IEI Technology ICE-BDE-T7 User manual

1
COM Express Basic size Type 7 Module support, Intel® Broadwell-DE
Processor D-1500, Two ECC DDR4 SO-DIMM, GbE, 10G KR,
NCSI, SATAIII, USB 3.0, PCIe Gen3, RoHS
ICE-BDE-T7
Quick Installation Guide
Version 1.0
Mar 28, 2018.
Package List
ICE-BDE-T7 package includes the following items:
1 x ICE-BDE-T7 single board computer
1 x Heatsink
1 x QIG
©2018 Copyright by IEI Integration corp.
All rights reserved.

2
Specifications
Form Factor: PICMG COM.0 Rev 3.0 , Type 7
CPU:
Intel® Broadwell-DE D-1500 Processors
PCH:NA
Memory:
Two 260-pin 1600/2133 MHz Dual-Channel DDR4 SDRAM
supported
Support ECC
(system max. 32GB)
BIOS: UEFI BIOS
Ethernet:
Intel® I211-AT
2 x 10G KR Interfaces
10G Sideband Signals
( 10G_INT 10G_PHY_MDC/MDIO 10G_PHY_SEL
10G_PHY_RST
10G_LED_I2C 10G_SFP_I2C 10G_SDP)
Embedded Controller:IT8528EFX
IO:
2 x RS-232 (2-Wire) to base board
4 x USB 2.0 to base board
4 x USB 3.0 to base board (with 4 x USB 2.0)
2 x SATA 6GB/s signal to base board
SMBus/JTAG: YES, to base board
JTAG:on board
SPI:
1. On board connector
2. To base board
I2C:YES, to base board
LPC:YES, to base board

3
Expansion:
1x PCIe x16 Gen 3 (Bifurcatable to 2 x8, 1 x8 & 2 x4, or 4 x4)
1x PCIe x8 Gen 3 (Bifurcatable to 1 x8 & 2 x4)
8x PCIe x1 (Gen2) signal to base board
Bifurcatable to 1 x8 or 2 x4 or 4 x1 +1x4 or 8 x1
Watchdog Timer:
Software programmable supports 1~255 sec system reset
GPIO: 8 bit GPIO, to base board
TPM: Through base board
Power Supply:
12V: 12V±5%, 5VSB: 5V±5%, RTC Battery: 2.0-3.3V
Operating Temperature: -20°C ~ 60°C with air flow
Operation Humidity: 5% ~ 95%, non-condensing
Dimensions: 125 mm x 95 mm
Ordering Information

COM Express Basic size Type 7 Module support, Intel®
ICE-BDE-T7-1548-R10:
Broadwell-DE Eight-Core processor D-1548 (45W), two ECC
DDR4 SO-DIMM, GbE, 10G KR, NCSI, SATA 6Gb/s, USB 3.0,
PCIe Gen3, RoHS

COM Express Basic size Type 7 Module support, Intel®
ICE-BDE-T7-1518-R10:
Broadwell-DE Quad-Core processor D-1518 (35W), two ECC
DDR4 SO-DIMM , GbE, 10G KR, NCSI, SATA 6Gb/s, USB 3.0,
PCIe Gen3, RoHS

COM Express Basic size Type 7 Module support, Intel®
ICE-BDE-T7-1508-R10:

4
Broadwell-DE Quad-Core processor D-1508 (25W), two ECC
DDR4 SO-DIMM , GbE, 10G KR, NCSI, SATA 6Gb/s, USB 3.0,
PCIe Gen3, RoHS

Base Board for COM Express Type 7 Module
ICE-DB-T7-i2-R10:

5
Jumpers setting and connectors
LABEL FUNCTION
J_SPI1
BIOS Programmer Connector
J_EC1
EC Programmer Connector
J_CPLD1 CPLD Programmer Connector
DBG_PORT1 For LPC Debug card
DBG_EC1 For EC Debug Card (FPC 20-Pin)
J1 COMEXPRESS Type7 CPU Board Pin Define
J2 CPU Card Board to Board Pin Define
J_CPLD1: CPLD Programmer Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC3.3SB
5
NC
2
CPLD_TDO
6
CPLD_TMS
3 CPLD_TDI 7 GND
4 NC 8 CPLD_TCK
J_EC1: EC Programmer Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC3.3V
4
CLK
2
CS
5
MOSI
3
MISO
6
GND
J_SPI1: BIOS Programmer Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 VCC1.8V 4 CLK
2 CS 5 MOSI
3 MISO 6 GND

6
J1: COMEXPRESS Type7 CPU Board Pin Define
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
A1
GND
B1
GND
A2
MDI3_N
B2
ACT
A3
MDI3_P
B3
LPC_FRAME#
A4
LINK100
B4
LPC_AD0
A5
LINK1000
B5
LPC_AD1
A6
MDI2_N
B6
LPC_AD2
A7
MDI2_P
B7
LPC_AD3
A8
LINK
B8
SIO_DRQ#0
A9
MDI1_N
B9
NC
DBG_EC1: For EC Debug Card (FPC 20-Pin)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1
KSI0
11
KSO9
2 KSO0 12 KSO10
3 KSO1 13 KSO12
4
KSO2
14
KSI1
5 KSO3 15 KSO11
6 KSO4 16 KSI2
7 KSO5 17 KSI3
8
KSO6
18
GND
9 KSO7 19 GND
10 KSO8 20 GND
DBG_PORT1: For LPC Debug Card
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 NC 7 LPC_AD2
2 LPC_CLK_REF 8 LPC_AD3
3
SYS_RESET#
9
INT_SERIRQ
4 LPC_FRAME# 10 GND
5 LPC_AD0 11 VCC3
6
LPC_AD1
12
NC

7
A10
MDI1_P
B10
LPC_CLK_REF
A11
GND
B11
GND
A12
MDI0_N
B12
PM_PWRBTN#
A13
MDI0_P
B13
SMB_CLK
A14
NC
B14
SMB_DATA
A15
PM_SLP_S3#
B15
SMB_ALERT#
A16
SATA0_TX+
B16
SATA1_TX+
A17
SATA0_TX-
B17
SATA1_TX-
A18
PM_SLP_S4#
B18
LPCPD_N
A19
SATA0_RX+
B19
SATA1_RX+
A20
SATA0_RX-
B20
SATA1_RX-
A21
GND
B21
GND
A22 PE2_TX_DP_7 B22 PE2_RX_DP_7
A23 PE2_TX_DN_#7 B23 PE2_RX_DN#_7
A24 PM_SLP_S5# B24 PWR_OK
A25
PE2_TX_DP_6
B25
PE2_RX_DP_6
A26
PE2_TX_DN_#6
B26
PE2_RX_DN#_6
A27
NC
B27
WDTRST#
A28
SATA_LED#
B28
NC
A29
NC
B29
NC
A30
NC
B30
AC_SDIN0
A31
GND
B31
GND
A32
NC
B32
SPKR
A33
NC
B33
I2C_CLK
A34
BIOS_DIS
B34
I2C_DATA
A35
NC
B35
NC
A36
PE2_TX_DP_5
B36
PE2_RX_DP_5
A37
PE2_TX_DN_#5
B37
PE2_RX_DN#_5
A38
GND
B38
GND
A39
PE2_TX_DP_4
B39
PE2_RX_DP_4
A40
PE2_TX_DN_#4
B40
PE2_RX_DN#_4
A41
GND
B41
GND
A42
USB2-
B42
USB3-
A43 USB2+B43 USB3+
A44 USB_2_3_OC# B44 USB_0_1_OC#
A45 USB0-B45 USB1-

8
A46
USB0+
B46
USB1+
A47
+V3.3A_RTC
B47
NC
A48
NC
B48
NC
A49
NC
B49
SYS_RESET#
A50
INT_SERIRQ
B50
CB_RESET#
A51
GND
B51
GND
A52
PCIE_TX_DP_6
B52
PCIE_RX_DP_6
A53
PCIE_TX_DN#_6
B53
PCIE_RX_DN#_6
A54
DIN0
B54
DOUT1
A55
PCIE_TX_DP_5
B55
PCIE_RX_DP_5
A56
PCIE_TX_DN#_5
B56
PCIE_RX_DN#_5
A57
GND
B57
DOUT2
A58 PCIE_TX_DP_4 B58 PCIE_RX_DP_4
A59 PCIE_TX_DN#_4 B59 PCIE_RX_DN#_4
A60 GND B60 GND
A61
PCIE_TX_DP_3
B61
PCIE_RX_DP_3
A62
PCIE_TX_DN#_3
B62
PCIE_RX_DN#_3
A63
DIN1
B63
DOUT3
A64
PCIE_TX_DP_2
B64
PCIE_RX_DP_2
A65
PCIE_TX_DN#_2
B65
PCIE_RX_DN#_2
A66
GND
B66
WAKE0#
A67
DIN2
B67
NC
A68
PCIE_TX_DP_1
B68
PCIE_RX_DP_1
A69
PCIE_TX_DN#_1
B69
PCIE_RX_DN#_1
A70
GND
B70
GND
A71
PE2_TX_DP_0
B71
PE2_RX_DP_0
A72
PE2_TX_DN_#0
B72
PE2_RX_DN#_0
A73
GND
B73
GND
A74
PE2_TX_DP_1
B74
PE2_RX_DP_1
A75
PE2_TX_DN_#1
B75
PE2_RX_DN#_1
A76
GND
B76
GND
A77
PE2_TX_DP_2
B77
PE2_RX_DP_2
A78
PE2_TX_DN_#2
B78
PE2_RX_DN#_2
A79 GND B79 GND
A80 GND B80 GND
A81 PE2_TX_DP_3 B81 PE2_RX_DP_3

9
A82
PE2_TX_DN_#3
B82
PE2_RX_DN#_3
A83
GND
B83
GND
A84
NCSI_TC_EN
B84
+V5A
A85
DIN3
B85
+V5A
A86
NC
B86
+V5A
A87
NC
B87
+V5A
A88
CLK_PCIE_CLK_P
B88
NC
A89
CLK_PCIE_CLK_N
B89
NC
A90
GND
B90
GND
A91
NC
B91
NCSI_CLK
A92
SPI_MISO
B92
NCSI_RXD1
A93
DOUT0
B93
NCSI_RXD0
A94 SPI_CLK B94 NCSI_CRS
A95 SPI_MOSI B95 NCSI_TXD1
A96 NC B96 NCSI_TXD0
A97
NC
B97
SPI_CS
A98
RS1_TX
B98
NC
A99
RS1_RX
B99
NC
A100
GND
B100
GND
A101
RS2_TX
B101
FAN_PWROUT
A102
RS2_RX
B102
FAN_TACHIN
A103
LID#
B103
SLEEP
A104
VCC12
B104
VCC12
A105
VCC12
B105
VCC12
A106
VCC12
B106
VCC12
A107
VCC12
B107
VCC12
A108
VCC12
B108
VCC12
A109
VCC12
B109
VCC12
A110
GND
B110
GND
J2: CPU Card Board to Board Pin Define
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
C1 GND D1 GND
C2
GND
D2
GND
C3
USB3_RXN_0
D3
USB3_TXN_0

10
C4
USB3_RXP_0
D4
USB3_TXP_0
C5
GND
D5
GND
C6
USB3_RXN_1
D6
USB3_TXN_1
C7
USB3_RXP_1
D7
USB3_TXP_1
C8
GND
D8
GND
C9
USB3_RXN_2
D9
USB3_TXN_2
C10
USB3_RXP_2
D10
USB3_TXP_2
C11
GND
D11
GND
C12
USB3_RXN_3
D12
USB3_TXN_3
C13
USB3_RXP_3
D13
USB3_TXP_3
C14
GND
D14
GND
C15
NC
D15
DDI1_CTRLCLK_AUX_P
C16 NC D16 DDI1_CTRLCLK_AUX_N
C17 NC D17 NC
C18 GND D18 NC
C19
PCIE_RX_DP_7
D19
PCIE_TX_DP_7
C20
PCIE_RX_DN#_7
D20
PCIE_TX_DN#_7
C21
GND
D21
GND
C22
PCIE_RX_DP_8
D22
PCIE_TX_DP_8
C23
PCIE_RX_DN#_8
D23
PCIE_TX_DN#_8
C24
NC
D24
NC
C25
GND
D25
GND
C26
NC
D26
NC
C27
NC
D27
NC
C28
GND
D28
GND
C29
NC
D29
NC
C30
NC
D30
NC
C31
GND
D31
GND
C32
NC
D32
10GBE_SPI_CS_N_1P0V
C33
NC
D33
10GBE_SPI_DI_1P0V
C34
NC
D34
NC
C35
NC
D35
NC
C36
LAN_I2C_SDA_1P0V
D36
10G_SFP+_Present_N
C37 LAN_I2C_SCL_1P0V D37 10G_BaseT_Present_N
C38 LAN_MDC_LED1_1 D38 10GBE_SPI_CLK_1P0V
C39 LAN_MDC_LED1_0 D39 10GBE_SPI_DO_1P0V

11
C40
LAN_SDP0_1_1P0V
D40
LAN_SDP0_0_1P0V
C41
GND
D41
GND
C42
GBE_KR_RX1_P
D42
GBE_KR_TX1_P
C43
GBE_KR_RX1_N
D43
GBE_KR_TX1_N
C44
GND
D44
GND
C45
LAN_MDC_LED0_1
D45
LAN_MDIO_DIR_CTL1
C46
LAN_MDC_LED0_0
D46
LAN_MDIO_DIR_CTL0
C47
SEL_I2C_1P0V
D47
LAN_SDP1_0_1P0V
C48
GND
D48
GND
C49
GBE_KR_RX0_P
D49
GBE_KR_TX0_P
C50
GBE_KR_RX0_N
D50
GBE_KR_TX0_N
C51
GND
D51
GND
C52 PE1_RX_DP_0 D52 PE1_TX_DP_0
C53 PE1_RX_DN#_0 D53 PE1_TX_DN_#0
C54 NC D54 NC
C55
PE1_RX_DP_1
D55
PE1_TX_DP_1
C56
PE1_RX_DN#_1
D56
PE1_TX_DN_#1
C57
NC
D57
NC
C58
PE1_RX_DP_2
D58
PE1_TX_DP_2
C59
PE1_RX_DN#_2
D59
PE1_TX_DN_#2
C60
GND
D60
GND
C61
PE1_RX_DP_3
D61
PE1_TX_DP_3
C62
PE1_RX_DN#_3
D62
PE1_TX_DN_#3
C63
NC
D63
NC
C64
NC
D64
NC
C65
PE1_RX_DP_4
D65
PE1_TX_DP_4
C66
PE1_RX_DN#_4
D66
PE1_TX_DN_#4
C67
NC
D67
GND
C68
PE1_RX_DP_5
D68
PE1_TX_DP_5
C69
PE1_RX_DN#_5
D69
PE1_TX_DN_#5
C70
GND
D70
GND
C71
PE1_RX_DP_6
D71
PE1_TX_DP_6
C72
PE1_RX_DN#_6
D72
PE1_TX_DN_#6
C73 GND D73 GND
C74 PE1_RX_DP_7 D74 PE1_TX_DP_7
C75 PE1_RX_DN#_7 D75 PE1_TX_DN_#7

12
C76
GND
D76
GND
C77
NC
D77
NC
C78
PE1_RX_DP_8
D78
PE1_TX_DP_8
C79
PE1_RX_DN#_8
D79
PE1_TX_DN_#8
C80
GND
D80
GND
C81
PE1_RX_DP_9
D81
PE1_TX_DP_9
C82
PE1_RX_DN#_9
D82
PE1_TX_DN_#9
C83
NC
D83
NC
C84
GND
D84
GND
C85
PE1_RX_DP_10
D85
PE1_TX_DP_10
C86
PE1_RX_DN#_10
D86
PE1_TX_DN_#10
C87
GND
D87
GND
C88 PE1_RX_DP_11 D88 PE1_TX_DP_11
C89 PE1_RX_DN#_11 D89 PE1_TX_DN_#11
C90 GND D90 GND
C91
PE1_RX_DP_12
D91
PE1_TX_DP_12
C92
PE1_RX_DN#_12
D92
PE1_TX_DN_#12
C93
GND
D93
GND
C94
PE1_RX_DP_13
D94
PE1_TX_DP_13
C95
PE1_RX_DN#_13
D95
PE1_TX_DN_#13
C96
GND
D96
GND
C97
NC
D97
NC
C98
PE1_RX_DP_14
D98
PE1_TX_DP_14
C99
PE1_RX_DN#_14
D99
PE1_TX_DN_#14
C100
GND
D100
GND
C101
PE1_RX_DP_15
D101
PE1_TX_DP_15
C102
PE1_RX_DN#_15
D102
PE1_TX_DN_#15
C103
GND
D103
GND
C104
VCC12
D104
VCC12
C105
VCC12
D105
VCC12
C106
VCC12
D106
VCC12
C107
VCC12
D107
VCC12
C108
VCC12
D108
VCC12
C109 VCC12 D109 VCC12
C110 GND D110 GND

13
Board Layout: Jumper and Connector Locations
(Unit: mm)
