IFM Electronic efector100 ID503A User manual

Operating instructions
(safety-related part ATEX)
Inductive sensors
ID503A
UK
80233523 / 00 11 / 2015

2
Remarks for safe use in hazardous areas
Functions and features
• Use in hazardous areas according to the classification
II 2D
(group II, category 2D, apparatus for dust atmosphere).
Complies with the requirements of the standards IEC 60079-0:2011 and
IEC 60079-31:2013.
• EC type examination certificate
BVS 12 ATEX E 125 X
• IECEx type examination certificate
IECEx BVS 12.0078 X
• Marking
II 2D Ex tb IIIC T90°C Db IP65
• Permissible operating temperature of the application (proper usage):
Ta: -20°C...+60°C
Installation / Set-up
The units must only be installed, connected and set up by qualified staff. The qualified staff
must have knowledge of types of protection, regulations and provisions for apparatus in
hazardous areas.
Check whether the classification (see "Marking" above and marking on the unit) is suitable
for the application.
Installation remarks / Installation
• Adhere to the relevant national regulations and provisions.
• The relevant installation regulations must be adhered to. In particular, take into account the
requirements relating to the temperature limitation as regards the expected dust deposits.
• Avoid electrostatic charging on housings and cables.
• To avoid electrostatic charging steps must be taken to ensure the equalisation of potential
of metal parts (plug housing, fixing elements, etc.).
• Protect the units and the cables efficiently against damage.
• To avoid soiling, do not remove the dust caps from the cable glands or the plugs until
introducing the cables or attaching the socket.
• It is the responsibility of the user to determine the appropriate tightening torques for the
type of cable used. The cable glands and the cap nut have to be firmly tightened. If the
connection thread or the cap nut is overtightened or undertightened, the type of protection,
the ingress resistance and the strain relief are impaired.
• The housing screws are to be fastened with 0.5 Nm, the fixing screws with max. 4 Nm.

3
UK
• Maintenance intervals are application-specific and therefore need to be defined by the
operator depending on the operating conditions.
• During maintenance, especially those parts on which the type of protection depends need
to be examined (e.g. integrity of the components of the cable gland, of the seals).
Special conditions for safe operation
• For units with terminal chamber (cable gland) and cable units a sufficient strain relief must
be ensured or the cable must be firmly laid.
• Do not disconnect the cables from units with terminal chamber while live.
• The housing and housing parts made of plastic were tested in accordance with IEC 60079-
0 for group II and for a low mechanical risk with an impact energy of 4 joules.
• Avoid direct radiation with high UV components (sunlight). Mount the unit in a protected
place.
• Units of the type ID must be mounted on a flat surface and the entire bottom must lie
flat on the surface. When mounted with the ifm mounting sets E11121 or E11122, these
requirements are met.
• A fuse must be connected between the current source and the unit. Observe the following
conditions:
- The fuse must have a rated current of max. 40 mA / time-lag in accordance with EN
60127-2.
- The fuse must be located outside the hazardous areas.
- Make sure that for 3-wire circuits the current consumption of the sensor flows through
the fuse. The possible load current is thus reduced by the current consumption.
- Insert the fuse in the specified electric circuit (see the following wiring diagrams).

4
• Wiring diagrams for the installation of the fuse:
2
4
3
L+
1
L
5
2
4
3
L+
1
L
5
11
ID503A
1: fuse
Maintenance / repair
The unit must not be modified nor can it be repaired. In case of a fault please contact the
manufacturer.
Data sheets, EC declaration of conformity and EC type examination certificates are available
from the manufacturer on request.
