Icom IC-RX7 Installation and operating instructions

SERVICE MANUAL
ADDENDUM
CONTENTS
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
BOARD LAYOUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 10
Feb. 2010

Feb. 2010
1
SECTION 6.
SECTION 6. PARTS LIST
IC1 1110005180 S.IC UPC2746TB-E3 B 9.4/20.9
IC5 1110005230 S.IC UPC2757TB-E3 B 15.2/19.4
IC8 1110005230 S.IC UPC2757TB-E3 B 29.6/21.7
IC9 1130009981 S.IC TC7W53FK(TE85L,F) B 24/4.3
IC13 1110003201 S.IC TA31136FNG(EL) B 38.1/15.8
Q2 1530003990 S.TRA 2SC4738-BL(TE85L,F) T 17.9/45
Q3 1590001660 S.TRA XP4312(TX) T 21.7/43.2
Q5 1530003810 S.TRA 2SC5008-T1 B 14/30.1
Q6 1530003781 S.TRA 2SC5624VH-TL-E B 9.8/27.8
Q7 1530003612 S.TRA FH102A-TR-E B 22.7/35.3
Q11 1590001680 S.TRA XP1110(TX) B 31.8/38.7
Q12 1530003260 S.TRA 2SC5006-T1 B 28.4/27.6
Q17 1590001810 S.TRA XP1113(TX) B 31.8/36.2
Q18 1590001810 S.TRA XP1113(TX) B 3.2/16.9
Q19 1590001810 S.TRA XP1113(TX) B 5.7/16.9
Q23 1590003251 S.TRA UNR9115G0L B 29/11.4
Q25 1590001190 S.TRA XP6501-(TX).AB B 27.5/9.2
Q26 1590001190 S.TRA XP6501-(TX).AB B 32.3/8.5
Q31 1530003260 S.TRA 2SC5006-T1 B 43.2/22.7
Q36 1530003260 S.TRA 2SC5006-T1 T 39/24.3
Q37 1590002010 S.TRA XP1114(TX) B 28.9/15.8
Q38 1590002010 S.TRA XP1114(TX) T 41.3/21.1
Q39 1590003291 S.TRA UNR9213G0L B 29/13.4
Q40 1590003291 S.TRA UNR9213G0L T 43.7/21.2
Q41 1530003260 S.TRA 2SC5006-T1 B 2.2/32.6
Q42 1530003260 S.TRA 2SC5006-T1 B 1.3/30.3
Q43 1510001110 S.TRA 2SA1577T106R B 11.1/16.6
Q44 1530003990 S.TRA 2SC4738-BL(TE85L,F) B 12.4/13.5
Q45 1590003251 S.TRA UNR9115G0L B 40.4/38
Q46 1590003291 S.TRA UNR9213G0L B 29.8/5.2
Q47 1590003231 S.TRA UNR9113G0L T 21.2/39
D1 1720000241 S.DIO 1SV172(TE85R,F) T 14.8/39.5
D2 1790001261 S.DIO MA2S077G0L T 17.8/38.9
D4 1790001621 S.DIO 1SV308(TPL3,F) B 25.5/39.6
D5 1790001621 S.DIO 1SV308(TPL3,F) T 23.7/38.2
D7 1790001621 S.DIO 1SV308(TPL3,F) B 16.5/39.4
D8 1790001621 S.DIO 1SV308(TPL3,F) B 14.5/38.4
D9 1790001621 S.DIO 1SV308(TPL3,F) B 17.6/37.7
D10 1790001621 S.DIO 1SV308(TPL3,F) B 16.4/37.7
D12 1750000721 S.VAR HVC375BTRF-E B 18.8/33.1
D13 1750000721 S.VAR HVC375BTRF-E B 18/31.4
D14 1790001241 S.DIO MA2S7280GL B 25.5/34.1
D15 1790001241 S.DIO MA2S7280GL B 26.8/34.1
D18 1790001241 S.DIO MA2S7280GL B 5.3/31.1
D19 1790001241 S.DIO MA2S7280GL B 5.3/33.6
D20 1790001241 S.DIO MA2S7280GL B 12.1/31.2
D21 1790001241 S.DIO MA2S7280GL B 12.1/32.4
D22 1790001241 S.DIO MA2S7280GL B 6.5/28.8
D23 1790001241 S.DIO MA2S7280GL B 6.5/31.3
D25 1750000721 S.VAR HVC375BTRF-E B 15.6/27.6
D26 1750000721 S.VAR HVC375BTRF-E B 17.4/28.4
D27 1790001621 S.DIO 1SV308(TPL3,F) B 30.8/34.3
D28 1790001621 S.DIO 1SV308(TPL3,F) B 28.1/34.3
D29 1790001621 S.DIO 1SV308(TPL3,F) T 28.4/35.2
D31 1720000840 S.VAR HVD328CKRU-E B 20.5/30
D32 1750000711 S.VAR HVC350BTRF-E B 2.4/27.3
D33 1790001241 S.DIO MA2S7280GL B 25.5/30.9
D34 1790001241 S.DIO MA2S7280GL B 26.8/30.9
D35 1720000840 S.VAR HVD328CKRU-E B 22.9/28
D36 1750000711 S.VAR HVC350BTRF-E B 3.3/23.1
D37 1790001621 S.DIO 1SV308(TPL3,F) B 25.7/24
D38 1790001621 S.DIO 1SV308(TPL3,F) B 23/24.2
D40 1790001621 S.DIO 1SV308(TPL3,F) B 3.3/21
D41 1790001621 S.DIO 1SV308(TPL3,F) B 12.3/24
D42 1790001621 S.DIO 1SV308(TPL3,F) B 9.1/24
D44 1750001070 S.DIO DAN235ETL B 32.7/25
D45 1790001241 S.DIO MA2S7280GL B 32.3/6.1
D47 1750001070 S.DIO DAN235ETL B 38.3/8.3
D48 1750001070 S.DIO DAN235ETL B 42.3/8.8
D49 1750001070 S.DIO DAN235ETL B 44.4/27.5
D50 1790001241 S.DIO MA2S7280GL B 41.9/24.3
D51 1790001261 S.DIO MA2S077G0L B 21.1/31.2
D52 1790001261 S.DIO MA2S077G0L B 20.2/25.5
D53 1750001830 S.VAR SVC389-TL-E T 30.6/39.9
D54 1790001251 S.DIO MA2S1110GL B 13/16.7
D55 1790001241 S.DIO MA2S7280GL B 14.8/14
D56 1790001621 S.DIO 1SV308(TPL3,F) B 28.8/40.7
D57 1790001261 S.DIO MA2S077G0L B 21.7/42.1
D58 1790001261 S.DIO MA2S077G0L B 24.7/27.6
FI1 2040001190 S.SAW EFCH429MKQP1 B 22.4/20.1
FI2 2010002280 S.MON 19S15A 19.650 MHz (FL-293) B 37.3/25.4
FI3 2020002170 S.CER ELFY450E T 29.5/6.3
X1 6050012790 S.XTA CR-869 DSA321SC 19.2 MHz T 37.4/27.1
X3 6070000191 S.DIS CDBKB450KCAY24-R0 T 38.6/16.1
L1 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) B 7.1/37.6
L2 6200010630 S.COI LQW18AN8N2D00D B 12/35.7
L3 6200007001 S.COI ELJRE 82NGFA B 22.1/38.1
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
L4 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) B 4.4/37
L5 6200010130 S.COI LQW18AN6N8C00D B 8.4/34.9
L7 6200009220 S.COI LQW18AN15NG00D
(LQW1608A15NG00) B 2.6/36.1
L8 6200010120 S.COI LQW18AN5N6C00D B 9.1/33
L10 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) B 1.8/34.3
L11 6200005601 S.COI ELJRE 3N3ZFA B 18.1/35
L12 6200005631 S.COI ELJRE 5N6ZFA B 17.6/33.1
L13 6200010130 S.COI LQW18AN6N8C00D B 9.1/30.4
L15 6200010130 S.COI LQW18AN6N8C00D B 9.9/25.8
L16 6200009280 S.COI LQW18AN27NG00D
(LQW1608A27NG00) B 23.5/32.4
L18 6200005611 S.COI ELJRE 3N9ZFA B 12.3/29.3
L19 6200005591 S.COI ELJRE 2N7ZFA B 13.1/27.4
L20 6200009280 S.COI LQW18AN27NG00D
(LQW1608A27NG00) B 22.9/26.9
L21 6200002041 S.COI NLV25T-101J B 28.6/24.3
L22 6200005641 S.COI ELJRE 6N8ZFA B 12.8/20.8
L23 6200005701 S.COI ELJRE 22NGFA B 17.9/18.4
L24 6200005721 S.COI ELJRE 33NGFA B 27.8/19.1
L25 6200002971 S.COI NLV32T-121J T 33.5/13.9
L29 6200013520 S.COI NLFC322522T-151K-PF T 26.8/40.1
L31 6200005051 S.COI NLV25T-330J T 34.7/39.2
L33 6200004720 S.COI MLF1608D R10K-T B 26.3/37.8
L34 6200004600 S.COI MLF1608D R15K-T B 28.1/31.7
L36 6200005651 S.COI ELJRE 8N2ZFA B 2.4/28.5
L38 6200004600 S.COI MLF1608D R15K-T B 29.3/30.1
L40 6200008570 S.COI LQW2BHN6N8D03L B 3.7/24.8
L41 6200007170 S.COI MLF1608A 3R3K-T B 35.9/22.7
L43 6200007170 S.COI MLF1608A 3R3K-T B 41.5/22.5
L44 6200006380 S.COI ELJFC 150K B 33.1/19.6
L50 6200009220 S.COI LQW18AN15NG00D
(LQW1608A15NG00) B 8.9/36.8
L51 6200006960 S.COI MLF1608A 2R7K-T B 42/27
L52 6200011670 S.COI LQW18AN82NG00D B 20.9/32.4
L53 6200011670 S.COI LQW18AN82NG00D B 20.2/26.8
L54 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) B 10.1/36.6
L55 6200009250 S.COI LQW18ANR22G00D
(LQW1608AR22G00) B 12.9/36.9
L56 6200009250 S.COI LQW18ANR22G00D
(LQW1608AR22G00) B 15.2/40.6
L60 6200005641 S.COI ELJRE 6N8ZFA B 15.5/32.2
L61 6200011770 S.COI LQW18ANR10G00D B 18.4/43.9
L62 6200009070 S.COI LQW18AN18NG00D
(LQW1608A18NG00) B 21.3/40
L63 6200011770 S.COI LQW18ANR10G00D B 19.8/43.9
L64 6200011770 S.COI LQW18ANR10G00D B 25.9/27.6
R1 7030005120 S.RES ERJ2GEJ 102 X (1K) B 13.3/40.3
R2 7030005570 S.RES ERJ2GEJ 820 X (82) T 17/40.4
R3 7030007280 S.RES ERJ2GEJ 331 X (330) T 18.2/39.9
R4 7030005570 S.RES ERJ2GEJ 820 X (82) T 18.2/40.8
R5 7030009140 S.RES ERJ2GEJ 272 X (2.7K) T 20.6/40.4
R11 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 18.6/39.4
R13 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 16.4/35.4
R14 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 15.5/35.4
R15 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 19.7/41.8
R16 7030005050 S.RES ERJ2GEJ 103 X (10K) T 19.7/43.6
R22 7030005090 S.RES ERJ2GEJ 104 X (100K) B 18.8/30
R24 7030005090 S.RES ERJ2GEJ 104 X (100K) T 21.3/41.3
R25 7030005120 S.RES ERJ2GEJ 102 X (1K) T 26.3/37.2
R26 7030005290 S.RES ERJ2GEJ 682 X (6.8K) B 23.7/37.8
R27 7030007340 S.RES ERJ2GEJ 153 X (15K) B 26/35.8
R28 7030005290 S.RES ERJ2GEJ 682 X (6.8K) B 0.75/32.8
R29 7030007340 S.RES ERJ2GEJ 153 X (15K) B 4.2/28.3
R31 7030007280 S.RES ERJ2GEJ 331 X (330) B 20.7/37.1
R32 7030007280 S.RES ERJ2GEJ 331 X (330) B 3.9/34.1
R34 7030005240 S.RES ERJ2GEJ 473 X (47K) B 14.2/31.5
R35 7030008010 S.RES ERJ2GEJ 123 X (12K) B 14.2/32.4
R36 7030005240 S.RES ERJ2GEJ 473 X (47K) B 7.8/29.6
R37 7030008010 S.RES ERJ2GEJ 123 X (12K) B 7.8/28.7
R38 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 20.7/38.9
R41 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 2.7/29.9
R43 7030005120 S.RES ERJ2GEJ 102 X (1K) B 27.8/38.5
R44 7030005120 S.RES ERJ2GEJ 102 X (1K) T 28.4/36.8
R45 7030005710 S.RES ERJ2GEJ 121 X (120) B 16/29.6
R46 7030007280 S.RES ERJ2GEJ 331 X (330) B 7.8/26
R49 7030005090 S.RES ERJ2GEJ 104 X (100K) B 15.8/28.6
R52 7030005090 S.RES ERJ2GEJ 104 X (100K) B 18.5/27.9
R54 7030005120 S.RES ERJ2GEJ 102 X (1K) [EUR-01] B 22.3/33.5
7030005120 S.RES ERJ2GEJ 102 X (1K) [UK-01]
7030007300 S.RES ERJ2GEJ 332 X (3.3K) [USA-01]
7030005120 S.RES ERJ2GEJ 102 X (1K) [EXP-01]
7030005120 S.RES ERJ2GEJ 102 X (1K) [CHN-01]
7030005120 S.RES ERJ2GEJ 102 X (1K) [CAN-01]
R57 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 33/34.3
R60 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 30/35.6
R61 7030005090 S.RES ERJ2GEJ 104 X (100K) B 22.1/29.9
R62 7030005240 S.RES ERJ2GEJ 473 X (47K) B 0.75/25.9
R65 7030005050 S.RES ERJ2GEJ 103 X (10K) B 27/29.3
R66 7030005240 S.RES ERJ2GEJ 473 X (47K) B 27/28.1
R67 7030004980 S.RES ERJ2GEJ 101 X (100) B 30.2/27.3
R68 7030005090 S.RES ERJ2GEJ 104 X (100K) B 21.4/28.2
R69 7030005240 S.RES ERJ2GEJ 473 X (47K) B 0.75/24.3

Feb. 2010
2
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
R73 7030005580 S.RES ERJ2GEJ 560 X (56) B 22.5/25.3
R75 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 2.9/22.1
R76 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 13.3/26.1
R77 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 7.8/24.2
R78 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 10.5/22.9
R85 7030005710 S.RES ERJ2GEJ 121 X (120) B 15.3/21.4
R86 7030005570 S.RES ERJ2GEJ 820 X (82) B 11.5/19.4
R87 7030004980 S.RES ERJ2GEJ 101 X (100) B 11.5/18.5
R89 7030005570 S.RES ERJ2GEJ 820 X (82) B 12.7/18.7
R97 7030005300 S.RES ERJ2GEJ 150 X (15) B 15.3/16.4
R98 7030007270 S.RES ERJ2GEJ 151 X (150) B 16.5/16
R101 7030005700 S.RES ERJ2GEJ 274 X (270K) T 40.2/28
R108 7030007340 S.RES ERJ2GEJ 153 X (15K) B 27.5/5.6
R109 7030004980 S.RES ERJ2GEJ 101 X (100) B 27.4/11.4
R110 7030005290 S.RES ERJ2GEJ 682 X (6.8K) T 35.6/24.7
R113 7030005230 S.RES ERJ2GEJ 334 X (330K) B 25.7/8.9
R114 7030005220 S.RES ERJ2GEJ 223 X (22K) B 26.6/7.2
R118 7030005160 S.RES ERJ2GEJ 105 X (1M) B 23.9/8.9
R126 7030005240 S.RES ERJ2GEJ 473 X (47K) B 30.5/10.5
R128 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 29.4/8.8
R129 7030005090 S.RES ERJ2GEJ 104 X (100K) B 30.3/8.8
R138 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 29.5/7.2
R141 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 31.1/25.4
R142 7030005100 S.RES ERJ2GEJ 154 X (150K) B 33.3/6.3
R143 7030005100 S.RES ERJ2GEJ 154 X (150K) B 31.2/5.7
R148 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 32.9/23.5
R149 7030010040 S.RES ERJ2GEJ-JPW B 33.8/22.6
R150 7030003290 S.RES ERJ3GEYJ 560 V (56) [EUR-01] B 33.4/27.4
7030003290 S.RES ERJ3GEYJ 560 V (56) [UK-01]
7030003290 S.RES ERJ3GEYJ 560 V (56) [EXP-01]
7030003290 S.RES ERJ3GEYJ 560 V (56) [CHN-01]
7030003290 S.RES ERJ3GEYJ 560 V (56) [CAN-01]
R154 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 39.7/7.4
R157 7030005050 S.RES ERJ2GEJ 103 X (10K) B 39.7/6.5
R162 7030007340 S.RES ERJ2GEJ 153 X (15K) T 30.1/13.2
R167 7030010040 S.RES ERJ2GEJ-JPW B 43.2/25.9
R168 7030005050 S.RES ERJ2GEJ 103 X (10K) B 41.7/7.4
R169 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 44.2/9.3
R172 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 44.5/29.2
R173 7030005050 S.RES ERJ2GEJ 103 X (10K) B 32.3/27.8
R179 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 40.3/8.8
R181 7030004980 S.RES ERJ2GEJ 101 X (100) B 45.8/25.7
R184 7030005090 S.RES ERJ2GEJ 104 X (100K) B 34.5/13.9
R185 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 34.5/15.7
R187 7030005110 S.RES ERJ2GEJ 224 X (220K) B 44.5/24.5
R188 7030007340 S.RES ERJ2GEJ 153 X (15K) B 43.6/24.5
R189 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 39.2/11.5
R190 7030005240 S.RES ERJ2GEJ 473 X (47K) B 32.9/15.7
R194 7030005120 S.RES ERJ2GEJ 102 X (1K) B 44.2/20.4
R195 7030007340 S.RES ERJ2GEJ 153 X (15K) B 31.5/14.5
R196 7030005120 S.RES ERJ2GEJ 102 X (1K) B 32.2/13.3
R203 7030009160 S.RES ERJ2GEJ 181 X (180) B 41.3/19.8
R204 7030005000 S.RES ERJ2GEJ 471 X (470) B 34.5/16.6
R210 7030005240 S.RES ERJ2GEJ 473 X (47K) B 41.4/16.5
R213 7030008010 S.RES ERJ2GEJ 123 X (12K) T 40.9/23.9
R214 7030005010 S.RES ERJ2GEJ 681 X (680) T 36.8/20.4
R215 7030004990 S.RES ERJ2GEJ 221 X (220) B 36.6/20.5
R216 7030007310 S.RES ERJ2GEJ 155 X (1.5M) T 40.5/25.1
R218 7030005120 S.RES ERJ2GEJ 102 X (1K) T 35.6/23.1
R221 7030007280 S.RES ERJ2GEJ 331 X (330) B 28.2/26
R222 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 23/29.3
R223 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 20.4/24.5
R224 7030005090 S.RES ERJ2GEJ 104 X (100K) T 27.7/38.1
R225 7030005720 S.RES ERJ2GEJ 563 X (56K) B 27.5/2.6
R226 7030010040 S.RES ERJ2GEJ-JPW B 4/32.3
R227 7030010040 S.RES ERJ2GEJ-JPW B 36.7/6.9
R228 7030005060 S.RES ERJ2GEJ 333 X (33K) B 7.8/41.6
R229 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 14.9/15.1
R230 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 12/11.8
R232 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 38.4/38.9
R233 7030010040 S.RES ERJ2GEJ-JPW B 36/39.9
R234 7030005120 S.RES ERJ2GEJ 102 X (1K) B 27.1/40.3
R236 7030005070 S.RES ERJ2GEJ 683 X (68K) B 12.9/11.8
R237 7030010040 S.RES ERJ2GEJ-JPW B 41.4/14.8
R238 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 18/41.9
R239 7030007250 S.RES ERJ2GEJ 220 X (22) B 23.9/33.5
R240 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 23.2/40.7
R241 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 8.9/4.5
R242 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 25.9/25.9
R243 7030005090 S.RES ERJ2GEJ 104 X (100K) T 22.7/37.9
C2 4030016930 S.CER C1005 JB 1A 104K-T T 13.4/38
C3 4030016930 S.CER C1005 JB 1A 104K-T T 16.1/38
C4 4030016930 S.CER C1005 JB 1A 104K-T T 19.4/38.3
C6 4030016930 S.CER C1005 JB 1A 104K-T T 19.4/40.6
C7 4030017460 S.CER C1005 JB 1H 102K-T T 17.6/43.1
C8 4030017460 S.CER C1005 JB 1H 102K-T B 19.5/38.2
C9 4030017460 S.CER C1005 JB 1H 102K-T B 15.1/37.1
C10 4030017460 S.CER C1005 JB 1H 102K-T B 14.8/33.9
C11 4030017460 S.CER C1005 JB 1H 102K-T B 13.2/33.7
C12 4030017460 S.CER C1005 JB 1H 102K-T T 23.6/41.5
C15 4030017380 S.CER C1005 CH 1H 050B-T B 9.7/39.1
C16 4030017460 S.CER C1005 JB 1H 102K-T B 17.7/36
C17 4030016790 S.CER C1005 JB 1E 103K-T T 18.5/43.1
C18 4030017460 S.CER C1005 JB 1H 102K-T T 19.9/44.8
C19 4030017360 S.CER C1005 CH 1H 030B-T B 7.8/36.2
C22 4030017600 S.CER C1005 CH 1H 080C-T B 14.6/35.4
C23 4030017460 S.CER C1005 JB 1H 102K-T T 19.7/42.7
C24 4030017460 S.CER C1005 JB 1H 102K-T B 20.7/38
C25 4030017390 S.CER C1005 CH 1H 180J-T B 13.7/35.4
C29 4030017350 S.CER C1005 CH 1H 020B-T B 12.3/34.6
C30 4030016790 S.CER C1005 JB 1E 103K-T B 20.9/44.2
C31 4030017460 S.CER C1005 JB 1H 102K-T T 23.6/40.6
C34 4030017590 S.CER C1005 CH 1H 070C-T B 6.3/36.2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
C35 4030017420 S.CER C1005 CH 1H 470J-T B 10.6/34.6
C37 4030017340 S.CER C1005 CH 1H 010B-T B 5.1/38.3
C38 4030017360 S.CER C1005 CH 1H 030B-T B 11.4/33.7
C40 4030017380 S.CER C1005 CH 1H 050B-T B 3.9/35.9
C41 4030017340 S.CER C1005 CH 1H 010B-T B 7.7/33.8
C43 4030017340 S.CER C1005 CH 1H 010B-T B 10.2/33.3
C46 4030017600 S.CER C1005 CH 1H 080C-T B 3.9/35
C47 4030017350 S.CER C1005 CH 1H 020B-T B 7.7/32.9
C49 4030016930 S.CER C1005 JB 1A 104K-T T 25.1/37.7
C51 4030017730 S.CER C1005 JB 1H 471K-T B 8.1/31.7
C52 4030017420 S.CER C1005 CH 1H 470J-T T 21.5/45
C61 4030017460 S.CER C1005 JB 1H 102K-T B 16.6/33.4
C68 4030017460 S.CER C1005 JB 1H 102K-T B 20.7/36.2
C69 4030017460 S.CER C1005 JB 1H 102K-T B 3.9/33.2
C70 4030016930 S.CER C1005 JB 1A 104K-T T 30.5/35.2
C72 4030016930 S.CER C1005 JB 1A 104K-T B 29/38.1
C73 4030016930 S.CER C1005 JB 1A 104K-T T 27.5/36.8
C75 4030017730 S.CER C1005 JB 1H 471K-T B 16/30.5
C76 4030017730 S.CER C1005 JB 1H 471K-T B 7.8/26.9
C80 4030017460 S.CER C1005 JB 1H 102K-T B 20.7/35.3
C81 4030017460 S.CER C1005 JB 1H 102K-T B 4/30.4
C82 4030017660 S.CER C1005 CH 1H 330J-T B 27.8/37.6
C83 4030017420 S.CER C1005 CH 1H 470J-T B 30.7/32.6
C84 4030017390 S.CER C1005 CH 1H 180J-T B 20.7/34.4
C86 4030017600 S.CER C1005 CH 1H 080C-T B 3.6/31.4
C87 4030017600 S.CER C1005 CH 1H 080C-T B 27.3/36.4
C88 4030017610 S.CER C1005 CH 1H 090C-T B 29.1/32.2
C90 4030017660 S.CER C1005 CH 1H 330J-T B 28.5/35.9
C91 4030017680 S.CER C1005 CH 1H 820J-T B 30.7/30.8
C93 4030017460 S.CER C1005 JB 1H 102K-T B 14.2/28.6
C94 4030017730 S.CER C1005 JB 1H 471K-T B 7.8/27.8
C96 4030017560 S.CER C1005 CH 1H 2R5B-T B 10.4/24.7
C98 4030017460 S.CER C1005 JB 1H 102K-T B 20.7/33.5
C99 4030017460 S.CER C1005 JB 1H 102K-T B 4/29.5
C100 4030017730 S.CER C1005 JB 1H 471K-T B 17.6/30
C101 4030017460 S.CER C1005 JB 1H 102K-T B 7.8/25.1
C102 4030016790 S.CER C1005 JB 1E 103K-T B 32.5/33.1
C104 4030017360 S.CER C1005 CH 1H 030B-T B 28.2/29.6
C106 4030017440 S.CER C1005 CH 1H 221J-T B 23.3/30.5
C107 4030017460 S.CER C1005 JB 1H 102K-T B 0.75/27.8
C108 4030016930 S.CER C1005 JB 1A 104K-T B 34.6/34.3
C110 4030017420 S.CER C1005 CH 1H 470J-T B 30.7/29.3
C113 4030017460 S.CER C1005 JB 1H 102K-T B 20.2/28.8
C115 4030017460 S.CER C1005 JB 1H 102K-T B 12.3/26.1
C116 4030017460 S.CER C1005 JB 1H 102K-T B 5.9/26.8
C117 4030017460 S.CER C1005 JB 1H 102K-T B 15.2/26.5
C118 4030016930 S.CER C1005 JB 1A 104K-T B 29.1/33.8
C119 4030017350 S.CER C1005 CH 1H 020B-T B 23.9/29.3
C120 4030017350 S.CER C1005 CH 1H 020B-T B 1.6/25.9
C122 4030017440 S.CER C1005 CH 1H 221J-T B 20.2/27.9
C123 4030017460 S.CER C1005 JB 1H 102K-T B 1.6/24.3
C124 4030016930 S.CER C1005 JB 1A 104K-T B 30.2/28.2
C127 4030017460 S.CER C1005 JB 1H 102K-T B 34.6/39.6
C128 4030017460 S.CER C1005 JB 1H 102K-T B 34.6/37.8
C129 4030017460 S.CER C1005 JB 1H 102K-T B 18.1/26
C131 4030017460 S.CER C1005 JB 1H 102K-T B 4.5/22.1
C132 4030017460 S.CER C1005 JB 1H 102K-T B 6.5/33.9
C133 4030017660 S.CER C1005 CH 1H 330J-T B 23.7/25.5
C135 4030017590 S.CER C1005 CH 1H 070C-T B 1.6/22.7
C136 4030016930 S.CER C1005 JB 1A 104K-T B 29.8/26
C137 4030017460 S.CER C1005 JB 1H 102K-T B 34.6/38.7
C138 4030017460 S.CER C1005 JB 1H 102K-T B 34.6/36.9
C139 4030017460 S.CER C1005 JB 1H 102K-T T 17.9/12.9
C141 4030016930 S.CER C1005 JB 1A 104K-T B 8.1/22.9
C142 4030017460 S.CER C1005 JB 1H 102K-T T 20.9/18.7
C145 4030017460 S.CER C1005 JB 1H 102K-T B 7.4/16.8
C146 4030017460 S.CER C1005 JB 1H 102K-T B 2.7/19.2
C147 4030017460 S.CER C1005 JB 1H 102K-T B 4.9/19.7
C150 4030017460 S.CER C1005 JB 1H 102K-T B 34.6/35.5
C151 4030017460 S.CER C1005 JB 1H 102K-T B 3.9/19.7
C152 4030017460 S.CER C1005 JB 1H 102K-T B 6.4/19.7
C157 4030016930 S.CER C1005 JB 1A 104K-T B 11.2/21.3
C158 4030016930 S.CER C1005 JB 1A 104K-T B 10.3/18.9
C162 4030017460 S.CER C1005 JB 1H 102K-T T 28.1/15.9
C167 4030017420 S.CER C1005 CH 1H 470J-T T 12.7/19.4
C168 4030017420 S.CER C1005 CH 1H 470J-T T 12.7/20.3
C172 4030017420 S.CER C1005 CH 1H 470J-T T 13.2/24.4
C173 4030016930 S.CER C1005 JB 1A 104K-T B 14.4/21.4
C174 4030017370 S.CER C1005 CH 1H 3R5B-T B 14.9/17.6
C178 4030017420 S.CER C1005 CH 1H 470J-T T 14.1/24.4
C181 4030017460 S.CER C1005 JB 1H 102K-T T 40.2/27.1
C183 4030016790 S.CER C1005 JB 1E 103K-T B 36/38.3
C187 4030016790 S.CER C1005 JB 1E 103K-T T 40.2/26.2
C188 4030017460 S.CER C1005 JB 1H 102K-T B 16.5/17.6
C189 4030017460 S.CER C1005 JB 1H 102K-T B 30.5/12.4
C190 4030017360 S.CER C1005 CH 1H 030B-T B 17.4/20.1
C191 4030017040 S.CER C1005 JB 1A 333K-T B 27.5/7.2
C194 4030016790 S.CER C1005 JB 1E 103K-T B 25.7/7.2
C201 4030016790 S.CER C1005 JB 1E 103K-T B 25.6/10.6
C203 4030017460 S.CER C1005 JB 1H 102K-T B 27.8/22
C206 4030017460 S.CER C1005 JB 1H 102K-T B 29.2/20
C207 4550007600 S.TAN F920J106MPABMA B 32.7/10.6
C208 4030017460 S.CER C1005 JB 1H 102K-T B 24.8/8.9
C217 4030017700 S.CER C1005 CH 1H 151J-T B 30.4/7.2
C220 4030017460 S.CER C1005 JB 1H 102K-T B 30.5/19.2
C221 4030017460 S.CER C1005 JB 1H 102K-T B 34.5/17.5
C223 4030017460 S.CER C1005 JB 1H 102K-T B 31.1/23.8
C225 4030017460 S.CER C1005 JB 1H 102K-T B 28.4/7.2
C226 4030017640 S.CER C1005 CH 1H 150J-T B 34.5/7.2
C228 4030016930 S.CER C1005 JB 1A 104K-T B 26.6/2.6
C239 4030017460 S.CER C1005 JB 1H 102K-T B 40.9/6

Feb. 2010
3
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
C242 4030017730 S.CER C1005 JB 1H 471K-T [EUR-01] B 33.2/29.1
4030017730 S.CER C1005 JB 1H 471K-T [UK-01]
4030017420 S.CER C1005 CH 1H 470J-T [USA-01]
4030017730 S.CER C1005 JB 1H 471K-T [EXP-01]
4030017730 S.CER C1005 JB 1H 471K-T [CHN-01]
4030017730 S.CER C1005 JB 1H 471K-T [CAN-01]
C244 4030017400 S.CER C1005 CH 1H 220J-T B 38/22.7
C245 4030017430 S.CER C1005 CH 1H 101J-T T 31/13.2
C246 4030017430 S.CER C1005 CH 1H 101J-T T 29.2/13.2
C247 4030016790 S.CER C1005 JB 1E 103K-T B 38/6.6
C249 4030017430 S.CER C1005 CH 1H 101J-T T 33.9/11.7
C253 4030016790 S.CER C1005 JB 1E 103K-T B 41.8/6
C256 4030016930 S.CER C1005 JB 1A 104K-T B 45.8/9.3
C258 4030016930 S.CER C1005 JB 1A 104K-T B 45.7/29.7
C259 4030016930 S.CER C1005 JB 1A 104K-T B 31.6/26.6
C261 4030016930 S.CER C1005 JB 1A 104K-T B 40.8/10
C262 4030016930 S.CER C1005 JB 1A 104K-T B 38.5/10
C263 4030016930 S.CER C1005 JB 1A 104K-T B 37.1/11.1
C265 4030016930 S.CER C1005 JB 1A 104K-T B 42.3/18.1
C266 4030017730 S.CER C1005 JB 1H 471K-T B 34.5/14.8
C269 4030016790 S.CER C1005 JB 1E 103K-T B 45.4/24.5
C270 4030017730 S.CER C1005 JB 1H 471K-T B 33.3/14.5
C272 4030017460 S.CER C1005 JB 1H 102K-T B 44.2/21.3
C275 4030016790 S.CER C1005 JB 1E 103K-T B 32.4/14.5
C276 4030016790 S.CER C1005 JB 1E 103K-T B 39.4/10
C278 4030016790 S.CER C1005 JB 1E 103K-T B 32/16.6
C279 4030017460 S.CER C1005 JB 1H 102K-T B 42.4/21
C280 4030017460 S.CER C1005 JB 1H 102K-T B 33.3/17
C284 4030017460 S.CER C1005 JB 1H 102K-T B 40.4/22.1
C285 4030017460 S.CER C1005 JB 1H 102K-T B 40.4/20.5
C286 4030017040 S.CER C1005 JB 1A 333K-T B 38.4/20.5
C291 4030016790 S.CER C1005 JB 1E 103K-T T 38.8/22.8
C292 4030016930 S.CER C1005 JB 1A 104K-T T 42.7/18.5
C293 4030017730 S.CER C1005 JB 1H 471K-T B 39.3/20.5
C296 4030016790 S.CER C1005 JB 1E 103K-T T 40/23
C297 4030017680 S.CER C1005 CH 1H 820J-T B 37.5/20.5
C300 4030017730 S.CER C1005 JB 1H 471K-T B 34.8/20.5
C301 4030017680 S.CER C1005 CH 1H 820J-T B 35.7/20.5
C306 4550007600 S.TAN F920J106MPABMA T 43/23.3
C313 4030016790 S.CER C1005 JB 1E 103K-T T 36.5/23.8
C316 4030017460 S.CER C1005 JB 1H 102K-T T 43.6/19.6
C401 4030017460 S.CER C1005 JB 1H 102K-T T 11.9/4.5
C402 4030017460 S.CER C1005 JB 1H 102K-T T 10.7/4.5
C403 4030018860 S.CER C1005 JB 0J 105K-T B 26.6/5
C404 4030017040 S.CER C1005 JB 1A 333K-T B 27.1/3.8
C405 4030017620 S.CER C1005 CH 1H 100C-T B 27.3/20.8
C406 4030017460 S.CER C1005 JB 1H 102K-T T 18.4/13.8
C412 4030017600 S.CER C1005 CH 1H 080C-T B 7.8/39
C413 4030017430 S.CER C1005 CH 1H 101J-T B 8.8/39.1
C414 4030017400 S.CER C1005 CH 1H 220J-T B 41.2/25.6
C415 4030017780 S.CER C1005 JB 1H 472K-T B 36.7/3.2
C416 4030016930 S.CER C1005 JB 1A 104K-T B 32.2/1.1
C417 4030016930 S.CER C1005 JB 1A 104K-T B 23.3/31.4
C418 4030016930 S.CER C1005 JB 1A 104K-T B 18.8/24.5
C419 4030017610 S.CER C1005 CH 1H 090C-T B 12.4/37.9
C420 4030017500 S.CER C1005 CH 1H 560J-T B 11.2/37.5
C421 4030017430 S.CER C1005 CH 1H 101J-T B 41.4/18.1
C422 4550007680 S.TAN TEESVP 0J 226M8R B 14.3/11.8
C423 4550007680 S.TAN TEESVP 0J 226M8R B 8.9/18.1
C424 4030017460 S.CER C1005 JB 1H 102K-T B 16.5/15.1
C425 4030017460 S.CER C1005 JB 1H 102K-T T 12.7/18.4
C426 4030017460 S.CER C1005 JB 1H 102K-T B 10.4/11.3
C427 4030017460 S.CER C1005 JB 1H 102K-T B 38.4/38
C428 4030016930 S.CER C1005 JB 1A 104K-T B 25.9/40.7
C431 4030017460 S.CER C1005 JB 1H 102K-T T 25.5/36
C434 4030018890 S.CER C1005 JB 0J 224K-T B 29.3/3.7
C435 4030016790 S.CER C1005 JB 1E 103K-T T 42.1/24.7
C436 4030017560 S.CER C1005 CH 1H 2R5B-T B 7.8/40.2
C437 4030017460 S.CER C1005 JB 1H 102K-T B 10.9/29.6
C438 4030017460 S.CER C1005 JB 1H 102K-T B 7/14.8
C439 4030017460 S.CER C1005 JB 1H 102K-T B 7.2/12.1
C440 4030017460 S.CER C1005 JB 1H 102K-T B 8.3/14.8
C441 4030017460 S.CER C1005 JB 1H 102K-T T 8/14.7
C442 4030017460 S.CER C1005 JB 1H 102K-T B 8.8/12.2
C443 4030017460 S.CER C1005 JB 1H 102K-T B 10.1/12.5
C444 4030018860 S.CER C1005 JB 0J 105K-T B 24.4/10.7
C445 4030017420 S.CER C1005 CH 1H 470J-T T 13/2.4
C446 4030017510 S.CER C1005 CH 1H 680J-T B 17.6/40.4
C447 4030018140 S.CER C1005 JB 1H 391K-T B 17.5/41.7
C448 4030017510 S.CER C1005 CH 1H 680J-T B 19.2/40.4
C449 4030017580 S.CER C1005 CH 1H 060C-T B 18.4/41.8
C450 4030017350 S.CER C1005 CH 1H 020B-T B 19.6/41.3
C451 4030017580 S.CER C1005 CH 1H 060C-T B 19.6/42.2
C452 4030017380 S.CER C1005 CH 1H 050B-T B 21.3/41
C453 4030017460 S.CER C1005 JB 1H 102K-T B 25.9/25
C454 4030017590 S.CER C1005 CH 1H 070C-T B 24.6/25.5
C455 4030017460 S.CER C1005 JB 1H 102K-T B 23.4/39
C456 4030017650 S.CER C1005 CH 1H 270J-T
[USA-01] only B 34.4/28.3
J1 6510024971 S.CON AXK5F16537YG T 17.7/21.6
J2 6510024971 S.CON AXK5F16537YG T 28.9/20.4
J3 6510026700 S.CON AXK3S50335G T 11.9/8.9
J4 6450002250 CON HSJ1456-010320
J5 6450002131 CON 04-730A3-02BKA
EP6 6910013310 S.BEA MMZ1608D121B B 36/36.2
EP9 6910014690 S.BEA MPZ1608S221A-T B 32.9/3.6
EP10 6910014690 S.BEA MPZ1608S221A-T B 33.8/1.6
EP11 6910014680 S.BEA MMZ1608Y 121BT B 36/33.6
EP12 6910014680 S.BEA MMZ1608Y 121BT B 42/34.4
EP13 6910014680 S.BEA MMZ1608Y 121BT B 34.5/31.8
EP14 6910014680 S.BEA MMZ1608Y 121BT B 39.1/29.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[1STVCO UNIT]
IC2 1110005180 S.IC UPC2746TB-E3 T 16.5/14.2
IC3 1130011660 S.IC MB15T61ULPVA-G-ER B 10.4/11.8
Q1 1530003260 S.TRA 2SC5006-T1 T 11/3.6
Q2 1530003260 S.TRA 2SC5006-T1 T 8.3/8.1
Q3 1530003260 S.TRA 2SC5006-T1 T 8.3/12.6
Q4 1530003260 S.TRA 2SC5006-T1 T 8.3/17.1
Q6 1560000531 S.FET 2SK880-GR(TE85R,F) B 10.4/16.7
Q7 1530003001 S.TRA 2SC4117-BL(TE85R,F) B 5.3/16.5
Q8 1530003582 S.TRA 2SC5231A-8-TL-E B 18.3/14.6
Q10 1590001810 S.TRA XP1113(TX) B 8.8/2.9
Q11 1590001810 S.TRA XP1113(TX) B 7.1/6.6
Q12 1530003592 S.TRA 2SC5277A-2-TL-E B 11.5/6.6
D1 1750001650 S.VAR 1SV309(TPH3,F) T 5/2
D2 1750001650 S.VAR 1SV309(TPH3,F) T 3.9/3.8
D3 1750001051 S.VAR HVC417CTRU-E T 5/5.7
D4 1750001051 S.VAR HVC417CTRU-E T 5/10.2
D5 1750001051 S.VAR HVC417CTRU-E T 5/14.7
D7 1790001621 S.DIO 1SV308(TPL3,F) T 15.8/6.1
D8 1790001621 S.DIO 1SV308(TPL3,F) T 13.8/9
D9 1790001621 S.DIO 1SV308(TPL3,F) T 13.8/13.5
D10 1790001621 S.DIO 1SV308(TPL3,F) T 15.9/16.1
L1 6200011660 S.COI LQW18ANR15G00D T 3.8/2
L2 6200011660 S.COI LQW18ANR15G00D T 6.2/2
L3 6200010020 S.COI C2012C-12NG-A T 8.4/3.5
L4 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 13.2/4.5
L5 6200009250 S.COI LQW18ANR22G00D
(LQW1608AR22G00) T 3.8/5.9
L6 6200010030 S.COI C2012C-15NG-A T 5.7/8
L7 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 10.5/9.1
L8 6200009250 S.COI LQW18ANR22G00D
(LQW1608AR22G00) T 3.8/10.4
L9 6200010310 S.COI C2012C-27NG-A T 5.7/12.5
L10 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 10.5/13.7
L12 6200010540 S.COI C2012C-47NG-A T 5.7/17
L13 6200011770 S.COI LQW18ANR10G00D T 11.8/17.4
L15 6200011770 S.COI LQW18ANR10G00D T 14.5/2.6
L16 6200011770 S.COI LQW18ANR10G00D T 11.8/7.2
L17 6200011770 S.COI LQW18ANR10G00D T 11.8/11.8
L18 6200011650 S.COI LQW18AN68NG00D T 10/18.6
L19 6200011860 S.COI LQW18ANR47G00D T 3.8/14.9
L20 6200007961 S.COI ELJRF 6N8JFB (6.8) [EUR-01] T 14.1/16.9
6200007961 S.COI ELJRF 6N8JFB (6.8) [UK-01]
6200007961 S.COI ELJRF 6N8JFB (6.8) [USA-01]
6200007961 S.COI ELJRF 6N8JFB (6.8) [CAN-01]
L21 6200007941 S.COI ELJRF 10NJFB [EUR-01] T 16.5/17.2
6200007941 S.COI ELJRF 10NJFB [UK-01]
6200007941 S.COI ELJRF 10NJFB [USA-01]
6200007941 S.COI ELJRF 10NJFB [CAN-01]
R1 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.3/3.1
R2 7030004990 S.RES ERJ2GEJ 221 X (220) T 15.6/1.5
R3 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 12.4/1.5
R4 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 8.7/1.6
R5 7030007270 S.RES ERJ2GEJ 151 X (150) T 16.5/1.5
R6 7030004980 S.RES ERJ2GEJ 101 X (100) T 10.7/7.7
R7 7030004990 S.RES ERJ2GEJ 221 X (220) T 13/6.1
R8 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 9.8/6.1
R9 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 6/6.1
R10 7030004990 S.RES ERJ2GEJ 221 X (220) T 13.9/6.1
R11 7030004980 S.RES ERJ2GEJ 101 X (100) T 10.7/12.3
R12 7030004990 S.RES ERJ2GEJ 221 X (220) T 13/10.6
R13 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 9.8/10.7
R14 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 6/10.6
R15 7030004990 S.RES ERJ2GEJ 221 X (220) T 13.9/10.6
R16 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 6/15.1
R17 7030004990 S.RES ERJ2GEJ 221 X (220) T 11.8/15.3
R18 7030004990 S.RES ERJ2GEJ 221 X (220) T 10.7/17.2
R19 7030007270 S.RES ERJ2GEJ 151 X (150) T 13/15.3
R23 7030005120 S.RES ERJ2GEJ 102 X (1K) B 9.3/14.8
R24 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 8.4/16.6
R25 7030004990 S.RES ERJ2GEJ 221 X (220) B 13.2/15.4
R26 7030005290 S.RES ERJ2GEJ 682 X (6.8K) B 8.4/17.5
R27 7030005210 S.RES ERJ2GEJ 822 X (8.2K) B 7.2/16.7
R28 7030007340 S.RES ERJ2GEJ 153 X (15K) B 3.4/12.3
R29 7030005090 S.RES ERJ2GEJ 104 X (100K) B 15.2/12.6
R30 7030004990 S.RES ERJ2GEJ 221 X (220) B 17.3/13
R31 7030005080 S.RES ERJ2GEJ 823 X (82K) B 18/16
R32 7030007270 S.RES ERJ2GEJ 151 X (150) B 18.5/12.2
R33 7030007260 S.RES ERJ2GEJ 330 X (33) T 19.2/16.4
R34 7030007250 S.RES ERJ2GEJ 220 X (22) T 17.8/12.5
R35 7030009140 S.RES ERJ2GEJ 272 X (2.7K) B 3.1/13.5
R36 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 15.6/3.2
R37 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 13.8/7.7
R38 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 13.9/12.2
R39 7030005710 S.RES ERJ2GEJ 121 X (120) [EUR-01] T 12.9/16.5
7030005710 S.RES ERJ2GEJ 121 X (120) [UK-01]
7030005710 S.RES ERJ2GEJ 121 X (120) [USA-01]
7030005040 S.RES ERJ2GEJ 472 X (4.7K) [EXP-01]
7030005040 S.RES ERJ2GEJ 472 X (4.7K) [CHN-01]
7030005710 S.RES ERJ2GEJ 121 X (120) [CAN-01]
R40 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 17.1/7.2
R41 7030005300 S.RES ERJ2GEJ 150 X (15) T 19.5/15
R42 7030004970 S.RES ERJ2GEJ 470 X (47) T 19.2/13.7

Feb. 2010
4
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[1ST VCO UNIT]
R43 7030009530 S.RES ERJ2GEJ 270 X (27) [EUR-01] T 19.2/10.5
7030009530 S.RES ERJ2GEJ 270 X (27) [UK-01]
7030007260 S.RES ERJ2GEJ 330 X (33) [USA-01]
7030010040 S.RES ERJ2GEJ-JPW [EXP-01]
7030010040 S.RES ERJ2GEJ-JPW [CHN-01]
7030007260 S.RES ERJ2GEJ 330 X (33) [CAN-01]
R44 7030009530 S.RES ERJ2GEJ 270 X (27) [EUR-01] T 17.1/9.4
7030009530 S.RES ERJ2GEJ 270 X (27) [UK-01]
7030007260 S.RES ERJ2GEJ 330 X (33) [USA-01]
7030010040 S.RES ERJ2GEJ-JPW [EXP-01]
7030010040 S.RES ERJ2GEJ-JPW [CHN-01]
7030007260 S.RES ERJ2GEJ 330 X (33) [CAN-01]
R46 7030005120 S.RES ERJ2GEJ 102 X (1K) B 13.8/6.4
R47 7030005120 S.RES ERJ2GEJ 102 X (1K) B 8.9/7
R48 7030005120 S.RES ERJ2GEJ 102 X (1K) B 10/7.9
R49 7030008300 S.RES ERJ2GEJ 184 X (180K) B 12.9/6.4
R53 7030005570 S.RES ERJ2GEJ 820 X (82) B 12.3/15.4
R55 7030005120 S.RES ERJ2GEJ 102 X (1K) B 18.5/9.7
R56 7030005120 S.RES ERJ2GEJ 102 X (1K) B 16.9/10.1
R57 7030005120 S.RES ERJ2GEJ 102 X (1K) B 18.5/10.8
R59 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 9.8/15.6
R60 7030010040 S.RES ERJ2GEJ-JPW T 2.7/1.7
R61 7030010040 S.RES ERJ2GEJ-JPW T 2.7/5.4
R62 7030010040 S.RES ERJ2GEJ-JPW T 2.7/10.1
R63 7030010040 S.RES ERJ2GEJ-JPW T 2.7/14.6
R66 7030009530 S.RES ERJ2GEJ 270 X (27) [EUR-01] T 16.3/10.7
7030009530 S.RES ERJ2GEJ 270 X (27) [UK-01]
7030010090 S.RES ERJ2GEJ 180 X (18) [USA-01]
7030010090 S.RES ERJ2GEJ 180 X (18) [CAN-01]
C2 4030017460 S.CER C1005 JB 1H 102K-T T 5.9/3.8
C3 4030017370 S.CER C1005 CH 1H 3R5B-T T 12.4/3.1
C4 4030017360 S.CER C1005 CH 1H 030B-T T 11.5/1.6
C5 4030017460 S.CER C1005 JB 1H 102K-T T 10.5/1.6
C6 4030016930 S.CER C1005 JB 1A 104K-T T 9.6/1.6
C7 4030017340 S.CER C1005 CH 1H 010B-T T 15.3/4.5
C8 4030016930 S.CER C1005 JB 1A 104K-T T 13.3/1.5
C9 4030017460 S.CER C1005 JB 1H 102K-T T 2.7/7
C10 4030017460 S.CER C1005 JB 1H 102K-T T 3.7/8
C11 4030017380 S.CER C1005 CH 1H 050B-T T 8.8/6.1
C12 4030017460 S.CER C1005 JB 1H 102K-T T 6.9/6.1
C13 4030016930 S.CER C1005 JB 1A 104K-T T 7.8/6.1
C14 4030017530 S.CER C1005 CH 1H 0R5B-T T 12.9/7.7
C15 4030016930 S.CER C1005 JB 1A 104K-T T 10.7/6.1
C16 4030017380 S.CER C1005 CH 1H 050B-T T 9.8/7.7
C17 4030017460 S.CER C1005 JB 1H 102K-T T 2.7/12.5
C18 4030017460 S.CER C1005 JB 1H 102K-T T 3.7/12.5
C19 4030017610 S.CER C1005 CH 1H 090C-T T 9.8/12.3
C20 4030017610 S.CER C1005 CH 1H 090C-T T 8.8/10.6
C21 4030017460 S.CER C1005 JB 1H 102K-T T 7.8/10.6
C22 4030016930 S.CER C1005 JB 1A 104K-T T 6.9/10.6
C23 4030017530 S.CER C1005 CH 1H 0R5B-T T 13/12.2
C24 4030016930 S.CER C1005 JB 1A 104K-T T 10.7/10.7
C25 4030017460 S.CER C1005 JB 1H 102K-T T 2.8/17.4
C26 4030017460 S.CER C1005 JB 1H 102K-T T 7.8/15.1
C27 4030017390 S.CER C1005 CH 1H 180J-T T 9.8/17.2
C28 4030017390 S.CER C1005 CH 1H 180J-T T 8.8/15.1
C29 4030017460 S.CER C1005 JB 1H 102K-T T 3.7/17
C30 4030016930 S.CER C1005 JB 1A 104K-T T 10.7/15.6
C31 4030017460 S.CER C1005 JB 1H 102K-T B 12.4/5
C35 4030017770 S.CER C1005 JB 1H 332K-T B 8.4/15.7
C37 4550003220 S.TAN TEESVA 1E 105M8R B 14.2/17.2
C38 4550000930 S.TAN TEESVA 1D 684M8R B 4.9/12.8
C39 4550000930 S.TAN TEESVA 1D 684M8R B 7.1/12.8
C40 4030016790 S.CER C1005 JB 1E 103K-T B 3.1/10.5
C41 4030017460 S.CER C1005 JB 1H 102K-T B 13.6/10.8
C42 4030017460 S.CER C1005 JB 1H 102K-T B 16.1/13.5
C43 4030017620 S.CER C1005 CH 1H 100C-T [EUR-01] B 19.2/16.3
4030017620 S.CER C1005 CH 1H 100C-T [UK-01]
4030017620 S.CER C1005 CH 1H 100C-T [USA-01]
4030017350 S.CER C1005 CH 1H 020B-T [EXP-01]
4030017350 S.CER C1005 CH 1H 020B-T [CHN-01]
4030017620 S.CER C1005 CH 1H 100C-T [CAN-01]
C44 4030017460 S.CER C1005 JB 1H 102K-T B 18.5/13.1
C45 4030017340 S.CER C1005 CH 1H 010B-T T 12.9/18.1
C46 4030017460 S.CER C1005 JB 1H 102K-T T 18.3/13.7
C47 4030017460 S.CER C1005 JB 1H 102K-T T 18.3/15.3
C48 4340000290 S.MYL ECHU 1C 103JX5 B 3.1/15.7
C49 4030017380 S.CER C1005 CH 1H 050B-T [EUR-01] T 15.1/12.5
4030017380 S.CER C1005 CH 1H 050B-T [UK-01]
4030017380 S.CER C1005 CH 1H 050B-T [USA-01]
4030017620 S.CER C1005 CH 1H 100C-T [EXP-01]
4030017620 S.CER C1005 CH 1H 100C-T [CHN-01]
4030017380 S.CER C1005 CH 1H 050B-T [CAN-01]
C50 4030017460 S.CER C1005 JB 1H 102K-T T 19.2/12.1
C52 4030017460 S.CER C1005 JB 1H 102K-T T 18.3/8.9
C54 4030017460 S.CER C1005 JB 1H 102K-T T 16.5/3.7
C55 4030017460 S.CER C1005 JB 1H 102K-T T 14.8/6.1
C56 4030017460 S.CER C1005 JB 1H 102K-T T 14.8/10.6
C57 4030017460 S.CER C1005 JB 1H 102K-T T 14.2/14.9
C58 4030016930 S.CER C1005 JB 1A 104K-T B 13.2/13.8
C59 4030016790 S.CER C1005 JB 1E 103K-T B 10/6.3
C60 4030016790 S.CER C1005 JB 1E 103K-T B 8.8/8.7
C61 4030016930 S.CER C1005 JB 1A 104K-T B 11.3/15
C62 4030016930 S.CER C1005 JB 1A 104K-T B 13.6/9.9
C63 4030017460 S.CER C1005 JB 1H 102K-T B 13.6/11.7
C64 4550007600 S.TAN F920J106MPABMA B 15.2/15
C65 4550007600 S.TAN F920J106MPABMA B 5.2/2.5
C66 4550007600 S.TAN F920J106MPABMA B 4.4/4.2
C67 4550007600 S.TAN F920J106MPABMA B 4/6
C68 4030017460 S.CER C1005 JB 1H 102K-T B 13.6/12.6
C69 4030016930 S.CER C1005 JB 1A 104K-T T 6.9/15.1
C70 4550007600 S.TAN F920J106MPABMA B 4.8/8.4
C71 4030017460 S.CER C1005 JB 1H 102K-T B 13.8/2.3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[1STVCO UNIT]
C72 4030017350 S.CER C1005 CH 1H 020B-T T 20.4/11
C73 4030017350 S.CER C1005 CH 1H 020B-T T 18.3/6.8
C74 4030017380 S.CER C1005 CH 1H 050B-T [EUR-01] T 14.1/18.7
4030017380 S.CER C1005 CH 1H 050B-T [UK-01]
4030017380 S.CER C1005 CH 1H 050B-T [USA-01]
4030017380 S.CER C1005 CH 1H 050B-T [CAN-01]
C75 4030017370 S.CER C1005 CH 1H 3R5B-T [EUR-01] T 14.1/17.8
4030017370 S.CER C1005 CH 1H 3R5B-T [UK-01]
4030017370 S.CER C1005 CH 1H 3R5B-T [USA-01]
4030017370 S.CER C1005 CH 1H 3R5B-T [CAN-01]
C76 4030017600 S.CER C1005 CH 1H 080C-T [EUR-01] T 15.3/17.4
4030017600 S.CER C1005 CH 1H 080C-T [UK-01]
4030017600 S.CER C1005 CH 1H 080C-T [USA-01]
4030017600 S.CER C1005 CH 1H 080C-T [CAN-01]
C77 4030017550 S.CER C1005 CH 1H 1R5B-T [EUR-01] T 16.5/18.1
4030017550 S.CER C1005 CH 1H 1R5B-T [UK-01]
4030017550 S.CER C1005 CH 1H 1R5B-T [USA-01]
4030017550 S.CER C1005 CH 1H 1R5B-T [CAN-01]
C78 4030017580 S.CER C1005 CH 1H 060C-T [EUR-01] T 17.7/18.3
4030017580 S.CER C1005 CH 1H 060C-T [UK-01]
4030017580 S.CER C1005 CH 1H 060C-T [USA-01]
4030017580 S.CER C1005 CH 1H 060C-T [CAN-01]
J1 6510024981 S.CON AXK6F16337YG B 17.4/5.4

Feb. 2010
5
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[2NDVCO UNIT]
IC1 1130011671 S.IC MB15E03SLPFV1-G-ER-6E1 B 5.6/10.8
Q1 1530003612 S.TRA FH102A-TR-E T 5.3/9
Q3 1530003592 S.TRA 2SC5277A-2-TL-E T 9.7/14.7
Q4 1530003630 S.TRA 2SC4617 TLS T 9/6.6
D1 1750000741 S.VAR 1SV314(TPH3,F) T 1.9/11.5
L1 6200009070 S.COI LQW18AN18NG00D
(LQW1608A18NG00) T 4/12.5
L2 6200005721 S.COI ELJRE 33NGFA T 7.3/7
L3 6200005701 S.COI ELJRE 22NGFA T 4.6/5.4
L4 6200009351 S.COI ELJRE R22GFA T 5.2/14.1
R1 7030004970 S.RES ERJ2GEJ 470 X (47) T 6.2/14.7
R2 7030005050 S.RES ERJ2GEJ 103 X (10K) T 5.7/10.8
R3 7030005120 S.RES ERJ2GEJ 102 X (1K) T 3/9
R4 7030005120 S.RES ERJ2GEJ 102 X (1K) T 4.8/7.2
R9 7030005580 S.RES ERJ2GEJ 560 X (56) B 6.8/6.6
R10 7030004980 S.RES ERJ2GEJ 101 X (100) B 6.8/7.5
R11 7030005120 S.RES ERJ2GEJ 102 X (1K) B 4.8/7.1
R12 7030005120 S.RES ERJ2GEJ 102 X (1K) B 3/7.1
R13 7030005120 S.RES ERJ2GEJ 102 X (1K) B 3.9/7.1
R14 7030005530 S.RES ERJ2GEJ 100 X (10) B 6.5/14.7
R15 7030009270 S.RES ERJ2GEJ 821 X (820) B 5.3/14.2
R16 7030005120 S.RES ERJ2GEJ 102 X (1K) T 10.4/11.8
R17 7030008300 S.RES ERJ2GEJ 184 X (180K) T 7.9/13
R18 7030005120 S.RES ERJ2GEJ 102 X (1K) T 7.5/15.1
R19 7030005120 S.RES ERJ2GEJ 102 X (1K) T 7.9/12.1
R21 7030005120 S.RES ERJ2GEJ 102 X (1K) T 8.8/8
R22 7030007280 S.RES ERJ2GEJ 331 X (330) B 5.3/15.1
C1 4550006910 S.TAN TEESVP 1C 334M8R T 2.9/14.9
C2 4030017390 S.CER C1005 CH 1H 180J-T T 2.4/12.5
C3 4030017640 S.CER C1005 CH 1H 150J-T T 5.3/12
C4 4030017620 S.CER C1005 CH 1H 100C-T T 3.9/10.8
C5 4030017640 S.CER C1005 CH 1H 150J-T T 3/9.9
C6 4030017460 S.CER C1005 JB 1H 102K-T T 3/8.1
C7 4030017570 S.CER C1005 CH 1H 040B-T T 6.2/7
C8 4030017340 S.CER C1005 CH 1H 010B-T T 5.7/5.4
C9 4030017380 S.CER C1005 CH 1H 050B-T T 3.3/6.2
C10 4030017380 S.CER C1005 CH 1H 050B-T T 3.3/4.7
C16 4030017730 S.CER C1005 JB 1H 471K-T T 4.2/3
C17 4030017380 S.CER C1005 CH 1H 050B-T B 8/7.1
C18 4030017420 S.CER C1005 CH 1H 470J-T B 1.2/9.5
C19 4030017420 S.CER C1005 CH 1H 470J-T B 2.1/7.1
C20 4030017420 S.CER C1005 CH 1H 470J-T B 1.2/7.1
C21 4550007630 S.TAN F920J475MPABMA B 2.6/14.7
C22 4030016790 S.CER C1005 JB 1E 103K-T T 10/13
C23 4030016790 S.CER C1005 JB 1E 103K-T T 7.9/13.9
C24 4030016790 S.CER C1005 JB 1E 103K-T B 8.4/14.3
C25 4030017460 S.CER C1005 JB 1H 102K-T B 9.9/9.5
C26 4030016930 S.CER C1005 JB 1A 104K-T B 9.9/13
C27 4030017460 S.CER C1005 JB 1H 102K-T B 1.2/11.4
C30 4030017460 S.CER C1005 JB 1H 102K-T T 6.9/5.3
C31 4030017460 S.CER C1005 JB 1H 102K-T B 8.9/6.1
C32 4550007600 S.TAN F920J106MPABMA T 8.3/10.1
C33 4030017350 S.CER C1005 CH 1H 020B-T T 2.4/13.5
J1 6510024981 S.CON AXK6F16337YG B 5.6/3.8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[LOGIC UNIT]
IC1 1130007031 S.IC TC7W08FU(TE12L,F) B 12.1/78.1
IC3 1180003380 S.REG NJU7775F32-TE1-#ZZZB B 42.6/39
IC4 1180003380 S.REG NJU7775F32-TE1-#ZZZB B 32.7/41.8
IC6 1110005731 S.IC S-80928CNMC-G8Y-G B 45.7/58.4
IC8 1130007111 S.IC TC7W04FU(TE12L,F) B 7.6/55.1
IC9 1110002810 S.IC NJM2070M-TE1-#ZZZB B 5.1/86.8
IC10 1130011860 S.IC SM6451BT-G-E2 B 4/77
IC11 1130007111 S.IC TC7W04FU(TE12L,F) B 5.6/33.1
IC12 1110006380 S.IC LM2904PWR B 21.7/42.6
IC14 1140012950 S.IC 24LC512T-I/SM <SEI> B 40.6/92.7
IC15 1140012950 S.IC 24LC512T-I/SM <SEI> B 42.7/86.9
IC16 1190001830 S.IC BH2220FVM-TR B 12.1/74.7
IC17 1140013020 S.IC HD64F2238RTF13V (EMPTY) B 31.2/66.6
IC18 1190002830 S.IC BQ24064DRCR B 42.8/51.7
IC19 1110006490 S.IC LMV321IDCKR B 1.9/49.7
IC20 1130011770 S.IC CD4066BPWR B 7.7/47.2
Q2 1510000671 S.TRA 2SA1588-GR(TE85R, F) B 37.7/37
Q5 1530003630 S.TRA 2SC4617 TLS T 9.3/99.8
Q8 1510001100 S.TRA 2SA1832-GR(TE85R,F) B 4/56.6
Q10 1530003990 S.TRA 2SC4738-BL(TE85L,F) B 2.3/54.8
Q11 1520000651 S.TRA 2SB1201S-TL-E B 27.4/94.4
Q12 1590001170 S.TRA XP1501-(TX).AB B 32.3/91.8
Q16 1590003251 S.TRA UNR9115G0L B 25/45.7
Q18 1530003990 S.TRA 2SC4738-BL(TE85L,F) B 11.3/51.8
Q20 1590001190 S.TRA XP6501-(TX).AB B 20/51.5
Q21 1590001650 S.TRA XP4601(TX) B 20.5/15.7
Q23 1590001391 S.FET 2SJ144-Y(TE85R,F) B 16.5/50.6
Q24 1530003990 S.TRA 2SC4738-BL(TE85L,F) B 3.4/19.4
Q25 1590003291 S.TRA UNR9213G0L B 39.7/56.7
Q26 1590003291 S.TRA UNR9213G0L B 41.9/58.2
Q27 1590002950 S.FET HAT1023R-EL B 36.5/46.6
Q28 1590001810 S.TRA XP1113(TX) B 15.9/56.6
Q29 1530003091 S.TRA 2SC4213-B(TE85R,F) B 12.2/90.2
Q30 1590003251 S.TRA UNR9115G0L B 27.3/90.7
D2 1790000671 S.DIO SB07-03C-TB-E B 34.6/51.1
D5 1790001251 S.DIO MA2S1110GL B 23.5/21.8
D7 1790001251 S.DIO MA2S1110GL [USA-01] B 32.8/22.2
1790001251 S.DIO MA2S1110GL [EXP-01]
1790001251 S.DIO MA2S1110GL [CHN-01]
1790001251 S.DIO MA2S1110GL [CAN-01]
D8 1790001251 S.DIO MA2S1110GL B 24.7/21.2
D10 1790001251 S.DIO MA2S1110GL [UK-01] B 36.4/22.2
1790001251 S.DIO MA2S1110GL [EXP-01]
1790001251 S.DIO MA2S1110GL [CHN-01]
D11 1790001251 S.DIO MA2S1110GL B 25.9/21.2
D13 1790001251 S.DIO MA2S1110GL [EUR-01] B 37.6/22.2
1790001251 S.DIO MA2S1110GL [USA-01]
1790001251 S.DIO MA2S1110GL [EXP-01]
1790001251 S.DIO MA2S1110GL [CHN-01]
1790001251 S.DIO MA2S1110GL [CAN-01]
D14 1790001251 S.DIO MA2S1110GL B 41.8/20.3
D15 1750000771 S.VAR HVC376BTRF-E B 46.7/77.6
D16 1750000940 S.DIO 1SS400 TE61 B .9/57.2
D19 1750001830 S.VAR SVC389-TL-E B 26.5/17
D22 1790001251 S.DIO MA2S1110GL B 16.1/54.7
D24 1790001561 S.DIO 1SS372(TE85R,F) B 5.4/29
D25 1790001561 S.DIO 1SS372(TE85R,F) B 5.4/26.4
D26 1790001561 S.DIO 1SS372(TE85R,F) B 5.4/23.8
D27 1790001561 S.DIO 1SS372(TE85R,F) B 5.4/21.2
D28 1790001251 S.DIO MA2S1110GL B 31.8/50.2
D29 1790001251 S.DIO MA2S1110GL B 37.8/35.1
D31 1790001251 S.DIO MA2S1110GL B 30/47.6
D32 1790001251 S.DIO MA2S1110GL B 34.8/34.3
D33 1790001251 S.DIO MA2S1110GL B 41.2/55.2
D34 1790001141 S.ZEN MAZ8039GLL B 39/54.7
D35 1790001241 S.DIO MA2S7280GL B 36.8/51.2
D37 1790001251 S.DIO MA2S1110GL B 22.5/15.8
D38 1790001810 S.VAR AVR-M1005C080MTABB B 39.4/49.8
D39 1790001810 S.VAR AVR-M1005C080MTABB B 38.2/52.6
D40 1750001670 S.DIO RR264M-400TR B 31.3/54.2
X1 6050011830 S.XTA CR-774 SMD-49TB 12.288 MHz
<KDS> B 42.5/77.3
L1 6200003640 S.COI MLF1608E 100K-T B 7.9/31.6
R2 7410001110 S.ARR EXB28V332JX B 42.9/67.2
R3 7410001220 S.ARR EXB28V103JX B 31.1/78
R5 7030005050 S.RES ERJ2GEJ 103 X (10K) B 44.9/60.5
R6 7410001220 S.ARR EXB28V103JX B 24.6/76.5
R7 7410001130 S.ARR EXB28V102JX B 36.1/56
R9 7030005240 S.RES ERJ2GEJ 473 X (47K) B 42.6/27.7
R10 7030005240 S.RES ERJ2GEJ 473 X (47K) B 36.7/88.4
R11 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 35.8/88.4
R16 7030005090 S.RES ERJ2GEJ 104 X (100K) B 5.7/58.2
R19 7030005570 S.RES ERJ2GEJ 820 X (82) T 9.4/98
R20 7030005570 S.RES ERJ2GEJ 820 X (82) T 7.6/98
R21 7030005090 S.RES ERJ2GEJ 104 X (100K) B 5.7/57.3
R22 7030005570 S.RES ERJ2GEJ 820 X (82) T 8.5/98
R23 7410001130 S.ARR EXB28V102JX B 16.2/68.4
R24 7030010040 S.RES ERJ2GEJ-JPW B 43.3/65.2
R29 7030005050 S.RES ERJ2GEJ 103 X (10K) B 39.2/72
R31 7410001220 S.ARR EXB28V103JX B 40.4/70.2
R32 7030005530 S.RES ERJ2GEJ 100 X (10) B 38.2/79.3
R33 7030005160 S.RES ERJ2GEJ 105 X (1M) B 38.6/77.2
R37 7030005240 S.RES ERJ2GEJ 473 X (47K) B 14.4/23.4
R39 7030005240 S.RES ERJ2GEJ 473 X (47K) B 4.1/55.1
R40 7410001130 S.ARR EXB28V102JX B 27.8/56.9

Feb. 2010
6
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[LOGIC UNIT]
R41 7030005090 S.RES ERJ2GEJ 104 X (100K) B 16/23.4
R44 7030005050 S.RES ERJ2GEJ 103 X (10K) B 3.9/58.2
R45 7030008290 S.RES ERJ2GEJ 183 X (18K) B 2.2/57.3
R46 7030008010 S.RES ERJ2GEJ 123 X (12K) B 4.1/54.2
R48 7410001130 S.ARR EXB28V102JX B 21.2/60
R50 7410001130 S.ARR EXB28V102JX B 26.1/58.7
R51 7030005090 S.RES ERJ2GEJ 104 X (100K) B 46.3/80.1
R53 7410001130 S.ARR EXB28V102JX B 23.2/58.4
R57 7030010040 S.RES ERJ2GEJ-JPW B 2.2/56.4
R61 7030007320 S.RES ERJ2GEJ 225 X (2.2M) B 46.3/75.9
R66 7030005090 S.RES ERJ2GEJ 104 X (100K) B 14.8/80
R67 7410001130 S.ARR EXB28V102JX B 19.3/69.7
R70 7030005050 S.RES ERJ2GEJ 103 X (10K) B 37.9/57.3
R71 7030005050 S.RES ERJ2GEJ 103 X (10K) B 37.9/58.2
R79 7410001130 S.ARR EXB28V102JX B 33.6/56
R81 7030005160 S.RES ERJ2GEJ 105 X (1M) B 30.8/88.9
R83 7030005000 S.RES ERJ2GEJ 471 X (470) B 8.6/77.9
R84 7030005000 S.RES ERJ2GEJ 471 X (470) B 15.1/77.3
R85 7030005070 S.RES ERJ2GEJ 683 X (68K) B 32.2/90.1
R86 7030000010 S.RES MCR10EZHJ JPW (000) B 17.9/90
R89 7030005120 S.RES ERJ2GEJ 102 X (1K) B 34.5/92
R90 7030005090 S.RES ERJ2GEJ 104 X (100K) B 34.5/93.8
R91 7030005090 S.RES ERJ2GEJ 104 X (100K) B 26/78.8
R97 7030008290 S.RES ERJ2GEJ 183 X (18K) B 31.8/93.6
R102 7030005050 S.RES ERJ2GEJ 103 X (10K) B 7.3/78.5
R105 7030005050 S.RES ERJ2GEJ 103 X (10K) B 5/81.3
R107 7030005170 S.RES ERJ2GEJ 474 X (470K) B 39.5/38.3
R108 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 38.1/38.8
R111 7030005530 S.RES ERJ2GEJ 100 X (10) B 4.8/91.1
R112 7030005000 S.RES ERJ2GEJ 471 X (470) T 40.7/12.8
R113 7030005110 S.RES ERJ2GEJ 224 X (220K) B 24.3/17.9
R114 7030005120 S.RES ERJ2GEJ 102 X (1K) B 2.9/82.2
R115 7030007340 S.RES ERJ2GEJ 153 X (15K) B 6.6/82.2
R116 7030005090 S.RES ERJ2GEJ 104 X (100K) B 23.8/15
R117 7030010040 S.RES ERJ2GEJ-JPW B 40.2/40.2
R118 7030005310 S.RES ERJ2GEJ 124 X (120K) B 24.8/43
R121 7030008010 S.RES ERJ2GEJ 123 X (12K) B 24.4/41.8
R124 7030005090 S.RES ERJ2GEJ 104 X (100K) B 34.3/38.8
R128 7030005530 S.RES ERJ2GEJ 100 X (10) B 11.1/53.7
R129 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 9.9/53.1
R130 7030005570 S.RES ERJ2GEJ 820 X (82) B 12.8/51.8
R132 7030005100 S.RES ERJ2GEJ 154 X (150K) B 11.1/50.4
R133 7030005170 S.RES ERJ2GEJ 474 X (470K) B 21/38.3
R135 7030008300 S.RES ERJ2GEJ 184 X (180K) B 14/54.2
R136 7030008300 S.RES ERJ2GEJ 184 X (180K) B 23.8/38.7
R137 7030009150 S.RES ERJ2GEJ 824 X (820K) B 22.6/38.3
R140 7030005080 S.RES ERJ2GEJ 823 X (82K) B 15.7/53.7
R141 7030005090 S.RES ERJ2GEJ 104 X (100K) B 15.3/52.5
R142 7030005080 S.RES ERJ2GEJ 823 X (82K) B 17.9/40.1
R144 7030007340 S.RES ERJ2GEJ 153 X (15K) B 17.8/54.9
R145 7030005080 S.RES ERJ2GEJ 823 X (82K) B 21.9/17.4
R146 7030005220 S.RES ERJ2GEJ 223 X (22K) B 21.9/18.3
R147 7030005170 S.RES ERJ2GEJ 474 X (470K) B 17.9/41
R149 7030005090 S.RES ERJ2GEJ 104 X (100K) B 19.5/53.4
R150 7030005100 S.RES ERJ2GEJ 154 X (150K) B 17.9/42.8
R151 7030007350 S.RES ERJ2GEJ 393 X (39K) B 17.9/43.7
R155 7030008300 S.RES ERJ2GEJ 184 X (180K) B 18.7/49.7
R156 7030008300 S.RES ERJ2GEJ 184 X (180K) B 18.2/50.9
R157 7030007320 S.RES ERJ2GEJ 225 X (2.2M) B 16.5/52.5
R160 7030007320 S.RES ERJ2GEJ 225 X (2.2M) B 21.8/51.1
R161 7030005170 S.RES ERJ2GEJ 474 X (470K) B 21.2/53.4
R162 7030005080 S.RES ERJ2GEJ 823 X (82K) B 19.1/45.2
R163 7030005050 S.RES ERJ2GEJ 103 X (10K) B 24.5/47.6
R165 7030005160 S.RES ERJ2GEJ 105 X (1M) B 18.2/47.6
R166 7030007350 S.RES ERJ2GEJ 393 X (39K) B 18.2/45.2
R167 7030010040 S.RES ERJ2GEJ-JPW B 23.6/47.6
R170 7030007320 S.RES ERJ2GEJ 225 X (2.2M) B 22.7/49.2
R171 7030009290 S.RES ERJ2GEJ 562 X (5.6K) B 19.1/47.6
R172 7030005050 S.RES ERJ2GEJ 103 X (10K) B 4.9/19.2
R177 7030006610 S.RES ERJ2GEJ 394 X (390K) B 21.8/49.2
R178 7030007350 S.RES ERJ2GEJ 393 X (39K) B 20.5/48.8
R179 7030005240 S.RES ERJ2GEJ 473 X (47K) B 40.2/58.3
R182 7030005090 S.RES ERJ2GEJ 104 X (100K) B 38.2/49.9
R184 7030009190 S.RES RR0510P-332-D (3.3K) B 44.8/48.5
R185 7030005770 S.RES RR0510P-101-D (100) B 42/47.9
R188 7030009190 S.RES RR0510P-332-D (3.3K) B 43.2/47.5
R189 7510001661 S.THR NTCG16 4LH 473JT B 34.9/36.2
R190 7030008270 S.RES RR0510P-104-D (100K) B 33.9/37.6
R191 7030008051 S.RES ERA3YKD 184V (180K) B 30/50.2
R192 7030008270 S.RES RR0510P-104-D (100K) B 31.3/48.5
R193 7030008270 S.RES RR0510P-104-D (100K) B 32.5/35.1
R194 7030008051 S.RES ERA3YKD 184V (180K) B 36/34.4
R195 7030011880 S.RES RR0510P-183-D (18K) B 42.3/56.3
R196 7030011000 S.RES RR0510P-392-D (3.9K) B 43.5/56.1
R201 7030005080 S.RES ERJ2GEJ 823 X (82K) B 43/54.2
R202 7030008270 S.RES RR0510P-104-D (100K) B 46/55.1
R203 7030005240 S.RES ERJ2GEJ 473 X (47K) B 43.5/57.8
R208 7410001130 S.ARR EXB28V102JX B 38.6/60.9
R209 7030007280 S.RES ERJ2GEJ 331 X (330) B 37.9/59.1
R210 7030005050 S.RES ERJ2GEJ 103 X (10K) B 22.6/71.7
R211 7030005050 S.RES ERJ2GEJ 103 X (10K) B 40.8/62.4
R212 7030005120 S.RES ERJ2GEJ 102 X (1K) B 41.8/63.3
R213 7030005120 S.RES ERJ2GEJ 102 X (1K) B 21.2/73.9
R214 7030005120 S.RES ERJ2GEJ 102 X (1K) B 22.1/73.9
R216 7510001581 S.THE NTCG16 4BH 153JT B 46.5/23.2
R217 7030005050 S.RES ERJ2GEJ 103 X (10K) B 20.3/73.9
R218 7030005050 S.RES ERJ2GEJ 103 X (10K) B 3.8/50.2
R219 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 4.2/51.5
R220 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 8.6/51.9
R221 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 4.2/49
R222 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 4.2/48.1
R223 7030009290 S.RES ERJ2GEJ 562 X (5.6K) B 5.8/51.5
R224 7030009290 S.RES ERJ2GEJ 562 X (5.6K) B 7.4/51.5
R225 7030005600 S.RES ERJ2GEJ 273 X (27K) B 7.4/43
R226 7030005600 S.RES ERJ2GEJ 273 X (27K) B 9/43
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[LOGIC UNIT]
R227 7030005050 S.RES ERJ2GEJ 103 X (10K) B 4.2/52.4
R228 7030005050 S.RES ERJ2GEJ 103 X (10K) B 22.6/70.6
R229 7030010040 S.RES ERJ2GEJ-JPW B 34.7/77.4
R231 7030005050 S.RES ERJ2GEJ 103 X (10K) B 43/31.2
R232 7030005050 S.RES ERJ2GEJ 103 X (10K) B 42.6/26.2
R233 7030005050 S.RES ERJ2GEJ 103 X (10K) B 42.6/24.7
R234 7030005050 S.RES ERJ2GEJ 103 X (10K) B 42.6/23.2
R235 7030005050 S.RES ERJ2GEJ 103 X (10K) B 42.6/29.2
R236 7030005240 S.RES ERJ2GEJ 473 X (47K) B 36.8/95.4
R237 7030005240 S.RES ERJ2GEJ 473 X (47K) B 35/95.4
R239 7030005240 S.RES ERJ2GEJ 473 X (47K) B 23.8/73.9
R240 7030005110 S.RES ERJ2GEJ 224 X (220K) B 24.7/74.5
R241 7030005240 S.RES ERJ2GEJ 473 X (47K) T 10.6/98.5
R242 7030005090 S.RES ERJ2GEJ 104 X (100K) B 37.6/81.6
R243 7030005240 S.RES ERJ2GEJ 473 X (47K) B 40.3/31.7
R244 7030005240 S.RES ERJ2GEJ 473 X (47K) B 40.3/30.7
R245 7030010040 S.RES ERJ2GEJ-JPW B 8.4/87.1
R246 7030005050 S.RES ERJ2GEJ 103 X (10K) B 39.2/73.8
R247 7030005050 S.RES ERJ2GEJ 103 X (10K) B 38.3/73.8
R248 7030005090 S.RES ERJ2GEJ 104 X (100K) B 24.4/40.9
R249 7030005090 S.RES ERJ2GEJ 104 X (100K) B 17.9/41.9
R250 7030005100 S.RES ERJ2GEJ 154 X (150K) B 33.8/90.1
R251 7030005770 S.RES RR0510P-101-D (100) B 40.7/48.2
R252 7030000020 S.RES MCR10EZHJ 1 (010) B 29.4/54.2
R253 7030005170 S.RES ERJ2GEJ 474 X (470K) B 26.5/74
R254 7030010040 S.RES ERJ2GEJ-JPW B 35.9/75.1
R256 7030010040 S.RES ERJ2GEJ-JPW B 40.4/67.8
R257 7030005050 S.RES ERJ2GEJ 103 X (10K) B 22.3/90.3
C1 4030016930 S.CER C1005 JB 1A 104K-T B 37.6/88.4
C2 4030017460 S.CER C1005 JB 1H 102K-T B 26/75.2
C3 4030017460 S.CER C1005 JB 1H 102K-T B 26.9/75.2
C4 4030017460 S.CER C1005 JB 1H 102K-T B 26.9/76.9
C5 4030017460 S.CER C1005 JB 1H 102K-T B 27.8/77
C6 4030017460 S.CER C1005 JB 1H 102K-T B 29/77.9
C7 4030016790 S.CER C1005 JB 1E 103K-T B 46.1/56
C8 4030017460 S.CER C1005 JB 1H 102K-T B 29/77
C9 4030017460 S.CER C1005 JB 1H 102K-T B 32.9/77.8
C10 4030017460 S.CER C1005 JB 1H 102K-T B 33.8/77.8
C15 4030017460 S.CER C1005 JB 1H 102K-T B 14.4/24.3
C16 4030017460 S.CER C1005 JB 1H 102K-T T 10.6/97.6
C17 4030017420 S.CER C1005 CH 1H 470J-T B 38.8/96.6
C18 4030017420 S.CER C1005 CH 1H 470J-T B 33.7/96.6
C19 4030017640 S.CER C1005 CH 1H 150J-T B 38.9/78.4
C20 4030016930 S.CER C1005 JB 1A 104K-T B 24.9/60.4
C21 4030017460 S.CER C1005 JB 1H 102K-T B 35.6/73.6
C22 4030017350 S.CER C1005 CH 1H 020B-T B 38.2/76
C23 4030016790 S.CER C1005 JB 1E 103K-T B 46.3/75
C24 4030017730 S.CER C1005 JB 1H 471K-T B 46.3/79.2
C25 4030018870 S.CER C1005 JF 0J 105Z-T B 46.3/81
C26 4030016930 S.CER C1005 JB 1A 104K-T T 10.9/100.2
C27 4030017460 S.CER C1005 JB 1H 102K-T T 44.7/6.5
C29 4030017420 S.CER C1005 CH 1H 470J-T B 0.9/55
C31 4030017460 S.CER C1005 JB 1H 102K-T B 19.3/89
C32 4030017460 S.CER C1005 JB 1H 102K-T B 31.7/88.9
C34 4030017460 S.CER C1005 JB 1H 102K-T B 32.6/88.9
C35 4030016930 S.CER C1005 JB 1A 104K-T B 14.9/95.1
C36 4030018860 S.CER C1005 JB 0J 105K-T B 34.5/91.1
C37 4030018520 S.CER C1608 JB 0J 225M-T B 33.7/88.4
C42 4510009870 S.ELE 10 CE 100 LD B 20.3/96.4
C43 4030017460 S.CER C1005 JB 1H 102K-T B 34.5/92.9
C51 4030016930 S.CER C1005 JB 1A 104K-T B 6.4/91.1
C53 4550007700 S.TAN TEESVP 1C 225M8R B 21.9/77
C54 4550007700 S.TAN TEESVP 1C 225M8R B 20.2/76.6
C58 4550007700 S.TAN TEESVP 1C 225M8R B 18.4/77.3
C59 4550007700 S.TAN TEESVP 1C 225M8R B 16.7/78
C61 4550007690 S.TAN TEESVP 1C 105M8R B 11.6/87.7
C62 4550007690 S.TAN TEESVP 1C 105M8R B 11.6/86
C64 4550007690 S.TAN TEESVP 1C 105M8R B 11.6/84.2
C66 4550007690 S.TAN TEESVP 1C 105M8R B 11.6/82.5
C67 4550007690 S.TAN TEESVP 1C 105M8R B 11.6/80.7
C68 4030017460 S.CER C1005 JB 1H 102K-T B 35.7/37.6
C70 4550006880 S.TAN TEESVD2 0J 157M12R B 6.9/94.2
C71 4030017460 S.CER C1005 JB 1H 102K-T B 36.1/38.8
C73 4030016930 S.CER C1005 JB 1A 104K-T B 2.9/81.3
C74 4030016950 S.CER C1005 JB 1A 473K-T B 3.2/91.1
C75 4030017460 S.CER C1005 JB 1H 102K-T B 40.4/38.3
C76 4030017460 S.CER C1005 JB 1H 102K-T B 0.75/79.5
C77 4550007090 S.TAN TEESVA 1A 226M8R B 8.9/82.6
C78 4550007090 S.TAN TEESVA 1A 226M8R B 41.7/36.3
C79 4550007090 S.TAN TEESVA 1A 226M8R B 30/41.2
C80 4030017460 S.CER C1005 JB 1H 102K-T B 28.5/42.3
C81 4030018860 S.CER C1005 JB 0J 105K-T B 7.3/80.1
C82 4550007090 S.TAN TEESVA 1A 226M8R B 5/72.2
C83 4030016930 S.CER C1005 JB 1A 104K-T B 6.6/81.3
C84 4550000730 S.TAN TEESVA 0J 225M8R B 1.3/85.1
C85 4030017460 S.CER C1005 JB 1H 102K-T B 27/45.2
C87 4030016930 S.CER C1005 JB 1A 104K-T B 24.3/16.3
C88 4030017460 S.CER C1005 JB 1H 102K-T B 34.3/39.7
C89 4030017460 S.CER C1005 JB 1H 102K-T B 27/46.2
C90 4030017760 S.CER C1005 JB 1H 222K-T B 26/42.7
C92 4030016930 S.CER C1005 JB 1A 104K-T B 11.3/48.2
C93 4030019500 S.CER GRM21BB31A106KE18
(GRM40 B) B 41.9/43.6
C94 4030019500 S.CER GRM21BB31A106KE18
(GRM40 B) B 41.9/41.8
C95 4030016970 S.CER C1005 JB 1E 223K-T B 26/41.8
C98 4030016930 S.CER C1005 JB 1A 104K-T B 12.3/54.2
C99 4030016930 S.CER C1005 JB 1A 104K-T B 5/82.2
C101 4030018860 S.CER C1005 JB 0J 105K-T B 9.5/51.9
C102 4030019500 S.CER GRM21BB31A106KE18
(GRM40 B) B 37/41.8
C103 4030019500 S.CER GRM21BB31A106KE18
(GRM40 B) B 35.3/41.8

Feb. 2010
7
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[LOGIC UNIT]
C104 4030016930 S.CER C1005 JB 1A 104K-T B 21/37.4
C106 4030018860 S.CER C1005 JB 0J 105K-T B 14/50.4
C108 4030017040 S.CER C1005 JB 1A 333K-T B 14/51.3
C109 4030017460 S.CER C1005 JB 1H 102K-T B 31.4/46
C111 4030016930 S.CER C1005 JB 1A 104K-T B 12.3/53.3
C112 4030016930 S.CER C1005 JB 1A 104K-T T 43.3/9.2
C114 4030017490 S.CER C1608 JB 1A 105K-T B 23.8/51.4
C115 4030017510 S.CER C1005 CH 1H 680J-T B 5.9/36.1
C117 4030017040 S.CER C1005 JB 1A 333K-T B 17.3/53.7
C120 4030016930 S.CER C1005 JB 1A 104K-T B 14/53.3
C121 4030016930 S.CER C1005 JB 1A 104K-T B 14/52.4
C122 4030017490 S.CER C1608 JB 1A 105K-T B 3.4/30.3
C123 4030017730 S.CER C1005 JB 1H 471K-T B 19.1/40.5
C124 4030017460 S.CER C1005 JB 1H 102K-T B 23.4/17.9
C125 4030016930 S.CER C1005 JB 1A 104K-T B 7.9/33.7
C126 4030017490 S.CER C1608 JB 1A 105K-T B 8.7/29
C127 4030017490 S.CER C1608 JB 1A 105K-T B 7.4/29
C128 4030017490 S.CER C1608 JB 1A 105K-T B 3.4/27.7
C130 4030017730 S.CER C1005 JB 1H 471K-T B 17.8/52.5
C131 4030017490 S.CER C1608 JB 1A 105K-T B 7.4/26.4
C133 4030017440 S.CER C1005 CH 1H 221J-T B 20.5/49.7
C134 4030017490 S.CER C1608 JB 1A 105K-T B 3.4/25.1
C135 4030017460 S.CER C1005 JB 1H 102K-T B 24.8/44.2
C136 4030017430 S.CER C1005 CH 1H 101J-T B 19.1/43.2
C137 4030017490 S.CER C1608 JB 1A 105K-T B 7.4/23.8
C138 4030017490 S.CER C1608 JB 1A 105K-T B 3.4/22.5
C139 4030016780 S.CER C1005 JB 1E 153K-T B 16.7/40.5
C141 4030018100 S.CER C1005 JB 1H 681K-T B 22.3/52.4
C142 4030017490 S.CER C1608 JB 1A 105K-T B 7.4/21.2
C143 4030017460 S.CER C1005 JB 1H 102K-T B 16.7/43.2
C144 4030017780 S.CER C1005 JB 1H 472K-T B 25.4/47.6
C147 4030018100 S.CER C1005 JB 1H 681K-T B 22.7/51.1
C148 4030018860 S.CER C1005 JB 0J 105K-T B 18.7/48.8
C149 4030008680 S.CER C2012 JF 1C 105Z-T B 9/22.4
C155 4030017760 S.CER C1005 JB 1H 222K-T B 23.6/49.2
C156 4030017900 S.CER C1005 JB 1E 123K-T B 20/47.6
C157 4030016930 S.CER C1005 JB 1A 104K-T B 18.7/46.4
C158 4030019090 S.CER C2012 JB 1C 225M-T B 6.9/19
C161 4030016790 S.CER C1005 JB 1E 103K-T B 21.8/47.6
C162 4030018860 S.CER C1005 JB 0J 105K-T B 20.9/47.6
C163 4030011600 S.CER C1608 JB 1E 104K-T B 4/17.7
C164 4030017460 S.CER C1005 JB 1H 102K-T B 40.3/49.8
C165 4030016930 S.CER C1005 JB 1A 104K-T B 34.8/37.6
C166 4030019500 S.CER GRM21BB31A106KE18
(GRM40 B) B 31.2/44.6
C167 4030016930 S.CER C1005 JB 1A 104K-T B 33/37.6
C168 4030016930 S.CER C1005 JB 1A 104K-T B 31.3/47.6
C169 4030016930 S.CER C1005 JB 1A 104K-T B 33.7/34.7
C170 4030017460 S.CER C1005 JB 1H 102K-T B 38.2/50.8
C171 4030017460 S.CER C1005 JB 1H 102K-T B 43.2/55.1
C172 4030016930 S.CER C1005 JB 1A 104K-T B 38.2/51.7
C173 4030017460 S.CER C1005 JB 1H 102K-T B 19.6/17.9
C174 4030019500 S.CER GRM21BB31A106KE18
(GRM40 B) B 41.9/45.3
C175 4030017460 S.CER C1005 JB 1H 102K-T B 19.1/36.3
C178 4030016930 S.CER C1005 JB 1A 104K-T B 46.5/60.5
C179 4550007680 S.TAN TEESVP 0J 226M8R B 36.1/77.5
C180 4030016930 S.CER C1005 JB 1A 104K-T B 34.4/75
C182 4030018860 S.CER C1005 JB 0J 105K-T B 8.6/75.9
C183 4030016930 S.CER C1005 JB 1A 104K-T B 8.6/79
C184 4030017460 S.CER C1005 JB 1H 102K-T B 45.7/48.5
C185 4030017480 S.CER C1608 JB 1A 474K-T B 43.1/48.9
C186 4030019500 S.CER GRM21BB31A106KE18
(GRM40 B) B 39.9/52.2
C187 4030017790 S.CER C1005 JB 1H 682K-T B 11/47
C188 4030017790 S.CER C1005 JB 1H 682K-T B 4.2/47.2
C189 4030017920 S.CER C1005 JB 1A 683K-T B 5.8/52.4
C190 4030017920 S.CER C1005 JB 1A 683K-T B 7.4/52.4
C191 4030016930 S.CER C1005 JB 1A 104K-T B 11.3/49.1
C192 4030016930 S.CER C1005 JB 1A 104K-T B 3/51.9
C193 4030018860 S.CER C1005 JB 0J 105K-T B 1.2/51.5
C194 4340000450 S.MYL ECPU1C105MA5 B 13.8/93.1
C195 4030019090 S.CER C2012 JB 1C 225M-T B 6.9/17.3
C197 4030017400 S.CER C1005 CH 1H 220J-T B 21.7/68.3
C198 4030016930 S.CER C1005 JB 1A 104K-T B 6.7/59.6
C199 4030017460 S.CER C1005 JB 1H 102K-T B 19.4/73
C201 4030017460 S.CER C1005 JB 1H 102K-T B 9.6/72.9
C202 4030017460 S.CER C1005 JB 1H 102K-T B 8.3/73.6
C203 4030017460 S.CER C1005 JB 1H 102K-T B 8.6/75
J5 6510021901 S.CON BM02B-ASRS-TF(LF)(SN) T 43.6/3.3
J6 6510025170 S.CON IMSA-9631S-27Y-921 B 23.8/82.9
J7 6510026690 S.CON AXK4S50535G B 12.4/63.7
DS10 5040003010 S.LED SML-A12WT T 11.5/95
DS11 5040003010 S.LED SML-A12WT T 23.8/95
DS12 5040003010 S.LED SML-A12WT T 36.1/95
DS13 5030003310 LCD BTG-9864C-FBWD-N-G-A <VKH>
S21 7600000210 ENC TP70N00E20-15F-1903
EP1 6910018460 S.BEA MMZ1005Y102C-T B 37.9/96.6
EP2 6910018460 S.BEA MMZ1005Y102C-T B 34.6/96.6
EP8 3310003010 ANT KY-058-006-2 <KAI>
EP9 6910014690 S.BEA MPZ1608S221A-T B 29/36.3
EP10 6910014690 S.BEA MPZ1608S221A-T B 15.3/37.1
EP13 6910018460 S.BEA MMZ1005Y102C-T B 15.8/75.2
EP15 6910018460 S.BEA MMZ1005Y102C-T B 34.9/75.8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount

Feb. 2010
8
SECTION 8
.
BOARD LAYOUTS
• 1st VCO UNIT
(TOP VIEW)
• LOGIC UNIT
(TOP VIEW)
• 2nd VCO UNIT
(TOP VIEW)
• MAIN UNIT
(TOP VIEW)
UHFC
GC
800C
VHFC
TRAC
ATT
B1C B2C
ANTSW
HFC
ATTC
R3V
VCO1 VCO2 VCO3 VCO4
PCK
PDATA
PSTBa PSTB2
GND
PS VP
GND
BAR
+3V
GND
OSC
VCO4
VCO3
VCO2
VCO1
VCO3V
GND GND
+3V
GND GND
OSC
GND GND
PCK PDATA PSTB2 PS GND 2ndLO GND R3V
1stLO
GND
PCK
PDATA
PSTB1
PS
GND
VP
AFO AFE SPO EAR CLONE GND TUNE SHIFT3V FSET GND VCC GND +3V NOISE RSSI AM DET AGCC WFM HVE HVE N/C HV HV HV
SPO GND
SP1 (CHASSIS)
J1 (CHASSIS)
[SP]
[DC 6V]
C16
C26
C27
C112
21SD11SD01SD
J5
Q5
R19
R20
R22
R112
R241
B6969C
B
W
R
G
H0H5H10H15H20H25H30H35H40H45
V0 V5 V10 V15 V20 V25 V30 V35 V40 V45 V50 V55 V60 V65 V70 V75 V80 V85 V90 V95 V100
C2 C3
C4 C6
C7
C12
C17
C18
C23
C31
C49
C52
C70
C73
C139
C142
C162
C167
C168
C172 C178
C181
C187
C245 C246
C249
C291
C292
C296
C306
C313
C316
C401
C402
C406
C425
C431
C435
C441
C445
D1 D2
D5
D29
D53
FI3
J1
J2
J3
J4
J5
L25
L29
L31
Q2
Q3
Q36
Q38
Q40
Q47
R2
R3
R4 R5
R15
R16
R24
R25
R44
R101
R110
R162
R213
R214
R216
R218
R224
R238
R241
R243
X1
X3
B6970D
H0H5H10H15H20H25H30H35H40H45
V0 V5 V10 V15 V20 V25 V30 V35 V40 V45
C2
C3
C4 C5 C6
C7
C8
C9
C10
C11 C12 C13
C14
C15
C16
C17 C18
C19
C20 C21 C22
C23
C24
C25
C26
C27
C28
C29
C30
C45
C46
C47
C49
C50
C52
C54
65C55C
C57
C69
C72
C73
C74
C75
C76
C77
C78
D1
D2
D3 D4 D5
D7
D8
D9
D10
IC2
L1 L2
L3
L4
L5
L6
L7
L8
L9
L10
L12
L13
L15
L16 L17
L18
L19
L20 L21
Q1
Q2
Q3
Q4
R1
R2
R3
R4
R5
R6
R7 R8 R9
R10
R11
R12
R13
R14 R15
R16
R17
R18
R19
R33
R34
R36
R37 R38
R39
R40
R41
R42R43
R44
R59
36R26R16R06R
R66
B6971C
H0H5H10H15H20
V0 V5 V10 V15
C1
C2
C3
C4
C5
C6
C7
C8
C9
C10
C16
C22
C23
C30
C32
C33
D1
L1
L2
L3 L4
Q1
Q3
Q4
R1
R2
R3
R4
R16
R17
R18
R19
R21
B6972A
H0H5H10
V0 V5 V10 V15

Feb. 2010
9
• 1st VCO UNIT
(BOTTOM VIEW)
• LOGIC UNIT
(BOTTOM VIEW)
• 2nd VCO UNIT
(BOTTOM VIEW)
• MAIN UNIT
(BOTTOM VIEW)
+3V
GND
OSC
VCO4
VCO3
VCO2
VCO1
VCO3V
GND GND +3V GND GND OSC GND GND
PCK
PDATA
PSTB2
PS
GND
2ndLO
GND
R3V
1stLO
GND
PCK
PDATA
PSTB1
PS
GND
VP
CLONE
J4
BATT+
BATT–
SPO
AFO
AFE
J5
[EXT DC]
[EXT SP]
HVE
HV
B1C
PSTB2
PSTB1
PDATA
PCK
VCO4
VCO2
VCO1
ATTC
ANTSW
HFC
ATT
B2C
VCO3
VHFC
800MC
UHFC
BAR
TRAC
GC
R3V
AFO
SPO
CLONE
GND
GND
GND
GND
GND
GND
NC
GND
GND
TUNE
SHIFT3V
FSET
NOISE
RSSI
DET
AGCC
WFM
PS
VP
+3V
AM
HV
HV
HV
EAR
AFE
C8
C9
C10 C11
C15
C16
C19
C22
C24
C25
C29
C30
C34
C35
C37
C38
C40
C41
C43
C46
C47
C51
C61
C68
C69
C72
C75
C76
C80
C81
C82
C83
C84
C86
C87
C88
C90
C91
C93
C94
C96
C98
C99
C100
C101
C102
C104
C106
C107
C108
C110
C113
C115
C116
C117
C118
C119
C120
C122
C123
C124
C127
C128
C129
C131
C132
C133
C135
C136
C137
C138
C141
C145
C146
C147
C150
C151 C152
C157
C158
C173
C174
C183
C188
C189
C190
C191 C194
C201
C203
C206
C207
C208
C217
C220
C221
C223
C225
C226
C228
C239
C242
C244
C247
C253
C256
C258
C259
C261
C262
C263
C265
C266
C269
C270
C272
C275
C276
C278
C279
C280
C284 C285
C286
C293 C297
C300 C301
C403
C404
C405
C412
C413
C414
C415
C416
C417
C418
C419
C420
C421
C422
C423
C424
C426
C427
C428
C434
C436
C437
C438
C439
C440
C442
C443
C444
C446
C447
C448
C449
C450
C451
C452
C453
C454
C455
C456
D4 D7
D8
D9
D10
D12
D13
D14 D15
D18
D19
D20
D21
D22
D23
D25
D26
D27
D28
D31
D32
D33 D34
D35
D36
D37 D38
D40
D41
D42
D44 D45
D47
D48
D49
D50
D51
D52
D54
D55
D56 D57
D58
EP6
EP9
EP10
EP11
EP12
EP13
EP14
FI1
FI2
IC1
IC5
IC8
IC9
IC13
L1
L2
L3
L4
L5
L7
L8
L10
L11
L12
L13
L15
L16
L18
L19
L20
L21
L22
L23
L24
L33
L34
L36
L38
L40
L41
L43
L44
L50
L51
L52
L53
L54
L55
L56
L60
L61
L62
L63
L64
MP1
Q5
Q6
Q7
Q11
Q12
Q17
Q18Q19
Q23
Q25
Q26
Q31
Q37
Q39
Q41
Q42
Q43
Q44
Q45
Q46
R1
R11
R13 R14
R22
R26
R27
R28
R29
R31
R32
R34
R35
R36
R37
R38
R41
R43
R45
R46
R49
R52
R54
R57
R60
R61
R62
R65
R66
R67
R68
R69
R73
R75
R76
R77
R78
R85
R86
R87
R89
R97
R98
R108
R109
R113
R114
R118
R126
R128 R129
R138
R141
R142
R143
R148
R149
R150
R154
R157
R167
R168
R169
R172
R173
R179
R181
R184
R185
R187 R188
R189
R190
R194
R195
R196
R203
R204
R210
R215
R221
R222
R223
R225
R226
R227
R228
R229
R230
R232
R233
R234
R236
R237
R239
R240
R242
H0 H5 H10 H15 H20 H25 H30 H35 H40 H45
V0V5V10V15V20V25V30V35V40
V45
C1
C2
C3
C4
C5
C6
C7
C8
C9
C10
C15
C17
C18
C19
C20
C21
C22
C23 C24 C25
C29
C31
C32
C34
C35
C36
C37
C42
C43
C51
C53
C54
C58
C59
C61 C62 C64 C66 C67
C68
C70
C71
C73
C74
C75
C76
C77
C78
C79
C80
C81
C82
C83
C84
C85
C87
C88
C89
C90
C92
C93 C94
C95
C98
C99
C101
C102
C103
C104
C106 C108
C109
C111
C114
C115
C117 C120
C121
C122
C123
C124
C125
C126
C127
C128
C130
C131
C133
C134
C135
C136
C137
C138
C139
C141
C142
C143
C144
C147
C148
C149
C155
C156
C157
C158
C161
C162
C163
C164
C165
C166
C167
C168
C169
C170
C171
C172
C173
C174
C175
C178
C179
C180
C182 C183
C184
C185
C186
C187
C188
C189C190
C191
C192
C193
C194
C195
C197
C198
C199
C201
C202
C203
D2
D5
D7
D8
D9
D10
D11
D12 D13
D14
D15
D16
D19
D22
D24 D25 D26 D27
D28
D29
D31
D32
D33
D34
D35
D37
D38
D39
D40
EP1
EP2
EP9
EP10
EP13
EP15
IC1
IC3
IC4
IC6
IC8
IC9
IC10
IC11
IC12
IC14
IC15
IC16
IC17
IC18
IC19
IC20
J6
J7
L1
Q2
Q8
Q10
Q11
Q12
Q16
Q18
Q20
Q21
Q23
Q24
Q25
Q26
Q27
Q28
Q29
Q30
R2
R3
R5
R6
R7
R9
R10
R11
R16 R21
R23
R24
R29
R31
R32
R33
R37
R39
R40
R41
R44
R45
R46
R48
R50
R51
R53
R57
R61
R66
R67
R70 R71
R79
R81
R83
R84
R85
R86
R89 R90
R91
R97
R102
R105
R107
R108
R111
R113
R114R115
R116
R117
R118
R121
R124
R128
R129
R130
R132
R133
R135
R136
R137
R140
R141
R142
R144
R145 R146
R147
R149
R150 R151
R155
R156
R157
R160
R161
R162
R163
R165 R166
R167
R170
R171
R172
R177
R178
R179
R182
R184
R185
R188
R189
R190
R191
R192
R193
R194
R195
R196
R201
R202
R203
R208
R209
R210
R211
R212
R213
R214
R216
R217
R218
R219
R220
R221 R222
R223R224
R225R226
R227
R228
R229
R231
R232 R233 R234 R235
R236 R237
R239
R240
R242
R243
R244
R245
R246
R247
R248
R249
R250
R251
R252
R253
R254
R256
R257
S21
X1
H0 H5 H10 H15 H20 H25 H30 H35 H40 H45
V0V5V10V15V20V25V30V35V40V45V50V55V60V65V70V75V80V85V90V95V100
C31
C35
C37
C38 C39
C40
C41
C42
C43
C44
C48
C58
C59
C60
C61
C62
C63
C64
C65
C66
C67
C68
C70
C71
IC3
J1
Q6
Q7
Q8
Q10
Q11
Q12
R23
R24
R25
R26
R27
R28
R29
R30
R31
R32
R35
R46
R47
R48
R49
R53
R55 R56
R57
H0 H5 H10 H15 H20
V0V5V10V15
C17
C18
C19 C20
C21
C24
C25C26
C27
C31
IC1
J1
R9
R10
R11 R12 R13
R14
R15
R22
H0 H5 H10
V0V5V10V15

Feb. 2010
*; Refer to “PARTS LIST.”
10
SECTION 10
SECTION 10
.
VOLTAGE DIAGRAM
R37
47K
0.001
C15
0.001 C21
KEY
S3
KEY
S2
KEY
S15
KEY
S8
KEY
S12
KEY
S17
KEY
S4
KEY
S9
KEY
S7
KEY
S13
KEY
S11
KEY
S18
KEY
S1
KEY
S6
KEY
S16
KEY
S5
KEY
S10
KEY
S14
KEY
S19
47K R10
0.001 C2 0.001 C3 0.001 C4 0.001 C5 0.001 C6 0.001 C8
0.001 C9 0.001 C10
1k
R40
1k
R48
1k
R53
0.1 C20
0R24
47P
C17
47P
C18
0.001
C16
0.1
C167
10
R32
1M
R33
15P
C19
0.01
C23
12K
R46
100K
R16
1SS400
D16
100K
R21
10K
R44
KEY
S20
0.1
C26
0.1
C165
10k
R3
10k
R6
2P
C22
1
C25
EXB28V332 J
R2
470P
C24
100K
R51
10KR71
HVC376B
D15
TC7W04FU
IC8
1
2
3
45
6
7
8
2.2 C59 2.2 C53 100K R91 2.2 C58
1 C61 1 C62 1 C66 1 C64 1 C67
2.2 C54
IMSA-9631S-27Y921
J6
1 2
3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27
2829
82
R19
82
R22
2.2M
R61
24LC512T
IC15
1A0
2A1
3A2
4VSS 5
SDA
6
SCL
7
WP
8
VCC
24LC512T
IC14
1A0
2A1
3A2
4VSS 5
SDA
6
SCL
7
WP
8
VCC
0.01
C7
0.1
C1
0.1
C178
10K
R5
82
R20
22
C179
0.1
C180
KEY
S25
KEY
S22
KEY
S24
KEY
S23
KEY
S26
MA2S1110G
D11
MA2S1110G
D14
MA2S1110G
D5
MA2S1110G
D8
MMZ1005Y102CT
EP2
MMZ1005Y102CT
EP1
S-80928CNMC
IC6
1OU T
2VDD
3VSS 4
NC
5
CD
2SC4738
Q10
2SA1832
Q8
470
R83
470
R84
100K
R66
0.1
C183
TC7W08FU
IC1
1
2
3
45
6
7
8
NTCG16
R189
100K
R190
330
R209
1k R23
1k
R67
1kR214
MMZ1005Y102CTEP13
10KR211
10KR210
1kR212
10KR217
2SC4617
Q5
10K
R228
0
R229
TP70N00E2015F
S21
E
UP
DN
MMZ1005Y102CT
EP15
1kR213
R70 10K
*D9
*D7 *D10
*D12
*D13
100K R41
1k R50
10k
R31
10K
R231
10K
R232
10K
R233
10K
R234
10K
R235 47K
R236
47K
R237
47K
R239
47K
R241
100K
R242
47K
R243
47K
R244
10KR246
10KR247
R9
47K
R29
10K
4.7K R11
18K
R45
47K
R39
CR-774
X1
SML-A12WT
DS10
SML-A12WT
DS11
SML-A12WT
DS12
1k
R79
1k
R7
1k
R208
22P
C197
470K
R253
3076
MP7
0
R254
0
R256
HD64F2238RTF13V
IC17
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
CL_IN
LCDCS
LCDRES
LCDCK
LCDDT
BEEP
LCDDT
LCDCS
LCDRS
LCDCK
CL_OUT
HVDET
ANTSW
B2C B1C
ATT
WFM
CHGC
POWE R
DCK
DUD
AGCC
CL_OUT
RTONE
CTONE
VSCAF
RSSI
TEMP
BATTI
HVIN
I0I0
KS3
KS2
I1I1
KS1
KS0
KR4
KR3
KR2
KR1
VCCVCC
LDATA
DATAC
VRCK
VRDATA
LCK
PSTB2 PSTB1
PDATA
PCK
PS
CKO
DASTB
LIGHT
AFON
LCDRES
CLS0
TEMP
DATAC
EAR
KR0
KR5
POWE R
RESET MD2 ECK ESIO
ESIO
ECK
TREBLE_C
BASS_C
LDATA
BDET
KR0 KR1 KR2 KR3
UHFC
GC
800MC
NOISE
TREBLE_B
KS3 KS2 KS1 KS0
TCON
PCON
VCO1 VCO2 VCO3 VCO4
AM
BASS_B
KR4
TRUT H
SHIFT
CPU3V
NMI
TXD2
RXD2
SCK2
VRSTB
LCK
DCK
DUD
CHG
CL_IN
R3C
KR5
I0
I1
LIGHT
CPU3V
LCDRS
CPU3V
TXD2
RXD2
SCK2
BDET
HFC
VHFC
NMI
FW E
MD2
+3V +3V
FW E
SCAN 123
456
0
789
OK
HOLD
DOW NR IGHT
SERCH
RXF1 RXF0
B3 B2 B1 B0
POWE R
LCD Back Light
LCDDIAL
EEPROM
RESET
CPU
C lone Buff
CPU-MAIN
CPU-LOGIC
MENU UP FAVLEFT
Batt.DET
#
BACK
LIGHT ON :2.2V
LIGHT OFF:0.0V
• LOGIC UNIT (Left side)

Feb. 2010
11
*; Refer to “PARTS LIST.”
0.001
C170
0.001
C85
1
C149
HAT1023R
Q27
5D
6D
7D
8D1
S2
S3
S4
G
XP6501
Q20
1 2 34
5 6
0.001
C109
47P
C29
0.001
C173
0.1
C120
15K
R144
0.1
C92
0.001
C27
0.001
C89
0.001
C164
0.1
C111
MA2S7280G
D35
0.1
C104
0.001
C135
180K
R135
10
R128
470K
R133
0.001
C175
0.1
C121
0.1
C98
1M
R165
100K
R141
82K
R140
39K
R151
39K
R166
0.001
C143
0.1
C157
100P
C136
0.022
C95
0.0022
C90
1
C127
1
C131
1
C137
1
C142
1
C122
1
C128
1
C134
1
C138
0.1
C163
1
C114
2.2M
R157
0.1
C169
82K
R162
82K
R142
12K
R121
120K
R118
0.015
C139
820K
R137
0
R57
CP7
CP10S
CP8
CP10S
68P
C115
0.1
C168
Q25
UNR9213G0
MA2S1110G
D33
47K
R179
0.01
C161
390K
R177
0.0022
C155
2.2M
R170
470K
R161
2.2M
R160
180K
R156
100K R149
180K
R155
2SA1588
Q2
0.001
C75
0.001
C71
0.001
C68
470K
R107
0.001
C80
0
R117
0.1
C125
100K
R124
D2
SB07-03C
10U
L1
1
C126
10K
R172
180K
R136
Q16
UNR9115G0
2SJ144
Q23
1SS372
D24
1SS372
D25
1SS372
D26
1SS372
D27
TC7W04FU
IC11
1
2
3
45
6
7
8
BM02B-ASRS-TF
J5
1
2
3 4
68K
R85
XP1501
Q12
1 2 34
5
0
R86 2SB1201
Q11
0.001
C76
0.1
C73
0.1
C83
SM6451B
IC10
1RSTN
2ADRS1
3ADRS2
4DVDD
5LOUT
6LIN
7AVDD
8VRL 9
VRR
10
AVSS
11
RIN
12
ROUT
13
DVSS
14
MLEN
15
MCK
16
MDT
10
R111
150 MSVD2
C70
0.047
C74
0.1
C35
10K
R105
10K
R102
LM2904PWR
IC12
1
2
3
45
6
7
8
CP1
CP06S
220K
R113
D19
SVC389
CP4
CP06S
100K
R116
CP3
CP06S
CP2
CP06S
0.1
C87
XP4601
Q21
1
2
34
5
6
0.1
C112
KY-058
EP8
1 2 3 4
0.001
C124
0.001
C32
0.001
C34
1M
R81
0.001
C43
1
C36
2.2
C37
1k
R89
0.001
C31
0.1
C51
0.001
C88
220P
C133
470P
C130
39K
R178
0.1
C99
NJM2070M
IC9
11
22
33
4455
66
77
88
15K
R115
2.2 SVA
C84
0.1
C172
MA2S1110G
D37
82K
R145
22K
R146
MPZ1608S221A
EP9
M PZ1608S221A
EP10
22
C78
22
C79
1
C182
BH2220FVM
IC16
1AO1
2AO2
3AO3
4VCC 5
GND
6
DI
7
CLK
8
LD
2SC4738
Q18
2SC4738 Q24
MA2S1110G
D28
MA2S1110G
D32
MA2S1110G
D29
MA2S1110G
D31
MA2S1110G
D22
180K
R191
180K
R194
100K
R193
100K
R192
AVR-M1005C080MT
D38
MAZ8039GL
D34
NTCG16
R216 0.001
C184
0.47
C185
82K
R201
47K
R203
UNR9213G0
Q26
LMV321IDCK
IC19 1
2
3
4
5
10K
R218
CD4066BPWR
IC20
1I/O1
2O /I1
3O /I2
4I/O2
5CONT2
6CONT3
7VSS 8
I/O3
9
O/I3
10
O/I4
11
I/O4
12
CONT4
13
CONT1
14
VDD
0.0068
C187
0.0068
C188
0.068
C189 0.068
C190
4.7K
R219
4.7K
R220
4.7K
R221
4.7K
R222
27K
R225
27K
R226
0.1
C191
0.1
C192
ECPU1C105MA5
C194
680P
C147
680P
C141
10K
R227
2.2
C158
2.2
C195
AVR-M1005C080MT
D39
AXK4S50535G
J7
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
2031
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
2130
2229
2328
2427
2526
BQ24064
IC18
1
IN 2
TMR 3
STAT1 4
STA2 5
VSS
6ISET
7PG
8CE
9BAT
10 OUT
11
10
C93
10
C94
10
C102
10
C103
10
C166
10
C174
10
C186
XP1113
Q28
1
2
34
5
0
R245
100K
R249
100
C42
18K
R97
100K
R90
470K
R147
100K
R248
470P
C123
0
R167
10K
R163
0.0047
C144
150K
R150
NJU7775F32
IC3
1
VIN 2
GND 3
CTRL
4NC
5VOUT
NJU7775F32
IC4
1
VIN 2
GND 3
CTRL
4NC
5VOUT
5.6K
R171
0.012
C156
18k
R195
3.9k
R196
100K
R202
3.3K
R188
3.3K
R184
100
R185
100
R251
1
R252
0.1
C198
100K
R182
0.001
C199
RR264M
D40
3076
MP6
1 2 3
0.001
C201
0.001
C202
0.001
C203
0.001
C171
4.7K
R108
22
C77
22
C82
2SC4213
Q29
UNR9115G0
Q30
10K R257
1
C162
1
C148
1
C106
1
C101
1
C193
1
C81
1k
R114
220K
R240
150K
R250
5.6K
R224
5.6K
R223
4.7K
R129
82
R130
470
R112
150K
R132
0.033
C117
0.033
C108
B1C
PSTB2
PSTB1
PDATA
PCK
VCO4
VCO2
VCO1
ATTC
ANTSW
HFC
ATT
B2C
VCO3
TCON
PCON
CKO
VHFC
800MC
UHFC
CLONE
AFO
BAR
TRAC
GC
VP
BAR
TRAC
R3V
TUNE
BATTIN
HVIN
R3C
SPO
CTONE
CTONE
RTONE
VCC
HVDET
CPU3V
CPU3V
CHGC
AFO
SPO
CLONE
TUNE
SHIFT3V
FSET
NOISE
RSSI
DET
AGCC
WFM
PS
VP
CPU3V
+3V
AM
AF_TRUTH
TREBLE_B
BASS_B
BASS_C
TREBLE_C
LDATA
LCK
DASTB
R3V
VRSTB VRCK
VRDATA
AF_TRUTH
SHIFT3V
SHIFT
TRUTH
VSCAF
CHG
VP
HV
EAR
BEEP
TRAC
ATTC
FSET
R3V
+3V
AFON
VCC
INT SP
Li+
Li-
AF VR
AF AMP
AF FIL
BATT Charge
BAR ANT
Reg
VP_DC-DC
CPU-MAIN
CPU-LOGIC
AFE
BW GR
FM MODE:3.1V
AM/WFM AF FILTER OFF:0.0V
HV 6V:0.0V
HV 3V:3.2V
COM:12.7V
AF ON :3.1V
AF OFF:0.0V
Power ON : 0.0V
Power OFF:3.2V
AF ON :3.2V
AF OFF:2.7V
TONE ON :3.1V
TONE OFF:0.0V
CHARGE:0.0V
CHARGE OFF:3.2V
AF ON :0.6V
AF OFF:2.6V
• LOGIC UNIT (Right side)

Feb. 2010
12
*; Refer to “PARTS LIST.”
2P
C120
0.001
C99
2.2K
R11
120
R45
0.001
C10
7P
C34
0.1
C2
0.001
C101
MA2S7280G
D34
XP1113
Q17
1
2
34
5
0.001
C16
1SV308
D5
1SV308
D8
2.2K
R14
1SV308
D28
MA2S7280G
D21
47K
R34
0.001
C116
4.7K
R38
1SV308
D37
0.001
C129
1SV308
D42
0.001
C147
MA2S7280G
D19
0.001
C69
0.001
C18
470P
C51
4.7K
R41
CP1
CP06S
0.001
C117
100K
R49
XP1113
Q18
1
2
34
5
0.1
C3
XP1113 Q19
1
2
34
5
10K
R65
0.001
C81
0.001
C80
MA2S7280G
D18
330
R32
0.001
C9
1SV308
D10
0.001
C113
0.001
C150
0.001
C127
0.01
C102
0.001
C8
HVC350B
D36
HVC375B
D25
0.1
C118
330
R46
47K
R62
12K
R35
1SV308
D9
330
R31
0.1
C73
0.1
C6
0.001
C131
2.2K
R75
HVC375B
D12
0.001
C132
0.001
C98
2SC5008
Q5
0.001
C23
2.2K
R76
1SV308
D4
1SV308
D29
0.001
C93
0.001
C61
8P
C86
0.1
C4
470P
C100
0.001
C31
2.2K
R57
1SV308
D27
470P
C94
0.001
C138
MA2S7280G
D22
0.001
C145
0.1
C108
0.001
C152
1P
C37
MA2S7280G
D33
100U
L21
1k
R1
47K
R66
1SV308
D40
MA2S7280G
D15
MA2S7280G
D23
0.001
C11
1SV308
D38
0.001
C146
3P
C19
0.001
C128
6.8N
L40
3.3K
R60
100K
R52
100K
R24
MA2S7280G
D20
2.2K
R13
100K
R22
XP1110
Q11
1
2
34
5
MA2S7280G
D14
HVC375B
D26
100
R67
3.9N
L18
HVC350B
D32
FH102A-E
Q7
1
2
3
4
5
6
0.001
C151
12K
R37
1k
R25
1SV308
D7
10K
R16
1k
R43
HVC375B
D13
1SV308
D41
0.001
C137
18P
C84
0.001
C68
470P
C76
1SV172F
D1
4.7K
R78
2SC5624
Q6
3P
C38
1P
C43
2.5P
C96
7P
C135
470P
C75
5P
C40
0.1
C124
0.1
C136
0.01
C30
0.001
C123
2.2K
R77
47K
R69
47K
R36
15K
R29
15K
R27
0.001
C115
XP4312
Q3
1
2
34
5
6
2SC5006
Q41
2SC5006
Q42
0.001
C12
47P
C52
2SC5006
Q12
330
R221
0.001
C107
8.2N
L36
6.8K
R26
27N L16
3.3k
R54
0.1
C417
MA2S077G0
D51
2.2K
R222
HVD328C
D31
HVD328C
D35
220P
C106
100K
R61
100K
R68
2P
C119
220P
C122
27N
L20
LQW18AN82NG00D
L53
MA2S077G0
D52
0.1
C418 2.2K
R223
33P
C133
47P
C110
3P
C104
82P
C91
9P
C88
47P
C83
0.10U
L33
8P
C87
33P
C90
33P
C82
0.1
C49
0.1
C70
0.1
C72
33U
L31
1k
R44
SVC389
D53
100K
R224
8P
C412
5P
C15
100P
C413
9P
C419
0.22U
L55
0.22U
L56
0.01
C17
0.001
C7
0
R226
33K
R228
6.8K
R28
LQW18AN82NG00D
L52
0.001
C427
2.2K
R232
1SV308
D56
UNR9115G0
Q45
0
R233
1k
R234
0.1
C428
2SC4738
Q2
0.001
C431
0.15U
L34
0.15U
L38
0.001
C24
15N
L50
15N
L7
22N
L1
22N
L4
22N
L10
8P
C46
56P
C420
22N
L54
3.3N
L11
5.6N
L12
2.7N
L19
150U
L29
6.8N
L60
8P
C22
18P
C25
2P
C29
47P
C35
1P
C41
2P
C47
LQW18AN8N2D00
L2
LQW18AN6N8C00
L5
LQW18AN6N8C00
L13
LQW18AN6N8C00
L15
LQW18AN5N6C00
L8
2.5P
C436
0.001
C437
MA2S077G0
D2
1.5K
R15
1.5K
R238
2.7K
R5
82
R2
82
R4
330
R3
22
R239
56
R73
68P
C446
390P
C447
68P
C448
0.1U
L61
18N
L62
6P
C449
6P
C451
2P
C450
5P
C452
MA2S077G0
D57
2.2K
R240
0.001
C453
UNR9113G0
Q47
7P
C454
MA2S077G0
D58
2.2K
R242
0.001
C455
0.1U
L63
0.1U
L64
82N
L3
4.7K
R241
100K
R243
3076
MP1
1 2 3
B2C
VHFC
800MC
GC
UHFC
800M3V
ATTC
ATTC
AGC
AGC
TUNE
TRAC
HFC
B1C
ANTSW
R3V
BAR
G3V
UHF3V
R3V
EAR
TUNE
SHIFT3V
VHF3V
ATT
800M(470-833MHz)
1G(833-1300MHz)
UHF(350-470MHz)
SW(0.15-0.45 / 1.62-76MHz)
BC(0.45-1.62MHz)
RF_IN
VHF(76-350MHz)
Reg SW
ATT
BAR_ANT(0.45-1.62MHz )
500kHz:0.4V
AM ANTENNA
EXT-DX :0.0V
EXT-LOCAL:0.0V
BAR :3.1V
500kHz
AM ANTENNA
BAR :0.0 V
EXT-DX :3.1V
EXT-LOCAL:0.0V
500kHz
EXT-LOCAL:3.1V
AM ANTENNA
BAR :0.0V
EXT-DX :0.0V
500kHz
850MHz:0.8 V
145MHz:1.4V
ATT ON :3.1V
ATT OFF:0.0V
EARPHONE ANT ON :3.1V
EARPHONE ANT OFF:0.0V
600MHz:0.4V
435MHz:1.4V
200MHz:3.1V
145MHz:0.0V
• MAIN UNIT (Left side)

Feb. 2010
13
*; Refer to “PARTS LIST.”
1k
R194
0.001
C220
0.01
C278
2SC5006
Q36
XP1114
Q37
1
2
34
5
0.1
C259
ELFY450E
FI3
IO
XP1114
Q38
1
2
34
5
100K
R184
22K
R114
180
R203
0.01
C247
27P
C456
0.01
C313
1.5K
R185
680
R214
0.001
C280
0.01
C276
XP6501
Q25
1 2 34
5 6
0.01
C187
47K
R190
15
R97
470P
C300
FL-293
FI2
1
2
3
4
1.5K
R189
82P
C297
470
R204
R169
4.7K
J2
1 2
3 4
5 6
7 8
9 1 0
11 12
13 14
15 16
1k
R218
0.01
C291
0.1
C256
150K
R142
R157
10K
470P
C270
47P
C178
DAN235E
D47
DAN235E
D49
0.001
C272
0.1
C265
UNR9213G0
Q39
0.1
C258
1.5M
R216
DAN235E
D44
0.1
C292
R143
150K
2SC5006
Q31
0.001
C208
0.001
C285
100K
R129
47P
C167
*C242
150P
C217
R179
4.7K
10K
R173
XP6501
Q26
1 2 34
5 6
0.001
C162
0.1
C262
1M
R118
0.001
C225
0.001
C221
0.001
C316
0.001
C189
J1
1 2
3 4
5 6
7 8
9 1 0
11 12
13 14
15 16
47K
R126
DAN235E
D48
220K
R187
UPC2757TB
IC8
1RFI
2GND
3LO 4
PS 5
VCC 6
IFO
0.1
C261
0.01
C253
15K
R188
CP6
Reference Frequency check point; CP6
47P
C168
0.001
C142
UPC2757TB
IC5
1RF I
2GND
3LO 4
PS 5
VCC 6
IFO
0.01
C296
15K
R195
47P
C172
0.1
C228
0.001
C181
12K
R213
MA2S7280G
D50
470P
C266
10
C306
0.001
C206
3.3U
L43
*R150
22P
C244
0.001
C279
UNR9213G0
Q40
0.01
C194
3.3K
R138
0.001
C284
0.001
C139
0.001
C223
0.01
C269
R168
10K
0.001
C188
JTBM450CX24
X3
6.8N
L22
R154
4.7K
UNR9115G0
Q23
0.01
C201
R162
15K
10
C207
0.01
C275
0.1
C263
0.001
C239
100
R109
TA31136FNG
IC13
1OSCIN
2OSCOUT
3M IXOUT
4VCC
5IFIN
6DEC
7FILOUT
8FILIN 9
AFOUT
10
QUAD
11
IFOUT
12
RSSI
13
N-DET
14
N -REC
15
GND
16
MIXIN
0.001
C402
0.001
C406
0.001
C401
MA2S7280G
D45
0.001
C203
EFCH429MKQP1
FI1
I O
22N
L23
3P
C190
10P
C405
4.7K
R141
4.7K
R148
0
R149 3.3U
L41
2.7U
L51
22P
C414
0
R167
4.7K
R172
100
R181
HSJ1456-010320
J4
04-730A3-02BKA
J5
M PZ1608S221A
EP10
0.0047
C415
0.1
C416
M PZ1608S221A
EP9
0.01
C183
MMZ1608D121B
EP6
MMZ1608Y121BT EP11
MMZ1608Y121BT
EP12
1K
R196
150
R98
270K
R101
6.8K
R110
47K
R210
100P
C421
0
R227
3.5P
C174
TC7W53FK
IC9
1COM
2INH
3VEE
4GND 5
A
6
CH1
7
CH0
8
VCC
2SC4738
Q44
MA2S111
D54
MA2S7280G
D55
4.7K
R229
2.2K
R230
0.001
C424
0.001
C425
0.001
C426
2SA1577
Q43
MMZ1608Y121BT
EP13
MMZ1608Y121BT
EP14
22
C423
22
C422
AXK3S50335G
J3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20 31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
21 30
22 29
23 28
24 27
25 26
56K
R225
15P
C226
68K
R236
0.033
C286
UNR9213G0
Q46
0.22
C434
82
R89
UPC2746TB
IC1
1IN
2GND
3GND 4
OUT 5
GND 6
VCC
82
R86
100
R87
0.1
C157
CR-869
X1
1VCONT 2
GND
3
OU T
4VCC
0.01
C435
0
R237
0.1
C158
0.1
C141
15U
L44
82P
C301
120U
L25
3.3U
L65
100P
C249
100P
C246
100P
C245
0.001
C438
0.001
C439
0.001
C440
0.001
C441
0.001
C442
0.001
C443
1.5K
R128
330K
R113
1
C444
47P
C445
120
R85
0.1
C173
33N
L24
1
470P
C403
C293
0.033
C404
0.033
C191
220
R215
15K
R108
PDATA
PSTB1
PCK
WFM
VP
PSTB2
PDATA
PCK
+3V
OSC
PDATA
VCO4
PCK
ATTC
VCO3
VCO1
PSTB2
PSTB1
PS
VCO2
R3V
BAR
R3V
OSC
VCO1
VCO2
VCO3
VCO4
OSC
+3V
WFM
FSET
NOISE
VHFC
800MC
GC
UHFC
PS
R3V
AFO
SPO
CLONE
TUNE
SHIFT3V
FSET
VCC
RSSI
DET
AGCC
WFM
HV
HVE
AFE
VP
PS
R3V
VCC
VCO3V
DET
AGCC
+3V
EAR
VCO3V
AM
AM
OSC
RSSI
+3V
TRAC
ATT
B1C
B2C
ANTSW
HFC
NOISE
R3V
AGC
1st_VCO_OUT
FM DET
AM DET
AM/NFM_CONT
2nd VCO UNIT
1st VCO UNIT
2nd_VCO_OUT
19.200MHz
IF AMP
1st MIXER 2nd MIX
Reference frequency signal AMP
MODE CONT
1 st IF FILTER 2nd IF FILTER
3rd IF FILTER
Ref
EXT SP
EXT DC
RF_AMP
RX RF signals path while the earphone antenna is activated
AM MODE :0.0V
FM MODE :3.1V
WFM MODE:3.1V
RX:0.9V
• MAIN UNIT (Right side)

Feb. 2010
14
*; Refer to “PARTS LIST.”
*; Refer to “PARTS LIST.”
0.001
C41
1SV308
D9
0.68 SVA
C39
220
R25
1SV308
D10
0.1
C61
0.1
C15
1k
R48
0.01
C59
0.001
C56
2SC5006
Q4
0.001
C57
180K
R49
*R39
MB15T61UL
IC3
1SWB1 2DORF1 3SW1 4SW2 5DORF2 6VPRF 7LD/FOUT
8
PS
9
GNDRF
10
XFINRF
11
FINRF2
12
FINRF1
13
VCCRF
14
GNDRF
15
VCCSD
16
LE
17
DATA
18
CLOCK
19
OSCIN
20 GNDOSC
21 SWA2
22 SWB2
23 GNDDIG
24 SWA1
4.7K
R8
15
R41
0.001
C2
0.001
C31
220
R2
0.001
C9
220
R10
HVC417C
D3
*C43
3.3K
R24
8.2K
R4
4.7K
R36
2SK880
Q6
1k
R55
0.1
C24
8.2K
R27
0.1
C62
UPC2746TB
IC2
1IN
2GND
3GND 4
OUT 5
GND 6
VCC
*C49
10
C64
XP1113
Q10
1
2
34
5
0.01
C48
2.7K
R35
82
R53
HVC417C
D4
0.5P
C14
0.001
C63
0.001
C47
1SV308
D8
6.8K
R26
0.001
C44
10
C66
0.001
C52
0.68 SVA
C38
8.2K
R14
0.001
C12
0.1
C13
10
C67
0.1
C6
47
R42
33
R33
2SC5006
Q1
4.7K
R38
2SC5231A 8-E
Q8
J1
1 2
3 4
5 6
7 8
9 1 0
11 12
13 14
15 16
2SC5277A 2-E
Q12
0.01
C40
100K
R29
4.7K
R40
2SC5006
Q3
1k
R56
220
R7
0.001
C5
0.001
C55
0.1
C58
15K
R28
0.5P
C23
0.001
C54
4.7K
R37
1 MSVA
C37
0.001
C10
220
R12
2SC4117
Q7
4.7K
R3
0.001
C25
150
R32
82K
R31
0.0033
C35
0.001
C21
1k
R47
220
R30
10
C65
1k
R57
0.1
C8
0.001
C18
8.2K
R9
1SV308
D7
0.001
C68
0.01
C60
4.7K
R13
XP1113 Q11
1
2
34
5
2SC5006
Q2
1k
R46
0.001
C17
0.1
C22
0.001
C42
1k
R23
0.001
C46
220
R15
0.1U
L15
0.1U
L16
0.1U
L17
0.001
C29
0.001
C26
4.7K
R59
8.2K
R16
0.1
C69
0.1U
L13
220
R17
0.1
C30
10
C70
0.001
C71
0.47U
L19
18P
C27
18P
C28
C2012C
L6
C2012C
L9
100
R1
100
R6
100
R11
220
R18
C2012C
L12
LQW18AN68NG00D
L18
47N
L10
47N
L7
47N
L4
0.22U
L8
22
R34
0.22U
L5
0
R60
0
R61
0
R62
0
R63
LQW18ANR15G00D
L1
LQW18ANR15G00D
L2
HVC417C
D5
1SV309
D2
1SV309
D1
5P
C16
5P
C11
9P
C19
9P
C20
3.5P
C3
3P
C4
1P
C7
1P
C45
150
R19
R65
R64
ERJ2GE-JPW
ERJ2GE-JPW
150
R5
C2012C
L3
*R43
*R44
0.001
C50
2P
C72
2P
C73
*L20
*C74
*L21
*C75
*C76
*C77
*C78
*R66
VP
GND
+3V
VCO1
VCO2
VCO3
VCO4
OSC
GND
GND
PCK
PDATA
PSTB1
PS
PS
VCO3V
1Lo
VCO4
VCO3
VCO2
VCO1
311.9500-520.8999MHz
511.6400-712.0999MHz
700.9000-939.0999MHz
939.1000-1170.1499MHz
BUFF
Loop Filter
PLL
602MHz:0.8
988MHz:0.7
50MHz:0.75V
435MHz:0.75V
V
V
2SC5277A 2-E
Q3
1k
R21
1k
R19
1k
R13
820
R15
0.01
C24
0.001
C25
0.22U
L4
15P
C3
5P
C10
470P
C16
1P
C8
100
R10
5P
C9
33N
L2
18N
L1
1SV314
D1
0.01
C22
1k
R4
1k
R16
56
R9
4.7
C21
22N
L3
5P
C17
0.001
C31
4P
C7
0.001
C27
10
C32
2P
C33
47
R1
0.001
C6
47P
C20
0.33 SVSP
C1
330
R22
2SC4617
Q4
1k
R18
47P
C18
10P
C4
10
R14
M B15E03SLPFV1
IC1
1
OSCI 2
OSCO 3
VP 4
VCC 5
DO 6
GND 7
XFIN 8
FIN
9CLK
10 DAT
11 LE
12 PS
13 ZC
14 L/F
15 P
16 R
47P
C19
FH102A-E
Q1
1
2
3
4
5
6
10K
R2
18P
C2
0.01
C23
0.1
C26
1k
R12
1k
R11
180K
R17
0.001
C30
J1
1 2
3 4
5 6
7 8
9 1 0
11 12
13 14
15 16
15P
C5
1k
R3
3076
MP1 PSTB2
PCK
PDATA
PS
+3V
2Lo
R3V
GND
OSC
PLL
Reference frequency signal Buffer
2ndVCO
409.4500MHz
or
448.7500MHz
RX:1.1V
• 1st VCO UNIT • 2nd VCO UNIT

SERVICE MANUAL
ADDENDUM
CONTENTS
REPLACEMENT PAGE . . . . . . . . . . . . . . . . . . . . . . . 6-1
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 8
Feb. 2009

Feb. 2009 (Replacement page)
6 - 1
[CHASSIS PARTS]
REF ORDER DESCRIPTION QTY.
NO. NO.
J1 6910020160 3076 SMA 1
SP1 2510001490 362P0801 1
W1 8900016000 OPC-1129A 1
MP1 8210024920 3076 FRONT PANEL (Incl. MP15) 1
MP2 8210024870 3076 REAR PANEL 1
MP3 8110009570 3076 BATT COVER 1
MP4 8930076050 3076 LOCK PLATE 1
MP5 8310072210 3076 WINDOW PLATE 1
MP6 8930076060 3076 JACK CAP 1
MP7 8610013760 KNOB N-377 (Incl. MP23) 1
MP8 8930077390 3076 KEYBOARD (A) 1
MP9 8930076290 3076 DETECT BUTTON 1
MP10 8930076300 3076 MAIN SEAL 1
MP11 8930077170 3076 REAR SEAL 1
MP12 8930076320 3076 ANT RUBBER 1
MP13 8930076360 3076 TOP PLATE 1
MP14 8930076600 3076 WINDOW SHEET 1
MP15 8930076620 3076 SP NET 1
MP16 8930067890 2869 PLUS TERMINAL 2
MP17 8930066800 O-RING (BE) 1
MP18 8930059610 SPONGE (HC) 2
MP19 8930051390 2304 SHAFT 1
MP20 8930030920 1301 SHEET 1
MP21 8830000881 VR NUT (I)-1 1
MP22 8830001470 VR NUT (N) 1
MP23 8610007510 KNOB SPRING NO.7800 1
MP24 8810008751 SCREW BT B0 2X15NI-ZK3 (BT) 2
MP25 8810009221 SCREW BT B0 2X8 NI-ZK3 (BT) 2
MP26 8810008641 0TAP 1FLAT WASHER B0 2X4 NI-ZC3 (BT) 8
MP27 8810000101 SCREW PH M2X4 ZK3 1
MP28 8810006791 SCREW PH M2X3.5 ZK3 2
MP29 8510019060 3076 EARTH PLATE 1
MP30 8930062950 SHIELD SPONGE (AF) 1
MP31 8930061120 SHIELD SPONGE (AA) 1
MP32 8930076960 3076 VOL RUBBER 1
MP33 8930076530 3076 SHEET 1
MP34 8930069710 THERMALLY SHEET (BC) 1
MP35 8930076700 INSULATION SHEET (MI) 1
MP38 8930077330 3076 MAGNETIC SHIELD 1
[LOGIC UNIT]
[ACCESSORIES]
[MAIN UNIT]
REF ORDER DESCRIPTION QTY.
NO. NO.
J5 6510021901 BM02B-ASRS-TF (LF) (SN) 1
J6 6510025170 IMSA-9631S-27Y921 1
J7 6510026690 AXK4S50535G 1
DS13 5030003080 KMC9864-A-00-SPI 1
S21 7600000210 TP70N00E2015F-1903 1
EP8 3310003010 KY-058-006-2 1
MP1 8210024910 3076 REFLECTOR 1
MP2 8930076310 3076 LCD HOLDER 1
MP3 8930076690 3076 WHITE SHEET 1
MP4 8930064320 SPONGE (HW) 1
MP5 8930039831 THERMALLY SHEET (D)-1 1
MP6 8930076830 3076 DCDC SHIELD 1
MP7 8510019070 3076 LOGIC SHIELD 1
REF ORDER DESCRIPTION QTY.
NO. NO.
J1 6510024970 AXK5F16535YJ 1
J2 6510024970 AXK5F16535YJ 1
J3 6510026700 AXK3S50335G 1
J4 6450002250 HSJ1456-010320 1
J5 6450002131 04-730A3-02BKA 1
MP1 8930076971 3076 MAIN SHIELD-1 1
MP2 8930077190 3076 VCO SHEET 1
MP3 8930076930 INSULATION SHEET (MH) 1
[1st VCO UNIT]
REF ORDER DESCRIPTION QTY.
NO. NO.
J1 6510024980 AXK6F16335YJ 1
MP1 8510019050 3076 A-VCO CASE 1
MP2 8510019090 3076 VCO PLATE 1
REF ORDER DESCRIPTION QTY.
NO. NO.
EP1** – BP-244 EXP 1
EP2** – BC-149D [EUR-02] 1
– BC-153SA [USA-01] 1
– BC-149A [EXP-01] 1
– BC-153SC [CHN-01] 1
– BC-149A [CAN] 1
EP3** – FA-S270C 1
MP1** – MB-112G 1
MP2 8010018080 STRAP HK-009 1
[2nd VCO UNIT]
REF ORDER DESCRIPTION QTY.
NO. NO.
J1 6510024980 AXK6F16335YJ 1
MP1 8510019030 3076 B-VCO CASE 1
*: Refer to “BOARD LAYOUTS.”
**: Available as an optional product.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
SECTION 6
.
MECHANICAL PARTS
EP1
MP2 EP3
MP1
EP2

Feb. 2009
1
SECTION 6
.
PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
IC1 1110005180 S.IC UPC2746TB-E3 B 9.4/20.9
IC5 1110005230 S.IC UPC2757TB-E3 B 15.2/19.4
IC8 1110005230 S.IC UPC2757TB-E3 B 29.6/21.7
IC9 1130009981 S.IC TC7W53FK(TE85L,F) B 24/4.3
IC13 1110003201 S.IC TA31136FNG(EL) B 38.1/15.8
Q2 1530003990 S.TRA 2SC4738-BL(TE85L,F) T 17.9/45
Q3 1590001660 S.TRA XP4312(TX) T 21.7/43.2
Q5 1530003810 S.TRA 2SC5008-T1 B 14/30.1
Q6 1530003781 S.TRA 2SC5624VH-TL-E B 9.8/27.8
Q7 1530003612 S.TRA FH102A-TR-E B 22.7/35.3
Q11 1590001680 S.TRA XP1110(TX) B 31.8/38.7
Q12 1530003260 S.TRA 2SC5006-T1 B 28.4/27.6
Q17 1590001810 S.TRA XP1113(TX) B 31.8/36.2
Q18 1590001810 S.TRA XP1113(TX) B 3.2/16.9
Q19 1590001810 S.TRA XP1113(TX) B 5.7/16.9
Q23 1590003250 S.TRA UNR9115J-(TX) B 29/11.4
Q25 1590001190 S.TRA XP6501-(TX).AB B 27.5/9.2
Q26 1590001190 S.TRA XP6501-(TX).AB B 32.3/8.5
Q31 1530003260 S.TRA 2SC5006-T1 B 43.2/22.7
Q36 1530003260 S.TRA 2SC5006-T1 T 39/24.3
Q37 1590002010 S.TRA XP1114(TX) B 28.9/15.8
Q38 1590002010 S.TRA XP1114(TX) T 41.3/21.1
Q39 1590003290 S.TRA UNR9213J-(TX) B 29/13.4
Q40 1590003290 S.TRA UNR9213J-(TX) T 43.7/21.2
Q41 1530003260 S.TRA 2SC5006-T1 B 2.2/32.6
Q42 1530003260 S.TRA 2SC5006-T1 B 1.3/30.3
Q43 1510001110 S.TRA 2SA1577T106R B 11.1/16.6
Q44 1530003990 S.TRA 2SC4738-BL(TE85L,F) B 12.4/13.5
Q45 1590003250 S.TRA UNR9115J-(TX) B 40.4/38
Q46 1590003290 S.TRA UNR9213J-(TX) B 29.8/5.2
Q47 1590003230 S.TRA UNR9113J-(TX) T 21.2/39
D1 1720000241 S.DIO 1SV172(TE85R,F) T 14.8/39.5
D2 1790001260 S.DIO MA2S077-(TX) T 17.8/38.9
D4 1790001621 S.DIO 1SV308(TPL3,F) B 25.5/39.6
D5 1790001621 S.DIO 1SV308(TPL3,F) T 23.7/38.2
D7 1790001621 S.DIO 1SV308(TPL3,F) B 16.5/39.4
D8 1790001621 S.DIO 1SV308(TPL3,F) B 14.5/38.4
D9 1790001621 S.DIO 1SV308(TPL3,F) B 17.6/37.7
D10 1790001621 S.DIO 1SV308(TPL3,F) B 16.4/37.7
D12 1750000721 S.VAR HVC375BTRF-E B 18.8/33.1
D13 1750000721 S.VAR HVC375BTRF-E B 18/31.4
D14 1790001240 S.DIO MA2S728-(TX) B 25.5/34.1
D15 1790001240 S.DIO MA2S728-(TX) B 26.8/34.1
D18 1790001240 S.DIO MA2S728-(TX) B 5.3/31.1
D19 1790001240 S.DIO MA2S728-(TX) B 5.3/33.6
D20 1790001240 S.DIO MA2S728-(TX) B 12.1/31.2
D21 1790001240 S.DIO MA2S728-(TX) B 12.1/32.4
D22 1790001240 S.DIO MA2S728-(TX) B 6.5/28.8
D23 1790001240 S.DIO MA2S728-(TX) B 6.5/31.3
D25 1750000721 S.VAR HVC375BTRF-E B 15.6/27.6
D26 1750000721 S.VAR HVC375BTRF-E B 17.4/28.4
D27 1790001621 S.DIO 1SV308(TPL3,F) B 30.8/34.3
D28 1790001621 S.DIO 1SV308(TPL3,F) B 28.1/34.3
D29 1790001621 S.DIO 1SV308(TPL3,F) T 28.4/35.2
D31 1720000840 S.VAR HVD328CKRU-E B 20.5/30
D32 1750000711 S.VAR HVC350BTRF-E B 2.4/27.3
D33 1790001240 S.DIO MA2S728-(TX) B 25.5/30.9
D34 1790001240 S.DIO MA2S728-(TX) B 26.8/30.9
D35 1720000840 S.VAR HVD328CKRU-E B 22.9/28
D36 1750000711 S.VAR HVC350BTRF-E B 3.3/23.1
D37 1790001621 S.DIO 1SV308(TPL3,F) B 25.7/24
D38 1790001621 S.DIO 1SV308(TPL3,F) B 23/24.2
D40 1790001621 S.DIO 1SV308(TPL3,F) B 3.3/21
D41 1790001621 S.DIO 1SV308(TPL3,F) B 12.3/24
D42 1790001621 S.DIO 1SV308(TPL3,F) B 9.1/24
D44 1750001070 S.DIO DAN235ETL B 32.7/25
D45 1790001240 S.DIO MA2S728-(TX) B 32.3/6.1
D47 1750001070 S.DIO DAN235ETL B 38.3/8.3
D48 1750001070 S.DIO DAN235ETL B 42.3/8.8
D49 1750001070 S.DIO DAN235ETL B 44.4/27.5
D50 1790001240 S.DIO MA2S728-(TX) B 41.9/24.3
D51 1790001260 S.DIO MA2S077-(TX) B 21.1/31.2
D52 1790001260 S.DIO MA2S077-(TX) B 20.2/25.5
D53 1720000821 S.VAR SVC347S/T-TL-E T 30.6/39.9
D54 1790001250 S.DIO MA2S111-(TX) B 13/16.7
D55 1790001240 S.DIO MA2S728-(TX) B 14.8/14
D56 1790001621 S.DIO 1SV308(TPL3,F) B 28.8/40.7
D57 1790001260 S.DIO MA2S077-(TX) B 21.7/42.1
D58 1790001260 S.DIO MA2S077-(TX) B 24.7/27.6
FI1 2040001190 S.SAW EFCH429MKQP1 B 22.4/20.1
FI2 2010002280 S.MON 19S15A 19.650 MHz(FL-293) B 37.3/25.4
FI3 2020002170 S.CER ELFY450E T 29.5/6.3
X1 6050012790 S.XTA CR-869 DSA321SC 19.2 MHz T 37.4/27.1
X3 6070000191 S.DIS CDBKB450KCAY24-R0 T 38.6/16.1
L1 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) B 7.1/37.6
L2 6200010630 S.COI LQW18AN8N2D00D B 12/35.7
L3 6200007001 S.COI ELJRE 82NGFA B 22.1/38.1
S.=Surface mount
[MAIN UNIT]
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
L4 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) B 4.4/37
L5 6200010130 S.COI LQW18AN6N8C00D B 8.4/34.9
L7 6200009220 S.COI LQW18AN15NG00D
(LQW1608A15NG00) B 2.6/36.1
L8 6200010120 S.COI LQW18AN5N6C00D B 9.1/33
L10 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) B 1.8/34.3
L11 6200005601 S.COI ELJRE 3N3ZFA B 18.1/35
L12 6200005631 S.COI ELJRE 5N6ZFA B 17.6/33.1
L13 6200010130 S.COI LQW18AN6N8C00D B 9.1/30.4
L15 6200010130 S.COI LQW18AN6N8C00D B 9.9/25.8
L16 6200009280 S.COI LQW18AN27NG00D
(LQW1608A27NG00) B 23.5/32.4
L18 6200005611 S.COI ELJRE 3N9ZFA B 12.3/29.3
L19 6200005591 S.COI ELJRE 2N7ZFA B 13.1/27.4
L20 6200009280 S.COI LQW18AN27NG00D
(LQW1608A27NG00) B 22.9/26.9
L21 6200002041 S.COI NLV25T-101J B 28.6/24.3
L22 6200005641 S.COI ELJRE 6N8ZFA B 12.8/20.8
L23 6200005701 S.COI ELJRE 22NGFA B 17.9/18.4
L24 6200005721 S.COI ELJRE 33NGFA B 27.8/19.1
L25 6200002971 S.COI NLV32T-121J T 33.5/13.9
L29 6200013520 S.COI NLFC322522T-151K-PF T 26.8/40.1
L31 6200005051 S.COI NLV25T-330J T 34.7/39.2
L33 6200004720 S.COI MLF1608D R10K-T B 26.3/37.8
L34 6200004600 S.COI MLF1608D R15K-T B 28.1/31.7
L36 6200005651 S.COI ELJRE 8N2ZFA B 2.4/28.5
L38 6200004600 S.COI MLF1608D R15K-T B 29.3/30.1
L40 6200008570 S.COI LQW2BHN6N8D03L B 3.7/24.8
L41 6200007170 S.COI MLF1608A 3R3K-T B 35.9/22.7
L43 6200007170 S.COI MLF1608A 3R3K-T B 41.5/22.5
L44 6200006380 S.COI ELJFC 150K B 33.1/19.6
L50 6200009220 S.COI LQW18AN15NG00D
(LQW1608A15NG00) B 8.9/36.8
L51 6200006960 S.COI MLF1608A 2R7K-T B 42/27
L52 6200011670 S.COI LQW18AN82NG00D B 20.9/32.4
L53 6200011670 S.COI LQW18AN82NG00D B 20.2/26.8
L54 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) B 10.1/36.6
L55 6200009250 S.COI LQW18ANR22G00D
(LQW1608AR22G00) B 12.9/36.9
L56 6200009250 S.COI LQW18ANR22G00D
(LQW1608AR22G00) B 15.2/40.6
L60 6200005641 S.COI ELJRE 6N8ZFA B 15.5/32.2
L61 6200011770 S.COI LQW18ANR10G00D B 18.4/43.9
L62 6200009070 S.COI LQW18AN18NG00D
(LQW1608A18NG00) B 21.3/40
L63 6200011770 S.COI LQW18ANR10G00D B 19.8/43.9
L64 6200011770 S.COI LQW18ANR10G00D B 25.9/27.6
L65 6200007170 S.COI MLF1608A 3R3K-T [USA-01] only
R1 7030005120 S.RES ERJ2GEJ 102 X (1K) B 13.3/40.3
R2 7030005570 S.RES ERJ2GEJ 820 X (82) T 17/40.4
R3 7030007280 S.RES ERJ2GEJ 331 X (330) T 18.2/39.9
R4 7030005570 S.RES ERJ2GEJ 820 X (82) T 18.2/40.8
R5 7030009140 S.RES ERJ2GEJ 272 X (2.7K) T 20.6/40.4
R11 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 18.6/39.4
R13 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 16.4/35.4
R14 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 15.5/35.4
R15 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 19.7/41.8
R16 7030005050 S.RES ERJ2GEJ 103 X (10K) T 19.7/43.6
R22 7030005090 S.RES ERJ2GEJ 104 X (100K) B 18.8/30
R24 7030005090 S.RES ERJ2GEJ 104 X (100K) T 21.3/41.3
R25 7030005120 S.RES ERJ2GEJ 102 X (1K) T 26.3/37.2
R26 7030005290 S.RES ERJ2GEJ 682 X (6.8K) B 23.7/37.8
R27 7030007340 S.RES ERJ2GEJ 153 X (15K) B 26/35.8
R28 7030005290 S.RES ERJ2GEJ 682 X (6.8K) B 0.75/32.8
R29 7030007340 S.RES ERJ2GEJ 153 X (15K) B 4.2/28.3
R31 7030007280 S.RES ERJ2GEJ 331 X (330) B 20.7/37.1
R32 7030007280 S.RES ERJ2GEJ 331 X (330) B 3.9/34.1
R34 7030005240 S.RES ERJ2GEJ 473 X (47K) B 14.2/31.5
R35 7030008010 S.RES ERJ2GEJ 123 X (12K) B 14.2/32.4
R36 7030005240 S.RES ERJ2GEJ 473 X (47K) B 7.8/29.6
R37 7030008010 S.RES ERJ2GEJ 123 X (12K) B 7.8/28.7
R38 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 20.7/38.9
R41 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 2.7/29.9
R43 7030005120 S.RES ERJ2GEJ 102 X (1K) B 27.8/38.5
R44 7030005120 S.RES ERJ2GEJ 102 X (1K) T 28.4/36.8
R45 7030005710 S.RES ERJ2GEJ 121 X (120) B 16/29.6
R46 7030007280 S.RES ERJ2GEJ 331 X (330) B 7.8/26
R49 7030005090 S.RES ERJ2GEJ 104 X (100K) B 15.8/28.6
R52 7030005090 S.RES ERJ2GEJ 104 X (100K) B 18.5/27.9
R54 7030005120 S.RES ERJ2GEJ 102 X (1K) [EUR-01] B 22.3/33.5
7030005120 S.RES ERJ2GEJ 102 X (1K) [UK-01]
7030007300 S.RES ERJ2GEJ 332 X (3.3K) [USA-01]
7030005120 S.RES ERJ2GEJ 102 X (1K) [EXP-01]
7030005120 S.RES ERJ2GEJ 102 X (1K) [CHN-01]
7030005120 S.RES ERJ2GEJ 102 X (1K) [CAN-01]
R57 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 33/34.3
R60 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 30/35.6
R61 7030005090 S.RES ERJ2GEJ 104 X (100K) B 22.1/29.9
R62 7030005240 S.RES ERJ2GEJ 473 X (47K) B 0.75/25.9
R65 7030005050 S.RES ERJ2GEJ 103 X (10K) B 27/29.3
R66 7030005240 S.RES ERJ2GEJ 473 X (47K) B 27/28.1
R67 7030004980 S.RES ERJ2GEJ 101 X (100) B 30.2/27.3
R68 7030005090 S.RES ERJ2GEJ 104 X (100K) B 21.4/28.2

Feb. 2009
2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
R69 7030005240 S.RES ERJ2GEJ 473 X (47K) B 0.75/24.3
R73 7030005580 S.RES ERJ2GEJ 560 X (56) B 22.5/25.3
R75 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 2.9/22.1
R76 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 13.3/26.1
R77 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 7.8/24.2
R78 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 10.5/22.9
R85 7030005710 S.RES ERJ2GEJ 121 X (120) B 15.3/21.4
R86 7030005570 S.RES ERJ2GEJ 820 X (82) B 11.5/19.4
R87 7030004980 S.RES ERJ2GEJ 101 X (100) B 11.5/18.5
R89 7030005570 S.RES ERJ2GEJ 820 X (82) B 12.7/18.7
R97 7030005300 S.RES ERJ2GEJ 150 X (15) B 15.3/16.4
R98 7030007270 S.RES ERJ2GEJ 151 X (150) B 16.5/16
R101 7030005700 S.RES ERJ2GEJ 274 X (270K) T 40.2/28
R108 7030007340 S.RES ERJ2GEJ 153 X (15K) B 27.5/5.6
R109 7030004980 S.RES ERJ2GEJ 101 X (100) B 27.4/11.4
R110 7030005290 S.RES ERJ2GEJ 682 X (6.8K) T 35.6/24.7
R113 7030005230 S.RES ERJ2GEJ 334 X (330K) B 25.7/8.9
R114 7030005220 S.RES ERJ2GEJ 223 X (22K) B 26.6/7.2
R118 7030005160 S.RES ERJ2GEJ 105 X (1M) B 23.9/8.9
R126 7030005240 S.RES ERJ2GEJ 473 X (47K) B 30.5/10.5
R128 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 29.4/8.8
R129 7030005090 S.RES ERJ2GEJ 104 X (100K) B 30.3/8.8
R138 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 29.5/7.2
R141 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 31.1/25.4
R142 7030005100 S.RES ERJ2GEJ 154 X (150K) B 33.3/6.3
R143 7030005100 S.RES ERJ2GEJ 154 X (150K) B 31.2/5.7
R148 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 32.9/23.5
R149 7030010040 S.RES ERJ2GEJ-JPW B 33.8/22.6
R150 7030003290 S.RES ERJ3GEYJ 560 V (56) [EUR-01] B 33.4/27.4
7030003290 S.RES ERJ3GEYJ 560 V (56) [UK-01]
7030003290 S.RES ERJ3GEYJ 560 V (56) [EXP-01]
7030003290 S.RES ERJ3GEYJ 560 V (56) [CHN-01]
7030003290 S.RES ERJ3GEYJ 560 V (56) [CAN-01]
R154 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 39.7/7.4
R157 7030005050 S.RES ERJ2GEJ 103 X (10K) B 39.7/6.5
R162 7030007340 S.RES ERJ2GEJ 153 X (15K) T 30.1/13.2
R167 7030010040 S.RES ERJ2GEJ-JPW B 43.2/25.9
R168 7030005050 S.RES ERJ2GEJ 103 X (10K) B 41.7/7.4
R169 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 44.2/9.3
R172 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 44.5/29.2
R173 7030005050 S.RES ERJ2GEJ 103 X (10K) B 32.3/27.8
R179 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 40.3/8.8
R181 7030004980 S.RES ERJ2GEJ 101 X (100) B 45.8/25.7
R184 7030005090 S.RES ERJ2GEJ 104 X (100K) B 34.5/13.9
R185 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 34.5/15.7
R187 7030005110 S.RES ERJ2GEJ 224 X (220K) B 44.5/24.5
R188 7030007340 S.RES ERJ2GEJ 153 X (15K) B 43.6/24.5
R189 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 39.2/11.5
R190 7030005240 S.RES ERJ2GEJ 473 X (47K) B 32.9/15.7
R194 7030005120 S.RES ERJ2GEJ 102 X (1K) B 44.2/20.4
R195 7030007340 S.RES ERJ2GEJ 153 X (15K) B 31.5/14.5
R196 7030005120 S.RES ERJ2GEJ 102 X (1K) B 32.2/13.3
R203 7030009160 S.RES ERJ2GEJ 181 X (180) B 41.3/19.8
R204 7030005000 S.RES ERJ2GEJ 471 X (470) B 34.5/16.6
R210 7030005240 S.RES ERJ2GEJ 473 X (47K) B 41.4/16.5
R213 7030008010 S.RES ERJ2GEJ 123 X (12K) T 40.9/23.9
R214 7030005010 S.RES ERJ2GEJ 681 X (680) T 36.8/20.4
R215 7030004990 S.RES ERJ2GEJ 221 X (220) B 36.6/20.5
R216 7030007310 S.RES ERJ2GEJ 155 X (1.5M) T 40.5/25.1
R218 7030005120 S.RES ERJ2GEJ 102 X (1K) T 35.6/23.1
R221 7030007280 S.RES ERJ2GEJ 331 X (330) B 28.2/26
R222 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 23/29.3
R223 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 20.4/24.5
R224 7030005090 S.RES ERJ2GEJ 104 X (100K) T 27.7/38.1
R225 7030005720 S.RES ERJ2GEJ 563 X (56K) B 27.5/2.6
R226 7030010040 S.RES ERJ2GEJ-JPW B 4/32.3
R227 7030010040 S.RES ERJ2GEJ-JPW B 36.7/6.9
R228 7030005060 S.RES ERJ2GEJ 333 X (33K) B 7.8/41.6
R229 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 14.9/15.1
R230 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 12/11.8
R232 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 38.4/38.9
R233 7030010040 S.RES ERJ2GEJ-JPW B 36/39.9
R234 7030005120 S.RES ERJ2GEJ 102 X (1K) B 27.1/40.3
R236 7030005070 S.RES ERJ2GEJ 683 X (68K) B 12.9/11.8
R237 7030010040 S.RES ERJ2GEJ-JPW B 41.4/14.8
R238 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 18/41.9
R239 7030007250 S.RES ERJ2GEJ 220 X (22) B 23.9/33.5
R240 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 23.2/40.7
R241 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 8.9/4.5
R242 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 25.9/25.9
R243 7030005090 S.RES ERJ2GEJ 104 X (100K) T 22.7/37.9
C2 4030016930 S.CER ECJ0EB1A104K T 13.4/38
C3 4030016930 S.CER ECJ0EB1A104K T 16.1/38
C4 4030016930 S.CER ECJ0EB1A104K T 19.4/38.3
C6 4030016930 S.CER ECJ0EB1A104K T 19.4/40.6
C7 4030017460 S.CER ECJ0EB1E102K T 17.6/43.1
C8 4030017460 S.CER ECJ0EB1E102K B 19.5/38.2
C9 4030017460 S.CER ECJ0EB1E102K B 15.1/37.1
C10 4030017460 S.CER ECJ0EB1E102K B 14.8/33.9
C11 4030017460 S.CER ECJ0EB1E102K B 13.2/33.7
C12 4030017460 S.CER ECJ0EB1E102K T 23.6/41.5
C15 4030017380 S.CER ECJ0EC1H050B B 9.7/39.1
C16 4030017460 S.CER ECJ0EB1E102K B 17.7/36
C17 4030016790 S.CER ECJ0EB1C103K T 18.5/43.1
C18 4030017460 S.CER ECJ0EB1E102K T 19.9/44.8
C19 4030017360 S.CER ECJ0EC1H030B B 7.8/36.2
C22 4030017600 S.CER ECJ0EC1H080C B 14.6/35.4
C23 4030017460 S.CER ECJ0EB1E102K T 19.7/42.7
C24 4030017460 S.CER ECJ0EB1E102K B 20.7/38
C25 4030017390 S.CER ECJ0EC1H180J B 13.7/35.4
C29 4030017350 S.CER ECJ0EC1H020B B 12.3/34.6
C30 4030016790 S.CER ECJ0EB1C103K B 20.9/44.2
S.=Surface mount
[MAIN UNIT]
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
C31 4030017460 S.CER ECJ0EB1E102K T 23.6/40.6
C34 4030017590 S.CER ECJ0EC1H070C B 6.3/36.2
C35 4030017420 S.CER ECJ0EC1H470J B 10.6/34.6
C37 4030017340 S.CER ECJ0EC1H010B B 5.1/38.3
C38 4030017360 S.CER ECJ0EC1H030B B 11.4/33.7
C40 4030017380 S.CER ECJ0EC1H050B B 3.9/35.9
C41 4030017340 S.CER ECJ0EC1H010B B 7.7/33.8
C43 4030017340 S.CER ECJ0EC1H010B B 10.2/33.3
C46 4030017600 S.CER ECJ0EC1H080C B 3.9/35
C47 4030017350 S.CER ECJ0EC1H020B B 7.7/32.9
C49 4030016930 S.CER ECJ0EB1A104K T 25.1/37.7
C51 4030017730 S.CER ECJ0EB1E471K B 8.1/31.7
C52 4030017420 S.CER ECJ0EC1H470J T 21.5/45
C61 4030017460 S.CER ECJ0EB1E102K B 16.6/33.4
C68 4030017460 S.CER ECJ0EB1E102K B 20.7/36.2
C69 4030017460 S.CER ECJ0EB1E102K B 3.9/33.2
C70 4030016930 S.CER ECJ0EB1A104K T 30.5/35.2
C72 4030016930 S.CER ECJ0EB1A104K B 29/38.1
C73 4030016930 S.CER ECJ0EB1A104K T 27.5/36.8
C75 4030017730 S.CER ECJ0EB1E471K B 16/30.5
C76 4030017730 S.CER ECJ0EB1E471K B 7.8/26.9
C80 4030017460 S.CER ECJ0EB1E102K B 20.7/35.3
C81 4030017460 S.CER ECJ0EB1E102K B 4/30.4
C82 4030017660 S.CER ECJ0EC1H330J B 27.8/37.6
C83 4030017420 S.CER ECJ0EC1H470J B 30.7/32.6
C84 4030017390 S.CER ECJ0EC1H180J B 20.7/34.4
C86 4030017600 S.CER ECJ0EC1H080C B 3.6/31.4
C87 4030017600 S.CER ECJ0EC1H080C B 27.3/36.4
C88 4030017610 S.CER ECJ0EC1H090C B 29.1/32.2
C90 4030017660 S.CER ECJ0EC1H330J B 28.5/35.9
C91 4030017680 S.CER ECJ0EC1H820J B 30.7/30.8
C93 4030017460 S.CER ECJ0EB1E102K B 14.2/28.6
C94 4030017730 S.CER ECJ0EB1E471K B 7.8/27.8
C96 4030017560 S.CER ECJ0EC1H2R5B B 10.4/24.7
C98 4030017460 S.CER ECJ0EB1E102K B 20.7/33.5
C99 4030017460 S.CER ECJ0EB1E102K B 4/29.5
C100 4030017730 S.CER ECJ0EB1E471K B 17.6/30
C101 4030017460 S.CER ECJ0EB1E102K B 7.8/25.1
C102 4030016790 S.CER ECJ0EB1C103K B 32.5/33.1
C104 4030017360 S.CER ECJ0EC1H030B B 28.2/29.6
C106 4030017440 S.CER ECJ0EC1H221J B 23.3/30.5
C107 4030017460 S.CER ECJ0EB1E102K B 0.75/27.8
C108 4030016930 S.CER ECJ0EB1A104K B 34.6/34.3
C110 4030017420 S.CER ECJ0EC1H470J B 30.7/29.3
C113 4030017460 S.CER ECJ0EB1E102K B 20.2/28.8
C115 4030017460 S.CER ECJ0EB1E102K B 12.3/26.1
C116 4030017460 S.CER ECJ0EB1E102K B 5.9/26.8
C117 4030017460 S.CER ECJ0EB1E102K B 15.2/26.5
C118 4030016930 S.CER ECJ0EB1A104K B 29.1/33.8
C119 4030017350 S.CER ECJ0EC1H020B B 23.9/29.3
C120 4030017350 S.CER ECJ0EC1H020B B 1.6/25.9
C122 4030017440 S.CER ECJ0EC1H221J B 20.2/27.9
C123 4030017460 S.CER ECJ0EB1E102K B 1.6/24.3
C124 4030016930 S.CER ECJ0EB1A104K B 30.2/28.2
C127 4030017460 S.CER ECJ0EB1E102K B 34.6/39.6
C128 4030017460 S.CER ECJ0EB1E102K B 34.6/37.8
C129 4030017460 S.CER ECJ0EB1E102K B 18.1/26
C131 4030017460 S.CER ECJ0EB1E102K B 4.5/22.1
C132 4030017460 S.CER ECJ0EB1E102K B 6.5/33.9
C133 4030017660 S.CER ECJ0EC1H330J B 23.7/25.5
C135 4030017590 S.CER ECJ0EC1H070C B 1.6/22.7
C136 4030016930 S.CER ECJ0EB1A104K B 29.8/26
C137 4030017460 S.CER ECJ0EB1E102K B 34.6/38.7
C138 4030017460 S.CER ECJ0EB1E102K B 34.6/36.9
C139 4030017460 S.CER ECJ0EB1E102K T 17.8/12.8
C141 4030016930 S.CER ECJ0EB1A104K B 8.1/22.9
C142 4030017460 S.CER ECJ0EB1E102K T 20.9/18.7
C145 4030017460 S.CER ECJ0EB1E102K B 7.4/16.8
C146 4030017460 S.CER ECJ0EB1E102K B 2.7/19.2
C147 4030017460 S.CER ECJ0EB1E102K B 4.9/19.7
C150 4030017460 S.CER ECJ0EB1E102K B 34.6/35.5
C151 4030017460 S.CER ECJ0EB1E102K B 3.9/19.7
C152 4030017460 S.CER ECJ0EB1E102K B 6.4/19.7
C157 4030016930 S.CER ECJ0EB1A104K B 11.2/21.3
C158 4030016930 S.CER ECJ0EB1A104K B 10.3/18.9
C162 4030017460 S.CER ECJ0EB1E102K T 28.1/15.9
C167 4030017420 S.CER ECJ0EC1H470J T 12.7/19.4
C168 4030017420 S.CER ECJ0EC1H470J T 12.7/20.3
C172 4030017420 S.CER ECJ0EC1H470J T 13.2/24.4
C173 4030016930 S.CER ECJ0EB1A104K B 14.4/21.4
C174 4030017370 S.CER ECJ0EC1H3R5B B 14.9/17.6
C178 4030017420 S.CER ECJ0EC1H470J T 14.1/24.4
C181 4030017460 S.CER ECJ0EB1E102K T 40.2/27.1
C183 4030016790 S.CER ECJ0EB1C103K B 36/38.3
C187 4030016790 S.CER ECJ0EB1C103K T 40.2/26.2
C188 4030017460 S.CER ECJ0EB1E102K B 16.5/17.6
C189 4030017460 S.CER ECJ0EB1E102K B 30.5/12.4
C190 4030017360 S.CER ECJ0EC1H030B B 17.4/20.1
C191 4030017040 S.CER ECJ0EB1A333K B 27.5/7.2
C194 4030016790 S.CER ECJ0EB1C103K B 25.7/7.2
C201 4030016790 S.CER ECJ0EB1C103K B 25.6/10.6
C203 4030017460 S.CER ECJ0EB1E102K B 27.8/22
C206 4030017460 S.CER ECJ0EB1E102K B 29.2/20
C207 4550007600 S.TAN F920J106MPABMA B 32.7/10.6
C208 4030017460 S.CER ECJ0EB1E102K B 24.8/8.9
C217 4030017700 S.CER ECJ0EC1H151J B 30.4/7.2
C220 4030017460 S.CER ECJ0EB1E102K B 30.5/19.2
C221 4030017460 S.CER ECJ0EB1E102K B 34.5/17.5
C223 4030017460 S.CER ECJ0EB1E102K B 31.1/23.8
C225 4030017460 S.CER ECJ0EB1E102K B 28.4/7.2
C226 4030017640 S.CER ECJ0EC1H150J B 34.5/7.2
C228 4030016930 S.CER ECJ0EB1A104K B 26.6/2.6
C239 4030017460 S.CER ECJ0EB1E102K B 40.9/6

Feb. 2009
3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
C242 4030017730 S.CER ECJ0EB1E471K [EUR-01] B 33.2/29.1
4030017730 S.CER ECJ0EB1E471K [UK-01]
4030017420 S.CER ECJ0EC1H470J [USA-01]
4030017730 S.CER ECJ0EB1E471K [EXP-01]
4030017730 S.CER ECJ0EB1E471K [CHN-01]
4030017730 S.CER ECJ0EB1E471K [CAN-01]
C244 4030017400 S.CER ECJ0EC1H220J B 38/22.7
C245 4030017430 S.CER ECJ0EC1H101J T 31/13.2
C246 4030017430 S.CER ECJ0EC1H101J T 29.2/13.2
C247 4030016790 S.CER ECJ0EB1C103K B 38/6.6
C249 4030017430 S.CER ECJ0EC1H101J T 33.9/11.7
C253 4030016790 S.CER ECJ0EB1C103K B 41.8/6
C256 4030016930 S.CER ECJ0EB1A104K B 45.8/9.3
C258 4030016930 S.CER ECJ0EB1A104K B 45.7/29.7
C259 4030016930 S.CER ECJ0EB1A104K B 31.6/26.6
C261 4030016930 S.CER ECJ0EB1A104K B 40.8/10
C262 4030016930 S.CER ECJ0EB1A104K B 38.5/10
C263 4030016930 S.CER ECJ0EB1A104K B 37.1/11.1
C265 4030016930 S.CER ECJ0EB1A104K B 42.3/18.1
C266 4030017730 S.CER ECJ0EB1E471K B 34.5/14.8
C269 4030016790 S.CER ECJ0EB1C103K B 45.4/24.5
C270 4030017730 S.CER ECJ0EB1E471K B 33.3/14.5
C272 4030017460 S.CER ECJ0EB1E102K B 44.2/21.3
C275 4030016790 S.CER ECJ0EB1C103K B 32.4/14.5
C276 4030016790 S.CER ECJ0EB1C103K B 39.4/10
C278 4030016790 S.CER ECJ0EB1C103K B 32/16.6
C279 4030017460 S.CER ECJ0EB1E102K B 42.4/21
C280 4030017460 S.CER ECJ0EB1E102K B 33.3/17
C284 4030017460 S.CER ECJ0EB1E102K B 40.4/22.1
C285 4030017460 S.CER ECJ0EB1E102K B 40.4/20.5
C286 4030017040 S.CER ECJ0EB1A333K B 38.4/20.5
C291 4030016790 S.CER ECJ0EB1C103K T 38.8/22.8
C292 4030016930 S.CER ECJ0EB1A104K T 42.7/18.5
C293 4030017730 S.CER ECJ0EB1E471K B 39.3/20.5
C296 4030016790 S.CER ECJ0EB1C103K T 40/23
C297 4030017680 S.CER ECJ0EC1H820J B 37.5/20.5
C300 4030017730 S.CER ECJ0EB1E471K B 34.8/20.5
C301 4030017680 S.CER ECJ0EC1H820J B 35.7/20.5
C306 4550007600 S.TAN F920J106MPABMA T 43/23.3
C313 4030016790 S.CER ECJ0EB1C103K T 36.5/23.8
C316 4030017460 S.CER ECJ0EB1E102K T 43.6/19.6
C401 4030017460 S.CER ECJ0EB1E102K T 11.9/4.5
C402 4030017460 S.CER ECJ0EB1E102K T 10.7/4.5
C403 4030018860 S.CER ECJ0EB0J105K B 26.6/5
C404 4030017040 S.CER ECJ0EB1A333K B 27.1/3.8
C405 4030017620 S.CER ECJ0EC1H100C B 27.3/20.8
C406 4030017460 S.CER ECJ0EB1E102K T 18.3/13.7
C412 4030017600 S.CER ECJ0EC1H080C B 7.8/39
C413 4030017430 S.CER ECJ0EC1H101J B 8.8/39.1
C414 4030017400 S.CER ECJ0EC1H220J B 41.2/25.6
C415 4030017780 S.CER ECJ0EB1E472K B 36.7/3.2
C416 4030016930 S.CER ECJ0EB1A104K B 32.2/1.1
C417 4030016930 S.CER ECJ0EB1A104K B 23.3/31.4
C418 4030016930 S.CER ECJ0EB1A104K B 18.8/24.5
C419 4030017610 S.CER ECJ0EC1H090C B 12.4/37.9
C420 4030017500 S.CER ECJ0EC1H560J B 11.2/37.5
C421 4030017430 S.CER ECJ0EC1H101J B 41.4/18.1
C422 4550007680 S.TAN TEESVP 0J 226M8R B 14.3/11.8
C423 4550007680 S.TAN TEESVP 0J 226M8R B 8.9/18.1
C424 4030017460 S.CER ECJ0EB1E102K B 16.5/15.1
C425 4030017460 S.CER ECJ0EB1E102K T 12.7/18.4
C426 4030017460 S.CER ECJ0EB1E102K B 10.4/11.3
C427 4030017460 S.CER ECJ0EB1E102K B 38.4/38
C428 4030016930 S.CER ECJ0EB1A104K B 25.9/40.7
C431 4030017460 S.CER ECJ0EB1E102K T 25.5/36
C434 4030018890 S.CER ECJ0EB0J224K B 29.3/3.7
C435 4030016790 S.CER ECJ0EB1C103K T 42.1/24.7
C436 4030017560 S.CER ECJ0EC1H2R5B B 7.8/40.2
C437 4030017460 S.CER ECJ0EB1E102K B 10.9/29.6
C438 4030017460 S.CER ECJ0EB1E102K B 7.1/14.8
C439 4030017460 S.CER ECJ0EB1E102K B 7.2/12.1
C440 4030017460 S.CER ECJ0EB1E102K B 8.2/15.3
C441 4030017460 S.CER ECJ0EB1E102K T 7.8/14.5
C442 4030017460 S.CER ECJ0EB1E102K B 8.8/12.2
C443 4030017460 S.CER ECJ0EB1E102K B 10/12.5
C444 4030018860 S.CER ECJ0EB0J105K B 24.4/10.7
C445 4030017420 S.CER ECJ0EC1H470J T 13/2.4
C446 4030017510 S.CER ECJ0EC1H680J B 17.6/40.4
C447 4030018140 S.CER ECJ0EB1H391K B 17.5/41.7
C448 4030017510 S.CER ECJ0EC1H680J B 19.2/40.4
C449 4030017580 S.CER ECJ0EC1H060C B 18.4/41.8
C450 4030017350 S.CER ECJ0EC1H020B B 19.6/41.3
C451 4030017580 S.CER ECJ0EC1H060C B 19.6/42.2
C452 4030017380 S.CER ECJ0EC1H050B B 21.3/41
C453 4030017460 S.CER ECJ0EB1E102K B 25.9/25
C454 4030017590 S.CER ECJ0EC1H070C B 24.6/25.5
C455 4030017460 S.CER ECJ0EB1E102K B 23.4/39
C456 4030017650 S.CER ECJ0EC1H270J [USA-01] only B 34.4/28.3
J1 6510024971 S.CON AXK5F16537YG [EUR-01] T 17.7/21.6
6510024970 S.CON AXK5F16535YJ [UK-01]
6510024971 S.CON AXK5F16537YG [USA-01]
6510024971 S.CON AXK5F16537YG [EXP-01]
6510024970 S.CON AXK5F16535YJ [CHN-01]
6510024971 S.CON AXK5F16537YG [CAN-01]
J2 6510024971 S.CON AXK5F16537YG [EUR-01] T 28.9/20.4
6510024970 S.CON AXK5F16535YJ [UK-01]
6510024971 S.CON AXK5F16537YG [USA-01]
6510024971 S.CON AXK5F16537YG [EXP-01]
6510024970 S.CON AXK5F16535YJ [CHN-01]
6510024971 S.CON AXK5F16537YG [CAN-01]
J3 6510026700 S.CON AXK3S50335G T 11.9/8.9
J4 6450002250 CON HSJ1456-010320
S.=Surface mount
[MAIN UNIT]
[1st VCO UNIT]
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
J5 6450002131 CON 04-730A3-02BKA
EP6 6910013310 S.BEA MMZ1608D121B B 36/36.2
EP9 6910014690 S.BEA MPZ1608S221A-T B 32.9/3.6
EP10 6910014690 S.BEA MPZ1608S221A-T B 33.8/1.6
EP11 6910014680 S.BEA MMZ1608Y 121BT B 36/33.6
EP12 6910014680 S.BEA MMZ1608Y 121BT B 42/34.4
EP13 6910014680 S.BEA MMZ1608Y 121BT B 34.5/31.8
EP14 6910014680 S.BEA MMZ1608Y 121BT B 39.1/29.4
IC2 1110005180 S.IC UPC2746TB-E3 T 16.5/14.2
IC3 1130011660 S.IC MB15T61ULPVA-G-ER B 10.4/11.8
Q1 1530003260 S.TRA 2SC5006-T1 T 11/3.6
Q2 1530003260 S.TRA 2SC5006-T1 T 8.3/8.1
Q3 1530003260 S.TRA 2SC5006-T1 T 8.3/12.6
Q4 1530003260 S.TRA 2SC5006-T1 T 8.3/17.1
Q6 1560000531 S.FET 2SK880-GR(TE85R,F) B 10.4/16.7
Q7 1530003001 S.TRA 2SC4117-BL(TE85R,F) B 5.3/16.5
Q8 1530003582 S.TRA 2SC5231A-8-TL-E B 18.3/14.6
Q10 1590001810 S.TRA XP1113(TX) B 8.8/2.9
Q11 1590001810 S.TRA XP1113(TX) B 7.1/6.6
Q12 1530003591 S.TRA 2SC5277-D2-TL-E B 11.5/6.6
D1 1750001650 S.VAR 1SV309(TPH3,F) T 5/2
D2 1750001650 S.VAR 1SV309(TPH3,F) T 3.9/3.8
D3 1750001051 S.VAR HVC417CTRU-E T 5/5.7
D4 1750001051 S.VAR HVC417CTRU-E T 5/10.2
D5 1750001051 S.VAR HVC417CTRU-E T 5/14.7
D7 1790001621 S.DIO 1SV308(TPL3,F) T 15.8/6.1
D8 1790001621 S.DIO 1SV308(TPL3,F) T 13.8/9
D9 1790001621 S.DIO 1SV308(TPL3,F) T 13.8/13.5
D10 1790001621 S.DIO 1SV308(TPL3,F) T 15.9/16.1
L1 6200011660 S.COI LQW18ANR15G00D T 3.8/2
L2 6200011660 S.COI LQW18ANR15G00D T 6.2/2
L3 6200010020 S.COI C2012C-12NG-A T 8.4/3.5
L4 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 13.2/4.5
L5 6200009250 S.COI LQW18ANR22G00D
(LQW1608AR22G00) T 3.8/5.9
L6 6200010030 S.COI C2012C-15NG-A T 5.7/8
L7 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 10.5/9.1
L8 6200009250 S.COI LQW18ANR22G00D
(LQW1608AR22G00) T 3.8/10.4
L9 6200010310 S.COI C2012C-27NG-A T 5.7/12.5
L10 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 10.5/13.7
L12 6200010540 S.COI C2012C-47NG-A T 5.7/17
L13 6200011770 S.COI LQW18ANR10G00D T 11.8/17.4
L15 6200011770 S.COI LQW18ANR10G00D T 14.5/2.6
L16 6200011770 S.COI LQW18ANR10G00D T 11.8/7.2
L17 6200011770 S.COI LQW18ANR10G00D T 11.8/11.8
L18 6200011650 S.COI LQW18AN68NG00D T 10/18.6
L19 6200011860 S.COI LQW18ANR47G00D T 3.8/14.9
L20 6200007961 S.COI ELJRF 6N8JFB (6.8) [EUR-01] T 14.1/16.9
6200007961 S.COI ELJRF 6N8JFB (6.8) [UK-01]
6200007961 S.COI ELJRF 6N8JFB (6.8) [USA-01]
6200007961 S.COI ELJRF 6N8JFB (6.8) [CAN-01]
L21 6200007941 S.COI ELJRF 10NJFB [EUR-01] T 16.5/17.2
6200007941 S.COI ELJRF 10NJFB [UK-01]
6200007941 S.COI ELJRF 10NJFB [USA-01]
6200007941 S.COI ELJRF 10NJFB [CAN-01]
R1 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.3/3.1
R2 7030004990 S.RES ERJ2GEJ 221 X (220) T 15.6/1.5
R3 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 12.4/1.5
R4 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 8.7/1.6
R5 7030007270 S.RES ERJ2GEJ 151 X (150) T 16.5/1.5
R6 7030004980 S.RES ERJ2GEJ 101 X (100) T 10.7/7.7
R7 7030004990 S.RES ERJ2GEJ 221 X (220) T 13/6.1
R8 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 9.8/6.1
R9 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 6/6.1
R10 7030004990 S.RES ERJ2GEJ 221 X (220) T 13.9/6.1
R11 7030004980 S.RES ERJ2GEJ 101 X (100) T 10.7/12.3
R12 7030004990 S.RES ERJ2GEJ 221 X (220) T 13/10.6
R13 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 9.8/10.7
R14 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 6/10.6
R15 7030004990 S.RES ERJ2GEJ 221 X (220) T 13.9/10.6
R16 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 6/15.1
R17 7030004990 S.RES ERJ2GEJ 221 X (220) T 11.8/15.3
R18 7030004990 S.RES ERJ2GEJ 221 X (220) T 10.7/17.2
R19 7030007270 S.RES ERJ2GEJ 151 X (150) T 13/15.3
R23 7030005120 S.RES ERJ2GEJ 102 X (1K) B 9.3/14.8
R24 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 8.4/16.6
R25 7030004990 S.RES ERJ2GEJ 221 X (220) B 13.2/15.4
R26 7030005290 S.RES ERJ2GEJ 682 X (6.8K) B 8.4/17.5
R27 7030005210 S.RES ERJ2GEJ 822 X (8.2K) B 7.2/16.7
R28 7030007340 S.RES ERJ2GEJ 153 X (15K) B 3.4/12.3
R29 7030005090 S.RES ERJ2GEJ 104 X (100K) B 15.2/12.6
R30 7030004990 S.RES ERJ2GEJ 221 X (220) B 17.3/13
R31 7030005080 S.RES ERJ2GEJ 823 X (82K) B 18/16
