Hytera PD602 User manual

1
Preface
Thanks for your favor in our product. To derive optimum performance from the product, please read this
manual and the supplied Safety Information Booklet carefully before use.
This manual is applicable to the following model:
PD602 VHF Digital Portable Radio

1
Copyright Information
Hytera is the trademark or registered trademark of Hytera Communications Co., Ltd. (the Company) in
PRC and/or other countries or areas. The Company retains the ownership of its trademarks and product
names. All other trademarks and/or product names that may be used in this manual are properties of
their respective owners.
The product describes in this manual may include the Company’s computer programs stored in memory
or other media. Laws in PRC and/or other countries or areas protect the exclusive rights of the Company
with respect to its computer programs. The purchase of this product shall not be deemed to grant, either
directly or by implication, any rights to the purchaser regarding the Company’s computer programs. Any
of the Company’s computer programs may not be copied, modified, distributed, decompiled, or
reverse-engineered in any manner without the prior written consent of the Company.
The AMBE+2TM voice coding technology embodied in this product is protected by intellectual property
rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc. This voice
coding technology is licensed solely for use within this product. The user of this technology is explicitly
prohibited from attempting to decompile, reverse engineer, or disassemble the Object Code or in any
other way convert the Object Code into a human readable form.
U.S. Patent No: #6,912,495 B2, #6,199,037 B1, #5,870,405, #5,826,222, #5,754,974, #5,701,390,
#5,715,365, #5,649,050, #5,630,011, #5,581,656, #5,517,511, #5,491,772, #5,247,579, #5,226,084 and
#5,195,166.
Disclaimer
The Company endeavors to achieve the accuracy and completeness of this manual, but no warranty of
accuracy or reliability is given. All the specifications and designs are subject to change without notice
due to continuous technology development. No part of this manual may be copied, modified, translated,
or distributed in any manner without the express written permission of us.
We do not guarantee, for any particular purpose, the accuracy, validity, timeliness, legitimacy or
completeness of the Third Party products and contents involved in this manual.
If you have any suggestions or would like to learn more details, please visit our website at:
http://www.hytera.com.

1
RF Radiation Information
This product must be restricted to operations in an Occupational/Controlled RF exposure Environments.
The product must be only used by users who are fully aware of the hazards of the exposure and who are
able to exercise control over their RF exposure to qualify for the higher exposure limits.
RF Radiation Profile
Radio Frequency (RF) is a frequency of electromagnetic radiation in the range at which radio signals are
transmitted. RF technology is widely used in communication, medicine, food processing and other fields.
It may generate radiation during use.
RF Radiation Safety
In order to ensure user health, experts from relevant industries including science, engineering, medicine
and health work with international organizations to develop standards for safe exposure to RF radiation.
These standards consist of:
United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2
sub-part J;
American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE)
C95. 1-1992;
Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999;
International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998;
FCC Regulations
Federal Communication Commission (FCC) requires that all radio communication products should meet
the requirements set forth in the above standards before they can be marketed in the U.S, and the
manufacturer shall post a RF label on the product to inform users of operational instructions, so as to
enhance their occupational health against exposure to RF energy.
Operational Instructions and Training Guidelines
To ensure optimal performance and compliance with the occupational/controlled environment RF energy
exposure limits in the above standards and guidelines, users should transmit no more than 50% of the
time and always adhere to the following procedures:
Your radio radiates measurable RF energy only while it is transmitting (during talking), not when it is
receiving (listening) or in standby mode.

2
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct.
The interference by one or more of the following measures:
● Reorient or relocate the receiving antenna. Increase the separation between the equipment and
receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
● Consult the dealer or an experienced radio/TV technician for help
Operation is subject to the following two conditions: 1. This device may not cause harmful interference,
and 2. This device must accept any interference received, including interference that may cause
undesired operation.
Note:” Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.”
Compliance with RF Exposure Standards
Hytera’s 2-way radio complies with the following RF energy exposure standards and guidelines:
•United States Federal Communications Commission, Code of Federal Regulations; 47 CFR §§ 1.1307,
1.1310 and 2.1093
• American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE)
C95. 1-1992
• Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition
RF Exposure Compliance and Control Guidelines and Operating
Instructions
To control your exposure and ensure compliance with the occupational/controlled environment exposure
limits always adhere to the following procedures.
Guidelines:
•Do not remove the RF Exposure Label from the device.
• User awareness instructions should accompany device when transferred to other users.

3
• Do not use this device if the operational requirements described herein are not met.
Operating Instructions:
• Transmit no more than the rated duty factor of 50% of the time. To transmit (talk), push the
Push-To-Talk (PTT) button. To receive calls, release the PTT button. Transmitting 50 % of the time,
or less, is important because this radio generates measurable RF energy exposure only when
transmitting (in terms of measuring for standards compliance).
• Hold the radio in a vertical position in front of face with the microphone (and the other parts of the radio,
including the antenna) at least one inch (2.5 cm) away from the nose. Keeping the radio at the proper
distance is important because RF exposures decrease with distance from the antenna. Antenna
should be kept away from eyes.
• When worn on the body, always place the radio in a Hytera’s approved clip, holder, holster, case, or
body harness for this product. Using approved body-worn accessories is important because the use of
Hytera’s or other manufacturer’s non-approved accessories may result in exposure levels, which exceed
the FCC’s occupational/controlled environment RF exposure limits.
•If you are not using a body-worn accessory and are not using the radio in the intended use position in
front of the face, then ensure the antenna and the radio are kept at least 2.5 cm (one inch) from the body
when transmitting. Keeping the radio at the proper distance is important because RF exposures
decrease with increasing distance from the antenna.
• Use only manufacturer’s name approved supplied or replacement antennas, batteries, and accessories.
Use of non-manufacturer-name approved antennas, batteries, and accessories may exceed the FCC RF
exposure guidelines.
•For a list of Hytera’s approved accessories (see the user manual), or (visit the following website which
lists approved accessories: http: add website address), or(The manufacturer should include the
appropriate bracketed item{s} in the manual.)
• For a list of Hytera’s approved accessories (see the user manual), or (visit the following website which
lists approved accessories: www.hytera.cn
IC statement
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired operation
of the Device.

4
The device has been tested and compliance with SAR limits, users can obtain Canadian information on
RF exposure and compliance
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil nedoit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Après examen de ce matériel aux conformité aux limites DAS et/ou aux limites d’intensité de champ RF,
les utilisateurs peuvent sur l’exposition aux radiofréquences et la conformité and compliance d’acquérir
les informations correspondantes
EU Regulatory Conformance
As certified by the qualified laboratory, the product is in compliance with the essential requirements and
other relevant provisions of the Directive 1999/5/EC. Please note that the above information is
applicable to EU countries only.

5
Contents
1. Documentation Conventions.............................................................................................................8
1.1 Instructional Icons...........................................................................................................................8
1.2 Notational Conventions...................................................................................................................8
1.3 Key Operation.................................................................................................................................8
2. Items in the Package........................................................................................................................10
3. Product Overview.............................................................................................................................11
3.1 Product Controls...........................................................................................................................11
3.2 Programmable Keys .....................................................................................................................12
4. Status Indication ..............................................................................................................................14
4.1 LED Indicator................................................................................................................................14
5. Before Use ........................................................................................................................................15
5.1 Charge the Battery........................................................................................................................15
5.2 Assembling Accessories...............................................................................................................16
5.2.1 Assembling the Antenna .....................................................................................................16
5.2.2 Assembling the Battery.......................................................................................................16
5.2.3 Assembling the Belt Clip.....................................................................................................17
5.2.4 Attaching Audio/Programming Cable..................................................................................17
6. Basic Operations..............................................................................................................................18
6.1 Powering On/Off ...........................................................................................................................18
6.2 Adjusting the Volume....................................................................................................................18
6.3 Adjust Power Level.......................................................................................................................18
6.4 Selecting a Zone...........................................................................................................................18
6.5 Selecting a Channel......................................................................................................................18
6.6 Switching the Channel Mode........................................................................................................18
7. Call.....................................................................................................................................................20
7.1 Private Call ...........................................................................................................................20
7.2 Group Call ............................................................................................................................20
7.3 All Call ..................................................................................................................................20
7.4 Calls on Analog Channels .....................................................................................................20
7.5 One Touch Call.............................................................................................................................21
7.6 Time-out Timer (TOT)...................................................................................................................21
7.7 Busy Channel Lockout..................................................................................................................21
7.8 Pseudo Trunking ..................................................................................................................21
8. Functions and Operations...............................................................................................................22
8.1 Rent..............................................................................................................................................22

6
8.2 Scan..............................................................................................................................................22
8.3 Roam ▼..............................................................................................................................22
8.4 Talk Around ..................................................................................................................................23
8.5 Monitor ....................................................................................................................................23
8.6 Squelch Off ...........................................................................................................................23
8.7 Adjust Squelch Level .............................................................................................................23
8.8 VOX..............................................................................................................................................24
8.9 LQO..............................................................................................................................................24
8.10 Covert Mode ...............................................................................................................................24
8.11 GPS Report ▼..................................................................................................................24
8.12 Battery Power Indicator...............................................................................................................24
8.13 Audio Feedback Suppression.....................................................................................................25
8.14 MIC AGC ....................................................................................................................................25
8.15 Radio Registration Service .................................................................................................25
8.16 Telemetry ▼......................................................................................................................25
8.17 Man Down ▼.............................................................................................................................26
8.18 Lone Worker...............................................................................................................................26
8.19 Priority Interrupt ..........................................................................................................................26
8.19.1 Manual Priority Interrupt ...................................................................................................26
8.19.2 Auto Priority Interrupt........................................................................................................27
8.20 Scrambler /Encrypt ..........................................................................................................27
8.21 Emergency Alarm .......................................................................................................................28
8.21.1 Emergency Type...............................................................................................................28
8.21.2 Emergency ID Type ...................................................................................................28
8.21.3 Emergency Mode..............................................................................................................29
8.21.4 Operation Methods for Analog Emergency ...............................................................29
8.21.5 Operation Method for Digital Emergency .................................................................31
9. Troubleshooting...............................................................................................................................33
10. Care and Cleaning..........................................................................................................................35
11. Optional Accessories.....................................................................................................................36
12. Appendix.........................................................................................................................................38
12.1 Signaling Introduction .................................................................................................................38
12.1.1 HDC1200..........................................................................................................................38
12.1.2 5-Tone...............................................................................................................................38

7
12.1.3 2-Tone...............................................................................................................................39

8
1. Documentation Conventions
For your better understanding of this manual, please read the following conventions first.
1.1 Instructional Icons
Icon Description
Note Indicates references that can further describe the related topics.
Caution Indicates situations that could cause data loss or equipment damage.
▼Indicates that the function is unavailable on PD600X TL LT digital
portable radio.
Indicates functions that are available on digital channel only.
Indicates functions that are available on analog channel only.
Functions marked with no function icons are available on both analog
and digital channels.
1.2 Notational Conventions
Convention Description
“ ” The quotation marks enclose the name of a software interface element.
For example, click “OK”.
Bold The text in boldface denotes the name of a hardware button. For example,
press the PTT key.
->
The symbol directs you to access a multi-level menu. For example, to
select “New” from the “File” menu, we will describe it as follows: File ->
New.
1.3 Key Operation
Operation Definition
Short press To press a key and release it quickly.

9
Operation Definition
Long press To press a key for the preset time (2s by default) and release it.
Hold To press a key and do not release it.

10
2. Items in the Package
Please unpack carefully and check that all items listed below are received. If any item is missing or
damaged, please contact your dealer.
Radio Battery Charger
Power Adapter Antenna Belt clip
Strap Documentation Kit
Note: The frequency band of the antenna is marked on the label of the antenna; if not, refer to the
label on the radio for frequency band information.

11
3. Product Overview
This section introduces the mechanical structure and the programmable key features of this radio.
3.1 Product Controls
No. Part Name No. Part Name
○
1 SK1 (Side Key 1) ○ 8 Power On-Off/Volume Control Knob
○
2 PTT (Push-to-Talk) Key ○ 9 Microphone
○
3 SK2 (Side Key 2) ○ 10 Accessory Jack
○
4 TK (Top Key) ○ 11 Battery latch
○
5 Channel Selector Knob ○ 12 Antenna
○
6 Speaker ○ 13 Belt clip
○
7 LED Indicator ○ 14 Battery

12
3.2 Programmable Keys
For enhanced convenience, you may request your dealer to program the keys SK1, SK2 and TK as
shortcuts to the functions listed below.
No. Shortcut Key Description
1 Zone Up To select a zone quickly
2 Zone Down
3 Adjust Power Level To adjust the power level quickly. The power level: High and Low.
4 Talk Around To switch the operation mode between the Direct mode and the
Repeat mode quickly.
5 Monitor Press this key to switch to the Monitor Squelch Mode, and press it
again to switch to the Rx Squelch Mode.
6 Monitor Momentary
Press this key to start monitoring, and release it to exit monitoring.
This feature is linked with both the long press and short press of the
key.
7 Squelch Off To activate the Squelch Off feature quickly, so the speaker will be
unmuted. The feature will remain active upon radio restart.
8 Squelch Off
Momentary
Press this key to activate the Squelch Off feature momentarily.
Release it to return to the previous mode. The Squelch Off Momentary
feature must be assigned to short press and long press of a key
together.
9 Scan To enable or disable the Scan feature quickly.
10 Nuisance
Temporary Delete To temporarily ignore rarely used channel activity.
11 Adjust Squelch
Level To change the squelch level among Open, Normal and Tight.
12 Battery Power
Indicator
Press this key and check the current battery power status via the LED
indicator.
13 Man Down ▼To enable or disable the Man Down function quickly.
14 Scramble To enable or disable the Scrambler feature quickly. Scrambler is used
to encrypt your voice so as to guarantee privacy of your

13
No. Shortcut Key Description
communication.
15 Encrypt ▼
To enable or disable the Encrypt feature quickly. Encrypt is used to
encrypt your voice and message so as to guarantee privacy of your
communication.
16 Lone Worker To enable or disable the Lone Worker feature quickly.
17 One Touch Call To call the preset contact quickly. At most five keys can be assigned
with this feature.
18 Telemetry ▼To monitor remote equipment.
19 Roam ▼To enable or disable the Roam feature quickly.
20 Priority Interrupt
To terminate the ongoing activity on the current channel, so as to
initiate a new call or data service.
21 VOX To enable or disable the VOX feature quickly.
22 GPS Report ▼To upload the GPS data to the system immediately.
23 Option Board ▼To enable or disable the option board on the current channel.
24 Emergency On To make an emergency call for help in emergent situations.
25 Emergency Off To exit the emergency call.
26 Preset Channel
To switch the channel quickly. The target channel, preset by the
dealer, is a channel from any zone. At most 4 programmable keys can
be assigned with this feature at one time.
27 LQO To enable or disable LQO feature.
28 Covert Mode To enter or exit the Covert mode.
Note:
Long and short press of a key can be assigned with different functions by your dealer.
Short press of the TK key is assigned with the Emergency On feature, long press assigned with
the Emergency Off feature. You can also assign it with other features via your dealer.

14
4. Status Indication
4.1 LED Indicator
The LED on the top of the radio will help you easily identify the current radio status.
LED Indication Radio Status
The LED flashes green. Powering on
The LED glows red. Transmitting
The LED glows green. Receiving
The LED flashes orange
slowly. Scanning
The LED flashes orange
rapidly. Emergency
The LED glows orange. No voice is being transmitted or received on the channel after a call is
established. Within such period, you can hold the PTT key to talk.

15
5. Before Use
5.1 Charge the Battery
Caution: Make sure the radio is powered off during charging.
Use only the charger and battery specified by Hytera. Charger LED can indicate the charging process.
See the table below. The following figure shows the steps for charging.
Step 1 Connect the power adapter to AC socket. See arrow ①.
Step 2 Plug the other end of the power adapter into the rear jack of the charger. See arrow ②.
Step 3 Place the radio with the battery attached, or the battery alone, into the charger. See arrow ③.
During charging, the LED on the charger will indicate the charging status. The charging status begins
when the charger LED glows red. When charging is complete, the charger LED glows green.
See the following table for details.
Note
To achieve optimal battery performance, please charge the battery for 5 hours before initial use.
Be sure to read the Safety Information Booklet to get necessary battery safety information.
LED Indication Charging Status

16
LED Indication Charging Status
The LED flashes red slowly. Standby (no load)
The LED glows red. Charging
The LED glows orange. 90% charged
The LED glows green. Fully charged
The LED flashes red rapidly. Charging failure
5.2 Assembling Accessories
5.2.1 Assembling the Antenna
Turn the antenna clockwise to fasten it. To remove the antenna, rotate it counter-clockwise.
5.2.2 Assembling the Battery
Step 1 Attach the battery as ①shows in the following figure.
Step 2 Slightly press the bottom of the battery until a click is heard. See ②in the following figure.
To remove the battery, turn off the radio first. Then slide the battery latch upwards (as ②shows) to

17
unlock the battery.
5.2.3 Assembling the Belt Clip
Step 1 Remove the screws on the back of the radio, as shown in the following figure.
Step 2 Align the screw holes in the belt clip and on the radio’s back, and then tighten the screws.
To remove the belt clip, loosen the screws.
5.2.4 Attaching Audio/Programming Cable
Step 1 Open the accessory jack cover as the arrow below shows.
Step 2 Align the accessory connector with the accessory jack.
Caution
When aligning, make sure not to scrape the silica gel surrounding the accessory jack
screw hole, in order to ensure the waterproof performance of the radio.
Be sure to align the screw on the accessory connector to the screw hole in the jack
before fastening the screw.
Step 3 Tighten the screw on the connector.
To remove the accessory connector, loosen the screw.

18
6. Basic Operations
6.1 Powering On/Off
Rotate the Power On-Off/Volume Control knob clockwise/counter-clockwise until a click is heard to
turn the radio on/off.
6.2 Adjusting the Volume
After turning the radio on, rotate the Power On-Off/Volume Control knob clockwise to increase the
output sound volume, or counter-clockwise to decrease it.
6.3 Adjust Power Level
With this feature, you may switch power levels quickly. Generally, we recommend you to adopt low
power for battery saving. However, if you cannot communicate with radios located at a distant place with
low power, please select high power.
Operation: Press the programmed Adjust Power Level key to switch the Tx power of the current
channel between High and Low.
6.4 Selecting a Zone
A zone is a group of channels exhibiting the same property. You can list such channels into a zone for
convenient management to them. This radio supports 3 zones: Zone 1, Zone 2 and Zone 3, each of
which can contain 16 channels at most.
You may quickly toggle to your wanted zone by pressing the programmed Zone Up or Zone Down key.
When toggling to a zone, you will hear the alert tone for the zone (one alert tone for Zone 1, two alert
tones for Zone 2 and three alert tones for Zone 3).
6.5 Selecting a Channel
After turning the radio on, rotate the Channel Selector knob to select a needed channel. You can also
switch to the designated channel by pressing the programmed Preset Channel key.
If the Channel Notify function is active, you will hear the corresponding channel number when switching
to any channel.
6.6 Switching the Channel Mode
Each channel can be programmed as either analog channel or digital channel via your dealer. If the
