ICP DAS USA PCI-1800HU User manual

One PCI-1800/1802 (LU/HU) series card
One companion PCI CD (V4.7 or later)
One Quick Start Guide (This document)
One CA-4002 D-Sub connector
for PEX-P8R8i/P16R16i
English/ Version 1.1/ April 2010
for PC
I
-1800 LU/H
U
PCI-1802 LU/HU
English/ May 2010/ Version 1.0
1
PCI-1800/1802 LU/HU Quick Start Guide
What’s in the shipping
package?
Software Utility CD
CA-4002 D-Sub Connector
Quick Start Guide
PCI-1800/1802 (LU/HU)
Series Card

Installing Windows Driver
Follow these steps:
1. Setup the Windows driver. The driver is located at:
CD:\NAPDOS\PCI\PCI-180x\DLL_OCX\
http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-180x/dll_ocx/
The Windows driver only supports Windows 98/NT/2000/ and 32-bit
Windows XP/2003/Vista/7 Versions.
2. Click the “Next>” button to start the installation.
3. Click the “Next>” button to install the driver into the default folder.
4. Click the “Install” button to continue the installation.
5. Select “NO, I will restart my computer later” and then click the
“Finish” button.
Jumper & Card ID Setting
2
PCI-1800/1802 LU/HU Quick Start Guide

SW1 Card ID Setting
JP1: Analog Input Type Selection.
(Please make sure JP1 jumper is kept in default setting before self-test.)
Follow these steps:
1. Shut down and power off your computer.
2. Remove the cover from the computer.
3. Select an unused PCI slot.
4. Carefully insert your I/O card into the PCI slot.
5. Replace the PC cover.
6. Power on the computer.
After powering-on the computer, please finish the Plug&Play
steps according to the prompted messages.
3
PCI-1800/1802 LU/HU Quick Start Guide
Installing Hardware on PC
Card ID
1
ID0 2 ID1 3 ID2 4 ID3
(*) 0 OFF OFF OFF OFF
ON OFF OFF OFF1 OFF ON OFF OFF2 ::::: ON OFF ON ON13 OFF ON ON ON14 ON ON ON ON15
(*) Default setting
(Default Setting)

Pin Assignments
CON1 Digital Output connector (20-pin box header)
CON2 Digital Input connector (20-pin box header)
CON3 Analog Input Connector (Female DB37)
PCI-1800/1802 LU/HU Quick Start Guide
PCI-1802LU/HU
32-ch Single-Ended/
16-ch Differential
PCI-1800LU/HU
16-ch Single-Ended/
8-ch Differential
4

Self Test
DIO Test Wiring:
1. Use CA-2002 (optional) to connect the CON1 with CON2.
Analog Input Test Wiring:
2. Prepare for device:
zDN-37 (optional) wiring terminal board.
zProvide a stable signal source. (For example, dry battery)
3. Connect a DN-37 to the COM3.
PCI-1800/1802 LU/HU Quick Start Guide
5

4. Wire the signal source to channel 0.
Keep set the JP1 jumper to Single-Ended (page 3), and wire
the signals as follows:
For PCI-1802 LU/HU:
Connect the AI 0 (Pin1) to signal positive (+)
Connect the A.GND (Pin17) to signal negative (-)
For PCI-1800 LU/HU:
Connect the AI 0 (Pin1) to signal positive (+)
Connect the A.GND (Pin14) to signal negative (-)
6
PCI-1800/1802 LU/HU Quick Start Guide

Execute the PCI-1800/1802 (LU/HU) sample program:
5. The sample program is contained in:
CD:\NAPDOS\PCI\PCI-180x\DLL_OCX\Demo\
http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-180x/dll_ocx/demo/
6. The following sample program is written in Delphi.
File: DLL_Delphi3_xxxxxx.exe
Path: ....\ DLL_Delphi3\01\
Double click the “Demo1.exe”
7. Verify total numbers of the PCI-1800/1802 (LU/HU)
card and perform AI, DIO functions test.
7
PCI-1800/1802 LU/HU Quick Start Guide
Click this button to start test.
Confirm the number of
PCI-180x cards installed
successfully on this PC.
Select the board to activate. (It ranges form 0 to total
board number subtracting one)

8. Get AI and DIO function test result.
Additional Information
PCI-1800/1802 LU/HU Series Card product page:
http://www.icpdas.com/products/DAQ/pc_based/pci_1800.htm
CA-3710, CA-2002 and DN-37 page (optional):
http://www.icpdas.com/products/Accessories/cable/cable_selection.htm
http://www.icpdas.com/products/DAQ/screw_terminal/dn_37.htm
Documentation:
CD:\NAPDOS\PCI\PCI-180x\Manual
http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-180x/manual/
Software:
CD:\NAPDOS\PCI\PCI-180x
http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-180x
ICP DAS Web Site: http://www.icpdas.com
Contact Us (E-Mail): [email protected]
Copyright @ 2010 by ICP DAS Co., Ltd. All Rights Reserved. 8
Check continual analog input on CH0.
Check analog input on CH0 textbox.
Check the “Digital Out”
value (write) and “Digital In”
value
(
read
)
should be identical.
