I-Tech RKP117 User manual

1U Rack mount high bright 17” TFT LCD monitor keyboard drawer / KVM switch
RKP 117, RKP117-801
RKP117-1601
Features:
 Unique mechanical design to
maximize rack mountable space
 Black anodized aluminum front panel
 Adjustable mounting brackets from
15.4” to 31.1” (390 to 790 mm) (front to
rear 19" mounts). Suitable for 30” to
39.4”(750 to 1000mm) deep 19”cabinet
 Keyboard with GlidePoint touch pad
mouse
 Built-in on screen display controlled
by integral membrane switches
 Standard D-sub 15-pin VGA input
connector
 Supplied with 12V 5A remote power
adapter
 All mounting hardware includ
With KVM Features only:
 Multi-platform-mix PCs, SUNs, IBMs, HPs, Compaq &
DELL
 Support 8 characters password protection & search PC
server name
 Cascades for use with up to 128 servers
 New keep alive feature safeguards server for power loss
to the switch
 Built-in microprocessor emulation for each port boots
up process
 Auto scan-mode for monitoring your servers at intervals
5 to 99s
 Hot-pluggable when adding or removing PC w/o
powering down the switch
 Name you server up to 16 characters long
 Supplied w/12V 1A remote power adapter(single power
source)
 Supplied with 8 screened cables 6ft long
 No software needed & all mounting hardware
included
Specification
Monitor
Panel: 17" LCD panel
Display type: TFT / LCD active matrix color
Resolutions: 1280 x 1024
Response time: Tr=5ms/ Tf=20ms
Contrast ratio: 350 : 1 typical
Brightness: 250 cd/m2 typical
Pixel pitch: 0.264mm (H) x 0.264mm (W)
Panel color: 16.7 million display colors
Viewing angle: 150o (Horiz.)/ 125 o(Vert.)
Storage temp. -25oC to 60 oC
Operating temp. 0 oC to 50 oC
MTBF 20,000 hours
KVM
Computer connectors: 8/16
Connector: 15-pin HDB type, Keyboard, mouse, all-in-1
Cascade level: 8
Max. access PCs: 128
Input VGA resolution: 1,920 x 1,440
Power supply
Remote adapter: 110V - 220V AC Input 12V 5A Output
Adapter Size: 4.3”(L) x 2.4” (W) x 1.2”(H) (108x61x30mm)
Cable length from mains plug to adapter: 6ft (182cm)
Cable length from adapter to unit: 6ft (180cm )
Safety approval: UL, CE
Mains plug options available
Product dimension--- 17.3”(W) x 1.75”(H) x 23.64”(D) (439x44.5x600mm)
Packing dimension--- 28.96”(L) x 22.66”(W) x 7”(H) (735x575x180mm)
Weight
Model No KVM Net / Gross weight
RKP1017 Non 24.2 lbs/ 41.8lbs (11kg/19kg)
RKP1017-801 8 port 26.4lbs/ 46.2lbs (12kg/21kg)
RJP1017-1601 16 port 28.6lbs / 48.4lbs ( 13kg/22kg)
Construction
1. Class A active matrix TFT LCD panel
2. Rear metal case
3. 8 or 16-port KVM control board
4. Adjustable mounting bracket
5. Analog-to-digital signal converter board
6. Inverter
7. Ball bearing telescopic slides
8. 8-push-button channel selector switches
9. Front cover
10. Panel button control
11. Front metal case
