IBM ThinkPad 73P3315 User manual

IBM ThinkPad Multi-Burner Plus Ultrabay
Enhanced Drive
User’s Guide


IBM ThinkPad Multi-Burner Plus Ultrabay
Enhanced Drive
User’s Guide


Note: Before using this information and the product it supports, read the information in
Appendix B, “Service and Support,” on page B-1and Appendix C, “IBM Statement of
Limited Warranty Z125-4753-08 04/2004,” on page C-1.
First Edition (October 2004)
© Copyright International Business Machines Corporation 2004. All rights reserved.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Contents
Safety information . . . . . . . . . .v
General safety guidelines . . . . . . . vii
Service . . . . . . . . . . . . . . . . vii
Power cords and power adapters . . . . . . . vii
Extension cords and related devices . . . . . . viii
Plugs and outlets . . . . . . . . . . . . viii
Batteries . . . . . . . . . . . . . . . viii
Heat and product ventilation . . . . . . . .ix
CD and DVD drive safety . . . . . . . . . .ix
Registering your option . . . . . . . .xi
Chapter 1. About the Multi-Burner Plus
drive . . . . . . . . . . . . . . . 1-1
Product description . . . . . . . . . . . 1-1
Software description . . . . . . . . . . . 1-2
Installation requirements . . . . . . . . . . 1-4
Installing the drive . . . . . . . . . . . . 1-4
Locating the drive controls . . . . . . . . . 1-4
Chapter 2. Using the Multi-Burner Plus
drive . . . . . . . . . . . . . . . 2-1
Before you begin . . . . . . . . . . . . 2-1
Handling and caring for a disc . . . . . . . . 2-1
Caring for the Multi-Burner Plus drive . . . . . 2-2
Loading a disc . . . . . . . . . . . . . 2-3
Using the drive . . . . . . . . . . . . . 2-3
Using single-sided and double-sided DVD-RAM
media . . . . . . . . . . . . . . . 2-3
Removing the disc from the cartridge . . . . 2-3
Returning the disc to the cartridge . . . . . 2-4
Precautions for handling . . . . . . . . . 2-4
Using the drive with CDs and DVDs . . . . . 2-4
Manually ejecting a disc . . . . . . . . . 2-4
Using the DVD player software . . . . . . . 2-5
Using the DVD function . . . . . . . . . . 2-5
Enabling driver letter access (DLA) . . . . . 2-5
Enabling the DMA setting . . . . . . . . 2-6
Using Intervideo WinDVD Creator Plus . . . . . 2-7
Installing WinDVD and viewing a DVD movie 2-7
Starting WinDVD . . . . . . . . . . . 2-8
Using the CD-R and CD-RW function . . . . . 2-9
Using the DVD-R/DVD-RW and
DVD+R/DVD+RW functions . . . . . . . . 2-9
Backing up a CD or DVD . . . . . . . . . 2-9
Problem solving . . . . . . . . . . . . 2-9
Appendix A. Product specifications A-1
Appendix B. Service and Support . . . B-1
Online technical support . . . . . . . . . . B-1
Telephone technical support . . . . . . . . B-1
Appendix C. IBM Statement of Limited
Warranty Z125-4753-08 04/2004 . . . . C-1
Part 1 - General Terms . . . . . . . . . . C-1
Part 2 - Country-unique Terms . . . . . . . C-4
Part 3 - Warranty Information . . . . . . . C-14
Types of Warranty Service . . . . . . . . C-14
Appendix D. Guarantee supplement
for Mexico . . . . . . . . . . . . . D-1
Appendix E. Notices . . . . . . . . E-1
Trademarks . . . . . . . . . . . . . . E-2
Electronic emission notices . . . . . . . . . E-2
Federal Communications Commission (FCC)
statement . . . . . . . . . . . . . . . E-2
© Copyright IBM Corp. 2004 iii

iv IBM ThinkPad Multi-Burner Plus Ultrabay Enhanced Drive: User’s Guide

Safety information
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.
Avant d’installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
Antes de instalar este producto lea la información de seguridad.
© Copyright IBM Corp. 2004 v

Läs säkerhetsinformationen innan du installerar den här produkten.
vi IBM ThinkPad Multi-Burner Plus Ultrabay Enhanced Drive: User’s Guide

General safety guidelines
Always observe the following precautions to reduce the risk of injury and property
damage.
Service
Do not attempt to service a product yourself unless instructed to do so by the IBM
Support Center. Use only an IBM authorized service provider who is approved to
repair your particular product.
Note: Some parts can be upgraded or replaced by the customer. These parts are
referred to as Customer Replaceable Units, or CRUs. IBM expressly identifies CRUs
as such, and provides documentation with instructions when it is appropriate for
customers to replace those parts. You must closely follow all instructions when
performing such replacements. Always make sure that the power is turned off and
that the product is unplugged from any power source before you attempt the
replacement. If you have any questions or concerns, contact the IBM Support
Center.
Power cords and power adapters
Use only the power cords and power adapters supplied by the product
manufacturer.
Never wrap a power cord around the power adapter or other object. Doing so can
stress the cord in ways that can cause the cord to fray, crack or crimp. This can
present a safety hazard.
Always route power cords so that they will not be walked on, tripped over, or
pinched by objects.
Protect the cord and power adapters from liquids. For instance, do not leave your
cord or power adapter near sinks, tubs, toilets, or on floors that are cleaned with
liquid cleansers. Liquids can cause a short circuit, particularly if the cord or power
adapter has been stressed by misuse. Liquids can also cause gradual corrosion of
the power cord terminals and/or the connector terminals on the adapter which can
eventually result in overheating.
Always connect power cords and signal cables in the correct order and ensure that
all power cord connectors are securely and completely plugged into receptacles.
Do not use any power adapter that shows corrosion at the ac input pins and/or
shows signs of overheating (such as deformed plastic) at the ac input or anywhere
on the power adapter.
Do not use any power cords where the electrical contacts on either end show signs
of corrosion or overheating or where the power cord appears to have been
damaged in any way.
© Copyright IBM Corp. 2004 vii

Extension cords and related devices
Ensure that extension cords, surge protectors, uninterruptible power supplies, and
power strips that you use are rated to handle the electrical requirements of the
product. Never overload these devices. If power strips are used, the load should
not exceed the power strip input rating. Consult an electrician for more
information if you have questions about power loads, power requirements, and
input ratings.
Plugs and outlets
If a receptacle (power outlet) that you intend to use with your computer
equipment appears to be damaged or corroded, do not use the outlet until it is
replaced by a qualified electrician.
Do not bend or modify the plug. If the plug is damaged, contact the manufacturer
to obtain a replacement.
Some products are equipped with a three-pronged plug. This plug fits only into a
grounded electrical outlet. This is a safety feature. Do not defeat this safety feature
by trying to insert it into a non-grounded outlet. If you cannot insert the plug into
the outlet, contact an electrician for an approved outlet adapter or to replace the
outlet with one that enables this safety feature. Never overload an electrical outlet.
The overall system load should not exceed 80 percent of the branch circuit rating.
Consult an electrician for more information if you have questions about power
loads and branch circuit ratings.
Be sure that the power outlet you are using is properly wired, easily accessible,
and located close to the equipment. Do not fully extend power cords in a way that
will stress the cords.
Connect and disconnect the equipment from the electrical outlet carefully
Batteries
All IBM personal computers contain a non-rechargeable coin cell battery to provide
power to the system clock. In addition many mobile products such as Thinkpad
notebook PCs utilize a rechargeable battery pack to provide system power when in
portable mode. Batteries supplied by IBM for use with your product have been
tested for compatibility and should only be replaced with IBM approved parts.
Never attempt to open or service any battery. Do not crush, puncture, or incinerate
batteries or short circuit the metal contacts. Do not expose the battery to water or
other liquids. Only recharge the battery pack strictly according to instructions
included in the product documentation.
Battery abuse or mishandling can cause the battery to overheat, which can cause
gasses or flame to “vent” from the battery pack or coin cell. If your battery is
damaged, or if you notice any discharge from your battery or the buildup of
foreign materials on the battery leads, stop using the battery and obtain a
replacement from the battery manufacturer.
Batteries can degrade when they are left unused for long periods of time. For some
rechargeable batteries (particularly Lithium Ion batteries), leaving a battery unused
in a discharged state could increase the risk of a battery short circuit, which could
viii IBM ThinkPad Multi-Burner Plus Ultrabay Enhanced Drive: User’s Guide

shorten the life of the battery and can also pose a safety hazard. Do not let
rechargeable Lithium-Ion batteries completely discharge or store these batteries in a
discharged state.
Heat and product ventilation
Computers generate heat when turned on and when batteries are charging.
Notebook PCs can generate a significant amount of heat due to their compact size.
Always follow these basic precautions:
v Do not leave the base of your computer in contact with your lap or any part of
your body for an extended period when the computer is functioning or when
the battery is charging. Your computer produces some heat during normal
operation. Extended contact with the body could cause discomfort or, potentially,
a skin burn.
v Do not operate your computer or charge the battery near flammable materials or
in explosive environments.
v Ventilation slots, fans and/or heat sinks are provided with the product for safety,
comfort, and reliable operation. These features might inadvertently become
blocked by placing the product on a bed, sofa, carpet, or other flexible surface.
Never block, cover or disable these features.
CD and DVD drive safety
CD and DVD drives spin discs at a high speed. If a CD or DVD is cracked or
otherwise physically damaged, it is possible for the disc to break apart or even
shatter when the CD drive is in use. To protect against possible injury due to this
situation, and to reduce the risk of damage to your machine, do the following:
v Always store CD/DVD discs in their original packaging
v Always store CD/DVD discs out of direct sunlight and away from direct heat
sources
v Remove CD/DVD discs from the computer when not in use
v Do not bend or flex CD/DVD discs, or force them into the computer or their
packaging
v Check CD/DVD discs for cracks before each use. Do not use cracked or
damaged discs
General safety guidelines ix

x IBM ThinkPad Multi-Burner Plus Ultrabay Enhanced Drive: User’s Guide

Registering your option
Thank you for purchasing this IBM
®
product. Please take a few moments to
register your product and provide us with information that will help IBM to better
serve you in the future. Your feedback is valuable to us in developing products
and services that are important to you, as well as in developing better ways to
communicate with you. Register your option on the IBM Web site at
http://www.ibm.com/pc/register/
IBM will send you information and updates on your registered product unless you
indicate on the Web site questionnaire that you do not want to receive further
information.
© Copyright IBM Corp. 2004 xi

xii IBM ThinkPad Multi-Burner Plus Ultrabay Enhanced Drive: User’s Guide

Chapter 1. About the Multi-Burner Plus drive
This manual provides information on registering, installing, and using the IBM
®
ThinkPad
®
Multi-Burner Plus Ultrabay
™
Enhanced Drive, and is available on the
Software and User’s Guide Super CD in the following languages:
v Brazilian Portuguese
v Czech
v English
v French
v German
v Italian
v Japanese
v Simplified Chinese
v Slovak
v Spanish
v Traditional Chinese
v Turkish
The
appendixes of this guide contain warranty information and legal notices.
Product description
Your Multi-Burner Plus is compatible with the DVD Forum DVD-Multi Recorder
specification, and can record as well as read DVD-RAM, DVD-RW, and DVD-R (for
General, 650 nm) media. Your drive can also record DVD+R, DVD+RW, CD-R,
CD-RW, and High-Speed CD-RW media. Buffer underrun prevention is utilized to
ensure reliable burning of DVD-R, DVD+R, and CD-R media. Your Multi-Burner
Plus can read many other formats including DVD Video, Video CD, audio CD,
multiple-session, extended architecture (XA) CDs, and Kodak Photo CDs. The
Multi-Burner Plus is designed for installation in your Ultrabay Enhanced Drive
Bay.
Media type Write speed
CD-R 24X Max.
CD-RW 4X
High Speed CD-RW 10X
Ultra Speed CD-RW 16X
DVD-R 8X Max.
DVD+R 8X Max.
DVD-RW 4X Max.
DVD+RW 4X Max.
DVD-RAM 3X Max.
In addition to this guide, your option package includes the following:
v Multi-Burner Plus drive
v Enhanced Drive Adapter for Ultrabay 2000
v Carrying case
v Software and User’s Guide Super CD
v Quick Reference Guide
© Copyright IBM Corp. 2004 1-1

Contact your place of purchase if an item is missing or damaged. Be sure to retain
your proof of purchase. It might be required to receive warranty service. See
Appendix C, “IBM Statement of Limited Warranty Z125-4753-08 04/2004,” on page
C-1 for technical support information.
Software description
Your IBM Multi-Burner Plus Software and User’s Guide Super CD contains the
following software with the following requirements:
v Intervideo WinDVD Creator Plus
With this software, you can record video files to DVD-RW, DVD+RW, DVD-R, or
DVD+R media that can be played in most stand-alone DVD players. You can
also use this software to edit and modify your own video assets prior to
recording.
If you have an analog or IEEE 1394 capture device installed in your computer,
you can use this software to record video from a camera.
The following table provides information on the Intervideo WinDVD Creator
Plus system requirements.
Computer part Minimum Optimal
Processor Intel Celeron 800Mhz Intel Pentium III 600Mhz
Direct DVD support requires
P4 1.6GHz or higher for
real-time requirement
RAM 64Mb 128Mb
Operating system Windows 2000 or Windows
XP
Windows 2000 or Windows
XP
Sound Windows-compatible sound
card that supports 48KHz
playback
Windows-compatible sound
card that supports 48KHz
playback (PCI recommended)
Video Windows-compatible AGP or
PCI graphic card
Windows-compatible AGP or
PCI graphic card (overlay
support recommended)
Hard drive
v 70 MB for installation
v 620 MB for every hour of
VCD-quality MPEG-1
video
v 2 GB for every hour of
DVD-quality MPEG-2
video
v 70 MB for installation
v 620 MB for every hour of
VCD-quality MPEG-1
video
v 2 GB for every hour of
DVD-quality MPEG-2
video
Others CD or DVD burner required
for VCD and DVD burning.
Appropriate hardware
needed to import video from
external sources, such as DV
cameras and camcorders
Note: WinDVD Creator Plus can import and export DivX content with the DivX
codec pre-installed. DivX is a trademark of DivXNetworks, Inc.
v IBM Drive Letter Access (DLA)
1-2 IBM ThinkPad Multi-Burner Plus Ultrabay Enhanced Drive: User’s Guide

With this software you can write directly to CD-RW, CD-R, DVD-RAM,
DVD-RW, DVD+RW, DVD-R, and DVD+R media using the drive letter as if you
were writing to a diskette. DLA formats all disc format types. With DLA, you
can drag-and-drop files, create new directories, or save files from any application
directly to your Multi-Burner Plus.
v UDF reader
This software enables you to install software for reading DVD-RAM, DVD-RW,
DVD+RW, and CD-RW media on computers with DVD drives. It also allows
you to read DLA-created discs on systems without DLA installed.
v IBM RecordNow
IBM RecordNow is disc mastering software that allows you to create your own
music or data discs from files on your computer, or from other disc media such
as CDs or DVDs. Music discs created with IBM RecordNow will play on any CD
player, whether it’s at home, in your car, or through your computer’s CD-ROM.
IBM RecordNow also makes it easy to create data discs that can be read on any
appropriate CD or DVD disc reader.
Note: Some DVD players cannot read CD-R media. Refer to the documentation
that accompanied your drive for information on supported media.
IBM RecordNow guides you, step-by-step, through the recording process with
simple wizards and an intuitive interface.
Using IBM RecordNow you can create:
– Exact copies of existing discs: The Exact Copy feature makes a duplicate of
your master disc, transferring the disc layout of the original disc to your
CD-R, CD-RW, or DVD media.
– Discs of archived data from your hard drive: The Make a Data Disc feature
stores electronic data, such as the files and applications that reside on your
computer’s hard drive. Unlike music discs, data discs store files that are
readable only by a computer, and cannot be played on your home or car
stereo, even if audio files are on the disc.
– Music compilations from WAV, MP3, or WMA files, or from existing music
discs: The Make a Music Disc feature creates custom music discs from files on
your hard drive or your existing music discs. The CD music database feature
can automatically tag your files with track information to help you sort
through your collection.
Note:
Please refer to the IBM RecordNow On-line Help, for more information on
how to Make an Exact copy, Create a Data Disc, or Create an Audio disc
with IBM RecordNow.
To start RecordNow, complete the following procedure:
1. Click Start.
2. Click Programs.
3. Click IBM RecordNow.
4. Click RecordNow to open the main recording software window.
v
IBM Simple Backup
This software enables you to create full or incremental backups of your system
files on DVD-RAM, DVD-RW, DVD-R, CD-R, CD-RW, DVD+R, or DVD+RW
media, and allows you to restore your computer if it crashes.
v Intervideo WinDVD
This software enables you to play back DVD videos on your computer or to
play video files from your hard disk drive.
Chapter 1. About the Multi-Burner Plus drive 1-3

Note: Some graphics adapters such as the FIREGL, Intergraph, and 3dLabs, do not
support DVD video playback.
Installation requirements
To install the Multi-Burner Plus drive, your ThinkPad computer must meet the
following requirements:
v A ThinkPad system with an Ultrabay Enhanced Drive Bay or ThinkPad Dock or
Dock II
v An Enhanced Drive Adapter for Ultrabay 2000
v The Microsoft
®
Windows
®
XP or Microsoft Windows 2000 Professional operating
system
Notes:
1. IBM offers limited support for computers with Microsoft Windows 95,
Microsoft Windows 98, or Microsoft Windows Millennium Edition (Me)
desktop operating systems.
2. The ThinkPad A21e computer does not support DVD playback under Windows
NT.
Installing the drive
Your ThinkPad computer includes a help system, Access ThinkPad, that provides
drive installation instructions specific to your computer. To correctly install the
multi-burner drive into the Ultrabay enhanced drive bay, use the instructions given
in the Access ThinkPad help system.
Locating the drive controls
The following diagram shows the location of the controls on the front of the drive:
1 Power light: This light is visible when the drive is in use.
2 Eject button: Press this button to eject a DVD or CD.
3 Manual eject hole: Use this emergency release to eject a DVD or CD when the
Eject button does not work. For more information on manually ejecting a DVD or
CD, see “Manually ejecting a disc” on page 2-4.
1-4 IBM ThinkPad Multi-Burner Plus Ultrabay Enhanced Drive: User’s Guide

Chapter 2. Using the Multi-Burner Plus drive
This section provides information on how to handle, load, and care for DVDs and
CDs and on how to care for your Multi-Burner Plus drive.
Before you begin
For best results, review the following guidelines before using the drive:
v Do not move your ThinkPad computer while formatting or writing a disc
because this might cause data errors. Also, minimize typing while formatting or
writing to a disc, as this might also cause data errors.
v Keep the ThinkPad computer on a flat surface when writing to a disc.
v Make sure the ThinkPad computer is plugged into an ac outlet when using the
drive. The disc might be damaged if the battery runs out while writing to a disc.
v Turn screen savers off. Using a screen saver might interrupt the formatting and
writing process.
v Do not put your ThinkPad computer into hibernation or suspend mode while
writing to a disc.
Note:
The read and write results of the drive depend upon the quality and
characteristics of the DVD or CD media used.
Handling and caring for a disc
Carefully handle and clean discs, especially writable media types such as CD-R
and CD-RW discs, so that they remain readable. You can prolong the life of your
discs by using the following precautions:
v Always store discs in their original packaging.
v Always store discs out of direct sunlight.
v Always store discs away from direct heat sources.
v Remove discs from the computer when not in use.
v Check discs for cracks BEFORE each use.
IMPORTANT: Do not use discs that are cracked.
v Do not force discs into the computer or packaging.
v Do not bend or flex discs.
v Do not use commercial cleaners to clean discs.
v Do not write on the surface of discs.
© Copyright IBM Corp. 2004 2-1

v Handle discs by the edges or the center hole.
v Do not touch the surface of discs.
v To remove dust or fingerprints, wipe discs from the center to the edge with a
soft, lint-free cloth.
Attention: Wiping a disc using a circular motion can cause data loss.
Caring for the Multi-Burner Plus drive
To protect your drive during operation, observe the following precautions:
v Remove the disc from the drive before moving the drive.
v Do not insert foreign objects into the drive.
v Do not stack objects on the drive.
v Do not remove the drive cover or attempt to service the drive.
v Do not operate the drive under any of the following conditions:
– High temperature, high humidity, or direct sunlight
– Excessive vibration, sudden shock, or inclined surface
– Excessive dust
2-2 IBM ThinkPad Multi-Burner Plus Ultrabay Enhanced Drive: User’s Guide
