IBM 7133 D40 User manual

7133 Models D40 and T40
Serial Disk Systems
Service Guide
GY33-0192-07

7133 Models D40 and T40
Serial Disk Systems
Service Guide
GY33-0192-07

Eighth Edition (October 2002)
This revision supersedes GY33-0192-06. Technical changes are shown by a vertical line to the left of each change.
The following paragraph does not apply to any country where such provisions are inconsistent with local law:
THIS PUBLICATION IS PRINTED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain transactions;
therefore, this statement may not apply to you.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the
information herein; these changes will be incorporated in new editions of the publication.
It is possible that this publication may contain reference to, or information about, products (machines and programs),
programming, or services that are not announced in your country. Such references or information must not be
construed to mean that such products, programming, or services will be offered in your country. Any reference to a
licensed program in this publication is not intended to state or imply that you can use only the licensed program
indicated. You can use any functionally equivalent program instead.
© Copyright International Business Machines Corporation 1998, 2002. All rights reserved.
Note to U.S. Government Users — Documentation related to restricted rights — Use, duplication, or disclosure is
subject to restrictions set forth in the GSA ADP Schedule Contract.

Contents
Communications Statements...................ix
Federal Communications Commission (FCC) Statement ..........ix
Japanese Voluntary Control Council for Interference (VCCI) Statement .....ix
Korean Government Ministry of Communication (MOC) Statement .......ix
New Zealand Compliance Statement .................ix
International Electrotechnical Commission (IEC) Statement .........x
Avis de conformitéàla réglementation d’Industrie Canada..........x
Industry Canada Compliance Statement ................x
United Kingdom Telecommunications Requirements ............x
European Union (EU) Statement ..................x
Radio Protection for Germany ...................x
Taiwan Class A Compliance Statement ................xi
Safety Notices .......................xiii
Definitions of Safety Notices ...................xiii
Safety Notice for Installing, Relocating, or Servicing ...........xiii
Laser Safety Information ....................xiv
About This Book.......................xv
Numbering Convention .....................xv
Trademarks .........................xv
Related Publications ......................xvi
Chapter 1. Reference Information .................1
Controller Card ........................3
SSA Loops and Links ......................3
Advanced SSA Optical Extender (Pair) Feature .............4
Remote Power On Control Feature .................4
−48 Volt Power Supply (Model D40 Only) ...............4
Lights and Controls.......................5
Operator Panel Lights and Controls ................8
Disk Drive Status Lights....................12
Controller Card Light .....................12
Fan Assembly Lights .....................12
Power Supply Assembly Lights and Controls .............13
Bypass Card Lights .....................13
Disk Drive Module Lights ...................15
Other 7133 Settings ......................16
Parts Locations .......................17
Parts Locations (Model D40) ..................18
Parts Locations (Model T40) ..................20
Remote-Power-On Control Unit and Cables ..............21
Advanced SSA Optical Extenders and Fibre Optic Cables .........22
Single-Mode Configuration ...................22
Multi-Mode Configuration ...................24
Specifications for Fibre Optic Cables and Connectors ..........26
Optical Extender Lights ....................26
iii

Connectors .........................27
Back Connectors (Model D40)..................27
Internal Connections (Model D40) ................28
Back Connectors (Model T40)..................29
Internal Connections (Model T40) ................30
SSA Connectors ......................31
Mainline-Power Connector (Model D40, 220 V ac/dc) ..........32
Mainline-Power Connector (Model D40, −48Vdc)...........32
Mainline-Power Connector (Model T40)...............33
Internal Power Connector (Model T40) ...............33
Remote-Power-On Control Unit Connectors and Switch .........34
Power Distribution Schematic ...................35
Labels ..........................36
Product Characteristics .....................38
Dimensions and Weight (Model D40) ...............38
Dimensions and Weight (Model T40) ...............38
AC and DC Input-Voltage Requirements ..............38
Environment .......................38
Altitude .........................40
Heat Output (Maximum)....................40
Sizes of Disk Drive Modules ..................40
Power Sequencing ......................41
Disk Drive Acclimation .....................41
SSA Bypass Cards ......................41
Automatic Mode ......................42
Forced Inline Mode .....................43
Forced Bypass Mode.....................44
Forced Open Mode .....................44
Resetting Bypass Card Modes .................44
Bypass Card Jumpers ....................45
SSA Subsystem Configurations ..................47
Rules for SSA Loops .....................47
Cable Configurations .....................47
Larger Configurations ....................49
SSA Cables for 7133 Models D40 and T40 .............56
Preventing the Isolation of Disk Drives in Higher-Availability Configurations ....57
Physical Location of a Device ...................59
Finding the Device When Service Aids Are Available ..........59
Additional Device Location Information ...............59
Controller Card Microcode Maintenance ...............60
Disk Drive Microcode Maintenance .................60
Vital Product Data (VPD) ....................61
SSA Disk Drives ......................61
7133 Models D40 and T40 ...................61
Service Functions .......................62
7133 Models D40 and T40 Service Aids ..............62
Service Inspection Guide ....................64
Inspection Checklist .....................64
Checking the Grounding of the 7133 ................65
Grounding Check (Model D40) .................65
iv 7133 Models D40 and T40 Service Guide

Grounding Check (Model T40)..................69
Chapter 2. Problem Determination Procedures ............73
Disk Drive Module Power-On Self-Tests (POSTs) ............73
Controller Card Power-On Self-Tests (POSTs) .............74
Service Request Numbers (SRNs) .................75
The SRN Table.......................75
Using the SRN Table.....................75
FRU Names Used in the SRN Table................76
The SRNs ........................77
Maintenance Analysis Procedures (MAPs)...............86
How to Use these MAPs ....................86
MAP 2010: 7133 Models D40 and T40 –START............87
MAP 2020: 7133 Models D40 and T40 –Power .............95
MAP 2022: 7133 Models D40 and T40 –Power-On ...........99
MAP 2030: 7133 Models D40 and T40 –Remote Power On Control Feature 103
MAP 2330: 7133 Models D40 and T40 –Optical Extender .........109
MAP 2410: 7133 Models D40 and T40 –Repair Verification ........131
SSA Link Errors .......................132
Resetting Bypass Card Modes .................132
SSA Link Error Problem Determination ..............132
Link Status (Ready) Lights ..................135
Optical Extender Lights ...................136
Displaying Link Problems ...................136
Chapter 3. Removal and Replacement Procedures ..........137
Concurrent Maintenance ....................137
Covers ..........................138
Operator Panel Flap ....................138
Front Cover (Model D40) ...................139
Front Cover (Model T40) ...................143
Back Cover (Model T40) ...................144
All Power .........................145
Power (Model D40) .....................146
Power (Model T40) .....................148
Disk Drive Modules and Dummy Disk Drive Modules...........150
Removing a Module.....................150
Installing a Module .....................156
Power Supply Assemblies....................162
Removing a Power Supply Assembly ...............163
Installing a Power Supply Assembly ...............168
Fan Assemblies .......................173
Operator Panel and Disk Drive Status Light Assemblies, Flexible Circuits, and
Front Bezel Assembly ....................175
ESD Cover (Model D40) ...................176
Operator Panel Assembly (Model D40) ..............177
Operator Panel Flexible Circuit (Model D40).............179
Disk Drive Status Lights Assembly (Model D40) ...........181
Front Bezel Assembly (Model T40)................183
Operator Panel Assembly and Operator Panel Flexible Circuit (Model T40) 188
Contents v

Disk Drive Status Lights Assembly (Model T40) ...........189
Power Switch and Cable Assembly (Model T40) ............190
Early-Type Power Switch and Cable Assembly ............191
Later-Type Power Switch and Cable Assembly ............193
Converting from Early- to Later-Type Bezel Assembly and Power Switch and
Cable Assembly .....................195
Controller Card Assembly ....................199
Bypass (SNBC) Cards .....................201
Remote-Power-On Control Unit ..................204
Remote-Power-On Control Unit (Model D40) ............204
Remote-Power-On Control Unit (Model T40) ............206
Frame Assembly .......................208
Model D40 in an RS/6000 Rack.................210
Model D40 in a Netfinity Rack .................215
Model T40 ........................218
Removing a 7133 Model D40 from a Rack ..............221
Model D40 in an RS/6000 Rack.................223
Model D40 in a Netfinity Rack .................229
Support Rails ........................232
RS/6000 Support Rails....................232
Netfinity Support Rails ....................237
Chapter 4. Parts Catalog....................241
Conventions ........................241
Assembly 1: 7133 Model D40 ..................242
Assembly 2: 7133 Model T40 ..................248
Country Power Cables .....................252
Appendix A. Additional Information for RISC Systems .........253
Related Publications .....................254
Web Support Pages......................254
Addressing SSA Disk Drives ...................255
Location Code Format ....................255
Pdisks, Hdisks, and Disk Drive Module Identification ..........255
Software and Microcode Errors ..................256
Controller Card Microcode Maintenance ...............257
Downloading Disk Drive Microcode.................258
Diagnostics Information ....................258
Concurrent Diagnostics ...................258
Nonconcurrent Diagnostics ..................258
Problems Corrected.....................258
Displaying Link and Power Problems ................259
Service Aids ........................260
Physical Link Configuration ..................260
Enclosure Configuration ...................262
Enclosure Environment ...................264
Enclosure Settings .....................265
Command Line Tools .....................266
ssaencl Command .....................266
Disk Drive Modules in Use ...................269
vi 7133 Models D40 and T40 Service Guide

Configuring a Disk Drive Module to the Using System ..........271
Configuring a 7133 to the Using System ...............272
Unconfiguring a 7133 from the Using System .............272
MAP Extension .......................273
Appendix B. Additional Information for PC Servers ..........275
Related Publications .....................275
Web Support Pages......................276
Location Code Format .....................277
Software and Microcode Errors ..................277
Controller Card Microcode Maintenance ...............277
Downloading Disk Drive Microcode.................277
Diagnostics Information ....................278
Concurrent Diagnostics ...................278
Nonconcurrent Diagnostics ..................278
Problems Corrected.....................278
Displaying Link and Power Problems ................278
Service Aids ........................279
Command Line Tools .....................279
Disk Drive Modules in Use ...................280
Configuring a Disk Drive Module to the Using System ..........280
Configuring a 7133 to the Using System ...............280
Unconfiguring a 7133 from the Using System .............280
MAP Extension .......................280
Index ..........................281
Contents vii

viii 7133 Models D40 and T40 Service Guide

Communications Statements
The following statements apply to this product. The statements for other products
intended for use with this product appear in their accompanying manuals.
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in which case the
user will be required to correct the interference at his own expense.
Properly shielded and grounded cables and connectors must be used in order to meet
FCC emission limits. Neither the provider nor the manufacturer is responsible for any
radio or television interference caused by using other than recommended cables and
connectors or by unauthorized changes or modifications to this equipment.
Unauthorized changes or modifications could void the user’s authority to operate the
equipment.
This device complies with Part 15 of FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Japanese Voluntary Control Council for Interference (VCCI) Statement
This product is a Class A Information Technology Equipment and conforms to the
standards set by the Voluntary Control Council for Interference by Information
Technology Equipment (VCCI). In a domestic environment, this product might cause
radio interference, in which event the user might be required to take adequate
measures.
Korean Government Ministry of Communication (MOC) Statement
Please note that this device has been approved for business purposes with regard to
electromagnetic interference. If you find that this device is not suitable for your use, you
can exchange it for one that is approved for non-business purposes.
New Zealand Compliance Statement
This is a Class A product. In a domestic environment this product might cause radio
interference, in which event the user might be required to take adequate measures.
ix

International Electrotechnical Commission (IEC) Statement
This product has been designed and built to comply with (IEC) Standard 950.
Avis de conformité à la réglementation d’Industrie Canada
Cet appareil numérique de la classe A est conforme àla norme NMB-003 du Canada.
Industry Canada Compliance Statement
This Class A digital apparatus complies with IECS-003.
United Kingdom Telecommunications Requirements
This apparatus is manufactured to the International Safety Standard EN60950 and as
such is approved in the U.K. under approval number NS/G/1234/J/100003 for indirect
connection to public telecommunications systems in the United Kingdom.
European Union (EU) Statement
This product is in conformity with the protection requirements of EU council directive
89/336/EEC on the approximation of the laws of the Member States relating to
electromagnetic compatibility. Neither the provider nor the manufacturer can accept
responsibility for any failure to satisfy the protection requirements resulting from a
non-recommended modification of the product, including the fitting of option cards not
supplied by the manufacturer.
This product is in conformity with the EU council directive 73/23/EEC (and the
Complementary Markings Directive, 93/68/EEC) on the approximation of the laws of the
Member States relating to electrical equipment designed for use with certain voltage
limits. This conformity is based on compliance with the following harmonized standard:
EN60950.
Radio Protection for Germany
Zulassungsbescheinigung laut Gesetz über die elektromagnetische Verträglichkeit
von Geräten (EMVG) vom 30, August 1995.
Dieses Gerät ist berechtigt in Übereinstimmung mit dem deutschen EMVG das
EG–Konformitätszeichen zu führen.
Der Aussteller der Konformitätserklärung ist die IBM Deutschland.
Informationen in Hinsicht EMVG Paragraph 3 Abs. (2):
Das Gerät erfüllt die Schutzanforderungen nach EN 50082-1 und EN 55022 Klasse A.
EN55022 Klasse A Geräte bedürfen folgender Hinweise:
x7133 Models D40 and T40 Service Guide

Nach dem EMVG: “Geräte dürfen an Orten, für die sie nicht ausreichend entstört sind,
nur mit besonderer Genehmigung des Bundesministeriums für Post und
Telekommunikation oder des Bundesamtes für Post und Telekommunikation betrieben
werden. Die Genehmigung wird erteilt, wenn keine elektromagnetischen Störungen zu
erwarten sind.”(Auszug aus dem EMVG, Para.3, Abs.4). Dieses
Genehmigungsverfahren ist nach Paragraph 9 EMVG in Verbindung mit der
entsprechenden Kostenverordnung (Amtsblatt 14/93) kostenpflichtig.
Nach der EN 55022: “Dies ist eine Einrichtung der Klasse A. Diese Einrichtung kann im
Wohnbereich Funkstörungen verursachen; in diesem Fall kann vom Betreiber verlangt
werden, angemessene Massnahmen durchzuführen und dafür aufzukommen.”
Anmerkung: Um die Einhaltung des EMVG sicherzustellen, sind die Geräte wie in den
Handbüchern angegeben zu installieren und zu betreiben.
Taiwan Class A Compliance Statement
Communications Statements xi

xii 7133 Models D40 and T40 Service Guide

Safety Notices
For a translation of the danger and caution notices contained in this book, see the 7133
Serial Disk Systems and SSA Adapters: Translated Safety Notices manual, SA33-3274.
Definitions of Safety Notices
Adanger notice indicates the presence of a hazard that has the potential of causing
death or serious personal injury.
This book contains a danger notice on pages 147 and 167.
Acaution notice indicates the presence of a hazard that has the potential of causing
moderate or minor personal injury.
This book contains a caution notice on pages 210, 213, 215, 216, 219, 222, 223, 227,
229, and 231.
An attention notice indicates an action that could cause damage to a program, device,
system, or data.
Safety Notice for Installing, Relocating, or Servicing
Before connecting or removing any cables to or from connectors at the using system,
be sure to follow the steps in the installation or relocation checklist specified in the
Installation and Service Guide, or equivalent, for your using system.
For safety checks when servicing, refer to “Service Inspection Guide”on page 64.
xiii

Laser Safety Information
Notes:
1. The information given here applies only to 7133s that have the Advanced SSA
Optical Extender (Pair) feature.
2. The Advanced SSA Optical Extender, referred to in this information as an optical
extender, is part of the serial optic channel converter assembly.
This system contains a laser product called the optical extender. In the United States,
the optical extender is certified as a Class 1 laser product that conforms to the
requirements contained in the Department of Health and Human Services (DHHS)
regulation 21 CFR Subchapter J. Internationally, the optical extender is certified as a
Class 1 laser product that conforms to the requirements contained in the International
Electrotechnical Commission (IEC) standard 825-1 (1993).
Class 1 laser products are not considered to be hazardous. The optical extender
internally contains an indium gallium arsenide / indium phosphide (InGaAs/InP)
semiconductor laser diode emitting in the wavelength range of 1280 to 1340
nanometers. This laser diode is a Class 1 laser that is rated at 5.0 milliwatts. The
design of the optical extender is such that access to laser radiation above a Class 1
level during operation, user maintenance, or service conditions is prevented.
FCC Class A - See Manual
Class 1 Laser Product
Part Number nnnnnnn
CLASS 1 LASER PRODUCT
APPAREIL A LASER DE CLASSE 1
LUOKAN 1 LASERLAITE
TO IEC 825-1:1993
xiv 7133 Models D40 and T40 Service Guide

About This Book
This book provides service information for service representatives who service 7133
Models D40 and T40 Serial Disk Systems. This information is organized as follows:
vChapter 1, “Reference Information”briefly introduces the 7133 Models D40 and T40,
and gives useful reference information.
vChapter 2, “Problem Determination Procedures”gives problem determination
procedures.
vChapter 3, “Removal and Replacement Procedures”gives removal and replacement
procedures.
vChapter 4, “Parts Catalog”is the parts catalog.
vAppendix A, “Additional Information for RISC Systems”gives additional information
for 7133 Models D40 and T40 that are attached to RISC systems.
vAppendix B, “Additional Information for PC Servers”gives additional information for
7133 Models D40 and T40 that are attached to PC servers.
An index is provided at the back of the book.
Important: This book does not include service information for 7133 Models 010, 020,
500, and 600 SSA Disk Subsystems. For those models, see Related
Publications in the “Additional Information”appendix (in this book) for your
using system.
Numbering Convention
In this book, one gigabyte (GB) equals 1 000 000 000 bytes.
Trademarks
The following items are trademarks of International Business Machines Corporation in
the United States, or other countries, or both.
AIX
IBM
RS/6000
Netfinity
Eserver
pSeries
xv

Related Publications
The Installation and Service Guide, or equivalent, for your using system
7133 Models D40 and T40 Serial Disk Systems: Operator Guide, SA33-3278
7133 Model D40 Serial Disk System: Installation Guide, GA33-3279
7133 Model T40 Serial Disk System: Installation Guide, GA33-3280
7133 Models D40 and T40 Serial Disk Systems: Hardware Technical Information,
SA33-3281
7133 Serial Disk Systems and SSA Adapters: Translated Safety Notices,
SA33-3274.
For other publications, see Related Publications in the “Additional Information”appendix
(in this book) for your using system.
For the latest information about SSA, SSA microcode levels, and SSA publications, see
the web support page:
http://www.hursley.ibm.com/ssa/
xvi 7133 Models D40 and T40 Service Guide

Chapter 1. Reference Information
Are You Using the Correct Book? Do not use this book if you are servicing a 7133
Model 010, 020, 500, or 600 SSA Disk Subsystem. For the correct book, see Related
Publications in the “Additional Information”appendix (in this book) for your using
system.
The 7133 Models D40 and T40 Serial Disk Systems (see Figure 1) are Serial Storage
Architecture (SSA) disk subsystems that can be attached to any computer that provides
support for SSA. Model D40 1 is a rack-mounted unit that can be installed in a
standard Electrical Industries Association (EIA) 19-inch rack. Model T40 2 is a
deskside unit.
The 7133 can contain up to 16 SSA disk drive modules (eight at the front and eight at
the back). The disk drive modules are connected to each other in strings of four
modules (two strings at the front of the 7133, and two strings at the back). These
strings can be connected to each other, to strings in other 7133s, or to SSA
attachments (for example, SSA adapters). The SSA attachments can be in separate
using systems or in the same using system.
1
2
Figure 1. 7133 Models D40 and T40
1

The 7133 can be disconnected from its related SSA attachments while the using system
is running. Also, most of the field-replaceable units (FRUs) of the 7133 can be removed
and replaced while the 7133 and the using system are running. For a list of those
FRUs, see “Concurrent Maintenance”on page 137.
Each 7133 Model D40 or Model T40 contains two power supply assemblies and three
fan assemblies, which together provide all the necessary power and cooling. It also
contains a controller card, which monitors and controls the various functions of the
7133. For further details about the controller card, see “Controller Card”on page 3.
The 7133 Models D40 and T40 can be configured to the using system as devices if
applicable. See “Configuring a 7133 to the Using System”in the “Additional Information”
appendix (in this book) for your using system. When a 7133 is configured as a device:
vErrors that are detected in the 7133 are logged in the system error log against that
7133.
vVital product data (VPD) for the 7133 can be accessed.
Each FRU contains its own VPD. A using system can access this VPD while the 7133
is being configured to that particular using system.
Enclosure configuration information is stored in several locations in the 7133 to allow
concurrent replacement of FRUs. (Such information might be, for example, the
information that is displayed on the ID display of the 7133.) When a new FRU is
installed, any special configuration information that is required by that FRU is read from
other locations in the 7133. That information is then used to update the new FRU. To
ensure that the configuration is not corrupted or changed, always exchange FRUs one
at a time. Do not exchange multiple FRUs between 7133s.
27133 Models D40 and T40 Service Guide
