Huvitz HNT-7000 Setup guide

Customer Service Department HUVITZ Co.,Ltd
2014. 03. 25 1/9
How to Setup the Center and PD
[HNT-7000]

Customer Service Department HUVITZ Co.,Ltd
2014. 03. 25 2/9
[HNT-7000] How to Setup the Center and PD
1. Enter the Engineer Mode
While holding down PRINT button,
turn on the Power switch.
BEEP!
Press the DEMO button to enter the
ENGINEER SETUP MODE
Enter “6 TRACK MOTOR TEST”
1 2
3
TRACK BALL

Customer Service Department HUVITZ Co.,Ltd
2014. 03. 25 3/9
[HNT-7000] How to Setup the Center and PD
2. Move the Head & Body
4
Please move the head to the end of Left,
Down and Front using the Track ball &
Track wheel.
(Moving the X, Y, Z axis.) Please click the ‘Align Center’.
5

Customer Service Department HUVITZ Co.,Ltd
2014. 03. 25 4/9
About the side cover, please check
these tow covers if it is in a line or not.
If it is not in a line, please go on to
the ‘Track Motor Setup’.
6
If you want to move the top of head to left,
please give the (+) of X-Head.
If move it to right, please give the (-) value.
7
After changing the value, please repeat no.1 to 7.
And then, you can find the position of the center.
3. Check the side cover of head with body & Adjust
[HNT-7000] How to Setup the Center and PD

Customer Service Department HUVITZ Co.,Ltd
2014. 03. 25 5/9
[HNT-7000] How to Setup the Center and PD
If you want to move the top of head to
backward, please give the (+) value of Z-Head.
If you want to move it to the front side,
please give the (-) value of Z-Head.
9
Please check the back side of covers.
If it is not in a line, please go on to
the ‘Track Motor Setup’.
8 After changing the value, please repeat it
And then, you can make it in a line.
4. Check the back cover of head with body & Adjust

Customer Service Department HUVITZ Co.,Ltd
2014. 03. 25 6/9
[HNT-7000] How to Setup the Center and PD
Please put on the calibration JIG on
Chin-rest.
Set the ‘FT’ and IOP 60.
10 11
5. Preparing the setup of PD

Customer Service Department HUVITZ Co.,Ltd
2014. 03. 25 7/9
We will use the 1st and 3rd model eye Press ‘Start’ button with the 1st model eye.
13
12
[HNT-7000] How to Setup the Center and PD
6. Focus the Left model eye and measure the ‘FT’.

Customer Service Department HUVITZ Co.,Ltd
2014. 03. 25 8/9
[HNT-7000] How to Setup the Center and PD
If the focus is passed the 3rd model
eye, please go on to the No.1.
If the focus is not reached the 3rd
model eye, please go on to the No.2.
1) Please give the (-) value of X-Base.
2) Please give the (+) value of X-Base.
7. Set the value of X-Base
APP LED
14
15
16
After changing the value, please repeat 13 to 16.
And then, you can set the normal PD.
