IEI Technology PCIE-Q370 User manual

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page i
User Manual
Full-Size PICMG 1.3 CPU Card Supports LGA1151 8th Gen.
Intel® Core™ i7/i5/i3, Pentium® or Celeron® CPU,
Intel® Q370 Chipset, DDR4, VGA, Dual Intel® PCIe GbE,
USB 3.1, SATA 6Gb/s, M.2, RS-232, HD Audio and RoHS
Rev. 1.00 – September 21, 2018
MODEL:
PCIE-Q370

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page ii
Revision
Date Version Changes
September 21, 2018 1.00 Initial release

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page iv
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page v
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 FEATURES................................................................................................................... 3
1.3 CONNECTORS ............................................................................................................. 4
1.4 DIMENSIONS............................................................................................................... 5
1.5 DATA FLOW................................................................................................................ 6
1.6 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST........................................................................................................... 10
2.1ANTI-STATIC PRECAUTIONS.......................................................................................11
2.2 UNPACKING PRECAUTIONS........................................................................................11
2.3 PACKING LIST........................................................................................................... 12
2.4 OPTIONAL ITEMS...................................................................................................... 13
3 CONNECTORS ........................................................................................................... 15
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 16
3.1.1 PCIE-Q370 Layout .......................................................................................... 16
3.1.2 Peripheral Interface Connectors ..................................................................... 17
3.1.3 External Interface Panel Connectors............................................................... 18
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 18
3.2.1 +12V ATX Power Connector ........................................................................... 18
3.2.2 Audio Kit Connector ........................................................................................ 19
3.2.3 Battery Connector............................................................................................ 20
3.2.4 Chassis Intrusion Connector............................................................................ 21
3.2.5 DDR4 DIMM Sockets ...................................................................................... 22
3.2.6 Digital I/O Connector...................................................................................... 22
3.2.7 EC Debug Connector....................................................................................... 23
3.2.8 Fan Connector (CPU)...................................................................................... 24
3.2.9 Fan Connectors (System)................................................................................. 25
3.2.10 Front Panel Connector .................................................................................. 25

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page vi
3.2.11 I2CConnector ................................................................................................ 26
3.2.12 Keyboard and Mouse Connector ................................................................... 27
3.2.13 LAN LED Connectors.................................................................................... 28
3.2.1 M.2 2280 Slot, M-Key...................................................................................... 29
3.2.2 Power Button ................................................................................................... 31
3.2.3 RS-232 Serial Ports.......................................................................................... 31
3.2.4 RS-422/485 Serial Port.................................................................................... 32
3.2.5 SATA 6Gb/s Drive Connector .......................................................................... 33
3.2.6 SMBus Connector ............................................................................................ 34
3.2.7 SPI Flash Connector........................................................................................ 35
3.2.8 SPI Flash Connector, EC................................................................................. 36
3.2.9 TPM Connector................................................................................................ 37
3.2.10 USB 2.0 Connectors....................................................................................... 38
3.2.11 USB 2.0 Connector (Type A).......................................................................... 39
3.2.12 USB 3.1 Connector ........................................................................................ 40
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 41
3.3.1 Ethernet Connectors ........................................................................................ 41
3.3.2 USB 3.1 Gen 1 Connectors.............................................................................. 42
3.3.3 VGA Connector................................................................................................ 42
4 INSTALLATION ......................................................................................................... 44
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 45
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 45
4.3 SOCKET LGA1151 CPU INSTALLATION ................................................................... 47
4.4 SOCKET LGA1151 COOLING KIT INSTALLATION ..................................................... 50
4.5 DIMM INSTALLATION.............................................................................................. 52
4.6 SYSTEM CONFIGURATION......................................................................................... 53
4.6.1 AT/ATX Power Mode Setting ........................................................................... 53
4.6.2 Clear CMOS Button......................................................................................... 53
4.6.3 PCIe x16 Channel Mode Setup........................................................................ 54
4.6.4 Flash Descriptor Security Override Jumper.................................................... 54
4.6.5 USB Power Selection....................................................................................... 56
4.7 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 57
4.7.1 SATA Drive Connection ................................................................................... 57
4.8 SOFTWARE INSTALLATION ........................................................................................ 59

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page vii
4.8.1 Driver Download ............................................................................................. 59
4.9 INTEL®AMTSETUP PROCEDURE............................................................................. 61
5 BIOS.............................................................................................................................. 62
5.1 INTRODUCTION......................................................................................................... 63
5.1.1 Starting Setup................................................................................................... 63
5.1.2 Using Setup...................................................................................................... 63
5.1.3 Getting Help..................................................................................................... 64
5.1.4 Unable to Reboot after Configuration Changes.............................................. 64
5.1.5 BIOS Menu Bar................................................................................................ 64
5.2 MAIN........................................................................................................................ 64
5.3ADVANCED............................................................................................................... 66
5.3.1 CPU Configuration .......................................................................................... 67
5.3.2 PCH-FW Configuration................................................................................... 69
5.3.3 Trusted Computing........................................................................................... 70
5.3.4 ACPI Settings................................................................................................... 71
5.3.5 iWDD H/W Monitor......................................................................................... 72
5.3.5.1 Smart Fan Mode Configuration................................................................ 73
5.3.6 F81866 Super IO Configuration...................................................................... 75
5.3.6.1 Serial Port 1 Configuration....................................................................... 76
5.3.6.2 Serial Port 2 Configuration....................................................................... 77
5.3.6.3 Serial Port 3 Configuration....................................................................... 78
5.3.6.4 Serial Port 4 Configuration....................................................................... 79
5.3.7 RTC Wake Settings........................................................................................... 80
5.3.8 Serial Port Console Redirection ...................................................................... 81
5.3.8.1 Legacy Console Redirection Settings....................................................... 84
5.3.9 USB Configuration........................................................................................... 85
5.3.10 CSM Configuration........................................................................................ 86
5.3.11 NVMe Configuration...................................................................................... 87
5.3.12 iEi Feature ..................................................................................................... 88
5.4 CHIPSET ................................................................................................................... 89
5.4.1 System Agent (SA) Configuration .................................................................... 90
5.4.1.1 Memory Configuration ............................................................................. 91
5.4.1.2 Graphics Configuration............................................................................. 91
5.4.1.3 PEG Port Configuration............................................................................ 93

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page viii
5.4.2 PCH-IO Configuration .................................................................................... 94
5.4.2.1 PCI Express Configuration....................................................................... 97
5.4.2.2 SATA Configuration.................................................................................. 99
5.4.2.3 HD Audio Configuration......................................................................... 101
5.5 SECURITY............................................................................................................... 102
5.6 BOOT...................................................................................................................... 103
5.7 SAVE &EXIT .......................................................................................................... 105
A REGULATORY COMPLIANCE............................................................................ 106
B PRODUCT DISPOSAL............................................................................................ 108
C BIOS OPTIONS.........................................................................................................110
D TERMINOLOGY ......................................................................................................114
E DIGITAL I/O INTERFACE......................................................................................118
E.1 INTRODUCTION .......................................................................................................119
E.2ASSEMBLY LANGUAGE SAMPLE 1.......................................................................... 120
E.3ASSEMBLY LANGUAGE SAMPLE 2.......................................................................... 120
F WATCHDOG TIMER............................................................................................... 121
G HAZARDOUS MATERIALS DISCLOSURE....................................................... 124

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page ix
List of Figures
Figure 1-1: PCIE-Q370....................................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: PCIE-Q370 Dimensions (mm) ....................................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Peripheral Interface Connectors .............................................................................16
Figure 3-2: +12V ATX Power Connector Pinout Location........................................................19
Figure 3-3: Audio Connector Location.......................................................................................19
Figure 3-4: Battery Connector Location.....................................................................................21
Figure 3-5: Chassis Intrusion Connector Location...................................................................21
Figure 3-6: DDR4 DIMM Socket Locations.................................................................................22
Figure 3-7: Digital I/O Connector Location................................................................................22
Figure 3-8: EC Debug Connector Location................................................................................23
Figure 3-9: CPU Fan Connector Location..................................................................................24
Figure 3-10: System Fan Connector Location...........................................................................25
Figure 3-11: Front Panel Connector Location...........................................................................26
Figure 3-12: I2C Connector Location..........................................................................................26
Figure 3-13: Keyboard and Mouse Connector Location...........................................................27
Figure 3-14: LAN LED Connector Locations .............................................................................28
Figure 3-15: M.2 2280 Slot Location ...........................................................................................29
Figure 3-16: Power Button Location...........................................................................................31
Figure 3-17: RS-232 Serial Port Locations.................................................................................31
Figure 3-18: RS-422/485 Serial Port Locations..........................................................................32
Figure 3-19: SATA 6Gb/s Drive Connector Locations..............................................................33
Figure 3-20: SMBus Connector Location...................................................................................34
Figure 3-21: SPI Flash Connector Location...............................................................................35
Figure 3-22: SPI EC Flash Connector Location.........................................................................36
Figure 3-23: TPM Connector Location........................................................................................37
Figure 3-24: USB 2.0 Connector Locations ...............................................................................38
Figure 3-25: USB 2.0 Connector (Type A) Pinout Location......................................................39
Figure 3-26: USB 3.1 Connector Location .................................................................................40

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page x
Figure 3-27: External Peripheral Interface Connector..............................................................41
Figure 3-28: Ethernet Connector.................................................................................................41
Figure 3-29: VGA Connector .......................................................................................................43
Figure 4-1: Disengage the CPU Socket Load Lever..................................................................47
Figure 4-2: Remove Protective Cover.........................................................................................48
Figure 4-3: Insert the Socket LGA1151 CPU..............................................................................49
Figure 4-4: Close the Socket LGA1151 ......................................................................................49
Figure 4-5: Cooling Kit Support Bracket....................................................................................51
Figure 4-6: DIMM Installation.......................................................................................................52
Figure 4-7: AT/ATX Power Mode Switch Location....................................................................53
Figure 4-8: Clear CMOS Button Location...................................................................................53
Figure 4-9: Flash Descriptor Security Override Jumper Location ..........................................54
Figure 4-10: SATA Drive Cable Connection...............................................................................57
Figure 4-11: SATA Power Drive Connection..............................................................................58
Figure 4-12: IEI Resource Download Center..............................................................................59

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page xi
List of Tables
Table 1-1: PCIE-Q370 Specifications............................................................................................9
Table 2-1: Packing List.................................................................................................................12
Table 2-2: Optional Items.............................................................................................................14
Table 3-1: Peripheral Interface Connectors...............................................................................18
Table 3-2: External Peripheral Connectors................................................................................18
Table 3-3: +12V ATX Power Connector Pinouts........................................................................19
Table 3-4: Audio Connector Pinouts ..........................................................................................20
Table 3-5: Battery Connector Pinouts........................................................................................21
Table 3-6: Chassis Intrusion Connector Pinouts......................................................................21
Table 3-7: Digital I/O Connector Pinouts....................................................................................23
Table 3-8: EC Debug Connector Pinouts...................................................................................24
Table 3-9: CPU Fan Connector Pinouts......................................................................................24
Table 3-10: System Fan (SYS_FAN1) Connector Pinouts........................................................25
Table 3-11: Front Panel Connector Pinouts...............................................................................26
Table 3-12: I2C Connector Pinouts..............................................................................................27
Table 3-13: Keyboard and Mouse Connector Pinouts..............................................................28
Table 3-14: LAN1 LED Connector (LED_LAN1) Pinouts...........................................................28
Table 3-15: LAN2 LED Connector (LED_LAN2) Pinouts...........................................................28
Table 3-16: M.2 2280 Connector Pinouts ...................................................................................30
Table 3-17: RS-232 Serial Port Pinouts ......................................................................................32
Table 3-18: RS-422/485 Serial Port Pinouts ...............................................................................32
Table 3-19: DB-9 RS-422/485 Pinouts.........................................................................................33
Table 3-20: SATA 6Gb/s Drive Connector Pinouts....................................................................34
Table 3-21: SMBus Connector Pinouts ......................................................................................34
Table 3-22: SPI Flash Connector Pinouts..................................................................................35
Table 3-23: SPI EC Flash Connector Pinouts ............................................................................36
Table 3-24: TPM Connector Pinouts...........................................................................................37
Table 3-25: USB 2.0 Connector Pinouts.....................................................................................38
Table 3-26: USB 2.0 Connector (Type A) Pinouts .....................................................................39
Table 3-27: USB 3.1 Connector Pinouts.....................................................................................40

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page xii
Table 3-28: LAN Pinouts..............................................................................................................41
Table 3-29: USB 3.1 Port Pinouts................................................................................................42
Table 3-30: VGA Connector Pinouts...........................................................................................43
Table 4-1: AT/ATX Power Mode Switch Settings.......................................................................53
Table 4-2: PCIe x16 Channel Mode Setup..................................................................................54
Table 4-3: Flash Descriptor Security Override Jumper Settings.............................................54
Table 4-4: BIOS Options and Configured USB Ports................................................................56
Table 4-5: USB Power Source Setup..........................................................................................56
Table 5-1: BIOS Navigation Keys................................................................................................64
Table 5-2: BIOS Options and Configured USB Ports................................................................96

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page xiii
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................65
BIOS Menu 2: Advanced..............................................................................................................66
BIOS Menu 3: CPU Configuration...............................................................................................67
BIOS Menu 4: PCH-FW Configuration........................................................................................69
BIOS Menu 5: Trusted Computing..............................................................................................70
BIOS Menu 6: ACPI Settings .......................................................................................................71
BIOS Menu 7: iWDD H/W Monitor ...............................................................................................72
BIOS Menu 8: Smart Fan Mode Configuration ..........................................................................73
BIOS Menu 9: F81866 Super IO Configuration ..........................................................................75
BIOS Menu 10: Serial Port 1 Configuration Menu.....................................................................76
BIOS Menu 11: Serial Port 2 Configuration Menu.....................................................................77
BIOS Menu 12: Serial Port 3 Configuration Menu.....................................................................78
BIOS Menu 13: Serial Port 4 Configuration Menu.....................................................................79
BIOS Menu 14: RTC Wake Settings............................................................................................80
BIOS Menu 15: Serial Port Console Redirection.......................................................................81
BIOS Menu 16: Legacy Console Redirection Settings .............................................................84
BIOS Menu 17: USB Configuration.............................................................................................85
BIOS Menu 18: CSM Configuration.............................................................................................86
BIOS Menu 19: NVMe Configuration...........................................................................................87
BIOS Menu 20: iEi Feature...........................................................................................................88
BIOS Menu 21: Chipset................................................................................................................89
BIOS Menu 22: System Agent (SA) Configuration....................................................................90
BIOS Menu 23: Memory Configuration.......................................................................................91
BIOS Menu 24: Graphics Configuration.....................................................................................91
BIOS Menu 25: PEG Port Configuration.....................................................................................93
BIOS Menu 26: PCH-IO Configuration........................................................................................94
BIOS Menu 27: PCI Express Configuration ...............................................................................97
BIOS Menu 28: PCIEX1 Slot/M.2 Slot..........................................................................................97
BIOS Menu 29: SATA Configuration...........................................................................................99
BIOS Menu 30: HD Audio Configuration..................................................................................101

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page xiv
BIOS Menu 31: Security.............................................................................................................102
BIOS Menu 32: Boot...................................................................................................................103
BIOS Menu 33: Save & Exit........................................................................................................105

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page 1
Chapter
1
1 Introduction

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page 2
1.1 Introduction
Figure 1-1: PCIE-Q370
The PCIE-Q370 is a full-size PICMG 1.3 CPU card. It accepts a Socket LGA1151 8th
generation Intel® Core™ i7/i5/i3, Pentium® or Celeron® processor and supports four
288-pin 2666MHz dual-channel DDR4 DIMM modules up to 64 GB.
The PCIE-Q370 provides two GbE interfaces through the Intel® I219LM (with Intel® AMT
11.0 support) and the Intel® I211AT PCIe controllers. The integrated Intel® Q370 chipset
supports six SATA 6Gb/s drives with RAID 0/1/5/10 function.
Two USB 3.1 on the rear panel, two USB 3.1 by internal box header, six USB 2.0 by pin
headers, one USB 2.0 by internal Type A connector, three RS-232, one RS-422/485 and
one M.2 M-key slot provide flexible expansion options. High Definition Audio (HDA)
support ensures HDA devices can be easily implemented on the PCIE-Q370.

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page 3
1.2 Features
The PCIE-Q370 motherboard features are listed below:
Full-size PICMG 1.3 CPU card
8th generation LGA1151 Intel® Core™ i7/i5/i3, Pentium® or Celeron®
processor supported
Intel® Q370 chipset
Four 288-pin 2666 MHz dual-channel DDR4 DIMMs support up to 64 GB
Two Intel® PCIe GbE connectors (LAN1 with Intel® AMT 11.0 support)
Supports PCI Express Generation 3.0
One M.2 2280 M-key slot for storage
Six SATA 6Gb/s connectors support RAID 0, 1, 5, 10 function
Two USB 3.1 ports on the rear I/O
Two USB 3.1 ports via internal box header
Six USB 2.0 ports via internal pin headers
One USB 2.0 via internal Type A connector
Three RS-232 serial ports
One RS-422/485 serial port
TPM V1.2 hardware security function supported by TPM module
High Definition Audio
RoHS compliant

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page 4
1.3 Connectors
The connectors on the PCIE-Q370 are shown in the figure below.
Figure 1-2: Connectors

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page 5
1.4 Dimensions
The main dimensions of the PCIE-Q370 are shown in the diagram below.
Figure 1-3: PCIE-Q370 Dimensions (mm)

PCIE-Q370 Full-size PICMG 1.3 CPU Card
Page 6
1.5 Data Flow
Figure 1-4 shows the data flow between the system chipset, the CPU and other
components installed on the motherboard.
Figure 1-4: Data Flow Diagram
