IFM Electronic Efector 300 User manual

Operating instructions
Mechatronic flow sensor
SBT6xx
80008277 / 00 02 / 2014
UK

2
1 Preliminary note
►Instructions
> Reaction, result
→Cross-reference
Important note
Non-compliance can result in malfunction or interference.
Information
Supplementary note.
2 Safety instructions
• Please read this document prior to set-up of the unit. Ensure that the product is
suitable for your application without any restrictions.
• Improper or non-intended use may lead to malfunctions of the unit or to un-
wanted effects in your application. That is why installation, electrical connec-
tion, set-up, operation and maintenance of the unit must only be carried out by
qualified personnel authorised by the machine operator.
• In order to guarantee the correct condition of the device for the operating time
the device must only be used in media with which the wetted parts are compat-
ible(→Technicaldata).
Contents
1 Preliminary note...................................................................................................2
2 Safety instructions ...............................................................................................2
3 Functions and features ........................................................................................3
4 Function...............................................................................................................4
5 Installation............................................................................................................4
6 Electrical connection............................................................................................5
7 Technical data and scale drawing........................................................................5
8 Maintenance, repair, disposal..............................................................................5

3
UK
• The responsibility whether the measurement devices are suitable for the
respective application lies with the operator. The manufacturer assumes no
liability for consequences of misuse by the operator. Improper installation and
use of the devices result in a loss of the warranty claims.
WARNING
Personal injury can occur if the unit and connections become hot or media
underpressure(upto15bar)orhotmedia(upto180°C)leak.
►Install the unit according to the applicable rules and regulations.
►Ensure that the system is free of pressure during installation.
► Ensurethatnomediacanleakatthemountinglocationduringinstallation.
► Equiptheunitwithsuitableprotection(e.g.cover)toavoidhazardtoperson-
nelfromtouchingthesensor,connectionsandcablesorfromleakingmedia.
3 Functions and features
Theunitmonitorsliquids(water,glycolsolutions).
It detects the flow quantity on the principle of differential pressure and converts it
intoananalogueoutputsignal(4...20mA).

4
4 Function
0
0
1Q [l/min]
1: nalvalueofthemeasuringrange
Theanaloguesignalforwater(20°C)islinearfrom4mA(=noflow)to20mA
(=finalvalueofthemeasuringrange,seeTechnicalData).
For an output signal > 20 mA the flow quantity is above the final value of the
measuring range.
5 Installation
IN OUT
Rp 4
3
Rp 4
3
►Insert the unit into the Rp ¾ pipe
according to the direction of flow
(arrow)andtighten.
IN=inlet
OUT=outlet
Baffled pipes on the sensor's inlet or outlet side are not necessary.
► Donotinstalltheunitonferromagneticmaterials.
(Ferromagnetic materials are all metals exerting an attractive force on test
magnets.)
► Donotoperatetheunitinthevicinityofmagneticconstantandalternating
fields(e.g.weldingsystems).

5
UK
►If the sensors are installed side by side, observe a minimum distance of 50 mm
between the sensor axes.
6 Electrical connection
The unit must be connected by a qualified electrician.
The national and international regulations for the installation of electrical
equipment must be adhered to.
Voltage supply according to EN 50178, SELV, PELV.
► Disconnectpower.
►Connect the unit as follows:
43
2 1
L+
L
1 BN
2 WH
3 BU
Corecoloursofifmsockets:1=BN(brown),2=WH(white),3=BU(blue)
ColourstoDINEN60947-5-2
Informationaboutavailablesockets/connectorsatwww.ifm.com.
7 Technical data and scale drawing
Technical data and scale drawing at www.ifm.com
8 Maintenance, repair, disposal
If used correctly, no maintenance and repair measures are necessary.
Incaseofstronglypollutedmedia:mountafilterbeforetheinlet(IN).
Recommendation: use a 200-micron filter. Only the manufacturer is allowed to
repair the unit.
After use dispose of the unit in an environmentally friendly way in accordance with
the applicable national regulations.
More information at www.ifm-electronic.com
