity for Right Eye................................................124
12.1.6. Adjustment of the SPH-CYL-AXIS Values for Left Eye ............................125
12.1.7. Jackson Cross Cylinder Test(AXIS) for Left Eye......................................125
12.1.8. Jackson Cross Cylinder Test(CYL) for Left Eye .......................................126
12.1.9. Red-Green Test for Left Eye ....................................................................126
12.1.10. Checking The Visual Acuity for Left Eye ..................................................126
12.1.11. Balancing Binocular Vision ......................................................................126
12.1.12. Checking The Visual Acuity for Binocular Vision......................................127
12.1.13. Horizontal Coincidence Test at Far ..........................................................128
12.1.14. Vertical Coincidence Test at Far ..............................................................128
12.1.15. Near Addition Test with Fused Cross Cylinder Lenses ............................129
12.1.16. Near Visual Acuity Test ............................................................................130
12.1.17. Near Horizontal/Vertical Von Graefe Test ................................................131
13. System-Providing Unit Tests ............................................................................133
13.1. Near Visual Acuity Test ....................................................................................136
13.2. Near Point of Convergence Test ......................................................................136
13.3. Near Point of Accommodation Test ..................................................................138
13.4. Near Addition Test with Fused Cross Cylinder Lenses ....................................139
13.5. Negative Relative Accommodation Test...........................................................141
13.6. Positive Relative Accommodation Test ............................................................142
13.7. Negative Relative Convergence Test...............................................................144
ОсОО «МЕДОФФ» www.medoff.net

------------------------------------------------------------------ HDR-7000 Operator’s Manual 7
13.8. Positive Relative Convergence Test ................................................................ 145
13.9. Cylinder Axis Test ............................................................................................ 147
13.10. Cylinder Power Test......................................................................................... 149
13.11. Red/Green Test................................................................................................ 150
13.12. Jackson Cross Cylinder Test ........................................................................... 151
13.13. Dual Cross Cylinder Test ................................................................................. 153
13.14. Cross Grid Test for Distance............................................................................ 155
13.15. Dominant Eye Test for Phoria .......................................................................... 157
13.16. Horizontal Maddox Test ................................................................................... 157
13.17. Vertical Maddox Test........................................................................................ 159
13.18. Polarized Binocular Balance Test .................................................................... 161
13.19. Polarized Red/Green Test................................................................................ 163
13.20. Worth 4 Dots Test ............................................................................................ 165
13.21. Schober Test.................................................................................................... 167
13.22. Horizontal Von Graefe Test.............................................................................. 169
13.23. Vertical Von Graefe Test .................................................................................. 172
13.24. Horizontal Coincidence Test ............................................................................ 173
13.25. Vertical Coincidence Test................................................................................. 175
13.26. Polarized Cross Test........................................................................................ 177
13.27. Polarized Cross Test with Fixation Point.......................................................... 179
13.28. Stereo Test....................................................................................................... 183
13.29. Minute Stereo Test ........................................................................................... 184
14. Examination Results and Printout ................................................................... 187
14.1. How to Print ..................................................................................................... 187
ОсОО «МЕДОФФ» www.medoff.net

8 HDR-7000 Operator’s Manual ------------------------------------------------------------------
14.2. Print on the Paper ............................................................................................188
14.3. Print on the Screen ..........................................................................................195
15. Maintenance .......................................................................................................196
15.1. Replacing Printing Paper .................................................................................196
15.2. Replacing Fuse ................................................................................................197
15.3. Cleaning ...........................................................................................................198
15.4. Storage.............................................................................................................198
15.5. Disposal ...........................................................................................................199
16. Troubleshooting .................................................................................................200
16.1. Digital Refractor doesn’t work at all..................................................................200
16.2. Refractor Body makes noisy sound while performing power-on self-test ........200
16.3. Operation Panel displays empty screen ..........................................................200
16.4. Operation Panel doesn’t print out ....................................................................200
16.5. Chart presenting device doesn’t respond to Operation Panel .........................201
16.6. Transferred measurement from auto ref/keratometer or auto lensmeter are not
received by Operation Panel ........................................................................................201
16.7. All the polarization tests are not working..........................................................202
17. Specifications.....................................................................................................203
18. Components And Options.................................................................................205
18.1. Standard Package Components ......................................................................205
18.2. Optional interface Package..............................................................................206
19. Service Information............................................................................................207
ОсОО «МЕДОФФ» www.medoff.net

------------------------------------------------------------------ HDR-7000 Operator’s Manual 9
1. Introduction
1.1. Outline of the Instrument
The HUVITZ Digital Refractor HDR-7000 system is a computerized auto refractor
used for subjective refraction by regarding the patient’s accommodation power and
facilities. Also the Digital Refractor is used for detecting and measuring any
anomalies in binocular vision such as muscle balance, binocular balance,
aniseikonia, fusion, and stereopsis. The subjective refraction can be practiced on
the basis of objective refraction that is done by using an Auto Ref/Keratometer(RK)
connected to Digital Refractor. The examiner can do their optometric practice in
pretty short period of time with ease with the aid of fully integrated and automated
Digital Refraction System where every instrument for the refraction is interfaced
and controlled by one touch of button on the Digital Refractor.
HDR-7000 system includes a refractor body, an operation panel, and a junction
box.
The refractor body has more than a hundred lenses and serves as an automatic
lens-loading unit. It is connected to the operation panel via the junction box and is
controlled by the operation panel.
The operation panel is the main controller of HDR-7000 system. It controls the
refractor body, chart-presenting device, and also receives data transmitted from
Auto Ref/Keratometer(RK), Auto Lensmeter(LM), or a PC interfaced with Digital
Refraction System. And also it has a built-in thermal printer with it.
The junction box serves as a power supply to the Digital Refractor and the
Operation Panel. And it provides communication ports for interfaced instruments
such as Chart Projector or Auto Ref/Keratometer.
ОсОО «МЕДОФФ» www.medoff.net

10 HDR-7000 Operator’s Manual ------------------------------------------------------------------
1.2. Classification
Classification Under the Provision if 93/42/EEC (MDD): Class I
Protection Against Electrical Shock: Class I
Applied Parts: Type B applied parts.
Protection against harmful ingress of water: Ordinary, IPX0
Degree of safety in the presence of a flammable anesthetics mixture with air
or with oxygen or with nitrous oxide: Not suitable for use in the presence of a
flammable anesthetics mixture with air or with oxygen or with nitrous oxide.
Mode of Operation: Continuous
1.3. Certification
UL60601-1
CAN/CSA C22.2
NO.601.1
MEDICAL EUIPMENT
WITH RESPECT TO ELECTRIC SHOCK
FIRE AND MECHANICAL HAZARDS ONLY
IN ACCORDANCE WITH UL 2601-1, AND
CAN/CSA C22.2 NO.601.1
(This applies only to the instrument that has the certification symbol printed explicitly on
the product label.)
MEDICAL EUIPMENT
CLASS I WITH MEASURING FUNCTION (MDD 93/42/EEC)
ОсОО «МЕДОФФ» www.medoff.net

------------------------------------------------------------------ HDR-7000 Operator’s Manual 11
2. Safety Information
2.1. Introduction
Safety is everyone’s responsibility. The safe use of this equipment is largely
dependent upon the installer, user, operator, and maintainer. It is imperative that
personnel study and become familiar with this entire manual before attempting to
install, use, clean, service or adjust this equipment and any associated accessories. It
is paramount that the instructions contained in this manual are fully under stood and
followed to enhance safety to the patient and the user/operator. It is for this reason
that the following safety notices have been placed appropriately within the text of this
manual to highlight safety related information or information requiring special
emphasis. All user, operators, and maintainers must be familiar with and pay particular
attention to all warning and cautions incorporated herein.
“Warning” indicates the presence of a hazard that could result in severe personal injury,
death or substantial property damage if ignored.
NOTE
“Note” describes information for the installation, operation, or maintenance of which is
important but hazard related if ignored.
“Caution” indicates the presence of a hazard that could result in minor injury, or
property damaged if ignored.
!
W
ARNING
!CAUTION
ОсОО «МЕДОФФ» www.medoff.net

12 HDR-7000 Operator’s Manual ------------------------------------------------------------------
2.2. Safety Symbols
The International Electro technical Commission (IEC) has established a set of
symbols for medical electronic equipment, which classify a connection or warn of any
potential hazard. The classifications and symbol s are shown below.
Save these instructions
High voltage.
Type B Isolated patient connection.
This symbol identifies a safety note. Ensure you understand
the function of this control before using it. Control function is
described in the appropriate User’s or Service Manual.
Manufactured by xxxx (year).
Identifies the point where the system safety ground is
fastened to the chassis. Protective earth connected to
conductive parts of Class I equipment for safety purposes.
ОсОО «МЕДОФФ» www.medoff.net

------------------------------------------------------------------ HDR-7000 Operator’s Manual 13
2.3. Environment Factors
Avoid the following environments for operation or storage:
Where the equipment is exposed to water vapor.
Don’t operate equipment with a wet hand.
Where the equipment is exposed to direct sunlight.
Where the temperature changes extremely.
Normal operating temperature range is from 10℃to
40℃, Humidity is from 30% to 75%.
Where it is near the heat equipment.
Where the humidity is extremely high or there is a
ventilation problem.
Where the equipment is subject to excessive shocks or
vibrations.
ОсОО «МЕДОФФ» www.medoff.net

14 HDR-7000 Operator’s Manual ------------------------------------------------------------------
Where equipment is exposed to chemical material or
explosive gas.
Be careful not to be inserted dust, especially, metal.
Don’t disassemble the product or open.
We aren’t responsible for it for nothing.
Be careful not to close the fan located on the lateral or
rear side of the equipment.
Don’t plug the AC power cord into the outlet before the
connection between devices of the equipment is
completed. This can generate the defect.
Pull out the power cord with holding the plug, not the
cord.
Avoid places where the ambient temperature falls below 10℃or exceeds 40℃for
normal operation, or below –10℃or exceeds 40℃(14℉-104℉) for transportation and
storage. Humidity should be maintained between 30 and 75% for normal operation,
transportation and storage. Avoid environments where the equipment is exposed to
excessive shocks or vibrations.
ОсОО «МЕДОФФ» www.medoff.net

------------------------------------------------------------------ HDR-7000 Operator’s Manual 15
2.4. Safety Precaution
This equipment has been developed and tested according to safety standards as well
as national and international standards. This guarantees a very high degree of safety
for this device. The legislator expects us inform the user expressively about the safety
aspects in dealing with the device. The correct handling of this equipment is
imperative for its safe operation. Therefore, please read carefully all instructions
before switching on this device. For more detailed information, please contact our
Customer Service Department or one of our authorized representatives.
1. This equipment must not be used (a) in an area that is in danger of explosions
and (b) in the presence of flammable, explosive, or volatile solvent such as
alcohol, benzene or similar chemicals.
2. Do not put or use this device in humid rooms. Humidity should be maintained
between 30 and 75% for normal operation. Do not expose the device to water
splashes, dripping water, or sprayed water. Do not place containers containing
fluids, liquids, or gases on top of any electrical equipment or devices.
3. The equipment must be operated only by, or under direct supervision of a
properly trained and qualified person.
4. Modifications of this equipment may only be carried out by Huvitz’s service
technicians or other authorized persons.
5. Customer maintenance of this equipment may only be performed as stated in
the Operator’s Manual and Service Manual. Any additional maintenance may
only be performed by Huvitz’s service technicians or other authorized persons.
6. The manufacturer is only responsible for effects on safety, reliability, and
performance of this equipment when the following requirements are fulfilled: (1)
The electrical installation in the respective room corresponds to the
specifications stated in this manual and (2) This equipment is used, operated,
and maintained according to this manual and Service Manual.
7. The manufacturer is not liable for damage caused by unauthorized tampering
ОсОО «МЕДОФФ» www.medoff.net

16 HDR-7000 Operator’s Manual ------------------------------------------------------------------
with the device(s). Such tampering will forfeit any right to claim under warranty.
8. This equipment may only be used together with accessories supplied by Huvitz.
If the customer makes use of other accessories, use them only if their safe
usability under technical aspect has been proved and confirmed by Huvitz or
the manufacturer of the accessory.
9. Only the person who has undergone proper training and instructions is
authorized to install, use, operate, and maintain this equipment.
10. Keep the Operator’s Manual and Service Manual in a place easily accessible
at all times for persons operating and maintaining the equipment.
11. Do not force cable connections. If a cable does not connect easily, be sure that
the connector (plug) is appropriate for the receptacle (socket). If you cause any
damage to a cable connector(s) or receptacle(s), let the damage(s) be repaired
by an authorized service technician.
12. Please do not pull on any cable. Always hold on to the plug when disconnect
cables.
13. This equipment may be used for the international application related to Visual
Acuity Test, Astigmatism Test, Phoria Test, Stereo Vision Test according to this
manual.
14. Before every operation, visually check the equipment for exterior mechanical
damage(s) and for proper function.
15. Do not cover any ventilation grids or slits.
16. Immediately turn off and unplug any equipment that gives off smoke, sparks,
strange noises, or odors.
17. Battery Serving: Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
ОсОО «МЕДОФФ» www.medoff.net

------------------------------------------------------------------ HDR-7000 Operator’s Manual 17
18. "Use only with Huvitz Co., Ltd. Model Digital Refractor HDR-7000(JB) Power
supply" when Operating the HDR-7000 and HDR-7000(OP).
19. For Instruments with 115 or 230 input Voltage Switch, be sure to set the input-
voltage switch to the voltage of the area where the instruments is being used.
Otherwise, it may result in fire or electric shock.
20. Be sure to disconnect power cord before connecting or disconnecting the
cables (especially cables from HDR-7000(JB) to refractor body). Otherwise,
the cable may be damaged, which may result in fire or electric shock on the
circuitry.
21. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to other devices in the vicinity. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to other devices, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving device
-Increase the separation between the equipment
-Connect the equipment into an outlet on a circuit different from that to
which the other device(s) are connected
-Consult the manufacturer or field service technician for help
22. "External equipment intended for connection to signal input, signal output or
other connectors, shall comply with relevant IEC standard (e.g., IEC 60950 for
IT equipment and IEC 60601 series for medical electrical equipment). In
addition, all such combinations - systems - shall comply with the standard IEC
60601-1-1, Safety requirements for medical electrical systems. Any person
who connects external equipment to signal input, signal output or other
connectors has formed at system and is therefore responsible for the system to
comply with the requirements of IEC60601-1-1. If, in doubt, contact qualified
technician or your local representative." (Or some cases, for example LCD
Monitor, "This device is intended to connect to the medical device only, which
complies with standards of IEC 60601 series.")
ОсОО «МЕДОФФ» www.medoff.net

18 HDR-7000 Operator’s Manual ------------------------------------------------------------------
23. Do not touch signal input/signal output and patient simultaneously (example,
Ref. Body and OP connectors of DIGITAL REFRACTOR HDR-7000, RS-232C
of DIGITAL REFRACTOR HDR-7000(OP) and connectors of Converter Box).
Digital Refractor is heavy, so please fix it on the unit table not to be moved.
Otherwise, heavy equipment crash to fall examinee. As a result, examinee may be
hurt.
To perform automatic POST (Power on Self Test), Digital Refractor moves left and
right side, To avoid injury of examinee, please keep examinee from Digital
Refractor at least 20cm or more during POST initialization.
Do not place your hand or finger between the left and the right side of Digital
Refractor. Also ensure that the examinee does not place his/her hand or fingers
there either. Otherwise, hand or fingers may be hurt.
Digital Refractor HDR-7000(JB) does NOT support rack installation nor wall-
mount installation. Any other device for Digital Refractor HDR-7000(JB)
installation should be compliant with relevant IEC standard.
Do NOT use 200-240 Vac power input for HDR-7000(JB) in the region of North
America under the authority of UL.
!CAUTION
!CAUTION
!CAUTION
!CAUTION
!CAUTION
ОсОО «МЕДОФФ» www.medoff.net

------------------------------------------------------------------ HDR-7000 Operator’s Manual 19
3. Features
1. Using standard protocol CAN, all appliances are connected by daisy-chain line.
As a result, HDR-7000 system makes office environment more clean and
modest.
2. Because 1 or more(up to 8) HDR-7000 system and 1 or more(up to 4 each)
LM/RK are connected without any additional equipment, high utilization and
low cost can be achieved.
3. Compatibility between Huvitz products enables to manage patients’ data more
easily. For example, not only S/C/A value but also KER, PD data are gathered
automatically from RK. Also S/C/A value, prism, additional power data are
gathered automatically from LM. All of these data are presetting to the HDR-
7000 system without manual control.
4. HDR-7000 system supports near PD (48~80mm) and near working distance
(50~74cm), so you can execute perfect near vision tests.
5. Separated Dual Cross Cylinder lens and automatic occlusion during lens
change makes more accurate test result.
6. For accurate Phoria and Strabismus test, HDR-7000 system support prism
measurement by 0.1D unit up to 20D unit. Also automatic occlusion during
prism change minimizes the examinee’s eye adaptation.
7. On-line guide assist examiners to finish test fast and convenient.
8. To analyze result at a glance, HDR-7000 system supports table and graphic
result display facilities.
9. Built-in high-speed printer saves additional space to install printer equipments
and prints test results extremely fast.
10. PRESET faculty defers physical lens change until all the necessary lenses are
ОсОО «МЕДОФФ» www.medoff.net

20 HDR-7000 Operator’s Manual ------------------------------------------------------------------
properly set at any states.
11. HDR-7000 system supports wide visual acuity up to 40’
12. Touch Screen supports various functions of the Operation Panel by using
touch-pen with ease.
13. Dialog-driven menu and simple function keys make it easy to access
complicated faculties. In addition, using [SHIFT] or [ALT] key combinations,
various options and faculties are easily accessed and executed.
14. To escape from the previous dialog as fast and convenient as possible, [ESC]
key is supported.
15. For professional examiners, 18 visual acuity tests, 24 monocular/binocular
balance tests, 35 user defined unit tests are supported. Also a Standard and 10
user-definable pre-programmed sequences are supported.
16. The CDR-MATE program running on a PC which supports PC-connectivity and
PC-style printer interface is optional.
17. Various binocular balance tests and phoria tests are supported. Advanced
graphical guide systems for such complicated tests are also available.
ОсОО «МЕДОФФ» www.medoff.net
