Introduction
SignalTEK NT comprises two hand-held units and a set of standard accessories all held in a
semi-rigid case.
Fig 1 SignalTEK NT components
The Near-End unit is the terminal from where all tests are run and stored. The Remote Unit is
a loopback terminal that enables performance testing. The Near-End Unit and Remote Unit
are paired. When they are both connected to the same network, the Near-End Unit will find
the Remote Unit that it is uniquely paired with, and not any other SignalTEK NT Remote Unit
that may be connected to the same network.
The Near-End unit may be used as a stand-alone device for wiremap testing copper network
cables. When both units are directly connected by a cable, wiremap and cable performance
tests can be run. When the Near-End Unit is connected to a network, it can be used to carry
out a range of IP tests. When both the Near-End and Remote Unit are connected to an active
network, both IP tests and network performance tests are possible.

SignalTEK NT 156875 Iss 3
User Guide Page 5
Care of your SignalTEK NT
Although light and portable, the SignalTEK NT units are robust and have been designed to
operate in a protected outdoor working environment.
To ensure reliable operation:
Avoid very high or low temperatures - SignalTEK NT is designed to operate between 0°C and
+40°C, although you should only charge the batteries between +10°C and +30°C. You can
store the unit safely between -20°C and +70°C.
To avoid damage, when they are not in use we recommend that you keep both SignalTEK NT
units in their carrying case.
Do not use solvents, strong detergents or abrasive materials to clean SignalTEK NT. Use only
cleaning agents approved for use on ABS and polycarbonate plastics.
Final Disposal
When your SignalTEK NT has reached the end of its life you must dispose of both complete
units in accordance with local environmental regulations.
Safety Information
When using SignalTEK NT, always take basic safety precautions to reduce the risk of fire,
electric shock and injury to persons. These include the following:
When connecting to the line, special care must be taken as high voltages may be present on
the line and there may be a danger of electrocution.
Avoid using SignalTEK NT during an electrical storm - there is a remote risk of electric shock
by lightning.
Use only the mains electricity adaptor supplied with your SignalTEK NT.
CLASS 1 LASER PRODUCT. Light output from the fiber optic port can damage eyesight even
though it is invisible. Never stare into open optical ports or the end of a fiber to see if light is
coming out.
Connector Safety
The following connectors conform to EN60950 SELV safety status:
RJ-45 Ethernet port.
USB port.
DC inlet port.
DO NOT CONNECT ANY TELECOMMUNICATIONS
NETWORK TO ANY OF THE TESTER’S PORTS

SignalTEK NT 156875 Iss 3
User Guide Page 6
Power
SignalTEK NT can be powered from:
A rechargeable power module,
Directly from power connected to the DC inlet built in to the power module.
Power Module Management
The power module must be fully charged
before you use it for the first time
A fully charged power module will support up to five hours of heavy, continuous use. For
maximum life of the power module it is recommended to discharge it fully and then recharge
it fully at least once a month. The power module is not user-serviceable. When it has reached
the end of its life, please contact your local IDEAL representative for service.
Power Module Recharging
The power module can be fully recharged in three hours with the SignalTEK NT (either unit)
switched ON or OFF. To recharge the power module, connect the supplied power adaptor to
the DC inlet. For convenience the power module may be removed from, or left attached to,
the unit for charging. The Power LED next to the DC inlet glows green to show that the
battery is being charged, and flashes green to show that it is not being charged. The Near-End
Unit’s power module charge state is indicated at FULL, 2/3, 1/3 and EMPTY by the graphical
power meter shown in the display’s information bar at the top of its LCD display.
Fig 2 Power indications
The Remote Unit’s power module charge state is indicated by an LED directly below the
Autotest key. LED indications are:
Power LED
Status
Green Power ON. Battery level sufficient for use
Red Power ON. Battery charge level low but still
operational
Off Power OFF
Switching ON and OFF
To switch ON the units, press the ON/OFF button. A splash screen showing the IDEAL logo
and model identity is shown on the display. The Near-End unit attempts to detect a network
and the Remote Unit. The home screen is then shown on the display. SignalTEK NT is ready
for use.

SignalTEK NT 156875 Iss 3
User Guide Page 7
To switch OFF either unit, press and hold the Power button for approximately 1/2 second, a
shutdown message is displayed on the screen. The currently stored setup is saved. If the unit
does not switch OFF within five seconds, see Master Reset.Always switch OFF the unit
before removing the power module.
Caution
Do NOT remove the power module when the unit is switched on.
Power Saving
Near-End Unit. Power saving preferences are selected from SETUP>SYSTEM>PREF. Auto Off
can be Disabled (unit remains ON indefinitely), or set to switch the unit OFF after three, 10 or
30 minutes of inactivity. The backlight can be set to Always On, or to dim to 50% brightness
after three minutes of inactivity. Note that when mains power is connected the display is
always on full brightness and the unit remains ON indefinitely.
Remote Unit. The remote unit remains ON indefinitely whether on battery or mains power.
Master Reset
In the unlikely event of a system lock-up which prevents the unit from being switched OFF, it
may be necessary to perform a master reset. This will not delete any stored data.
Remove the power module to access a small aperture in the SignalTEK NT (Fig 3).
Insert a paper clip into the reset hole and press the internal reset switch.
Fig 3
Replace the power module.

SignalTEK NT 156875 Iss 3
User Guide Page 8
Handset Controls, Indicators and Ports
Fig 4
1 RJ 45 port 9 Function keys F1 to F3 17 Link LED
2 RJ 45 activity LED 10 Escape key 18 Status LED
3 RJ 45 link LED 11 Cursor and ENTER keys 19 1000 Mb/s line rate LED
4 Optical port (SFP) 12 ON/OFF button 20 100 Mb/s line rate LED
5 Optical activity LED 13 Power module 21 10 Mb/s line rate LED
6 Optical link LED 14
Charger LED 22 Remote Autotest button
7 USB port 15
DC in connector 23 Power LED
8 LCD color touchscreen
display
16 Autotest button 24 Wi-Fi Adapter
24

SignalTEK NT 156875 Iss 3
User Guide Page 9
Menu Navigation
Cursor and ENTER keys. The arrowed cursor keys are
intuitively marked to move the highlighted field between all
menu icons, settings fields and drop-down menus that appear
on the display. ENTER selects the currently highlighted option.
Escape key. Returns to previous screen or hides the options of
a drop-down menu. Note that when a value in a settings field is
changed, if the Escape key is pressed before
the soft key
‘APPLY’, the value will not be stored.
Autotest key. Immediately runs pre-stored range of tests. The
range is easily changed using the SETUP menu. The Autotest
keys on the Near-End and Remote Unit have identical function.
Function keys. F1 to F3 are to select the corresponding soft
keys at the lower edge of the display.
Fig 5
Soft Keys
The soft keys appear along the bottom edge of the display. Their function changes and is
dependent on the screen currently shown on the display.
Data entry
Fig 6
When you navigate to and select a field that
requires a value or text to be entered, such as a
customer’s name or a URL, a QWERTY
keyboard will be shown on the display (Fig 6
).
All data is entered using the QWERTY
keyboard. Move the key that is highlighted on
the keyboard using the tester’s cursor keys.
ENTER selects the currently highlighted key
which will now
appear in the text window
directly above the keyboard. Key stroke errors
are corrected using the backspace key ( <−
).
Press the
UP cursor key to move the cursor
into the text window for editing.
Press the QWERTY keyboard’s SHIFT key to
change the display from lower to upper case.
Press SHIFT a second time to display symbols
and punctuation characters.
When the text or value has been entered, press
the soft key OK (F1). The display will return to
the previous screen which is now populated
with the required data. You must press the
soft key APPLY to save the changes.

SignalTEK NT 156875 Iss 3
User Guide Page 10
Getting started
Press the soft key DETECT (F1) and the Near-End Unit will determine the mode of operation
dependent on the services detected. The display will show a home screen with one of four
connection symbols. There are two modes of operation, Cable and Ethernet. Cable has one
way of connecting, Ethernet has three.
Modes of Operation
Cable
Cable mode is used for Wiremap testing and
cable route tracing using the tone generator.
When the Near-
End Unit is connected to a
copper cable, with or without an Active Remote,
press the soft key DETECT (F1)
to display all
options available from the Cable mode screen.
When an Active Remote is connected it will be
shown on screen (Fig 7
) and its identification
number displayed. For a full description of
these options, see Tests menu description –
Cable mode.
Fig 7
Ethernet
Fig 8
Ethernet mode is used for a range of IP and
performance tests. There are three ways
to connect in Ethernet mode:-
(1) When the Near-
End Unit and Remote
Unit are directly connected, with copper or
fiber cable, press the soft key DETECT (F1)
to detect all options available (Fig 8
). In
addition to wiremap tests (
copper), cable
performance can be tested and measured.
For a full description of these options see
Tests menu description – Ethernet mode,
page 25.

SignalTEK NT 156875 Iss 3
User Guide Page 11
(2) When the Near-End Unit is connected
to an active network, using copper or
fiber cable, press the soft key DETECT
(F1) to display all options available (Fig
9
). IP tests can be run. For a full
description of these options see – Tests
menu description – Ethernet mode, page
26.
The detected services are PoE
(802.3af/at), ISDN, PBX and Unknown.
The connected Port number and LLDP
Power are displayed (when available.)
The IPv4 and IPv6 addresses assigned to
the tester are displayed (when available).
Fig 9
Fig 10
(3) When both the Near-
End Unit and
Remote Unit are connected to an active
network, using copper or fiber cables,
press the soft key DETECT (F1) to
display all options available (Fig 10). IP
tests and performance tests can be run.
For a full description of these options
see – Tests menu description – Ethernet
mode, page 29.
The detected services are PoE
(802.3af/at), ISDN, PBX and Unknown.
The IPv4 and IPv6 addresses assigned
to the tester are displayed (when
available).

SignalTEK NT 156875 Iss 3
User Guide Page 12
Ports
From the home screen press the soft key
PORTS (F2), highlight the required port
and press ENTER (Fig 11).
Tick the check box to always see this
screen at startup.
Fig 11
Replaceable insert – RJ-45 socket
To replace a damaged or worn RJ-45 socket insert proceed as follows:
Equipment required: Kit, IDEAL part number 150058 – includes Tool x1 and Replacement
Insert x10.
1. Switch the SignalTEK NT off.
2. Remove cables.
3. Carefully push the tool STRAIGHT into the socket. BE CAREFUL - DO NOT MOVE
THE TOOL VERTICALLY!
4. Keeping the tool STRAIGHT firmly pull the insert out from the socket.
5. Using fingers replace a new insert STRAIGHT into the socket and secure in place
by firmly pushing
3. 4. 5.
Fig 12

SignalTEK NT 156875 Iss 3
User Guide Page 13
Setup
All user-defined settings and preferences of the SignalTEK NT are set from the SETUP menu.
A description of the available settings and preferences is found on pages 14 to 18.

SignalTEK NT 156875 Iss 3
User Guide Page 14
Setup menu descriptions
From the home screen, press the soft key SETUP (F3) to display the
Setup menu shown in Fig 13. The settings for all tests, functions and
preferences can be changed and saved from here.
Selecting any of the seven icons will produce the options that follow:
Fig 13
Highlight the System icon and press ENTER to access the settings and preferences listed
below:
Enter your name or your company’s name, address and phone number(s). The details stored
here will appear on all reports exported via a USB key.
This option enables you to manage Jobs as follows: Create new Jobs. View, edit or delete
existing Jobs. Save Jobs to a USB key. Set up Jobs preferences and result Name format. The
‘Activate’ icon selects the Job you require to be active. See Jobs for a full description.
Sets the language for the tester. The on-screen display, and the exported results and reports
will appear in the selected language.
Sets the power saving options, the preferred units of length and the date and time formats.
Export or import setup information to/from a USB key. Use this function when you wish to
copy setup information from one tester to another.
Sets the current date and time. Note that the date and time are recorded against test results
and will appear on exported reports. The internal clock is autonomous of the power module
for up to one day.
For the Near-End Unit this menu item facilitates software
updates downloaded from the
IDEAL website and saved to a USB key. Select the update icon and follow the on-screen
instructions. To update the Remote Unit: with unit switched OFF, insert USB key and then
PRESS and HOLD the AUTOTEST key while switching on the unit.
The LEDs will illuminate in sequence indicating that a software update is in progress. The unit
reboots when the update is complete.
Provides model, software, hardware and firmware information.
Provides the option to return all settings to the factory default. The Near-End and Remote
Unit must be paired after resetting to factory default. Refer to PAIR on page 18.
A FACTORY RESET WILL REMOVE ALL STORED
DATA
AND PAIRING INFORMATION
FROM THE TESTER

SignalTEK NT 156875 Iss 3
User Guide Page 15
Highlight the Tests icon and press ENTER to access the settings and
preferences listed below:
The two wiretests that follow are available
:-
Set the details of the Wiremap test:
· Cable Type
o Cat 3, Cat 5, Cat 5e, Cat 6, Cat 6A, Cat 7 and 7A, Cat 8, USOC8 1Pair,
USOC8 2Pair, USOC8 3Pair, USOC8 4Pair, ETH 1236, ETH 1278, PROFINET 4W,
COAX RGxx, ISDN BRI, DB, Custom
· Shield Type
o UTP - Shield must not be connected for test to pass
o STP - Shield must be connected for test to pass
o UTP / STP - Test can pass if shield is connected or disconnected
· Display Preference
o None, 568A, 568B, USOC, TERA
· Custom NVP.
o Accurate length measurement relies on correct setting of the Nominal
Velocity of Propagation (NVP) for the cable to be tested. Use Custom NVP -
enabling custom NVP and entering number
· Split Pair:
o Enable or disable
· Xover Allowed:
o Enable or disable.
Select from three tones. This avoids confusion when a second or third tester is
being used on the same installation. Choose on which pin, or pin pair, to play
the tone to achieve the best results.
The six IP tests that follow are available
:-
Set the target URL/Numerical address (select from up to 10 targets stored in
the v4 TARGET look up table or edit the currently displayed URL),
Count (Number of times to repeat the Ping - 1 to 999999),
Pause (Interval between successive Pings - 10 to 5000 ms),
Length (Number of bytes in Ping frame payload - 8 to 1000 bytes).
Set the target URL/Numerical address (select from up to 10 targets stored in
the v4 TARGET look up table or edit the currently displayed URL),
Maximum number of hops (2 to 100),
Timeout (Abort timeout for any hop: 2 to 30 secs), Use a short timeout to
reduce test time, or a long timeout to reach remote internet locations.
Protocol (ICMP or UDP as required by your network).
Select Name Lookup if supported by your network. If not required, de-select
Name Lookup to reduce test time.
Select whether the Netscan is to be Local (scan within the range of the tester’s
own IP address) or Custom (scan within the range of the IP address
configured).
Set the Scan Range depending on whether a wide scan or a short test time is
more important.

SignalTEK NT 156875 Iss 3
User Guide Page 16
IP Tests continued
Scan Range
Max Number of Hosts
Test time
Class C/24 256 Short
Class C/20 4096 Medium
Class B/16 65,536 Long
IPv6 Netscan Setup – None required (Automatically set).
Select PoE or PoE Plus to suit your network.
Set minimum power to be detected to suit the demand of your appliance.
Set the target URL/Numerical address (select from up to 10 targets stored in
the v6 TARGET look up table or edit the currently displayed URL),
Count (Number of times to repeat the Ping - 1 to 999999),
Pause (Interval between successive Pings - 1 to 5 seconds),
Length (Number of bytes in the Ping frame payload - 8 to 1000 bytes).
Set the target URL/Numerical address (select from up to 10 targets stored in
the v6 TARGET look up table or edit the currently displayed URL),
Maximum number of hops (1 to 30),
Timeout (Abort timeout for any hop - 2 to 30 secs),
Select Name Lookup if supported by your network. If not required, de-select
Name Lookup to reduce test time.
The five performance tests that follow are available:
Tick IEEE802.3 check box to set the frame failure threshold to 0 and the test
duration to 10 secs. With the tick box unchecked the frame failure threshold
and duration can be set manually to suit your test. The frame size is
permanently set to 1518. Frame fill is always fixed. Select the expected Line
Rate depending on the cable type.
No. of Calls (Set expected number of simultaneous calls on the network – 1 to
10,000),
Threshold (Frames) (Enter the number of errored frames acceptable – 0 to
99),
Duration (Set test duration from 1 second up to 24 hrs).
No. of sessions (Set expected number of simultaneous sessions on the network
– 1 to 500),
Threshold (Frames) (Enter the number of errored frames acceptable – 0 to
99),
Duration (Set test duration from 1 second up to 24 hrs).
Definition (Set to HD or SD),
No. of Streams (Set expected number of simultaneous calls on the network – 1
to 70),
Threshold (Frames) (Enter the number of errored frames acceptable – 0 to
99),
Duration (Set test duration from 1 second up to 24 hrs).
Resolution (Set to VGA, 720p, 1080p, 3MP or 5MP),
CODEC (Set to H.264 or MJPEG),
No. of Cameras (Set the number of cameras in the system),
Threshold (Frames) (Enter the number of errored frames acceptable – 0 to
99).

SignalTEK NT 156875 Iss 3
User Guide Page 17
Select the tests that will run every time the Near-End or Remote Unit’s
Autotest button is pressed. For details of the tests available, see Fig 33.
Select this option to enter up to 10 IPv4 targets in a look up table. The targets
you save here can be quickly selected when running Ping4 and TRoute4 tests.
Select this option to enter up to 10 IPv6 targets in a look up table. The targets
you save here can be quickly selected when running Ping6 and TRoute6 tests.

SignalTEK NT 156875 Iss 3
User Guide Page 18
Enable/disable IPv4 and set IP address as static or dynamic (DHCP)
depending on which type your network supports. If Static is selected, enter
the numerical address, Netmask, Gateway, DNS1 and DNS2.
Enable/disable IPv6 and select ad
dress type as Static, Stateless, Stateful
(DCHP) depending on which type your network supports. If Static is selected,
enter numerical IP address, Prefix (64 or 128), Gateway, DNS1 and DNS2.
The factory set MAC address of the tester is displayed.
The skew between the Ethernet pairs is displayed. Skew is the delay (ns)
between the arrival time of the four pairs of the Gigabit Ethernet signals. It is
measured relative to the first signal to arrive, so that the displayed skew is
always zero for at least one pair.
NOTE
Both MAC and skew data are displayed for information only.
Provides the information that follows on the SFP connected to the Optical
port:
Status – Available or Not Fitted, Vendor, Part number, Rx Power (dBm), Tx
Power (dBm).
See Supported SFP Transceivers below.
When first supplied, the Near-
End and Remote units are paired. When a
different or replacement Remote Unit is used, or the Near-End Unit has been
RESET to factory default settings, sele
ct PAIR from the set up menu and
press the soft key PAIR (F1). When the message ‘Remote detected’ is shown
on the display the units are paired indefinitely.
Provides the change of job reports parameters such as report format (PDF,
CSV), size (Summary, Brief and Full), results content level (All, Pass, Fail) and
wireless password.
See JOBS|OPTIONS|SETUP part on page 33 for details.
Supported SFP Transceivers
The SFP types that follow are supported. The use of other SFP types is possible but correct
operation is not guaranteed.
Type
Manufac
turer
Part No
Speed
Fiber
type
Waveleng
th
Connector
Type
SX Avago AFBR-5705PZ 1Gb/s Multimode 850nm LC Duplex
SX Apac LM28-C3S-TI-N-DD 1Gb/s Multimode 850nm LC Duplex
LX Avago AFCT-5705PZ 1Gb/s Singlemode 1310nm LC Duplex
LX Apac LS38-C3S-TC-N-DD 1Gb/s Singlemode 1310nm LC Duplex
ZX Apac LS48-C3U-TC-N-DD 1Gb/s Singlemode 1550nm LC Duplex

SignalTEK NT 156875 Iss 3
User Guide Page 19
Tests modes
Testing with SignalTEK NT falls into two modes, Cable and Ethernet.
Cable mode
Cable testing comprises of wiremap tests and a tone generator.
When no network or SignalTEK NT Remote Unit is detected, the home screen information bar
will read ‘Cable’. When the TESTS icon is selected, the cable tests shown in the menu map at
Fig 14 are available.
Fig 14 Tests menu map – Cable testing
Ethernet mode
Ethernet testing is divided into three categories that are dependent on the services detected
by the Near-End Unit. All available tests are illustrated in the three menu maps that follow.
(1) When a SignalTEK NT Remote Unit is directly connected but no active network is detected,
the home screen information bar will read ‘Ethernet’. When the TESTS icon is selected, the
Ethernet tests shown in the menu map at Fig 15 are available.
Fig 15 Tests menu map – Ethernet testing (1)
(2) When an active network is detected but no SignalTEK NT Remote Unit, the home screen
information bar will read ‘Ethernet’ and when the TESTS icon is selected; the Ethernet tests
shown at Fig 16 are available.
Fig 16 Tests menu map – Ethernet testing (2)

SignalTEK NT 156875 Iss 3
User Guide Page 20
(3) When a SignalTEK NT Remote Unit is detected through an active network the information
bar will read ‘Ethernet’. When the TESTS icon is selected, the Ethernet tests shown at Fig 17
are available.
Fig 17 Test menu map – Ethernet testing (3)
Tests – run, setup and save
To select a test highlight its icon and press Enter. Each test has its own result screen. This is
indicated by the test name being shown in the display’s information bar. Press the soft key
RUN (F1) to start the test. The test will use the setup criteria currently stored for that test.
The F1 soft key changes to STOP, giving you the opportunity to abort the test.
When you want to change the setup criteria before a test is run, press the soft key SETUP
(F3). The display will show a screen where all variables for the test can be changed. Press the
soft key APPLY (F2) to save the changes and return to the result screen.
For all tests a symbol is displayed at the top right hand corner of the screen below the clock in
the display’s information bar.
Indicates test has not
been run and that the
tester is ready.
Will be displayed if the test is
aborted, or when a test has been
run and a fault detected or a
network is unknown or
unreachable.
Indicates test is in
progress.
This symbol is
also displayed while the
tester is detecting a port.
Indicates a test has been run with
no faults detected.
When a test is complete the results will be displayed; the soft keys now read RUN, SAVE and
SETUP. You can save the results now or press Escape to return to the Tests screen and select
another test to run. The results of the previous test are not lost unless you wish to discard
them by pressing the soft key RESET (F1). This arrangement gives you the choice of saving
the results of either one or several tests to a single Result. To find out how Results are stored,
see the description of ‘Jobs’ on page 31.
Press the soft key SAVE (F2) and the Save Results screen is displayed. Dropdown menus give
you the choice of which job and result you would like to store the test under. The remaining
storage capacity is displayed as a percentage. For a full description of the storage of test
results see Jobs.
