Iceco VL45 ProS User manual

Please email us at: offi[e-mail]
VL45/60 ProS
V1.5

Catalogue
1 1
- - - - - - - - -
Tips For Opening The Door
2 2
- - - - - - - - - - - - - - - - - - - - - -
Supply Details
3 4
- - - - - - - - - - - - - - - - - - - - - - - - - - -
Operation
4 8
- - - - - - - - - -
Cleaning And Maintenance
5 10
-----------
Error Codes & Solutions
6 12
- - - - - - - - - -
Warranty & Return Policy
7 13
- - - - - - - - - - -
Troubleshooting (Q & A)
8 17
-----------------
Safety Instructions

Tips For Opening The Door
1
1. To open the lid from the
right side, keep fingers
together and grip the
right latch.
2. Push the latch inwards
and lift up the lid.
3. To open the lid from the
left side, repeat the
above steps.
4. Grip the latch on both
sides and push them
inwards to disassemble
the lid.
01

Supply Details
Refrigerator x1 Wire Basket x1
02
2
Extra Supplies
5.9 Feet 110V AC Wall
Outlet Cable X1
11.5 Feet 12/24V
DC Cigarette
Lighter Plug Cable x1
Drain Plug
x 1
Screws
x 2
Corner Guards
x 4
Handle
x 1
Allen Wrench
x 1

MODEL VL45 ProS VL60 ProS
Dimensions
HxWxD
Net
Weight
Storage
Volume
Refrigerant
712.6x406.1x461 mm
DC 12/24V & AC 110-120V
R513A
28.1x15.9x18.1 inch
767.6x470.1x461 mm
30.2 x18.5x18.1 inch
52.0 lbs 55.8 lbs
47.5 quarts 63.4 quarts
23.6 kg 25.3 kg
45 liters 60 liters
-18°C to +10°C (0°F to 50°F)
Temperature
Range
Voltage
03

3Operation
04
BPower ON/OFF Button
CCompressor Speed (MAX/ECO Mode)
ABattery Protection Settings
DTemp DOWN Button
ETemp UP Button
A B C
D
E
TEMPERATURE

05
3.1 MAX & ECO Mode
After the fridge turned on(Press & Hold B/Power
Button), you can press the MODE Button C to
switch between MAX or ECO mode for the
fridge.
A B C
D
E
TEMPERATURE
3.2 Switch Between °C and °F
After the fridge turned on(Press & Hold B/Power
Button), press and hold Button C and Button D
for 3 seconds to switch between the temperature
values of Celsius & Fahrenheit.
A B C
D
E
TEMPERATURE

06
Press Temperature Up (Button E) to increase
the temperature.
Press Temperature Down (Button D) to decrease
the temperature.
The SET temperature will appear as a
FLASHING number and after the temperature
is SET, the display will return to show the fridge’s
CURRENT interior temperature.
3.3 Setting Temperature
After the fridge turned on, the fridge's CURRENT
interior temperature reading will appear on the
display, as a solid non-flashing number. To
change the fridge's set temperature:
A B C
D
E
TEMPERATURE

07
NOTICE: Details of Battery Protection
Mode could be found in Page 15.
3.4 Triple Battery Protection Operation
After the fridge turned on, press Battery Protection
Button A to adjust the fridge's low battery
protection level pre-sets.
A B C
D
E
TEMPERATURE
+
3.5 USB Connector
NOTICE: USB connector only takes
effect when charging in DC power cord.

Cleaning And Maintenance
4
08
4.1 Cleaning
Always unplug the fridge before cleaning
the fridge.
You can clean the interior and exterior of
the fridge by using warm water, mixed
with a gentle non-abrasive detergent.
You may use a soft sponge, or micro fiber
cloth.
When not in use, it’s better to leave the lids
open to reduce odors.
If odors occur, please clean the fridge
thoroughly, or use baking soda in a bowl
to absorb odors.

09
4.2 Danger Behavior
Use pointed objects to scrape, or defrost ice.
Use abrasive detergents to clean.
Use heavy duty sponges (due to scratching).
Clean the fridge with running water or
pressure washer.
Clean the fridge without power input covers
secured.

10
Error Codes & Solutions
5
The DC voltage is below the protection
settings and the battery protection
mode is activated.
E1
Code Description
The cooling fan is over-loaded with
more than 1A of current.
E2
Motor start error
The motor of compressor is blocked or
the pressure difference in the
refrigeration system is too high.
E3
Minimum motor speed error
The compressor is over-loaded, and the
motor cannot maintain its minimum
speed of 1850 rpms.
E4
Thermal cut-out of electronic unit
Thermal cut-out error. If the refrigeration
system overloads, or the ambient
temperature is too high, the thermal
sensor is overheated.
E5
NTC failure (open circuit)
LL
NTC failure (short circuit)
HH

11
Solutions
If this error code appears when the fridge is
operating on 12V DC, please try to lower the
battery protection setting and see if the error
is resolved. The battery protection mode may
be triggered prematurely on certain vehicles
due to small wiring imperfections, contributing
to a measured DC voltage drop at compressor
start-up. Lowering the battery protection
setting may resolve this issue.
Please also care about the reading of your
battery voltage to make sure it is not
depleted/discharged.
If possible, please connect the AC power to try
if the refrigerator appears error code.
Please contact us directly if the error persists.

12
Warranty & Return Policy
6
30 days refund guarantee upon receiving.
For returns or exchanges, please call us,
or fill out the following return and exchange
registration form in the package as a proof
of return. All materials must be returned in
the original condition and packaging. Thank
you for your cooperation.
If the product is received damaged or
defective during transportation, you will
need to contact our customer service
within 2 business days. Make sure to
provide relevant photos or videos, your
order ID number, and your name. A
customer service agent will help assist
into solving the issue at a timely manner
(Return, Exchange, or Discount
Compensation). A free return label will be
provided if needed.
5 years warranty on the compressor.
1 year warranty for other parts or accessories.

13
Troubleshooting (Q & A)
7
1. Heat resistance & water resistance
ICECO refrigerators are engineered to operate at
an ambient temperature of up to 55 °C(131 °F).
Heat resistance
ICECO refrigerators can operate under light rain
conditions. Please keep the vents above clear
of water, and please add some clearances to
the bottom of the fridge if the ground is wet.
Weather Proof
We DO NOT recommend exposing the fridge
to moderate or heavy rain.
As with all electrical appliances, over-exposure
to moisture may shorten the fridge’s life.

14
2. Why did it change back to the original
temperature after setting the
temperature?
The Solid/Non-Flashing number on the display
is the CURRENT interior temperature.
The Flashing number is your SET temperature
after adjustment. The compressor will shut off
when the SET temperature is reached.
3. What should I do if the refrigerator is
upside down when it is delivered?
Please leave your refrigerator upright for 24
hours to allow the compressor lubricant to
resettle before powering on the fridge.
Otherwise it may contribute to certain operation
abnormalities.
4. What is the function of triple battery
protection? How do they work?
The triple battery protection is designed to
prevent over-discharge and battery depletion.
When the measured DC voltage is below the
set value, the compressor is shut off to prevent
battery depletion.

15
LOW
VOLTAGE
PROTECTION
POSITION
DISPLAY
12V
CUT OFF
(V)
CUT IN
(V)
CUT OFF
(V)
CUT IN
(V)
24V
1 Bar
2 Bars
3 Bars
9.6 10.9 21.3 22.7
10.4 11.7 22.8 24.2
11.1 12.4 24.3 25.7
MED
HIGH
For example, when you switch to a LOW MODE,
the battery voltage is under 9.6 volts, the
refrigerator will automatically cut the power OFF;
The refrigerator will start again till the battery
voltage reached back to 10.9 volts.
5. What is the power draw in max/ fast
cooling mode?
Model Electrical
Power
GO12 50W
Model Electrical
Power
JP42 55W
GO20 50W VL35
Series 65W
JP Series 60W VL Series 85W
VL45 ProS 45W VL60 ProS 47W
VL75 ProD 57W VL90 ProD 61W

16
Because of the sinking nature of cold air, the
different temperatures may exist in different
locations in the refrigerator (the temperature of
the bottom will be the lowest). The panel only
shows the average temperature of the refrigerator.
6. Why is there a temperature difference
(between the actual temperature of the
refrigerator and the set temperature)?
7. What kind of cable do I need to use in
the car and at home?
The DC cable is provided. You can power it
from your vehicle's cigarette lighter plug using
the DC cable. You can also power it at home,
but you need to use with AC cable as
precondition.
8. What is the specification of the fuse
of the refrigerator?
The supply line is protected by a 15A fuse
located in the refrigerator.
This data is only suitable for laboratory testing,
and the actual power is subject to actual
conditions.

17
Safety Instruction
8
SAFETY INSTRUCTIONS
Please read the user manual and safety
instructions carefully before using the appliance.
By ignoring the safety instructions, the
manufacturer cannot be held responsible for
the damage.
The use of accessories that are not
recommended by manufacturer can cause
injuries and will invalidate any warranty that
you may have.
The appliance shall not be exposed to
moderate/heavy rain.
Place the refrigerator on a dry, secure surface,
with adaquate ventilation.

18
Do not leave the refrigerator unattended
in uncovered, outdoor areas exposed to
the elements.
！
Do not use this appliance near direct
heatsources, such as an open flame or
radiator.
！
Do not place open containers of liquid
inside the fridge.
！
Please don't put hot/warm food into the
fridge directly without letting it cooling
off. Place/arrange the content of your
fridge securely when using the refrigerator
inside a moving vehicle.
！
To maximize energy savings, please make sure
the lid is closed and secure, and only open the
fridge when you need to.
The power cable must only be replaced by
qualified technical personnel and by an
assistant body authorized by the manufacturer.
Before carrying out any maintenance operations
on the refrigerator, disconnect all power sources
from the fridge.
This appliance is suitable for camping use.
