WARRANTY
All products manufactured by ICP DAS are warranted
against defective materials for a period of one year from
the date of delivery to the original purchaser.
WARNING
ICP DAS assumes no liability for damages consequent to
the use of this product. ICP DAS reserves the right to
change this manual at any time without notice. The
information furnished by ICP DAS is believed to be
accurate and reliable. However, no responsibility is
assumed by ICP DAS for its use, nor for any
infringements of patents or other rights of third parties
resulting from its use.
COPYRIGHT
Copyright © 2021 by ICP DAS. All rights are reserved.
TRADEMARKS
Names are used for identification purposes only and may
be registered trademarks of their respective companies.
CONTACT US
If you have any questions, please feel free to contact us
via email at:
[email protected]om
SUPPORT
PCIe-S112/PCIe-S112i、PCIe-S142/PCIe-S142i
PCIe-S114/PCIe-S114i、PCIe-S144/PCIe-S144i
PCIe-S118、PCIe-S148
Written by Albert Deng
Edited by Sunny Chiu
PCIe Multiport Serial Card
User Manual

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 2 -
TABLE OF CONTENTS
PACKING LIST........................................................................................................................................................................4
1. INTRODUCTION ..........................................................................................................................................................6
1.1 FEATURES..............................................................................................................................................7
1.2 SPECIFICATIONS.......................................................................................................................................9
1.2.1 PCIe-S112(i)/PCIe-S142(i) ..............................................................................................................................9
1.2.2 PCIe-S114(i)/PCIe-S144(i) ............................................................................................................................10
1.2.3 PCIe-S118/PCIe-S148...................................................................................................................................11
1.3 OPTIONS .............................................................................................................................................12
2. HARDWARE CONFIGURATION .................................................................................................................................15
2.1 DIMENSIONS ........................................................................................................................................15
2.1.1 PCIe-S112(i)/ PCIe-S142(i) ...........................................................................................................................15
2.1.2 PCIe-S114(i)/ PCIe-S144(i) ...........................................................................................................................16
2.1.3 PCIe-S118/PCIe-S148...................................................................................................................................17
2.2 WIRING NOTES FOR RS-232/422/485 ......................................................................................................18
2.2.1 RS-232 Wiring .............................................................................................................................................18
2.2.2 RS-485 Wiring .............................................................................................................................................18
2.2.3 RS-422 Wiring .............................................................................................................................................19
2.3 PIN ASSIGNMENTS .................................................................................................................................20
2.3.1 PCIe-S112 ....................................................................................................................................................20
2.3.2 PCIe-S142 ....................................................................................................................................................20
2.3.3 PCIe-S114 ....................................................................................................................................................21
2.3.4 PCIe-S144 ....................................................................................................................................................22
2.3.5 PCIe-S118 ....................................................................................................................................................23
2.3.6 PCIe-S148 ....................................................................................................................................................24
3. HARDWARE INSTALLATION......................................................................................................................................25
4. SOFTWARE INSTALLATION .......................................................................................................................................29
4.1 OBTAINING THE DRIVER INSTALLER PACKAGE.................................................................................................29
4.2 INSTALLING DRIVER FOR PCIe MULTIPORT SERIAL CARD ..................................................................................30
4.3 PNPDRIVER INSTALLATION ......................................................................................................................32
4.4 VERIFYING THE INSTALLATION ...................................................................................................................34
4.4.1 Accessing Windows Device Manager..........................................................................................................34
4.4.2 Check the Configuration of the COM Port...................................................................................................36

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 3 -
4.5 MANUAL CONFIGURATION FOR COM PORTS ................................................................................................37
4.6 UNINSTALLING THE DEVICE DRIVER.............................................................................................................40
5. TESTING THE PCIe MULTIPORT SERIAL CARD ..........................................................................................................41
5.1 PCIe-S112(I)/ PCIe-S142(I)..................................................................................................................41
5.1.1 Preparation .................................................................................................................................................41
5.1.2 Self-test Wiring ...........................................................................................................................................41
5.1.3 Executing Test Program ..............................................................................................................................43
5.2 PCIe-S114(I)/ PCIe-S144(I)..................................................................................................................45
5.2.1 Preparation .................................................................................................................................................45
5.2.2 Self-test Wiring ...........................................................................................................................................45
5.2.3 Executing Test Program ..............................................................................................................................47
5.3 PCIe-S118/ PCIe-S148 ........................................................................................................................49
5.3.1 Preparation .................................................................................................................................................49
5.3.2 Self-test Wiring ...........................................................................................................................................49
5.3.3 Executing Test Program ..............................................................................................................................51
REVISION HISTORY.............................................................................................................................................................53

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 4 -
Packing List
The shipping package includes the following items:
Note:
If any of these items are missing or damaged, please contact the local distributor
for more information. Save the shipping materials and cartons in case you need to
ship the card in the future.
PCIe-S112(i)/
PCIe-S142(i)
One PCIe-S1x2 Series Card
One Quick Start
PCIe-S114(i)/
PCIe-S144(i)
One PCIe-S1x4 Series Card
One Quick Start
One CA-4002
Connector
PCIe-S118/
PCIe-S148
One PCIe-S1x8 Series Card
One Quick Start
One CA-PC62M
Connector

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 5 -
More Information
More information about the software and manual for the PCIe multiport serial cards can be
obtained on the ICP DAS website, https://www.icpdas.com/.
You can visit the product page by entering part or all of your model name in the search bar, and get
the detailed information about the software and manual by clicking the Download Center icon in
the upper right position of the product page.
Model Name

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 6 -
1. Introduction
The PCIe multiport serial card is the foremost choice for PC-based communication solutions,
ensuring smooth communication in both time-critical applications and industrial fields. Installing a
multiport card increases the number of serial ports available on the PC, meaning that it is much
easier to integrate a PC with a large number of external serial communication devices, such as PLCs,
meters, controllers, laboratory instruments, modems, card readers, serial printers, RFID readers,
bar code readers, and sensors.
Comparison Table for PCIe Multiport Serial Cards:
Model
RS-232
RS-422/RS-485
ESD
Protection
Max.
Speed
(bps)
FIFO
Size
(bytes)
Connector
Ports
Isolation
Ports
Isolation
PCIe-S112
2
-
-
-
-
921.6 K
256
Male DB-9
PCIe-S112i
2
3.0 kV
-
-
±4 kV
921.6 K
256
Male DB-9
PCIe-S142
-
-
2
-
921.6 K
256
Male DB-9
PCIe-S142i
-
-
2
3.0 kV
±4 kV
921.6 K
256
Male DB-9
PCIe-S114
4
-
-
-
-
921.6 K
256
Female DB-37
PCIe-S114i
4
3.0 kV
-
-
±4 kV
921.6 K
256
Female DB-37
PCIe-S144
-
-
4
-
921.6 K
256
Female DB-37
PCIe-S144i
-
-
4
3.0 kV
±4 kV
921.6 K
256
Female DB-37
PCIe-S118
8
-
-
-
-
921.6 K
256
Female DB-62
PCIe-S148
-
-
8
-
-
921.6 K
256
Female DB-62

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 7 -
1.1 Features
PCI Express
PCI Express (PCIe) is a computer expansion card standard. A key difference between PCIe and
earlier PC buses is a topology based on point-to-point serial links, rather than shared parallel bus
architecture. Conceptually, the PCIe bus can be thought of as a 'high-speed serial replacement' of
the older PCI/PCI-X bus.
Hardware FIFO up to 256 bytes
FIFO is an acronym for "First In, First Out", and is a method used for organizing and manipulating
data relative to time and prioritization. FIFO is used for buffering and flow control while the data is
transmitted from the hardware to the software. When using a hardware FIFO (buffer), a small delay
in either the software or the operating system will not cause any data loss.
PCIe multiport serial cards are equipped with a large 256-byte hardware FIFO for each port. A large
hardware FIFO is useful for preventing data loss if the loading on your system is heavy, e.g. while
running a multi-task operating system, such as Windows or Linux.

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 8 -
Automatically Select COM Port Numbers
The COM ports on a PCIe multiport serial card can be automatically detected and configured by the
software driver. You can clearly and easily specify any COM port to access your serial devices in
control programs with regardless of which PCI Express slot that the PCIe multiport serial card is
inserted in.
.
Various Accessories
There are a lot of optional accessories for the PCIe multiport serial cards, such as RS-232 cables and
daughter boards. These tools make wiring much easier than ever before.

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 9 -
1.2 Specifications
1.2.1 PCIe-S112(i)/PCIe-S142(i)
Models
PCIe-S112
PCIe-S112i
PCIe-S142
PCIe-S142i
COM Ports
Ports
2 x 9-wire RS-232
2 x RS-422/485
Baud Rate
300 ~ 921600 bps
Data Bits
5, 6, 7, 8
Parity
None, Even, Odd, Mark, Space
Stop Bits
1, 1.5, 2
FIFO
Internal 256 bytes
Isolation
-
3000 VDC
-
3000 VDC
Power
Consumption
120 mA @ 5 V
440 mA @ 5 V
120 mA @ 5 V
440 mA @ 5 V
Mechanical
Dimensions (W x L x D)
94 x 109 x 22
Connector
2 x DB9 (Male)
Environmental
Operating Temperature
0°C ~ +60°C
Storage Temperature
-20°C ~ +70°C
Humidity
5 ~ 85% RH, Non-condensing

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 10 -
1.2.2 PCIe-S114(i)/PCIe-S144(i)
Models
PCIe-S114
PCIe-S114i
PCIe-S144
PCIe-S144i
COM Ports
Ports
4 x 9-wire RS-232
4 x RS-422/485
Baud Rate
300 ~ 921600 bps
Data Bits
5, 6, 7, 8
Parity
None, Even, Odd, Mark, Space
Stop Bits
1, 1.5, 2
FIFO
Internal 256 bytes
Isolation
-
3000 VDC
-
3000 VDC
Power
Consumption
120 mA @ 5 V
880 mA @ 5 V
120 mA @ 5 V
880 mA @ 5 V
Mechanical
Dimensions (W x L x D)
110 x 110 x 22
100 x 114 x 22
Connector
Female DB-37
Environmental
Operating Temperature
0°C ~ +60°C
Storage Temperature
-20°C ~ +70°C
Humidity
5 ~ 85% RH, Non-condensing

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 11 -
1.2.3 PCIe-S118/PCIe-S148
Models
PCIe-S118
PCIe-S148
COM Ports
Ports
8 x RS-232
8 x RS-422/485
Baud Rate
2400 ~ 921600 bps
Data Bits
5, 6, 7, 8
Parity
None, Even, Odd, Mark, Space
Stop Bits
1, 1.5, 2
FIFO
Internal 256 bytes
Power
Consumption
120 mA @ 5 V
Mechanical
Dimensions (W x L x D)
90 x 131 x 22
93 x 128 x 22
Connector
Female DB-62
Environmental
Operating Temperature
0°C ~ +60°C
Storage Temperature
-20°C ~ +70°C
Humidity
5 ~ 85% RH, Non-condensing

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 12 -
1.3 Options
Item & Description
PCIe-S112(i)
PCIe-S142(i)
CA-PC09F
9-pin Female D-sub connector
with plastic cover


DN-09-2/DN-09-2F
I/O Connector Block with DIN-
Rail Mounting and two 9-Pin
male Header


CA-0910F
9-pin Female-Female D-sub
Cable, 1 m


CA-0915
9-pin Male-Female D-sub Cable,
1.5 m


CA-090910
9-pin Female D-sub & (9-wire)
RS-422 Cable, 1 m
-


Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 13 -
Item & Description
PCIe-S114 (i)
PCIe-S144 (i)
CA-4002
37-pin Male D-sub connector with
plastic cove


DN-37
I/O Connector Block (Pitch= 5.08
mm) with DIN-Rail Mounting
Include: One CA-3710 (37-pin Male-
Male D-sub Cable 1.0 m)


CA-3710
37-Pin Male-Male D-sub Cable 1 m
(45º)


CA-3710D
37-Pin Male-Male D-sub Cable 1 m
(180º)


CA-3720
DB-37 Male-Male D-sub Cable 2 m
Cable(45 º)


CA-3720D
37-Pin Male-Male D-sub Cable 2 m
(180º)


CA-9-3715D
DB-37 Male(D-sub) to 4-Port DB-9
Male(D-sub) Cable 1.5 M (180 º)



Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 14 -
Item & Description
PCIe-S118
PCIe-S148
CA-9-6210
DB-62 Male(D-sub) to 8-Port DB-9
Male(D-sub) Cable 1 m (180 º)


CA-PC09F
9-pin Female D-sub Connector
with Plastic Cover


CA-PC62M
62-pin Male D-sub Connector
with Plastic Cover


DN-09-2/DN-09-2F
I/O Connector Block with DIN-Rail
Mounting and two 9-pin Male
Headers


CA-0910F
9-pin Female-Female D-sub Cable,
1 m


CA-0915
9-pin Male-Female D-sub Cable,
1.5 M



Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 15 -
2. Hardware Configuration
2.1 Dimensions
2.1.1 PCIe-S112(i)/ PCIe-S142(i)

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 16 -
2.1.2 PCIe-S114(i)/ PCIe-S144(i)
PCIe-S114(i)
PCIe-S144(i)

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 17 -
2.1.3 PCIe-S118/PCIe-S148
PCIe-S118
PCIe-S148

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 18 -
2.2 Wiring Notes for RS-232/422/485
2.2.1 RS-232 Wiring
2.2.2 RS-485 Wiring
Note: FGND is the frame ground that is soldered to the metal shield on the DB-9 cable.

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 19 -
2.2.3 RS-422 Wiring
Note:
1. Usually, you have to connect all signal grounds of RS-422/485 devices together to reduce
common-mode voltage between devices.
2. Twisted-pair cable must be used for the DATA+/- wires.
3. Both two ends of the cable may require a termination resistor connected across the two
wires (DATA+ and DATA-). Typically 120 Ω resisters are used.
4. The Data+ and B pins are positive-voltage pins, and Data- and A pins are negative-voltage
pins in the above figure. The B/A pins may be defined in another way depending on devices,
please check it first.

Serial Communication Board with 2/4/8 RS-232/422/485 Ports
Copyright © 2021 ICP DAS CO., Ltd. All Rights Reserved. - 20 -
2.3 Pin Assignments
2.3.1 PCIe-S112
2.3.2 PCIe-S142
