Idtech Securemag User manual

USER MANUAL

SecureMag

Encrypted

MagStripe Reader

USB, RS232 and PS2 Interface

80096504-001

RevM 9/16/2015

Page 2 of 74

SecureMag User Manual

FCC WARNING STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and,

if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be required to correct the

interference at his expense.

FCC COMPLIANCE STATEMENT

This device complies with Part 15 of the FCC Rules. Operation of this device is subject to

the following conditions: this device may not cause harmful interference and this device

must accept any interference received, including interference that may cause undesired

operation.

CANADIAN DOC STATEMENT

This digital apparatus does not exceed the Class B limits for radio noise for digital

apparatus set out in the Radio Interference Regulations of the Canadian Department of

Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites

applicables aux appareils numériques de las classe A prescrites dans le Réglement sur le

brouillage radioélectrique édicté par les ministère des Communications du Canada.

CE STANDARDS

An independent laboratory performed testing for compliance to CE requirements. The unit

under test was found compliant to Class B.

Page 3 of 74

SecureMag User Manual

LIMITED WARRANTY

ID TECH warrants to the original purchaser for a period of 12 months from the date of

invoice that this product is in good working order and free from defects in material and

workmanship under normal use and service. ID TECH’s obligation under this warranty is

limited to, at its option, replacing, repairing, or giving credit for any product that returned

to the factory of origin with the warranty period and with transportation charges and

insurance prepaid, and which is, after examination, disclosed to ID TECH’s satisfaction to

be defective. The expense of removal and reinstallation of any item or items of equipment

is not included in this warranty. No person, firm, or corporation is authorized to assume for

ID TECH any other liabilities in connection with the sales of any product. In no event shall

ID TECH be liable for any special, incidental or consequential damages to purchaser or any

third party caused by any defective item of equipment, whether that defect is warranted

against or not. Purchaser’s sole and exclusive remedy for defective equipment, which does

not conform to the requirements of sales, is to have such equipment replaced or repaired by

ID TECH. For limited warranty service during the warranty period, please contact ID

TECH to obtain a Return Material Authorization (RMA) number & instructions for

returning the product.

THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE. THERE ARE NO

OTHER WARRANTIES OR GUARANTEES, EXPRESS OR IMPLIED, OTHER THAN

THOSE HEREIN STATED. THIS PRODUCT IS SOLD AS IS. IN NO EVENT SHALL

ID TECH BE LIABLE FOR CLAIMS BASED UPON BREACH OF EXPRESS OR

IMPLIED WARRANTY OF NEGLIGENCE OF ANY OTHER DAMAGES WHETHER

DIRECT, IMMEDIATE, FORESEEABLE, CONSEQUENTIAL OR SPECIAL OR FOR

ANY EXPENSE INCURRED BY REASON OF THE USE OR MISUSE, SALE OR

FABRICATIONS OF PRODUCTS WHICH DO NOT CONFORM TO THE TERMS

AND CONDITIONS OF THE CONTRACT.

The information contained herein is provided to the user as a convenience. While every

effort has been made to ensure accuracy, ID TECH is not responsible for damages that

might occur because of errors or omissions, including any loss of profit or other

commercial damage, nor for any infringements or patents or other rights of third parties

that may result from its use. The specifications described herein were current at the time of

publication, but are subject to change at any time without prior notice.

ID TECH and Value through Innovation are trademarks of International Technologies &

Systems Corporation. USB (Universal Serial Bus) specification is copyright by Compaq

Computer Corporation, Intel Corporation, Microsoft Corporation, and NEC Corporation.

Windows is registered trademarks of Microsoft Corporation.

ID TECH

10721 Walker Street

Cypress, CA 90630

(714) 761-6368

Page 4 of 74

SecureMag User Manual

Revision History

Revision

Date

Description

05/05/2010

Initial Release

Jenny W

06/14/2010

Added RS232 interface

Jenny W

06/16/2010

General edits and modified Appendix A

Jenny W

06/25/2010

Updated reader command summary

Jenny W

06/28/2010

Updated reader command.

- Added Set Reader Options and Get Reader

Options command

Jenny W

06/29/2010

Added level 4 security features to demo

software section

Jenny W

07/21/2010

- Modified commands for Key Loading

- Removed commands for Enter/Quit Key

Loading mode as they are no longer being

supported

Jenny W

09/07/2010

Added original and enhanced security

structures and descriptions

Bruce K

09/07/2010

Added PS2 interface

Jimmy W

09/10/2010

- Updated demo software screenshots.

- Revised data format information.

- General edits.

Jenny W

09/24/2010

- Added decryption example for level 3 and

4 original and enhanced encryption format.

- Revised to include more detailed

explanations on the command format and

security features

Jenny W

05/02/2011

- Edited original and enhanced encryption

output format

- Added more info in Section 10 Data

Output.

Jenny W

06/27/2011

- Updated setting parameters table

- Added prefix, postfix support in USBKB

and PS2 encrypted output.

- Added 19 bytes ISO card account number

support

Jenny W

01/13/2012

Many updates to the configuration

parameters Appendix A

Bruce K

06/07/2012

Added additional information on the track

status byte

Jenny W

08/20/2012

Added suggestion on having 1 second delay

Jenny W

Page 5 of 74

SecureMag User Manual

between Setting Commands and Get Settings

Commands

02/04/2013

Added the new mask feature in SecureMag

firmware v5.00 for serial interface and v 5.03

for USB interface

Candy H

06/06/2013

Remove key loading command

Candy H

03/26/2014

Update HIDSIZE definition

Clarify data length in enhanced format to be

“Track 1 unencrypted data length”

Jimmy W

Candy H

06/19/2014

Update the track length on page 53

Candy H

9/16/2015

Correct Section 10.5 Encryption Output

Format Setting to correct Hex value

Jason H

Page 6 of 74

SecureMag User Manual

Table of Contents

1. Introduction...................................................................................................... 8

2. Features and Benefits......................................................................................... 8

3. Terms and Abbreviations ................................................................................... 9

4. Applicable Documents..................................................................................... 10

5. Operation ....................................................................................................... 11

6. Specification................................................................................................... 12

7. Command Process........................................................................................... 15

7.1 Get Copyright Information.......................................................................... 17

7.2 Version Report Command........................................................................... 17

7.3 Reader Reset Command.............................................................................. 17

7.4 OPOS/JPOS Command............................................................................... 17

7.5 Arm/Disarm to Read Command................................................................... 17

7.6 Read Buffered MSR Data Command............................................................ 18

7.7 Read MSR Options Command..................................................................... 19

7.8 Set MSR Options Command........................................................................ 19

7.8.1. Beep Volume ....................................................................................................19

7.8.2. Change to Default Settings ...............................................................................19

7.8.3. MSR Reading Settings......................................................................................20

7.8.4. Decoding Method Settings................................................................................20

7.8.5. Terminator Setting ............................................................................................20

7.8.6. Preamble Setting...............................................................................................20

7.8.7. Postamble Setting..............................................................................................21

7.8.8. Track n Prefix Setting.......................................................................................21

7.8.9. Track x Suffix Setting.......................................................................................21

7.8.10. Track Selection .................................................................................................21

7.8.11. Track Separator Selection.................................................................................22

7.8.12. Start/End Sentinel and Track 2 Account Number Only....................................22

8. Security Features............................................................................................. 23

8.1 Encryption Management...................................................................................24

8.2 Check Card Format...........................................................................................24

8.3 MSR Data Masking...........................................................................................24

9. Using the Demo Program................................................................................. 26

9.1 Manual Command...................................................................................... 27

9.2 Decryption................................................................................................. 28

9.3 Reader Operations...................................................................................... 30

10. Data Format.................................................................................................... 31

10.1 Level 1 and level 2 Standard Mode Data Output Format.............................. 31

10.1.1. USB HID Data Format......................................................................... 32

10.1.2. Descriptor Tables................................................................................. 33

10.2 Level 1 and level 2 POS Mode Data Output Format.................................... 36

10.3 DUKPT Level 3 Data Output Original Format ........................................... 39

Page 7 of 74

SecureMag User Manual

10.4 DUKPT Level 4 Data Output Original Format ........................................... 40

10.5 DUKPT Level 3 Data Output Enhanced Format......................................... 41

10.6 Additional Description............................................................................. 45

10.7 Decryption Example................................................................................ 48

10.7.1. Security Level 3 Decryption - Original Encryption Format....................... 48

10.7.2. Security Level 4 Decryption - Original Encryption Format....................... 51

10.7.3. Security Level 3 Decryption - Enhanced Encryption Format .................... 51

10.7.4. Security Level 4 Decryption –Enhanced Encryption Format.................... 54

10.8 Level 4 Activate Authentication Sequence................................................. 55

Appendix A Setting Configuration Parameters and Values ...................................... 60

Appendix B Key Code Table in USB Keyboard Interface ....................................... 68

Page 8 of 74

SecureMag User Manual

1. Introduction

ID TECH SecureMag reader delivers superior reading performance with the ability to

encrypt sensitive card data. The data encryption process prevents card holder information

from being accessed when the data is stored or in transit, so the data remains secure from

end to end. The reader fully supports TDES and AES data encryption using DUKPT key

management method. The SecureMag is offered in USB, RS232 as well as PS2 interfaces.

2. Features and Benefits

Bi-directional card reading

Reads encoded data that meets ANSI/ISO/AAMVA standards and some

custom formats such as ISO track 1 format on track 2 or 3

Reads up to three tracks of card data

A LED and a beeper on the reader provide status of the reading operations

Compatible with USB specification Revision 2.0 (USB interface)

Compatible with HID specification Version 1.1 (USB interface)

Uses standard Windows HID driver for communications; no third party

device driver is required (USB interface)

Provides clear text confirmation data including card holder’s name and a

portion of the PAN as part of the Masked Track Data

User friendly configuration software for device configuration

Page 9 of 74

SecureMag User Manual

3. Terms and Abbreviations

AAMVA American Association of Motor Vehicle Administration

ABA American Banking Association

AES Advanced Encryption Standard

ASIC Application Specific Integrated Circuit

BPI Bits per Inch

CADL California Drivers License Format (obsolescent)

CE European Safety and Emission approval authority

COM Serial Communication

CTS Clear-To-Send

CDC USB to serial driver (Communication Device Class)

DES Data Encryption Standard

DUKPT Derived Unique Key Per Transaction

DMV Department of Motor Vehicle

GND Signal Ground

HID Human Interface Device

IPS Inches per Second

ISO International Organization for Standardization

JIS Japanese Industrial Standard

JPOS Java for Retail Point Of Sale

KB Keyboard

KSN Key Serial Number

LED Light Emitting Diode

LRC Longitudinal Redundancy Check Character.

MAC Message Authentication Code

MSR Magnetic Stripe Reader

OLE Object Linking and Embedding

OPOS OLE for Retail Point Of Sale

OTP One Time Programmable

PAN Primary account number

PCI Payment Card Industry

PID USB Product ID

POS Point of Sale

PPMSR Serial Port Power Magstripe Reader

P/N Part Number

PS/2 IBM Personal System/2 Keyboard Interface

RTS Request To Send

SPI Serial Peripheral Interface

T1, T2, T3 Track 1 data, Track 2 data, Track 3 data

TDES Triple Data Encryption Standard

VID USB Vendor ID

Note: many unusual words used in this document are defined in the Function ID

table on page.

Page 10 of 74

SecureMag User Manual

4. Applicable Documents

ISO 7810 –1985 Identification Cards –Physical

ISO 7811 - 1 through 6 Identification Cards - Track 1 through 3

ISO 7816 - 1 through 4 Identification Cards - Integrated circuit cards with contacts

ISO 4909 Magnetic stripe content for track 3

ISO 7812 Identification Cards –Identification for issuers Part 1 & 2

ISO 7813 Identification Cards –Financial Transaction Cards

ANSI X.94 Retail Financial Services Symmetric Key Management

Page 11 of 74

SecureMag User Manual

5. Operation

A card may be swiped through the reader slot when the LED is green. The magnetic

stripe must face toward the magnetic read head and may be swiped in either direction.

After a card is swiped, the LED will turn off temporarily until the decode process is

completed. If there are no errors decoding the card data then the LED will turn green. If

there are any errors decoding the card data, the LED will turn red for less than one second

to indicate that an error occurred and then turn green.

The reader LED will be off during the data transfer and is ready to read another card

when the LED returns to green. A red LED indicates an error and the beeper will also

provide error indications. The beeper will beep for each correctly read track of data on

the magstripe card. Depending on the security level configured, the card data might be

displayed in clear or encrypted mode.

Page 12 of 74

SecureMag User Manual

6. Specification

Power Consumption

5VDC +/- 10%

Maximum operating current consumption less than 50mA

RS232 interface –external power adaptor supplies power through RS232 cable

USB interface –from host interface. No external power adaptor needed.

Swipe speed

3 to 65 inches per second

Bi-directional

Indicators

Tri-color LED

oRed indicates bad read

oLED off while reading and decoding

oGreen indicates good read, and ready to read

Beeper

oA beep sound indicates good read

Communication Interface

RS232

oBaud Rate –1200, 2400, 4800, 9600, 19200, 38400, 56700, 115200

oData bits –8

oStop bits –1 or 2

oParity –off, odd, even, mark or space

oSupports RTS/CTS hardware and Xon-Xoff software handshaking

USB

oComplies with USB 2.0 specification

PS2 Keyboard

oIBM PS2 interface compatible

Card Size

Supports cards that meets the ISO 7810 and 7811 1-7 standards

Dimension

3.94 inches (length) by 1.38 inches (width) and 1.18 inches (height).

Page 13 of 74

SecureMag User Manual

Interface cable and connector

RS232 interface

oIDT standard RS232 Interface Cable

oDB-9 Female connector with 2mm power jack in the housing

oStandard cable length is 6 feet

oPin Out Table

J1*

Color

Signal

P1*

CASE_GND

SHELL

White

TXD

Green

RXD

Yellow

VCC

from power jack

Brown

RTS

8**

Grey

CTS

4**

Black

GND

*J1 is the connector to PCB end and P1 is DB-9 end

** RTS and CTS are not used unless hardware handshaking support is enabled by

Function ID 0x44 (Handshake)

USB

oIDT standard USB interface cable

oSeries “A” plug

oStandard cable length is 6 feet

oPin Out Table

Color

Signal

CASE_GND

SHELL

GRN

+DATA

Red

V_IN

White

-DATA

BLK

GND

Keyboard wedge

oIDT standard Keyboard Wedge cable

oY cable with dual PS/2 6-pin mini-DIN connectors; male side is connected

to PC, female side connected to KB.

oStandard cable length is 6 feet

oPin Out Table

Color

Signal

CASE_GND

SHELL

White

P-CLK

Green

P-DATA

Yellow

VCC

Brown

K-CLK

Grey

K-DATA

Black

GND

Page 14 of 74

SecureMag User Manual

PS/2 Connector

LED indicator

2mmx5mm, Green/Red dual color under firmware control

Page 15 of 74

SecureMag User Manual

7. Command Process

Command requests and responses are sent to and received from the device. For USB

interface devices, the commands are sent to the device using HID class specific request

Set_Report (21 09 …). The response to a command is retrieved from the device using

HID class specific request Get_Report (A1 01 …). These requests are sent over the

default control pipe. For RS232 interface devices, please see the commands listed below.

Function ID Table

The complete table of Function ID used in command/response are listed in Appendix A.

It’s recommended to have at least one second delay between Setting Commands and Get

Settings Commands.

Setting Command

The setting data command is a collection of many function setting blocks and its

format is as follows.

Command:

Response: <ACK> or <NAK> for wrong command (invalid funcID, length and

value)

Each function-setting block <FuncSETBLOCK> has following format:

Where:

<FuncID> is one byte identifying the setting(s) for the function.

<Len> is the length count for the following function-setting block <FuncData>.

<FuncData> is the current setting for this function. It has the same format as in

the sending command for this function.

Get Setting Command

This command will send current setting to application.

Command: <STX> <R> <FuncID> <ETX> <LRC 1>

Response: <ACK> <STX> <FuncID> <Len> <FuncData> <ETX> <LRC 2>

<FuncID>, <Len> and <FuncData> definition are same as described above.

Where:

Characters

Hex Value

Description

<STX>

Start of Text

Page 16 of 74

SecureMag User Manual

<ETX>

End of Text

<ACK>

Acknowledge

<NAK>

15 for

RS232 and

USB HID

interface;

FD for USB

KB interface

Negative Acknowledge

Warning: Unsupported ID in setting

Warning: Reader already in OPOS

mode

<R>

Review Setting

<S>

Send Setting

<LRC>

Xor’d all the data before LRC.

Reader Command Summary

ASCII

HEX

Name

Use

‘8’

Requests reader’s copyright notice

‘9’

Version Report

Requests version string

‘F”

Key Loading

Special command to load encryption

keys

‘I’

Reader Reset

Reset the reader. Software reset does

not resend startup string

‘M’

OPOS/ JPOS Command

Command to enter OPOS or JPOS

mode

‘P’

Arm/Disarm to Read

Arm to Capture Buffer Mode MSR

‘Q’

Read Buffered Data

Read Stored MSR Data

‘R’

Read MSR Options

Read various reader optional settings

‘S’

Set MSR Options

Set various reader optional functions

Notation used throughout the document:

Bold: boldface font indicates default setting value

‘2’: single quotation indicates ASCII characters, for example, ‘2’ is 32 in hex

“Number”: a null terminated character string

<Len>: angle brackets indicate a specific character or character string in a command or

response

Hex: the hex character 53 is ‘5’ in ASCII or 83 in decimal. Sometimes hex characters are

represented with an hattached to the end, for example, 53h.

\02: is a way to show that the following number is in hex. It is used by the configuration

program.

Page 17 of 74

SecureMag User Manual

7.1 Get Copyright Information

02 38 03 39

A ‘31-byte’ Copyright Notice will be returned.

Response is as follows:

ACK STX <Copyright String> ETX LRC

Response Example mixed hex and ASCII:

7.2 Version Report Command

02 39 03 38

Response is as follows:

ACK STX<Version String> ETX LRC

Response Example mixed hex and ASCII:

\06\02ID TECH TM3 SecureMag RS232 Reader V 3.19\03\LRC

7.3 Reader Reset Command

02 49 03 48

The reader supports a reset reader command. This allows the host to return the

reader to its default state.

Response is as follows:

7.4 OPOS/JPOS Command

There are three forms of the command:

02 4D 01 30 03 7D Enter Standard Mode (Exit OPOS Mode)

02 4D 01 31 03 7C Enter OPOS Mode

02 4D 01 32 03 7F Enter JPOS Mode

Response is as follows:

17 Reader already in OPOS Mode

15 Command failure (wrong length or wrong parameter)

06 Success

7.5 Arm/Disarm to Read Command

Arm to read:

02 50 01 30 03 LRC

This command enables the MSR to be ready for a card swipe in buffered mode.

Page 18 of 74

SecureMag User Manual

Any previously read data will be erased and reader will wait for the next swipe.

As the user swipes a card, the data will be saved, but will not be sent to the host.

The reader holds the data until receiving the next “Arm to Read” or “MSR Reset”

command.

Disarm to read:

02 50 01 32 03 LRC

This command will disable MSR read and clear any magnetic data in buffered

mode. The reader enters to a disarmed state and will ignore MSR data.

Response is as follows:

Other possible response statuses:

NAK 'P' command length must be 1

NAK 'P' command must be 0x30 or 0x32

NAK Reader not configured for buffered mode

NAK Reader not configured for magstripe read

NAK for keyboard interface is FD, non-KB mode NAK is 15

7.6 Read Buffered MSR Data Command

02 51 01 <Track Selection Option> 03 LRC

The <Track Select Option> byte is defined as follows:

‘0’ Any Track

‘1’ Track 1

‘2’ Track 2

‘3’ Track 1 and Track 2

‘4’ Track 3

‘5’ Track 1 and Track 3

‘6’ Track 2 and Track 3

‘7’ Track 1, Track 2 and Track 3

‘8’ Track 1 and/ or Track 2

‘9’ Track 2 and/ or Track 3

This command requests card data information for the buffered mode.

The selected MSR data is sent to the host with or without envelope format,

according to the operation mode setting.

This command does not erase the data.

Response is as follows:

06 02 <Len_H> <Len_L> <MSR Data> 03 LRC

Page 19 of 74

SecureMag User Manual

Other possible response statuses:

18 'Q' command length must be 1

18 Reader not configured for buffered mode

NAK Already armed

NAK for keyboard interface is FD, non-KB mode NAK is 15

7.7 Read MSR Options Command

02 52 1F 03 LRC

<Response> format:

The current setting data block is a collection of many function-setting blocks

<FuncSETBLOCK> as follows:

Each function-setting block <FuncSETBLOCK> has the following format:

Where:

<FuncID> is one byte identifying the setting(s) for the function.

<Len> is a one byte length count for the following function-setting block <FuncData>

<FuncData> is the current setting for this function. It has the same format as in the

sending command for this function.

<FuncSETBLOCK> are in the order of their Function ID<FuncID>

7.8 Set MSR Options Command

The default value is listed in bold.

7.8.1. Beep Volume

The beep volume and frequency can be each adjusted to two different levels, or

turned off.

02 53 11 01 <Beep Settings>03 LRC

Beep Settings:

‘0’ for beep volume off

‘1’ for beep volume high, low frequency

‘2’ for beep volume high, high frequency

‘3’ for beep volume low, high frequency

‘4’ for beep volume low, low frequency

7.8.2. Change to Default Settings

02 53 18 03 LRC

Page 20 of 74

SecureMag User Manual

This command does not have any <FuncData>. It returns all non-security settings

for all groups to their default values.

7.8.3. MSR Reading Settings

02 53 1A 01<MSR Reading Settings> 03 LRC

MSR Reading Settings:

‘0’ MSR Reading Disabled

‘1’ MSR Reading Enabled

7.8.4. Decoding Method Settings

02 53 1D 01<Decoding Method Settings> 03 LRC

Decoding Method Settings:

‘0’ Raw Data Decoding in Both Directions

‘1’ Decoding in Both Directions

‘2’ Moving stripe along head in direction of encoding

‘3’ Moving stripe along head against direction of encoding

With the bi-directional method, the user can swipe the card in either direction and

still read the data encoded on the magnetic stripe. Otherwise, the card can only be

swiped in one specified direction to read the card. Raw Decoding just sends the

card’s magnetic data in groups of 4 bits per character. No checking is done except

to verify track has or does not have magnetic data.

7.8.5. Terminator Setting

Terminator characters are used to end a string of data in some applications.

02 53 21 01 <Terminator Settings> 03 LRC

Any one character, 00h is none; default is CR (0Dh).

7.8.6. Preamble Setting

Characters can be added to the beginning of a string of data. These can be special

characters for identifying a specific reading station, to format a message header

expected by the receiving host, or any other character string. Up to fifteen ASCII

characters can be defined.

02 53 D2 <Len><Preamble> 03 LRC

Where:

Len = the number of bytes of preamble string

Preamble = {string length}{string}
