Iceco JP60P User manual

JP60P
offi[e-mail]
offi[e-mail]
Any questions please contact us:

Catalogue
Catalogue
1 1
- - - - - - - - - - - - - - - - -
Supply Details
2 2
---------------------
Operation
3 6
- - - - - - - -
Cleaning And Maintenance
4 7
- - - - - - - - - -
Error Codes & Solutions
5 9
- - - - - - - - -
Warranty & Return Policy
6 10
- - - - - - - - -
Troubleshooting (Q & A)
7 15
-------------
Safety Instructions

Supply Details
JP60P refrigerator x1 Basket x1
DC CONNECTION
CABLE x1
80W AC ADAPTER
(FOR HOME USE)
01
1
MODEL JP60P Series
External dimensions
(LxWxH)
28.9*19.3*18.8(inch)
735 x 490 x 477(mm)
Net weight 51.9lbs/23.5kg
Installed power 60W
Supply voltage DC 12V/24V
Supply current 7.0A/3.5A
Temperature setting -18°C to +10°C (0°F to 50°F)
Insulation C-pentane
Shell material LLDPE

Operation
2(Using in Vehicles)
02
BFunction Button
(MAX mode & ECO mode)
CTemperature Down Button
(Changing setting temperature down)
DTemperature UP Button
(change setting temperature up)
APower ON / OFF Button

2.1 MAX & MIN Mode
With power on (long press A)→ press B
(MAX/ECO light turns on)
03
Tip: Press the C or D button to adjust the
temperature according to your needs. In
order to save energy, the compressor will
stop running automatically after reaching
the setting temperature, and restart again
when the inside temperature goes up

04
2.2 Switch Between °C to °F
In the standby mode, long press B and D at 3S,
→ press C or D to switch °C or °F.
TIP: When the temperature is adjusted, the
screen will show the temperature inside the
refrigerator.

2.3 Triple Battery Protection Operation
In the standby status(connecting the power
without pressing A), long press A and B at the
same time for 3S to enter the battery protection
setting menu. Press D and C to adjust the level.
Display : “- - -” → low mode; “= = =” →
middle mode; “≡ ≡ ≡” → high mode.
This is an electronic device which has the function of
piloting the motor of the compressor and carrying out all
the controls and electrical protection of the system.
TIP: It can be adjusted according to the
actual situation. When the refrigerator
connection voltage is lower than the cut off
value, the refrigerator will automatically
disconnect the power supply. The
refrigerator will restart only if the voltage is
higher than or equal to the cut in value.
05

06
Cleaning And Maintenance
3
3.1 Cleaning
Cleaning the freezer with a wet cloth and warm
water mixed with gentle non-abrasive
detergents.
3.2 Maintenance
Don't forget to power off and disconnect the
plug before cleaing the unit.
Don't use pointed objects or abrasive
detergents. to clean the fridge.
Don't use pointed or sharp objects, such as
knife, to punch through the ice when
defrosting.
Don't cleaning the fridge with running water
or using a high pressure washer.

07
Error Codes & Solutions
4
Error Code
Battery protection cut-out
※ The voltage can not reach the cut-out
value, the battery protection is activated.
E1
Fan over-current cut-out
※ The fan overloads with more than 1 A
current.
E2
Motor start error
※ The motor of compressor is blocked or
the pressure difference in the refrigeration
system is too high.
E3
Minimum motor speed error
※ The compressor overloads and the
motor can not maintain its minimun speed
1850 rpms.
E4
Thermal cut-out of electronic unit
※ Thermal cut-out error If the refrigeration
system overloads, or the ambient
temperature is too high, the thermal sensor
is overheated.
E5
NTC fault (NTC open circuit or short circuit)
E6

08
Solutions
1. If error codes appears on the screen
If error codes appear when the fridge is
powered by 12v source, plz confirm whether
the current voltage is stable. Because the
voltage of the car battery is unstable during
driving, which will activate the battery
protection function and error codes will
display.
If you don't have a tool to measure the
voltage, plz connect the fridge to 110V
source with the AC adapter. If the error code
still displays, please contact us and provide
corresponding videos or pictures which can
help us to solve your problems faster.
2. The refrigerator doesn’t work
If the refrigerator doesn’t work (can’t
refrigeration, abnormal noise etc; ) Please
contact us with short videos or photos, we will
help you process return or exchange service.

09
Warranty & Return Policy
5
30-day money back guaranty upon receiving
goods.
5 year warranty compressor.
1 year warranty for refrigerator accessories.
For returns or exchanges, please fill out the
following return and exchange registration
form in the package as a proof of return. All
materials must be returned in the original
condition and packaging. Thank you for
your cooperation.
If the product is received damaged or
defective during transportation, you need to
contact our customer service within 2
business days. Make sure to provide relevant
photos or videos, your order ID number and
your name. A customer service agent will
help assist into solving the issue at a timely
manner. A free return label will be provided if
needed.

10
Troubleshooting (Q & A)
6
1. Heat resistance & water resistance
ICECO refrigerators can operate normally
at an ambient temperature of 55 ℃(131 ℉).
Heat resistance
ICECO refrigerators can be used in light rain,
but please be careful not to put water into the
vent, and do not place it on the wet ground.
It is not recommended to use it in the open air
when it is raining, otherwise it will damage the
refrigerator.
Waterproof
Refrigerator is a kind of electrical appliances,
it is better not to touch water directly or it may
damage the circuit of the refrigerator.

2. Why did it change back to the original
temperature after setting the
temperature?
Because when setting the temperature, the
refrigerator will display the original
temperature. It takes time to reach the setting
temperature.
11
3. What should I do if the refrigerator is
upside down when it is delivered?
To ensure the maximum performance of the
refrigerator, we suggest to allow the refrigerator
stand upright for 24 hours (at least 4 hours)
before using the refrigerator.

12
4. What is the function of triple battery
protection? How do they work?
3-stage battery protection helps you prevent
dead car battery or the refrigerator drain your
power supply.
For example, when you switch to a LOW
MODE, the battery voltage is lower than 9.6
volts, the refrigerator will automatically power
off; When the battery voltage reaches 10.9
volts, the refrigerator will start again.
PROTECTION
POSITION
LOW
MIDDLE
HIGH
CUT
OFF(V)
9.6
10.4
11.1
CUT
IN(V)
22.6
24.1
25.6
CUT
IN(V)
10.9
11.7
12.4
CUT
OFF(V)
21.3
22.8
24.3
12V 24V
VOLTAGE
≡ ≡ ≡
DISPLAY

5.What is the average power in max/fast
cooling mode?
Model Electrical
Power
GO12 50W
Model Electrical
Power
JP60P 60W
GO20 50W VL35
Series 85W
JP Series 60W VL Series 85W
6. Why is there the temperature
difference (the setting temperature
of the refrigerator and the actual
temperature in the refrigerator)?
13
Because of the structure of the refrigerator, the
temperature will be displayed differently when
you test in the different point. ICECO measured
the inside temperature in the center of the box
and it would closer to the temperature you see
in the display. In normal conditions, the bottom
and the wall of the refrigerator will be lower than
the display temperature.

The temperature of different positions is
different. where the temperature is measured.
The temperature of upper, middle and lower
of the refrigerator are different. Under normal
circumstances, the bottom of the refrigerator
and the place near the wall of the refrigerator
are closer to the setting temperature.
7. Can the refrigerator put
high-concentration things directly?
Not recommended, because
high-concentration things may damage the
refrigerator directly.
If you want to put something with high
concentration, please put it in a container and
refrigerate it.
8. What kind of cable do I need to use in
the car and at home?
When using in the car, you need to use DC
cable. You need to connect the DC cable to the
AC adapter when using at home. (Except for
JP series and VL series which have individual
cables for home and car; VL35 Series need to
buy AC adapter separately).
14

15
9. What is the specification of the fuse of
the refrigerator?
The supply line is protected by a 15A fuse
located in the refrigerator.
Safety Instruction
7
SAFETY INSTRUCTIONS
Please read the user manual and safety
instructions carefully before using the
appliance.
By ignoring the safety instructions, the
manufacturer cannot be held responsible for
the damage.
The use of accessories that are not
recommended by manufacturer can cause
injuries and will invalidate any warranty that
you may have.
The appliance shall not be exposed to rain.
Place the refrigerator on a dry, protected
surface, away from corners.

16
Do not use the refrigerator in uncovered,
outdoor areas exposed to the elements.
！
Do not use this appliance near direct heat
sources, for example, a cooker, radiator
or exposing it to direct sunlight.
！
Do not place ice or liquids which are not
sealed in containers within the refrigerator.
！
Do not place hot products or hot food in the
refrigerator. Place the products so that they
do not knock against each otheror break
when the appliance is in motion.
！
Ensure that the lid is always firmly on and reduce
the time it is left open to the minimum possible.
The power cable must only be replaced by qualified
technical personnel and by an assistant body
authorized by the manufacturer.
Before carrying out any maintenance operations
on the refrigerator, disconnect the power cable
from the plug.
This appliance is suitable for camping use.

17
WARNING!
Keep ventilation openings, in the
appliance enclosure or in the built-in
structure, clear of obstruction.
！
Do not use mechanical devices or other
means to accelerate the defrosting
process, other than those recommended
by the manufacturer.
！
Do not damage the refrigerant circuit.
！
Do not use electrical appliances inside
the food storage compartments of the
appliance, unless they are of the type
recommended by the manufacturer.
！
Do not store explosive substances such
as aerosol cans with a flammable
propellant in this appliance.
！
Risk of fire and electrical shock.
！
Do not let hot items touch the plastic
parts of the appliance.
！
Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
！
