Icom IC-F3061T User manual

INSTRUCTION MANUAL
This device complies with Part 15 of the FCC Rules. Operation is
subject to the condition that this device does not cause harmful
interference.
iF4063T/S
iF4061T/S
UHF TRANSCEIVERS
iF3063T/S
iF3061T/S
VHF TRANSCEIVERS

i
WORD DEFINITION
RWARNING Personal injury, fire hazard or electric shock
may occur.
CAUTION Equipment damage may occur.
NOTE If disregarded, inconvenience only. No risk
of personal injury, fire or electric shock.
READ ALL INSTRUCTIONS carefully and com-
pletely before using the transceiver.
SAVE THIS INSTRUCTION MANUAL — This
instruction manual contains important operating instructions
for the IC-F3061T/S/F3063T/S VHF TRANSCEIVERS and
IC-F4061T/S/F4063T/S UHF TRANSCEIVERS.
Icom, Icom Inc. and the logo are registered trademarks of Icom
Incorporated (Japan) in the United States, the United Kingdom, Germany,
France, Spain, Russia and/or other countries.
EXPLICIT DEFINITIONS
FCC INFORMATION
• FOR CLASS B UNINTENTIONAL RADIATORS:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in ac-
cordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guaran-
tee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to cor-
rect the interference by one or more of the following meas-
ures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and re-
ceiver.
• Connect the equipment into an outlet on a circuit differ-
ent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV techni-
cian for help.
IMPORTANT

ii
TABLE OF CONTENTS
IMPORTANT...................................................................................... i
EXPLICIT DEFINITIONS................................................................... i
FCC INFORMATION ......................................................................... i
TABLE OF CONTENTS.................................................................... ii
PRECAUTIONS............................................................................... iii
1 ACCESSORIES ......................................................................1−3
 ■ Supplied accessories...............................................................1
 ■ Accessory attachments ...........................................................1
2 PANEL DESCRIPTION ...........................................................4−9
 ■ Front panel...............................................................................4
 ■ Function display.......................................................................6
 ■ Programmable function keys ...................................................7
3 BASIC OPERATION ...........................................................10−11
 ■ Turning power ON..................................................................10
 ■ Channel selection ..................................................................11
 ■ Call procedure .......................................................................11
4 LTR OPERATION................................................................12−13
 ■ Receiving a call......................................................................12
 ■ Transmitting a call ..................................................................13
5 CONVENTIONAL OPERATION..........................................14−17
 ■ Receiving and transmitting ....................................................14
 ■ User set mode .......................................................................16
 ■ Emergency transmission ....................................................... 17
 ■ Scrambler function.................................................................17
 ■ Stun function..........................................................................17
 ■ Priority A channel selection ...................................................17
6 BATTERY CHARGING .......................................................18−22
 ■ Caution ..................................................................................18
 ■ Optional battery chargers ......................................................20
7 BATTERY CASE .......................................................................23
 ■ Optional battery case (BP-240) .............................................23
8 SWIVEL BELT CLIP ...........................................................24−25
 ■ MB-93 contents......................................................................24
 ■ Attaching................................................................................24
 ■ Detaching...............................................................................25
9 OPTIONS ............................................................................26−28
10 SAFETY TRAINING INFORMATION ..................................29−30

iii
PRECAUTIONS
RCAUTION! NEVER hold the transceiver so that
the antenna is very close to, or touching exposed parts of
the body, especially the face or eyes, while transmitting. The
transceiver will perform best if the microphone is 2 to 4 in. (5
to 10 cm) away from the lips and the transceiver is vertical.
RCAUTION! NEVER operate the transceiver with a
headset or other audio accessories at high volume levels.
RCAUTION! NEVER short the terminals of the bat-
tery pack.
RCAUTION! NEVER use non-Icom battery packs/
chargers to prevent the loss of the transceiver’s good per-
formance and warranty.
DO NOT push [PTT] when not actually desiring to transmit.
DO NOT use or place the transceiver in direct sunlight or
in areas with temperatures below +22°F (–30°C) or above
+140°F (+60°C).
The basic operations, transmission and reception of the
transceiver are guaranteed within the specified operating
temperature range. However, the LCD display may not be
operated correctly, or show an indication in the case of long
hours of operation, or after being placed in extremely cold
areas.
DO NOT modify the transceiver for any reason.
KEEP the transceiver away from the heavy rain, and
Never immerse it in the water. The transceiver construction
is water resistant, not waterproof.
Icom optional equipment is designed for optimal perform-
ance when used with this transceiver. We are not respon-
sible for the transceiver being damaged or any accident
caused when using non-Icom optional equipment.
For U.S.A only
CAUTION: Changes or modifications to this transceiver, not
expressly approved by Icom Inc., could void your authority to
operate this transceiver under FCC regulations.

1
1
ACCESSORIES
■Supplied accessories
The following accessories are supplied: Qty.
qFlexible antenna.............................................................. 1
wBattery pack .................................................................... 1
eBelt clip ........................................................................... 1
rConnector cover (with screw).................................... 1 set
Some accessories are not supplied with depending on versions.
■Accessory attachments
DFlexible antenna
Connect the supplied flexible antenna to
the antenna connector.
CAUTION!
• NEVER HOLD the antenna when
carrying the transceiver.
• Transmitting without an antenna
may damage the transceiver.
q w e
r
1

2
1ACCESSORIES
DBattery pack
To attach the battery pack:
Slide the battery pack in the direction of the arrow (q), then
lock it with the battery release button.
• Slide the battery pack until the battery release button makes a
‘click’ sound.
To release the battery pack:
Slide the battery release button in the direction of the arrow
(w) as shown below. The battery pack is then released.
NEVER release or attach the battery pack when the
transceiver is wet or soiled. This may result water or dust
getting into the transceiver/battery pack and may result in
the transceiver being damaged.
DBelt clip
To attach the belt clip:
qRelease the battery pack if it is attached.
wSlide the belt clip in the direction of the arrow until the belt
clip is locked and makes a ‘click’ sound.
To detach the belt clip:
qRelease the battery pack if it is attached.
wPinch the clip (q), and slide the belt clip in the direction
of the arrow (w).
q
w
q
w
Battery release button

3
1
ACCESSORIES
1
DConnector cover
Attach the connector cover when the optional speaker-
microphone or head-set is not used.
To attach the connector cover:
qInsert the connector cover into the multi-connector.
wTighten the screw.
CAUTION!
Attach the connector cover when the optional speaker-
microphone or head-set is not used.
Otherwise the terminals of the multi-connector may be
shorted by metal object, etc., and this could damage the
transceiver.
To detach the connector cover:
qUnscrew the screw using a phillips screwdriver.
wDetach the connector cover for the speaker-microphone
or head-set connector.
q
w
q
w
Multi-
connector
Connector
cover

4
2PANEL DESCRIPTION
■Front panel
qROTARY SELECTOR
 
Rotate to select the pre-programmed memory channels
or the operating zone.
(Depending on the pre-setting)
wANTENNA CONNECTOR
Connects the supplied antenna.
eDEALER-PROGRAMMABLE KEY [Emer]
 
Desired functions can be programmed by your dealer.
(p. 6)
rDEALER-PROGRAMMABLE KEY [Side1]
 
Desired functions can be programmed by your dealer.
(p. 6)
tPTT SWITCH [PTT]
Push and hold to transmit; release to receive.
yDEALER-PROGRAMMABLE KEYS [Side2]/[Side3]
 
Desired functions can be programmed independently by
your dealer. (p. 6)
u10-KEYPAD (Depending on version)
 
The keypad allows you to enter digits to:
• Select memory channels
• Select tone channels
• Select DTMF codes (during transmit)
• Set TX codes
• Start up with the password
iDEALER-PROGRAMMABLE KEYS [P0] to [P3]
 
Desired functions can be programmed independently by
your dealer. (p. 6)
oFUNCTION DISPLAY
 
Displays a variety of information such as an operating
channel number/name, 2-tone code, DTMF numbers, se-
lected function, etc.
w
e
t
r
y
q
!1
!0
o
!2
u
i
Microphone
Speaker

5
2
PANEL DESCRIPTION
2
!0 MULTI-CONNECTOR
Connect an optional speaker-microphone.
!1 BUSY/TRANSMIT INDICATOR
 ➥
Lights green while receiving a signal, or when the
squelch is open.
 ➥Lights red while transmitting.
!2 VOLUME CONTROL [VOL]
 
Rotate to turn the power ON/OFF and adjusts the audio
level.
■Function display
SET CALA TXCU TXC
q t iuyrew
o
!0
qSIGNAL STRENGTH INDICATOR
Indicates relative signal strength level.
wLOW POWER INDICATOR
Appears when low output power is selected.
eAUDIBLE INDICATOR
 ➥ Appears when the channel is in the ‘audible’ (un-mute)
condition.
 ➥ Appears when the specified 2-tone is received.
r COMPANDER INDICATOR
Appears when the compander function is activated.
t SCRAMBLER INDICATOR
Appears when the voice scrambler function is activated.
Connector cover
NOTE: Attach the connector
cover when the optional
speaker-microphone is not
used.
See (p. 3) for details.

6
2PANEL DESCRIPTION
y BELL INDICATOR
 
Appears/blinks when the specific 2-tone/DTMF select call
is received, according to the pre-programming.
u CALL CODE MEMORY INDICATOR
Appears when the call code memory is selected.
i BATTERY INDICATOR
Indicates remaining battery power.
Indication
Full Middle Charging
required No batteryBattery level
blinks when the battery is exhausted.
blinks when the battery is over charged.
o ALPHANUMERIC DISPLAY
 ➥ Displays an operating channel number, channel name,
Set mode contents, DTMF code, etc.
➥The indication mode can be selected from 1 line or 2
lines. Ask your dealer for details.
• In this instruction manual, the LCD illustration is described
using the 2 lines indication mode.
!0 KEY INDICATOR
 
Indicate the programmed function of the front panel keys
([P0], [P1], [P2] and [P3]).
■Programmable function keys
The following functions can be assigned to [Emer],[Side1],
[Side2], [Side3], [P0], [P1], [P2] and [P3] programmable
function keys.
Consult your Icom dealer or system operator for details con-
cerning your transceivers programming.
If the programmable function names are bracketed in the fol-
lowing explanations, the specific key is used to activate the
function depends on the programming.
CH UP AND DOWN KEYS “UP” “DOWN”
➥Push to select an operating channel.
➥Push to select a transmit code channel after pushing [TX
Code CH Select].
➥Push to select a DTMF channel after pushing [DTMF Au-
todial].
➥Push to select a scan group after pushing and holding
[Scan A Start/Stop]/[Scan B Start/Stop].
ZONE KEY “ZONE”
Push this key, then push [CH Up] or [CH Down] to select the
desired zone.
What is “zone”?— The desired channels are assigned
into a zone according to the intended use for grouping.
For example, ‘Staff A’ and ‘Staff B’ are assigned into a
“Business” zone, and ‘John’ and ‘Cindy’ are assigned into
a “Private” zone.

7
2
PANEL DESCRIPTION
2
SCAN A KEY “SCNA”
➥This key’s operation depends on the Power ON Scan set-
ting.
When the power ON scan function is turned OFF;
Push to start and cancel scanning operation. In case of
transmission during scan, cancels scanning.
When the power ON scan function is turned ON;
Push to pause scanning., then resumes scanning after
passing a specified time period. In case of transmission
during scan, scanning will be cancelled.
➥Push and hold this key for 1 sec. to indicate the scan
group, then push [CH Up] or [CH Down] to select the de-
sired group.
SCAN B KEY “SCNB”
➥Push to start and cancel scanning operation. In case of
transmission during scan, pauses scanning. Scanning
resumes after passing a specified time period.
➥Push and hold this key for 1 sec. to indicate the scan
group, then push [CH Up] or [CH Down] to select the de-
sired group.
SCAN ADD/DEL (TAG) KEY “SCAD”
➥Push to add or delete the selected channel to/from the
scan group.
1. Push to indicate the scan group, then push [CH Up] or
[CH Down] to select the desired group.
2. Push to add or delete the channel to/from the selected
scan group.
3. Push and hold for 1 sec. to exit the scan group selec-
tion mode.
➥Push this key while scan is paused (a signal is detected)
on a channel (except for priority channel,) the channel is
cleared from the scan group.
Depending on the setting, the cleared channel is
added to the scan group again after the scan is can-
celled. (Nuisance Delete function)
PRIO A/B KEYS “PRA” “PRAR” “PRB” “PRBR”
➥Push to select Priority A or Priority B channel.
➥Push and hold [Prio A (Rewrite)] to rewrite the Prio A
channel.
MR-CH 1/2/3/4 KEYS “CH1” “CH2” “CH3” “CH4”
Push to select an operating channel directly.
MONI KEY “MON”
Mute and release the CTCSS (DTCS) or 2-tone squelch mute.
Open any squelch/deactivate any mute while pushing this key.

8
2PANEL DESCRIPTION
LIGHT KEY “LIGT”
Push to turn the transceiver’s backlight ON temporarily only
when the backlight function is turned OFF in user set mode.
LOCK KEY “LOCK”
➥Push and hold for 1 sec. to electronically lock all program-
mable keys except the following:
• [Call] (incl. Call A and Call B), [Moni(Audi)] and [Emergency].
➥Push and hold for 1 sec. again to turn the lock function
OFF.
HIGH/LOW KEY “H/L”
Push to select the transmit output power temporarily or per-
manently, depending on the pre-setting.
• Ask your dealer for the output power level for each selection.
C.TONE CH ENT KEY “TSEL”
Push to select the continuous tone channel using [CH Up]/
[CH Down] to change the tone frequency/code setting. The
selected channel remains set as the continuous tone chan-
nel until another channel is designated as such.
TONE/RAN CH SELECT KEY “T SEL”
➥While in the analog mode operation, push to select the
continuous tone channel using [CH Up] or [CH Down] to
change the tone frequency/code setting.
➥While in the digital mode operation, push to select the
RAN channel using [CH Up] or [CH Down] to change the
RAN code setting.
TALK AROUND KEY “TA”
Push to turn the talk around function ON and OFF.
• The talk around function equalizes the transmit frequency to the
receive frequency for transceiver-to-transceiver communication.
WIDE/NARROW KEY “W/N”
Push to toggle the IF bandwidth between wide and narrow.
DTMF AUTODIAL KEY “DTMA”
➥Push to enter the DTMF channel selection mode. Then
select the desired DTMF channel using [CH Up]/[CH
Down].
➥After selecting the desired DTMF channel, push this key
to transmit the DTMF code.
RE-DIAL KEY “DTMR”
Push to transmit the last-transmitted DTMF code.
CALL KEYS “CALL” “CALA” “CALB”
Push to transmit a 2-tone.
• Call transmission is necessary before you call another station
depending on your signaling system.
• [Call A] and/or [Call B] may be available when your system
employs selective ‘Individual/Group’ calls. Ask your dealer which
call is assigned to each key.

9
2
PANEL DESCRIPTION
2
EMERGENCY KEY “EMR”
Push and hold for a specified period to transmit an emer-
gency call.
• If you want to cancel the emergency call, push (or push and hold)
the key again before transmitting the call.
• The emergency call is transmitted one time only or repeatedly until
receiving a control code depending on the pre-setting.
SURVEILLANCE KEY “SURV”
Push to turn the surveillance function ON or OFF.
When this function is turned ON, the beep is not emitted and
the LCD backlight does not light when a signal is received or
a key is pushed, etc.
TX CODE CHANNEL SELECT KEY “TXC”
Push to enter the ID code channel selection mode directly.
Then set the desired channel using [CH Up]/[CH Down].
(p. 15)
TX CODE CHANNEL UP/DOWN KEYS “TXCU” “TXCD”
Push to select a TX code channel directly.
SCRAMBLER FUNCTION “SCR”
Push to toggle the voice scrambler function ON and OFF.
COMPANDER KEY “COMP”
Push to toggle the compander function ON and OFF.
The compander function reduces noise components from
the transmitting audio to provide clear communication.
PHONE KEY “PHN”
Push to connect or disconnect the telephone network con-
nection during LTR operation.
USER SET MODE KEY “SET”
➥Push and hold to enter user set mode.
• During user set mode, push this key to select an item, and
change the value or condition using push [CH Up]/[CH Down].
➥Push and hold this key again to exit user set mode.
User set mode is also available via the ‘Power ON function.’
Refer to (p. 16) also.
OPT OUT KEYS “OP1” “OP2” “OP3”
Push to control the output signal level of the optional ports in
the optional unit connector.
OPT MOMENTARY KEYS “O1M” “O2M” “O3M”
Push and hold to control the output signal level of the option-
al ports in the optional unit connector.
TALKGROUP KEY “TGID”
While in the digital mode operation, push to enter the talk-
group ID selection mode. Then select the desired talkgroup
ID using [CH Up]/[CH Down].
TX STATUS KEY “TXST”
While in the digital mode operation, push to enter the Status
message selection mode. Then select the desired Status
message using [CH Up]/[CH Down].

■Turning power ON
Prior to using the transceiver for the first time, the battery
pack must be fully charged for optimum life and opera-
tion. (p. 20)
qRotate [VOL] to turn the power ON.
wIf the transceiver is programmed for a start up password,
input the digit codes as directed by your dealer.
• 10-keypad can be used for password input depending on version:
• The keys in the table below can be used for password input:
• The transceiver detects numbers in the same block as identical.
Therefore “01234” and “56789” are the same.
eWhen the “PASSWORD” indication does not clear after
inputting 4 digits, the input code number may be incorrect.
Turn the power off and start over in this case.
DBattery type selection
The battery type must be selected according to the attaching
battery type when tuning the transceiver ON.
➥While pushing and holding [Emer] and [PTT], rotate [VOL]
to toggle the attaching battery type.
• After the display appears, release [Emer] and [PTT].
• “DRY BATT” is displayed for about 3 sec. then “Lo” appears
when the battery case operation is selected.
• “LI-ION” is displayed for about 3 sec. when the Lithium-ion bat-
tery operation is selected.
• This operation may not be available depending on the pre-setting.
Ask your dealer for details.
KEY
NUMBER 0
5
4
9
3
8
2
7
1
6
(Side3)
10
3BASIC OPERATION

11
3
BASIC OPERATION
3
■Channel selection
Several types of channel selections are available. Methods
may differ according to your system set up.
NON-ZONE TYPE:
Push [CH Up] or [CH Down], or rotate [ROTARY SELEC-
TOR]* to select the desired operating channel, in sequence;
or, push one of [MR-CH 1] to [MR-CH 4] keys to select a
channel directly.
• Up to 16 pre-programmed channels can be selected via [ROTARY
SELECTOR].*
ZONE TYPE:
Push [Zone], then push [CH Up] or [CH Down] or rotate [RO-
TARY SELECTOR]* to select the desired zone.
AUTOMATIC SCAN TYPE:
Channel setting is not necessary for this type. When turning
power ON, the transceiver automatically starts scanning.
Scanning stops when receiving a call.
*Depending on the pre-setting.
■Call procedure
When your system employs tone signaling (excluding CTCSS
and DTCS), the call procedure may be necessary prior to voice
transmission. The tone signaling employed may be a selective
calling system which allows you to call specific station(s) only
and prevent unwanted stations from contacting you.
qSelect the desired TX code channel or 2-tone code ac-
cording to your System Operator’s instructions.
• This may not be necessary depending on programming.
• Refer to (pages 14 or 15) for selection.
wPush the call key (assigned to one of the dealer program-
mable keys: [Emer], [Side1], [Side2], [Side3], [P0], [P1],
[P2] and [P3]) or [PTT].
eAfter transmitting a 2-tone code, the remainder of your
communication can be carried out in the normal fashion.
Selective calling Non-selective calling

■Receiving a call
DGroup call
qPush [CH Up] or [CH Down], or rotate [ROTARY SELEC-
TOR]* to select the LTR system channel or talk group.
wWhen a call is received;
• ‘BUSY’ indicator lights green.
ePush and hold [PTT], then speak into the microphone at
a normal voice level.
rRelease [PTT] to return to receive.
DSelective call (DTMF call)
qPush [CH Up] or [CH Down], or rotate [ROTARY SELEC-
TOR]* to select the LTR system channel or talk group.
wPush [Call] to mute the channel.
eWhen receiving a call, the calling station name appears
and a beep is emitted. Then the mute is released.
• “ ” appears.
*:Depending on the pre-setting.
DPhone call
• Receive a phone call
q Push [CH Up] or [CH Down], or rotate [ROTARY SELEC-
TOR]* to select the phone channel of LTR system channel.
• “ ” appears.
wWhen a phone call is received (transceiver rings), push
[PHONE] (or push [PTT]).
• “ ” blinks.
ePush and hold [PTT], then speak into the microphone at
a normal voice level. Release [PTT] to return to receive.
rAfter conversation is finished, push [PHONE] (or while
pushing and holding [PTT], push [#]) to disconnect the
phone call.
• “ ” stops blinking.
002 ch-03
fH 173.7M
SET DTMA DTMR PHN
Blinks
002 ch-03
fH 173.7M
002 ch-03
fH 173.7M
SET DTMA DTMR PHN
Appears
12
4LTR OPERATION

13
4
LTR OPERATION
4
• Make a phone call
qSelect the phone channel of LTR system channel.
• “ ” appears.
wPush [PHONE] (or push [PTT]).
• “ ” blinks.
ePush [DTMF Autodial] (or while pushing and holding
[PTT] enter the desired telephone number using 10 key
pad) to make a phone call.
rAfter conversation is finished, push [PHONE] (or while
pushing and holding [PTT], push [#]) to disconnect the
phone call.
• “ ” stops blinking.
*:Depending on the pre-setting.
■Transmitting a call
DGroup call
qPush [CH Up] or [CH Down], or rotate [ROTARY SELEC-
TOR]* to select the LTR system channel or talk group.
wWhile pushing and holding [PTT], speak into the micro-
phone at a normal voice level after a beep is emitted.
• If an error beep is emitted, release [PTT]. After a while, repeat
step w.
• The beep can be turned OFF in User set mode.
DSelective call (DTMF call)
qPush [CH Up] or [CH Down], or rotate [ROTARY SELEC-
TOR*] to select the LTR system channel or talk group.
wPush [DTMF Autodial]— a DTMF encode channel ap-
pears.
ePush [CH Up] or [CH Down] to select the desired DTMF
encode channel.
rPush [PTT] to transmit the selected DTMF code in the se-
lected DTMF channel.
• Push [DTMF Autodial] to cancel the DTMF transmission.
002 ch-03
fH 173.7M
SET DTMA DTMR PHN
Blinks

14
5CONVENTIONAL OPERATION
■Receiving and transmitting
NOTE: Transmitting without an antenna may damage the
transceiver. See (p. 1) for accessory attachments.
Receiving:
qRotate [VOL] to turn the power ON.
wPush [CH Up] or [CH Down], or rotate [ROTARY SELEC-
TOR]* to select the conventional system channel, in se-
quence.
*Depending on the pre-setting.
eWhen receiving a call, adjust the audio output level to a
comfortable listening level.
Transmitting:
Wait for the channel to become clear to avoid interference.
qPush [Call] when initiating a call from your side.
• Coded audio may be heard from the transceiver, then “ ” ap-
pears.
• This operation may not be necessary depending on your signal-
ing system. Ask your dealer for details.
wWhile pushing and holding [PTT], speak into the micro-
phone at a normal voice level.
eRelease [PTT] to return to receive.
IMPORTANT: To maximize the readability of your signal;
1. Pause briefly after pushing [PTT].
2. Hold the microphone 5 to 10 cm (2 to 4 inches) from
your mouth, then speak into the microphone at a nor-
mal voice level.
DTransmitting notes
• Transmit inhibit function
The transceiver has several inhibit functions which restrict
transmission under the following conditions:
- The channel is in mute condition (‘Inaudible’ condition;
“ ” does not appear.)
- The channel is busy.
- Un-matched (or matched) CTCSS is received.
(Depending on the pre-setting.)
- The selected channel is a ‘receive only’ channel.
• Time-out timer
After continuous transmission for the pre-programmed time
period, the time-out timer is activated, causing the trans-
ceiver to stop transmitting.
• Penalty timer
Once the time-out timer is activated, transmission is further
inhibited for a period determined by the penalty timer.

15
5
CONVENTIONAL OPERATION
5
DTX code channel selection
If the transceiver has [TX Code CH Select] assigned to it,
the indication can be toggled between the operating channel
number (or name) and TX code channel number (or name).
When the TX code channel number (or name) is displayed,
[CH Up] or [CH Down] selects the TX code channel.
USING [TX CODE CH SELECT] KEY:
qPush [TX Code CH Select]— a TX code channel number
(or name) appears.
wPush [CH Up] or [CH Down] to select the desired TX code
channel.
ePush [Call] (or [PTT] during MSK operation) to transmit
the selected TX code.
rPush [TX Code CH Select] again to return to the operat-
ing channel number indication.
USING [TX CODE CH UP]/[TX CODE CH DOWN] KEY:
If the transceiver has a [TX Code CH Up] or [TX Code CH
Down] key assignment, the programmed TX code channel
can be selected directly when pushed.
DDTMF transmission
If the transceiver has [DTMF Autodial] assigned to it, the
automatic DTMF transmission function is available. Up to 8
DTMF channels are available.
TO SELECT A TX CODE:
qPush [DTMF Autodial]— a DTMF channel appears.
wPush [CH Up] or [CH Down] to select the desired DTMF
channel.
ePush [DTMF Autodial] to transmit the DTMF code in the
selected DTMF channel.

16
5CONVENTIONAL OPERATION
DTalkgroup ID code selection
If the transceiver has [Talkgroup] assigned to it, the indica-
tion can be toggled between the operating channel name
(and the channel number)* and the Talkgroup ID name (or
ID code if the ID name is not programmed.) When the Talk-
group ID name (or ID code) is displayed, [CH Up] or [CH
Down] selects the desired Talkgroup ID name (or ID code).
qPush [Talkgroup]— Talkgroup ID name (or ID code) ap-
pears.
wPush [CH Up] or [CH Down] to select the desired Talk-
group ID name (or ID code).
ePush [PTT] to transmit the selected Talkgroup ID.
DTX Status message selection
If the transceiver has [TX Status] assigned to it, the indica-
tion can be toggled between the operating channel name
(and the channel number)* and the Status message (and the
Status channel.)* When the Status message (and the Status
channel)* is displayed, [CH Up] or [CH Down] selects the
desired Status message.
qPush [TX Status]— Status message (and Status chan-
nel)* appears.
wPush [CH Up] or [CH Down] to select the desired Status
message.
ePush [PTT] to transmit the selected Status message.
* Only when the 2 lines indication mode is selected.
■User set mode
User set mode is accessed at power ON and allows you to
set seldom-changed settings. In this case you can “custom-
ize” the transceiver operation to suit your preferences and
operating style.
Entering the user set mode:
qWhile pushing and holding [P1] and [P2], rotate [VOL]
to turn the power ON. Then, push and hold [P0] to enter
user set mode.
wPush [P0] several times to select the appropriate item.
Then push [Side2] or [Side3] to set the desired level/con-
dition.
• Available set mode functions are Backlight, LCD contrast,
Beep, Beep Level, Ringer Level, SQL Level, AF Min Level,
Mic Gain, VOX Gain, VOX Delay, Battery Voltage and Signal
Moni.
eRotate [VOL] to turn the power OFF to exit user set mode.
NOTE: User set mode is also available via a programma-
ble key. Please refer to (p. 9) [User Set Mode] section.
