IEI Technology POC 965 SERIES User manual

Page I
POC 965 Series Medical Panel PC
POC-965 Series Medical Panel PC

Page II
POC 965 Series Medical Panel PC
Revision
Date Version Changes
2008-11 1.01
Modified the model number
2008-09 1.00
Initial release

Page III
POC 965 Series Medical Panel PC
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

Page IV
POC 965 Series Medical Panel PC
Manual Conventions
WARNING!
Warnings appear where overlooked details may cause damage to the equipment or result
in personal injury. Warnings should be taken seriously. Warnings are easy to recognize.
The word “warning” is written as “WARNING,” both capitalized and bold and is followed by
text. The text is the warning message. A warning message is shown below:
WARNING:
This is an example of a warning message. Failure to adhere to warning
messages may result in permanent damage to the POC-965 Series or
personal injury to the user. Please take warning messages seriously.
CAUTION!
Cautionary messages should also be heeded to help reduce the chance of losing data or
damaging the POC-965 Series. Cautions are easy to recognize. The word “caution” is
written as “CAUTION,” both capitalized and bold and is followed. The italicized text is the
cautionary message. A caution message is shown below:
CAUTION:
This is an example of a caution message. Failure to adhere to cautions
messages may result in permanent damage to the POC-965 Series.
Please take caution messages seriously.

Page V
POC 965 Series Medical Panel PC
NOTE:
These messages inform the reader of essential but non-critical information. These
messages should be read carefully as any directions or instructions contained therein can
help avoid making mistakes. Notes are easy to recognize. The word “note” is written as
“NOTE,” both capitalized and bold and is followed by text. The text is the cautionary
message. A note message is shown below:
NOTE:
This is an example of a note message. Notes should always be read.
Notes contain critical information about the POC-965 Series. Please
take note messages seriously.

Page VI
POC 965 Series Medical Panel PC
Packing List
NOTE:
If any of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the POC-965 Series from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to [email protected].
The items listed below should all be included in the POC-965 Series package.
1 x POC-965 Series medical panel PC
1 x Power cord (Europe standard or USA standard)
1 x Medical grade power adapter
1 x eSATA cable
1 x Touch pen
1 x User Manual and driver CD
1 x Screw kit
Images of the above items are shown in Chapter 3.

Page VII
POC 965 Series Medical Panel PC
Table of Contents
1INTRODUCTION................................................................................................. 1
1.1 GENERAL OVERVIEW ................................................................................................. 2
1.1.1 Model Variations................................................................................................ 3
1.1.2 Standard Features.............................................................................................. 3
1.2 EXTERNAL OVERVIEW................................................................................................ 4
1.2.1 Front Panel ........................................................................................................ 4
1.2.2 Rear Panel ......................................................................................................... 5
1.2.3 Bottom Panel...................................................................................................... 5
1.3 INTERNAL OVERVIEW................................................................................................. 6
1.4 SPECIFICATIONS ......................................................................................................... 7
1.4.1 Preinstalled Hardware Components.................................................................. 7
1.4.2 System Specifications..........................................................................................8
2SPECIFICATIONS............................................................................................. 10
2.1 DIMENSIONS..............................................................................................................11
2.1.1 POC-417B Dimensions.....................................................................................11
2.1.2 POC-419B Dimensions.................................................................................... 12
2.2 INTEL®DESK-TOP PROCESSOR SUPPORT................................................................. 13
2.3 MOTHERBOARD COMPONENTS................................................................................. 14
2.3.1 Memory Support............................................................................................... 14
2.3.1.1 Installed Memory...................................................................................... 14
2.3.1.2 Additional Memory................................................................................... 14
2.3.2 Storage Capacity.............................................................................................. 14
2.4 EXTERNAL PERIPHERAL INTERFACE CONNECTORS................................................... 15
2.4.1 Serial Port Connectors .................................................................................... 15
2.4.2 LAN Connectivity............................................................................................. 15
2.4.3 External USB Connectors................................................................................ 16
2.4.4 eSATA Connectivity.......................................................................................... 16
2.5 POC-965 SERIES FRONT SIDE.................................................................................. 17
2.5.1 Monitor ............................................................................................................ 17
2.5.2 Touch-Screen Module....................................................................................... 17

Page VIII
POC 965 Series Medical Panel PC
2.6 GRAPHICS ................................................................................................................ 17
2.6.1 Intel®GME965 Integrated Graphics Media Accelerator 950......................... 17
2.6.2 Dual-Display.................................................................................................... 18
2.7AUDIO ...................................................................................................................... 18
2.7.1 High Definition Audio Controller.................................................................... 18
2.7.2 Stereo Speakers................................................................................................ 18
2.8 SYSTEM POWER ....................................................................................................... 19
2.8.1 Power Mode..................................................................................................... 19
2.8.1.1 ATX Power Mode (Default)...................................................................... 19
2.8.1.2 AT Power Mode ........................................................................................ 20
2.8.2 Power Adapter................................................................................................. 20
2.8.3 Power Connector............................................................................................. 20
2.9 WIRELESS CONNECTIONS......................................................................................... 21
2.9.1 USB Bluetooth Module .................................................................................... 21
2.9.2 Wireless Ethernet ............................................................................................. 22
3UNPACKING...................................................................................................... 23
3.1 UNPACKING.............................................................................................................. 24
3.1.1 Packing List ..................................................................................................... 25
4INSTALLATION................................................................................................ 26
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 27
4.2 INSTALLATION PRECAUTIONS................................................................................... 27
4.3 PREINSTALLED COMPONENTS................................................................................... 28
4.4 INSTALLATION AND CONFIGURATION STEPS ............................................................. 28
4.5 CF CARD INSTALLATION .......................................................................................... 29
4.6AT/ATX MODE SELECTION...................................................................................... 30
4.7 MOUNTING THE SYSTEM .......................................................................................... 31
4.7.1 Wall Mounting.................................................................................................. 31
4.7.2 Arm Mounting .................................................................................................. 34
4.8 BOTTOM PANEL CONNECTORS ................................................................................. 36
4.8.1 12V DC Power Connection.............................................................................. 36
4.8.2 LAN Connection............................................................................................... 36
4.8.3 Serial Device Connection ................................................................................ 37
4.8.4 USB Device Connection................................................................................... 38

Page IX
POC 965 Series Medical Panel PC
4.8.5 VGA Monitor Connection ................................................................................ 39
5SYSTEM MAINTENANCE .............................................................................. 41
5.1 INTRODUCTION......................................................................................................... 42
5.2 MOTHERBOARD REPLACEMENT ............................................................................... 42
5.3 INTERNALALUMINUM COVER REMOVAL ................................................................. 42
5.4 HDD REPLACEMENT................................................................................................ 43
5.5 MEMORY MODULE REPLACEMENT........................................................................... 46
5.6 JUMPER SETTINGS .................................................................................................... 48
5.6.1 Clear CMOS Jumper (J_CMOS1)................................................................... 49
5.6.2 COM1 and COM3 RI and Voltage Select (J10)............................................... 49
5.6.3 COM3 RS-232/422/485 Select (J9).................................................................. 49
5.6.4 COM2 RI and Voltage Select (J6).................................................................... 49
5.6.5 CompactFlash® Setup (J4).............................................................................. 50
5.6.6 LCD Voltage Select (J2)................................................................................... 50
5.7 RS-422AND RS-485 PINOUTS ................................................................................. 50
6AMI BIOS SETUP.............................................................................................. 52
6.1 INTRODUCTION......................................................................................................... 53
6.1.1 Starting Setup................................................................................................... 53
6.1.2 Using Setup...................................................................................................... 53
6.1.3 Getting Help..................................................................................................... 54
6.1.4 Unable to Reboot After Configuration Changes.............................................. 54
6.1.5 BIOS Menu Bar................................................................................................ 54
6.2 MAIN........................................................................................................................ 55
6.3ADVANCED............................................................................................................... 56
6.3.1 CPU Configuration.......................................................................................... 57
6.3.2 IDE Configuration........................................................................................... 59
6.3.2.1 IDE Master, IDE Slave ............................................................................. 60
6.3.3 Super IO Configuration ................................................................................... 65
6.3.4 Hardware Health Configuration...................................................................... 67
6.3.5 Intel AMT Configuration.................................................................................. 72
6.3.5.1 ME Subsystem Configuration................................................................... 72
6.3.6 Intel Robson Configuration.............................................................................. 75
6.3.7 Remote Access Configuration.......................................................................... 76

Page X
POC 965 Series Medical Panel PC
6.3.8 USB Configuration........................................................................................... 79
6.3.9 Power Configuration ....................................................................................... 81
6.3.9.1 ACPI Configuration .................................................................................. 81
6.3.10 APM Configuration........................................................................................ 82
6.4 PCI/PNP................................................................................................................... 85
6.5 BOOT........................................................................................................................ 88
6.5.1 Boot Settings Configuration............................................................................. 89
6.5.2 Boot Device Priority........................................................................................ 91
6.6 SECURITY................................................................................................................. 92
6.7 CHIPSET ................................................................................................................... 93
6.7.1 North Bridge Configuration............................................................................. 93
6.7.2 South Bridge Configuration............................................................................. 96
6.8 EXIT......................................................................................................................... 97
7SOFTWARE DRIVERS..................................................................................... 99
7.1AVAILABLE SOFTWARE DRIVERS ............................................................................ 100
7.2 DRIVER CDAUTO-RUN.......................................................................................... 100
7.3 INTEL®CHIPSET DRIVER....................................................................................... 103
7.4 INTEL®GRAPHICS MEDIAACCELERATOR DRIVER ................................................ 106
7.5 INTEL®82566 GIGABIT LAN CONNECT DEVICE DRIVER.......................................110
7.6 GIGABIT ETHERNET CONTROLLER DRIVER .............................................................116
7.7 REALTEK HDAUDIO DRIVER (ALC883) INSTALLATION........................................ 122
7.7.1 BIOS Setup..................................................................................................... 122
7.7.2 Driver Installation ......................................................................................... 123
7.8 TOUCH SCREEN DRIVER......................................................................................... 126
7.9 BLUETOOTH DRIVER .............................................................................................. 130
7.10 INTEL®ACTIVE MANAGEMENT TECHNOLOGY DRIVER INSTALLATION................ 135
ASYSTEM SPECIFICATIONS......................................................................... 140
A.1 MOTHERBOARD SPECIFICATIONS........................................................................... 141
A.2 FLAT PANEL SCREEN SPECIFICATIONS ................................................................... 142
A.3 TOUCH SCREEN SPECIFICATIONS ........................................................................... 143
A.4 BLUETOOTH MODULE SPECIFICATIONS ................................................................. 143
A.5 WIRELESS LAN MODULE...................................................................................... 144
BSAFETY PRECAUTIONS............................................................................... 145

Page XI
POC 965 Series Medical Panel PC
B.1 SAFETY PRECAUTIONS........................................................................................... 146
B.1.1 General Safety Precautions........................................................................... 146
B.1.2 Anti-static Precautions .................................................................................. 147
B.2 MAINTENANCE AND CLEANING PRECAUTIONS...................................................... 147
B.2.1 Maintenance and Cleaning............................................................................ 147
B.2.2 Cleaning Tools............................................................................................... 148
B.3 ESD PRECAUTIONS ............................................................................................... 149
B.4 PRODUCT DISPOSAL .............................................................................................. 149
B.5 UL60601-1AND CAN/CSAC22.2 NO. 601.1.................................................... 150
B.6 EN60601-1-2,....................................................................................................... 150
B.7 FCC....................................................................................................................... 150
B.8 STANDARD INSPECTION BUREAU FOR CHINA ........................................................ 150
CBIOS CONFIGURATION OPTIONS............................................................ 152
C.1 BIOS CONFIGURATION OPTIONS ........................................................................... 153
DWATCHDOG TIMER ..................................................................................... 157
EHAZARDOUS MATERIALS DISCLOSURE............................................... 160
E.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ..................................... 161

Page XII
POC 965 Series Medical Panel PC
List of Figures
Figure 1-1: POC-965 Series Medical Panel PC...........................................................2
Figure 1-2: Front View...................................................................................................4
Figure 1-3: Rear View....................................................................................................5
Figure 1-4: Bottom View...............................................................................................6
Figure 1-5: Internal Overview.......................................................................................7
Figure 2-1: POC-417B Dimensions (units in mm)....................................................11
Figure 2-2: POC-419B Dimensions (units in mm)....................................................12
Figure 2-3: CPU and CPU Fan....................................................................................13
Figure 2-4: Memory Module and Memory Socket ....................................................14
Figure 2-5: COM Ports ................................................................................................15
Figure 2-6: RJ-45 Ethernet Connectors ....................................................................16
Figure 2-7: External USB Ports..................................................................................16
Figure 2-8: eSATA Connector....................................................................................16
Figure 2-9: LCD Screen ..............................................................................................17
Figure 2-10: VGA Connector......................................................................................18
Figure 2-11: Audio Jack..............................................................................................18
Figure 2-12: Stereo Speakers.....................................................................................19
Figure 2-13: Power Connector...................................................................................19
Figure 2-14: Power Connector...................................................................................20
Figure 2-15: Bluetooth Module ..................................................................................21
Figure 2-16: Wireless LAN Module............................................................................22
Figure 4-1: Back Cover Retention Screws................................................................29
Figure 4-2: CF Card Installation.................................................................................29
Figure 4-3: AT/ATX Switch Location.........................................................................30
Figure 4-4: Wall-mounting Bracket............................................................................32
Figure 4-5: Chassis Support Screws.........................................................................33
Figure 4-6: Secure the Panel PC................................................................................34
Figure 4-7: Arm Mounting Retention Screw Holes..................................................35

Page XIII
POC 965 Series Medical Panel PC
Figure 4-8: 4-pin Power Mini-DIN Connection..........................................................36
Figure 4-9: LAN Connection.......................................................................................37
Figure 4-10: Serial Device Connector .......................................................................38
Figure 4-11: USB Device Connection........................................................................39
Figure 4-12: VGA Connector......................................................................................40
Figure 5-1: Aluminum Back Cover Retention Screws.............................................43
Figure 5-2: System Fan Retention Screws ...............................................................44
Figure 5-3: Hard Drive Bracket Retention Screws...................................................44
Figure 5-4: Hard Drive Retention Screws .................................................................45
Figure 5-5: Hard Drive Installed.................................................................................46
Figure 5-6: SO-DIMM Socket Locations....................................................................47
Figure 5-7: DDR2 SO-DIMM Module Installation......................................................48
Figure 7-1: Introduction Screen.............................................................................. 101
Figure 7-2: Available Models................................................................................... 102
Figure 7-3: Available Drivers................................................................................... 102
Figure 7-4: Intel® Chipset Driver Directory........................................................... 103
Figure 7-5: Intel® Package Manager ...................................................................... 104
Figure 7-6: Intel® Setup Welcome Screen............................................................. 104
Figure 7-7: Intel® Chipset Driver License Agreement.......................................... 105
Figure 7-8: Readme File........................................................................................... 105
Figure 7-9: Intel® Chipset Driver Complete Installation Screen ......................... 106
Figure 7-10: Select the Operating System............................................................. 107
Figure 7-11: GMA Driver Readme File.................................................................... 107
Figure 7-12: GMA Driver File Extraction................................................................ 108
Figure 7-13: GMA Driver Installation Welcome Screen........................................ 108
Figure 7-14: GMA Driver License Agreement........................................................ 109
Figure 7-15: GMA Driver Installing Notice............................................................. 109
Figure 7-16: GMA Driver Installation Complete .................................................... 110
Figure 7-17: Intel® 82566 Operating System......................................................... 111
Figure 7-18: Select Operating System Type.......................................................... 112
Figure 7-19: Driver Directory................................................................................... 112
Figure 7-20: Intel® 82566 Device Driver Startup Icon .......................................... 113

Page XIV
POC 965 Series Medical Panel PC
Figure 7-21: Intel® 82566 Welcome Screen........................................................... 114
Figure 7-22: Intel® 82566 Driver License Agreement........................................... 114
Figure 7-23: Intel® 82566 Driver Setup Options.................................................... 115
Figure 7-24: Intel® 82566 Driver Installation Ready Window .............................. 115
Figure 7-25: Intel® 82566 Driver Installation Progress ........................................ 116
Figure 7-26: Windows Control Panel...................................................................... 117
Figure 7-27: System Icon......................................................................................... 118
Figure 7-28: Device Manager Tab........................................................................... 119
Figure 7-29: Device Manager List........................................................................... 120
Figure 7-30: Search for Suitable Driver.................................................................. 121
Figure 7-31: Locate Driver Files.............................................................................. 121
Figure 7-32: Location Browsing Window............................................................... 122
Figure 7-33: Select the Audio Driver Installation Icon.......................................... 123
Figure 7-34: The InstallShield Wizard Starts......................................................... 123
Figure 7-35: Preparing Setup Screen..................................................................... 124
Figure 7-36: InstallShield Wizard Welcome Screen.............................................. 124
Figure 7-37: Audio Driver Software Configuration............................................... 125
Figure 7-38: Installation Wizard Updates the System .......................................... 125
Figure 7-39: Restart the Computer......................................................................... 126
Figure 7-40: Touch Screen Driver Icon.................................................................. 127
Figure 7-41: Welcome Screen................................................................................. 127
Figure 7-42: License Agreement............................................................................. 128
Figure 7-43: Ready to Install the Program............................................................. 128
Figure 7-44: Installing PenMount DMC9000 .......................................................... 129
Figure 7-45: Reboot the Computer......................................................................... 129
Figure 7-46: Bluetooth Driver Icon......................................................................... 130
Figure 7-47: Welcome Screen................................................................................. 131
Figure 7-48: License Agreement............................................................................. 131
Figure 7-49: Bluetooth Driver Setup Options........................................................ 132
Figure 7-50: Bluetooth Driver Destination Folder................................................. 132
Figure 7-51: Ready to Install the Program............................................................. 133
Figure 7-52: Installing BlueSoleil............................................................................ 133

Page XV
POC 965 Series Medical Panel PC
Figure 7-53: Bluetooth Driver Complete Installation Screen............................... 134
Figure 7-54: Reboot the Computer......................................................................... 134
Figure 7-55: IAMT Driver Directory......................................................................... 135
Figure 7-56: IAMT Driver Installation Icon............................................................. 136
Figure 7-57: IAMT Welcome Screen....................................................................... 136
Figure 7-58: IAMT License Agreement................................................................... 137
Figure 7-59: IAMT Readme File............................................................................... 137
Figure 7-60: IAMT Setup Operations...................................................................... 138
Figure 7-61: Completed Installation....................................................................... 138
Figure 7-62: IAMT Driver Directory......................................................................... 139
Figure 7-63: HECI Driver Installation Icon ............................................................. 139
Figure 7-64: Wireless LAN Module......................................................................... 144

Page XVI
POC 965 Series Medical Panel PC
List of Tables
Table 1-1: Model Variations..........................................................................................3
Table 1-2: System Specifications................................................................................9
Table 5-1: Clear CMOS Jumper Settings ..................................................................49
Table 5-2: COM1 and COM3 RI and Voltage Settings..............................................49
Table 5-3: COM3 Mode Selection...............................................................................49
Table 5-4: COM2 RI and Voltage Selection...............................................................50
Table 5-5: CompactFlash® Master/Slave Selection.................................................50
Table 5-6: LCD Type Selection...................................................................................50
Table 5-7: RS-422 Pinouts (J7)...................................................................................51
Table 5-8: RS-485 Pinouts (J11).................................................................................51
Table 6-1: BIOS Navigation Keys...............................................................................54
Table 7-1: Motherboard Specifications.................................................................. 141
Table 7-2: TFT LCD Monitor Specifications........................................................... 142
Table 7-3: Touch Panel Specifications................................................................... 143
Table 7-4: Bluetooth Module Specifications ......................................................... 144

Page 1
POC 965 Series Medical Panel PC
1 Introduction
Chapter
1

Page 2
POC 965 Series Medical Panel PC
1.1 General Overview
Figure 1-1: POC-965 Series Medical Panel PC
The POC-417B and POC-419B (POC-965 Series) are Intel® Core™2 Duo or Intel®
Celeron® M powered flat panel PCs with a rich variety of functions and peripherals. Both
POC-965 Series models are designed for easy and simplified integration in to medical
applications.
An Intel® GME965 graphics memory controller hub (GMCH) coupled with an Intel®
ICH8M input/output controller hub ensures optimal memory, graphics, and peripheral I/O
support. The system comes with 2.0 GB of preinstalled DDR2 SDRAM and supports a
maximum of 4.0 GB of DDR2 SDRAM ensuring smooth data throughputs with reduced
bottlenecks and fast system access. The POC-965 Series also preinstalled with a 2.5”
80 GB SATA HDD for data storage.
Two serial ports and four external USB 2.0 ports ensure simplified connectivity to a variety
of external peripheral devices. A VGA connector enables connectivity to other monitors.
802.11 a/b/g/n Wi-Fi capabilities and two RJ-45 Ethernet connectors ensure smooth
connection of the system to an external LAN.

Page 3
POC 965 Series Medical Panel PC
1.1.1 Model Variations
The models of POC-965 Series are listed in Table 1-1.
POC-417B CPU LCD SATA HDD Memory Wireless
-CM550/2GB/80GB 2.0 GHz Intel®
Celeron® M (550)
17” 80 GB 2 GB DDR2 Yes
-T7500/2GB/80GB 2.2 GHz Intel® Core™2
Duo (T7500)
17” 80 GB 2 GB DDR2 Yes
POC-419B CPU LCD SATA HDD Memory Wireless
-CM550/2GB/80GB 2.0 GHz Intel®
Celeron® M (550)
19” 80 GB 2 GB DDR2 Yes
-T7500/2GB/80GB 2.2 GHz Intel® Core™2
Duo (T7500)
19” 80 GB 2 GB DDR2 Yes
Table 1-1: Model Variations
1.1.2 Standard Features
Some of the standard features of the POC-965 Series flat panel PC include:
Rugged mechanism design with ABS/PC case
IP 64 dustproof and waterproof front panel
Preinstalled 2.0 GB DDR2 memory
Preinstalled 80 GB SATA HDD
802.11 a/b/g/n Wireless LAN
eSATA port
Dual 10/100/1000 Mbps Ethernet support
Bluetooth connectivity supported
Simplified installation process
RoHS compliance

Page 4
POC 965 Series Medical Panel PC
1.2 External Overview
The POC-965 Series is a flat panel PC. The monitor and all internal components are
enclosed in an aluminum chassis. An ABS/PC plastic cover surrounds the aluminum
chassis. VESA compliant screw holes in the rear panel allow the POC-965 Series to be
attached to any VESA compliant mounting. The bottom of the POC-965 Series gives
access to a VGA port, four USB ports, an eSATA port, two Ethernet ports, a
RS-232/422/485 port, a RS-232 port, an audio jack, power input and power switch.
1.2.1 Front Panel
The front side of the POC-965 Series is a flat panel TFT LCD screen surrounded by an
ABS/PC plastic frame.
Figure 1-2: Front View
