WAREHOUSE REACH TRUCK

R1.0-1.4E Series

PRODUCT TECHNICAL GUIDE

TRUCK DIMENSIONS TRUCK DIMENSIONS

230 y

Ast = Wa + R + a

Ast = Wa + (l6-x)2+(b12 /2)2 + a

a = 200mm

b5b12 b4b2

a/2

b11

a/2





550

371

All values are nominal values and they are subject to tolerances.

For further information, please contact the manufacturer.

Hyster products might be subject to change without notice.

Lift trucks illustrated may feature optional equipment.

Values may vary with alternative conﬁgurations.

R1.0E, R1.2E, R1.4E

NOTES:

Speciﬁcations are affected by the condition of the vehicle and how it is equipped, as well

as the nature and condition of the operating area. Inform your dealer of the nature and

condition of the intended operating area when purchasing your Hyster®truck.

Safety: This truck conforms to the current EU and ANSI requirements.

Speciﬁcation data is based on VDI 2198

NOTICE:

Care must be exercised when handling elevated loads. Operators must be

trained and must read, understand and follow the instructions contained in the

Operating Manual.

All values are nominal values and they are subject to tolerances. For further

information, please contact the manufacturer.

Hyster products are subject to change without notice.

Lift trucks illustrated may feature optional equipment.

Values may vary with alternative conﬁgurations.

NOTE: Speciﬁcations, unless otherwise listed, are for a standard truck without

optional equipment.

GENERAL

1.1 Manufacturer (abbreviation) HYSTER

1.2 Manufacturer's type designation R1.0E R1.2E R1.4E

1.3 Drive: electric (battery or mains), diesel, petrol, fuel gas Electric (battery)

1.4 Operator type: hand, pedestrian, standing, seated, orderpicker Seated

1.5

Rated capacity / rated load

Q kg 1.0 1.2 1.4

1.6 Load centre distance c mm 600

1.8

Load distance (588 TB spreader / 586 TB spreader)

x mm 181 371

1.9 Wheelbase y mm 1300 1400

WEIGHT

2.1

Service weight

kg 2845 2948

2.2 Axle loading, unladen front/rear kg 1622 / 1223 1851 / 1097

2.3 Axle loading fork advanced, laden front/rear (1) kg 810 / 3035 695 / 3350 694 / 3654

2.4 Axle loading fork retracted, laden front/rear kg 1288 / 2557 1222 / 2823 1605 / 2743

WHEELS

3.1 Tyres: polyurethane, topthane, NDIIThane, front/rear NDIIThane

3.2 Tyre size, front ø mm x mm 343 x 140

3.3 Tyre size, rear ø mm x mm 220 x 85 285 x 100

3.5 Wheels, number front/rear (x = driven wheels) 1x / 2

3.7 Tread, rear b11 mm 990 1155

DIMENSIONS

4.1 Tilt of mast/fork carriage forward/backward α/ βdeg 1° / 3°

4.2 Height of mast, lowered h1mm 2191

4.3 Free lift h2mm 1706

4.4 Lift h3mm 5000

4.5 Height, mast extended (2) h4mm 5560

4.7 Height of overhead guard (cabin) (3) h6mm 2175

4.8 Seat height relating to SIP h7mm 1082

4.10 Height of wheel arms h8mm 235 308

4.19 Overall length l1mm 2500 2411

4.20 Length to face of forks l2mm 1350 1261

4.21 Overall width (4) b1 / b2mm 1125 1265

4.22 Fork dimensions DIN ISO 2331 s/e/l mm 40 / 80 / 1150

4.23 Fork carriage ISO 2328, class/type A, B 2A

4.24 Fork-carriage width b3mm 700

4.25 Forks spread MIN/MAX (5) b5mm 220/640

4.26 Distance between wheel arms/loading surfaces b4mm 900

4.28 Reach distance 14mm 341 560

4.31 Ground clearance, laden, below mast m1mm 75

4.32 Ground clearance, centre of wheelbase m2mm 75 85

4.34.1 Aisle width for pallets 1000mm x 1200mm crossways Ast mm 2770 2741

4.34.2 Aisle width for pallets 800mm x 1200mm lengthwise Ast mm 2850 2792

4.35 Turning radius Wamm 1555 1672

4.37 Length across wheel arms l7mm 1660 1795

4.42

Step height (from ground to running board)

mm 550 550

4.43 Step height (between intermediate steps and ﬂoor) mm 371

PERFORMANCE

5.1

Travel speed, laden/unladen

km/h 11 / 11

5.1.1 Travel speed, laden/unladen, backwards km/h 11 / 11

5.2 Lift speed, laden/unladen m/s 0,45 / 0,70 0,40 / 0,70 0,35 / 0,70

5.3 Lowering speed, laden/unladen m/s 0,55 / 0,45

5.4 Reaching speed, laden/unladen m/s 0,15 / 0,15

5.7 Gradeability, laden/unladen % 9,0 / 12,7 8,5 / 12,7 7,6 / 11,9

5.8 Max. gradeability laden/unladen % 14,6 / 20,2 13,8 / 20,2 12,5 / 19,0

5.9 Acceleration time laden/unladen s 5,5 / 4,9 5,6 / 4,9 5,7 / 4,8

5.10 Service brake Electric

ELECTRIC - ENGINE

6.1 Drive motor S2 60 minute rating kW 5.4

6.2 Lift motor, S3 15% rating kW 9.9

6.3 Battery according to DIN 43531/35/36 A,B,C, no B C

6.4 Battery voltage/nominal capacity K5 (V)/(Ah) 48 / 560 (7)

6.5 Battery weight (6) kg 937 939

6.6 Energy consumption according to DIN EN 16796 kWh/h 2.05 2.21 3.33

6.7 Turnover output according to VDI 2198 t/h 39 47 53

6.8 Turnover efﬁciency according to VDI 2198 t/kWh 17 18 18

DRIVE/LIFT

MECHANISM

8.1 Type of drive unit AC-Controller

ADDITION

DATA

10.7 Sound pressure level at the driver’s seat dB(A) 70

(1) Forks retracted.

(2) With load backrest 1000mm height, h4 + 508 mm; with load backrest 1500mm height,

h4 + 1008mm

(3) With beacon h6 + 120mm; With OHG Grid Protector h6 + 20mm ; With OHG Screen Protector

h6 + 30mm .

(4) With load wheels lateral covers: 1289mm (R1.4E/MR14E).

(5) Side shift stroke is +/-75mm.

(6) These values may vary of +/- 5%.

(7) See “Batteries table”.

MAST INFORMATION

3 STAGE FFL

Tilt

α/β

Lift

h3(mm)

Free lift

h2(mm)

Height,

mast lowered

h1(mm)

Height,

mast extended

h4(1) (mm)

Weight (2) (3)

(kg)

R1.0E

R1.2E

R1.4E

1°/3° 5000 1706 2191 5560 629

1°/3° 5250 1792 2277 5810 645

1°/3° 5500 1878 2363 6060 662

1°/3° 5750 1964 2449 6310 717

1°/3° 6000 2050 2535 6560 736

1°/3° 6250 2136 2621 6810 754

0,5°/1° 6500 2222 2707 7060 772

0,5°/1° 6750 2308 2793 7310 797

0,5°/1° 7000 2394 2879 7560 815

0,5°/1° 7250 2480 2965 7810 834

0,5°/1° 7500 2566 3051 8060 852

(1) With load backrest 1000mm height, h4 + 508mm; with load backrest 1500mm height, h4 + 1008mm

(2) All weights are: mast structures (weldment, cylinders, chain, pulley) + carriage + oil.

EXCLUDED: forks, accessories

(3) With load backrest 700mm width, 1000mm height, weight + 18 kg; with load backrest 700mm width, 1500mm height, weight + 26 kg

BATTERY INFORMATION

STANDARD EQUIPMENT AND OPTIONS

Please refer to Price List for full options conﬁguration

Other options available through Special Products Engineering Department (SPED).

Contact Hyster for details.

x Standard equipment

o Optional equipment

- Not available

PERFORMANCE (CONTINUED) R1.0E R1.2E R1.4E

Joystick mounted on adjustable length armrest o o o

Simultaneous hydraulic operation for lift and reach x x x

Rocker switch directional control x x x

Full suspension seat x x x

Cloth seat cover x x x

SKAI seat cover o o o

Low backrest seat x x x

Seat head rest o o o

Seat heating o o o

Antistatic seat ( cloth version only) o o o

180° steering o o o

360° steering x x x

Driver select steering mode 180 / 360° (push button) o o o

VISIBILITY R1.0E R1.2E R1.4E

Panoramic mirror o o o

Amber strobe light o o o

One front LED work light o o o

2 rear LED work lights o o o

DRIVE R1.0E R1.2E R1.4E

Travel speed 11 km/h x x x

343 x 140mm NDIIthane Drive Wheel x x x

343mm x 140mm Polyurethane Conductive Drive Wheel o o o

343 x 140mm Wet Grip Drive Wheel o o o

220 x 85 mm NDIIthane load wheels x x -

220 x 85 mm conductive load wheels o o -

220 x 85 mm wet grip load wheels o o -

285 x 100 mm NDIIthane load wheels - - x

285 x 100 mm conductive load wheels - - o

285 x 100 mm wet grip load wheels - - o

Creep speed button x x x

LIFT R1.0E R1.2E R1.4E

3 stage mast x x x

700 mm FEM 2A carriage x x x

Various sizes forks o o o

Without load backrest x x x

1000 mm high load backrest o o o

HANDLING R1.0E R1.2E R1.4E

Universal support bar o o o

Beverage holder and document tray o o o

A4 clipboard o o o

Stretch ﬁlm roll holder o o o

Side load wheel protection - - o

24V DC/DC Converter o o o

24-12V DC Converter o o o

Audible forward alarm (forks trailing) o o o

Audible reverse alarm (forks leading) o o o

Audible forward and reverse alarm o o o

Hyster Tracker wireless asset management - Access o o o

Hyster Tracker wireless asset management - Monitoring o o o

Hyster Tracker wireless asset management - Veriﬁcation o o o

BATTERIES R1.0E R1.2E R1.4E

1035 x 263 x 784 mm battery compartment (for 280/310 Ah DIN B Battery) x x -

1035 x 353 x 784mm battery compartment (for 420/465 Ah DIN B Battery) o o -

1035 x 443 x 784mm battery compartment (for 560/620 Ah DIN B Battery) o o -

1223 x 283 x 784mm battery compartment (for 420/465 Ah DIN C Battery) - - x

1223 x 355 x 784mm battery compartment (for 560/620 Ah DIN C Battery) - - o

Vertical battery extraction x x x

Side battery extraction o o o

Twin battery change station o o o

Extension cable o o o

APPEARANCE R1.0E R1.2E R1.4E

Hyster yellow paint base truck x x x

Special paint base truck o o o

SUPPLEMENTAL R1.0E R1.2E R1.4E

Literature package x x x

CE certiﬁcation x x x

Warranty: 24 Months / 4,000 Hours Parts manufacturer’s warranty x x x

Warranty: 36 Months / 6,000 Hours Parts manufacturer’s warranty o o o

R1.0E

1.1 Manufacturer (abbreviation) HYSTER

1.2 Manufacturer's type designition R1.0E

1.8 Load distance, centre of drive axle to forks x (mm) 361 361 361 271 271 271 181 181 181 181

1.9 Wheelbase y (mm) 1300 1300 1300 1300 1300 1300 1300 1300 1300 1300

2.1 Service weight kg 2389 2389 - 2602 2602 - 2845 2845 - -

2.3 Axle loading, unladen front/rear (1) kg 1522 867 1522 867 - - 1571 1031 1571 1031 - - 1622 1223 1622 1223 - - - -

2.4 Axle loading fork advanced, laden front/rear kg 577 2812 577 2812 - - 693 2909 693 2909 - - 810 3035 810 3035 - - - -

2.5 Axle loading fork retracted, laden front/rear kg 1327 2062 1327 2062 - - 1306 2296 1306 2296 - - 1288 2557 1288 2557 - - - -

4.19 Overall length l1(mm) 2320 2320 2320 2410 2410 2410 2500 2500 2500 2500

4.20 Length to face of forks l2(mm) 1170 1170 1170 1260 1260 1260 1350 1350 1350 1350

4.28 Reach distance l4(mm) 521 521 521 431 431 431 341 341 341 341

4.34.1 Aisle width for pallets 1000mm x 1200mm crossways Ast (mm) 2632 2632 2632 2700 2700 2700 2770 2770 2770 2770

4.34.2 Aisle width for pallets 800mm x 1200mm lengthwise Ast (mm) 2685 2685 2685 2766 2766 2766 2850 2850 2850 2850

4.35 Turning radius Wa(mm) 1555 1555 1555 1555 1555 1555 1555 1555 1555 1555

6.3 Battery according to DIN 43531/35/36 A,B,C, no B B no B B no B B no no

6.4 Battery voltage/nominal capacity K5 (2) (V)/(Ah) 48 280 48 310 48 360(3) 48 420 48 465 48 288(3) 48 560 48 620 48 360(3) 48 432(3)

6.5 Battery weight (3) kg 541 543 544 746 750 746 937 945 937 937

R1.2E

1.1 Manufacturer (abbreviation) HYSTER

1.2 Manufacturer's type designition R1.2E

1.8 Load distance, centre of drive axle to forks x (mm) 361 361 361 271 271 271 181 181 181 181

1.9 Wheelbase y (mm) 1300 1300 1300 1300 1300 1300 1300 1300 1300 1300

2.1 Service weight kg 2389 2389 - 2602 2602 - 2845 2845 - -

2.3 Axle loading, unladen front/rear (1) kg 1522 867 1522 867 - - 1571 1031 1571 1031 - - 1622 1223 1622 1223 - - - -

2.4 Axle loading fork advanced, laden front/rear kg 462 3127 462 3127 - - 577 3225 577 3225 - - 695 3350 695 3350 - - - -

2.5 Axle loading fork retracted, laden front/rear kg 1288 2301 1288 2301 - - 1254 2548 1254 2548 - - 1222 2823 1222 2823 - - - -
