Icom IC-R6 User manual

INSTRUCTION MANUAL
iR6
COMMUNICATIONS RECEIVER
New2001
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
WARNING: MODIFICATION OF THIS DEVICE TO RECEIVE
CELLULAR RADIOTELEPHONE SERVICE SIGNALS IS
PROHIBITED UNDER FCC RULES AND FEDERAL LAW.

i
New2001
FOREWORD
Thank you for purchasing this Icom product. The IC-R6
communications receiver is designed and built with Icom’s
superior technology and craftsmanship. With proper care,
this product should provide you with years of trouble-free
operation.
We want to take a moment of your time to thank you for mak-
ing your IC-R6 your radio of choice, and hope you agree with
Icom’s philosophy of “technology first.” Many hours of research
and development went into the design of your IC-R6.
DFEATURES
mCovers 0.100–1309.995 MHz* wide
frequency range
* Some frequency bands are prohibited , depending on the
receiver version
mExternal power supply operation
m1300 memory channels with 22 banks
available
m150 mW* AF power with BTL (bridge-tied
load) amplifier
 *At 10% distortion with a 16 Ωload (internal speaker)
IMPORTANT
READ ALL INSTRUCTIONS carefully and completely
before using the receiver.
SAVE THIS INSTRUCTION MANUAL— This
instruction manual contains important operating instructions
for the IC-R6.
EXPLICIT DEFINITIONS
WORD DEFINITION
RDANGER! Personal death, serious injury or an
explosion may occur.
RWARNING! Personal injury, fire hazard or electric
shock may occur.
CAUTION Equipment damage may occur.
NOTE Recommended for optimum use. No risk
of personal injury, fire or electric shock.
Icom, Icom Inc. and the Icom logo are registered trademarks of
Icom Incorporated (Japan) in Japan, the United States, the United
Kingdom, Germany, France, Spain, Russia and/or other countries.
Microsoft, Windows and Windows Vista are registered trademarks
of Microsoft Corporation in the United States and/or other countries.

ii
New2001
RWARNING! NEVER operate the receiver with a
earphone, headphones or other audio accessories at high
volume levels. Hearing experts advise against continuous
high volume operation. If you experience a ringing in your
ears, reduce the volume level or discontinue use.
RWARNING! NEVER operate the receiver while
driving a vehicle. Safe driving requires your full attention—
anything less may result in an accident.
RWARNING! NEVER connect the receiver to an AC
outlet. This may pose a fire hazard or result in an electric
shock.
RWARNING! NEVER throw a battery cell into a fire
since as internal battery gas can cause explosion.
RWARNING! NEVER disassemble the battery cell.
If the battery cell’s internal material (electrolyte liquid) gets
into your eyes, wash your eyes with water and obtain treat-
ment from an eye doctor immediately.
NEVER connect the receiver to a power source of more
than 6.3 V DC directly. This will damage the receiver.
NEVER connect the receiver to a power source using
reverse polarity. This will damage the receiver.
NEVER expose the receiver to rain, snow or any liquids.
The receiver may be damaged.
NEVER operate or touch the receiver with wet hands. This
may result in an electric shock or damage the receiver.
NEVER solder the battery cell. This may damage the bat-
tery.
DO NOT use or place the receiver in direct sunlight or
in areas with temperatures below –10°C (+14˚F) or above
+60°C (+140˚F).
DO NOT use harsh solvents such as benzine or alco-
hol to clean the receiver, because they can damage the
receiver’s surfaces.
Even when the receiver power is OFF, a slight current still
flows in the circuits. Remove batteries from the receiver
when not using it for a long time. Otherwise, the installed
batteries will become exhausted, and will need to be
recharged.
PRECAUTIONS

iii
New2001
FCC INFORMATION
• FOR CLASS B UNINTENTIONAL RADIATORS:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential
installation. This equipment generates, uses and can radi-
ate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guar-
antee that interference will not occur in a particular instal-
lation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit differ-
ent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV techni-
cian for help.
OPERATING THEORY
Electromagnetic radiation, which has frequencies of
20,000 Hz (20 kHz*) and above, is called radio frequency
(RF) energy because, it is useful in radio transmissions. The
IC-R6 receives RF energy from 0.100 MHz* to 1309.995
MHz and converts it into audio frequency (AF) energy which
in turn actuates a loudspeaker to create sound waves.
AF energy is in the range of 20 to 20,000 Hz.
*kHz is an abbreviation of kilohertz or 1000 hertz, MHz is abbrevi-
ation of megahertz or 1,000,000 hertz, where hertz is a unit of fre-
quency.
OPERATING NOTES
The IC-R6 may receive its own oscillated frequency, result-
ing in no reception or only noise reception, on some fre-
quencies.
The IC-R6 may receive interference from extremely strong
signals on different frequencies or when using an external
high-gain antenna.
CAUTION: Changes or modifications to this device, not
expressly approved by Icom Inc., could void your authority
to operate this device under FCC regulations.

iv
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
TABLE OF CONTENTS
FOREWORD ………………………………………………… i
IMPORTANT ………………………………………………… i
EXPLICIT DEFINITIONS …………………………………… i
PRECAUTIONS ……………………………………………… ii
FCC INFORMATION ……………………………………… iii
OPERATING THEORY …………………………………… iii
OPERATING NOTES ……………………………………… iii
TABLE OF CONTENTS ………………………………… iv–v
SUPPLIED ACCESSORIES ………………………………… v
QUICK REFERENCE GUIDE ���������� I–VII
nPreparation ……………………………………………… I
nYour first scanning experience ……………………… III
nMemory programming ……………………………… IV
nProgrammed scan operation………………………… V
1 PANEL DESCRIPTION ������������ 1–4
nFront, top and side panels ………………………… 1
nFunction display ……………………………………… 3
2 BATTERY CHARGING ������������ 5–8
nBattery installation …………………………………… 5
nCaution ………………………………………………… 5
nBattery charging ……………………………………… 7
3 FREQUENCY AND CHANNEL SETTING ��� 9–12
nVFO and memory channels ………………………… 9
nFrequency band selection …………………………… 9
nSetting a frequency …………………………………… 11
nSetting a tuning step ………………………………… 11
nSelecting a memory channel………………………… 12
nLock function ………………………………………… 12
4 BASIC OPERATION ������������ 13–17
nReceiving ……………………………………………… 13
nSetting audio volume ………………………………… 13
nSquelch level setting ………………………………… 14
nReceive mode selection ……………………………… 14
nMonitor function ……………………………………… 15
nAttenuator function …………………………………… 15
nDuplex operation ……………………………………… 16
nDial select step ……………………………………… 17
5 MEMORY CHANNELS ����������� 18–27
nGeneral description…………………………………… 18
nSelecting a memory channel………………………… 18
nMemory channel programming ……………………… 19
nMemory bank setting ………………………………… 20
nMemory bank selection ……………………………… 21
nProgramming memory/bank name ………………… 22
nSelecting display type………………………………… 23
nCopying memory contents …………………………… 24
nMemory clearing ……………………………………… 25
nTransferring memory contents ……………………… 26
nErasing/transferring bank contents ………………… 27
6 SCAN OPERATION ������������ 28–37
nScan types …………………………………………… 28
nFull/band/programmed link/programmed scan …… 29
nScan edges programming …………………………… 30
nProgramming scan name …………………………… 31
nProgramming other contents ………………………… 32
nMemory/all bank/bank link/bank scan ……………… 33
nAuto memory write scan …………………………… 34
17

v
New2001
nSkip channel/frequency setting……………………… 35
nScan resume setting ………………………………… 37
7 PRIORITY WATCH ������������ 38–40
nPriority watch types…………………………………… 38
nPriority watch operation ……………………………… 39
8 TONE SQUELCH AND POCKET BEEP ��� 41–44
nTone squelch frequency/DTCS code setting ……… 41
nTone/DTCS squelch operation ……………………… 43
nTone scan ……………………………………………… 44
9 Set mode ���������������� 45–56
nGeneral ………………………………………………… 45
nSet mode items ……………………………………… 46
10 OTHER FUNCTIONS ����������� 57–63
nAntenna selection …………………………………… 57
n[DIAL] function assignment ………………………… 58
nAuto power-off function ……………………………… 58
nWeather channel operation ………………………… 59
nData cloning ………………………………………… 61
nPartial reset …………………………………………… 63
nAll reset ……………………………………………… 63
11 CONTROL COMMAND ����������� 64–61
nGeneral ………………………………………………… 64
nData format …………………………………………… 64
nCommand table ……………………………………… 65
12 FREQUENCY TABLE ����������� 67–74
nTV channels …………………………………………… 67
nVHF marine channels ………………………………… 70
nWeather channels …………………………………… 70
nOther communications in the USA ………………… 72
nOther communications— other countries ………… 73
13 MAINTENANCE �������������� 75–76
nTroubleshooting ……………………………………… 75
nCP-18A/E fuse replacement ………………………… 76
14 SPECIFICATIONS ��������������� 77
15 OPTIONS ������������������ 79
16 POCKET GUIDE ������������� 80–81
17 CE �������������������� 81–82
SUPPLIED ACCESSORIES
qAntenna ············································································1
wHand strap ········································································1
eBelt clip·············································································1
rNi-MH batteries*atteries* ······························································ 2
tAC adapter* ····································································· 1
* Not supplied, or the shape is different, depending on the receiver
version.
New2001
TABLE OF CONTENTS
qw
e r t

■Preparation
DBattery installation
qRemove the batter y
cover from the receiver.
wInstall two AA (LR6)
size Ni-MH or alkaline
cell batteries.
• Be sure to observe the
correct polarity.
• Charge the Ni-MH bat-
teries before use. (See
page II for charging
instructions.)
Keep the battery terminals clean. It’s a good idea to clean
the battery terminals once a week.
DBelt clip
Conveniently attaches to your
belt.
To attach the belt clip:
Slide the belt clip into the plastic
loop on the back of the receiver.
To detach the belt clip:
Hold down the tab (q), and slide
the belt clip in the direction of the
arrow (w).
DAntenna
Insert the antenna connector into
the antenna base and tighten the
antenna screw.
• NEVER carry the receiver by
holding only the antenna.
• When the jack is not in use,
keep the jack cover attached
to protect the connectors from
dust and moisture.
✔For your information
Third-party antennas may increase receiver performance.
An optional AD-92SMA antenna connector adapter is
available to connect an antenna with a BNC connector.
DHandstrap
To facilitate carrying the receiver,
slide the hand strap through the
loop on the top of the belt clip.
Latch
q
w
I
QUICK REFERENCE GUIDE
New2001
Quick reference guide

II
QUICK REFERENCE GUIDE
New2001
DCharging the battery
Receiver
CP-18A/E
Cigarette lighter cable
with DC-DC converter
BC-196SA/SD/BC-153SC
to a cigarette
lighter socket
The shape may
differ, depending
on the version.
to an AC outlet
to the [DC4.5V]
jack
qInstall the Ni-MH batteries.
wPlug the AC adapter into an AC outlet.
eInsert the adapter plug into the [DC4.5V] of the receiver.
• The battery confirmation is displayed.
RWARNING!:
NEVER attempt to charge the alkaline batteries.
rRotate [DIAL] to select “Y,” then push [BAND].
[DIAL]
• The charging confirmation is displayed.
tRotate [DIAL] to select “Y,” then push [BAND] to start the
battery charging.
Rotate Then, push
• The battery icon scrolls during charge.
• Both segments blink when completely charged.
NOTE: When no operation is performed for 10 seconds, the
receiver automatically skips these settings, and the receiver
cannot charge the batteries. In that case, remove the batteries
for more than 2 seconds and retry these setting from step q.

III
QUICK REFERENCE GUIDE
New2001
Quick reference guide
Now that you have your IC-R6 ready, you are probably ex-
cited to start listening. We would like to take you through a
few basic operation steps to make your first “Listennig Expe-
rience” enjoyable.
DAbout the default settings
The [DIAL] control function can be traded with the [p]/[q]
keys function. However, in this QUICK REFERENCE
GUIDE, the factory default setting ([DIAL] selects the oper-
ating frequency) is used for simple instruction.
DBasic operation
1. Turning ON the receiver
➥Hold down [ ] for 1 second to
turn the power ON.
2. Adjusting audio level
➥Push [p]/[q]to set a desired
audio level.
3. Adjusting squelch level
➥While holding down [SQL],
rotate [DIAL] to set the squelch
level.
4. Setting a desired frequency
The tuning dial will allow you to dial in the frequency you
want to listen to. Pages 11 and 17 will instruct you on how to
set the tuning speed.
qPush [BAND] repeatedly to
select a frequency band.
• While holding down [BAND], then
rotating [DIAL] will also select a
frequency band.
wRotate [DIAL] to set the receive
frequency.
• While holding down [FUNC], rotate
[DIAL] to select frequencies in
MHz steps.
■Your first scanning experience
[DIAL]
[DIAL]

IV
QUICK REFERENCE GUIDE
New2001
■Your first scanning experience (continued)
5. Receive mode selection
➥Push [MODE] repeatedly to
select a desired receive mode.
• The FM, WFM or AM is selectable.
■Memory programming
The IC-R6 has 1300 memory channels for storing often used
receive frequency, mode, etc.
1. Setting frequency
In the VFO mode, set a desired receive frequency and
receive mode.
• When the “ ” icon is displayed, push [V/M] to select the VFO
mode.
2. Selecting a memory channel
Hold dow n [S.MW](V /M ) fo r
1 second, then rotate [DIAL] to
select a desired memory channel.
• The “ ” icon and memory chan-
nel number blink.
3. Writing a memory channel
Hold down [S.MW](V/M) for 1 second until 3 beeps sound.
• The memory channel number automatically increases if you con-
tinue to hold down [S.MW](V/M) after programming.
[DIAL]

V
QUICK REFERENCE GUIDE
New2001
■Programmed scan operation
25 pairs (50 channels) of scan edge memories, specify the
scanning ranges, are used for programmed scan operation.
The programmed scan scans between the frequencies in
channels “xxA” and “xxB” (xx=00 to 24). Therefore, before
operating the programmed scan, different frequencies must
be programmed into “A” and “B” scan edge channels.
DProgramming scan edges
A start frequency must be programmed into a “xxA,” and an
end frequency must be programmed into a “xxB” memory
channel.
1. Setting frequency
In the VFO mode, set a desired receive frequency and
receive mode.
• When the “ ” icon is displayed, push [V/M] to select the VFO
mode.
2. Selecting a scan edge “A” channel
Hold down [S.MW](V/M) for 1 second, then rotate [DIAL] to
select one of the 25 scan edge “A” channels.
• The “ ” icon and scan edge channel number blink.
3. Writing a scan edge channel
Hold down [S.MW](V/M) for 1 second until 3 beeps sound.
• The paired scan edge “B” channel is automatically selected if you
continue to hold down [S.MW](V/M) after programming.
• When programming is completed, return to the VFO mode.
4. Setting frequency
In the VFO mode, set a desired receive frequency.
5. Selecting a scan edge “B” channel
Hold down [S.MW](V/M) for 1 second, then rotate [DIAL] to
select one of the 25 scan edge “B” channels.
• The “ ” icon and the scan edge channel number blink.
• When the scan edge “B” channel is already selected in step 3, (by
holding down [S.MW](V/M) after programming), skip this step.
6. Writing a scan edge channel
Hold down [S.MW](V/M) for 1 second until 3 beeps sound.
• The next scan edge “A” channel is automatically selected if you
continue to hold down [S.MW](V/M) after programming.
• When programming is completed, return to the VFO mode.
Quick reference guide

VI
QUICK REFERENCE GUIDE
New2001
DStarting scan
1. Select the VFO mode.
Push [V/M] to select the VFO mode for a VFO scan opera-
tion, such as full scan, band scan and programmed scan.
• Select the memory mode by pushing [V/M] again for a memory
scan operation, such as all memory scan, bank link scan or bank
scan.
2. Selecting a scan type
Hold down [SCAN](MODE) for
1 second, and then rotate [DIAL]
to select one of the desired scan-
ning types.
• Select “ALL” for full scan, “BAND”
for band scan, “P-LINK x” for pro-
grammed link scan (x= 0 to 9),
“PROGxx” for programmed scan
(xx= 0 to 24; only programmed scan
edge numbers are displayed).
• Select “M-ALL” for all memory scan,
“B-ALL” for all bank scan, “B-LINK”
for bank link scan or “BANK-x” for
bank scan (x= A to R, T, U, W, Y; only
programmed bank groups are dis-
played).
• Full scan
• Band scan
• Program link scan
• Program scan
• All memory scan
• All bank scan
• Bank link scan
• Bank scan
Scan type display examples
In the VFO mode In the memory mode

VII
QUICK REFERENCE GUIDE
New2001
3. Starting scan
Push [SCAN](MODE) to start the scan.
• Rotate [DIAL] to change the scanning direction.
• Full/Band scan
• Program link
Program scan
• All memory/All bank
bank link scan
• Bank scan
In the VFO mode In the memory mode
4. Cancelling scan
Push [SCAN](MODE) again to stop the scan.
✔For your information
The memory channel number you program the scan edges
into correlates “PROGxx” as follows:
00A/00B: Selects “PROG 00” to scan between frequencies
programmed in channels 00A and 00B.
01A/01B: Selects “PROG 01” to scan between frequencies
programmed in channels 01A and 01B.
•
•
•
•
23A/23B: Selects “PROG 23” to scan between frequencies
programmed in channels 23A and 23B.
24A/24B: Selects “PROG 24” to scan between frequencies
programmed in channels 24A and 24B.
Quick reference guide

1
New2001
PANEL DESCRIPTION
1
!2
!0
u
t
r
e
w
!1
q
Function display
(pp 3, 4)
Speaker
o
i
y
qANTENNA CONNECTOR (p. I)
Connect the supplied antenna.
• An optional AD-92SMA is available for connecting an antenna
with a BNC connector.
wFUNCTION KEY [FUNC]
While holding down this switch, access a key’s secondary
or third function.
eSQUELCH • ATTENUATOR KEY [SQL] • [ATT](SQL)
➥Hold down to temporarily open the squelch and moni-
tor the operating frequency. (p. 15)
➥While holding down this switch, rotate [DIAL]* to adjust
the squelch level. (p. 14)
➥While holding down [FUNC], push to toggle the attenu-
ator function ON or OFF. (p. 15)
rUP/DOWN KEYS [p]/[q]*
Adjusts the audio volume level. (p. 13)
tBAND • LOCK • MEMORY NAME KEY
[BAND] • [ ](BAND) • [ ](BAND)
➥Push to select the operating frequency band. (p. 9)
➥While holding down [FUNC], push and hold for
1 second to toggle the lock function ON or OFF. (p. 12)
➥During memory mode operation, hold down [FUNC],
then push this key to select the display type.
• The display shows the memory bank name†, memory name†
and channel number in sequence, and then returns to the
frequency display. (†The memory bank name or memory
name must have preprogrammed.)
yTUNING STEP • SET • DIAL EXCHANGE KEY
[TS] • [SET](TS) • [ ](TS)
➥Push to enter the tuning step selecting mode. (p. 11)
➥Hold down for 1 second to enter the Set mode. (p. 45)
➥While holding down [FUNC], push to exchange the
[DIAL] and [p]/[q]keys’ functions. (p. 58)
*The functions of [DIAL] and [p]/[q]can be exchanged.
See page 58 for details.
■Front, top and side panels

2
1
PANEL DESCRIPTION
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
uPOWER KEY [ ]
Hold down for 1 second to turn the receiver power ON or
OFF.
iMODE • SCAN • TONE SCAN KEY
[MODE] • [SCAN](MODE) • [ ](MODE)
➥Push to select the receive mode. (p. 14)
➥Hold down for 1 second to enter the scan type selec-
tion mode. (pp. 29, 33)
• Push again to start the scan.
➥While holding down [FUNC], push to start a tone scan.
(p. 44)
oVFO/MEMORY • MEMORY WRITE • SKIP KEY
[V/M] • [S.MW](V/M) • [ ](V/M)
➥Toggles between the VFO and the memory mode. (p. 9)
➥Hold down for 1 second to enter the memory edit
mode. (p. 19)
mWhile in the VFO mode (p. 29)
Hold down [FUNC], then push this key to set the VFO
skip scan setting ON or OFF.
mWhile in the memory mode (p. 35)
Hold down [FUNC], then push this key to select the
scan skip setting for the selected channel.
!0EXTERNAL DC-IN CONNECTOR [DC4.5V] (p. 7)
Connect an AC adapter or an optional cigarette lighter
cable for both charging the installed rechargeable battery
and operating. Connectable voltage is from 4.5 V DC to
6.3 V DC.
!1EXTERNAL SPEAKER CONNECTOR [SP]
Connect an optional earphone or headphones.
The internal speaker will not function when any external
equipment is connected. (See page 79 for a list of avail-
able options.)
!2CONTROL DIAL [DIAL]*
➥Rotate to select the operating frequency. (p. 11)
➥While scanning, changes the scanning direction.
(pp. 29, 33)
➥While holding down [SQL], sets the squelch level.
(p. 14)
➥While holding down [FUNC], sets the operating fre-
quency in 100 kHz, 1 MHz or 10 MHz in the VFO
mode. (pp. 11, 17)
➥While holding down [FUNC], selects the memory
channel in 10 channels steps in the memory mode.
(pp. 12, 18)
➥While holding down [BAND], selects the frequency
band in the VFO mode. (p. 9)
*The functions of [DIAL] and [p]/[q]can be exchanged.
See page 58 for details.

3
1PANEL DESCRIPTION
New2001
qBATTERY ICON
➥Both segments appear when the batteries have ample
capacity.
• They do not appear when operating with an external power
source.
➥Only the right segment “ ” appears when the batter-
ies have less than half capacity.
➥Scrolls while charging the rechargeable batteries. (p. 8)
➥Both segments disappear when completely charged.
wLOCK ICON (p. 12)
Appears when the lock function is activated.
eDUPLEX ICONS (p. 16)
“DUP” appears when plus duplex, and “DUP–” appears
when minus duplex operation is selected.
rTONE ICONS (p. 43)
➥“T SQL” appears while the tone squelch function is in use.
➥“T SQL-R” appears while the reverse tone squelch
function is in use.
➥“DTCS” appears while the DTCS squelch function is in
use.
➥“DTCS” appears while the reverse DTCS squelch func-
tion is in use.
➥“S” appears with the “T SQL” or “DTCS” icon while
the pocket beep function (with Tone squelch or DTCS
squelch) is in use.
■Function display
q
!5
!3 !2
o
i
!1
!0
!4
w e yr t u

4
1
PANEL DESCRIPTION
New2001
1
tVSC ICON (p. 52)
Appears while the VSC (Voice Squelch Control) function
is in use.
yAUTO WRITE CHANNEL ICON (p. 34)
Appears when an auto write channel is selected.
uSKIP ICONS
mWhile in the VFO mode (p. 29)
“PSKIP” appears when the VFO skip scan setting is
ON.
mWhile in memory mode (p. 35)
➥“SKIP” appears when the selected memory channel
is specified as a skip channel.
➥“PSKIP” appears when the displayed frequency is
specified as a skip channel for the memory scan or
skip frequency for the VFO scan.
iPRIORITY WATCH ICON (pp. 39, 40)
Appears while priority watch is in use.
oMEMORY ICON (pp. 9, 18)
Appears when the memory mode is selected.
!0MEMORY CHANNEL NUMBER
Shows the selected memory channel number. (pp. 9, 18)
!1SIGNAL STRENGTH INDICATOR (p. 13)
Shows the relative signal strength while receiving signals.
!2ATTENUATOR ICON (p. 15)
Appears while the RF attenuator is in use.
!3RECEIVE MODE ICONS (p. 14)
Shows the selected receive mode.
• FM, WFM and AM modes are selectable.
!4VOLUME EXCHANGE ICON (p. 58)
Appears when the function of [DIAL] and [p]/[q]are
exchanged.
!5FREQUENCY READOUT
Shows a variety of information, such as the operating fre-
quency, Set mode contents, memory names.
• The smaller “75,” “50” or “25” to the right of the frequency read-
out shows the 0.75, 0.5 or 0.25 kHz, respectively.
• The decimal point blinks during a scan.

5
New2001
BATTERY CHARGING
2
■Battery installation
Before installing, or replacing the batteries, hold down [ ]
for 1 second to turn the power OFF.
qRemove the battery cover from the receiver.
Latch
wInstall two AA (LR6) size Ni-MH batteries.
• Be sure to observe the correct polarity.
■Caution
• RDANGER! NEVER short the battery terminals (or charg-
ing terminals on the bottom of the receiver). Also, current
may flow into nearby metal objects such as a necklace, so
be careful when placing batteries (or the receiver) in hand-
bags, etc.
Simply carrying with or placing near metal objects such as
a necklace, etc. may cause shorting. This may damage not
only the batteries, but also the receiver.
• RDANGER! NEVER incinerate used batteries. Internal
battery gas may cause an explosion.
• RDANGER! NEVER immerse the batteries in water. If the
batteries become wet, be sure to wipe them dry BEFORE
installing them to the receiver.
• When installing batteries, make sure they are all the same
brand, type and capacity. Also, do not mix new and old bat-
teries together.
• Never use batteries whose insulated covering is damaged.
• Keep battery terminals clean to avoid rust or misscontact.
It’s a good idea to clean battery terminals once a week.
DCaution for the Ni-MH batteries
• CAUTION: Always use the batteries within the speci-
fied temperature range, –5˚C to +60˚C (+23˚F to +140˚F).
Using the batteries out of their specified temperature range
will reduce the battery’s performance and battery life.

6
2
BATTERY CHARGING
New2001
2
• CAUTION: Shorter battery life could occur if the batteries
are left completely discharged, or in an excessive temper-
ature environment (above +55˚C; +131˚F) for an extended
period of time. If the batteries must be left unused for a
long time, they must be detached from the receiver after
charging. Keep them safely in a cool dry place at the fol-
lowing temperature range:
–20˚C to +45˚C (–4˚F to +113˚F) (up to a month)
–20˚C to +35˚C (–4˚F to +95˚F) (up to six months)
–20˚C to +25˚C (–4˚F to +77˚F) (up to a year*)
* We recommend charging the batteries every 6 months.
• If your Ni-MH batteries seem to have no capacity, even
after being charged, completely discharge them by leaving
the power ON overnight. Then, fully charge the batteries
again. If the batteries still do not retain a charge (or only
very little charge), a new batteries must be purchased.
Prior to using the receiver for the first time, the batteries
must be fully charged for optimum life and operation.
• The supplied batteries are rechargeable batteries.
Charge the batteries before first operating the receiver, or
when the batteries become exhausted.
If you want to prolong the battery life, the following points
should be observed:
- Avoid over charging.
- Use the batteries until it becomes almost completely ex-
hausted, under normal conditions.
DCharging caution
• RWARNING! NEVER charge alkaline batteries.
The receiver can charge only the Ni-MH batteries (1.2 V,
1400 mAH typical). Other types of rechargeable battery,
such as Ni-Cd or Li-Ion cannot be charged.
• AVOID over charging— The installed rechargeable batter-
ies can be charged during operation when the AC adapter
or the cigarette lighter cable is connected. To prevent over
charging, the IC-R6 has charging timer that automatically
disconnecting* the charging line electronically after 15 hours
from charging. However, the charging timer will reset and
start charging again when disconnect then reconnecting the
AC adapter or CP-18A/E more than 1 minute interval.
* When the “CHARGE” setting in the Set mode is set to “CHG2 (default),”
the receiver continues to trickle charge after 15 hours have past.
• Recommended temperature range for charging:
between 0°C (+32˚F) and +40°C (+104˚F) by the receiver.
• Use the BC-196SA/SD/BC-153SC AC adapter or CP-18A/
E cigarette liter cable only. NEVER use other manufactur-
ers’ chargers.
• The external DC power supply voltage must be between
12–16 V to charge the batteries and for operation when
using an optional CP-18A/E.
• If the battery icons (“ ” and “ ”) disappear only
1 minute after connecting to the DC power supply, the bat-
teries may have problem. In this case, contact your Icom
dealer/distributor, or purchase new batteries.

7
2BATTERY CHARGING
New2001
■Battery charging
DCharging connections
RWARNING!:
NEVER attempt to charge alkaline batteries.
Receiver
CP-18A/E
Cigarette lighter cable
with DC-DC converter
BC-196SA/SD/BC-153SC
to a cigarette
lighter socket
The shape may
differ, depending
on the version.
to an AC outlet
to the [DC4.5V]
jack
• Charging period: Approx. 15 hours*
* Charging pauses when the receiver’s temperature is out of its
specified temperature range (at that time both battery icons
blink), then resumes when it returns to the specified range. In
that case, the charging time will be longer than 15 hours.
• External DC power operation becomes possible when
using an AC adapter or cigarette lighter cable. The installed
Ni-MH batteries can also be charged simultaneously.
• CAUTION: BE SURE to disconnect the CP-18A/E from the
cigarette lighter socket when charging is finished, because,
a slight current still flows in the CP-18A/E and will drain the
vehicle’s battery.
DCharging description
When charging the installed batteries at the first time, or
once the batteries are removed for more than 2 seconds, the
following operations are necessary.
qInstall Ni-MH batteries. (See page 5.)
wPlug the AC adapter into an AC outlet; or the CP-18A/E
into a cigarette lighter socket.
eInsert the adapter plug into [DC4.5V] of the receiver.
• The battery confirmation is displayed.
If the confirmation does not appear, following operation
is necessary.
qDisconnect the adapter plug from [DC4.5V].
wHolding down [FUNC], insert the adapter plug again.
eRelease [FUNC].
NOTE: When no operation is performed for 10 seconds, the
receiver automatically skips these settings, and the receiver
cannot charge the batteries. In that case, remove the bat-
teries for more than 2 seconds and retry these setting from
step q.
