Step 1: Are all of the Internal Options Installed?
These instructions are for 7043 43P Series systems that have internal options (such
as adapters, disk drives, or memory upgrades) already installed. If you have internal
options that are not installed, go to "Installing Optional Features" in the User's Guide,
order number SA38-0511-03, shipped with your system.
Step 2: Check Your Inventory
ØBooks Ø"About Your
Machine"
document
ØSystem Unit
ØSystem Unit
Vertical Stand ØKeys ØDisplay and System Unit
Power Cords
Ø9-pin to 25-pin
Serial Converters
(2)
ØKeyboard
(optional)
Wrist/Palm Rest
(optional)
ØDisplay and Cable
(optional)
1

ØMouse (optional) ØDisplay Cable
Toroid (with Some
Units)
Step 3: Need Help?
If you encounter difficulties while setting up your system unit, contact your sales
representative for assistance.
Step 4: Read the Safety Notices
Safety Note: Before continuing, refer to the System Unit Safety Information book
for Danger and Caution notices. Do not plug any cables into the system unit,
adapters, or electrical outlets until you have reviewed this information. Make
sure none of the power cords are connected before continuing to the next
step.
Step 5: Determine Installation Area
Determine where you are going to install the system unit and if you are using the
system unit in the horizontal or vertical position. If using the vertical position, refer to
“Step 18: Attach the Vertical Stand” on page 10 and then return here.
2Setup Guide

Step 6: Connect the Keyboard and Mouse
Rear of System Unit
If a wrist/palm rest was included with your keyboard and you wish to attach it, refer
to keyboard documentation for installation instructions.
Step 7: Connect the Serial and Parallel Devices
If you have a parallel device (such as a printer), connect it to the parallel connector.
If you have one serial device, connect it to the serial connector S1. If you have an
ASCII terminal, you must connect it to the serial connector S1. An additional serial
device may be connected to the S2 connector.
Two 9-to-25-pin serial converters are provided with your system unit to increase
serial device compatibility.
Parallel
Connector
Serial
Connectors
S2
S1
3

Step 8: Connect the First External SCSI Device
If you have no SCSI devices to attach, skip to “Step 10: Check Your Display Type”
on page 6.
1. Connect the SCSI cable to the SCSI connector.
2. Connect the other end of the SCSI cable to the SCSI device.
3. Connect the SCSI device terminator (If this is the last device connected).
Note: The built-in SCSI interface is Fast/Wide 16-bit SCSI-2 SE. When a cable
is not attached to the SCSI connector on the system unit, the connector
is automatically terminated.
4. Refer to the SCSI device documentation to set the SCSI device address. For
future reference, you can record the address in Appendix A of the User's Guide.
2
SCSI Device
SCSI Device
Terminator
SCSI
Cable
3
1
4Setup Guide

Step 9: Connect Any Additional External SCSI Devices
1. Locate the last SCSI device in the chain from the system unit. Remove the
SCSI device terminator.
2. Connect the new SCSI cable where you just removed the SCSI device
terminator.
3. Connect the other end of the SCSI cable to the new SCSI device.
4. Connect the SCSI device terminator.
5. Refer to the SCSI device documentation to set the SCSI device address. For
future reference, you can record the address in Appendix A of the User's Guide.
6. Repeat this step for each additional SCSI device you attach.
Last
SCSI
Device
SCSI Device
Terminator
New
SCSI
Device
SCSI Device
Terminator
3
1
2
4
New SCSI
Cable
5

Step 10: Check Your Display Type
If you ordered a display with your system unit, the system unit has been set to use
the highest display resolution and refresh rate available for that display. If you want
to:
Attach a different display to your system unit
Change the default display resolution or refresh rate
then after completing the installation steps, refer to the Customer Installable Options
Library CD-ROM for the documentation for the graphics adapter. Change the
settings for the display you are installing.
Step 11: Connect the Display
Connect the display cable to the back of the display and to the graphics adapter
connector. Consult the "About Your Machine" document for the locations of installed
adapters.
For more display instructions, see your display documentation.
Note: Some displays require an additional cable.
1
2
3
4
5
Toroid
6Setup Guide

Step 12: Attach the Display Cable Toroid
If the cable for your display does not include a toroid, locate the toroid shipped with
your system unit and follow the installation instructions included with the toroid.
Step 13: Connect the Adapter Cables
If you are using any optional adapters (such as Token-Ring or 8-port EIA-232),
connect the cables to the appropriate connectors in slots 1, 2, 3, 4, or 5. Consult the
"About Your Machine" document for the locations of installed adapters.
Step 14: Connect Audio Cables
If you are using earphones, microphone or audio equipment, connect the cables to
the appropriate connector.
7

Step 15: Are You Using an Ethernet Connection?
Ask your system administrator if you are not sure. If you are not using Ethernet, go
to “Step 18: Attach the Vertical Stand” on page 10. To connect the Ethernet cable:
For Twisted-Pair (10 Base T for Model 140 and Model 240, 100/10 Base T for
Model 150), go to “Step 16: Connect Twisted-Pair Ethernet” on page 8.
For Thick (10 Base 5 for Model 140 and Model 240, 100/10 Base 5 for Model
150), go to “Step 17: Connect Thick Ethernet” on page 9.
For Thin (10 Base 2 for Model 140 and Model 240, 100/10 Base 2 for Model
150), connect the Thin cable to the optional Transceiver (10 Base 2 for Model
140 and Model 240, 100/10 Base 2 for Model 150), then go to “Step 17: Connect
Thick Ethernet” on page 9
Step 16: Connect Twisted-Pair Ethernet
Note: The twisted-pair connector is compatible with the IEEE 802.3 Ethernet
network (10 Base T link enabled for Model 140 and Model 240, 100/10 Base
T link enabled for Model 150).
Connect the twisted-pair cable to the Twisted-Pair connector.
The twisted-pair Ethernet cable is now installed; go to “Step 18: Attach the
Vertical Stand” on page 10.
8Setup Guide

Step 17: Connect Thick Ethernet
1. Connect your thick Ethernet cable to the ET connector.
2. Lock the thick cable to the Ethernet connector by sliding the Ethernet connector
toward the large notch.
Lock ET
Connector
3. The thick Ethernet cable is now installed. Go to “Step 18: Attach the Vertical
Stand” on page 10.
9

Step 18: Attach the Vertical Stand
If you plan to use your system unit in a vertical position you must use the vertical
stand. To attach the vertical stand, place the system unit on the edge of a table. To
attach the vertical stand, insert the tabs on the vertical stand into the slots in the side
of your system unit, then slide the vertical stand toward the top of the system unit.
10 Setup Guide

Step 19: Set the Power Supply Voltage (Model 140 and Model 240 only)
For nominal input voltages between 100v and 127v, set the switch to 115. For input
voltages between 200v and 240v, set the switch to 230.
Attention: The power supply voltage must be switched to match the voltage
provided by your power outlets. Turning on the system unit with the voltage
selector switch in the wrong position could damage your equipment.
The Model 150 has an autoranging power supply, so you do not have to manually
set the voltage switch.
11

Step 20: Plug in the Power Cables
1. Plug the power cables into the system unit, display, and attached devices.
2. Plug these power cables into electrical outlets.
CAUTION:
This product is equipped with a three-wire power cable and plug for your
safety. Use this power cable with a properly grounded electrical outlet to avoid
electrical shock.
12 Setup Guide

Step 21: Your System Unit Is Now Set Up
Arrange your system unit and attached devices so you can use them comfortably.
For more information on arranging your system unit, visit the Healthy Computing web
site at: http://www.pc.ibm.com/us/healthycomputing
Notes:
1. The system unit can support displays up to 27.3 kg (60 lbs) in weight.
2. Be sure to maintain at least 50 mm (2 in.) of space at the rear of the system unit
to allow for proper cooling.
To power on the system, unlock the cover lock and slide the door to the left to
access the white power switch.
Step 22: Go to Your Operating System Documentation
If an operating system has been preinstalled in your 7043 43P Series system, or if
you plan to install one now, please refer to the operating system installation
documentation.
13
