IBM SAN Volume Controller 2145-8F2 Manual

IBM System Storage SAN Volume Controller
Models 2145-8F2 and 2145-8F4
Hardware Installation Guide
Ve r s i o n 4 . 3 .1
GC27-2221-00


IBM System Storage SAN Volume Controller
Models 2145-8F2 and 2145-8F4
Hardware Installation Guide
Ve r s i o n 4 . 3 .1
GC27-2221-00


Note:
Before using this information and the product it supports, read the information in Safety and environmental notices and
Notices.
This edition applies to the IBM System Storage SAN Volume Controller Models 2145-8F2 and 2145-8F4 running
version 4, release 3, modification 1 of IBM System Storage SAN Volume Controller software and to all subsequent
releases and modifications until otherwise indicated in new editions. The information in this guide was formerly
provided in GC27-2132-02.
© Copyright International Business Machines Corporation 2003, 2008.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Contents
Figures ...............v
Safety and environmental notices . . . vii
Inspecting the SAN Volume Controller for unsafe
conditions...............vii
External device check..........viii
Internal device checks .........viii
Checking the grounding of a SAN Volume
Controller, the uninterruptible power supply, and
the redundant ac-power switch ........ix
Inspecting the uninterruptible power supply for
unsafe conditions .............x
Handling static-sensitive devices .......xi
Environmental notices and statements .....xi
1089CORE ..............xi
Product recycling and disposal .......xii
About this guide ..........xiii
Who should use this guide .........xiii
Emphasis ...............xiii
SAN Volume Controller library and related
publications ..............xiv
Related Web sites ............xvii
How to order IBM publications .......xvii
How to send your comments........xviii
SAN Volume Controller installation
and configuration overview .....xix
Chapter 1. SAN Volume Controller
overview ..............1
Operating environment for the SAN Volume
Controller 2145-8F4 and SAN Volume Controller
2145-8F2 ................1
SAN Volume Controller 2145-8F4 and SAN
Volume Controller 2145-8F2 environment
requirements .............2
SAN Volume Controller 2145-8F4 and SAN Volume
Controller 2145-8F2 controls and indicators ....4
Node status LED ............4
Front-panel display ...........5
Navigation buttons ...........5
Product serial number ..........5
SAN Volume Controller 2145-8F4 and SAN
Volume Controller 2145-8F2 operator information
panel ................6
Select button .............8
Node identification label .........8
ErrorLED..............8
SAN Volume Controller 2145-8F4 and SAN Volume
Controller 2145-8F2 rear panel indicators .....8
SAN Volume Controller 2145-8F4 rear panel
indicators ..............8
SAN Volume Controller 2145-8F2 rear panel
indicators ..............9
Fibre-channel LEDs...........10
External connectors on the SAN Volume Controller
2145-8F4 and the SAN Volume Controller 2145-8F2 . 12
SAN Volume Controller 2145-8F4 connectors . . 12
SAN Volume Controller 2145-8F2 connectors . . 14
SAN Volume Controller 2145-8F4 and SAN Volume
Controller 2145-8F2 fibre-channel port numbers and
worldwide port names ..........15
Chapter 2. Redundant ac-power switch 17
Redundant ac power environment requirements . . 17
Cabling of redundant ac-power switch (example). . 18
Chapter 3. Uninterruptible power
supply ...............21
2145 UPS-1U ..............21
2145 UPS-1U configuration .........21
2145 UPS-1U controls and indicators ......22
Load segment 2 indicator.........24
Load segment 1 indicator.........24
Alarm ...............24
On-battery indicator ..........24
Overload indicator ...........24
Power-on indicator ...........24
On/off button ............25
Test and alarm reset button ........25
2145 UPS-1U connectors and switches .....25
Uninterruptible power-supply environment
requirements ..............27
2145 UPS-1U environment ........27
Power cables for the 2145 UPS-1U ......27
Chapter 4. Installing the SAN Volume
Controller 2145-8F4 or the SAN Volume
Controller 2145-8F2 hardware .....31
Optionally installing the redundant ac-power switch 31
Attaching the mounting plates to the redundant
ac-power switch ............32
Labeling the cables ...........32
Connecting the input-power cables to the
redundant ac-power switch ........33
Installing the redundant ac-power switch in the
rack ................33
Connecting the redundant ac-power switch to the
site power ..............34
Testing the redundant ac-power switch ....35
Installing the 2145 UPS-1U .........35
Installing the support rails for the 2145 UPS-1U 36
Installing the 2145 UPS-1U in the rack ....37
Installing the 2145 UPS-1U cable-retention
bracket ...............42
© Copyright IBM Corp. 2003, 2008 iii
e
ee
11

Installing the SAN Volume Controller 2145-8F2 or
the SAN Volume Controller 2145-8F4 ......43
Installing the support rails for the SAN Volume
Controller 2145-8F4 or the SAN Volume
Controller 2145-8F2 ...........43
Installing the SAN Volume Controller in a rack 46
Connecting the SAN Volume Controller 2145-8F2 or
the SAN Volume Controller 2145-8F4 to the 2145
UPS-1U................47
Installing the SAN Volume Controller 2145-8F4
cable retention bracket..........48
Connecting the SAN Volume Controller 2145-8F4 or
the SAN Volume Controller 2145-8F2 to the SAN
and to the Ethernet network.........49
Verifying the SAN Volume Controller 2145-8F2 or
the SAN Volume Controller 2145-8F4 installation . . 50
Appendix. Accessibility .......55
Notices ..............57
Trademarks ..............59
Electronic emission notices .........59
Federal Communications Commission (FCC)
statement ..............59
Industry Canada compliance statement ....60
Avis de conformité à la réglementation
d’Industrie Canada ...........60
New Zealand compliance statement .....60
European Union EMC Directive conformance
statement ..............60
Germany compliance statement.......61
Japanese Voluntary Control Council for
Interference (VCCI) statement .......62
People’s Republic of China Class A Electronic
Emission Statement...........62
International Electrotechnical Commission (IEC)
statement ..............62
United Kingdom telecommunications
requirements .............62
Korean Class A Electronic Emission Statement. . 62
Taiwan Class A compliance statement ....62
European Contact Information ........63
Taiwan Contact Information .........63
Index ...............65
iv IBM System Storage SAN Volume Controller: Models 2145-8F2 and 2145-8F4 Hardware Installation Guide

Figures
1. SAN Volume Controller 2145-8F2 and SAN
Volume Controller 2145-8F4 front-panel
assembly ..............4
2. SAN Volume Controller 2145-8F2 and SAN
Volume Controller 2145-8F4
operator-information panel ........6
3. SAN Volume Controller 2145-8F4 rear-panel
indicators .............9
4. SAN Volume Controller 2145-8F2 rear-panel
indicators .............9
5. SAN Volume Controller 2145-8F4 fibre-channel
LEDs...............10
6. SAN Volume Controller 2145-8F4 and SAN
Volume Controller 2145-8F2 ac and dc LEDs . 12
7. SAN Volume Controller 2145-8F4 external
connectors .............12
8. Power connector ...........13
9. Service ports of the SAN Volume Controller
2145-8F4 .............13
10. Ports not used during normal operation by the
SAN Volume Controller 2145-8F4 .....14
11. Ports not used on the front panel of the SAN
Volume Controller 2145-8F4 .......14
12. SAN Volume Controller 2145-8F2 external
connectors .............14
13. Power connector ...........15
14. The physical port numbers for the SAN
Volume Controller 2145-8F4 .......15
15. The physical port numbers for the SAN
Volume Controller 2145-8F2 .......15
16. Photo of the redundant ac-power switch 17
17. A four-node SAN Volume Controller cluster
with the redundant ac-power switch feature . 19
18. 2145 UPS-1U front-panel assembly .....22
19. 2145 UPS-1U connectors and switches....25
20. 2145 UPS-1U dip switches .......26
21. Ports not used by the 2145 UPS-1U ....26
22. Power connector ...........26
23. Attaching the mounting plates ......32
24. Power cable clips ..........33
25. Positioning the clips..........34
26. Positioned in rack ..........34
27. Installing the support rails for a 2145 UPS-1U
into the rack ............36
28. Adjusting the rail depth on the 2145 UPS-1U 36
29. Securing the rear rail on the 2145 UPS-1U 37
30. Securing the front rail on the 2145 UPS-1U 37
31. Mounting screws for the 2145 UPS-1U . . . 39
32. Removing the 2145 UPS-1U front panel 39
33. The 2145 UPS-1U internal battery connector
with protective tape..........40
34. The 2145 UPS-1U internal-battery connector 40
35. 2145 UPS-1U (rear view) ........41
36. 2145 UPS-1U front-panel assembly .....41
37. 2145 UPS-1U power cable-retention bracket
hardware .............42
38. 2145 UPS-1U power cable-retention bracket 42
39. Retracting the latch-lock carrier ......43
40. Opening the front latch-lock carrier assembly 44
41. Opening the back latch-lock carrier assembly 44
42. Installing the front end of the rail .....45
43. Closing the latch-lock carrier assembly . . . 46
44. Connecting the SAN Volume Controller
2145-8F2 power cable to the 2145 UPS-1U . . 48
45. Attaching the cable retention bracket to the
SAN Volume Controller 2145-8F4 power cable . 49
46. SAN Volume Controller 2145-8F4 with
cable-retention bracket attached ......49
47. Connectors at the back of the SAN Volume
Controller 2145-8F4 ..........50
48. Connectors at the back of the SAN Volume
Controller 2145-8F2 ..........50
49. Front-panel display when push buttons are
pressed ..............51
50. Node number ............52
51. Ethernet mode ...........52
© Copyright IBM Corp. 2003, 2008 v
1
11
EE

vi IBM System Storage SAN Volume Controller: Models 2145-8F2 and 2145-8F4 Hardware Installation Guide

Safety and environmental notices
Review the multilingual safety notices for the IBM®System Storage™SAN Volume
Controller, redundant ac-power switch, and the uninterruptible power supply
before you install and use the product.
To find the translated text for a caution or danger notice:
1. Look for the identification number at the end of each caution notice or each
danger notice. In the following examples, the numbers (C001) and (D002) are
the identification numbers.
CAUTION:
A caution notice indicates the presence of a hazard that has the potential of
causing moderate or minor personal injury. (C001)
DANGER
A danger notice indicates the presence of a hazard that has the potential
of causing death or serious personal injury. (D002)
2. Locate IBM Systems Safety Notices with the user publications that were provided
with the SAN Volume Controller hardware.
3. Find the matching identification number in the IBM Systems Safety Notices. Then
review the topics concerning the safety notices to ensure that you are in
compliance.
4. Optionally, read the multilingual safety instructions on the SAN Volume
Controller Web site. Go to www.ibm.com/storage/support/2145, click the
current product documentation link, and then click Multi-language.
Inspecting the SAN Volume Controller for unsafe conditions
Use caution when working in any potential safety hazardous situation that is not
covered in the safety checks. If unsafe conditions are present, determine how
serious the hazards are and whether you can continue before you correct the
problem.
Before you start the safety inspection, make sure that the power is off, and that the
power cord is disconnected.
Each device has required safety items installed to protect users and IBM service
personnel from injury. This guide addresses only those items.
Important: Good judgment must also be used to identify potential safety hazards
due to the attachment of non-IBM features or options not covered by
this inspection guide.
If any unsafe conditions are present, you must determine how serious the apparent
hazard could be and whether you can continue without first correcting the
problem. For example, consider the following conditions and their potential safety
hazards:
Electrical hazards (especially primary power)
Primary voltage on the frame can cause serious or lethal electrical shock.
© Copyright IBM Corp. 2003, 2008 vii

Explosive hazards
A damaged CRT face or a bulging capacitor can cause serious injury.
Mechanical hazards
Loose or missing items (for example, nuts and screws) can cause serious
injury.
To inspect each SAN Volume Controller node for unsafe conditions, perform the
following steps. If necessary, see any suitable safety publications.
1. Turn off the SAN Volume Controller and disconnect the power cord.
2. Check the frame for damage (loose, broken, or sharp edges).
3. Check the power cables using the following steps:
a. Ensure that the third-wire ground connector is in good condition. Use a
meter to check that the third-wire ground continuity is 0.1 ohm or less
between the external ground pin and the frame ground.
b. Ensure that the power cord is the appropriate type, as specified in the parts
listings.
c. Ensure that the insulation is not worn or damaged.
4. Check for any obvious nonstandard changes, both inside and outside the unit.
Use good judgment about the safety of any such changes.
5. Check inside the SAN Volume Controller for any obvious unsafe conditions,
such as metal particles, contamination, water or other fluids, or marks of
overheating, fire, or smoke damage.
6. Check for worn, damaged, or pinched cables.
7. Ensure that the voltage that is specified on the product-information label
matches the specified voltage of the electrical power outlet. If necessary, verify
the voltage.
8. Inspect the power-supply assemblies and check that the fasteners (screws or
rivets) in the cover of the power-supply unit have not been removed or
disturbed.
9. Before connecting the SAN Volume Controller to the storage area network
(SAN), check the grounding.
External device check
Ensure that you perform an external device check before you install the SAN
Volume Controller.
To conduct an external device check, perform the following steps:
1. Verify that all external covers are present and are not damaged.
2. Ensure that all latches and hinges are in the correct operating condition.
3. If the SAN Volume Controller is not installed in a rack cabinet, check for loose
or broken feet.
4. Check the power cord for damage.
5. Check the external signal cable for damage.
6. Check the cover for sharp edges, damage, or alterations that expose the internal
parts of the device.
7. Correct any problems that you find.
Internal device checks
Ensure that you perform an internal device check before you install the SAN
Volume Controller.
viii IBM System Storage SAN Volume Controller: Models 2145-8F2 and 2145-8F4 Hardware Installation Guide

To conduct the internal device check, perform the following steps:
1. Check for any non-IBM changes that might have been made to the device. If
any are present, obtain the “Non-IBM Alteration Attachment Survey,” form
number R009, from the IBM branch office. Complete the form and return it to
the branch office.
2. Check the condition of the inside of the device for any metal or other
contaminants, or any indications of water, other fluid, fire, or smoke damage.
3. Check for any obvious mechanical problems, such as loose components.
4. Check any exposed cables and connectors for wear, cracks, or pinching.
Checking the grounding of a SAN Volume Controller, the
uninterruptible power supply, and the redundant ac-power switch
Ensure that you understand how to check the grounding of a SAN Volume
Controller, the uninterruptible power supply, and the optional redundant ac-power
switch feature.
Ensure that you understand how to check the grounding of a SAN Volume
Controller, the uninterruptible power supply, and the optional redundant ac-power
switch.
To test the grounding of a SAN Volume Controller node, perform the following
steps. Before you start, confirm that you know the SAN Volume Controller model
type and whether you are using redundant ac power. Determine the location of the
signal cables that are attached to the SAN Volume Controller.
When you are asked to test the grounding continuity, use your local procedures to
perform the test. The test is successful if the measured resistance is 0.1 ohm or less.
Attention: Some electrical circuits can be damaged if the external signal cables
are present at the SAN Volume Controller while it is undergoing a grounding test.
1. Ensure that the SAN Volume Controller node is powered off. See “MAP 5350:
Powering off a SAN Volume Controller node” in the IBM System Storage SAN
Volume Controller Troubleshooting Guide.
2. Disconnect all signal cables from the SAN Volume Controller node, which
includes the following cables:
vThe fibre-channel cables
vThe Ethernet cable or cables
vThe serial cable that is connected to the uninterruptible power supply
3. Disconnect all signal cables from the uninterruptible power supply.
4. If redundant ac power is not used, disconnect the uninterruptible power-supply
power cable from the site power-distribution unit.
5. If redundant ac power is used, turn off any SAN Volume Controller that is
being supplied from the redundant ac-power switch, and remove the power
cable to this system from the redundant ac-power switch.
6. If redundant ac power is used, disconnect both input power leads from the site
power distribution units.
7. If redundant ac power is not used, test the grounding continuity between a
conductive area on the SAN Volume Controller frame and the ground pin on
the plug of the uninterruptible power-supply input-power cable.
8. If redundant ac power is used, test the grounding continuity between a
conductive area on the SAN Volume Controller frame and the ground pin on
Safety and environmental notices ix
1

the plug of the main power cable of the redundant ac-power switch. If the test
is successful, test the grounding continuity between a conductive area on the
SAN Volume Controller frame and the ground pin on the plug of the backup
power cable of the redundant ac-power switch. Both tests must be successful.
9. After you have completed testing the grounding continuity, perform one of the
following procedures, depending on the outcome of the test.
vIf the test is successful, reconnect any cables that were removed, and power
on any uninterruptible power-supply units and SAN Volume Controller
nodes that were powered off.
vIf the test was not successful, ensure that all cables are securely connected. If
the test still fails, test the individual system components. Before you test the
individual components, remove all cables from the components. If any
component test fails, replace the component. After each component has been
tested and the failing ones have been replaced, repeat the complete system
test by returning to step 1 on page ix.
Test the components in the following order:
a. The SAN Volume Controller node, from the frame to the ground pin of
the input power receptacle
b. The uninterruptible power supply from the ground pin of the input
power receptacle to the ground conductor of the output power receptacle
c. If used, the redundant ac-power switch from the ground pin of the main
input power receptacle to the ground conductor of the output power
receptacle, and from the ground pin of the backup input power receptacle
to the ground conductor of the output power receptacle
d. The SAN Volume Controller node to uninterruptible power-supply
power-cable assembly, between the two ground conductors of the power
cable
e. The uninterruptible power-supply input-power cable, between the two
ground conductors of the power cable
f. If used, the redundant ac-power switch main input-power cable, between
the two ground conductors of the cable
g. If used, the redundant ac-power switch backup input-power cable,
between the two ground conductors of the cable
Inspecting the uninterruptible power supply for unsafe conditions
Ensure that you take the time to inspect the uninterruptible power supply for
unsafe conditions.
Consider the following conditions and their potential safety hazards:
Electrical hazards (especially primary power)
Primary voltage on the frame can cause serious or lethal electrical shock.
Explosive hazards
A bulging capacitor can cause serious injury.
Mechanical hazards
Loose or missing items (for example, nuts and screws) can cause serious
injury.
Use caution when working in a potential safety hazard that is not covered in the
safety checks. If unsafe conditions are present, determine how serious the hazards
are and whether you can continue before you correct the problem.
xIBM System Storage SAN Volume Controller: Models 2145-8F2 and 2145-8F4 Hardware Installation Guide

Using the following inspection checklist as a guide, inspect the uninterruptible
power supply for unsafe conditions. If necessary, see any suitable safety
publications.
1. If any equipment has been damaged during the shipment, keep the shipping
cartons and packing materials.
2. To file a claim for the shipping damage, perform the following steps:
a. File with the carrier within fifteen days of receipt of the equipment.
b. Send a copy of the damage claim within fifteen days to your service
support representative.
Handling static-sensitive devices
Ensure that you understand how to handle devices that are sensitive to static
electricity.
Attention: Static electricity can damage electronic devices and your system. To
avoid damage, keep static-sensitive devices in their static-protective bags until you
are ready to install them.
To reduce the possibility of electrostatic discharge, observe the following
precautions:
vLimit your movement. Movement can cause static electricity to build up around
you.
vHandle the device carefully, holding it by its edges or frame.
vDo not touch solder joints, pins, or exposed printed circuitry.
vDo not leave the device where others can handle and possibly damage the
device.
vWhile the device is still in its antistatic bag, touch it to an unpainted metal part
of the system unit for at least two seconds. (This action removes static electricity
from the package and from your body.)
vRemove the device from its package and install it directly into your SAN
Volume Controller, without putting it down. If it is necessary to put the device
down, place it onto its static-protective bag. (If your device is an adapter, place it
component-side up.) Do not place the device onto the cover of the SAN Volume
Controller or onto a metal table.
vTake additional care when you handle devices during cold weather because
heating reduces indoor humidity and increases static electricity.
Environmental notices and statements
You must become familiar with the environmental notices and statements.
The following topics describe the environmental notices and statements that are
applicable to this product.
1089CORE
The following comments apply to the IBM servers that have been designated as
conforming to NEBS (Network Equipment-Building System) GR-1089-CORE.
Safety and environmental notices xi

Power and cabling information for NEBS (Network
Equipment-Building System) GR-1089-CORE
The equipment is suitable for installation in the following:
vNetwork telecommunications facilities
vLocations where the NEC (National Electrical Code) applies
The intrabuilding ports of this equipment are suitable for connection to
intrabuilding or unexposed wiring or cabling only. The intrabuilding ports of this
equipment must not be metallically connected to the interfaces that connect to the
OSP (outside plant) or its wiring. These interfaces are designed for use as
intrabuilding interfaces only (Type 2 or Type 4 ports as described in
GR-1089-CORE) and require isolation from the exposed OSP cabling. The addition
of primary protectors is not sufficient protection to connect these interfaces
metallically to OSP wiring.
Note: All Ethernet cables must be shielded and grounded at both ends.
The ac-powered system does not require the use of an external surge protection
device (SPD).
The dc-powered system employs an isolated DC return (DC-I) design. The DC
battery return terminal shall not be connected to the chassis or frame ground.
Product recycling and disposal
Ensure that you are aware of the materials that must be recycled. Before using this
information and the product that it supports, read the IBM Environmental Notices
and User Guide on the SAN Volume Controller Documentation CD.
xii IBM System Storage SAN Volume Controller: Models 2145-8F2 and 2145-8F4 Hardware Installation Guide
1
1
1

About this guide
This guide provides an overview of the IBM System Storage SAN Volume
Controller and detailed installation instructions.
Use this guide to perform the following tasks:
vInstall a new SAN Volume Controller system or extend an existing system.
vInstall one or more SAN Volume Controller nodes and related hardware
components, such as uninterruptible power supply units or an optional
redundant ac-power switch.
vConnect SAN Volume Controller components to a SAN.
vManage connections to an Ethernet network.
vVerify the completeness of a SAN Volume Controller installation.
The topics within this book provide conceptual, planning, and installation
information for the SAN Volume Controller hardware model that was ordered.
Who should use this guide
The intended audience for this guide is the IBM service representative.
This guide should be read by the IBM service representative who is responsible for
the initial installation of the SAN Volume Controller hardware, including the
redundant ac-power switch and the uninterruptible power supply.
After the IBM service representative has installed the SAN Volume Controller
hardware, the customer must use the IBM System Storage SAN Volume Controller
Software Installation and Configuration Guide to install any additional software and to
configure the SAN Volume Controller.
Emphasis
Different typefaces are used in this guide to show emphasis.
The following typefaces are used to show emphasis:
Boldface Text in boldface represents menu items and
command names.
Italics Text in italics is used to emphasize a word.
In command syntax, it is used for variables
for which you supply actual values, such as
a default directory or the name of a cluster.
Monospace Text in monospace identifies the data or
commands that you type, samples of
command output, examples of program code
or messages from the system, or names of
command flags, parameters, arguments, and
name-value pairs.
© Copyright IBM Corp. 2003, 2008 xiii
e
e
e
e

SAN Volume Controller library and related publications
Product manuals, other publications, and Web sites contain information that relates
to SAN Volume Controller.
SAN Volume Controller Information Center
The IBM System Storage SAN Volume Controller information center contains all of
the information that is required to install, configure and manage the SAN Volume
Controller. The information center is updated between SAN Volume Controller
product releases to provide the most current documentation. The information
center is available at the following Web site:
http://publib.boulder.ibm.com/infocenter/svcic/v3r1m0/index.jsp
SAN Volume Controller library
The following table lists and describes the publications that make up the SAN
Volume Controller library. Unless otherwise noted, these publications are available
in Adobe®portable document format (PDF) from the following Web site:
www.ibm.com/storage/support/2145
Title Description Order number
IBM System Storage SAN
Volume Controller Planning
Guide
This guide introduces the
SAN Volume Controller and
lists the features you can
order. It also provides
guidelines for planning the
installation and configuration
of the SAN Volume
Controller.
GA32-0551
IBM System Storage SAN
Volume Controller Model
2145-CF8 Hardware
Installation Guide
This guide provides the
instructions that the IBM
service representative uses to
install the hardware for SAN
Volume Controller model
2145-CF8.
GC52-1356
IBM System Storage SAN
Volume Controller Model
2145-8A4 Hardware
Installation Guide
This guide provides the
instructions that the IBM
service representative uses to
install the hardware for SAN
Volume Controller model
2145-8A4.
GC27-2219
IBM System Storage SAN
Volume Controller Model
2145-8G4 Hardware
Installation Guide
This guide provides the
instructions that the IBM
service representative uses to
install the hardware for SAN
