IDEAL UTV KIT User manual

UTV KIT
# UTVKIT-2200IEH
1. Exploded Drawing

2.Installation
2.1 Completely insert the rods (2) through the holes on the UTV Kit side extension panels (14).
2.2 Secure the rods with bolt (12).
2.3 Insert the securing pin (3) on each end of rod.
2.4 Insert ramps (1) at the end of the UTV Kit side extension panels.
2.5 Secure ramps with nut (15) and bolt (16).
2.6 Insert the wheel stops (13) at the front of the UTV Kit side extension panels.
Center Drop Panel usage: If side extension’s Center Drop Panels are lowered (folded down), ensure
to securely latch back into level position with platform, prior to lowering lift. Failure to do so, could
result in lift, vehicle & property damage.
3.Parts List
No. Part No. Description Qty.
1 JP23-02200-PB2 Ramp 2
2 JP23-02001-PB2 Rod 4
3 JP04-00005-000 Securing pin 4
4 JP23-04002-PB4 Baffle 4
5 5303-00006-000 Spring washer 4
6 5301-00006-000 Flat washer 4
7 5110-06012-000 Screw 4
8 JP23-04001-PB4 Pin 4
9 JP23-04200-PB4 Drop panel 2
10 5304-00012-000 Circlip 8
11 JP24-00025-000 Spindle 4
12 5121-10016-000 Bolt 8
13 JP17-00011-000 Wheel stop 2
14 JP23-04300-PB4 Side extension panel 2# 1
14-1 JP23-04100-PB4 Side extension panel 1# 1
15 5202-00008-000 Hex nut 4
16 5103-08025-000 Hex bolt 4

LIMITED WARRANTY
Structural Warranty:
The following parts and structural components carry a five year warranty:
Columns Arms Uprights Swivel Pins
Legs Carriages Overhead Beam
Tracks Cross Rails Top Rail Beam
Limited One-Year Warranty:
Tuxedo Distributors, LLC (iDEAL) offers a limited one-year warranty to the original purchaser of Lifts and Wheel Service
equipment in the United States and Canada. Tuxedo will replace, without charge, any part found defective in materials or
workmanship under normal use, for a period of one year after purchase. The purchaser is responsible for all shipping
charges. This warranty does not apply to equipment that has been improperly installed or altered or that has not been
operated or maintained according to specifications.
Other Limitations:
This warranty does not cover:
1. Parts needed for normal maintenance
2. Wear parts, including but not limited to cables, slider blocks, chains, rubber pads and pulleys
3. Replacement of lift and tire changer cylinders after the first 30 days. Aseal kit and installation instructions will
be sent for repairs thereafter.
4. On-site labor
Upon receipt, the customer must visually inspect the equipment for any potential freight damage before signing clear on
the shipping receipt. Freight damage is not considered a warranty issue and therefore must be noted for any potential
recovery with the shipping company.
The customer is required to notify Tuxedo of any missing parts within 72 hours. Timely notification must be received to
be covered under warranty.
Tuxedo will replace any defective part under warranty at no charge as soon as such parts become available from the
manufacturer. No guarantee is given as to the immediate availability of replacement parts.
Tuxedo reserves the right to make improvements and/or design changes to its lifts without any obligation to previously
sold, assembled or fabricated equipment.
There is no other express warranty on the Tuxedo lifts and this warranty is exclusive of and in lieu of all other warranties,
expressed or implied, including all warranties of merchantability and fitness for a particular purpose.
To the fullest extent allowed by law, Tuxedo shall not be liable for loss of use, cost of cover, lost profits, inconvenience,
lost time, commercial loss or other incidental or consequential damages.
This Limited Warranty is granted to the original purchaser only and is not transferable or assignable.
Some states do not allow exclusion or limitation of consequential damages or how long an implied warranty lasts, so the
above limitations and exclusions may not apply. This warranty gives you specific legal rights and you may have other
rights, which may vary from state to state.
1905 N Main St Suite C, Cleburne, TX 76033
Ph 817-558-9337 / Fax [phone]
