HydroHoist HarborHoist HH-20,000 V-HULL V-FRAME User manual

1Rev. 04072020

2Rev. 04072020
At HydroHoist®, we take pride in bringing the most advanced, easiest to use, and lowest maintenance boat li sys-
tems to the market. Installaon of the li is simple due to its lightweight design and ease of operaon.
The following pages contain step-by-step instrucons of the installaon and operaon processes.
The heavy series HarborHoist™ li takes 24 man-hours to assemble on average. Review all parts, hardware, and
required tools before beginning assembly. Don’t forget: safety rst.
If you have quesons, contact the Technical Support Team at 1-800-825-3379.
Legend:
Requires careful consideraon
WARNING: could cause harm or damage to the li, vessel, and user
INTRODUCTION
Lis must be installed by an approved HydroHoist® installer. Failure to comply will result in termina-
on of warranty and could cause injury to the user and damage to the li and vessel.
It is STRONGLY recommended that each installer read the manual before aempng an installaon.

3Rev. 04072020
PRE-INSTALLATION CONSIDERATIONS
Due to its size, the following determinaons must be made before installing a HarborHoist:
• Locaon of li assembly (remote or on-site)
• If remote then, method of transport from assembly to launch site
• Equipment required to safely build, transport, and launch the li
• Contact points between bunks and the hull (consider strakes and other hull protrusions)
If you plan to build remotely and assemble the li before transport, rst determine the li’s minimum width from
Chart 1. State regulaons may require special permits and escorts for transportaon. Consider how to obtain per-
mits and the cost. Remotely building pre-sub assemblies and then compleng nal assembly at the launch site might
be logiscally simpler.
Other items to consider:
• Does the launch site allow commercial work?
• Do you need a permit to work and/or launch at the ramp or dock?
• Is there a me limit on dock use?
• How will you transport the li from the launch site to the install locaon?
• How much of the li can be preassembled and transported safely?
• Do you have equipment with the capacity to li subassemblies onto a trailer for transport to the launch site?
• Does the nal assembly locaon have equipment to hoist and launch the completed li?
• Is there level ground for nal assembly, or will some assembly occur in the water?
• Verify the slip width meets the minimum requirements of the li width, see Chart 1.
• See Chart 2 for a list of the required tools.
Working through these consideraons is the rst step in a successful build.

4Rev. 04072020
Chart 1: General Specicaon Of The Li
*Size = Li Capacity in lbs. per Tank
3' x 8' x 3' = 3200
4' x 8' x 3' = 5000
Main Tanks = 1100
** B = 3 x 3 square beam with a V bend in the middle
*** This is the minimum the li can be for 4" of clearance per side
Standard V Hull Series *Tank Dimensions
Liing Size
Weight
of li
(lbs.)
# Main
Tanks
# Aux
Tanks Width Length Depth
Hull
Bunk
Length
Minimum
Li Width
Possible
***Max Beam of
Boat @ Minimum
Li Width
Max
Li
Width
20,000 5600 10 24' 8' 3' 28' 12' 6" 9' 4" 14' 5"
20,000
Narrow 5700 10 33' 8' 3' 28' 12' 6" 9' 4" 14' 5"
20,000 Wide 5800 10 24' 8' 3' 28' 14' 7" 11' 16' 4"
25,000 5900 10 34' 8' 3' 28' 12' 6" 9' 4" 14' 5"
25,000 Wide 6000 10 34' 8' 3' 28' 14' 7" 11' 16' 4"
Liing Size
Max Beam
of Boat @
Max Li
Width
****Minimum Slip
Recommended
**Cross Beam
Used (inches)
Max Length Boat
Recommended Water Depth Req. Overall Length of Li
20,000 12' 34" + Vessel beam 104B 42' 43" + Dra 28' 2"
20,000
Narrow 12' 34" + Vessel beam 104B 42' (45 Perfor- mance boats) 31" + Dra 28' 2"
20,000
Wide 13' 6" 34" + Vessel beam 126B 42' 43" + Dra 28' 2"
25,000 12' 34" + Vessel beam 104B 45' 43" + Dra 28' 2"
25,000
Wide 13' 6" 34" + Vessel beam 126B 45' 43" + Dra 28' 2"
**** This assumes you are using a rope mooring soluon. This measurement allows for a 4" space between
the rub rail of the vessel and walkway. If used with a pole mooring system add an addional 24" to the mini-
mum slip width to take into account this system. The addional 24” will allow for mooring on both sides of
the li (12” per side)

5Rev. 04072020
Chart 3: Torque Specicaons
BOLT SIZE FOOT POUNDS OF TORQUE
1/4-20 5 FT. LBS.
5/16-18 9 FT. LBS.
3/8-16 16 FT. LBS.
7/16-14 26 FT. LBS.
1/2-13 35 FT. LBS.
9/16-12 47 FT. LBS.
5/8-11 76 FT. LBS.
Chart 2: Required Tools
5/16” Socket Wrench / Driver Drill / Impact Driver
7/16” Socket Wrench / Driver 7/16 Drill Bit (n-coated high helix 6” cut length
recommended)
9/16” Deep Socket Wrench / Driver Hammer / Rubber Mallet
3/4” Deep Socket Wrench / Driver Thread Sealant
7/16” Box End Wrench Gloves
9/16” Box End Wrench Safety Glasses
3/4” Box End Wrench Drill Wax
Taper Tool (to aid hole alignments) 18” Bar Clamps (3)
5/16” Hex Bit Socket

6Rev. 04072020
Chart 4: PARTS LIST—20,000
HH-20,000 V-HULL V-FRAME
Part Description Expected Qty
TANK ASSEMBLY
HH-3000 TANK- HARBORHOIST GEN 1.5 10
HHE-2650 KIT BOX - HARDWARE - HARBORHOIST TANK SET 5
HH-2601 TOP PLATE - HH GEN 1 MOD- ALUMINUM 10
HH-LPL-1024 GASKET - TOP HARBORHOIST 10
HH-LPL-1028 GASKET - UNDERNEATH - HARBORHOIST 20
HH-7103 GASKET - BOTTOM - HH MAX 20
HH-7101 TOP CLAMP - RECEIVER HARBORHOIST 20
HH-7102 CHANNEL - SUPPORT HH MAX - ALUMINUM 20
HH-LPL-1025 STRAP PLATE - ALUMINUM HARBORHOIST 20
CROSS BEAM
HH-4304 CROSS CHANNEL - 3IN SQ. 104IN. V CENTER 10
WALKWAY
HH-1428 WALKWAY PANEL - HARBORHOIST G1.5 49
HH-2515 SUPPORT-WALKWAY HARBORHOIST 10
HH-LPL-1034 BEAM - 48IN SPAN - ALUM. HH. 8
HH-LPL-1033 TUBE - SPACER, 3X3 ALUMINUM 4
HH-2525 END CAP- HH WALKWAY WITH DECAL 4
HULL PADS
1035066 ASSY HYH HARBORHOIST ALUM BUNK LEFT 22 FT 1
1035067 ASSY HYH HARBORHOIST ALUM BUNK RIGHT 22 FT 1
1035103 ASSY HYH HARBORHOIST ALUM BUNK - 6 FT 2
1035195 HARDWARE KIT - HARBORHOIST HULL PADS (1 PER TANK SET) 5
1035214 HYH - HARBORHOIST HULL PAD CONNECTION KIT 1
CONTROL
HH-2750X CONTROL - HARBORHOIST GEN 1.5 5V EXTERNAL SENSOR 1
HH-2517 CONTROL STAND HARBORHOIST GEN 1.5 1
HHE-2655 KIT, HARDWARE, CONTROL HARDWARE HH 2018 1
3072517 HOSE - RUBBER 1-1/4 in. ID X 100 ft. - CUT 1
3072516 HOSE - RUBBER 1-1/4 in. ID X 50 ft. - CUT 1
HHE-7119 KIT - HARDWARE TO LINK TANK SETS TOGETHER 3
AUXILIARY (AUX) TANKS
HH-7106 I-BEAM - 6061 ALUMINUM 3 X 2.5 X .26/.15 X 25FT 2
HHE-7112 KIT - HARDWARE - SINGLE AUXILARY TANK HARBORHOIST 2
HHE-7116 KIT - HARDWARE - DOUBLE AUXILARY TANKS 1
HH-5130 AUXILARY TANK ASSY - HARBORHOIST 48X96X36 2

7Rev. 04072020
Chart 4: PARTS LIST—20,000 Narrow
HH-20,000 V-HULL V-FRAME NARROW
Part Description Expected Qty
TANK ASSEMBLY
HH-3000 TANK- HARBORHOIST GEN 1.5 10
HHE-2650 KIT BOX - HARDWARE - HARBORHOIST TANK SET 5
HH-2601 TOP PLATE - HH GEN 1 MOD- ALUMINUM 10
HH-LPL-1024 GASKET - TOP HARBORHOIST 10
HH-LPL-1028 GASKET - UNDERNEATH - HARBORHOIST 20
HH-7103 GASKET - BOTTOM - HH MAX 20
HH-7101 TOP CLAMP - RECEIVER HARBORHOIST 20
HH-7102 CHANNEL - SUPPORT HH MAX - ALUMINUM 20
HH-LPL-1025 STRAP PLATE - ALUMINUM HARBORHOIST 20
CROSS BEAM
HH-4304 CROSS CHANNEL - 3IN SQ. 104IN. V CENTER 10
WALKWAY
HH-1428 WALKWAY PANEL - HARBORHOIST G1.5 49
HH-2515 SUPPORT-WALKWAY HARBORHOIST 10
HH-LPL-1034 BEAM - 48IN SPAN - ALUM. HH. 8
HH-LPL-1033 TUBE - SPACER, 3X3 ALUMINUM 4
HH-2525 END CAP- HH WALKWAY WITH DECAL 4
HULL PADS
1035066 ASSY HYH HARBORHOIST ALUM BUNK LEFT 22 FT 1
1035067 ASSY HYH HARBORHOIST ALUM BUNK RIGHT 22 FT 1
1035103 ASSY HYH HARBORHOIST ALUM BUNK - 6 FT 2
1035195 HARDWARE KIT - HARBORHOIST HULL PADS (1 PER TANK SET) 5
1035214 HYH - HARBORHOIST HULL PAD CONNECTION KIT 1
CONTROL
HH-2760X CONTROL - HARBORHOIST GEN 1.5 6V EXTERNAL SENSOR 1
HH-2517 CONTROL STAND HARBORHOIST GEN 1.5 1
HHE-2655 KIT, HARDWARE, CONTROL HARDWARE HH 2018 1
3072517 HOSE - RUBBER 1-1/4 in. ID X 100 ft. - CUT 1
3072516 HOSE - RUBBER 1-1/4 in. ID X 50 ft. - CUT 1
HHE-7119 KIT - HARDWARE TO LINK TANK SETS TOGETHER 3
AUXILIARY (AUX) TANKS
HH-7106 I-BEAM - 6061 ALUMINUM 3 X 2.5 X .26/.15 X 25FT 2
HHE-7112 KIT - HARDWARE - SINGLE AUXILARY TANK HARBORHOIST 3
HHE-7116 KIT - HARDWARE - DOUBLE AUXILARY TANKS 1
HHE-7117 KIT - HARDWARE - SINGLE AUXILARY TANK FITTINGS 1
HH-3730 AUXILARY TANK ASSY - HARBORHOIST 36X96X36 3

8Rev. 04072020
Chart 4: PARTS LIST—20,000 Wide
HH-20,000 V-HULL V-FRAME WIDE
Part Description Expected Qty
TANK ASSEMBLY
HH-3000 TANK- HARBORHOIST GEN 1.5 10
HHE-2650 KIT BOX - HARDWARE - HARBORHOIST TANK SET 5
HH-2601 TOP PLATE - HH GEN 1 MOD- ALUMINUM 10
HH-LPL-1024 GASKET - TOP HARBORHOIST 10
HH-LPL-1028 GASKET - UNDERNEATH - HARBORHOIST 20
HH-7103 GASKET - BOTTOM - HH MAX 20
HH-7101 TOP CLAMP - RECEIVER HARBORHOIST 20
HH-7102 CHANNEL - SUPPORT HH MAX - ALUMINUM 20
HH-LPL-1025 STRAP PLATE - ALUMINUM HARBORHOIST 20
CROSS BEAM
FRM-06-0007 CROSS CHANNEL - 3IN SQ. V CENTER 126 IN LONG 10
WALKWAY
HH-1428 WALKWAY PANEL - HARBORHOIST G1.5 49
HH-2515 SUPPORT-WALKWAY HARBORHOIST 10
HH-LPL-1034 BEAM - 48IN SPAN - ALUM. HH. 8
HH-LPL-1033 TUBE - SPACER, 3X3 ALUMINUM 4
HH-2525 END CAP- HH WALKWAY WITH DECAL 4
HULL PADS
1035066 ASSY HYH HARBORHOIST ALUM BUNK LEFT 22 FT 1
1035067 ASSY HYH HARBORHOIST ALUM BUNK RIGHT 22 FT 1
1035103 ASSY HYH HARBORHOIST ALUM BUNK - 6 FT 2
1035195 HARDWARE KIT - HARBORHOIST HULL PADS (1 PER TANK SET) 5
1035214 HYH - HARBORHOIST HULL PAD CONNECTION KIT 1
CONTROL
HH-2750X CONTROL - HARBORHOIST GEN 1.5 5V EXTERNAL SENSOR 1
HH-2517 CONTROL STAND HARBORHOIST GEN 1.5 1
HHE-2655 KIT, HARDWARE, CONTROL HARDWARE HH 2018 1
3072517 HOSE - RUBBER 1-1/4 in. ID X 100 ft. - CUT 1
3072516 HOSE - RUBBER 1-1/4 in. ID X 50 ft. - CUT 1
HHE-7119 KIT - HARDWARE TO LINK TANK SETS TOGETHER 3
AUXILIARY (AUX) TANKS
HH-7106 I-BEAM - 6061 ALUMINUM 3 X 2.5 X .26/.15 X 25FT 2
HHE-7112 KIT - HARDWARE - SINGLE AUXILARY TANK HARBORHOIST 2
HHE-7116 KIT - HARDWARE - DOUBLE AUXILARY TANKS 1
HH-5130 AUXILARY TANK ASSY - HARBORHOIST 48X96X36 2

9Rev. 04072020
Chart 4: PARTS LIST— 25,000
HH-25,000 V-HULL V-FRAME
Part Description Expected Qty
TANK ASSEMBLY
HH-3000 TANK- HARBORHOIST GEN 1.5 10
HHE-2650 KIT BOX - HARDWARE - HARBORHOIST TANK SET 5
HH-2601 TOP PLATE - HH GEN 1 MOD- ALUMINUM 10
HH-LPL-1024 GASKET - TOP HARBORHOIST 10
HH-LPL-1028 GASKET - UNDERNEATH - HARBORHOIST 20
HH-7103 GASKET - BOTTOM - HH MAX 20
HH-7101 TOP CLAMP - RECEIVER HARBORHOIST 20
HH-7102 CHANNEL - SUPPORT HH MAX - ALUMINUM 20
HH-LPL-1025 STRAP PLATE - ALUMINUM HARBORHOIST 20
CROSS BEAM
HH-4304 CROSS CHANNEL - 3IN SQ. 104IN. V CENTER 10
HH-4348 CROSS CHANNEL - 3IN SQ. V CENTER AUX ASSIST 5
HHE-7108 KIT - HARDWARE - CROSS CHANNEL ASSIST BEAM (1KIT PER) 5
WALKWAY
HH-1428 WALKWAY PANEL - HARBORHOIST G1.5 49
HH-2515 SUPPORT-WALKWAY HARBORHOIST 10
HH-LPL-1034 BEAM - 48IN SPAN - ALUM. HH. 8
HH-LPL-1033 TUBE - SPACER, 3X3 ALUMINUM 4
HH-2525 END CAP- HH WALKWAY WITH DECAL 4
HULL PADS
1035066 ASSY HYH HARBORHOIST ALUM BUNK LEFT 22 FT 1
1035067 ASSY HYH HARBORHOIST ALUM BUNK RIGHT 22 FT 1
1035103 ASSY HYH HARBORHOIST ALUM BUNK - 6 FT 2
1035195 HARDWARE KIT - HARBORHOIST HULL PADS (1 PER TANK SET) 5
1035214 HYH - HARBORHOIST HULL PAD CONNECTION KIT 1
CONTROL
HH-2760X CONTROL - HARBORHOIST GEN 1.5 6V EXTERNAL SENSOR 1
HH-2517 CONTROL STAND HARBORHOIST GEN 1.5 1
HHE-2655 KIT, HARDWARE, CONTROL HARDWARE HH 2018 1
3072517 HOSE - RUBBER 1-1/4 in. ID X 100 ft. - CUT 1
3072510 HOSE - RUBBER 1-1/4 in. ID X 75 ft. - CUT 1
HHE-7119 KIT - HARDWARE TO LINK TANK SETS TOGETHER 3
AUXILIARY (AUX) TANKS
HH-7106 I-BEAM - 6061 ALUMINUM 3 X 2.5 X .26/.15 X 25FT 2
HHE-7112 KIT - HARDWARE - SINGLE AUXILARY TANK HARBORHOIST 3
HHE-7116 KIT - HARDWARE - DOUBLE AUXILARY TANKS 1
HH-5130 AUXILARY TANK ASSY - HARBORHOIST 48X96X36 3
HHE-7117 KIT - HARDWARE - SINGLE AUXILARY TANK FITTINGS 1

10 Rev. 04072020
Chart 4: PARTS LIST— 25,000 Wide
HH-25,000 V-HULL V-FRAME WIDE
Part Description Expected Qty
TANK ASSEMBLY
HH-3000 TANK- HARBORHOIST GEN 1.5 10
HHE-2650 KIT BOX - HARDWARE - HARBORHOIST TANK SET 5
HH-2601 TOP PLATE - HH GEN 1 MOD- ALUMINUM 10
HH-LPL-1024 GASKET - TOP HARBORHOIST 10
HH-LPL-1028 GASKET - UNDERNEATH - HARBORHOIST 20
HH-7103 GASKET - BOTTOM - HH MAX 20
HH-7101 TOP CLAMP - RECEIVER HARBORHOIST 20
HH-7102 CHANNEL - SUPPORT HH MAX - ALUMINUM 20
HH-LPL-1025 STRAP PLATE - ALUMINUM HARBORHOIST 20
CROSS BEAM
FRM-06-0007 CROSS CHANNEL - 3IN SQ. V CENTER 126 IN LONG 10
HH-4348 CROSS CHANNEL - 3IN SQ. V CENTER AUX ASSIST 5
HHE-7108 KIT - HARDWARE - CROSS CHANNEL ASSIST BEAM (1KIT PER) 5
WALKWAY
HH-1428 WALKWAY PANEL - HARBORHOIST G1.5 49
HH-2515 SUPPORT-WALKWAY HARBORHOIST 10
HH-LPL-1034 BEAM - 48IN SPAN - ALUM. HH. 8
HH-LPL-1033 TUBE - SPACER, 3X3 ALUMINUM 4
HH-2525 END CAP- HH WALKWAY WITH DECAL 4
HULL PADS
1035066 ASSY HYH HARBORHOIST ALUM BUNK LEFT 22 FT 1
1035067 ASSY HYH HARBORHOIST ALUM BUNK RIGHT 22 FT 1
1035103 ASSY HYH HARBORHOIST ALUM BUNK - 6 FT 2
1035195 HARDWARE KIT - HARBORHOIST HULL PADS (1 PER TANK SET) 5
1035214 HYH - HARBORHOIST HULL PAD CONNECTION KIT 1
CONTROL
HH-2760X CONTROL - HARBORHOIST GEN 1.5 6V EXTERNAL SENSOR 1
HH-2517 CONTROL STAND HARBORHOIST GEN 1.5 1
HHE-2655 KIT, HARDWARE, CONTROL HARDWARE HH 2018 1
3072517 HOSE - RUBBER 1-1/4 in. ID X 100 ft. - CUT 1
3072510 HOSE - RUBBER 1-1/4 in. ID X 75 ft. - CUT 1
HHE-7119 KIT - HARDWARE TO LINK TANK SETS TOGETHER 3
AUXILIARY (AUX) TANKS
HH-7106 I-BEAM - 6061 ALUMINUM 3 X 2.5 X .26/.15 X 25FT 2
HHE-7112 KIT - HARDWARE - SINGLE AUXILARY TANK HARBORHOIST 3
HHE-7116 KIT - HARDWARE - DOUBLE AUXILARY TANKS 1
HH-5130 AUXILARY TANK ASSY - HARBORHOIST 48X96X36 3
HHE-7117 KIT - HARDWARE - SINGLE AUXILARY TANK FITTINGS 1

11 Rev. 04072020
STEP 1: WALKWAY TOP PLATE ASSEMBLY
1. Align the mounng holes for the Top Plate and Top Gasket.
2. Run the Bolts and Liing Ring through the Top Plate and Top Gasket. Fasten with washers as illustrated below.
Bolt 3/8-16x3x5
Flat Washer 1/4” (x8)
Brass Hex Nut 1/2-13
Lock Washer 1/2” 18-8 SS
Liing Ring 1.5 x 4 SS
Nylock Nut 1/4-20 SS (x4)
Top Gasket
Top Plate
Flat Washer 1/4”
Part # Hardware Required
HH-LPL-1502 Nyloc Nut (1/4-20 SS)
HH-LPL-1501 Hex Bolt (1/4-20 x 1.5 SS)
2090216 Flat Washer (1/4” SS)
HH-1916 Lock Washer 1/2” 18-8 SS
HH-1926 Hex Nut 1/2-13 Brass
HH-2602 Liing Ring 1.5 x 4 SS
Part # Parts Required (Per Tank)
HH-2601 Top Plate
HH-LPL-1024 Top Gasket
Use Kit Box: #HHE-2650

12 Rev. 04072020
STEP 2: ATTACH TOP PLATE ASSEMBLY TO STRAP PLATES
1. Align the Walkway Assembly with a Strap Plate.
2. Put U-Bolts through the Strap Plate and into the Walkway assembly, loosely fastening as illustrated.
3. Repeat the process for the second Strap Plate.
NOTE: Only hand ghten brass hex nuts on top of the U-Bolts. They will be removed later to assemble the walkway.
Lock Washer (3/8”) (x8) Brass Hex Nut (3/8-16) (x8) U-Bolt (3/8-16 x 3 x 6) (x4)
Strap Plate (x2) Walkway Assembly
Part # Parts Required (Per Tank)
NA Walkway Assembly
HH-LPL-1025 Strap Plate
Part # Hardware Required
HH-LPL-1503 U-Bolt 3/8-16 x 3 x 6
2090242 Flat Washer 3/8”
HH-LPL-1505 Lock Washer 3/8”
HH-2603 Brass Nut 3/8-16
Assembly aid: Aach zip es to the bases of the U-Bolts to keep them in place during installaon. Zip es
are not provided in the kit.
Use Kit Box: #HHE-2650

13 Rev. 04072020
STEP 3: ATTACH TANK FRAME BRACKETS TO STRAP PLATES
1. Align the mounng holes for the Support Channel, Strap Plate, and Boom Gasket.
2. Slide the U-Bolts through the boom of the Support Channel.
Assembly Aid: Aach Zip Ties to the bases of the U-Bolts to keep them in place during installaon. Zip Ties are
not provided in the kit.
3. Insert the 5” Flat Head Bolt through the Support Channel and the Boom Gasket.
IMPORTANT: Tighten the Nut against the Nylon Bushing so the Bolt cannot rotate. This will make it easier to as-
semble the boom tank to the Boom Gasket.
Part # Parts Required (Per Tank)
HH-7102 Support Channel
HH-7103 Boom Gasket
HH-LPL-1025 Strap Plate
Part # Hardware Required
HH-LPL-1503 U-Bolt (3/8-16 x 3 x 5)
HH-LPL-1006 Flat Head Bolt (5” SS)
HH-LPL-1031 Nylon HH Tank Bushing
HH-1926 Hex Nut (1/2-13 Brass)
HH-1916 Lock Washer
U-Bolt
Lock washer
Strap
Support Channel
Boom Gasket
Nylon Bushing
Hex Nut
Flathead Bolt
Aach Zip Ties
Use Kit Box: #HHE-2650

14 Rev. 04072020
STEP 4: ATTACH STRAP PLATE ASSEMBLY TO TANK
1. Roll the tank onto its back for unobstructed access to the top and boom of the tank, as illustrated below.
2. Place the completed Strap Plate Assembly into the recesses along the front and top of the tank.
The next procedure must be followed in order to prevent damage to the tank. DO NOT force the
assembly together as this could cause the nylon bushing to damage the tank.
3. Slide the 1/2 x 13 x 8” Boom Hex Bolt through the Boom Tank Gasket, the loosely assembled tank bracket and
the Top Clamp, as illustrated below.
4. Tighten the Top-Side Bolt Assembly unl snug.
5. Tighten the Boom-Side Bolt Assembly unl snug.
6. Tighten Top-Side Brass Nut to specicaon, drawing the assembly into the recess of the tank. Verify this is com-
pleted to avoid the bolt rotang when assembly the cross beam in a later step.
7. Tighten the Boom-Side Bolt Assembly to specicaon.
IMPORTANT: Verify that the (Top Side) Brass Nut has been ghtened in Step 6 to avoid rotaon when assembling
the Cross Channel in a future step.
Tank shown on its back
Gasket Underneath
1/2x3x8” Boom Hex
Strap Plate
(Top-Side) Brass Nut
Nylon Bushing
(Boom-Side) 1/2” Hex
U-Bolt
Top-Side Bolt
Assembly
Boom-Side Bolt
Assembly
Part # Hardware Required
HH-LPL-1508 Flat Washer (1/2 x2 OD SS)
HH-2100 Brass Nyloc Nut (1/2-13)
HH-7901 Boom Hex Bolt (1/2 x 13 x 8)
HH-LPL-1031 Nylon Bushing HH Tank
HH-2603 Nut (3/8-16)
Part # Parts Required (Per Tank)
HH3000 Tank
HH-LPL-1028 Gasket - Underneath Tank
Use Kit Box: # HHE –2650

15 Rev. 04072020
STEP 5: STUB TUBE INSTALLATION
1. Reposion the tank in the upright posion.
2. Apply thread sealant to the Stub Tube Recommend Sealants: #2 Permatex, 3M 4200, or Permatex with
PTFE. Sealant must have PTFE. See sealant manufacturer applicaon instrucons.
3. Screw the Stub Tube into the tank ng.
4. Apply Thread Sealant to the elbow and screw into Stub Tube ng. You may need to hold the Stub Tube
ng with a pipe wrench to avoid turning it while screwing in the elbow. As the threads ghten, pay
aenon to the direcon that the elbow /hose is poinng.
• Oen, the li’s hull pad dead rise is shallower than that of the vessel. To increase the dead rise
capability of the li, the Stub Tube may need to be trimmed. See Chart 6 for trimming the Stub
Tube and Chart 7 for spacing hull pads. In combinaon, these will give you the dra of the li
needed for your vessel.
• Be careful not to overshoot the desired alignment since backing o the Stub Tube can cause a
leak path around the ng. The Stub Tube can be hand ghtened such that minimal threads on
the elbow are visible.
REPEAT STEPS 1-5 FOR EACH TANK BEFORE PROCEEDING TO STEP 6.
Part # Parts Required (Per Tank)
HHE-2650 Stub Tube Assembly (Kit Box)
Part # Hardware Required
HHE-2650 Hose Clamp #24 (Kit Box)
Not supplied Thread Sealant
Tanks sets are numbered from front to rear. Set 1 is the farthest forward.
Chart 6: STUB TUBE MAXIMUM TRIM PER TANK SET
Forward Front to Rear (in.) A
Model Lis SET 1 SET 2 SET 3 SET 4 SET 5
20,000 - 25,000 00.75" 1.5" 2.25" 3"
Stub Tube Assembly in Tank
Stub Tube Stub Tube Elbow
Use Kit Box: #HHE-2650

16 Rev. 04072020
STEP 6(a): ALIGNING THE TANKS
Side Alignment
1. Align the tanks next to each other, ve on each side, spacing them so the mooring rings are 68.25” apart. You may
want to use the full-length hull support bracket as a straight-edge to align the tanks. The hull support bracket is
used in a later step.
2. Align tanks opposite each other using the rules for minimum beam of li or beam of boat. See Step 6(b) for proper
alignment. Verify the tanks are separated enough to accommodate the cross channel in STEP 6(c).
68.25” 68.25” 68.25” 68.25”
The minimum beam of the li is calculated by adding 34” to the beam of the boat. If the li uses AUX tanks,
the minimum beam of the li maybe determined by the width of the AUX tank. Refer to Table 1.
When sizing the slip this way, it will leave a minimum of a 4IN. gap for each of the lis. Near this width, the
walkway could catch on the edge of the dock while raising or lowering. Dock fenders are recommended to pre-
vent this. See Chart 1 for minimum li widths.
4” 4”
Beam of Li
AUX Tank Width
Minimum beam of li

17 Rev. 04072020
3. Perform Steps 6(b) and (c). Verify equal length diagonals as you build from tank Set 1 to tank.
Set 5 as shown below to ensure they are square.
4. Aer conrming the li is square and all assembly for Steps 6(b) and (c) are completed, ghten all
hardware completely.
Set 1 Set 2 Set 1 Set 2 Set 3
Set 1 Set 2 Set 3 Set 4 Set 1 Set 2 Set 3 Set 4 Set 5

18 Rev. 04072020
STEP 6(b): TANK AND WALKWAY ALIGNMENT AND ATTACHMENT
1. Place the Spacer Tubes between the outside set of U-Bolts on tank Set 1 and Set 5. See Figure B below.
2. Place Span Beams between the U-Bolt sets on the connecng tanks. See Figure C below.
3. Starng with tank Set 3, loosely aach the walkway support on top of the span beam, as illustrated below.
Ensure the U-Bolts are centered in the middle of the walkway slots on the walkway support. As walkway
supports are added to the other tank sets, the U-Bolts will shi outward in the walkway slots. Add walk-
way supports to tank Set 2 and tank Set 4 and then add walkway supports to tank Set 1 and tank Set 5. Thus
working from the middle out. See Figure A.
4. Conrm the Span Beams are centered between the two tanks and the Spacers are in the proper posion.
Wait to ghten all hardware on the walkway unl you have completed Step 6(c).
If you use a Single-Sided Tie-O method for mooring, the Spacer Tubes must be removed in a later step. Do
not ghten the U-Bolts fastening the walkway over the spacers. Refer to STEP 16: TIE-OFF MOORING.
Spacer Spacer
Install Span Beams to connect the tanks
Set 1 Set 2 Set 3 Set 4 Set 5
Span Beam installed between U-Bolts on connecng tanks
Walkway Support Walkway Slots
Figure C: Span Beam
Spacer Tube installed between the outside
set of U-Bolts on front and rear tank sets
Figure B: Spacer Tube
Brass Nut 3/8”
Lock Washer 3/8”
Flat Washer 3/8” Figure A: Tank Walkway connecng
Part # Parts Required (Per Tank Set)
HH-LPL-1033 Aluminum Spacer Tube (3 X 3)
HH-LPL-1034 Beam - 48in Span—Alum. HH.
HH - 2515 Walkway Support
Part # Hardware Required (Per Tank Set)
HH-LPL-1505 Lock Washer (3/8” SS)
HH-1975 Brass Nut (3/8-16)
2090242 Flat Washer (3/8” SS)
Use Kit Box: #HHE-2650

19 Rev. 04072020
1. Place the Receiver Spacers, two per tank, on the rear bolts that are poinng up. Be sure to place them on
the opposite tank that you are connecng.
2. Connect the facing tanks by placing the Cross Channels on top of the Support Channels between the U-
Bolts. Install the Top Clamp to the tank frame assemblies.
3. Finger-ghten the U-Bolt nuts to hold the Top Clamp in place. Repeat for each set of tanks.
Do not fully ghten unl you verify that Step 6(a), 6(b), and 6(c) have been completed.
STEP 6(c): INSTALL TANK CROSS BEAM ASSEMBLY
Part # Parts Required (Per Tank)
HH-7101 Top Clamp—Receiver HH
HH-3404 Cross Channel - 3IN. SQ. 104IN. Long AL
Support Channel
Top Clamp
Receiver Spacer
1/2”-13 Brass Hex Nut Nyloc 3/8-16 Brass Hex Nut
3/8” SS Flat Washer
3/8” SS Lock Washer
3” SQ Cross Channel
Part # Hardware Required (Per Tank)
HH-1975 Brass Hex Nut3/8-16
2090242 Flat Washer 3/8” SS
HH-LPL-1505 Lock Washer 3/8-16 SS
HHE-7107 Rear PVC Spacer
HH-LPL-1508 Washer - Flat-1/2" x 2 OC SS
HH-2100 Nut 1/2 -13 Brass NYLOC
THE CROSS CHANNEL ENDS SHOULD NOT BE VISIBLE THROUGH THE SIGHT HOLE ON THE TOP CLAMP.
IF THE END OF THE CHANNEL IS VISIBLE, THIS COULD REDUCE THE STRUCTURE LOAD CAPABILITIES OF
THE FRAME ASSEMBLY.
Sight Hole
Use Kit Box: #HHE-2650

20 Rev. 04072020
STEP 7(a): HULL PAD ALIGNMENT (V-HULL ONLY)
Before installing the hull pads, it is important to determine the bunk spacing: how far apart the hull pads should be
mounted on the cross beams. To calculate the proper spacing, refer to the table below. Consult your boat manufactur-
er for dead rise informaon.
How to Use the Bunk Value Table
The chart shows pad separaon and max dead rise angle to maintain 1” minimum clearance to the cross channel
listed top to boom.
Aligning the Hull Pads
Place the hull pads as wide as possible while maintaining clearance between the hull and I-beam. Be sure to check
the boat, boat trailer, or consult the boat manufacturer to ensure the locaon is clear of underwater obstrucons,
such as speedometer sensors, water pickups, etc. The hull pads can be placed on the li so that the front is narrow-
er than the rear if needed to support sharper dead rises at the bow of the vessel. If you do this, verify that the hull
pad does not cross a stake or other feature on the hull that would result in a concentrated loading condion. The
chart below is based on the dead rise angle and separaon distance and is provided as a starng point only.
IF YOUR VESSELS DEADRISE FALLS IN BETWEEN TWO NUMBERS IN THE CHART. ALWAYS, MOVE TO THE
NARROWER HULL PAD SEPARATION FOR HULL PAD PLACEMENT.
Table 7(a): Bunk Value Table
V-Center
Cross Beam
Hull Bunks
Hull Pad Max Min.
Separation Dead Rise Clearance
(In) (Deg) (In)
25 35.5 1
30 30.7 1
32 29.2 1
35 27 1
40 24.3 1
