IEI Technology AFLLX Series User manual

AFOLUX LX Series Flat Panel PC
Page 1
IEI Technology Corp.
User Manual
AFOLUX LX Series Flat Panel PC
MODEL:
AFL LX Series
Fanless All-in-one Panel PC with AMD LX 800 CPU,
TFT LCD, Wireless LAN, Bluetooth, Touch Screen,
RS-232/422/485 and IP 64 Protection
Rev. 2.00 – 28 October, 2010

AFOLUX LX Series Flat Panel PC
Page 2
Revision
Date Version Changes
28 October, 2010 2.00 Updated for R20 version
30 September, 2009 1.21 Added screw torque warning
13 April, 2009 1.20 Added AFL-xxA-LX-R12 and AFL-xxA-LX24V-R11 models
information
October, 2007 1.11 Added new model (AFL-10A-LX) information
August, 2007 1.10 - Added Bluetooth module specifications
- Added AT/ATX mode selection description
- Modified jumper settings information
- Added Watchdog Timer appendix
January, 2007 1.00 Initial release

AFOLUX LX Series Flat Panel PC
Page 3
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

AFOLUX LX Series Flat Panel PC
Page 4
Table of Contents
01 INTRODUCTION.........................................................................................................245H245H11
1H1H1.1 AFOLUX LX SERIES FLAT PANEL PC OVERVIEW ................................................... 246H246H12
2H2H1.1.1 Model Variations.............................................................................................. 247H247H12
3H3H1.1.2 Applications ..................................................................................................... 248H248H13
4H4H1.1.3 Standard Features............................................................................................ 249H249H14
5H5H1.2 EXTERNAL OVERVIEW.............................................................................................. 250H250H14
6H6H1.2.1 General Description......................................................................................... 251H251H14
7H7H1.2.2 Front Panel ...................................................................................................... 252H252H14
8H8H1.2.3 Rear Panel ....................................................................................................... 253H253H15
9H9H1.2.4 Top Panel and Side Panels............................................................................... 254H254H15
10H10H1.2.5 Bottom Panel.................................................................................................... 255H255H16
11H11H1.3 INTERNAL OVERVIEW............................................................................................... 256H256H17
12H12H1.4 SPECIFICATIONS ....................................................................................................... 257H257H17
13H13H1.4.1 Preinstalled Hardware Components................................................................ 258H258H17
14H14H1.4.2 System Specifications....................................................................................... 259H259H18
15H15H1.4.3 Motherboard Specifications............................................................................. 260H260H19
16H16H1.4.4 Flat Panel Screen Specifications ..................................................................... 261H261H20
17H17H1.4.5 Touch Screen Specifications............................................................................. 262H262H21
18H18H1.4.6 Bluetooth Module Specifications ..................................................................... 263H263H21
19H19H1.5 DIMENSIONS............................................................................................................. 264H264H23
20H20H1.5.1 AFL-07A-LX Dimensions................................................................................. 265H265H23
21H21H1.5.2 AFL-08AH-LX Dimensions.............................................................................. 266H266H24
22H22H1.5.3 AFL-10A-LX Dimensions................................................................................. 267H267H25
23H23H1.5.4 AFL-12A-LX Dimensions................................................................................. 268H268H26
24H24H2 MOTHERBOARD....................................................................................................... 269H269H27
25H25H2.1 INTRODUCTION......................................................................................................... 270H270H28
26H26H2.2 CPU SUPPORT .......................................................................................................... 271H271H28
27H27H2.2.1 AMD
®
Geode™ LX 800 500MHz Specifications............................................. 272H272H28
28H28H2.2.2 AMD
®
Geode™ LX 800 500MHz Power Management................................... 273H273H29

AFOLUX LX Series Flat Panel PC
Page 5
29H29H2.3 SYSTEM CHIPSET...................................................................................................... 274H274H29
30H30H2.4 GRAPHICS SUPPORT.................................................................................................. 275H275H30
31H31H2.5 ETHERNET CONTROLLER SPECIFICATIONS................................................................ 276H276H32
32H32H2.5.1 Overview .......................................................................................................... 277H277H32
33H33H2.5.2 Features ........................................................................................................... 278H278H32
34H34H2.6 PERIPHERAL DEVICE INTERFACES,CONNECTORS,AND SLOTS ................................. 279H279H33
35H35H2.6.1 OEM Options................................................................................................... 280H280H33
36H36H2.6.2 Internal Slots.................................................................................................... 281H281H33
37H37H2.6.3 Internal Peripheral Device Connectors........................................................... 282H282H33
38H38H2.6.4 External Peripheral Device Connectors.......................................................... 283H283H34
39H39H3 INSTALLATION ......................................................................................................... 284H284H35
40H40H3.1 INSTALLATION PRECAUTIONS ................................................................................... 285H285H36
41H41H3.2 PREINSTALLED COMPONENTS................................................................................... 286H286H36
42H42H3.3 INSTALLATION AND CONFIGURATION STEPS ............................................................. 287H287H37
43H43H3.4 UNPACKING.............................................................................................................. 288H288H37
44H44H3.4.1 Packing List ..................................................................................................... 289H289H38
45H45H3.5 CF CARD INSTALLATION .......................................................................................... 290H290H39
46H46H3.6 HDD INSTALLATION (AF-12A-LX ONLY) ............................................................... 291H291H41
47H47H3.7 AT / AT X MODE SELECTION...................................................................................... 292H292H43
48H48H3.7.1 AT Power Mode................................................................................................ 293H293H43
49H49H3.7.2 ATX Power Mode............................................................................................. 294H294H44
50H50H3.8 MOUNTING THE SYSTEM .......................................................................................... 295H295H44
51H51H3.8.1 Wall Mounting.................................................................................................. 296H296H44
52H52H3.8.2 Panel Mounting................................................................................................ 297H297H47
53H53H3.8.3 Arm Mounting .................................................................................................. 298H298H50
54H54H3.8.4 Cabinet and Rack Installation ......................................................................... 299H299H52
55H55H3.9 BOTTOM PANEL CONNECTORS ................................................................................. 300H300H54
56H56H3.9.1 LAN Connection............................................................................................... 301H301H54
57H57H3.9.2 Serial Device Connection ................................................................................ 302H302H55
58H58H3.9.3 USB Device Connection................................................................................... 303H303H56
59H59H4 SYSTEM MAINTENANCE ....................................................................................... 304H304H57
60H60H4.1 SYSTEM MAINTENANCE INTRODUCTION .................................................................. 305H305H58
61H61H4.2 MOTHERBOARD REPLACEMENT ............................................................................... 306H306H58

AFOLUX LX Series Flat Panel PC
Page 6
62H62H4.3 INTERNAL ALUMINUM COVER REMOVAL ................................................................. 307H307H58
63H63H4.3.1 AFL-07A-LX Internal Aluminum Cover Removal............................................ 308H308H59
64H64H4.3.2 AFL-08AH-LX Internal Aluminum Cover Removal......................................... 309H309H60
65H65H4.3.3 AFL-10A-LX Internal Aluminum Cover Removal............................................ 310H310H61
66H66H4.3.4 AFL-12A-LX Internal Aluminum Cover Removal............................................ 311H311H62
67H67H4.4 MEMORY MODULE REPLACEMENT........................................................................... 312H312H63
68H68H4.5 JUMPER SETTINGS .................................................................................................... 313H313H65
69H69H4.5.1 JP3: COM3 Pin-9 Signal Select Jumper Settings............................................ 314H314H66
70H70H4.5.2 JP4: COM1 and COM2 Pin-9 Signal Select Jumper Settings......................... 315H315H67
71H71H4.5.3 JP5: COM2 Mode Select Jumper Settings....................................................... 316H316H67
72H72H4.5.4 JP6: COM2 Mode Select Jumper Settings....................................................... 317H317H68
73H73H4.5.4.1 COM2 RS-422 and RS-485 Pinouts ......................................................... 318H318H68
74H74H5 AWARD BIOS SETUP................................................................................................. 319H319H69
75H75H5.1 INTRODUCTION......................................................................................................... 320H320H70
76H76H5.1.1 Starting Setup................................................................................................... 321H321H70
77H77H5.1.2 Using Setup...................................................................................................... 322H322H70
78H78H5.1.3 Getting Help..................................................................................................... 323H323H71
79H79H5.1.4 Main BIOS Menu ............................................................................................. 324H324H71
80H80H5.2 STANDARD CMOS FEATURES .................................................................................. 325H325H73
81H81H5.2.1 IDE Primary Master/Slave .............................................................................. 326H326H76
82H82H5.3 ADVANCED BIOS FEATURES .................................................................................... 327H327H78
83H83H5.4 ADVANCED CHIPSET FEATURES ................................................................................ 328H328H83
84H84H5.5 INTEGRATED PERIPHERALS....................................................................................... 329H329H85
85H85H5.6 POWER MANAGEMENT SETUP .................................................................................. 330H330H89
86H86H5.7 PNP/PCI CONFIGURATIONS ...................................................................................... 331H331H95
87H87H5.8 PC HEALTH STATUS ................................................................................................. 332H332H98
88H88HA SAFETY PRECAUTIONS....................................................................................... 333H333H100
89H89HA.1 SAFETY PRECAUTIONS .......................................................................................... 334H334H101
90H90HA.1.1 General Safety Precautions........................................................................... 335H335H101
91H91HA.1.2 Anti-static Precautions .................................................................................. 336H336H102
92H92HA.2 MAINTENANCE AND CLEANING PRECAUTIONS...................................................... 337H337H102
93H93HA.2.1 Maintenance and Cleaning............................................................................ 338H338H102
94H94HA.2.2 Cleaning Tools............................................................................................... 339H339H103

AFOLUX LX Series Flat Panel PC
Page 7
95H95HB BIOS CONFIGURATION OPTIONS..................................................................... 340H340H104
96H96HB.1 BIOS CONFIGURATION OPTIONS ........................................................................... 341H341H105
97H97HC SOFTWARE DRIVERS........................................................................................... 342H342H108
98H98HC.1 REMOTE MANAGEMENT TOOL............................................................................... 343H343H109
99H99HC.2 TOUCH PANEL DRIVER........................................................................................... 344H344H109
100H100HC.2.1 Introduction................................................................................................... 345H345H109
101H101HC.2.2 Driver Installation..........................................................................................346H346H110
102H102HC.2.3 Touch Panel Driver Configuration.................................................................347H347H113
103H103HD WATCHDOG TIMER ...............................................................................................348H348H114
104H104HE HAZARDOUS MATERIALS DISCLOSURE ........................................................349H349H117
105H105HE.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ......................................350H350H118

AFOLUX LX Series Flat Panel PC
Page 8
List of Figures
106H106HFigure 1-1: Front View..................................................................................................................351H351H15
107H107HFigure 1-2: AFL-07A-LX/AFL-08AH-LX Rear View.....................................................................352H352H15
108H108HFigure 1-3: AFL-08AH-LX Top View............................................................................................353H353H16
109H109HFigure 1-4: AFL-08AH-LX Side View...........................................................................................354H354H16
110H110HFigure 1-5: AFOLUX LX Series Bottom View.............................................................................355H355H17
111H111HFigure 1-6: AFL-07A-LX Dimensions (units in mm) ..................................................................356H356H23
112H112HFigure 1-7: AFL-08AH-LX Dimensions (units in mm)................................................................357H357H24
113H113HFigure 1-8: AFL-10A-LX Dimensions (units in mm) ..................................................................358H358H25
114H114HFigure 1-9: AFL-12A-LX Dimensions (units in mm) ..................................................................359H359H26
115H115HFigure 2-1: AFLMB-LX800 Connector Overview........................................................................360H360H34
116H116HFigure 3-1: Back Cover Retention Screws.................................................................................361H361H39
117H117HFigure 3-2: AFL-08AH-LX Plastic Back Cover Removal ...........................................................362H362H40
118H118HFigure 3-3: CF Card Location......................................................................................................363H363H40
119H119HFigure 3-4: AFL-08AH-LX Plastic Back Cover Replacement....................................................364H364H40
120H120HFigure 3-5: AFL-12A-LX Aluminum Back Cover Retention Screws.........................................365H365H41
121H121HFigure 3-6: Four Hexagonal Pillars on the Bottom Panel.........................................................366H366H41
122H122HFigure 3-7: AFL-12A-LX HDD Bracket Retention Screws.........................................................367H367H42
123H123HFigure 3-8: AF-12A-LX HDD Retention Screws..........................................................................368H368H42
124H124HFigure 3-9: AT/ATX Switch Location...........................................................................................369H369H43
125H125HFigure 3-10: Wall-mounting Bracket...........................................................................................370H370H45
126H126HFigure 3-11: Chassis Support Screws........................................................................................371H371H46
127H127HFigure 3-12: Secure the Panel PC...............................................................................................372H372H47
128H128HFigure 3-13: AFL-07A-LX Panel Opening ...................................................................................373H373H48
129H129HFigure 3-14: AFL-08AH-LX Panel Opening.................................................................................374H374H48
130H130HFigure 3-15: AFL-10A-LX Panel Opening ...................................................................................375H375H48
131H131HFigure 3-16: AFL-12A-LX Panel Opening ...................................................................................376H376H49
132H132HFigure 3-17: Tighten the Panel Mounting Clamp Screws (AFL-10A/12A-LX) .........................377H377H50
133H133HFigure 3-18: AFL-07A-LX/AFL-08AH-LX Arm Mounting Retention Screw Holes....................378H378H51
134H134HFigure 3-19: AFL-10A-LX/AFL-12A-LX Arm Mounting Retention Screw Holes......................379H379H51
135H135HFigure 3-20: The Rack/Cabinet Bracket......................................................................................380H380H52
136H136HFigure 3-21: Secure the Rack/Cabinet Bracket (AFL-10A-LX/AFL-12A-LX)............................381H381H53

AFOLUX LX Series Flat Panel PC
Page 9
137H137HFigure 3-22: Install into a Rack/Cabinet .....................................................................................382H382H54
138H138HFigure 3-23: LAN Connection......................................................................................................383H383H54
139H139HFigure 3-24: Serial Device Connector.........................................................................................384H384H55
140H140HFigure 3-25: USB Device Connection.........................................................................................385H385H56
141H141HFigure 4-1: AFL-07A-LX Aluminum Back Cover Retention Screws.........................................386H386H59
142H142HFigure 4-2: Four Hexagonal Pillars on the Bottom Panel (AFL-07A-LX).................................387H387H59
143H143HFigure 4-3: AFL-08AH-LX Aluminum Back Cover Retention Screws......................................388H388H60
144H144HFigure 4-4: Four Hexagonal Pillars on the Bottom Panel (AFL-08AH-LX)..............................389H389H60
145H145HFigure 4-5: Wireless Module Cables...........................................................................................390H390H61
146H146HFigure 4-6: The Internal Aluminum Cover Removal..................................................................391H391H61
147H147HFigure 4-7: Power Switch Cable..................................................................................................392H392H61
148H148HFigure 4-8: AFL-10A-LX Aluminum Back Cover Retention Screws.........................................393H393H62
149H149HFigure 4-9: Four Hexagonal Pillars on the Bottom Panel (AFL-10A-LX).................................394H394H62
150H150HFigure 4-10: AFL-12A-LX Aluminum Back Cover Retention Screws.......................................395H395H63
151H151HFigure 4-11: Four Hexagonal Pillars on the Bottom Panel (AFL-12A-LX)...............................396H396H63
152H152HFigure 4-12: SO-DIMM Socket Location .....................................................................................397H397H64
153H153HFigure 4-13: DDR SO-DIMM Module Installation........................................................................398H398H64
154H154HFigure 4-14: Jumper Locations...................................................................................................399H399H66

AFOLUX LX Series Flat Panel PC
Page 10
List of Tables
155H155HTable 1-1: Model Variations.........................................................................................................400H400H13
156H156HTable 1-2: AFOLUX LX Series System Specifications..............................................................401H401H19
157H157HTable 1-3: Motherboard Specifications ......................................................................................402H402H20
158H158HTable 1-4: TFT LCD Monitor Specifications...............................................................................403H403H20
159H159HTable 1-5: Touch Panel Specifications.......................................................................................404H404H21
160H160HTable 1-6: Bluetooth Module Specifications..............................................................................405H405H22
161H161HTable 2-1: Geode LX Graphics Features ....................................................................................406H406H31
162H162HTable 4-1: COM3 Pin-9 Signal Select Jumper Settings.............................................................407H407H66
163H163HTable 4-2: COM1 and COM2 Pin-9 Signal Select Jumper Settings..........................................408H408H67
164H164HTable 4-3: COM2 Mode Select Jumper Settings........................................................................409H409H67
165H165HTable 4-4: COM2 Mode Select Jumper Settings........................................................................410H410H68
166H166HTable 4-5: RS-422 Pinouts ...........................................................................................................411H411H68
167H167HTable 4-6: RS-485 Pinouts ...........................................................................................................412H412H68
168H168HTable 5-1: BIOS Navigation Keys................................................................................................413H413H71

AFOLUX LX Series Flat Panel PC
Page 11
1 Introduction
Chapter
1

AFOLUX LX Series Flat Panel PC
Page 12
1.1 AFOLUX LX Series Flat Panel PC Overview
The AFOLUX LX series flat panel PC is a flexible, multi-functional and fanless flat panel
PC that can be applied in diverse operational environments and implemented in
multi-faceted applications. The AFOLUX LX series comes fully kitted with a
high-performance motherboard and a host of other peripheral interface connectors. The
integrated wireless LAN module and Bluetooth module ensure an uninterrupted wireless
connection. The flexible AT/ATX power mode selection allows the AFOLUX series to meet
multiple application requirements. The AFOLUX LX series is designed for ease of use and
easy installation.
1.1.1 Model Variations
The model variations of AFOLUX LX series are listed in 414H414HTable 1-1. The AFOLUX LX
series all comes with a touch screen and an 802.11b/g wireless module.
AFL-07A Brightness LCD Memory Power Input HSUPA
-LX/R/256-R20 400cd/m27” 256MB DDR 12 V DC No
-LX/R/512-R20 400cd/m27” 512MB DDR 12 V DC No
-LX24V/R/256-R20 400cd/m27” 256MB DDR 18~30 V DC No
-LX24V/R/512-R20 400cd/m27” 512MB DDR 18~30 V DC No
AFL-08AH Brightness LCD Memory Power Input HSUPA
-LX/R/256-R20 450cd/m28.4” 256MB DDR 12 V DC No
-LX/R/512-R20 450cd/m28.4” 512MB DDR 12 V DC No
-LX24V/R/256-R20 450cd/m28.4” 256MB DDR 18~30 V DC No
-LX24V/R/512-R20 450cd/m28.4” 512MB DDR 18~30 V DC No
AFL-10A Brightness LCD Memory Power Input HSUPA
-LX/R/256-R20 400cd/m210.4” 256MB DDR 12 V DC No
-LX/RH/256-R20 400cd/m210.4” 256MB DDR 12 V DC Yes
-LX/R/512-R20 400cd/m210.4” 512MB DDR 12 V DC No
-LX/RH/512-R20 400cd/m210.4” 512MB DDR 12 V DC Yes
-LX24V/R/256-R20 400cd/m210.4” 256MB DDR 18~30 V DC No
-LX24V/RH/256-R20 400cd/m210.4” 256MB DDR 18~30 V DC Yes
-LX24V/R/512-R20 400cd/m210.4” 512MB DDR 18~30 V DC No
-LX24V/RH/512-R20 400cd/m210.4” 512MB DDR 18~30 V DC Yes

AFOLUX LX Series Flat Panel PC
Page 13
AFL-12A Brightness LCD Memory Power Input HSUPA
-LX/R/256-R20 500cd/m212.1” 256MB DDR 12 V DC No
-LX/RH/256-R20 500cd/m212.1” 256MB DDR 12 V DC Yes
-LX/R/512-R20 500cd/m212.1” 512MB DDR 12 V DC No
-LX/RH/512-R20 500cd/m212.1” 512MB DDR 12 V DC Yes
-LX24V/R/256-R20 500cd/m212.1” 256MB DDR 18~30 V DC No
-LX24V/RH/256-R20 500cd/m212.1” 256MB DDR 18~30 V DC Yes
-LX24V/R/512-R20 500cd/m212.1” 512MB DDR 18~30 V DC No
-LX24V/RH/512-R20 500cd/m212.1” 512MB DDR 18~30 V DC Yes
Table 1-1: Model Variations
1.1.2 Applications
The AFOLUX LX series all-in-one panel PC is designed for multiple applications. Its
durability and strength makes it an ideal choice for public access computers. Some
possible applications include:
Vehicle Interior device
oTruck PC
oLogistic car PC
General computing
oPC based testing center
oDistance learning
Industrial applications
oPlant environment monitoring system
oFactory automation platform
oManufacturing shop flow
oEquipment and device control
Home and building automation
oDigital surveillance system
oE-home platform
oHome IA control terminal
Self-Service Kiosk
oReceptionist kiosk in hotel and business premises
oSelf registration terminal in hospital and airport

AFOLUX LX Series Flat Panel PC
Page 14
oTicket vending machine for transportation use
1.1.3 Standard Features
Some of the standard features of the AFOLUX LX series flat panel PC include:
Fanless Design
AMD® Geode LX-800 processor
Rugged mechanism design with ABS/PC case
IP 64 dustproof and waterproof front panel
One 256MB/512MB DDR memory module pre-installed
AT/ATX power mode supported
Wireless LAN integrated with PIFA antenna
Dual 10/100Mbps Ethernet support
One CompactFlash®Type II socket support
Simplified installation process
RoHS compliance
1.2 External Overview
1.2.1 General Description
The AFOLUX LX series is a stylish flat panel PC that comprises of a screen, rear panel,
top panel, bottom panel and two side panels (left and right). An ABS/PC plastic front frame
surrounds the front screen. The rear panel provides screw holes for a wall-mounting
bracket compliant with VESA FDMI standard. The bottom panel provides access to
external interface connectors that include LAN, USB 2.0, serial port, reset button, power
connector and power switch.
1.2.2 Front Panel
The front side of the AFOLUX LX series is a flat panel TFT LCD screen with LED backlight
surrounded by an ABS/PC plastic frame.

AFOLUX LX Series Flat Panel PC
Page 15
Figure 1-1: Front View
1.2.3 Rear Panel
The rear panel provides access to retention screw holes that support the wall mounting.
Refer to 415H415HFigure 1-2.
Figure 1-2: AFL-07A-LX/AFL-08AH-LX Rear View
1.2.4 Top Panel and Side Panels
The top panel and side panels of AFOLUX LX series provides access to slots that support
panel mount and rack mount (416H416HFigure 1-3 and 417H417HFigure 1-4).

AFOLUX LX Series Flat Panel PC
Page 16
Figure 1-3: AFL-08AH-LX Top View
Figure 1-4: AFL-08AH-LX Side View
1.2.5 Bottom Panel
The bottom panel of the AFOLUX LX series has the following I/O interfaces (418H418HFigure 1-5):
1 x Audio jack
1 x RS-232 serial port connector
1 x RS-232 or RS-422/485 serial port connector (selected by a jumper)
1 x Power connector
2 x RJ-45 10/100Mbps Ethernet connectors
2 x USB 2.0 connectors
1 x Power switch
1 x Reset button

AFOLUX LX Series Flat Panel PC
Page 17
Figure 1-5: AFOLUX LX Series Bottom View
1.3 Internal Overview
The AFOLUX LX series internal components are protected in a plastic back cover. An
AT/ATX switch is in the left side of the aluminum chassis inside the plastic cover. Other
internal components, the motherboard, wireless LAN module and DDR memory module,
are installed in the aluminum chassis on a metal sheet that protects the rear of the TFT
LCD screen. Below the metal sheet is a circuit board that is connected to the screen and
the motherboard.
1.4 Specifications
1.4.1 Preinstalled Hardware Components
The AFOLUX LX series flat panel PC has the following preinstalled components:
1 x Motherboard
1 x TFT LCD screen
1 x Touch screen
1 x Inverter
1 x Wireless LAN module
1 x DDR memory module
1 x Bluetooth module
1 x AT/ATX switch
1 x HSUPA module (optional)

AFOLUX LX Series Flat Panel PC
Page 18
The technical specifications for some of these components and the system are shown in
the sections below.
1.4.2 System Specifications
The technical specifications for the AFOLUX LX series systems are listed in 419H419HTable 1-2.
SPECIFICATION AFL-07A-LX AFL-08AH-LX AFL-10A-LX AFL-12A-LX
Front Panel ABS/PC plastic front panel
Chassis Aluminum chassis
LCD Panel 7” 8.4” 10.4” 12.1”
Resolution 800 x 480 800 x 600 800 x 600 1024 x 768
Brightness 400cd/m2450cd/m2400cd/m2500cd/m2
Contrast Ratio 400:1 600:1 700:1 700:1
Viewing Angle (H-V) 140/110 160/140 160/140 160/160
RGB Bit 6-bit 6-bit 6-bit 6-bit
Backlight LED backlight LED backlight LED backlight LED backlight
Touch Screen 4-wire resistive type 4-wire resistive type 5-wire resistive type 5-wire resistive type
Extension 1 x Mini PCI (for wireless LAN module)
1 x Bluetooth module (USB interface, Bluetooth v2.0)
Drive Bay N/A N/A N/A
HSUPA Module N/A N/A Optional
1 x 2.5” HDD bay or
optional HSUPA module
SSD CompactFlash®Type II
Audio AMP 1.5W + AMP 1.5W (internal speaker)
I/O 1 x Audio jack
1 x RS-232 serial port
1 x RS-232 or RS-422/485 serial port
2 x 10/100 Mbps Ethernet port
2 x USB 2.0 port
1 x Power switch
1 x Reset button
1 x AT/ATX power switch (internal)
Power AFL-xxA-LX Series: 12 V DC input (36W DC power adapter)
AFL-xxA-LX24V Series: 18~30 V DC input
Power Consumption 20W 20W 25W 29W

AFOLUX LX Series Flat Panel PC
Page 19
SPECIFICATION AFL-07A-LX AFL-08AH-LX AFL-10A-LX AFL-12A-LX
Mounting Feature Panel, Rack, Wall, Arm, Stand
Operating Temperature 0ºC ~ 50ºC 0ºC ~ 50ºC 0ºC ~ 50ºC 0ºC-50ºC
0ºC-40ºC (using HDD)
Relative Humidity 5% ~ 80% RH, non-condensing
Vibration 5 - 17Hz, 0.1” double amplitude displacement.
17 - 640Hz, 1.5G acceleration, peak to peak.
Shock 10G Acceleration, peak to peak (11ms)
Dimension (W x H x D) 226 x 140 x 41 234 x 184 x 42 276 x 227 x 50.7 304 x 246 x 50
Net/Gross Weight 0.6 Kg 0.8 Kg 1.4kg 1.8 Kg
Front Panel Protection IP 64 compliant
Safety Meets UL / CE / CCC
EMC Meets CE / FCC class B
Table 1-2: AFOLUX LX Series System Specifications
1.4.3 Motherboard Specifications
The AFOLUX LX series come with an AFLMB-LX800 motherboard. The technical
specifications of the motherboard are listed in 420H420HTable 1-3.
Specification AFLMB-LX800
CPU AMD®Geode™ LX 800 500Mhz
Southbridge Chipset AMD® Geode™ CS5536
Display CRT integrated in AMD®Geode™ LX800
24-bit TTL integrated in AMD®Geode™ LX800
18-bit LVDS supported by buffer
Memory Supports one 1GB DDR 333/400 200-pin SO-DIMM SDRAM module
Extension One mini PCI slot
BIOS Award BIOS
SSD CF Type II
Super I/O N/A for legacy free
Audio AC'97 Codec Realtek ALC203, AMP 2W
LAN 10/100 Base-T dual RTL8100C
COM 1 x RS-232 serial port

AFOLUX LX Series Flat Panel PC
Page 20
1 x RS-232 or RS-422/485 serial port
IDE One 44-pin IDE connects to two IDE devices
Touch Screen Controller DMC9000
Power Supply DC 12V In
Dimensions 102mm x 186mm
Table 1-3: Motherboard Specifications
1.4.4 Flat Panel Screen Specifications
The AFOLUX LX series come with a TFT LCD monitor with LED backlight. The
specifications for the LCD monitor are shown in 421H421HTable 1-4 below.
Specification AFL-07A-LX AFL-08AH-LX AFL-10A-LX AFL-12A-LX
Size 7” 8.4” 10.4” 12.1”
Resolution 800 x 480 (WVGA) 800 x 600 (SVGA) 800 x 600 (SVGA) 1024 x 768 (XGA)
Pixel Pitch (mm) 0.0635 x 0.1905 0.213 x 0.213 0.264 x 0.264 0.3075 x 0.3075
LCD Color 262K colors 262K colors 262K colors 262K colors
View Angel (H/V) 140/110 160/140 160/140 160/160
Brightness (cd/m2) 400 450 400 500
Contrast Ratio 400:1 600:1 700:1 700:1
RGB Bit 6-bit 6-bit 6-bit 6-bit
Backlight LED LED LED LED
Table 1-4: TFT LCD Monitor Specifications
