USER MANUAL
Manufacturer: Hyundai Mobis Co., Ltd.
Model Names: ADB200AAN, ADB400AAN, ADB100AAU, ADB210AAN,
ADB101VAN, ADB401VAN, ADB200AKN, ADB400AKN, ADB101VKN,
ADB401VKN

1
Car Infotainment System
User's Manual
[ This guide covers specifications for
all vehicle models, including optional
specifications, and is based on the latest
version of system software.
[ Your system's functions and
specifications are subject to change
without prior notice for performance
improvement.
[ The functions and services described
in this guide are subject to change
without prior notice for performance
improvement. If the system software is
updated, the screenshots in this guide
may appear different than the actual
images on the system.
[ You can view the up-to-date information
about changed functions and services
from the web manual.
[ The functions and services described
in this guide may differ from those
provided in your vehicle. For precise
information related to your vehicle,
refer to the owner's manual or
catalogue of your vehicle.
Available
information for
users
Car Infotainment
System Quick
Reference Guide (Print)
This guide contains basic information to
use your system including component
names and functions. To use your
system correctly and safely, read this
guide before use.
Car Infotainment
System User's Manual
(Web)
This guide is a web manual you can
access by scanning a QR code in the
Quick Reference Guide or on your
system′s screen. This guide introduces
your system's functions and explains
how to use them.

2
Symbols used in
this guide
Warning
Indicates important information
related to user safety. Failure to follow
warnings may result in death or serious
personal injury.
Caution
Indicates important information related
to user safety. Failure to follow cautions
may result in personal injury, or
damage or malfunction your vehicle.
Note
Indicates helpful information for
convenient use.
(if equipped)
Indicates descriptions for optional
features, which may not be available on
your specific vehicle depending on the
model or trim level.
This guide covers specifications
for all vehicle models, including
optional specifications. It may include
descriptions for features that are
not equipped in your vehicle or are
unavailable for your vehicle model.
Safety warnings
For safety, follow the instructions below.
Failure to do so may increase the risk of a
traffic accident, which may result in death
or personal injury.
Ü About driving
Do not operate the system while
driving.
•Driving while distracted may result in a loss
of vehicle control, potentially leading to an
accident, severe personal injury, or death. The
driver′s primary responsibility is the safe and
legal operation of a vehicle, and any handheld
devices, equipment, or vehicle systems
which divert the driver′s attention from this
responsibility should never be used during
operation of the vehicle.
Avoid watching the screen while driving.
•Driving while distracted may lead to a traffic
accident.
•Stop your vehicle in a safe location before using
functions that require multiple operations.
Stop your vehicle first before using your
mobile phone.
•Using a mobile phone while driving may lead to
a traffic accident.
•If necessary, use the Bluetooth Handsfree
feature to make calls and keep the call as short
as possible.
Keep the volume low enough to hear
external sounds.
•Driving without the ability to hear external
sounds may lead to a traffic accident.
•Listening to a loud volume for a long time may
cause hearing damage.

3
Ü About handling the system
Do not disassemble or modify the
system.
•Doing so may result in an accident, fire, or
electric shock.
Do not allow liquids or foreign
substances to enter the system.
•Liquids or foreign substances may cause
noxious fumes, a fire, or a system malfunction.
Stop using the system if it malfunctions,
such as no audio output or display.
•If you continue using the system when it is
malfunctioning, it may lead to a fire, electric
shock, or system failure.
Û Note
If you experience any problems with the
system, contact your place of purchase or
dealer.
Safety cautions
For safety, follow the instructions below.
Failure to do so may result in personal
injury or damage to the system.
Ý About operating the system
Use the system with the engine
running.
•Using the system for a long time when the
engine is stopped may discharge the battery.
Do not install unapproved products.
•Using unapproved products may cause an error
while using the system.
•System errors caused by installing unapproved
products are not covered under the warranty.

4
Ý About handling the system
Do not apply excessive force to the
system.
•Excessive pressure on the screen may damage
the LCD panel or the touch panel.
When cleaning the screen or button
panel, make sure to stop the engine
and use a soft, dry cloth.
•Wiping the screen or buttons with a rough
cloth or using solvents (alcohol, benzene, paint
thinner, etc.) may scratch or chemically damage
the surface.
If you attach a liquid-type air freshener
to the fan louvre, the surface of the
louvre may become deformed due to
the flowing air.
Û Note
If you experience any problems with the
system, contact your place of purchase or
dealer.

5
1
System overview
Component names and functions 1-2
Control panel 1-2
Steering wheel remote control 1-4
Turning the system on or off 1-5
Turning on the system 1-5
Turning off the system 1-6
Using the touch screen 1-6
Getting to know the Home screen 1-8
Getting familiar with the Home screen
layout 1-8
Changing the Home screen widgets 1-9
Changing the Home screen menu
icons 1-9
Getting to know the All menus
screen 1-10
Getting familiar with the All menus
screen layout 1-10
Rearranging the All menus screen 1-10
Using Favourites 1-11
Adding favourite items 1-11
Rearranging the items in Favourites 1-11
Deleting favourite items 1-11
2
Useful functions
Using phone projection 2-2
Connecting your Android smartphone
via Android Auto 2-2
Connecting your iPhone via Apple
CarPlay 2-4
Getting to know the driving
assistance screen 2-6
Rear view screen 2-6
Steering-interactive camera 2-8
Surround view monitor (if equipped) 2-9
Viewing driving information 2-11
Using the ERA-GLONASS emergency
call service 2-11
3
Radio
Listening to the radio 3-2
Turning on the radio 3-2
Changing the radio mode 3-3
Scanning for available radio stations 3-4
Searching for radio stations 3-5
Saving radio stations 3-6
Listening to saved radio stations 3-7
Rearranging the preset list 3-7
Deleting saved radio stations 3-8
Changing the number of radio stations
on the preset list 3-9
4
Media
Using the media 4-2
Listening to music from a USB device 4-2
Listening to music via Bluetooth 4-6
5
Phone
Connecting Bluetooth devices 5-2
Pairing devices with your system 5-2
Connecting a paired device 5-3
Disconnecting a device 5-4
Deleting paired devices 5-5
Contents

6
Making a call via Bluetooth 5-5
Dialling from your call history 5-6
Dialling from your favourites list 5-7
Dialling from your contacts list 5-9
Dialling from the keypad 5-10
Answering a call via Bluetooth 5-11
Accepting or rejecting a call 5-11
Using functions during a call 5-12
Switching between calls 5-13
6
Voice functions
Using Voice memo 6-2
Starting Voice memo 6-2
Recording voice memos 6-2
Playing voice memos 6-3
7
Settings
Configuring the vehicle settings (if
equipped) 7-2
Drive mode (if equipped) 7-2
Active sound design (if equipped) 7-3
ECO coasting (if equipped) 7-3
Smart posture caring (if equipped) 7-3
Seat position change alert (if
equipped) 7-4
Heating/Ventilation (if equipped) 7-4
Climate (if equipped) 7-4
Configuring the device connection
settings 7-5
Bluetooth 7-5
Android Auto 7-6
Apple CarPlay 7-6
Configuring the advanced system
settings 7-7
Custom button 7-7
Steering wheel MODE button 7-7
Home screen 7-7
Media change notifications 7-8
Keep rear camera on (if equipped) 7-8
Configuring the general system
settings 7-8
Date/Time 7-8
Language 7-9
Keyboard 7-9
Screensaver 7-10
System info 7-10
Configuring the sound settings 7-11
Position 7-11
Volume levels 7-12
Equaliser 7-12
Volume ratio 7-12
Advanced 7-13
Default 7-14
Touch sound (Beep) 7-14
Configuring the display settings 7-14
Dimming 7-14
Brightness 7-15
Blue light 7-16
Default 7-16
8
Appendix
Troubleshooting 8-2
Sound and display 8-2
USB playback 8-3
Bluetooth connection 8-4
Phone projection 8-5
System operation 8-6
System status icons 8-7
FAQ 8-8
Product specifications 8-12
Index 8-16
Trademarks 8-20
Open Source Information 8-20

1
Component names and functions
Turning the system on or off
Using the touch screen
Getting to know the Home screen
Getting to know the All menus screen
Using Favourites
System overview

1-2
Component names and functions
The following explains the names and functions of the components on your system's control
panel and steering wheel remote control.
Control panel
Û Note
Depending on the vehicle model or specifications, the system components' appearance and
layout may differ from the actual product. Refer to the Quick Reference Guide.
Radio button •Turn on the radio. While listening to the radio, press
repeatedly to change the radio mode.
Media button •Play content from a media storage device. If you have
multiple media storage devices, select one from the
media selection window.
•Press and hold to display the media selection window.
Custom button ()•Use a custom function.
•Press and hold to access the Custom button settings
screen. >See ″Custom button.″
Power button (POWER)/
Volume knob (VOL)
•Turn the radio/media function on or off.
•Press and hold to turn off the screen and the sound.
•Turn to the left or right to adjust the system sound
volume.
Reset button •Restart the system.

1-3
Search backward/forward
button (SEEK/TRACK)
•While using the radio/media function, change the
station/track/file.
•While listening to the radio, press and hold to change
the station quickly. (The button′s operation may vary
depending on the radio mode you are using.)
•While playing media, press and hold to rewind or fast
forward (except for the Bluetooth audio mode).
Setup button •Access the settings screen.
•Press and hold to access the System info screen. >See
″System info.″
Search knob (TUNE FILE)•While listening to the radio, adjust the frequency or
change the station.
•While playing media, search for a track/file (except for
the Bluetooth audio mode).
•During a search, press to select the current track/file.

1-4
Steering wheel remote control
Û Note
Depending on the vehicle model or specifications, the system components' appearance and
layout may differ from the actual product. Refer to the Quick Reference Guide.
Voice recognition button ( ) •Start or end voice recognition of a connected
smartphone via phone projection. (The button′s
operation may vary depending on smartphone
specifications.)
Mode button •Change the mode (radio, media, etc.).
•Press and hold to access the Steering wheel MODE
button settings screen. >See ″Steering wheel MODE
button.″
Volume lever/button (+/-)•Adjust the sound volume.
Mute button ()•Mute or unmute the system.
•While playing media, pause or resume playback.
Search lever/button ( ) •While using the radio/media function, change the
station/track/file.
•While listening to the radio, press and hold to change
the station quickly. (The button′s operation may vary
depending on the radio mode you are using.)
•While playing media, press and hold to rewind or fast
forward (except for the Bluetooth audio mode).
Call/Answer button ()•Start connecting a mobile phone via Bluetooth.
•After a Bluetooth phone connection is made, access
your call history. Press and hold to dial the most recent
phone number. When a call comes in, answer the call.
•During a call, switch between the active call and the
held call. Press and hold to switch the call between the
system and the mobile phone.
Call end button ()•When a call comes in, reject the call.
•During a call, end the call.

1-5
Turning the system on
or off
The following explains how to turn the
system on or off.
Turning on the system
1 To turn on the system, start the
engine.
2 When the safety warning
appears, read it and press
Confirm.
•To change the system language,
press Language.
Ü Warning
•Some functions may be disabled for
safety reasons while the vehicle is
moving. They work only when the
vehicle stops. Park your vehicle in a safe
location before using any of them. In a
manual transmission vehicle, apply the
parking brake to use the functions. In an
automatic transmission vehicle, shift to
"P" (Park) or apply the parking brake.
•Stop using the system if it malfunctions,
such as no audio output or display. If
you continue using the system when it
is malfunctioning, it may lead to a fire,
electric shock, or system failure.
Ý Caution
•You can turn on the system when the
key ignition switch is placed in the "ACC"
or "ON" position. Using the system for
an extended period without the engine
running drains the battery. If you plan
on using the system for a long time,
start the engine.
•If you turn on your system without
starting the engine, a battery warning
will appear. Once the engine starts, the
battery warning will disappear.
Û Note
To avoid having audio play at an excessive
volume when you start the engine, adjust
the volume level before stopping the
engine. You can also set the system to
decrease the volume level automatically.
On the Home screen, press All menus >
Settings >Sound >Volume ratio and
activate the Volume limitation on start-
up option.

1-6
Turning off the system
If you do not want to use the
system while driving, press and
hold the Power button on the
control panel.
•The screen and the sound will turn off.
•To use the system again, press the
Power button.
After you have turned off
the engine, the system will
automatically turn off after a
while or as soon as you open the
driver's door.
•Depending on the vehicle model or
specifications, the system may turn off
as soon as you turn off the engine.
Using the touch
screen
Your system is equipped with a touch
screen. You can perform various functions
via touch inputs.
Ý Caution
•Do not apply excessive pressure to the
touch screen or press it with a pointed
object. Doing so may damage the touch
screen.
•Do not let any electrically conductive
material contact the touch screen. A
shock from static electricity may cause
the system or the touch screen to
malfunction.
Û Note
If you wear regular gloves, you will not be
able to control the touch screen. Remove
your gloves or wear gloves designed for
use with a touch screen.
Press
Press an object lightly and lift your
finger. You can perform a function or
select an option.

1-7
Press and hold
Press an object and hold it for at least
one second without lifting your finger.
You can rewind or fast forward media
by pressing and holding an appropriate
button.
Drag
Press an object, drag it, and then drop it
on a new location.
Slide
You can change the playback position
during media playback. On a playback
screen, press and hold the progress bar,
slide your finger along the progress bar,
and then lift it at a desired location.
Swipe
Swipe the screen lightly in an
appropriate direction. This is an easy
way to scroll through a menu or list
quickly.

1-8
Getting to know the
Home screen
From the Home screen, you can access
various functions.
Getting familiar with the
Home screen layout
d
ba
f
e
c
a Display the options list.
•Edit left widget: Change the
functions of the left widget.
•Edit right widget: Change the
functions of the right widget.
•Edit Home icons: Change the
shortcuts for menus you use
frequently on the Home screen.
•Manual: Access the web manual via
the QR code. For safety reasons, you
can access the QR code only when
your vehicle is stationary.
b Current time and date. Press to access
the time and date settings screen.
>See ″Date/Time.″
c System status icons >See ″System
status icons.″
d Left widget. Press to activate the
corresponding function in full screen.
Press and hold to change the widget
to another one. >See ″Changing the
Home screen widgets.″
e Right widget. Press to activate the
corresponding function in full screen.
Press and hold to change the widget
to another one. >See ″Changing the
Home screen widgets.″
f Menu icons. Press to access a selected
function. Press and hold to change
the menu′s type and location. >See
″Changing the Home screen menu icons.″
Û Note
•To move to the Home screen from
another screen, press .
•Depending on the vehicle model or
specifications, the Home screen layout
may vary.

1-9
Changing the Home screen
widgets
You can change the types of widgets
displayed on the Home screen.
1 On the Home screen, press
Menu >Edit left widget or
Edit right widget.
•Alternatively, press and hold the
widget you want to change.
2 Select a desired function.
Û Note
•You cannot set the same function for the
left and right widgets.
•Press Default to restore the default
settings for the widget.
Changing the Home screen
menu icons
You can change the types and locations of
menus on the Home screen.
1 On the Home screen, press
Menu >Edit Home icons.
•Alternatively, press and hold a menu
icon.
2 Press an icon on the menu list,
and drag it to the icon field at
the bottom of the screen.
•To change an icon′s location, press
the icon in the icon field, and drag it
to a desired location.
Û Note
•The All menus icon cannot be changed
to another menu. You can only change
its location.
•Press Default to restore the default
settings for menus.
•Once you change the menus displayed
on the Home screen, it may affect how
to access or perform some functions.
If you cannot find a function you want
from the Home screen, press All menus
to access or perform it.

1-10
Getting to know the
All menus screen
You can view the all menus and access a
desired function in the system.
Getting familiar with the
All menus screen layout
On the Home screen, press All
menus.
a b
c
a Display the options list.
•Rearrange icons: Rearrange the
menus on the All menus screen.
>See ″Rearranging the All menus
screen.″
•Manual: Access the web manual via
the QR code. For safety reasons, you
can access the QR code only when
your vehicle is stationary.
b Return to the previous level.
c All menus available on your system
Rearranging the All menus
screen
Rearrange the menus on the All menus
screen.
1 On the Home screen, press All
menus.
2 Press Menu >Rearrange
icons.
•Alternatively, press and hold
anywhere on the All menus screen.
3 Drag a menu to the desired
location.
Û Note
Press Default to restore the default
settings for the menu order.

1-11
Using Favourites
Add your frequently used functions to
Favourites to access them quickly. You can
add up to 24 items.
Adding favourite items
1 On the Home screen, press All
menus >Favourites >Add to
favourites.
•If you have already added items, on
the Favourites screen, press Menu
>Add.
2 Select items to add and press
Add >Yes.
Rearranging the items in
Favourites
You can rearrange the items added to
Favourites.
1 On the Home screen, press All
menus >Favourites >Menu
>Rearrange icons.
•Alternatively, press and hold an
added item.
2 Drag an item to a desired
location.
Û Note
You can only rearrange the items, and
cannot move an item to an empty slot.
Deleting favourite items
You can delete the items added to
Favourites.
1 On the Home screen, press All
menus >Favourites >Menu
>Delete.
2 Select items to delete and
press Delete >Yes.

2
Useful functions
Using phone projection
Getting to know the driving assistance screen
Viewing driving information
Using the ERA-GLONASS emergency call service
