I-Tech AMil-W1730e-AC User manual

- 1 -
LCD Drawer User Manual
MODEL: AMil-W1730e-AC / AMil-W1730b-AC
17.3" Multi Input LCD Console
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com Modified: 09-16-21

- 2 -
This manual, covering various aspects of the equipment such as installation, setup and
cascade, will help you make full use of this LCD KVM Drawer. Please read this manual
carefully and install and operate the equipment according to the manual to avoid damage to
this product its accessories.
Product package includes following items:
1 *17.3" inch LCD KVM Drawer;
1 * AC Power Cord with lock connector
1 * Rack installation bracket ( one pair )
1 * USER’S manual (CD)
1 * 1.8 Meter VGA cable
1 * 1.8 Meter DVI cable
1 * 1.8 Meter USB A Type cable
Please check items above. If any item is missing or damaged, please contact your dealer
promptly.
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com Modified: 09-16-21

- 3 -
Table of Contents
1 Introduction …………………………………………………………………………-4-
1.1Overview…………………………………………………………………...…. -4-
1.2 Functions & Features…………………………………… ……………...…..-4-
1.3 Hardware Requirement……………………………………………..….……-4-
1.3.1 Host Requirement………………………………………………....… -4-
1.3.2 Cables…………………………………………………………...….… -4-
1.4 Product Specifications………………………………………………..….…..-5-
1.5 LCD Specifications………………………………………………….…..……-5-
1.6 Front View………………………………………………………….…..……. -6-
1.7 Rear View……………………………………………………………..….…...-7-
2 Installation……………………………………………………………………...……-8-
2.1 Rack Installation……………………………………………………………… -8-
2.2 Standard Installation……………….………………………………….…… -9-
2.3 LCD KVM Console and KVM Cascade Installation…………… …….…. -10-
2.4 LCD OSD Menu Setup………………………………………………..….… -11-
3 Certificates………………………………………………………………..….….… -12-
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com Modified: 09-16-21

- 4 -
1 Introduction
1.1 Overview
The 17.3" LCD KVM integrates keyboard, LCD display and touch pad in a drawer type
worktable and provides a convenient space-saving operation mode for KVM switch
technology. The cover is an LCD display,while the base is keyboard and touchpad.
KVM console is a control device integrating 17.3" LCD, 104 keys keyboard and touchpad
mouse. You can access multiple hosts using the LCD console while saving money and
efforts.
LCD KVM console is the best choice to save time and efforts. Since all hosts can be
controlled from a single main control terminal, using the LCD KVM Console:(1)avoids the
cost of keyboard, mouse and monitor of each host; (2) saves work space; (3) saves power;
(4) saves the trouble of moving from one computer to another.
* For Mac and Sun hosts, USB cable must be used for connection.
1.2 Function & Features
The display is integrated to a drawer type worktable of 1U height to facilitate
rack installation. It meets the 1U height of rack specifications and can be
installed into19 inch rack cabinet . No need to install additional software or
hardware.
1.3 Hardware Requirement
1.3.1 Hosts Requirement:
(1) DVI, VGA graphic card
Note:
the max. resolution of the integrated LCD display is 1920x1200 (17.3")
Make sure theresolution of any connected computer does note exceed this resolution.
(2) USB port for keyboard and mouse.
1.3.2 Cables
(1) DB-15 VGA cable male to male
(2) USB A Type Cable
(3) DVI-D Cable male to male
(4) AC Power Cord with lock connector
(3) USB 2.0 Hub for peripheral USB device

- 5 -
1.4 Product Specifications
Model 17.3" LCD-Console
Brightness 400cd/m2
Contrast 1000:1
Angle of visibility 170°(H),176°(V)
Color display 16.7M
Keyboard
Mouse
Keyboard/Mouse
DVI-D
VGA HD-15 female connector
Local Control
Terminal
USB 2.0 For USB peripheral device
Video resolution 1920 x 1080 (17.3")
Power supply
Housing Metal housing
Weight 14Kg
Dimension(W x H x D)
104 keys
touch pad mouse
100-240V AC 50/60Hz via IEC Type power cord
482 x 42 x 660 (mm)
24 pin DVI-D female connector
USB 2.0
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com Modified: 09-16-21

- 6 -
1.6 Front View
NO Part Function Description
1 Handle to adjust screen opsition
2 LCD display
3 Waterproof-Keyboard
4 Waterproof-Touchpad
5 LCD OSD button
6 Mounting bracket Install into rack cabinet
7 Lock button Auto lock / release when lcd pull up and down
LCD button to control Screen Display position and
image setting.
8 USB2.0 HUB port
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com Modified: 09-16-21

- 7 -
1.7 Rear View
No Component Function Description
1 AC Power port MIL lock connector
2 Power Switch Rock switch, turn on/off equipment main power.
3
4
VGA port Connect to server or KVM.
5
USB port
6
DVI port Connect to server or KVM.
USB 2.0
1 2 3
4
Connect to server or KVM.
56
For USB peripheral device
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com Modified: 09-16-21

2 Installation
2.1 Rack Installation
- 8 -
Step 1
Step 2
Attach the two rear slide rails to the rear vertical mounting rails of the rack cabinet using
standard M6 cage nuts and screws.
Step 3
Position the LCD console drawer so the two rear slide rails will slide into the main body
of the LCD console drawer. Attach the mounting ears of the LCD console drawer to the
front vertical mounting rails of the rack cabinet using standard M6 cage nuts and screws.
Rear Cabinet Rails
Rear Slide Rails
Loosen screw Aon both sides to slide out and remove the two rear slide rails.

- 9 -
2.2 Standard Installation
Please follow the installation drawing and instructions below for standard installation:
* Please Shutdown the Power of Equipment Needs to be Connected
* Please Pay Attention to Earthing of Equipment
The standard installation is completed, and LCD KVM console can be powered on. Then
power on connected hosts.
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com Modified: 09-16-21

- 10 -
2.3 LCD KVM Console and KVM Cascade Installation
LCD KVM console port can be directly connector to another KVM Switch as cascade to
Perform unified management all connected hosts. Please follow the installation drawing
and instructions for standard installation:
(1) Make sure to power off all equipment to be connected and existing equipment.
(2) Switching slide switch on USB position
(3) Use an USB / VGA cable to connected the LCD and KVM switch console port.
(4) Turn on the KVM and LCD console power first and then power on hosts to prevent loss of
any keyboard or mouse.
Cascade connection drawing:
VGA USB VGA
USB
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com Modified: 09-16-21

- 11 -
2.4 LCD OSD Menu Setup
OSD Control buttons
LCD OSD can establish and setup LCD display. Setup instructions of four buttons are as
follows:
OSD Control Operation
Main Menu
Button Functions
POWER Turn on or off the LCD Display
MENU Activate OSD menu, select a menu and press MENU key to confirm the
selection and enter the submenu.
▲Press this key to increase setting or scroll up the menu bar
▼Press this key to Decrease setting or scroll down the menu bar
Auto/Source press to seletion video input
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com Modified: 09-16-21

- 12 -
3 Certificates
FCC
This product has been tested and is proved to meet requirements of Grade B electronic
devices and specifications of Section 15 of FCC certification. Please observe following two
conditions in operation that:
(1) The equipment will not generate any harmful interruption.
(2) If the equipment is interrupted, it may cause unnecessary operations.
CE
This equipment complies with regulations of EN55022:CLASS B.
RoHS
The whole package including products, packaging materials and documents meet RoHS
equipments.
