i3 International Ax40W2 series User manual

Ax40W2/4/8-series
User Guide
Before attempting to connect or operate this product, read these instructions carefully.
Save this manual for future use.
CONTENTS
1. Warnings and operation notes..........................................3
2. Unpacking....................................................................5
3. Installation.....................................................................6
4. Connecting your IP Camera to the SRX-Pro Server..... ....11
5. Advanced Camera Setup..................................................19
6. Specifications.................................................................36

2
i3-TRNG-CAMS-Ax40W.indd Rev. 141126
Ax40W-series User Guide
COPYRIGHT ©2013 by i3 International, Inc. All rights reserved.
No part of this manual may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including but not limited to, photocopying,
recording, or by any information storage or retrieval system, without the prior
written permission of the copyright owner and the publisher.
Annexxus is a registered trademark of i3 International Inc.
Disclaimer
This quick start guide is provided as is, without warranty of any kind, expressed or
implied, including but not limited to performance, merchantability, or fitness for any
particular purpose. Neither i3 International Inc. nor its dealers or distributors shall be
liable to any person or entity with respect to any liability, loss, or damage, caused or
alleged to have been caused directly or indirectly by this information.
Furthermore, i3 International Inc. reserves the right to revise this publication, and to
make changes to the content at any time, without notice.
FCC
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Address:
i3 International Inc.
780 Birchmount Road, Unit 16
Scarborough, ON M1K 5H4
Canada
Contact us:
Tech Support: 1.877.877.7241
Email. [email protected]
Web Site: www.i3international.com
Table of Contents
1. Warnings and operation notes
2. Product Overview
3. Unpacking
4. Installation
5. Configuration
6. Advanced Camera Setup
7. Specifications

3Rev. 141126i3-TRNG-CAMS-Ax40W.indd
1. Warnings and operation notes
Please read this guide carefully before you install the camera. Keep this
guide for future reference.
Thank you for purchasing an i3 Ax40W-series Mini-dome (Wedge) Fixed camera.
If the system needs to be modified or repaired, contact a certified i3 International
Dealer/Installer. When serviced by unauthorized technician, the system warranty
will be voided. Should you have any problems or questions regarding our products,
contact your local i3 International Dealer/Installer.
1.1 Precautions
Installation and serving should be performed only by qualified and
experienced technicians to conform to all local codes and to maintain
your warranty.
When installing your Ax40W camera be sure to avoid:
• excessive heat, such as direct sunlight or heating appliances
• contaminants such as dust and smoke
• strong magnetic fields
• sources of powerful electromagnetic radiation such as radios or TV transmitters
• moisture and humidity
• areas with mechanical vibrations
• fluorescent lamps or objects that reflect light
• unstable light sources as this may cause flickering
• temperatures below -10° Celsius or 14° Fahrenheit and above 40° Celsius or
104° Fahrenheit.
WARNING! The use of CSA certified/ UL Listed Class 2 power
adapter is required to ensure compliance.
WARNING! To reduce the risk of fire or electric shock, do not
expose the product to rain or moisture.

4
i3-TRNG-CAMS-Ax40W.indd Rev. 141126
1.2 Power Supply
When using 12VDC, ensure the supplied voltage meets the power consumption
requirements of this camera before powering the camera on. Incorrect voltage may
cause irreparable damage to the video camera and will effectively void the camera
warranty. The camera also comes with the built-in PoE power support.
1.3 Cleaning
• For maximum optical clarity, the camera or lens must remain clean. Use a soft,
dry cloth to remove finger prints and dust from the dome cover.
• Use a blower to remove dust from the lens.
• Clean the body with a soft, dry cloth. If it is very dirty, use a cloth dampened
with a small quantity of neutral detergent, then wipe dry.
• Do not use volatile solvents such as alcohol, benzene, or thinners, as they may
damage the surface finish.
1.4 Servicing
To avoid electrical shock and to preserve the product warranty, DO NOT disassemble
the camera. Refer servicing to qualified personnel only.
1.5 Safety Instructions
Equipment to be used in a Network Environment 0 per IEC TR62101. The camera
is to be connected only to PoE network that complies with IEEE 802.3af without
routing to the outside plant.
WARNING! DO NOT connect both PoE and DC12V power connectors
at the same time. For DC power supply use, make sure the polarity is
correct to avoid malfunction and / or camera damage.

5Rev. 141126i3-TRNG-CAMS-Ax40W.indd
2. Unpacking
Check that the items received match those listed on the order form and packing slip.
In addition to this manual and a fully assembled camera, the dome camera packing
box includes:
1. User Manual CD x1
2. Guide Pattern sticker x1
3. 2nd video monitor output BNC cable x1
4. Hex key x1
5. Plastic Anchor x2
6. Round Head Screw (Tapping Type) x2
7. Flat Head Screw (Machine Type 30L) x2
8. Wing (Butterfly) nut x2
9. Washer x2
10. Standard RJ45 Connector x2
11. Desiccant in a package x1
If any parts are missing or damaged, contact the dealer you purchased the camera
from.
Accessories (not to scale)
1
User Guide
IP Finder
2
FRONT
CABLE
90°
0°
270°
180°
54
3
10
67
8 9
11

6
i3-TRNG-CAMS-Ax40W.indd Rev. 141126
3. Installation
Use the appropriate brackets and equipment to mount the camera. After installing
the camera, your network camera should be accessed from your local network.
3.1 Camera Parts
Camera Dome
Camera Body - Side View
Camera Body - Top View
VIDEO OUT
RESET
DEFAULT
VIDEO OUT: Video output connector.
DEFAULT: Press and hold for 5 seconds to return to factory default.
RESET: Press to reboot system.

7Rev. 141126i3-TRNG-CAMS-Ax40W.indd
DC12V
POE/ETHERNET
3.2 Power Connectors
Connect the PoE or DC12V power connector.
PoE (IEEE 802.3af): Connect the RJ-45 connector to a PoE compatible network
device that supplied power through the Ethernet cable.
DC12V: Connect the DC12V power connector to a DC12V power.
WARNING! DO NOT connect both PoE and DC12V power connectors
at the same time. For DC power supply use, make sure the polarity is
correct to avoid malfunction and / or camera damage.

8
i3-TRNG-CAMS-Ax40W.indd Rev. 141126
3.3 Disassembling the Camera
Before you mount and adjust the camera,
follow these steps to disassemble the camera.
1. Using the hex key provided, loosen two
screws on the cover.
2. Remove the dome cover.
3.4 Attaching the Desiccant
1. Take the desiccant out of the package (#11 on Accessories list on page 5)
2. Peel the protective layer revealing the adhesive surface on the desiccant and
attach to the inside of the dome cover as shown in the diagram below.
Peel the
protective layer
on the desiccant
Attach
dessicant to
the inside
of the dome
cover

9Rev. 141126i3-TRNG-CAMS-Ax40W.indd
3.5 Mounting the Camera
Depending on mounting surface, you can use a combination of Plastic Anchors and
Tapping Screws or Machine Type Screws, Wing nuts and Washers.
1. Prepare the mounting surface. Adhere the Mounting Template (#2 on
Accessories list on page 5) to the surface.
2. Drill two screw holes on the mounting surface as well as one round hole
Ø30mm in diameter, according to the template.
3. If installing on solid surface, insert the Plastic Anchors (#6 on Accessories list)
into two holes.
4. Pass all the signal cables through the Ø30mm hole.
5. If installing on solid surface, secure the camera body to the mounting surface
with the Tapping Type Screws (#5 on Accessories list).
If installing on a T-bar ceiling, secure the camera body to the mounting surface
with the Machine Type Screws (#7 on Accessories list) below the mounting
surface and Wing Nut/Washer combo above the mounting surface (#8 & #9 on
Accessories list).
FRONT
CABLE
90°
0°
270°
180°
Ø 30mm
1
2
3
FRONT
CABLE
90°
0°
270°
180°
Ø
30mm
4
3
2
1
SOLID SURFACE MOUNTING T-BAR MOUNTING

10
i3-TRNG-CAMS-Ax40W.indd Rev. 141126
3.6 Adjusting the Camera Position
1. Loosen two screws, as shown in the picture below.
2. Adjust the lens to the desired shooting angle until the required view is achieved
3. Re-tighten the screws once the desired view is achieved.
Loosen two screws
before adjusting the lens
3.7 Completing the Installation
1. Re-attach the dome cover carefully
2. Re-tighten two screws that hold the camera dome cover. This completes the
installation.

11 Rev. 141126i3-TRNG-CAMS-Ax40W.indd
4. Connecting your IP Camera to the SRX-Pro Server
4.1 Camera Connection Options
4.2 Hardware/Software Requirements
The following requirements must be met to achieve a successful network connection
with the Ax40W-series IP camera.
SRX-Pro Server:
• i3 SRX-Pro Version 3.0 or higher
• Latest GiPi adapter is installed. GiPi adapters can be downloaded from i3 FTP
website. (Please contact i3 Technical Support for more information.)
• Windows XP, XPe, 7 Pro or 7e
• Internet Explorer Version 8.0 or later
• CPU: Intel Pentium Core 2 or higher
• Memory: 1GB or more
• VGA card--supporting Direct X 9.0 or above
Power Supply
Your camera requires a DC12V/PoE power supply. Make sure to use the correct
power supply before connecting to this network camera. Use a RJ45 network
connector to connect the camera to your computer or hub switch. Remember, If PoE
(Power over Ethernet) connector is used, an electrical cable is not required
Note: Camera damages resulted from improper power application are
NOT covered by the camera warranty.
i3 SRX-Pro Server
Crossover direct connection
LAN
i3 SRX-Pro Server
Via Gigabit Switch
Connection Type 1:
Connection Type 2:

12
i3-TRNG-CAMS-Ax40W.indd Rev. 141126
Switch
A Gigabit Switch is required to monitor two or more cameras from the same
SRX-Pro Server.
4.3 Configuring Internet Explorer for Video Display
Your Internet Explorer (v.8.0 or higher) must first be configured in order to properly
display video stream from your Annexxus camera.
Follow these instructions to configure your Internet Explorer browser.
Enable Cookies
1. In Internet Explorer window, click Tools -> Internet Options
2. Open Privacy tab, move the slider to “Low” or “Accept All Cookies”
3. Click Apply. Do not close the Internet Options window.
Adjust Internet Security Settings
1. Open Security tab in the Internet Options window
2. If the camera operates inside of the Intranet, click the Intranet icon;
If the camera operates outside outside of the Intranet, click the Internet icon.
3. Click Custom Level. Security Settings - Internet Zone window will be
displayed.
4. Scroll down to the ActiveX controls and plug-ins radio buttons and
configure as follows:
»Automatic prompting for ActiveX controls -> Enable
»Download signed ActiveX controls -> Prompt (recommended)
»Download unsigned ActiveX controls -> Prompt
»Initialize and script ActiveX not marked as safe for scripting -> Prompt
»Run ActiveX controls and plug-ins -> Enable
»Script ActiveX controls marked safe for scripting -> Enable
5. Click OK to save the Internet Security Settings
6. Close all Microsoft Internet Explorer Windows and open a new IE window. This
will allow the new settings to take effect.

13 Rev. 141126i3-TRNG-CAMS-Ax40W.indd
4.4 Using Annexxus Finder to assign IP Address to your IP Camera
To connect your Annexxus camera to your SRX-Pro Server, follow these instructions:
1. Close SRX-Pro Server software by pressing Alt+Shift+Ctrl+F4.
2. Change the IP address on the onboard NIC (LAN) (or on NIC1 if your SRX-Pro
Server has two onboard NIC cards) of your SRX-Pro Server to 192.0.0.XXX to
match the default IP range of your Annexxus IP camera.
3. Connect the network cable from the SRX-Pro Server (crossover direct
connection) or from the Gigabit switch to your Annexxus camera.
4. Turn on your Annexxus camera.
5. Locate the CD that came with your Annexxus camera and insert it in the
CD-ROM drive of your SRX-Pro Server.
6. Double-click “AnnexxusFinder.exe” file to install Annexxus Finder application.
Annexxus Finder application discovers all Annexxus cameras connected to your
network.
7. Follow the Annexxus Finder installation instructions until the application has
been successfully installed on your SRX-Pro Server.
8. Double-click Annexxus Finder icon on the Desktop to launch the application.
The application window will appear displaying a list of active network cameras
Camera’s default IP address is 192.0.0.16
Camera’s default subnet mask address is 255.255.255.0.
Default camera User Name and Password:
FW ver. i3_00_026-40 | User name: admin / Password: 1234
FW ver. i3_00_39-51, or higher | User name: i3admin / PW: i3admin

14
i3-TRNG-CAMS-Ax40W.indd Rev. 141126
9. Next, select desired camera in the Annexxus Finder software by double-clicking
it in the list and click Edit.
10. Enter the new IP address and Subnet Mask of the camera in the Change IP
Address area. The new camera IP address must match the original range
of your SRX-Pro LAN or NIC1 card. E.g. If your original SRX-Pro Server’s IP
address was 192.138.10.122, change your Annexxus camera’s IP address to
192.138.10.XXX.
Remember: Annexxus Cameras cannot share an IP address, each camera
requires its own unique IP address.
11. Enter the default camera password in the Input Password field and click Save.

15 Rev. 141126i3-TRNG-CAMS-Ax40W.indd
12. Wait a few moments as the new IP address is being applied to your Annexxus
camera. Wait for the following message to be displayed. Click OK to close it.
13. Repeat Steps 1-12 for all detected Annexxus cameras in the Annexxus Finder.
14. Now that the new IP address has been successfully assigned to your camera,
make sure you can connect to it through the Internet Explorer:
15. Launch Internet Explorer on your SRX-Pro Server and enter the IP Address you
have just assigned to your Annexxus camera. The password window should be
displayed.
16. Enter the default camera User Name and the default Password.
Default Login/Password:
FW ver. i3_00_026-40 | User name: admin / Password: 1234
FW ver. i3_00_39-51, or higher | User name: i3admin / PW: i3admin

16
i3-TRNG-CAMS-Ax40W.indd Rev. 141126
4.5 Adding your IP Camera to your SRX-Pro Server
1. Make sure that the latest version of GiPi updater is installed on your SRX-Pro
Server. You can download the updates from
ftp://ftp.i3international.com/drivers/gipi
Please contact i3 Technical Support team for access information.
2. Once the latest GiPi updater has been installed, restart i3 SRX-Pro Server
software.
17. Annexxus camera interface will be displayed in the Internet Explorer window.
You should be able to see the camera image on the screen.
If you do not see the camera image on the screen, call i3 International tech
support for help.

17 Rev. 141126i3-TRNG-CAMS-Ax40W.indd
1. Log In and go to the Setup -> IP Camera tab.
2. Click the Search button to display connected Annexxus cameras.

18
i3-TRNG-CAMS-Ax40W.indd Rev. 141126
1. Select the detected camera in the list and click Select.
2. In the Select IP Camera window, enter the default camera User Name and the
default Password, then click Add.
3. The selected camera will be added to the IP Camera list.
Don’t forget to assign the IP camera to the SRX-Pro video channel in the Your
Annexxus camera is now connected to SRX-Pro Server and is ready to record.
You may change resolution and frame rate for the Annexxus camera in the
IP Camera tab menu or you may choose to configure the camera’s advanced
settings (see the following section).
Default Login/Password:
FW ver. i3_00_026-40 | User name: admin / Password: 1234
FW ver. i3_00_39-51, or higher | User name: i3admin / PW: i3admin

19 Rev. 141126i3-TRNG-CAMS-Ax40W.indd
5. Advanced Camera Setup
To access Annexxus camera’s advanced setup, go to Setup -> IP Camera tab, select
the camera in the list of added IP cameras and click the Advanced Setup button.
The password window should be displayed. Enter the default camera User Name
and the default Password. Camera’s user interface will be displayed in a separate
Internet Explorer window.
Default Login/Password:
FW ver. i3_00_026-40 | User name: admin / Password: 1234
FW ver. i3_00_39-51, or higher | User name: i3admin / PW: i3admin

20
i3-TRNG-CAMS-Ax40W.indd Rev. 141126
In the main interface, you may adjust your camera’s
Brightness, Contrast, Saturation and Sharpness levels.
Click Save to save adjusted settings or
Default to set all settings back to 50%.
Note: This panel is enabled in the Live View mode only
and is disabled when in the Setup mode.
Next, click the Setup button to access Annexxus camera Setup features.
5.1 Basic Setup
You may switch to the advanced setup at any time by clicking the button in the
bottom left-hand corner. To switch back to the Basic Setup, click the same button
again.
Basic Setup is divided into Camera and Network settings.
After making any setting adjustments, remember to click the Save button
