PISO-P8R8U/P16R16U
PEX-P8R8i/P16R16i
User Manual
Warranty
All products manufactured by ICP DAS are warranted against defective
materials for a period of one year from the date of delivery to the original purchaser.
Warning
ICP DAS assumes no liability for any damage consequent to the use of this
product. ICP DAS reserves the right to change this manual at any time without notice.
The information furnished by ICP DAS is believed to be accurate and reliable.
However, ICP DAS assumes no responsibility for its use, nor for any infringements of
patents or other rights of third parties resulting from its use.
Copyright
Copyright © March 1998~2008 by ICP DAS. All rights are reserved.
Trademark
The names used in this document are for identification purposes only may be
registered trademarks of their respective companies.
License
The user can use, modify and backup this software on a single machine. The
user may not reproduce, transfer or distribute this software, or any copy, in whole or
in part.
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6, Mar/2010, PMH-021-16) -1-

Table of Contents
1. INTRODUCTION.......................................................................................................................................4
1.1. FEATURES AND APPLICATIONS.............................................................................................................6
1.1.1 Features.........................................................................................................................................6
1.1.2 Applications....................................................................................................................................6
1.2. BLOCK DIAGRAM .................................................................................................................................7
1.3. SPECIFICATIONS ...................................................................................................................................8
1.3.1 PISO-P8R8U/PEX-P8R8i...............................................................................................................8
1.3.2 PISO-P16R16U/PEX-P16R16i ............................................................................................................9
1.4. UNPACKING THE HARDWARE.............................................................................................................10
1.5. ORDER INFORMATION ........................................................................................................................10
1.6. PCI DATA ACQUISITION FAMILY .......................................................................................................11
1.7. PRODUCT CHECK LIST........................................................................................................................11
2. HARDWARE CONFIGURATION.........................................................................................................12
2.1. BOARD LAYOUT.................................................................................................................................12
2.2. JUMPER SETTINGS ..............................................................................................................................14
2.2.1 AC Filter Jumpers........................................................................................................................14
2.3. RELAY OUTPUT..................................................................................................................................15
2.4. ISOLATED INPUT.................................................................................................................................16
2.5. DAUGHTER BOARDS...........................................................................................................................18
2.5.1 DB-37............................................................................................................................................18
2.5.2 DN-37 ..........................................................................................................................................18
2.6. PIN ASSIGNMENTS..............................................................................................................................19
3. I/O CONTROL REGISTERS..................................................................................................................20
3.1. DETERMINING THE I/O ADDRESS .......................................................................................................20
3.2. I/O ADDRESS ASSIGNMENT................................................................................................................21
3.3. I/O ADDRESS MAPPING......................................................................................................................22
3.3.1. RESET\ Control Register..............................................................................................................22
3.3.2. CARD ID Register ........................................................................................................................23
3.3.3. I/O Data Register..........................................................................................................................24
4. DOS SDK...................................................................................................................................................25
4.1. PIO_PISO.EXE PROGRAM ................................................................................................................25
4.2. ERROR CODES ....................................................................................................................................26
4.3. LIB FUNCTIONS ..................................................................................................................................26
4.3.1. PIO_DriverInit...............................................................................................................................27
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6, Mar/2010, PMH-021-16) -2-

PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6, Mar/2010, PMH-021-16) -3-
4.3.2. PIO_GetConfigAddressSpace........................................................................................................28
4.3.3. PIO_DriverClose ...........................................................................................................................29
4.3.4. Show_PIO_PISO............................................................................................................................29
4.4. SAMPLE PROGRAM FOR DOS .............................................................................................................30
5. WINDOWS SDK.......................................................................................................................................35
5.1. PIO_PISO.EXE PROGRAM ................................................................................................................35
5.2. PROGRAM ARCHITECTURE .................................................................................................................36
5.3. ERROR CODES ....................................................................................................................................37
5.4. DLL FUNCTIONS ................................................................................................................................37
5.4.1. PISODIO_DriverInit......................................................................................................................38
5.4.2. PISODIO_DriverClose ..................................................................................................................38
5.4.3. PISODIO_GetConfigAddressSpace...............................................................................................39
5.4.4. PISODIO_GetDriverVersion .........................................................................................................40
5.4.5. PISODIO_GetDllVersion...............................................................................................................40
5.4.6. PISODIO_OutputByte....................................................................................................................41
5.4.7. PISODIO_InputByte ......................................................................................................................41
5.5. DEMO PROGRAM................................................................................................................................42
6. APPENDIX................................................................................................................................................43
6.1. REPORTING PROBLEMS.......................................................................................................................43

1. Introduction
Model Number Isolated Digital Input Output Type
PISO-P8R8U/PEX-P8R8i 8 Channels 8 Channels Relay Output
PISO-P16R16U/PEX-P16R16i 16 Channels 16 Channels Relay Output
PISO-PxRyU
(ODM Only)
x Channels y Channels Relay Output
Table 1-1: Model number and card types.
The PISO-P16R16x and PISO-P8R8x series are relay actuator output /
isolation input interface cards for PCs and compatible computers. The former
provides 16 input and 16 output channels and the latter provides 8 input and 8
output channels. The PISO-P16R16U/P8R8U can be easily installed in either a 3.3
V, 5 V or 3.3 V/5 V PCI slot and support true “Plug and Play” operations.
Figure 1-1: 3.3 V PCI-X slots and 5 V PCI slots.
5 V PCI Slots
3.3 V PCI-X Slots
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6, Mar/2010, PMH-021-16) -4-

The PEX-P16R16i/P8R8i are PCI-Express bus interface board of 16/8 channel
relay output and 16/8 channel input . it can be install in PCI-Express 1X , 4X , 8X ,
16X slot .
PCI-E X16
PCI-E X1
PCI-E X1
Figure 1-2: PCI-E X1 slots and PCI-E X16 slots.
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6, Mar/2010, PMH-021-16) -5-

1.1. Features and Applications
1.1.1 Features
Items PISO-P8R8U/PEX-P8R8i PISO-P16R16U/PEX-P16R16i
Common
Features
z3.3 V, 5 V or 3.3 V/5 V Universal PCI Bus add-on card for
PISO-P8R8U/P16R16U
zPCI-Express Bus add-on card for PEX-P8R8i/P16R16i
zOptically isolated digital input
zAC/DC digitally signed input
zAC digital input with filter (jumper selectable)
Input channel 8 16
Input type Optically isolated digital input
Output channel 8 16
Output type Relay output Relay output
Table 1-2: Features of the PISO-P8R8U/P16R16U and PEX-P8R8i/P16R16i card
1.1.2 Applications
•Factory automation
•Laboratory automation
•Communication switching
•Security control
•Product testing
•Energy management
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6, Mar/2010, PMH-021-16) -6-

1.2. Block Diagram
PCI Controller
EEPROM
PCI-Express Slot
Buffers
&
Drivers
Buffers
&
Filters
Photo-couple
Relay
Relay
Relay
Relay
PEX-P16R16i
PCI-E to PCI
Bridge
Photo-couple
Photo-couple
Photo-couple
Figure 1-2-1: Function Block Diagram.
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6, Mar/2010, PMH-021-16) -7-

1.3. Specifications
1.3.1 PISO-P8R8U/PEX-P8R8i
Model Name PISO-P8R8U PEX-P8R8i
Digital Input
Isolation Voltage 3750 Vrms (Photo-couple)
Channels 8
Compatibility 5 V/TTL
Input Voltage Logic 1:AC/DC 5 ~ 24 V(AC 50 ~ 1 kHz)
Logic 0: AC/DC 0 ~ 1 V
Response Speed Without Filter: 50 kHz (Typical)
With Filter: 0.455 kHz (Typical)
Relay Output
Channels 8
Relay Type 4 SPDT 4 SPST
Contact Rating AC:120 V @ 0.5 A
DC: 24 V @ 1 A
Operating Time 1 ms (typical)
Release Time 7 ms (typical)
Insulation Resistance 1000 MΩ
Life Mechanical: 5000000 ops.
Electrical: 100000 ops.
General
Bus Type 3.3 V / 5 V Universal PCI, 32-
bit, 33 MHz PCI-Express x1
Data Bus 16-bit
Card ID Yes(4-bit)
I/O Connector Female DB37 x 1
Dimensions (L x W x D) 149 mm x 105 mm x 22 mm
Power Consumption 800 mA @ +5 V
Operating Temperature 0 ~ 60 °C
Storage Temperature -20 ~ 70 °C
Humidity 5 ~ 85% RH, non-condensing
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6, Mar/2010, PMH-021-16) -8-

1.3.2 PISO-P16R16U/PEX-P16R16i
Model Name PISO-P16R16U PEX-P16R16i
Digital Input
Isolation Voltage 3750 Vrms (Photo-couple)
Channels 16
Compatibility 5 V/TTL
Input Voltage Logic 1:AC/DC 5 ~ 24 V(AC 50 ~ 1 kHz)
Logic 0: AC/DC 0 ~ 1 V
Response Speed Without Filter: 50 kHz (Typical)
With Filter: 0.455 kHz (Typical)
Relay Output
Channels 16
Relay Type 8 SPDT 8 SPST
Contact Rating AC:120 [email protected] A
DC: 24 V@1 A
Operating Time 1 ms (typical)
Release Time 7 ms (typical)
Insulation Resistance 1000 MΩ
Life Mechanical: 5000000 ops.
Electrical: 100000 ops.
General
Bus Type 3.3 V / 5 V Universal PCI,
32-bit, 33 MHz PCI-Express x1
Data Bus 16-bit
Card ID Yes(4-bit)
I/O Connector Female DB37 x 1
40-pin box header x 1
Dimensions (L x W x D) 149 mm x 105 mm x 22 mm
Power Consumption 800 mA @ +5 V
Operating Temperature 0 ~ 60 °C
Storage Temperature -20 ~ 70 °C
Humidity 5 ~ 85% RH, non-condensing
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6,Mar/2010, PMH-021-16) -9-

1.4. Unpacking the Hardware
This I/O card was thoroughly tested and inspected, both mechanically and
electrically, before shipping. It was free of marks and scratches and our delivery
quality policy requires that all equipment be in perfect condition before delivery.
However, some unintentional damage may occur while unpacking. Please read
this section before unpacking the card. Feel free to contact your supplier and
retain your shipping carton in case there are any errors.
CAUTION: This card contains sensitive electronic components that can be
easily damaged by static electricity.
1. This card should be unpacked using an anti-static mat.
2. The user should wear an anti-static wristband, grounded at the same point as
the anti-static mat.
3. Inspect the carton for obvious damage. Either shipping or handing may cause
damages. Be sure there is no shipping or handing damage on the card before
using.
4. After opening the carton, place the system board handle on a grounded anti-
static surface with the component side face up.
CAUTION: Do not apply power to the board if it has been damaged!
1.5. Order Information
•PISO-P8R8U & PEX-P8R8i
8-channel isolated digital input, 8-channel relay output board
•PISO-P16R16U & PEX-P16R16i
16-channel isolated digital input, 16-channel relay output board
Options
•DN-37: I/O connector block with DIN-Rail mounting and 37-pin D-type connector
•DB-37: 37-pin D-type connector pin-to-pin screw terminal for any 37-pin
D-type I/O board connector
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6, Mar/2010, PMH-021-16) -10-

PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6, Mar/2010, PMH-021-16) -11-
1.6. PCI Data Acquisition Family
ICP DAS provides a family of PCI-Bus data acquisition cards. These cards can
be divided into three groups as follows:
1. PCI-series: first generation, isolated or non-isolated cards
PCI-1002/1202/1800/1802/1602: multi-function family, non-isolated
PCI-P16R16/P16C16/P16POR16/P8R8: D/I/O family, isolated
PCI-TMC12A: timer/counter card, non-isolated
2. PIO-series: cost-effective generation, non-isolated cards
PIO-821: multi-function family
PIO-D168/D144/D96/D64/D56/D48/D24: D/I/O family
PIO-DA16/DA8/DA4: D/A family
3. PISO-series: cost-effective generation, isolated cards
PISO-813: A/D card
PISO-P32C32/P32S32WU/P64/C64: D/I/O family
PISO-P8R8/P8SSR8AC/P8SSR8DC/P16R16U/PEX-P16R16i: D/I/O family
PISO-730: D/I/O card
PISO-DA2: D/A card
1.7. Product Check List
In addition to this manual, the package includes the following items:
•One PISO-P8R8U/P16R16U or PEX-P8R8i/P16R16i card
•One ICP DAS PCI CD
•One Quick Start Guide
It is recommended to read the Quick Start Guide first. All important
information is provided in Quick Start Guide as follows:
1. The location of the DOS and Windows software drivers and utilities
2. How to install the software and utilities
3. The location of the diagnostic program
4. FAQ
Attention! If any of these items are missing or damaged, contact the
dealer from whom you purchased the product. Save the
shipping and packing materials in case you want to ship or
store the
p
roduct in the future.

2. Hardware Configuration
2.1. Board Layout
JP9~16
JP1~8 SW1
(
Card ID
)
CON2
CON1
Figure 2-1-1: PISO-P16R16U Board layout and components.
Item Description
CON1 I/O connector
CON2 I/O connector (P16R16U only)
JP1 ~ 8 Filter jumpers
JP9 ~ 16 Filter jumpers (P16R16U only)
SW1 Card ID switch
Table 2-1-1: Components and descriptions.
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6,Mar/2010, PMH-021-16) -12-

CON1 JP1~8 PCI-Express Bus Card ID JP9~16 CON2
Figure 2-1-2: PEX-P16R16i Board layout and components.
Item Description
CON1 I/O connector
CON2 I/O connector (P16R16i only)
JP1 ~ 8 Filter jumpers
JP9 ~ 16 Filter jumpers (P16R16i only)
SW1 Card ID switch
Table 2-1-2: Components and descriptions.
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6,Mar/2010, PMH-021-16) -13-

2.2. Jumper Settings
2.2.1 AC Filter Jumpers
Simply setting the jumpers on the board can change the I/O card configuration.
Each digital input channel can be jumper-configured as a single-pole, AC filter with
a time constant of 1.2 ms. The table below lists each digital input channel and the
corresponding jumper.
Jumper Channel Jumper Channel
JP1 DI0 JP9 DI8
JP2 DI1 JP10 DI9
JP3 DI2 JP11 DI10
JP4 DI3 JP12 DI11
JP5 DI4 JP13 DI12
JP6 DI5 JP14 DI13
JP7 DI6 JP15 DI14
JP8 DI7 JP16 DI15
Table 2-2: Jumper assignments.
The figure below shows how to select the digital input type:
Without Filter For DC Signal
(Default Settling)
With AC Filter
For AC Signal
1
2
3
1
2
3
Figure 2-2. Jumper Settings.
If AC input signals are used, the AC FILTER must be set by shorting pins 2-3
of the corresponding jumpers. If DC input signals are used, the AC FILTER is
optional. If the DC input signal response is less than 20 μs, set the filter to OFF. If
a slow response is required (about 5 to 10 ms) in order to reject either noise or
contact bouncing, short the AC FILTER (Pins 2-3).
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6,Mar/2010, PMH-021-16) -14-

2.3. Relay Output
Whenever data is written to the output control register, the relays will switch to
either NO (Normally Open) or NC (Normally Closed) status as specified by the
control code. A “1” in the control register causes the corresponding relay in an
energized state and shorts the COM (Common) to NO contact; while a “0” in the
control register turns off the corresponding relay and shorts the COM to NC contact.
When the power is first switched on or a reset signal from hardware or software
is occurred, the control register is 0 and all relays short to NC contact. The following
figures show how to use the relay.
Basic Circuitry: (Current Rating < 0.3 A):
Figure 2-3. Basic relay circuit.
Load
AC/ DC
Power Supply
COM NO
Relay Contact
Heavy Loading Application (> 0.3 A):
Power Relay
P16R16U
DO Relay
Power Relay
Contact
Heavy Loading
Figure 2-4. Heavy load relay circuit.
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6,Mar/2010, PMH-021-16) -15-

2.4. Isolated Input
Reading the isolation input register will identify the digital input state of the
photo-couple (isolation input). Figures 2-3 and 2-4 show the basic circuit of the digital
input.
Figure 2-5. Basic Digital Input Circuit.
5 ~ 24 V
AC/DC
Switch
DIA 0
DIB 0
If the AC signal is
used, pins 2-3 of JP1
must be shorted.
Internal
Circuit
Although the normal input voltage range is 5 to 24 V AC or DC, the input can
still be increased to a larger range by choosing suitable external resistors. The
following figure shows how to connect to a larger input. Please note that the input
current should be limited to between 2 mA to 20 mA; too large input current will burn
out the internal resistor Ri, while an input current that is too low will not activate the
photo-coupler isolator. Calculate the input voltage and current, and then replace the
resistor Ri.
PC - 354
Ri= 1.2 K Ω/1 W
I
f
 20mA
Vin
Onboard circuits
External Circuit
Figure 2-6. Isolated Digital Input Circuit
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6,Mar/2010, PMH-021-16) -16-

PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6,Mar/2010, PMH-021-16) -17-
If = 2 mA ~ 20 mA
As a rough estimate:
If Vin = 120 V and the photo-coupler turn-on voltage is ignored,
the result is:
Vin/
If = Ri
Vin = 120(V),
If =10(mA), Ri = Vin/ If
120(V) / 0.01 (A) = 12000 (Ω)
If the resistor Ri is replaced as 1.2 KΩ, the power consumption of Ri can be
calculated as follows:
P = I2Rex = (10 mA) 2 * 1.2KΩ= 1.2 W
The power consumption is 1.2 Watts, but selecting 1.5 or 2 Watts is better.
Thus, a 1.2 K / 2 W resistor can be selected to replace the resistor Ri.

2.5. Daughter Boards
2.5.1 DB-37
Direct connection board
•37-pin D-type connector pin-to-pin screw terminal for any 37-pin D-type I/O board
connector
Figure 2-7: DB-37.
2.5.2 DN-37
I/O connector block with DIN-Rail mounting
•Two 37-pin D-type connectors (one for an extension)
•Pin-to-pin screw terminal for the I/O connector
Figure 2-8: DN-37.
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6,Mar/2010, PMH-021-16) -18-

2.6. Pin Assignments
PCI
Extension Cable
CON 2
CON 2
CON 1
NO: Normally Open
COM: Common
NC: Normally Closed
DIA: Digital Input (Point A)
DIB: Digital Input (Point B)
Figure 2-9: Pin assignments.
PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6,Mar/2010, PMH-021-16) -19-

PISO-P8R8U/P16R16U/PEX-P8R8i/P16R16i User Manual (Ver.1.6,Mar/2010, PMH-021-16) -20-
3. I/O Control Registers
3.1. Determining the I/O Address
The plug & play BIOS will assign the proper I/O address to each PCI device in
the system during the boot up process. The fixed IDs of the PISO-P16R16U card
are as follows:
zVendor / Device ID = 0xE159 / 0x0001
zSub-Vendor / Device ID = 0x1800 / 0x0000
zSub-Aux ID = 0xFF (Don’t care)
ICP DAS provides all necessary functions for identifying and accessing this card.
Please refer to Chapters 4 and 5 for more information regarding the SDK (Software
Development Kit). The driver information is as follows:
1. Resource-allocated information:
•wBase: BASE address mapping for this PC
•wIrq: IRQ channel number allocated for this PC
2. PIO/PISO identification information:
•wSubVendor: Sub-Vendor ID of this board
•wSubDevice: Sub-Device ID of this board
•wSubAux: Sub-Aux ID of this board
3. PC’s physical slot information for the PC:
•wSlotBus: The position of hardware slot ID1 in this PC
•wSlotDevice: The position of hardware slot ID2 in this PC
The PIO_PISO.exe utility program will detect and display the details for all
PIO/PISO cards installed in the PC. Refer to Chapter 4 for more information.
