ICP DAS USA PDS-220F Series User manual

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 1
PDS-220Fx Series
User Manual
Warranty
All products manufactured by ICP DAS are under warranty regarding defective materials
for a period of one year, starting from the date of delivery to the original purchaser.
Warning
ICP DAS assumes no liability for damages resulting from the use of this product. ICP
DAS reserves the right to change this manual at any time without notice. The information
furnished by ICP DAS is believed to be accurate and reliable. However, no responsibility
is assumed by ICP DAS for its use, or for any infringements of patents or other rights of
third parties resulting from its use.
Copyright
Copyright 2010 by ICP DAS. All rights are reserved.
Trademark
Names used are for identification only and may be registered trademarks of their
respective companies.

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 2
Table of Contents
1. INTRODUCTION ..............................................................................................................................................................5
1.1. W HY F IBER O PTIC S OLUTIONS ?................................................................................................................................5
1.2. W HY V X C OMM T ECHNOLOGY ?................................................................................................................................7
1.3. W HY W EB S ERVER T ECHNOLOGY ?..........................................................................................................................9
2. TYPICAL APPLICATIONS FOR THE PDS-220FX ...................................................................................................10
2.1. RS-232/485/422 D EVICE N ETWORKING ....................................................................................................................10
2.2. F IBER I/O A PPLICATIONS .........................................................................................................................................11
2.3. C ONFIGURABLE F IBER O PTIC D ATA L OGGER ........................................................................................................11
3. HARDWARE INFORMATION......................................................................................................................................14
3.1. F EATURES .................................................................................................................................................................14
3.3. PDS-220F X S ELECTION G UIDE ...............................................................................................................................16
3.4. P IN A SSIGNMENTS ....................................................................................................................................................17
4. SETTING UP THE PDS-220FX MODULE...................................................................................................................19
5. CONFIGURATION VIA A WEB BROWSER..............................................................................................................26
5.1. C ONNECTING TO THE PDS-220F X M ODULE ...........................................................................................................26
5.2. N ETWORK S ETTINGS ................................................................................................................................................27
5.3. IP F ILTER S ETTING ..................................................................................................................................................30
5.4. COM P ORT S ETTINGS ..............................................................................................................................................31
5.5. M ISCELLANEOUS SETTINGS .....................................................................................................................................37
6. CONSOLE/TELNET COMMANDS LIST....................................................................................................................39
6.1. O PERATION F LOWCHART ........................................................................................................................................39
6.2. S WITCHING BETWEEN I NIT /N ORMAL M ODES .............................................................................................................40
6.3. C OMMAND L IST .........................................................................................................................................................41
APPENDIX A: LINKING TO A DEVELOPMENT PC ........................................................................................................63
APPENDIX B: FRAME GROUND..........................................................................................................................................66
GLOSSARY................................................................................................................................................................................67
1. ARP (A DDRESS R ESOLUTION P ROTOCOL )..................................................................................................................67
2. C LIENTS AND S ERVERS .................................................................................................................................................67
3. F IRMWARE .....................................................................................................................................................................67
4. G ATEWAY ......................................................................................................................................................................68

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 3
5. ICMP (I NTERNET C ONTROL M ESSAGES P ROTOCOL ).................................................................................................68
6. I NTERNET .......................................................................................................................................................................68
7. IP (I NTERNET P ROTOCOL ) ADDRESS ............................................................................................................................68
8. MAC (M EDIA A CCESS C ONTROL ) ADDRESS ................................................................................................................68
9. O PTICAL FIBER ..............................................................................................................................................................68
10. P ACKET .....................................................................................................................................................................69
11. P ING ..........................................................................................................................................................................69
12. RARP (R EVERSE A DDRESS R ESOLUTION P ROTOCOL )...........................................................................................69
13. S OCKET .....................................................................................................................................................................69
14. S UBNET M ASK ...........................................................................................................................................................69
15. TCP (T RANSMISSION C ONTROL P ROTOCOL )..........................................................................................................70
16. TCP/IP......................................................................................................................................................................70
17. UDP (U SER D ATAGRAM P ROTOCOL )......................................................................................................................70
FAQ .............................................................................................................................................................................................71
1. H OW DO I ACCESS A REMOTE PDS-220F X THAT IS SITUATED BEHIND AN NAT OR FIREWALL ?......................................71
2. H OW DO I OPEN A VIRTUAL COM P ORT GREATER THAN "COM 9" BY CALLING C REATE F ILE () W IN 32 API?.................72
3. D OES THE V X C OMM D RIVER (PC) SUPPORT AUTO - RECONNECTION AFTER FIXING A NETWORK BREAK ?...............73
4. W HY DOESN ' T THE V X C OMM D RIVER (PC) RECEIVE DATA FROM THE PDS-220F X MODULE ?................................74
5. D OES TRANSMISSION SPEED BECOME FASTER WHEN A SERIAL DEVICE IS WORKING WITH S ERIAL TO F IBER OPTIC
DEVICE SERVERS ?...................................................................................................................................................................75
6. W HY DOES THE PDS-220F X MODULE FAIL ON A PUBLIC I NTERNET CONNECTION ?..................................................77
7. C AN I USE THE S ET C OMM S TATE ( ) API TO CHANGE THE B AUD R ATE / DATA FORMAT SETTINGS OF A VIRTUAL
COM P ORT ?...........................................................................................................................................................................79
8. H OW MANY PC S CAN BE CONNECTED TO A SINGLE PDS-220F X DEVICE ?..................................................................79
9. C AN I SEARCH FOR OR CONNECT TO THE PDS-220F X IF THE IP ADDRESS OF MY PC IS NOT IN THE PDS-220F X IP
FILTER LIST ? H OW CAN I SOLVE THIS PROBLEM ?.................................................................................................................81

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 4
Packing List
The shipping package includes the following items:
One PDS-220Fx series hardware module
One printed quick start guide
One software utility CD
Note:
If any of these items is missed or damaged, contact the local distributor for more
information. Save the shipping materials and cartons in case you want to ship in the future.
More Information:
Documentations
CD:\NAPDOS\PDS\PDS-220Fx\Document\
VxComm Driver (Virtual COM)
CD:\NAPDOS\Driver\VxComm_Driver
Firmware
CD:\NAPDOS\PDS\ PDS-220Fx\VxComm\Server(PDS)
MiniOS7
CD:\NAPDOS\PDS\ PDS-220Fx\OS_image
Quick start

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 5
1.Introduction
The PDS-220Fx series is a family of Programmable Device Servers, also known as
"Serial-to-Fiber gateways”, that are designed to enable optical fiber connectivity to be
added to RS-232/422/485 devices. The user-friendly VxComm Driver/Utility allows users
to easily turn the built-in COM ports of the PDS-220Fx series into standard COM ports on
a PC. By virtue of its protocol independence, a small-core OS and high flexibility, the
PDS- 220Fx series is able to meet the demands of every network-enabled application.
The PDS-220Fx series includes a powerful and reliable Xserver programming structure
that allows you to rapidly design robust custom Fiber optics applications. The built-in,
high-performance MiniOS7 boots up the PDS-220Fx in just one second and gives you
fastest responses.
1.1. Why Fiber Optic Solutions?
Fiber optic communication permits transmission of data over longer distances than other
forms of communication because the signals travel along the fiber with minimum loss and
no crosstalk. Fiber optics provides the following important features:
˙Immunity to electromagnetic interference (EMI) — Motors, relays, welders and other
industrial equipment generate a tremendous amount of electrical noise that can cause
major problems with copper cabling.
˙High electrical resistance, making it safe to use near high-voltage equipment or
between areas with different earth potentials.
˙No sparks — important in environments that contain flammable or explosive gas.
˙No electromagnetic radiation, and it is difficult to tap into the signal without causing
disruption, which is an important factor in high-security environments.
Because of these reasons, optical fibers have largely replaced copper wire communications
in core networks in the developed world.

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 6
Applications:

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 7
1.2. Why VxComm Technology?
In general, writing code for a TCP/IP program is more difficult than for a COM port
program, or perhaps the COM port communication system was built many years ago.
As a result, a new technology, VxComm, was developed to virtualize the COM ports
of the PDS-220Fx to allow up to 256 COM ports to be used on the central computer.
The VxComm driver saves time when accessing serial devices through the fiber optic
network without the need for reprogramming the COM port software on the PC.

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 8
The VxComm driver controls all the details of the TCP/IP programming and with the
assistance of PDS-220Fx and VxComm technology, your COM port program will be able
to access your serial devices through the fiber optic network in the same way as it would
through a standard COM port.

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 9
1.3. Why Web Server Technology?
Web server technology enables configuration of the PDS-220Fx via a standard web
browser interface, e.g. Google Chrome, Firefox, Internet Explorer or Mozilla, etc. This
means that it is easy to check the configuration of the PDS-220Fx via a fiber optic network
without needing to install any other software tools, thereby reducing the user’s learning
curve.

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 10
2.Typical Applications for the PDS-220Fx
2.1. RS-232/485/422 Device Networking
--- Using Virtual COM Technology ---
The PDS-220Fx series is designed to allow RS-232/485/422 devices to be connected to
a fiber optic network. The VxComm utility allows the built-in PDS-220Fx COM port to be
virtualized to a standard COM port on a host PC, as shown below:
In the configuration above, Meter-1 is virtualized to link to COM3 on the host PC.
Therefore a program originally designed for the MS-COMM standard can still access the
meter without the need for any modification to the program.
COM1/2 on the PDS-
220Fx is mapped to
COM3/4 o
n the
host
PC
The original COM1/2
on the host PC
COM1/2 on the PDS-
220Fx is mapped to
COM5/6 o
n
the
host

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 11
2.2. Fiber I/O Applications
The PDS series provides fiber optic I/O solution:
Linking to I-7000 Series Modules
The I-7000 series provides a variety of I/O operations, such as D/I, D/O, A/D, D/A,
Counter and Frequency Measurement, etc. The I-7000 series was originally designed to be
used with RS-485 networks, so COM2 on the PDS-220Fx can be used to link to I-7000
series modules. These modules are very robust and work well in harsh industrial
environments.
By using VxComm technology, programs on the host PC that support serial devices
can be upgraded from a RS-485 network to a fiber optic network without requiring any
modifications to the program. Refer to Sec. 2.1 for more information.
2.3. Configurable Fiber Optic Data Logger
Using the VxComm driver, PDS-220Fx + I-7000 modules can be virtualized to become
COM port + I-7000 modules located on the host PC, and then the Data Logger in the
DCON Utility can be used to access data from the I-7000 via the fiber optic network.
Signal data originating from the I-7000 modules can be analyzed using MS-Excel without
the need to create any custom programs
1. The DCON utility includes a data logger function, as show below:

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 12
2. Configure the system connection, as shown below, and click the “Start” button to begin
logging data.
3. Open the log file in MS-Excel to read the log data, as shown in the example below:

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 13
By using the I-7000 DCON utility and MS-Excel in conjunction with VxComm
technology, the signal data of I-7000 modules from the fiber optic network can be
analyzed without the need to create any custom programs. For more information about the
log function refer to the online help feature (English and Traditional Chinese) of the
DCON utility.

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 14
3. Hardware Information
3.1. Features
Built-in Watchdog timer for use in harsh environments
Built-in self-tuning ASIC controller on the RS-485 port
Built-in 100 Base-FX optical fiber port
Built-in OS: ICP DAS MiniOS7
ODM service is available
3.2. Specifications
Models PDS-220FT PDS-220FC PDS-220FCS PDS-220FCS-60
System
CPU 80186, 80MHz or compatible
SRAM 512 KB
Flash 512 KB; Erase unit is one sector (64 KB); 100,000 erase/write cycles
EEPROM 16 KB; Data retention: 40 years; 1,000,000 erase/write cycles
Watchdog Yes
LED Indicators Sys, Link/Act
Init Pin Yes
Interface
Fiber Port 100 Base-FX,
ST connector
100 Base-FX,
SC connector
100 Base-FX,
SC connector
100 Base-FX,
SC connector
Mode Multi-mode fiber cables:
50/125, 62.5/125 or 100/140 µm
Wavelength 1300 or 1310 nm
Min. TX Output: -20 dBm
Max. TX Output: -14 dBm
Max. RX Sensitivity: -32 dBm
Max. RX Overload: -8 dBm
Budget: 12 dBm
Single mode fiber cables:
8.3/125, 8.7/125, 9/125 or
10/125 µm
Wavelength 1300 or 1310 nm
Min. TX Output: -15 dBm,
Max. TX Output: -8 dBm
Max. RX Sensitivity: -34 dBm,
Max. RX Overload: -5 dBm
Budget: 19 dBm
Single mode fiber cables:
8.3/125, 8.7/125, 9/125 or
10/125 µm
Wavelength 1300 or 1310 nm
Min. TX Output: -5 dBm,
Max. TX Output: 0 dBm
Max. RX Sensitivity: -35 dBm,
Max. RX Overload: -5 dBm
Budget: 30 dBm
Distance 2 km, (62.5/125 µm recommended)
for full duplex 30 Km, (9/125 µm recommended) for full duplex 60 Km, (9/125 µm recommended) for full duplex
Serial Ports
COM1 Male DB-9, 5-wire RS-232 (RxD, TxD, CTS, RTS, GND)
Note: +/- 4 kV ESD Protection
COM2 Removable Terminal Block,
2-wire RS-485 (D+, D-, GND) with Self-tuner ASIC or 4-wire RS-422 (TxD+, TxD-, RxD+, RxD-, GND)
Note: +/- 4 kV ESD Protection
UART 16c550 or compatible
Baud rate 115200 bps Max.
Data bits 7, 8
Parity None, Odd, Even, Mark, Space
Stop bits 1
General
Power Input +12 ~ +48 V DC (non-regulated)

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 15
External
Power supply
COM2: RS
-
485
Wiring
i
nformatio
n
COM1: RS-232
100 Base-FX
fiber port
Wiring information
LED Indicator
Robust insulated
and
fire retardant case
Power Consumption 0.14 A @24 V DC
Protection Power reverse polarity protection
Frame GND Yes, for EMS Protection.
Dimensions 25 mm x 168 mm x 135 mm (W x L x H)
Case Fire Retardant Plastic (UL94-V0 level)
Mounting DIN-Rail
Operating
Temperature -25°C ~ +75°C
Storage Temperature -30°C ~ +85°C
Humidity 10% ~ 90% RH, non-condensing
PDS-220Fx Front View

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 16
3.3. PDS-220Fx Selection Guide
Model CPU SRAM Flash Fiber Port Mode Distance COM1 COM2
PDS-220FT
100 Base-FX,
ST connector Multi 2 km
PDS-220FC
100 Base-FX,
SC connector Multi 2 km
PDS-220FCS
100 Base-FX,
SC connector Single 30 km
PDS-220FCS-60
80 MHz 512 KB 512 KB
100 Base-FX,
SC connector Single 60 km
5-wire
RS-232
RS-422
RS-485
5-wire RS-232: RxD, TxD, CTS, RTS, GND
4-wire RS-422: TxD+, TxD-, RxD+, RxD-
2-wire RS-485: Data+, Data-

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 17
3.4. Pin Assignments
The pin assignments for the PDS-220Fx models are:

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 18
Dimensions

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 19
4.Setting up the PDS-220Fx module
Step 1. Connect the PDS-220Fx module to the fiber optic network
Before connecting the PDS-220Fx module to a fiber optic network, the following
items are needed:
1. Power Supply：12 ~ 48 V
DC
(e.g. DP-665:
http://www.icpdas.com/products/Accessories/power_supply/power_list.htm )
2. Fiber to Ethernet Converter (e.g. NS-200AFT
http://www.icpdas.com/products/Switch/industrial/industrial_list.htm )
3. Check that the network settings on the PC are correctly configured and the Ethernet
connection is functioning normally.
4. Disable or correctly configure the Windows firewall and any Anti-Virus software
firewall first or else the “Search Servers” function in the VxComm Utility may not work
correctly. (Contact your System Administrator for more details if you are unsure how to do
this.)
5. Connect the PDS-220Fx module to the fiber optic network as shown on the following
page and switch on the power.
6. Make sure the LED indicator on the PDS-220Fx is flashing.
7. Install the VxComm Utility on your PC
The software is located at：
CD: \Napdos\7188e\tcp\vxcomm\driver(pc)\
http://ftp.icpdas.com/pub/cd/8000cd/napdos/7188e/tcp/vxcomm/driver(pc)/

PDS-220 Series User Manual (V1.0, Jun.2010) ----- 20
Connect both the NS-200AFx module and your computer to the same sub network or
the same Switch.
Short the RXD and TXD pins on the PDS-220Fx module to execute a self-test.
Supply 24 V
DC
(12 ~ 48 V
DC
) power to the PDS-220Fx module.
