IBM LTO Generation 3 User manual

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
The IBM Advantage
The IBM Advantage
IBM LTO Generation 3

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
LTO Technology Overview
Product Overview
Drive Interfaces
Diagnostics and Error Reporting
Log Pages/Buffers
On-line Resources

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
LTO Technology

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
Generation 2 (IBM LTO Drive) 3 (IBM LTO Drive)
Capacity 200 GB 400 GB
Transfer 35 MB/S 80 MB/S
Channels 816
Attachment SCSI 3, FC(2Mb) SCSI 3, FC (2Mb)
Form Factor Full High Full High
Media Type MP MP
Thickness 8.8uM 8.0 uM
Tape Length 609 M 680 M
Write/Read 6.22 M/S 5.46 M/S
Seek Speed 8 M/S 8 M/S
Tracks 512 704
Linear
Density 188kb/in 245kb/in
IBM LTO
Specifications Product Overview

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
HAA
Roller Bearings/Guides
Cartridge
Tape Path
Product Overview

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
LP0 ............Leader pin attach point - 0 M
LP1 ............Fwd servo detect begins - 1M
LP2 ............Start calibration region - 5 M
LP3 .(BOT).User data region starts - 6 M
LP4 .(EOT).User data region ends - 596 M
LP5 ............Max user data region ends - 596.1M
LP6 ............Rev servo detection begins - 601.1M
LP7 ............Physical end of tape - 609 M
LP0 to LP1 .......Unused
LP1 to LP2 .......Forward servo acquisition
LP2 to LP3 .......Calibration region
LP3 to LP4 .......User data region
LP4 to LP5 .......Unused data area
LP5 to LP6 .......Reverse servo acquisition
LP6 to LP7 .......Unused
Logical Point Definitions Logical Area Usage
LP0LP1
LP2LP3
LP4
LP5
LP6LP7
FID
EW
EW ...Early Warning
FID ...Format Identification Data Set
p
Regions on Tape

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
SERVO (Lateral Position)
14
13
0
1
+
+
+
+
+
+
+
11
11 nominal positions
AB
AC
ABC DA
Technology
Overview

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
10
SERVO (Longitudinal Position....LPOS)
Technology
Overview

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
Dual Actuator Head
Product Overview

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
^^ ^^
SERVO
SERVO
S
W
R
W
R
W
R
W
R
W
R
W
R
W
R
W
R
S
S
R
W
R
W
R
W
R
W
R
W
R
W
R
W
R
W
S
^^ ^^
DATA
Technology
Overview

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
Generation 2
SERVO FORMAT
SERVO FORMAT
Steps
Steps
Generation 3
Backward Compatibly
Technology
Overview

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
Technology
Overview
The CM is a 4096 byte write/read device mounted in the cartridge. The interface to
external devices is via a contactless radio frequency system. The radio frequency
provides power transfer and write/read access.
The CM contains:
* LTO-CM manufacturing information
* LTO-CM page control information
* Cartridge initialization information
* Tape directory
* Cartridge information
o Manufacturer info
o Pass history
o Error history
o Usage
o Tape Alert flags

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
IBM T800 & T800F
Product Overview

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
Legacy Performance
Gen 1 Gen 2 Gen 3
Gen 1
READ/WRITE
15MB/Sec READ/WRITE 20MB/Sec READ ONLY 20MB/Sec
Gen 2 N/A
READ/WRITE
35MB/Sec READ/WRITE 35MB/Sec
Gen 3 N/A N/A
READ/WRITE
80MB/Sec
Drive
Format

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
IBM LTO Common Features
IBM LTO Common Features
True 5 ¼ inches form factor
100 000 cartridge load/unload cycles
MTBF of 250 000 power-on hours at 100% duty cycle
Cartridge Memory (LTO-CM) for enhanced
performance
Read after write data integrity verification
Integrated head cleaner
Microcode updateable via the host attachment
interface (SCSI or Fibre Channel Interface), a Field
Microcode Replace (FMR) tape, or the drive LDI
interface (write buffer)

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
Gen 2 and Gen 3 Unique Features
Gen 2 and Gen 3 Unique Features
Reduced nominal power consumption
64 MB buffer
Speed Matching
Separate Writing of Multiple Filemarks
Channel Calibration
Power Management
Set Capacity
Ultra 160 SCSI interface
Drive external SCSI termination required
Fibre Channel 2Gbit/sec interface
Fibre Channel: Support for direct connection to an
F-port (e.g. McData switch)

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
Gen 3 Unique
Gen 3 Unique
128MB read-write cache
80 MB/s vs 35 MB/s
Speed matching: G3-40 to 80 MB/s G2-17.5 MB/s to 35
MB/s
400 GB vs 200 GB non compressed
Read adaptive equalization ( LMS )
ADI Library interface support (Availability 2Q05)
LDI serial interface selectable up to 115K baud rate
Fibre Channel 2Gbit/sec interface ( 4Gb and dual
active fibre ports available 4Q05 )

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
Controlled dynamic break function if power lost
Improved pin pick and threader mechanics to return leader pin
to cartridge
Enhanced cartridge pin retention ( positive pin retention )
A self resettable theader motor
Pin rails
Dual port FC interface architecture (4Q05)
New high bandwidth dual stage actuator
Some componentsRoHS compliance (Full RoHS 12/05)
16 channel implementation, 16@G3, 8@G2, 8@G1
New media, new media shell color ( dark bluish grey, Pantone
color number 7546C )
Gen 3 Unique (
Gen 3 Unique (continued continued) )

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
Gen 3 Unique
Gen 3 Unique (continued) (continued)
Read only support for tapes written by generation 1
drives.
Expanded request sense length to 96 bytes
Digital temperature sensor vs on/off temperature
sensor (output via LDI 3Q05)
Lower power 26W vs 29W (SCSI Drive)
Mounting screws have been changed to M3

IBM Storage Technology Division
© Copyright IBM Corporation 1999. All rights
reserved.
Presentation File
Name
Aluminum Base Casting for Rigid, Robust Tape
Transport
Reel Motors Rigidly Mounted to Base Casting
All Metal Clutch for Precision Alignment and Long Life
Cartridge Loads Onto Fixed Clutch for Optimum Tape
Guiding
(No Up/Down Movement of Clutch)
Steel Ball Bearings in Loader
Stainless Steel Cartridge Locating Pins
Teflon Coated Tray for Low Friction
Powerful Gear Reduction Loader Motor
Single Circuit Card
Motor Magnets Fully Encapsulated Prevents
Magnetic Particle Contamination
IBM Drive Designed for Long Life/High Quality
Built with Automation in Mind
Product Overvie
