IEI Technology IMB-H110-R10 User manual

IMB-H110 microATX Motherboard
Page i
User Manual
MODEL:
IMB-H110
microATX Motherboard Supports 6th Generation LGA1151
Intel® Core™ i7/i5/i3, Pentium® or Celeron® CPU, Intel® H110
Chipset, DDR4, VGA, DVI-I, LVDS, iDP, Dual GbE LAN, USB 3.0,
SATA 6Gb/s, 12 COM Ports, 12 USB Ports, HD Audio and RoHS
Rev. 1.00 – August 23, 2016

IMB-H110 microATX Motherboard
Page ii
Revision
Date Version Changes
August 23, 2016 1.00 Initial release

IMB-H110 microATX Motherboard
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

IMB-H110 microATX Motherboard
Page iv
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT SURFACE
This symbol indicates a hot surface that should not be touched without
taking care.

IMB-H110 microATX Motherboard
Page v
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 FEATURES................................................................................................................... 3
1.3 CONNECTORS ............................................................................................................. 4
1.4 DIMENSIONS............................................................................................................... 5
1.5 DATA FLOW................................................................................................................ 6
1.6 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST........................................................................................................... 10
2.1ANTI-STATIC PRECAUTIONS.......................................................................................11
2.2 UNPACKING PRECAUTIONS........................................................................................11
2.3 PACKING LIST........................................................................................................... 12
2.4 OPTIONAL ITEMS...................................................................................................... 13
3 CONNECTORS ........................................................................................................... 15
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 16
3.1.1 IMB-H110 Layout ............................................................................................ 16
3.1.2 Peripheral Interface Connectors ..................................................................... 17
3.1.3 External Interface Panel Connectors............................................................... 18
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 19
3.2.1 +12V ATX Power Connector ........................................................................... 19
3.2.2 Additional Power Connector ........................................................................... 19
3.2.3 ATX Power Connector ..................................................................................... 20
3.2.4 Audio Connector .............................................................................................. 22
3.2.5 Backlight Inverter Connector .......................................................................... 23
3.2.6 Battery Connector............................................................................................ 24
3.2.7 Chassis Intrusion Connector............................................................................ 25
3.2.8 DDR4 DIMM Sockets ...................................................................................... 25
3.2.9 Digital I/O Connector...................................................................................... 26
3.2.10 EC Debug Connector..................................................................................... 27

IMB-H110 microATX Motherboard
Page vi
3.2.11 Fan Connector (CPU).................................................................................... 28
3.2.12 Fan Connector (System) ................................................................................ 29
3.2.13 Front Panel Connector .................................................................................. 30
3.2.14 I2CConnector................................................................................................ 31
3.2.15 Internal DisplayPort Connector.................................................................... 32
3.2.16 Keyboard and Mouse Connector ................................................................... 33
3.2.17 LAN LED Connectors.................................................................................... 34
3.2.18 LVDS Connector ............................................................................................ 35
3.2.19 Parallel Port Connector ................................................................................ 36
3.2.20 PCI Slots ........................................................................................................ 37
3.2.21 PCIe x1 Slot ................................................................................................... 38
3.2.22 PCIe x16 Slot ................................................................................................. 39
3.2.23 PCIe Mini Slot................................................................................................ 39
3.2.24 Power Button ................................................................................................. 41
3.2.25 RS-232 Serial Port Connectors...................................................................... 42
3.2.26 RS-232/422/485 Serial Port Connectors ....................................................... 43
3.2.27 SATA 6Gb/s Drive Connector ........................................................................ 44
3.2.28 SMBus Connector .......................................................................................... 46
3.2.29 SPI Flash Connector...................................................................................... 47
3.2.30 SPI Flash Connector, EC............................................................................... 48
3.2.31 TPM Connector.............................................................................................. 49
3.2.32 USB 2.0 Connector ........................................................................................ 50
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 51
3.3.1 Audio Connector .............................................................................................. 51
3.3.2 Ethernet and USB 3.0 Connectors................................................................... 52
3.3.3 USB 2.0 Connectors......................................................................................... 53
3.3.4 VGA and DVI-I Connectors............................................................................. 54
4 INSTALLATION ......................................................................................................... 56
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 57
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 57
4.3 SOCKET LGA1151 CPU INSTALLATION ................................................................... 59
4.4 SOCKET LGA1151 COOLING KIT INSTALLATION ..................................................... 62
4.5 DIMM INSTALLATION.............................................................................................. 64
4.6 FULL-SIZE PCIE MINI CARD INSTALLATION............................................................. 65

IMB-H110 microATX Motherboard
Page vii
4.7 HALF-SIZE PCIE MINI CARD INSTALLATION............................................................. 66
4.8 SYSTEM CONFIGURATION......................................................................................... 69
4.8.1 AT/ATX Power Mode Setting ........................................................................... 69
4.8.2 Clear CMOS Button......................................................................................... 69
4.8.3 DVI/CRT Selection Switch............................................................................... 70
4.8.4 Flash Descriptor Security Override Jumper.................................................... 71
4.8.5 LVDS Panel Resolution Selection Switch ........................................................ 72
4.8.6 LVDS Voltage Selection Jumper....................................................................... 73
4.8.7 LVDS/iDP Selection Switch ............................................................................. 74
4.8.8 USB Power Selection....................................................................................... 75
4.9 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 75
4.9.1 SATA Drive Connection ................................................................................... 75
4.10ADDING USB 3.0 DRIVERS TO A WINDOWS 7INSTALLATION IMAGE...................... 77
4.11 DRIVER INSTALLATION........................................................................................... 79
5 BIOS.............................................................................................................................. 81
5.1 INTRODUCTION......................................................................................................... 82
5.1.1 Starting Setup................................................................................................... 82
5.1.2 Using Setup...................................................................................................... 82
5.1.3 Getting Help..................................................................................................... 83
5.1.4 Unable to Reboot after Configuration Changes.............................................. 83
5.1.5 BIOS Menu Bar................................................................................................ 83
5.2 MAIN........................................................................................................................ 84
5.3ADVANCED............................................................................................................... 85
5.3.1 Trusted Computing........................................................................................... 86
5.3.2 ACPI Settings................................................................................................... 87
5.3.3 Super IO Configuration ................................................................................... 88
5.3.3.1 Serial Port 1 ~ 6 Configuration................................................................. 89
5.3.3.2 Serial Port 1 Configuration....................................................................... 89
5.3.3.3 Serial Port 2 Configuration....................................................................... 90
5.3.3.4 Serial Port 3 Configuration....................................................................... 91
5.3.3.5 Parallel Port Configuration....................................................................... 95
5.3.4 F81866SEC Super IO Configuration............................................................... 97
5.3.4.1 Serial Port 7~12 Configuration................................................................. 97
5.3.5 iWDD H/W Monitor......................................................................................... 98

IMB-H110 microATX Motherboard
Page viii
5.3.5.1 Smart Fan Mode Configuration................................................................ 99
5.3.6 RTC Wake Settings......................................................................................... 100
5.3.7 Serial Port Console Redirection .................................................................... 102
5.3.7.1 Legacy Console Redirection Settings..................................................... 105
5.3.8 CPU Configuration ........................................................................................ 105
5.3.9 SATA Configuration........................................................................................ 107
5.3.10 NVMe Configuration.................................................................................... 108
5.3.11 USB Configuration....................................................................................... 109
5.3.12 iEi Feature ....................................................................................................110
5.4 CHIPSET ..................................................................................................................111
5.4.1 System Agent (SA) Configuration ...................................................................112
5.4.1.1 Graphics Configuration............................................................................113
5.4.1.2 PEG Port Configuration...........................................................................115
5.4.1.3 Memory Configuration ............................................................................116
5.4.2 PCH-IO Configuration ...................................................................................117
5.4.2.1 PCI Express Configuration......................................................................119
5.4.2.2 HD Audio Configuration......................................................................... 121
5.5 SECURITY............................................................................................................... 122
5.6 BOOT...................................................................................................................... 123
5.7 SAVE &EXIT.......................................................................................................... 125
A REGULATORY COMPLIANCE............................................................................ 126
B PRODUCT DISPOSAL............................................................................................ 128
C BIOS OPTIONS........................................................................................................ 130
D TERMINOLOGY ..................................................................................................... 134
E DIGITAL I/O INTERFACE..................................................................................... 138
E.1 INTRODUCTION ...................................................................................................... 139
E.2ASSEMBLY LANGUAGE SAMPLE 1.......................................................................... 140
E.3ASSEMBLY LANGUAGE SAMPLE 2.......................................................................... 140
F WATCHDOG TIMER............................................................................................... 141
G HAZARDOUS MATERIALS DISCLOSURE....................................................... 144

IMB-H110 microATX Motherboard
Page ix
List of Figures
Figure 1-1: IMB-H110......................................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: IMB-H110 Dimensions (mm) ......................................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Peripheral Interface Connectors .............................................................................16
Figure 3-2: +12V ATX Power Connector Pinout Location ........................................................19
Figure 3-3: Additional Power Connector Location....................................................................20
Figure 3-4: ATX Power Connector Location..............................................................................21
Figure 3-5: Audio Connector Location.......................................................................................22
Figure 3-6: Backlight Inverter Connector Location...................................................................23
Figure 3-7: Battery Connector Location.....................................................................................24
Figure 3-8: Chassis Intrusion Connector Location...................................................................25
Figure 3-9: DDR4 DIMM Socket Locations.................................................................................26
Figure 3-10: Digital I/O Connector Location ..............................................................................26
Figure 3-11: EC Debug Connector Location..............................................................................27
Figure 3-12: CPU Fan Connector Location................................................................................28
Figure 3-13: System Fan Connector Location...........................................................................29
Figure 3-14: Front Panel Connector Location ...........................................................................30
Figure 3-15: I2C Connector Location ..........................................................................................31
Figure 3-16: Internal DisplayPort Connector Location.............................................................32
Figure 3-17: Keyboard and Mouse Connector Location...........................................................33
Figure 3-18: LAN LED Connector Locations .............................................................................34
Figure 3-19: LVDS Connector Location......................................................................................35
Figure 3-20: Parallel Port Connector Location..........................................................................37
Figure 3-21: PCI Slot Locations ..................................................................................................38
Figure 3-22: PCIe x1 Slot Location .............................................................................................38
Figure 3-23: PCIe x16 Slot Location ...........................................................................................39
Figure 3-24: PCIe Mini Slot Location..........................................................................................40
Figure 3-25: Power Button Location...........................................................................................41
Figure 3-26: RS-232 Serial Port Connector Locations..............................................................42

IMB-H110 microATX Motherboard
Page x
Figure 3-27: RS-232/422/485 Serial Port Connector Locations................................................43
Figure 3-28: SATA 6Gb/s Drive Connector Locations..............................................................45
Figure 3-29: SMBus Connector Location...................................................................................46
Figure 3-30: SPI Flash Connector Location...............................................................................47
Figure 3-31: SPI EC Flash Connector Location.........................................................................48
Figure 3-32: TPM Connector Location........................................................................................49
Figure 3-33: USB 2.0 Connector Locations ...............................................................................50
Figure 3-34: External Peripheral Interface Connector..............................................................51
Figure 3-35: Audio Connector.....................................................................................................52
Figure 3-36: LAN Connector........................................................................................................53
Figure 3-37: DVI-I Connector.......................................................................................................55
Figure 3-38: VGA Connector .......................................................................................................55
Figure 4-1: Disengage the CPU Socket Load Lever..................................................................59
Figure 4-2: Remove Protective Cover.........................................................................................60
Figure 4-3: Insert the Socket LGA1151 CPU..............................................................................61
Figure 4-4: Close the Socket LGA1151 ......................................................................................61
Figure 4-5: Cooling Kit Support Bracket....................................................................................63
Figure 4-6: DIMM Installation.......................................................................................................64
Figure 4-7: Removing the Retention Screw...............................................................................65
Figure 4-8: Inserting the Full-size PCIe Mini Card into the Slot at an Angle..........................65
Figure 4-9: Securing the Full-size PCIe Mini Card ....................................................................66
Figure 4-10: Removing the Standoff...........................................................................................67
Figure 4-11: Installing the Standoff ............................................................................................67
Figure 4-12: Inserting the Half-size PCIe Mini Card into the Slot at an Angle........................68
Figure 4-13: Securing the Half-size PCIe Mini Card..................................................................68
Figure 4-14: AT/ATX Power Mode Switch Location..................................................................69
Figure 4-15: Clear CMOS Button Location.................................................................................70
Figure 4-16: DVI/CRT Selection Switch Location......................................................................70
Figure 4-17: Flash Descriptor Security Override Jumper Location ........................................71
Figure 4-18: LVDS Panel Resolution Selection Switch Location ............................................72
Figure 4-19: LVDS Voltage Selection Jumper Location ...........................................................73
Figure 4-20: LVDS/iDP Selection Switch Location....................................................................74
Figure 4-21: SATA Drive Cable Connection...............................................................................76
Figure 4-22: SATA Power Drive Connection..............................................................................77
Figure 4-23: Windows 7 USB 3.0 Creator Utility........................................................................78

IMB-H110 microATX Motherboard
Page xi
Figure 4-24: Update Process is Complete .................................................................................79

IMB-H110 microATX Motherboard
Page xii
List of Tables
Table 1-1: IMB-H110 Specifications..............................................................................................9
Table 2-1: Packing List.................................................................................................................12
Table 2-2: Optional Items.............................................................................................................14
Table 3-1: Peripheral Interface Connectors...............................................................................18
Table 3-2: External Peripheral Connectors................................................................................18
Table 3-3: +12V ATX Power Connector Pinouts........................................................................19
Table 3-4: Additional Power Connector Pinouts.......................................................................20
Table 3-5: ATX Power Connector Pinouts .................................................................................21
Table 3-6: Audio Connector Pinouts ..........................................................................................22
Table 3-7: Backlight Inverter Connector Pinouts......................................................................23
Table 3-8: Chassis Intrusion Connector Pinouts......................................................................25
Table 3-9: Digital I/O Connector Pinouts....................................................................................27
Table 3-10: EC Debug Connector Pinouts .................................................................................28
Table 3-11: CPU Fan Connector Pinouts ...................................................................................29
Table 3-12: System Fan Connector Pinouts ..............................................................................29
Table 3-13: Front Panel Connector Pinouts...............................................................................30
Table 3-14: I2C Connector Pinouts..............................................................................................31
Table 3-15: Internal DisplayPort Connector Pinouts ................................................................33
Table 3-16: Keyboard and Mouse Connector Pinouts..............................................................34
Table 3-17: LAN LED Connector Pinouts...................................................................................35
Table 3-18: LVDS Connector Pinouts.........................................................................................36
Table 3-19: Parallel Port Connector Pinouts .............................................................................37
Table 3-20: PCIe Mini Slot Pinouts..............................................................................................41
Table 3-21: RS-232 Serial Port Connector Pinouts...................................................................42
Table 3-22: RS-232/422/485 Serial Port Connector Pinouts.....................................................44
Table 3-23: DB-9 RS-232/422/485 Pinouts..................................................................................44
Table 3-24: SATA 6Gb/s Drive Connector Pinouts....................................................................45
Table 3-25: SMBus Connector Pinouts ......................................................................................46
Table 3-26: SPI Flash Connector Pinouts ..................................................................................47
Table 3-27: SPI EC Flash Connector Pinouts ............................................................................48

IMB-H110 microATX Motherboard
Page xiii
Table 3-28: TPM Connector Pinouts...........................................................................................49
Table 3-29: USB 2.0 Connector Pinouts.....................................................................................50
Table 3-30: USB 3.0 Port Pinouts................................................................................................52
Table 3-31: LAN Pinouts ..............................................................................................................53
Table 3-32: USB 2.0 Port Pinouts................................................................................................53
Table 3-33: DVI-I Connector Pinouts ..........................................................................................54
Table 3-34: VGA Connector Pinouts...........................................................................................55
Table 4-1: AT/ATX Power Mode Switch Settings.......................................................................69
Table 4-2: DVI/CRT Selection Switch Settings ..........................................................................70
Table 4-3: Flash Descriptor Security Override Jumper Settings.............................................71
Table 4-4: LVDS Panel Resolution Selection.............................................................................72
Table 4-5: LVDS Voltage Selection Jumper Settings................................................................73
Table 4-6: LVDS/iDP Selection Switch Settings........................................................................74
Table 4-7: BIOS Options and Configured USB Ports................................................................75
Table 4-8: USB Power Source Setup..........................................................................................75
Table 5-1: BIOS Navigation Keys................................................................................................83
Table 5-2: BIOS Options and Configured USB Ports............................................................. 118

IMB-H110 microATX Motherboard
Page xiv
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................84
BIOS Menu 2: Advanced..............................................................................................................85
BIOS Menu 3: Trusted Computing..............................................................................................86
BIOS Menu 4: ACPI Configuration..............................................................................................87
BIOS Menu 5: Super IO Configuration........................................................................................88
BIOS Menu 6: Serial Port 1 ~ 6 Configuration Menu.................................................................89
BIOS Menu 7: Parallel Port Configuration Menu.......................................................................95
BIOS Menu 8: F81866SEC Super IO Configuration...................................................................97
BIOS Menu 9: Serial Port 7~12 Configuration Menu.................................................................97
BIOS Menu 10: iWDD H/W Monitor .............................................................................................98
BIOS Menu 11: Smart Fan Mode Configuration ........................................................................99
BIOS Menu 12: RTC Wake Settings......................................................................................... 100
BIOS Menu 13: Serial Port Console Redirection.................................................................... 102
BIOS Menu 14: Legacy Console Redirection Settings .......................................................... 105
BIOS Menu 15: CPU Configuration.......................................................................................... 106
BIOS Menu 16: SATA Configuration........................................................................................ 107
BIOS Menu 17: NVMe Configuration........................................................................................ 108
BIOS Menu 18: USB Configuration.......................................................................................... 109
BIOS Menu 19: iEi Feature........................................................................................................ 110
BIOS Menu 20: Chipset............................................................................................................. 111
BIOS Menu 21: System Agent (SA) Configuration................................................................. 112
BIOS Menu 22: Graphics Configuration.................................................................................. 113
BIOS Menu 23: PEG Port Configuration.................................................................................. 115
BIOS Menu 24: Memory Configuration.................................................................................... 116
BIOS Menu 25: PCH-IO Configuration..................................................................................... 117
BIOS Menu 26: PCI Express Configuration ............................................................................ 119
BIOS Menu 27: MPCIE1 Slot..................................................................................................... 119
BIOS Menu 28: HD Audio Configuration................................................................................. 121
BIOS Menu 29: Security............................................................................................................ 122
BIOS Menu 30: Boot.................................................................................................................. 123

IMB-H110 microATX Motherboard
Page xv
BIOS Menu 31: Save & Exit.......................................................................................................125

IMB-H110 microATX Motherboard
Page 1
Chapter
1
1 Introduction

IMB-H110 microATX Motherboard
Page 2
1.1 Introduction
Figure 1-1: IMB-H110
The IMB-H110 is a microATX motherboard. It accepts a Socket LGA1151 Intel® Core™
i7/i5/i3, Pentium® or Celeron® processor and supports two 288-pin 2133 MHz
dual-channel DDR4 DIMM modules up to 64 GB.
The IMB-H110 provides two GbE interfaces through the Realtek RTL8111GN controllers.
The integrated Intel® H110 chipset supports four SATA 6Gb/s drives. In addition, the
IMB-H110 includes VGA, DVI-I and LVDS/iDP interfaces for dual independent display.
Expansion and I/O include one PCIe x16 slot, one PCIe x1 slot, two PCI slots, one PCIe
Mini slot, four USB 3.0 on the rear panel, six USB 2.0 on the rear panel, two USB 2.0 by
pin headers, ten RS-232 and two RS-232/422/485. High Definition Audio (HDA) support
ensures HDA devices can be easily implemented on the IMB-H110.

IMB-H110 microATX Motherboard
Page 3
1.2 Features
Some of the IMB-H110 motherboard features are listed below:
microATX form factor
6th generation LGA1151 Intel® Core™ i7/i5/i3, Pentium® or Celeron®
processor supported
Intel® H110 chipset
Two 288-pin 2133 MHz dual-channel unbuffered DDR4 DIMMs supported
(system max. 32 GB)
Two GbE connectors via Realtek RTL8111GN controllers
Dual independent display by VGA, DVI-I and LVDS/iDP interfaces
Four SATA 6Gb/s connectors
One PCIe x16 slot
One PCIe x1 slot
Two PCI slots
One full-size/half-size PCIe Mini slot
Four USB 3.0 ports on the rear I/O
Six USB 2.0 ports on the rear I/O
Two USB 2.0 ports via internal pin headers
Ten RS-232 serial ports
Two RS-232/422/485 serial ports
TPM V1.2 hardware security function supported by TPM module
High Definition Audio
RoHS compliant

IMB-H110 microATX Motherboard
Page 4
1.3 Connectors
The connectors on the IMB-H110 are shown in the figure below.
Figure 1-2: Connectors

IMB-H110 microATX Motherboard
Page 5
1.4 Dimensions
The main dimensions of the IMB-H110 are shown in the diagram below.
Figure 1-3: IMB-H110 Dimensions (mm)
