IEI Technology TANK-820-H61 Series User manual

TANK -820-H61 E mbedded S ys tem
Page i
User Manual
MODE L:
TANK -820-H61 Series
E mbedded S ys tem with 2nd Generation Intel® Core™ desktop
processor, VGA, DVI-I, Two Gigabit E thernet,
Four USB 2.0, Two USB 3.0, R S -232/422/485,
R oHS Compliant
R ev. 2.08 – 27 December 2017

TANK -820-H61 E mbedded S ys tem
Page ii
R evis ion
Date Version Changes
27 December 2017 2.08 Add Manual Conventions
2 December 2016 2.07 Update the location of CPU_FAN
7 March 2016 2.06 Update Pin Define of RS-232 Serial Port Connector
(COM1~COM4, COM7, COM8)
Update Pin Define of RS-422/485 Serial Port Connector
(COM5, COM6)
26 May 2015 2.05 Update P.N of System Fan
16 December 2014 2.04 Update Section 3.7.10: RJ-45 RS-422/485 Serial Ports
27 December 2013 2.03 Update BIOS version
Updated Section 3.4: System Fan Installation
16 July 2013 2.02 Update Section 1.4: Technical Specifications
(Operating Temperature : -20°C ~ 55°C)
19 June 2013 2.01 Update Section 1.2: Model Variations
22 May 2013 2.00 Change to fanless design
2 April 2013 1.01 Add backplane max. size
12 December 2012 1.00 Initial release

TANK -820-H61 E mbedded S ys tem
Page iii
Copyright
COPYR IGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TR ADE MARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

TANK -820-H61 E mbedded S ys tem
Page i
Manual Conventions
WAR NING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT SUR FACE
This symbol indicates a hot surface that should not be touched without
taking care.

TANK -820-H61 E mbedded S ys tem
Page ii
Table of Contents
1 INTRODUCTION ........................................................................................................... 1
1.1 OVERVIEW................................................................................................................... 2
1.2 MODEL VARIATIONS ..................................................................................................... 3
1.3 FEATURES ................................................................................................................... 3
1.4 TECHNICAL SPECIFICATIONS ........................................................................................ 3
1.5 FRONT PANEL.............................................................................................................. 6
1.6 REAR PANEL ................................................................................................................ 7
1.7 LED INDICATORS ........................................................................................................ 8
1.8 BACKPLANE OPTIONS .................................................................................................. 9
1.9 DIMENSIONS...............................................................................................................11
2 UNPACKING ................................................................................................................ 12
2.1 ANTI-STATIC PRECAUTIONS ........................................................................................ 13
2.2 UNPACKING PRECAUTIONS ........................................................................................ 13
2.3 UNPACKING CHECKLIST............................................................................................. 14
3 INSTALLATION ........................................................................................................... 17
3.1 INSTALLATION PRECAUTIONS ..................................................................................... 18
3.2 CF CARD INSTALLATION ............................................................................................ 18
3.3 HARD DISK DRIVE (HDD) INSTALLATION................................................................... 20
3.4 SYSTEM FAN INSTALLATION......................................................................................... 22
3.5 MOUNTING THE SYSTEM WITH MOUNTING BRACKETS ................................................. 23
3.6 FOOT PAD INSTALLATION ........................................................................................... 24
3.7 EXTERNAL PERIPHERAL INTERFACE CONNECTORS ...................................................... 25
3.7.1 ACC Mode Selection ........................................................................................ 26
3.7.2 AT/ATX Power Mode Selection........................................................................ 26
3.7.3 Audio Connector .............................................................................................. 27
3.7.4 CompactFlash® Type II................................................................................... 27
3.7.5 Digital Input/Output Connector....................................................................... 28
3.7.6 DVI Connector ................................................................................................. 28

TANK -820-H61 E mbedded S ys tem
Page iii
3.7.7 LAN Connectors............................................................................................... 29
3.7.8 Power Input, 3-pin Terminal Block.................................................................. 31
3.7.9 Power Input, 4-pin DIN Connector ................................................................. 31
3.7.10 RJ-45 RS-422/485 Serial Ports...................................................................... 31
3.7.11 RS-232 Serial Port Connectors ...................................................................... 33
3.7.12 USB Connectors............................................................................................. 34
3.7.13 VGA Connector .............................................................................................. 35
3.8 POWERING ON/OFF THE SYSTEM ............................................................................... 36
3.9 POWER...................................................................................................................... 37
3.9.1 ACC ON ........................................................................................................... 38
3.9.1.1 Boot-up...................................................................................................... 38
3.9.1.2 Shutdown................................................................................................... 39
3.9.2 ACC OFF ......................................................................................................... 40
3.9.2.1 Boot-up...................................................................................................... 40
3.9.2.2 Shutdown................................................................................................... 41
4 SYSTEM MOTHERBOARD........................................................................................ 42
4.1 OVERVIEW................................................................................................................. 43
4.1.1 Layout .............................................................................................................. 43
4.2 INTERNAL PERIPHERAL CONNECTORS......................................................................... 44
4.2.1 Battery Connector (BAT1) ............................................................................... 45
4.2.2 BIOS Programming Connector (SPI2)............................................................ 45
4.2.3 CPU Fan Connector (CPU_FAN1).................................................................. 45
4.2.4 EC Debug Connector (CN4)............................................................................ 45
4.2.5 EC Programming Connector (JSPI1).............................................................. 46
4.2.6 LED Connector (J2)......................................................................................... 46
4.2.7 PCH Fan Connector (PCH_FAN).................................................................... 46
4.2.8 SATA 3Gb/s Drive Connectors (SATA1).......................................................... 47
4.2.9 SATA Power Connector (CN1)......................................................................... 47
4.2.10 SMBus Connector (CN3)............................................................................... 47
4.2.11 TPM Connector (TPM1)................................................................................ 47
4.3 EXTERNAL INTERFACE PANEL CONNECTORS................................................................ 48
4.3.1 Audio Jack (JAUDIO1).................................................................................... 49
4.3.2 DIO connector (DIO1)..................................................................................... 49
4.3.3 DVI Connector (DVI_1)................................................................................... 49

TANK -820-H61 E mbedded S ys tem
Page iv
4.3.4 Ethernet and USB2.0 Connectors (USBLAN1)................................................ 50
4.3.5 Ethernet and USB2.0 Connectors (USBLAN2)................................................ 50
4.3.6 Power Connector (PWR2)............................................................................... 51
4.3.7 Power Connector (PWR1)............................................................................... 51
4.3.8 RS-232 Serial Port Connector (COM1)........................................................... 51
4.3.9 RS-232 Serial Port Connector (COM2)........................................................... 51
4.3.10 RS-232 Serial Port Connector (COM3)......................................................... 52
4.3.11 RS-232 Serial Port Connector (COM4)......................................................... 52
4.3.12 RS-232 Serial Port Connector (COM7)......................................................... 52
4.3.13 RS-232 Serial Port Connector (COM8)......................................................... 53
4.3.14 RS-422/485 Serial Port Connectors (COM5)................................................ 53
4.3.15 RS-422/485 Serial Port Connectors (COM6)................................................ 53
4.3.16 USB 3.0 Connectors (USB3_12).................................................................... 53
4.3.17 VGA Connector (VGA1)................................................................................. 54
4.4 JUMPER SETTINGS ..................................................................................................... 54
4.4.1 Clear CMOS Setup (J_CMOS2) ...................................................................... 54
5 BIOS .............................................................................................................................. 55
5.1 INTRODUCTION ......................................................................................................... 56
5.1.1 Starting Setup................................................................................................... 56
5.1.2 Using Setup ...................................................................................................... 56
5.1.3 Getting Help..................................................................................................... 57
5.1.4 Unable to Reboot after Configuration Changes .............................................. 57
5.1.5 BIOS Menu Bar................................................................................................ 57
5.2 MAIN ........................................................................................................................ 59
5.3 ADVANCED ................................................................................................................ 60
5.3.1 ACPI Settings ................................................................................................... 61
5.3.2 RTC Wake Settings ........................................................................................... 62
5.3.3 Trusted Computing........................................................................................... 63
5.3.4 CPU Configuration.......................................................................................... 64
5.3.4.1 CPU Information ...................................................................................... 65
5.3.5 SATA Configuration ......................................................................................... 67
5.3.6 Intel TXT(LT) Configuration............................................................................ 67
5.3.7 USB Configuration........................................................................................... 68
5.3.8 F81216 Secondary Super IO Configuration .................................................... 69

TANK -820-H61 E mbedded S ys tem
Page v
5.3.8.1 Serial Port n Configuration ...................................................................... 70
5.3.9 F81866 Super IO Configuration ...................................................................... 72
5.3.9.1 Serial Port n Configuration ...................................................................... 72
5.3.10 F81866 H/W Monitor..................................................................................... 78
5.3.10.1 Smart Fan Mode Configuration.............................................................. 78
5.3.11 Serial Port Console Redirection..................................................................... 82
5.3.11.1 Console Redirection Settings................................................................... 83
5.3.12 iEi Feature...................................................................................................... 86
5.4 CHIPSET.................................................................................................................... 87
5.4.1 PCH-IO Configuration .................................................................................... 88
5.4.2 System Agent (SA) Configuration .................................................................... 89
5.4.2.1 Graphics Configuration ............................................................................ 89
5.5 BOOT ........................................................................................................................ 91
5.6 SECURITY .................................................................................................................. 93
5.7 EXIT.......................................................................................................................... 94
A REGULATORY COMPLIANCE.................................................................................. 96
B SAFETY PRECAUTIONS ......................................................................................... 102
B.1 SAFETY PRECAUTIONS ............................................................................................. 103
B.1.1 General Safety Precautions ........................................................................... 103
B.1.2 Anti-static Precautions .................................................................................. 103
B.1.3 Product Disposal ........................................................................................... 104
B.2 MAINTENANCE AND CLEANING PRECAUTIONS .......................................................... 105
B.2.1 Maintenance and Cleaning............................................................................ 105
B.2.2 Cleaning Tools............................................................................................... 105
C HAZARDOUS MATERIALS DISCLOSURE........................................................... 107

TANK -820-H61 E mbedded S ys tem
Page vi
L is t of Figures
Figure 1-1: TANK-820-H61 .............................................................................................................2
Figure 1-2: TANK-820-H61 Front Panel ........................................................................................6
Figure 1-3: TANK-820-H61 Rear Panel..........................................................................................7
Figure 1-4: TANK-820-H61 LED Indicators...................................................................................8
Figure 1-5: HPE-3S6 (2P1E) ...........................................................................................................9
Figure 1-6: HPE-3S7 (1P2E) ...........................................................................................................9
Figure 1-7: Physical Dimensions (millimeters)..........................................................................11
Figure 3-1: CF Card Socket .........................................................................................................19
Figure 3-2: CF Card Socket Cover ..............................................................................................19
Figure 3-3: CF Card Installation ..................................................................................................20
Figure 3-4: Unscrew the Cover....................................................................................................20
Figure 3-5: Remove the Cover from TANK-820-H61 .................................................................21
Figure 3-6: HDD Installation ........................................................................................................21
Figure 3-7: HDD Retention Screws .............................................................................................22
Figure 3-8: System Fan Installation ............................................................................................23
Figure 3-9: Mounting Bracket Retention Screws ......................................................................24
Figure 3-10: Foot Pad Installation...............................................................................................25
Figure 3-11: ACC Mode Switch ...................................................................................................26
Figure 3-12: AT/ATX Power Mode Switch ..................................................................................27
Figure 3-13: Audio Connector .....................................................................................................27
Figure 3-14: DIO Connector.........................................................................................................28
Figure 3-15: DVI Connector .........................................................................................................29
Figure 3-16: LAN Connection ......................................................................................................30
Figure 3-17: RJ-45 Ethernet Connector......................................................................................30
Figure 3-18: 3-pin Terminal Block...............................................................................................31
Figure 3-19: Power Input Connector...........................................................................................31
Figure 3-20: RJ-45 RS-422/485 Serial Device Connection........................................................32
Figure 3-21: RJ-45 RS-422/485 Serial Port Connector ..............................................................32
Figure 3-22: DB-9 Connector Pinout Location ..........................................................................33
Figure 3-23: Serial Device Connector.........................................................................................34

TANK -820-H61 E mbedded S ys tem
Page vii
Figure 3-24: DB-9 RS-232 Serial Port Connector ......................................................................34
Figure 3-25: USB Device Connection .........................................................................................35
Figure 3-26: VGA Connector .......................................................................................................36
Figure 3-27: VGA Connector .......................................................................................................36
Figure 3-28: Power Button...........................................................................................................37
Figure 3-29: Power Connectors ..................................................................................................38
Figure 3-30: ACC On: AT Mode ...................................................................................................39
Figure 3-31: ACC On: ATX Mode.................................................................................................39
Figure 3-32: ACC On: Shutdown.................................................................................................40
Figure 3-33: ACC Off: AT Mode...................................................................................................40
Figure 3-34: ACC Off: ATX Mode ................................................................................................41
Figure 3-35: ACC Off: Shutdown.................................................................................................41
Figure 4-1: System Motherboard (Front)....................................................................................43
Figure 4-2: System Motherboard (Rear) .....................................................................................44

TANK -820-H61 E mbedded S ys tem
Page viii
Lis t of Tables
Table 1-1: TANK-820-H61 Model Variations.................................................................................3
Table 1-2: Technical Specifications..............................................................................................5
Table 1-3: LED Indicators Description..........................................................................................8
Table 1-4: Supported Signals ........................................................................................................9
Table 1-5: Rated Voltage and Current ........................................................................................10
Table 3-1: RJ-45 Ethernet Connector LEDs ...............................................................................30
Table 3-2: RJ-45 RS-422/485 Serial Port Pinouts ......................................................................32
Table 3-3: DB-9 Connector Pinouts ............................................................................................33
Table 3-4: Power LED Indicators Description............................................................................38
Table 4-1: Peripheral Interface Connectors ...............................................................................45
Table 4-2: Battery Connector Pinouts (BAT1) ...........................................................................45
Table 4-3: BIOS Programming Connector Pinouts (SPI2)........................................................45
Table 4-4: CPU Fan Connector Pinouts (CPU_FAN1)...............................................................45
Table 4-5: EC Debug Connector Pinouts (CN4).........................................................................46
Table 4-6: EC Programming Connector Pinouts (JSPI1)..........................................................46
Table 4-7: LED Connector Pinouts (J2)......................................................................................46
Table 4-8: PCH Fan Connector Pinouts (PCH_FAN).................................................................46
Table 4-9: SATA 3Gb/s Drive Connectors Pinouts (SATA1)....................................................47
Table 4-10: SATA Power Connector Pinouts (CN1) ..................................................................47
Table 4-11: SMBus Connector Pinouts (CN3)............................................................................47
Table 4-12: TPM Connector Pinouts (TPM1)..............................................................................48
Table 4-13: Rear Panel Connectors ............................................................................................48
Table 4-14: Audio Jack Pinouts (AUDIO1).................................................................................49
Table 4-15: DIO connector Pinouts (DIO1) .................................................................................49
Table 4-16: DVI Connector Pinouts (DVI_1)...............................................................................50
Table 4-17: Ethernet and USB2.0 Connectors Pinouts (USBLAN1) ........................................50
Table 4-18: Ethernet and USB2.0 Connectors Pinouts (USBLAN2) ........................................51
Table 4-19: Power Connector Pinouts (PWR2)..........................................................................51
Table 4-20: Power Connector Pinouts (PWR1)..........................................................................51
Table 4-21: RS-232 Serial Port Connector Pinouts (COM1) .....................................................51

TANK -820-H61 E mbedded S ys tem
Page ix
Table 4-22: RS-232 Serial Port Connector Pinouts (COM2) .....................................................52
Table 4-23: RS-232 Serial Port Connector Pinouts (COM3) .....................................................52
Table 4-24: RS-232 Serial Port Connector Pinouts (COM4) .....................................................52
Table 4-25: RS-232 Serial Port Connector Pinouts (COM7) .....................................................52
Table 4-26: RS-232 Serial Port Connector Pinouts (COM8) .....................................................53
Table 4-27: RS-422/485 Serial Port Connectors Pinouts (COM5)............................................53
Table 4-28: RS-422/485 Serial Port Connectors Pinouts (COM6)............................................53
Table 4-29: USB 3.0 Connectors Pinouts (USB3_12)................................................................54
Table 4-30: VGA Connector Pinouts (VGA1) .............................................................................54
Table 4-31: Jumper .......................................................................................................................54
Table 4-32: Clear CMOS Setup Jumper Settings (J_CMOS2)..................................................54
Table 5-1: BIOS Navigation Keys ................................................................................................57

TANK -820-H61 E mbedded S ys tem
Page x
B IOS Menus
BIOS Menu 1: Main .......................................................................................................................59
BIOS Menu 2: Advanced ..............................................................................................................61
BIOS Menu 3: ACPI Configuration ..............................................................................................61
BIOS Menu 4: RTC Wake Settings ..............................................................................................62
BIOS Menu 5: TPM Configuration ...............................................................................................64
BIOS Menu 6: CPU Configuration ...............................................................................................65
BIOS Menu 7: CPU Configuration ...............................................................................................66
BIOS Menu 8: IDE Configuration.................................................................................................67
BIOS Menu 9: Intel TXT(LT) Configuration.................................................................................68
BIOS Menu 10: USB Configuration .............................................................................................68
BIOS Menu 11: Secondary Super IO Configuration ..................................................................69
BIOS Menu 12: Serial Port n Configuration Menu.....................................................................70
BIOS Menu 13: F81866 Super IO Configuration ........................................................................72
BIOS Menu 14: Serial Port n Configuration Menu.....................................................................72
BIOS Menu 15: Hardware Health Configuration ........................................................................78
BIOS Menu 16: FAN Configuration .............................................................................................79
BIOS Menu 17: Serial Port Console Redirection .......................................................................83
BIOS Menu 18: Console Redirection Settings...........................................................................84
BIOS Menu 19: iEi Feature...........................................................................................................86
BIOS Menu 20: Chipset ................................................................................................................87
BIOS Menu 21: PCH-IO Configuration ........................................................................................88
BIOS Menu 22: System Agent (SA) Configuration ....................................................................89
BIOS Menu 23: Graphics Configuration.....................................................................................90
BIOS Menu 24: Boot .....................................................................................................................91
BIOS Menu 25: Security ...............................................................................................................93
BIOS Menu 26:Exit........................................................................................................................94

TANK -820-H61 E mbedded S ys tem
Page 1
C hapter
1
1Introduction

TANK -820-H61 E mbedded S ys tem
Page 2
1.1 Overview
Figure 1-1: TANK-820-H61
The TANK-820-H61 is an embedded system for wide range temperature environments. It
is powered by the 2nd Generation Intel® Core™ low power desktop processor, uses the
Intel® H61 chipset and has 2.0 GB of DDR3 memory on-board. The TANK-820-H61
series includes one VGA port, one DVI-I port, two GbE LAN ports, four USB 2.0 ports, two
USB 3.0 ports, six RS-232 connectors and two RS-422/485 connectors.

TANK -820-H61 E mbedded S ys tem
Page 3
1.2 Model Variations
The model variations of the TANK-820-H61 series are listed below.
Model No. Variations CPU Expansion Slots
TANK-820-H61
TANK-820-H61-i5/2G/2P1E-R10 Intel® Core™ i5 2xxT Tw o PCI slots
One PCIe x16 slot
(PCIe x8 signal)
TANK-820-H61-i3/2G/2P1E-R10 Intel® Core™ i3 2xxT
TANK-820-H61-P/2G/2P1E-R10 Intel® Pentium® G6xxT
TANK-820-H61-i5/2G/1P2E-R10 Intel® Core™ i5 2xxT One PCI slot
One PCIe x4 slot
(PCIe x1 signal)
One PCIe x16 slot
(PCIe x8 signal)
TANK-820-H61-i3/2G/1P2E-R10 Intel® Core™ i3 2xxT
TANK-820-H61-P/2G/1P2E-R10 Intel® Pentium® G6xxT
Table 1-1: TANK-820-H61 Model Variations
1.3 Features
The TANK-820-H61 features are listed below:
2nd Generation Intel® Core™ low power desktop processors for TANK-820
On-board 2GB DDR3 memory and one DDR3 SO-DIMM slot (system max.
10GB)
Redundant dual wild range DC power support (9 ~ 24 VDC)
Flexible PCI/PCIe expansion slots satisfy customized requirements
Rich I/O functions satisfy various applications
Dual PCIe GbE LAN for high speed network applications
One CompactFlash® socket
1.4 Technical Specifications
The TANK-820-H61 technical specifications are listed in Table 1-2.
S pecifications
S ys tem
CPU 2nd Generation Intel® Core™ low power desktop processor
Chips et Intel® H61

TANK -820-H61 E mbedded S ys tem
Page 4
S pecifications
Memory 1 x 204-pin DDR3 SDRAM SO-DIMM slot (Max. to 10G)
On-board 2GB DDR3 memory
E thernet Controller Dual Realtek RTL8111E PCIe GbE controllers with ASF 2.0 support
I /O a n d Indicators
E thernet 2 x RJ-45 GbE ports
RS-232 4 x RS-232 serial ports (DB-9)
2 x RS-232 serial ports (DB-9 with isolation)
RS-422/R S -485 2 x RS-422/485 serial ports (RJ-45)
USB Interfaces 4 x USB 2.0 ports on front side
2 x USB 3.0 ports on rear side
Dis play 1 x VGA port (2048 x 1536 @ 75Hz)
1 x DVI-I port (1920 x 1080 @ 60Hz)
Audio Connector 1 x Line-out port
1 x Mic-in port
Digital I/O 1 x DB-9 port on rear side
Interior E xpans ions Either one PCIe x8 (via PCIe x16 slot) and two PCI
or one PCIe x1 (via PCIe x4 slot), one PCIe x8 (via PCIe x16 slot)
and one PCI
L E D Indic ators AT power mode LED
ATX power mode LED
CPU temperature alert LED
HDD LED
Power 1 LED
Power 2 LED
S torage
S ATA 2.5’’ SATA HDD bay
CompactFlash® One CompactFlash® Type II socket

TANK -820-H61 E mbedded S ys tem
Page 5
S pecifications
Power
Power S upply Redundant dual DC input
Terminal Block: 9 ~ 24V
DC Jack: 9 ~ 24V
Power Consumption [email protected]A (Intel® Core™ i3-2100 processor with 6GB DDR3
memory) without add-on card
Environmental and Mechanical
Operating Temperature -20°C ~ 60°C with air flow
Storage Temperature -30°C~80°C
Humidity 5% ~ 95%, non-condensing
Mounting Desktop, wall mount
Color Black C + Silver
Chassis Construction Extruded Aluminum Alloy
Phys ical Dimens ions 133 mm x 206 mm x 269 mm (W x H x D)
Operating Shock Half-sine wave shock 5G, 11ms, 3 axis
Operating Vibration Meet MIL-STD-810F 514.5C-2 (with SSD)
Weight (Net/Gross) 4.2 Kg / 6.3 Kg
S afety & E MC CE / FCC
Table 1-2: Technical Specifications

TANK -820-H61 E mbedded S ys tem
Page 6
1.5 Front Panel
The front panel of the TANK-820-H61 has the following features (Figure 1-2):
Figure 1-2: TANK-820-H61 Front Panel
Connectors and buttons on the front panel include the following:
1 x 4-pin power DC jack for 9 V ~ 24 V power input
1 x Power terminal block for 9 V ~ 24 V power input
1 x Mic-in port (pink)
1 x Line-out port (green)
4 x RS-232 serial ports (DB-9)
2 x RS-422/485 serial ports (RJ-45)
2 x Gigabit Ethernet ports (RJ-45)

TANK -820-H61 E mbedded S ys tem
Page 7
4 x USB 2.0 ports
1 x Reset button
6 x LED indicators (Section 1.7)
1 x Power button
1 x CompactFlash® Type II socket
1 x VGA port
1 X DVI-I port
1 x To Ground
3 x Expansion slots
1 x ACC mode switch
1 x AT/ATX mode switch
1.6 R ear Panel
The rear panel of the TANK-820-H61 has the following features (Figure 1-2):
Figure 1-3: TANK-820-H61 Rear Panel
Connectors on the front panel include the following:
1 x DIO connector
2 x RS-232 serial ports (DB-9 with isolation)
2 x USB 3.0 ports
