I-Tech NVP2D Series User manual

NVP2D/3D User Manual 2U Multi-Display Console Drawer
NVP2DW17e-4k-L
NVP2DW17e-L
NVP2DW17Me-L
NVP2DW17Xe-L
NVP2D19e-L
NVP3DW17e-4k
NVP3DW17e
NVP3DW17Me
NVP3DW17Xe
NVP2DW17e-4k-R
NVP2DW17e-R
NVP2DW17Me-R
NVP2DW17Xe-R
NVP3D19e NVP2D19e-R
INDUSTRIAL DISPLAY SOLUTIONS
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com Modified Date: 07-13-2021

P. 1
1
2
Carry handle
Installation Slides
LCD module kit
LCD membrane
1
2
3
5
6
7
8
Keylock
Audio speaker ( for SDI option )
Keyboard interchangeable module kit
Mouse interchangeable module kit
6
< 1.1 > Package Content
< Part 1 >
< 1.2 > Structure Diagram
4
7
4
NVP2DW17e / NVP2DW17Me /
NVP2DW17Xe / NVP2D19e X 1
- 6ft DVI cable X 2 or 3
- USB keyboard cable X 1
- Power adapter & Power cord X 1
- M6 screw, cage nut & cup washer X 8
The above package content is only for the single console models.
It varies with options such as SDI & DC power.
NVP2DW17e-4k unit X 1
- 6ft DP cable X 2 or 3
- USB (B) to (A) cable X 1
- Power adapter & Power cord X 1
- M6 screw, cage nut & cup washer X 8
3
5
8
MRK
Package Content
Structure Diagram & Dimension

P. 2
RL C
Model Display Product Dimension
(W x D x H)
Packing Dimension
(W x D x H)
Net
Weight
Gross
Weight
NVP2DW17e-4k
NVP2DW17e
NVP2DW17Me
NVP2DW17Xe
-3 Triple 441.6 x 550 x 88 mm
17.4 x 21.7 x 3.5 inch
580 x 683 x 197 mm
22.8 x 26.9 x 7.8 inch
25.7 kg
56.5 lb
31.1 kg
68.4 lb
-2L Dual LH mounted 441.6 x 550 x 88 mm
17.4 x 21.7 x 3.5 inch
580 x 683 x 197 mm
22.8 x 26.9 x 7.8 inch
21 kg
46.2 lb
26 kg
57.2 lb
-2R Dual RH mounted
The weight is only for the single console models. It varies with accessories & options .
Front View 1mm = 0.03937 inch
Top View
Rear View NVP2DW17e-4k
Side View
Triple display
LC
Dual display ( LH mounted )
R
C
Dual display ( RH mounted )
Power
Central
Left
Right
DP Keyboard
Mouse
Central
Left
Right
Central
Left
Right
DVI-D VGA Power
Keyboard
Mouse
< 1.2 > NVP2DW17e-4k / NVP2DW17e / NVP2DW17Me / NVP2DW17Xe Dimension
NVP2DW17e-4k
NVP2DW17e
NVP2DW17Me
NVP2DW17Xe
NVP2DW17e / NVP2DW17Me / NVP2DW17Xe

P. 3
RL C
Model Display Product Dimension
(W x D x H)
Packing Dimension
(W x D x H)
Net
Weight
Gross
Weight
NVP2D19e
-3 Triple 441.6 x 600 x 88 mm
17.4 x 23.6 x 3.5 inch
580 x 683 x 197 mm
22.8 x 26.9 x 7.8 inch
26.7 kg
58.7 lb
32.1 kg
70.6 lb
-2L Dual LH mounted 441.6 x 600 x 88 mm
17.4 x 23.6 x 3.5 inch
580 x 683 x 197 mm
22.8 x 26.9 x 7.8 inch
22 kg
48.4 lb
27 kg
59.4 lb
-2R Dual RH mounted
The weight is only for the single console models. It varies with accessories & options .
< 1.2 > NVP2D19e Dimension
Front View 1mm = 0.03937 inch
Top View
Rear View
Side View
Triple display
LC
Dual display ( LH mounted )
R
C
Dual display ( RH mounted )
NVP2D19e
Central
Left
Right
DVI-D VGA Power
Keyboard
Mouse
2U
558.9
90°
103.5
559.7 600

P. 4
■Fix the Multi-display console drawer into the rack.
Complete the installation
Step 3
■The left and right rear mounting brackets are
attached to the Multi-display console drawer.
Step 1
< 1.3 > Installation - How to install Installation Slides
Step 2
■Measure the depth of the front and rear mounting rails.
■Align each rear mounting bracket to a suitable length.
■Mounting distance : 550 - 790 mm
M6 screw, cage nut & cup washer x 8 are provided.
Installation

P. 5
■Hold the handle and slide out the drawer.
■Open the Left / Right display.
Step
■ Flip up the LCD to a suitable angle.
Step 1
■ Unlock the key cylinder to 3 o’clock direction.
Step 2
Step 3
Step 4
< 1.3 > Installation - How to Use the Multi-Display Drawer

P. 6
7
The above steps are necessary.
Failure to complete these will cause damage.
■Return the multi-display drawer to park position.
Step
■Must completely extend the drawer before
returning it to the park position.
■Then pull and hold both side release buttons
when pushing the drawer back to the rack.
Step 5
■Operate the multi-display drawer.
Step 6
Step
Step 8
< 1.3 > Installation - How to Use the Multi-Display Drawer
■Close the Left / Right display.
■Flip down the LCD completely.

P. 7
■Pull and hold both side release buttons when
pushing the Multi display console drawer back
to the rack. ( shown in Figure 2 ).
Figure 2.
Figure 1.
■A purple release button is located on the
front of the slide. ( shown in Figure 1 ).
Figure 3. Caution : Keep your ngers away from the slide
stop. ( shown in Figure 3 ).
< 1.3 > Installation - How to Use the Slides

P. 8
Multi-display Console Drawer
< 1.4 > NVP2DW17e-4k connection to DP Server
Caution : The LCD console drawer is hot-pluggable, but components of connected devices, such
as the servers and KVM switch, may not be hot-pluggable. Plugging and unplugging cables while
servers and KVM are powered on may cause irreversible damage to the servers, KVM and LCD
console drawer. Before attempting to connect anything to the LCD console drawer, we suggest
turning o󰀨 the power to all devices. Apply power to connected devices again only after the LCD
console drawer is receiving power. The company is not responsible for damage caused in this way.
DP server
USB (B) to (A)
cable x 1
DP USB type A
* DP cable x 2 and USB (B) to (A) cable x 1 for dual display
DP cable
x 2 or 3
USB type B
Connection
Power
Central
Left
Right
DP Keyboard
Mouse
Central
Left
Right

P. 9
Mult-display Console Drawer
USB server
DVI cable
x 2 or 3
USB KB cable x 1
* DVI cable x 2 and USB KB cable x 1 for dual display
USBDVI
Caution : The LCD console drawer is hot-pluggable, but components of connected devices, such
as the servers and KVM switch, may not be hot-pluggable. Plugging and unplugging cables while
servers and KVM are powered on may cause irreversible damage to the servers, KVM and LCD
console drawer. Before attempting to connect anything to the LCD console drawer, we suggest
turning o󰀨 the power to all devices. Apply power to connected devices again only after the LCD
console drawer is receiving power. The company is not responsible for damage caused in this way.
Central
Left
Right
DVI-D VGA Power
Keyboard
Mouse
< 1.4 > NVP2DW17e / NVP2DW17Me / NVP2DW17Xe / NVP2D19e
connection to USB Server

P.10
Environmental
Conditions
Operating Temperature 0 to 55°C degree
Humidity 20~90%, non-condensing
Altitude 16,000 ft
Storage / Non-operating Temperature -20 to 60°C degree
Humidity 5~90%, non-condensing
Altitude 40,000 ft
Shock 10G acceleration (11ms duration)
Vibration 10~300Hz 0.5G RMS random
< Part 2 >
< 2.1 > Product Specifications - NVP2DW17e-4k
Power Power Supply Range Auto-sensing 100 to 240VAC,
50 / 60Hz
Power Consumption Screen ON Max. 21W
Power saving mode Max. 2W
Power button OFF Max. 1W
LCD
Panel
NVP2DW17e-4k
Native Resolution 3840 x 2160@60Hz
Panel Size ( diagonal ) 17.3-inch TFT color LCD
Brightness ( cd/m² ) 400
Contrast Ratio ( typ. ) 1000:1
Colors 16.7 M, 8-bit
Viewing Angle ( L/R/U/D ) 89/89/89/89
Response Time ( ms ) Max. 16
Dot pitch ( mm ) 0.0995
Display Area ( mm ) 382.12H x 214.94V
Surface treatment Anti-glare
Surface hardness 3H
Backlight Type LED
MTBF ( hrs ) 15,000
Compliance EMC FCC & CE certied
Safety CE / LVD certied
Environment RoHS3 & REACH compliant
Video Package DP 1.2 / HDCP 1.3
Option HDMI 2.0 / HDCP 2.2
Specications / OSD
Product Specications

P. 11
Applicable
Format
Display Port Input PC Signal 3840 x 2160 x 60Hz
1920 x 1080 x 60Hz
1600 x 1200 x 60Hz
1360 x 768 x 60Hz
1280 x 1024 x 60 / 75Hz
1280 x 768 x 60Hz
1024 x 768 x 60 / 70 / 75Hz
800 x 600 x 60 / 72 / 75Hz
720 x 400 x 70Hz
640 x 480 x 60 / 72 / 75Hz
Audio Signal 2ch Linear PCM
HDMI Input HDMI 2.0 3840 x 2160 x 60Hz
HDMI 2.0 / 1.4 3840 x 2160 x 30Hz
1920 x 1080 x 50 / 60Hz ( 1080p )
1920 x 1080 x 25 / 30Hz ( 1080i )
1280 x 720 x 50 / 60Hz ( 720p )
720 x 480 x 50 / 60Hz ( 576p / 480p )
Audio Signal 2ch Linear PCM
* In some circumstances, if the user connects the LCD to PC via HDMI port or video and audio signals, the LCD may display incorrectly
on a full screen. If so, please adjust the display card setting on display size to x the issue.
Physical
Specication
Product ( W x D x H ) mm 441.6 x 550 x 88
inch 17.4 x 21.7 x 3.5
Packing ( W x D x H ) mm 580 x 683 x 197
inch 22.8 x 26.9 x 7.8
Weight
Net Triple display 25.7 kg / 56.5 lb
Dual display 21 kg / 46.2 lb
Gross Triple display 31.1 kg / 68.4 lb
Dual display 26 kg / 57.2 lb
* All dimensions stated are subject to change if options are selected / integrated to base model part codes
< 2.1 > Product Specifications - NVP2DW17e-4k

P.12
Environmental
Conditions
Operating Temperature 0 to 55°C degree
Humidity 20~90%, non-condensing
Altitude 16,000 ft
Storage / Non-operating Temperature -20 to 60°C degree
Humidity 5~90%, non-condensing
Altitude 40,000 ft
Shock 10G acceleration (11ms duration)
Vibration 10~300Hz 0.5G RMS random
Power Power Supply Range Auto-sensing 100 to 240VAC, 50 / 60Hz
Power
Consumption
Screen ON Max. 14W
Power saving mode Max. 2W
Power button OFF Max. 1W
LCD
Panel
NVP2DW17e NVP2DW17Me
Native Resolution 1920 x 1080 1920 x 1080
Panel Size ( diagonal ) 17.3"17.3"
Standard Brightness ( cd/m² ) 300 300
High Brightness ( cd/m² ) - Option 1000 /
Contrast Ratio ( typ. ) 1000:1 800:1
Colors 16.7 M, 8-bit 16.7 M
Viewing Angle ( L/R/U/D ) 80/80/60/80 85/85/85/85
Response Time ( ms ) 5.5 9
Dot pitch ( mm ) 0.1989 0.1989
Display Area ( mm ) 381.888H x 214.812V 337.92H x 270.33V
Surface treatment Anti-glare, Hard-coating Anti-glare
Surface hardness 3H 3H
Backlight Type LED LED
MTBF ( hrs ) 15,000 15,000
Compliance EMC FCC & CE certied
Safety CE / LVD certied
Environment RoHS3 & REACH compliant
Video Package DVI-D + VGA
Option HDMI 1.4 / HDCP 1.4 or DP 1.0 / HDCP 1.3
< 2.1 > Product Specifications - NVP2DW17e / NVP2DW17Me

P.13
Physical
Specication
Product
( W x D x H )
MRK-F17 mm 441.6 x 550 x 88
inch 17.4 x 21.7 x 3.5
MRK-MF17 mm 441.6 x 600 x 88
17.4 x 23.6 x 7.8
inch
Packing ( W x D x H ) mm 580 x 683 x 197
inch 22.8 x 26.9 x 7.8
Net
Weight
MRK-F17 Triple display 25.7 kg / 56.5 lb
Dual display 21 kg / 46.2 lb
MRK-MF17 Triple display 26.7 kg / 58.7 lb
Dual display 22 kg / 48.4 lb
Gross
Weight
MRK-F17 Triple display 31.1 kg / 68.4 lb
Dual display 26 kg / 57.2 lb
MRK-MF17 Triple display 32.1 kg / 70.6 lb
Dual display 27 kg / 59.4 lb
* All dimensions stated are subject to change if options are selected / integrated to base model part codes
< 2.1 > Product Specifications - NVP2DW17e / NVP2DW17Me
Applicable
Format
DVI-D / VGA Input PC Signal 1920 x 1080 x 60Hz
1680 x 1050 x 60Hz
1440 x 900 x 60Hz
1360 x 768 x 60Hz
1280 x 1024 x 60Hz
1280 x 768 x 60Hz
1280 x 720 x 60Hz
1152 x 864 x 60Hz
1024 x 768 x 60Hz
800 x 600 x 60Hz
640 x 480 x 60Hz
Audio Signal 2ch Linear PCM
HDMI Input PC Signal Same as VGA
HDMI 1.4 1920 x 1080 x 50 / 60Hz ( 1080p )
1920 x 1080 x 25 / 30Hz ( 1080i )
1280 x 720 x 50 / 60Hz ( 720p )
720 x 480 x 50 / 60Hz ( 576p / 480p )
Audio Signal 2ch Linear PCM
Display port Input PC Signal 1920 x 1080 x 60Hz
1680 x 1050 x 60Hz
1440 x 900 x 60Hz
1360 x 768 x 60Hz
1280 x 1024 x 60Hz
1280 x 768 x 60Hz
1280 x 720 x 60Hz
1152 x 864 x 60Hz
1024 x 768 x 60Hz
800 x 600 x 60Hz
640 x 480 x 60Hz
Audio Signal 2ch Linear PCM
* In some circumstances, if the user connects the LCD to PC via HDMI port or video and audio signals, the LCD may display incorrectly
on a full screen. If so, please adjust the display card setting on display size to x the issue.

P.14
Environmental
Conditions
Operating Temperature 0 to 55°C degree
Humidity 20~90%, non-condensing
Altitude 16,000 ft
Storage / Non-operating Temperature -20 to 60°C degree
Humidity 5~90%, non-condensing
Altitude 40,000 ft
Shock 10G acceleration (11ms duration)
Vibration 10~300Hz 0.5G RMS random
< 2.1 > Product Specifications - NVP2DW17Xe / NVP2D19e
Power Power Supply Range Auto-sensing 100 to 240VAC, 50 / 60Hz
Power
Consumption
Screen ON Max. 25W Max. 22W
Power saving mode Max. 2W Max. 2W
Power button OFF Max. 1W Max. 1W
LCD
Panel
NVP2DW17Xe NVP2D19e
Native Resolution 1920 x 1200 1280 x 1024
Panel Size ( diagonal ) 16.2"19"
Standard Brightness ( cd/m² ) 300 250
High Brightness ( cd/m² ) - Option / 1000
Contrast Ratio ( typ. ) 600:1 1000:1
Colors 16.7 M, 8-bit 16.7 M
Viewing Angle ( L/R/U/D ) 89/89/89/89 85/85/80/80
Response Time ( ms ) 30 5
Dot pitch ( mm ) 0.191 0.294
Display Area ( mm ) 383.8H x 214.9V 337.92H x 270.33V
Surface treatment Anti-glare, Hard-coating Haze 25%, Hard-coating
Surface hardness 3H 3H
Backlight Type LED LED
MTBF ( hrs ) 20,000 30,000
Compliance EMC FCC & CE certied
Safety CE / LVD certied
Environment RoHS3 & REACH compliant
Video Package DVI-D + VGA DVI-D + VGA
Option HDMI 1.4 / HDCP 1.4 HDMI 1.2 / HDCP 1.1

P.15
Applicable
Format
DVI-D / VGA Input PC Signal 1920 x 1200 x 60Hz ( MRK-X17 only )
1400 x 1050 x 60Hz ( MRK-X17 only )
1440 x 900 x 60Hz ( MRK-X17 only )
1360 x 768 x 60Hz ( MRK-X17 only )
1280 x 1024 x 60 / 75Hz
1280 x 960 x 60Hz
1280 x 768 x 60 / 75Hz
1152 x 864 x 75Hz
1024 x 768 x 60 / 70 / 75Hz
848 x 480 x 60Hz
800 x 600 x 60 / 72 / 75Hz
720 x 400 x 70Hz
640 x 480 x 60 / 72 / 75Hz
640 x 400 x 70Hz
640 x 350 x 70Hz
Audio Signal 2ch Linear PCM
HDMI Input PC Signal Same as VGA
HDMI 1.2 / 1.4 1920 x 1080 x 50 / 60Hz ( 1080p )
( MRK-X17 only )
1920 x 1080 x 25 / 30Hz ( 1080i )
( MRK-X17 only )
1280 x 720 x 50 / 60Hz ( 720p )
720 x 480 x 50 / 60Hz ( 576p / 480p )
Audio Signal 2ch Linear PCM
* In some circumstances, if the user connects the LCD to PC via HDMI port or video and audio signals, the LCD may display incorrectly
on a full screen. If so, please adjust the display card setting on display size to x the issue.
< 2.1 > Product Specifications - NVP2DW17Xe / NVP2D19e
Physical
Specication
Product
( W x D x H )
MRK-X17 mm 441.6 x 550 x 88
inch 17.4 x 21.7 x 3.5
MRK-19 mm 441.6 x 600 x 88
17.4 x 23.6 x 7.8
inch
Packing ( W x D x H ) mm 580 x 683 x 197
inch 22.8 x 26.9 x 7.8
Net
Weight
MRK-X17 Triple display 25.7 kg / 56.5 lb
Dual display 21 kg / 46.2 lb
MRK-19 Triple display 26.7 kg / 58.7 lb
Dual display 22 kg / 48.4 lb
Gross
Weight
MRK-X17 Triple display 31.1 kg / 68.4 lb
Dual display 26 kg / 57.2 lb
MRK-19 Triple display 32.1 kg / 70.6 lb
Dual display 27 kg / 59.4 lb
* All dimensions stated are subject to change if options are selected / integrated to base model part codes

P.16
Key force 55 ± 5g
Travelling distance 3 ± 0.3mm
Switch life > 10 million life cycle time
OS support Windows / Linux / Unix / Mac OS
< 2.2 > Standard Keyboard / Mouse Specications
G keyboard integrated with trackball
Gb
G keyboard integrated with touchpad
Ge
Keyboard / Mouse Specications
Supporting layouts
America
United States
EMEA
United Kingdom Germany France Spain Italy
Asia
Japan Korea
