Iceco JP42 User manual

JP42

SAFETY INFORMATION:
Please read this operating manual carefully before starting the appliance. Keep it in a safe place for
future reference. If the appliance is passed on to another person, this instruction manual must be handed
over to the user along with it.
The manufacturer cannot be held liable for damage resulting from improper usage or incorrect operation.
WARNING
Safety Instruction: Failure to observe this instruction can cause fatal or serious injury.
NOTICE
Failure to observe this instruction can cause material damage and impair the function of the product
CAUTION
Safety Instruction: Failure to observe this instruction can lead to injury.
Name of Parts
Cup Holder
Scupper
Latch
AC adapter
Fixed handle

CONTENTS
1 Intended To Use
2 Features
3 Safety Information
3.1 Warning
3.2 Caution
3.3 Notice
4 Data Sheet
5 Operation
5.1 Temperature Setting
5.2 How To Use The Refrigerator
5.3 Using The Battery Monitor
6 Defrosting
6.1 Notice
6.2 Cleaning And Maintenance
8 FAULTS

1
This appliance is intended to be used in household and similar applications such as:
● Staff kitchen areas in shops, offices and other working environments;
● Farm houses and by clients in hotels, motels and other residential type environments;
● Bed and breakfast type environments;
● Catering and similar non-retail applications;
● Camping, hunting and other similar campaign.
1.Cooler and refrigerator in one machine, can be used as a cooler or refrigerator.
(Notice: The highest water level cannot higher than the compressor position when you use it as a cooler)
2.Removable hanging basket, easy to stock and take food.
3.Convenient design, with cup holder and drain cap.
Warning
● The water level cannot higher than the compressor position when you use as an ice chest.
● Children should be supervised that they do not play with the appliance.
● Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
● Do not use this appliance near direct heat sources, for example, a cooker, radiator or exposing it to
direct sunlight.
● The appliance shall not be exposed to rain. Place the refrigerator on a dry, protected surface, away
from edges.
● Do not use the appliance if it is visibly damaged.
● Do not use it with the damaged power cord and it must be replaced by the manufacturer or a qualified
person.
INTENDED USE
FEATURES
SAFETY INSTRUCTION
Caution
● Do not use electrical appliances inside the food storage compartments of the appliance, unless
they are of the type recommended by ICECO.
● Disconnect the power cable from the plug before carrying out any maintenance.

2
MODEL JP42
External dimensions (LxWxH)
Net weight 20.2KG (44.5 lbs)
55WInstalled power
Supply voltage DC 12V/24V
Temperature setting
Cooling system SECOP
Refrigerant gas R134a-CFC Free
Insulation C-pentane
Shell material LLDPE
DATA SHEET
-18°C to +10°C (0°F to 50°F)
665mm(26.2’’) 374mm(14.7’’)
414.5mm(16.3’’)
445mm(17.5’’)
445mm(17.5’’)
720mm(28.3’’)
720 x 414.5 x 445mm (28.3 x 16.3 x 17.5 inches)
Notice
● No responsible for the damage by ignoring the safety instructions.
● The use of accessories that are not recommended by ICECO can cause injuries and will invalidate
any warranty that you may have.
● Ensure that the ventilation openings are not covered.
● Make sure that leave enough space for the device to ventilate.
● Never immerse the device in water.
Supply current 6.0A/3.0A
Battery
The car battery could be old, undersized or have a dead cell causing too much voltage drop.

2.Key Operation
● In the standby status, short press the , and it will enter work mode. Under operating condition,
short press the , the appliance enters the standby mode.
1. After power on, the digital screen lights up for 2 seconds and then displays normally.
ECOMAX
Setting
Mode Indicator Light
ON/OFF Temperature Display
Temperature Adjustment
● When it is in the normal working state, short press / to adjust temperature from
0°F (-18°C)-50°F (+10°C). Long perss / , adjust temperature 5.4°F (3°C) per second.
3.ECO/MAX Function
When the appliance is running, short press to adjust the ECO&MAX mode.
Temperature Setting
In the standby mode, long press and at the same time for 3 seconds, use the
or to select Celsius or Fahrenheit.
3
OPERATION
CONTROL PANEL USE
SAVING ENERGY TIPS
● Do not open the appliance frequently if unnecessary.
● Make sure leave enough space to ventilating.
● Deforest the appliance once a layer of ice forms.
● Allow warm food to cool down first before placing it in the freezer to keep cool.

HOW TO USE THE REFRIGERATOR
The Fridge/Freezer is designed to operate on DC voltage inputs.
DC input 12V or 24V
DC cable 2.5m,16AWG
● Connect the feeding cable to a direct current 24V DC power source.
● Make sure the polarity is right.
● If connected to an existing cigarette plug, please carefully check up that power supply is sufficient.
● If the supplied power cable is not used, please see the table containing the information related to the
cable section:
4
1.When use as a cooler
Notice! Danger of Damaged
The Highest water level cannot higher than the compressor positions when you use as a cooler
2.Connecting with 12V or 24V
3.Connecting with 110-240V
The coolers have an integrated multi-voltage power supply with priority circuit for connecting
to an AC voltage source of 110-240V. The priority circuit automatically switches the cooler
to mains operation, if the device is connected to a 120/240V AC mains, even if the 12/24V
connection cable is still attached. In order to protect the freezer and cigarette socket, we
suggest use with one power supply.

VOLTAGE
DISPLAY
12V 24V
PROTECTION
POSITION
LOW 1 Bar 9.6 10.9 21.3 22.6
MIDDLE 2 Bars 10.4 11.7 22.8 24.1
HIGH 3 Bars 11.1 12.4 24.3 25.6
5
Battery Protection Level
BATTERY PROTECTION MODE
In the standby status, long press “on/off” and “setting” button at the same time for 3 seconds
to enter the battery protection setting menu. Press + and – to adjust the level, “- - “ refer to
the low mode, “= =” refer to the middle mode, and “≡ ≡” refer to the high mode.
Defrost the appliance in regular time can maintain the appliance.
Notice: Do not use hard or sharp tools to remove the ice or frost which attach to the box.
To defrost the freezer, please follow up:
● Disconnect the power.
● Take out the goods of the portable freezer.
● Leave the lid open.
● Open the scupper and drain away the defrosted water.
Cleaning and maintenance
● Please disconnect the appliance from the power supply before you clean it.
● Do not clean the appliance under running water or in dish water.
DEFROSTING

FAULTS
When there is error for the fridge, the code will show on the display. The possible error for each code
would be as follows.
ERROR TYPE
ERROR CODE
E1 The low battery protection mode take effect (the input voltage is lower than set value)
E2 Fan error
E3 Compressor motor start error (Motor block or refrigeration system pressure
difference is too large)
E4
E5
E6
The motor speed of the compressor is too low (the refrigeration system is overloaded,
the motor cannot maintain the minimum speed of 1850r/min)
Temperature too high or too low to protect the compressor control module (when the
environment temperature is too high or too low, or system load is too large, causing
module/ECU internal temperature 100°C ＞or ＜-10°C)
NTC fault (NTC open circuit or short circuit)
6

ICECO product comes with a 5-year warranty on
the compressor and 1 year warranty on all other
parts for your peace of mind. In the unlikely event
this product fails when used according to our user
guide, we will either repair or replace it. For full
warranty terms and conditions on this product,
please see the user guide.
Customer Support
For any technical or warranty
enquires please visit our customer
service portal at:
www.icecofreezer.com
This product is warranted for 5 years on the compressor and 1 year for all
other parts from the date of purchase. Our goods come with guarantees
that cannot be excluded under the Local Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Warranty does not cover products that have not been used in accordance with
user guide or are outside the warranty terms and conditions.
Quality Service Guarantee
QUESTIONS AND COMMENTS
Please visit us at icecofreezer.com or email us at [email protected]
