IBM SAN04B-R - System Storage Router Manual

IBM System Storage SAN04B-R
Installation, Service, and User’s Guide
Service information: 2005 /R04
GA32-0583-01
Read Before Using
This product contains software that is licensed under written license agreements. Your use of such software is subject to
the license agreements under which they are provided.


IBM System Storage SAN04B-R
Installation, Service, and User’s Guide
Service information: 2005 /R04
GA32-0583-01


Note:
Before using this information and the product it supports, read the information in “Notices” on page 61.
The following paragraph does not apply to any country (or region) where such provisions are inconsistent with local
law.
INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION “AS IS” WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR APARTICULAR PURPOSE. Some states (or regions) do
not allow disclaimer of express or implied warranties in certain transactions; therefore, this statement may not apply
to you.
©Copyright International Business Machines Corporation 2008.
US Government Users Restricted Rights –Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Read this first
Summary of changes
This is the second edition of the IBM System Storage SAN04B-R Installation,
Service, and User's Guide.The content changes since the last edition of this
publication are noted by avertical line placed in the left margin beside each
change. Minor edits are not identified by this mark. Asummary of the changes for
each edition are listed below.
Second edition
The following changes were made in the second edition:
vAdditional optional features for the router were added
vMinimum Fabric Operating System (FOS) was changed from 6.1.0 to 6.1.1 to
support new features
vEthernet port speed was increased, due to added functionality
Getting help
For the latest version of your product documentation, visit the web at
http://www.elink.ibmlink.ibm.com/public/applications/publications/cgibin/pbi.cgi.
Search by form number or title.
For more information about IBM®SAN products, see the following Web site:
http://www.ibm.com/servers/storage/san/
For support information for this product and other SAN products, see the following
Web site: http://www.ibm.com/servers/storage/support/san
You can also contact IBM within the United States at 1-800-IBMSERV
(1-800-426-7378). For support outside the United States, you can find the service
number at: http://www.ibm.com/planetwide/.
Visit www.ibm.com/contact for the contact information for your country or region.
For detailed information about the Fibre Channel standards, see the Fibre Channel
Industry Association (FCIA) Web site at: www.fibrechannel.org/
For information about storage industry standards, see the Storage Networking
Industry Association (SNIA) Web site at: http://www.snia.org/
Taiwan Contact Information
IBM Taiwan Product Service Contact Info:
IBM Taiwan Corporation
3F, No 7, Song Ren Rd., Taipei Taiwan
Tel: [phone]
©Copyright IBM Corp. 2008 iii
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|

Accessibility features for the SAN04B-R
Accessibility features help users who have adisability, such as restricted mobility or
limited vision, to use information technology products successfully.
Accessibility features
The following list includes the major accessibility features in this product:
vLight emitting diodes (LEDs) that flash at different rates, to represent the same
information as the colors of the LEDs
vIndustry-standard devices for ports and connectors
vManagement of the product through management applications is available
through Web and Graphical User Interface (GUI) options
Keyboard navigation
This product does not have an attached or integrated keyboard. Any keyboard
navigation is provided through the management software and GUI.
Vendor software
This product includes certain vendor software that is not covered under the IBM
license agreement. IBM makes no representation about the accessibility features of
these products. Contact the vendor for the accessibility information about its
products.
Related accessibility information
You can view the publications for this product in Adobe®Portable Document Format
(PDF) using the Adobe Acrobat Reader. The PDFs are provided on aproduct
documentation CD-ROM that is packaged with the product. The CD-ROM also
includes an accessible HTML version of this document.
IBM and accessibility
See the IBM Human Ability and Accessibility Center web site at
http://www.ibm.com/able/ for more information about the commitment that IBM has
to accessibility.
How to send your comments
Your feedback is important in helping us provide the most accurate and high-quality
information. If you have comments or suggestions for improving this document,
send us your comments by e-mail to [email protected] or use the Readers’
Comments form at the back of this publication. Be sure to include the following:
vExact publication title
vForm number (for example, GC26-1234-02)
vPage numbers to which you are referring
If the Reader Comment Form in the back of this manual is missing, you can direct
your mail to:
International Business Machines Corporation
Information Development
iv SAN04B-R Installation, Service, and User’s Guide
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|

Department GZW
9000 South Rita Road
Tucson, Arizona 85744-0001 U.S.A.
When you send information to IBM, you grant IBM anonexclusive right to use or
distribute the information in any way it believes appropriate without incurring any
obligation to you.
Read this first v
|
|
|
|
|
|

vi SAN04B-R Installation, Service, and User’s Guide

Contents
Read this first ......................... iii
Summary of changes ....................... iii
Second edition ........................ iii
Getting help .......................... iii
Taiwan Contact Information.................... iii
Accessibility features for the SAN04B-R ................iv
Accessibility features ......................iv
Keyboard navigation ......................iv
Vendor software ........................iv
Related accessibility information ..................iv
IBM and accessibility ......................iv
How to send your comments ....................iv
Figures ............................xi
Tables............................ xiii
Safety and environmental notices .................xv
Safety notices and labels .....................xv
Danger notices ........................xv
Caution notices ....................... xvii
Safety labels ........................ xviii
Attention notices ....................... xix
Rack safety ..........................xx
Rack installation .......................xx
Rack relocation (19″rack).................... xxi
Product recycling and disposal ................... xxii
Battery return program ..................... xxiii
For the European Union: .................... xxiii
About this document ..................... xxv
Product documents ....................... xxv
Brocade documents....................... xxv
IBM and Brocade product matrix ................. xxv
Chapter 1. Introducing the SAN04B-R ................1
Features and functions of the router .................1
Upgrade license features .....................3
Hardware components ......................3
Port side of the router ......................4
Nonport side of the router ....................6
Supported connectivity ......................6
Supported optional features.....................7
Chapter 2. Installing and configuring the router ............9
Items included with the router ....................9
Installation and safety considerations.................10
Facility requirements ......................10
Electrical requirements .....................11
Environmental requirements and considerations ............11
Setting up astand-alone router ...................11
Installing the router in acabinet...................12
Time required ........................12
©Copyright IBM Corp. 2008 vii
||
||
||
||
||
||
||
||
||
||
||
||
||

Items required ........................12
Installation instructions .....................12
Cabling and setting up the router ..................18
Planning for cable management .................18
Items required for setup ....................18
Setting up the router ......................18
Installing SFP transceivers ...................21
Connecting cables ......................22
Setting the router date and time .................22
Configuring FCIP and Fibre Channel routing services..........25
Verifying correct operation of the router ...............25
Backing up the configuration ...................26
Viewing, adding, and removing license keys (optional) ..........27
Viewing current license keys ...................27
Adding alicense key......................27
Removing alicense key ....................28
Chapter 3. Managing the router and monitoring components ......29
Managing the router .......................29
Interpreting LED activity .....................30
LEDs on the port side of the router ................30
Power status LED patterns ...................32
System status LED patterns ...................32
Ethernet management port LED patterns ..............33
Port status LED patterns ....................33
LEDs on the nonport side of the router ...............34
Interpreting POST results .....................36
POST and boot specifications ..................36
Diagnostics and troubleshooting ..................37
Diagnostic tests .......................37
CLI commands for device status .................37
CRU status .........................37
Powering off the router .....................38
Chapter 4. Removing and replacing CRUs ..............39
Replacing apower supply .....................39
Time required ........................40
Items required ........................40
Procedure..........................41
Replacing afan assembly .....................42
Time required ........................43
Items required ........................43
Procedure..........................43
Removing, and installing SFPs ...................44
Time required ........................45
Items required ........................45
Procedure..........................45
Replacing the router .......................53
Time required ........................53
Items required ........................53
Procedure..........................54
Appendix. Product specifications .................57
Summary of router components...................57
Weight and physical dimensions ..................57
Power supply .........................58
viii SAN04B-R Installation, Service, and User’s Guide

Environmental requirements ....................58
Data transmission ranges .....................59
Memory specifications ......................59
Port specifications........................59
Fibre Channel port specifications .................59
GbE port specifications .....................59
Serial port specifications ....................59
Parts list (CRUs) ........................60
Notices ...........................61
Trademarks ..........................63
Electronic emission notices ....................64
Federal Communications Commission (FCC) Class AStatement .....64
Industry Canada Class AEmission Compliance Statement ........64
Avis de conformité àla réglementation d’Industrie Canada ........64
European Union (EU) Electromagnetic Compatibility Directive.......64
Germany Electromagnetic Compatibility Directive ...........65
People’s Republic of China Class AElectronic Emission Statement ....66
Japan VCCI Class AITE Electronic Emission Statement.........66
Korea Class AElectronic Emission Statement ............66
Index ............................67
Contents ix

xSAN04B-R Installation, Service, and User’s Guide

Figures
1. Port side of the router .............................4
2. Nonport side of the router ............................6
3. Rack assembly ...............................13
4. Separating the inner and outer rails.........................14
5. Mounting the moving portion of the slide and mounting brackets to the router ........15
6. Mounting the fixed portion of the rail and the locking brackets to the rack ..........16
7. Inserting slides into the rack rails .........................17
8. LEDs and other components on the port side of the router ...............31
9. Nonport side components ...........................34
10. Power supply locations ............................40
11. Removing and replacing apower supply ......................41
12. Fan assembly locations ............................42
13. Removing and replacing afan assembly ......................44
14. SFP wire bale variety .............................45
15. SFP plastic tab variety .............................45
16. Fiber optic cable lever and latches ........................46
17. Removing afiber optic cable ..........................47
18. Unlocking the SFP module latch, wire bale type ...................48
19. Unlocking the SFP module latch, plastic tab type ...................49
20. Removing an SFP module, plastic tab type .....................49
21. Removing the protective cap from awire bale type SFP ................50
22. Removing the protective cap from aplastic tab type SFP ................50
23. Installing awire bale type SFP..........................51
24. Installing aplastic tab type SFP .........................52
25. Removing the caps from fiber optic cables .....................52
26. Inserting afiber optic cable into an SFP module ...................53
©Copyright IBM Corp. 2008 xi

xii SAN04B-R Installation, Service, and User’s Guide

Tables
1. Sample caution notices ............................ xviii
2. Brocade and IBM product and model number matrix ................. xxv
3. Capabilities of base model router and router capabilities with upgrade license .........3
4. Facility requirements .............................10
5. Environmental requirements ...........................11
6. Parts supplied with the rack-mount kit .......................13
7. Viewing current licenses ............................27
8. Management options for the router ........................29
9. Power status LED patterns ...........................32
10. System status LED patterns...........................32
11. Management port LED patterns .........................33
12. Port status LED patterns ............................33
13. Power supply status LED patterns ........................35
14. Fan assembly status LED patterns ........................35
15. Switch dimensions ..............................57
16. Power supply specifications ...........................58
17. Environmental requirements...........................58
18. Data transmission ranges by cable type and port speed ................59
19. Serial cable pinouts ..............................60
20. CRU part numbers ..............................60
©Copyright IBM Corp. 2008 xiii
||

xiv SAN04B-R Installation, Service, and User’s Guide

Safety and environmental notices
This section contains information about:
v“Safety notices and labels”
v“Rack safety” on page xx
v“Product recycling and disposal” on page xxii
Safety notices and labels
When using this product, observe the danger, caution, and attention notices
contained in this guide. The notices are accompanied by symbols that represent the
severity of the safety condition. The danger and caution notices are listed in
numerical order based on their IDs, which are displayed in parentheses, for
example (D004), at the end of each notice. Use this ID to locate the translation of
these danger and caution notices in the IBM Systems Safety Notices (G229–9054)
publication, which is on the CD-ROM that accompanies this product.
The following notices and statements are used in IBM documents. They are listed
below in order of increasing severity of potential hazards. Follow the links for more
detailed descriptions and examples of the danger, caution, and attention notices in
the sections that follow.
vNote: These notices provide important tips, guidance, or advice.
v“Attention notices” on page xix: These notices indicate potential damage to
programs, devices, or data.
v“Caution notices” on page xvii: These statements indicate situations that can
be potentially hazardous to you.
v“Danger notices”: These statements indicate situations that can be potentially
lethal or extremely hazardous to you. Safety labels are also attached directly to
products to warn of these situations.
vIn addition to these notices, “Safety labels” on page xviii may be attached to the
product to warn of potential hazards.
Danger notices
Adanger notice calls attention to asituation that is potentially lethal or extremely
hazardous to people. Alightning bolt symbol accompanies adanger notice to
represent adangerous electrical condition. Read and comply with the following
danger notices before installing or servicing this device.
DANGER
To prevent apossible shock from touching two surfaces with
different protective ground (earth), use one hand, when possible,
to connect or disconnect signal cables. (D001)
©Copyright IBM Corp. 2008 xv

DANGER
Overloading abranch circuit is potentially afire hazard and a
shock hazard under certain conditions. To avoid these hazards,
ensure that your system electrical requirements do not exceed
branch circuit protection requirements. Refer to the information
that is provided with your device or the power rating label for
electrical specifications. (D002)
DANGER
If the receptacle has ametal shell, do not touch the shell until
you have completed the voltage and grounding checks. Improper
wiring or grounding could place dangerous voltage on the metal
shell. If any of the conditions are not as described, STOP. Ensure
the improper voltage or impedance conditions are corrected
before proceeding. (D003)
DANGER
An electrical outlet that is not correctly wired could place
hazardous voltage on metal parts of the system or the devices
that attach to the system. It is the responsibility of the customer
to ensure that the outlet is correctly wired and grounded to
prevent an electrical shock. (D004)
Ageneral electrical danger notice provides instructions on how to avoid shock
hazards when servicing equipment. Unless instructed otherwise, follow the
procedures in the following danger notice.
xvi SAN04B-R Installation, Service, and User’s Guide

DANGER
When working on or around the system, observe the following
precautions:
Electrical voltage and current from power, telephone, and
communication cables are hazardous. To avoid ashock hazard:
vConnect power to this unit only with the IBM provided power
cord. Do not use the IBM provided power cord for any other
product.
vDo not open or service any power supply assembly.
vDo not connect or disconnect any cables or perform
installation, maintenance, or reconfiguration of this product
during an electrical storm.
vThe product might be equipped with multiple power cords. To
remove all hazardous voltages, disconnect all power cords.
vConnect all power cords to aproperly wired and grounded
electrical outlet. Ensure that the outlet supplies proper voltage
and phase rotation according to the system rating plate.
vConnect any equipment that will be attached to this product to
properly wired outlets.
vWhen possible, use one hand only to connect or disconnect
signal cables.
vNever turn on any equipment when there is evidence of fire,
water, or structural damage.
vDisconnect the attached power cords, telecommunications
systems, networks, and modems before you open the device
covers, unless instructed otherwise in the installation and
configuration procedures.
vConnect and disconnect cables as described below when
installing, moving, or opening covers on this product or
attached devices.
To disconnect:
1. Turn off everything (unless instructed otherwise).
2. Remove the power cords from the outlets.
3. Remove the signal cables from the connectors.
4. Remove all cables from the devices.
To connect:
1. Turn off everything (unless instructed otherwise).
2. Attach all cables to the devices.
3. Attach the signal cables to the connectors.
4. Attach the power cords to the outlets.
5. Turn on the devices.
(D005)
Caution notices
Acaution notice calls attention to asituation that is potentially hazardous to people
because of some existing condition. Acaution notice can be accompanied by
different symbols, as in the examples below:
Safety and environmental notices xvii

Table 1. Sample caution notices
If the symbol is... It means...
Ahazardous electrical condition with less
severity than electrical danger.
Agenerally hazardous condition not
represented by other safety symbols.
18-32 kg (39.7-70.5 lbs)
svc00167
18-32 kg (39.7-70.5 lbs)
Aspecification of product weight that
requires safe lifting practices. The weight
range of the product is listed below the
graphic, and the graphic and the wording of
the caution varies, depending on the weight
of the device.
P/N 18P5850-B
SJ000752
Apotential hazard of pinching the hand or
other body parts between parts.
Ahazardous condition due to moving parts
nearby.
Ahazardous condition due to the use of a
laser in the product. Laser symbols are
always accompanied by the classification of
the laser as defined by the U. S. Department
of Health and Human Services (for example,
Class I, Class II, and so forth).
Read and comply with the following caution notices before installing or servicing this
device.
CAUTION:
Energy hazard present. Shorting may result in system outage and
possible physical injury. Remove all metallic jewelry before
servicing. (C001)
CAUTION:
This part or unit is heavy but has aweight smaller than 18 kg (39.7
lb). Use care when lifting, removing, or installing this part or unit.
(C008)
CAUTION:
This product is equipped with a3-wire (two conductors and ground)
power cable and plug. Use this power cable with aproperly
grounded electrical outlet to avoid electrical shock. (C018)
Safety labels
As an added precaution, safety labels are often installed directly on products or
product components to warn of potential hazards. These can be either danger or
caution notices, depending upon the level of the hazard.
xviii SAN04B-R Installation, Service, and User’s Guide
