Proof of Performance
SecuriTEST IP
CCTV Camera Tester for
IP Digital / HD Coax / Analog Systems

2www.idealnetworks.net
SecuriTEST IP
CCTV Camera Tester for
IP Digital / HD Coax /
Analog Systems
SecuriTEST IP is an installation and troubleshooting tester
for digital/IP, HD coax and analog CCTV camera systems.
With a single tester that can power, configure and document,
SecuriTEST IP increases productivity from start to finish.
Supply power to cameras via PoE/PoE+ (Power over Ethernet)
or standard 12V DC power using its internal Li-Ion battery,
eliminating the need for external power adapters and injectors.
The QuickIP™ feature allows installers who are new to IP
camera systems to quickly and easily connect to cameras
without being network experts.
Create professional test reports including video screen shots
to verify the job has been completed successfully and reduce
unpaid call backs.
Physically connect
camera
Connect camera to the
tester using RJ-45, BNC
or Wi-Fi.
Send reports
Send reports from the jobsite
using email or preferred file
sharing service.
Power camera
Power the camera using:
PoE+ (tester battery or
network pass through), 12V DC
power (tester battery).
Document
Create PDF installation reports
with video images, statistics
and camera settings.
Camera Identification
and Login
Automatic network
configuration and connection
to IP cameras.
Camera setup
Comprehensive setup options
including aim, focus, PTZ
presets, network settings (IP),
video settings.
SecuriTEST
®
IP
Camera Configuration, Installation and Troubleshooting

Physically Connect Camera
Connect to any IP or analog camera using RJ-45,
BNC connections or Wi-Fi via network.
Wi-Fi Camera Analog Camera
IP Camera
Power Camera
Whether you are installing or troubleshooting cameras, SecuriTEST IP
supports all your power requirements for IP and analog cameras.
No need for separate power injectors – SecuriTEST IP
includes the following power outputs:
Power the camera using Power over
Ethernet (PoE+), up to 24 watts from the
tester - RJ-45 port.
Power the camera using 12V DC from
the tester - 2.5mm to 3.5mm barrel
connector.
Power the camera by passing PoE+
from the network and through the
tester - RJ-45 port.
3
Proof of Performance

Camera Identification and Login
QuickIP™ automates the process of connecting to
IP cameras, allowing novice technicians to configure
IP cameras as easily as analog cameras. For instances
where dynamic IP addresses are required by the camera,
SecuriTEST IP has a built-in DHCP server making setup
easy and eliminating the need for additional network
hardware.
A suite of networking troubleshooting tools are available
to pinpoint and solve network connectivity issues.
• Display Network Configuration
• Ping / TraceRoute
• Hub blink for Port Identification
• IP network Scan - check for IP address conflicts
IP Camera Setup
SecuriTEST IP oers a comprehensive range of ONVIF and non-ONVIF
camera setup tools to ensure the camera is installed correctly
Analog and HD Camera Setup
Easily setup analog cameras.
1. Configure camera – update camera information and
network settings.
2. Aim and focus - use the high-resolution touchscreen or
the hard keys when wearing gloves.
3. Program presets for PTZ cameras – Program PTZ
camera presets for users to automatically look at
predefined areas.
4.
Take snapshot – save video snapshots including preset
locations for your installation reports.
5. Record video clip – record video clips to demonstrate
complete coverage for PTZ cameras.
Video adjustment PTZ protocol settings Test pattern generator to adjust screens
4www.idealnetworks.net

Professional Reports*
Easily transfer reports from the jobsite – Using
the built-in Wi-Fi and the web browser, test reports
can be sent directly from the tester using email,
your preferred file sharing service or be exported
on microSD card.
Convert unpaid call backs to billable service
calls – Generate professional PDF reports that
provide proof of installation to the client.
No more spreadsheets – Today security engineers
waste time manually filling in excel documents to
create reports. SecuriTEST IP is the first camera
tester to capture camera image(s), network
configuration and automate documentation.
Reduce troubleshooting time – Reports
capture as-built configuration that will help to
reduce troubleshooting on future call backs.
18GB of combined storage –
10GB of internal memory and 8GB available
on the SD memory card included.
* Only applicable when using the ONVIF protocol
Example Report
Eliminate guess work troubleshooting cabling
faults – SecuriTEST IP is used in combination with
the “Cable Tracer/Remote Tool” to pinpoint cabling
faults such as cross overs, miswires, shorts and
opens. The length of the cabling is also provided.
Determine water ingress in data cabling – Many
cables are run outside or in underground conduit
and exposed to moisture. Moisture ingress through
the cable jacket, which is impossible to see, leads
to a number of performance problems.
Data Cable Test (UTP) – Wiremap
SecuriTEST IP includes the ability to identify and trace cables using the digital tone
generator and the “Cable Tracer/Remote Tool”. Choose from four tones and use the
“Cable Tracer/Remote Tool” with variable sensitivity settings to trace either large cable
bundles from a distance or pinpoint a single cable within a bundle.
Cable Tracing – Search for Cabling
5
Proof of Performance

SecuriTEST IP
Fast access to key features –
Short cut menu to instantly launch
your most used tools.
Long battery life – Up to 10
hours continuous usage with a
lithium-ion battery.
Ease of use – High resolution 7”
capacitive touchscreen with 1920 x
1200 resolution display.
One hand operation – Pan/
Tilt/Zoom (PTZ) the camera using
either the touchscreen or the hard
keys.
Accurate setup of 4k
cameras – Digital zoom displays
full detail of high resolution video
on the 7” touchscreen.
6www.idealnetworks.net

RS485 interface –
Control and program Pan/
Tilt/Zoom (PTZ) cameras
and monitor incoming PTZ
control signals to assist in
troubleshooting analog
cameras.
Setup security
monitors – Use the
analog Video Out port on
the tester with the test
pattern generator function
to setup security monitors.
Camera audio testing
using audio in port –
Test microphone equipped
cameras using the tester’s
internal speaker.
Troubleshooting
HDMI – Use the HDMI In
port, connect to any HDMI
source to isolate Network
Video Recorder (NVR) vs
monitor problems.
HDMI In – Eliminates
the need for a separate
monitor.
HDMI output – Display
tester screen on a larger
monitor using HDMI for
greater clarity.
Analog/AHD/CVI/
TVI video input -
Connect to all common
analog and HD-over-coax
cameras for maximum
versatility.
Camera audio
testing using audio
out port – Listen
to the camera audio
through the tester using
external headphones/
earbuds. Useful in noisy
environments.
Power up camera
with PoE+ – RJ-45
network port provides
PoE+ (up to 24 watts)
to the camera using
the internal battery
when network power is
unavailable.
USB charging – High
power 2A USB port to
quickly charge devices
such as mobile phones
and tablets. (Please note
this port does not support
data transfer).
PoE+ troubleshooting
– Display the PoE+
consumption of the
attached camera in real-
time using the power
monitor tool. Displays
voltage by pair and total
wattage drawn.
Data cable testing
– RJ-45 port to perform
wiremap testing of
unshielded twisted pair
(UTP) data cabling.
Automatically identify
cross over cables and
common wiremap faults
using the Tracer/Remote.
microSD slot – Transfer
test reports, screen
captures and video clips,
or update software using
microSD card.
12V DC power supply
– Power any camera using
the built-in 12V/2A DC
power supply.
Flashlight – Bright LED
flashlight with 5/10/30/60
minute auto-o options.
7
Proof of Performance

Ordering Information
Part No. Kit Contents
R171000
SecuriTEST IP – Digital/Analog/HD Coax CCTV Tester.
1 x SecuriTEST IP Camera Tester, 1 x carry case with strap, 2 x
neck straps, 1 x PSU EU/UK/US/AU adapters, 1 x cable tracer/
remote, 1 x 9.84 ft Cat. 5e UTP patch cable, 1 x 9.84 ft coax
cable with two end BNC (m) connectors, 1 x 9.84 ft DC12V 3.5(f)
to 2.5(f) power cable, 2 x RS485 female green plugs, 1 x 1.64
ft RS485 cable with female green plug and two clips, 1 x 1.64
ft audio male jack with other end two clips, 1 x quick reference
guide, 1 x 8GB microSD card and reader with USB adapter
Optional Accessories
Part No. Description
R171050 1 x Replacement Cable Tracer/Remote
R171051
1 x Replacement accessory set for SecuriTEST IP. 1 x coax cable
with two end BNC (m) connectors, 1 x DC12V 3.5(f) to 2.5(f)
power cable, 2 x RS485 female green plug
R171052 1 x Replacement Battery
For replacement accessories, please visit our website.
Basic Specifications
Internal
Memory
Max. Cable
Length
Battery
Life*
Dimension
(inches) Weight Operation
Temp
Operation
Humidity
10GB 328 ft 10 hours
6.3 (L) x
9.9 (W) x
1.9 (D)
2.2 lbs -14°F to
+122°F
30% to
90%
For detailed specifications, please visit our website.
*Battery life is dependent on the load being drawn.
CCTV Camera Tester for
IP Digital / HD Coax / Analog Systems
Proof of Performance
SecuriTEST IP
All Rights Reserved. IDEAL NETWORKS, SecuriTEST,
and the QuickIP logos are trademarks or registered
trademarks of IDEAL INDUSTRIES Networks Limited. Specification subject to change
without notice. E&OE
© IDEAL Networks 2019
Publication no.: 171819, Rev. 3
P-5549
IDEAL Networks North America
300 Roundhill Drive, Suite 1,
Rockaway, NJ 07866, USA
Tel. 973-9 57-7700
contactus@idealnetworks.net
www.idealnetworks.net
