DVR PARTS AND DEFINITIONS
Quick Installation Guide
SRX-Pro NVR series
SAFETY
When installing your U1 NVR be sure to avoid:
• Excessive heat, such as direct sunlight or heating appliances
• Contaminants such as dust and smoke
• Strong magnetic fields
• Sources of powerful electromagnetic radiation such as radios or TV transmitters
• Moisture and humidity
• Areas with mechanical vibrations
• Fluorescent lamps or objects that reflect light
• Unstable light sources as this may cause flickering
• Temperatures below 0° C (32° F) or above 45° C (113° F).
POWER SUPPLY
U1 Power consumption requirements: AC 100~ 240VAC.
No. Item Description
1PoE VIDEO IN 16 x 100Mbps RJ45 PoE ports for Ax47R2 or R4
cameras
2 USB 1 USB 3.0 interface / 2 USB 2 interfaces on front
panel
3 Serial Interface 1 × RS-232 (not supported reserved for future use)
4 Network Port RJ45 10/100/1000 Mbps Ethernet interface
5 AUDIO IN Audio Input 1 RCA (2.0Vp-p, 1kΩ)
6 AUDIO OUT Audio Output 1 RCA (2.0Vp-p, 1kΩ)
7 HDMI Output One HDMI video Output
8 VGA Output One VGA video output
9 Sensor Inputs 16 sensor inputs
10 Sensor Outputs 4 sensor outputs (with ground connections)
11 Power Switch Power ON/OFF
12 AC Power In AC Power in Port.
U1 Integrated DVMS
INSTALLATION
Time Zone Adjustment
All NVR units sold by i3 international are pre-set to Eastern Time zone (GMT
-5:00). It is imperative that you configure the time zone setting on the first
system start up. If the NVR is later re-located to a different time zone, this
setting must be changed once again. All previously-recorded data must be
formatted after each time zone change. Failure to do so may result in system
malfunction.
Once the SRX-Pro Server starts for the first time, the message bellow will be
displayed. Click Yes if the NVR is installed in the Eastern Time zone (GMT -5:00)
Click No if the NVR is installed in a different time zone - this will halt the SRX-
Pro software startup and allow you an opportunity to set the time zone.
If the NVR is being installed in a different time zone, follow the instructions below:
1. On Windows Desktop, click on the System Time in the bottom right-hand corner.
2. In the calendar window, click Change date and time settings.
3. In Date and Time tab, click on Change time zone button and select the correct
time zone in the drop down list.
Important: Please use the installation guides that came with your IP cameras
to install the cameras as needed.
The U1 is built in a 1.5U chassis for convenient Rackmount installation.
Follow safety precautions when selecting an installation location for your U1
NVR.
1. Using supplied screws to secure the provided rack brackets to the U1 unit,
then install the U1 NVR into the server rack.
2. Make sure the Power Switch is in the OFF position.
3. Ensure the power source is located within 1 meter (3 feet) from the UPS.
4. Ensure the system and its connecting cables have sufficient space and
that the system is placed on an even surface (shelf or Rackmount).
5. Wait until the system is at room temperature before switching it on.
6. Plug the supplied USB mouse and the USB Keyboard into the USB ports on
the front panel of the machine.
7. Plug in the monitor. Depending on the monitor model, use either the HDMI
(#7) or the VGA (#8) port on the back panel of the machine.
8. Connect all IP cameras into the RJ45 PoE ports (#1).
9. Connect your Sensor Inputs signal cables (where applicable) to RS-485
block (#10) on the rear panel of the machine. Using a pointed object, press
and hold the orange toggle portion of the D+ and D- RS-485 terminals
and insert the correct Sensor signal cables into the slots below. Release
the orange toggle to secure the cables in place. Ensure a secure and tight
cable connection.
10. Connect your Audio IN (#5) and OUT (#6) devices, if using, to the
corresponding RCA connectors on the rear panel.
11. To connect the NVR to your network plug the Network cable into the
Network Port (#4) on the rear panel of the NVR and then plug the other
end into the Network.
12. Connect the provided power cable to the DC Power Supply connector
(#12) and then plug it into the UPS unit.
13. Plug the UPS unit into the wall Power supply. Use of the UPS
(Uninterrupted Power Supply) is highly recommended by i3 for added
reliability and longevity of your NVR.
14. Flip Power Switch (#11) into the ON position. The DVR will power on and
the front panel LEDs light up.
4. Click OK. Click OK again to close Date and Time window.
5. Launch SRX-Pro Server software by clicking on Start > All programs . SRX-Pro
Server.
PACKAGE CONTENTS
Ensure that the items received match the following. In addition to this Quick Guide and the
U1 NVR, the packing box includes:
1. USB keyboard
2. USB mouse
3. Power cable
4. SRX-Pro Software and Utilities
DVD
5. Motherboard CDs
6. Security labels (x2)
7. Rackmount bracket (ear x2) +
bracket screws (x6)
Please Note: It is recommended for optimum system performance the pre-set
standard resolution settings be kept at the defalt settings. These are:
• Sub stream: CIF at 10 frames per second
• Main stream: 1.3MP at 3 frames per second

U1 Integrated DVMS
i3 INTERNATIONAL INC. 1.866.840.0004
www.i3international.com
U.S.A 4450 Witmer Industrial Estates Unit 4
Niagara Falls, NY 14305
Canada 780 Birchmount Road, Unit 16,
Scarborough, ON, M1K 5H4
i3-TRNG-DVR-U1-QIG.indd
QUICK START GUIDE
6. Once the software loads, the following message will be displayed on the
screen.
7. Click OK (Highly recommended) to format all storage drives and erase
video data recorded in a different time zone.
8. Click OK in the “All old data will be formatted” warning window.
9. Wait until the “Start allocating selected drive(s). It may take several minutes
to finish.” message changes to “Storage Drives have been allocated”.
10. Click OK in the Allocation window to close it. The Login window will open
on the screen. See Login Information below.
Main Screen Features
Once logged in you will see the SRX-Pro software main screen. Your connected
cameras will be visible in the Live View Display window. If the cameras are not
visible in the live view mode please contact Tech Support at: 1.877.877.7241 or
by email at: [email protected].
LOGIN INFORMATION
3 users will have been created with different levels of access to the
machine.
Username/Password Level of Access
user1 / manager View/ Search/ Playback/ burn CD-DVD/
View setup tab
user2 / assistant View/ Search/ Playback/ Burn CD-DVD
user3 / associate View/ Search/ Playback
NOTE: It is strongly recommended that after first logging into SRX-Pro as
user1/manager the passwords for all three users should be changed.
Follow the instructions listed below.
1. Click the Setup button from
the icon menu in the upper left
corner of SRX-Pro.
2. Click the User Management Tab.
This will display a list of the users in the left hand panel.
3. Click the User Name on the left to highlight it and then click the Edit
button at the top of the window.
4. The User Information will be displayed in the Right hand pane. Enter a
new Password and confirm the new password. Click “Apply” button at
the bottom to save the changes.
The Main Screen contains the following areas:
1. Menu Bar
2. Live Mode
3. Search Mode
4. Setup Mode
5. Login/Logout
6. Panic
7. PAC
8. Card Access (Portal)
9. 2-Way Audio
10. Screen Divisions
11. Full Screen
12. Rotate Channels
13. Current server Mode
14. SRX-Pro Control Center (tree View)
15. Channels/ Controls/Sensors Panel
16. Advanced Control Panel -PTZ
17. Advanced Data Manager Panel
18. Storage
19. Recording Indicator
20. Current User
21. Location
22. Server ID
23. Current Date/Time
Video Pilot Client (VPC Remote Connection)
Video Pilot Client (VPC) is i3 International’s remote software solution that allows
for simple and efficient video surveillance from a remote location by connect-
ing directly to your U1 DVMS.
Download VPC from our website (i3international.com/index.php/software-
downloads) and install it on your desktop. To launch VPC click the icon on the
Desk Top. You will be asked to enter a User name and Password.
Once you are logged into VPC it will be necessary to add a new server. Mouse
over “Add Server” and click “Add”.
The server information for your U1 will need to be entered. If you do not have
this information please contact Tech Support. For full operational instructions
Please see the full VPC documentation available from our web site.
Cloud Managed Service (CMS)
Cloud Managed Services or CMS is the engine for business insights. If CMS is
part of your U1 package please contact our CMS team
[email protected] to complete the CMS set up.
