IKEA LAGAN HGC3K User manual

LAGAN
HGC3K
GB
DE

ENGLISH
Please refer to the last page of this manual for the full list of IKEA
appointed After Sales Service Provider and relative national phone
numbers.
DEUTSCH
Auf der letzten Seite dieser Broschüre finden Sie eine vollständige
Liste der offiziellen IKEA After-Sales-Dienstleister mit den
jeweiligen nationalen Telefonnummern.

ENGLISH 4
DEUTSCH 17

Contents
Safety information 4
Safety instructions 6
Installation 8
Electrical connection 9
Product description 10
Daily use 11
Hints and tips 11
Care and cleaning 11
Troubleshooting 12
Technical data 13
Energy efficiency 13
Environmental concerns 14
IKEA guarantee 14
Subject to change without notice.
Safety information
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible if
an incorrect installation and use causes injuries and damage.
Always keep the instructions with the appliance for future
reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
•Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
from the appliance unless continuously supervised.
•Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
ENGLISH 4

•Keep children and pets away from the appliance when it
operates or when it cools down. Accessible parts may
become hot during use.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user maintenance of
the appliance without supervision.
General Safety
•WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements.
•Do not operate the appliance by means of an external timer
or separate remote-control system.
•WARNING: Unattended cooking on a hob with fat or oil can
be dangerous and may result in fire.
•NEVER try to extinguish a fire with water, but switch off the
appliance and then cover flame e.g. with a lid or a fire
blanket.
•CAUTION: The cooking process has to be supervised. A short
term cooking process has to be supervised continuously.
•WARNING: Danger of fire: Do not store items on the cooking
surfaces.
•Metallic objects such as knives, forks, spoons and lids should
not be placed on the hob surface since they can get hot.
•Do not use the appliance before installing it in the built-in
structure.
•Do not use a steam cleaner to clean the appliance.
•If the glass ceramic surface / glass surface is cracked, switch
off the appliance and unplug it from the mains. In case the
appliance is connected to the mains directly using junction
box, remove the fuse to disconnect the appliance from power
supply. In either case contact the Authorised Service Centre.
ENGLISH 5

•If the supply cord is damaged, it must be replaced by the
manufacturer, the Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
•WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by the
manufacturer of the appliance in the instructions for use as
suitable or hob guards incorporated in the appliance. The
use of inappropriate guards can cause accidents.
Safety instructions
Installation
Warning! The appliance must be
installed by the authorised
installer.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Keep the minimum distance from other
appliances and units.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Seal the cut surfaces with a sealant to
prevent moisture to cause swelling.
• Protect the bottom of the appliance from
steam and moisture.
• Do not install the appliance adjacent to
a door or under a window. This prevents
hot cookware falling from the appliance
when the door or the window is opened.
• If the appliance is installed above
drawers make sure that the space,
between the bottom of the appliance
and the upper drawer, is sufficient for air
circulation.
• The bottom of the appliance can get hot.
Make sure to install a non-combustible
separation panel under the appliance to
prevent access to the bottom.
Refer to the Assembly Instructions.
Electrical Connection
Warning! Risk of fire and electric
shock.
• All electrical connections should be made
by the authorised installer.
• The appliance must be earthed.
• Before carrying out any operation make
sure that the appliance is disconnected
from the power supply.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Make sure the appliance is installed
correctly. Loose and incorrect electricity
mains cable or plug (if applicable) can
make the terminal become too hot.
• Use the correct electricity mains cable.
• Do not let the electricity mains cable
tangle.
• Make sure that a shock protection is
installed.
• Use the strain relief clamp on the cable.
• Make sure the mains cable or plug (if
applicable) does not touch the hot
appliance or hot cookware, when you
connect the appliance to the near
sockets.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug (if applicable) or to the mains
ENGLISH 6

cable. Contact our Authorised Service
Centre or an electrician to change a
damaged mains cable.
• The shock protection of live and
insulated parts must be fastened in such
a way that it cannot be removed without
tools.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains
plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
Use
Warning! Risk of injury, burns
and electric shock.
• Remove all the packaging, labelling and
protective film (if applicable) before first
use.
• This appliance is for household use only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay unattended
during operation.
• Set the cooking zone to “off” after each
use.
• Do not put cutlery or saucepan lids on
the cooking zones. They can become hot.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not use the appliance as a work
surface or as a storage surface.
• If the surface of the appliance is cracked,
disconnect immediately the appliance
from the power supply. This to prevent
an electrical shock.
• When you place food into hot oil, it may
splash.
Warning! Risk of fire and
explosion
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and oils
when you cook with them.
• The vapours that very hot oil releases
can cause spontaneous combustion.
• Used oil, that can contain food remnants,
can cause fire at a lower temperature
than oil used for the first time.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
Warning! Risk of damage to the
appliance.
• Do not keep hot cookware on the control
panel.
• Do not put a hot pan cover on the glass
surface of the hob.
• Do not let cookware boil dry.
• Be careful not to let objects or cookware
fall on the appliance. The surface can be
damaged.
• Do not activate the cooking zones with
empty cookware or without cookware.
• Do not put aluminium foil on the
appliance.
• Cookware made of cast iron, aluminium
or with a damaged bottom can cause
scratches on the glass / glass ceramic.
Always lift these objects up when you
have to move them on the cooking
surface.
• This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.
ENGLISH 7

Care and cleaning
• Clean the appliance regularly to prevent
the deterioration of the surface material.
• Deactivate the appliance and let it cool
down before you clean it.
• Disconnect the appliance from the
electrical supply before maintenance.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products, abrasive
cleaning pads, solvents or metal objects.
Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
Disposal
Warning! Risk of injury or
suffocation.
• Contact your municipal authority for
information on how to discard the
appliance correctly.
• Disconnect the appliance from the mains
supply.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
Installation
Warning! Refer to Safety
chapters.
General information
Installation process must follow
the laws, ordinances, directives
and standards (electrical safety
rules and regulations, proper
recycling in accordance with the
regulations, etc.) in force in the
country of use!
ENGLISH 8

min.
28 mm
max.
R 5 mm
490±1
mm
560±1
mm
520 mm
590 mm
55 mm
min. 500 mm
min. 28 mm
min. 100 mm
Important!
• For further information on the installation
refer to the Assembly Instruction.
• If there is no oven beneath the hob insert
a dividing panel at a minimum distance
of 20 mm from the bottom of the hob.
• Do not use silicon sealant between the
appliance and the worktop.
Electrical connection
Warning! Refer to Safety
chapters.
Warning! All electrical
connections must be made by an
authorised installer.
Electrical connection
• Before connecting, check that the
nominal voltage of the appliance stated
on the rating plate, corresponds to the
available supply voltage. Also, check the
power rating of the appliance and
ensure that the wire is suitably sized to
suit the appliance power rating (refer to
the "Technical information" chapter). The
rating plate is located on the lower
casing of the hob.
• The appliance is not provided with a
mains cable. Buy the right one from a
specialized dealer. Single phase or two-
phase connection requires a mains cable
of minimum 70°C temperature stability.
Cable needs mandatory end sleeves.
According to IEC regulations use for one-
phase connection: mains cable 3 x 4mm²
and for two-phase connection: mains
cable 4 x 2.5mm². Please respect in first
priority specific national regulations.
• The appliance works perfectly on AC
230 V, AC 220 V~ or AC 240 V~ 50 Hz
electrical network.
• You must have the means for
disconnection incorporated in the fixed
wiring. Have the appliance connected to
the mains using a device that allows the
appliance to be disconnected from the
mains at all poles with a contact opening
ENGLISH 9

width of at least 3 mm, eg. automatic line
protecting cut-out, earth leakage trips or
fuse.
• You must have the connection and the
connecting links carried out as shown in
the connection diagram (it is located on
the underneath surface of the casing of
the hob). The earth lead is connected to
terminal marked with the symbol and
must be longer than leads carrying
electric current. Tighten the terminal
screws securely! Finally, secure the
connecting cable with the mains cable
cleat and the covering closed by
pressing firmly (lock into place).
Warning! Once connected to the
mains supply check that all
cooking zones are ready for use
by briefly setting each to
maximum power.
Product description
Cooking surface layout
180 mm
145 mm
210 mm
1 2
35 4
1Single cooking zone 1200 W
2Single cooking zone 1800 W
3Control Knobs
4Residual heat indicator
5Single cooking zone 2300 W
Control Knobs
You can set the cooking power between
level 1 and 9.
1 Lowest power
9 Highest power
0 Off position
Assignment of control knobs
1
2
3
2
3
1
Residual heat indicator
The residual heat indicator lights up, as
soon as one cooking zone is hot.
ENGLISH 10

Warning! Risk of burns from
residual heat! After you
deactivate the appliance, the
cooking zones need some time to
cool down. Look at the residual
heat indicator.
Use residual heat for melting and keeping
food warm.
Daily use
Adjusting the power setting
Function Knob setting
Turn clockwise to increase 1 - 9
Turn anti-clockwise to reduce 9 - 1
Turn to 0 to deactivate 0
Hints and tips
Noises during operation
When a cooking zone is active, it
may hum briefly. This is a
characteristic of all ceramic glass
cooking zones and does not
impair either the function or the
life of the appliance.
Care and cleaning
General information
Warning! Deactivate the
appliance and let it cool down
before you clean it.
Warning! For safety reasons, do
not clean the appliance with
steam blasters or high-pressure
cleaners.
Warning! Sharp objects and
abrasive cleaning agents will
damage the appliance. Clean
the appliance and remove the
residues with water and washing
up liquid after each use. Remove
also the remnants of the cleaning
agents!
ENGLISH 11

Scratches or dark stains on the
glass ceramic that cannot be
removed do not affect the
functioning of the appliance.
Removing the residues and stubborn
residues
1. Food containing sugar, plastics, tin foil
residues should be removed at once,
best tool for cleaning glass surface is a
scraper (not included with the
appliance). Place a scraper on the glass
ceramic surface at an angle and remove
residues by sliding the blade over the
surface. Wipe the appliance with a
damp cloth and a little washing up
liquid. Finally, rub the appliance dry
using a clean cloth.
2. Limescale rings, water rings, fat
splashes, shiny metallic discolorations
should be removed after the appliance
has cooled down using cleaner for glass
ceramic or stainless steel.
Troubleshooting
Warning! Refer to Safety
chapters.
What to do if…
Problem Possible cause Remedy
The cooking zones are not
functioning.
The desired power setting is
not set.
Set the power setting.
The fuse in the house electri-
cal installation (fuse box) has
been tripped.
Check the house electrical
installation fuse. If the fuses
trip a number of times,
please call an authorized
electrician.
The residual heat indicator
does not activate.
The cooking zone was only
on for a short time and is
therefore not hot.
If the cooking zone is sup-
posed to be hot, call the Af-
ter Sales Service.
If there is a fault, first try to find a solution to
the problem yourself. If you cannot find a
solution to the problem yourself, contact
your dealer or the After Sales Service.
If you operated the appliance
wrongly, or the installation was
not carried out by a registered
engineer, the visit from the After
Sales Service technician or
dealer may not take place free
of charge, even during the
warranty period.
ENGLISH 12

Technical data
Rating Plate
PQM
21552
501.823.52
Made in Germany
© Inter IKEA Systems B.V. 1999
DGT
230 V
Model LAGAN HGC3K
PNC 949 593 369 02 S No .................... 220V-240V AC 50-60 Hz
Typ 60PAD52AO 5.3kW
IKEA of Sweden AB
SE - 343 81 Älmhult
The graphic above represents the rating
plate of the appliance (without serial
number which is specific for each product),
which is located at its underneath surface of
the casing.
Dear Customer, keep the additional rating
plate with the user manual. This will allow us
to assist you better, by identifying precisely
your hob, in case you will need in future our
assistance. Thank you for your help!
Energy efficiency
Product information according to EU 66/2014 valid for EU market only
Model identification LAGAN HGC3K
501-823-52
Type of hob Built-In Hob
Number of cooking zones 3
Heating technology Radiant Heater
Diameter of circular cook-
ing zones (Ø)
Left front
Left rear
Right rear
21.0 cm
14.5 cm
18.0 cm
Energy consumption per
cooking zone (EC electric
cooking)
Left front
Left rear
Right rear
187.4 Wh / kg
183.0 Wh / kg
183.0 Wh / kg
Energy consumption of the
hob (EC electric hob)
184.5 Wh / kg
EN 60350-2 - Household electric cooking
appliances - Part 2: Hobs - Methods for
measuring performance
Energy saving
You can save energy during everyday
cooking if you follow below hints.
ENGLISH 13

• When you heat up water, use only the
amount you need.
• If it is possible, always put the lids on the
cookware.
• Before you activate the cooking zone put
the cookware on it.
• The cookware bottom should have the
same diameter as the cooking zone.
• Put the smaller cookware on the smaller
cooking zones.
• Put the cookware directly in the centre of
the cooking zone.
• Use the residual heat to keep the food
warm or to melt it.
Environmental concerns
Recycle materials with the symbol . Put
the packaging in relevant containers to
recycle it. Help protect the environment and
human health by recycling waste of
electrical and electronic appliances. Do not
dispose of appliances marked with the
symbol with the household waste. Return
the product to your local recycling facility or
contact your municipal office.
IKEA guarantee
How long is the IKEA guarantee valid?
This guarantee is valid for 2 years from the
original date of purchase of Your appliance
at IKEA. The original sales receipt is
required as proof of purchase. If service
work is carried out under guarantee, this
will not extend the guarantee period for the
appliance.
Who will execute the service?
IKEA service provider will provide the
service through its own service operations
or authorized service partner network.
What does this guarantee cover?
The guarantee covers faults of the
appliance, which have been caused by
faulty construction or material faults from
the date of purchase from IKEA. This
guarantee applies to domestic use only. The
exceptions are specified under the headline
“What is not covered under this
guarantee?” Within the guarantee period,
the costs to remedy the fault e.g. repairs,
parts, labour and travel will be covered,
provided that the appliance is accessible
for repair without special expenditure. On
these conditions the EU guidelines (Nr.
99/44/EG) and the respective local
regulations are applicable. Replaced parts
become the property of IKEA.
What will IKEA do to correct the problem?
IKEA appointed service provider will
examine the product and decide, at its sole
discretion, if it is covered under this
guarantee. If considered covered, IKEA
service provider or its authorized service
partner through its own service operations,
will then, at its sole discretion, either repair
the defective product or replace it with the
same or a comparable product.
What is not covered under this
guarantee?
• Normal wear and tear.
• Deliberate or negligent damage,
damage caused by failure to observe
operating instructions, incorrect
ENGLISH 14

installation or by connection to the
wrong voltage, damage caused by
chemical or electro-chemical reaction,
rust, corrosion or water damage
including but not limited to damage
caused by excessive lime in the water
supply, damage caused by abnormal
environmental conditions.
• Consumable parts including batteries
and lamps.
• Non-functional and decorative parts
which do not affect normal use of the
appliance, including any scratches and
possible color differences.
• Accidental damage caused by foreign
objects or substances and cleaning or
unblocking of filters, drainage systems or
soap drawers.
• Damage to the following parts: ceramic
glass, accessories, crockery and cutlery
baskets, feed and drainage pipes, seals,
lamps and lamp covers, screens, knobs,
casings and parts of casings. Unless such
damages can be proved to have been
caused by production faults.
• Cases where no fault could be found
during a technician’s visit.
• Repairs not carried out by our appointed
service providers and/or an authorized
service contractual partner or where
non-original parts have been used.
• Repairs caused by installation which is
faulty or not according to specification.
• The use of the appliance in a non-
domestic environment i.e. professional
use.
• Transportation damages. If a customer
transports the product to their home or
other address, IKEA is not liable for any
damage that may occur during transport.
However, if IKEA delivers the product to
the customer's delivery address, then
damage to the product that occurs
during this delivery will be covered by
this guarantee.
• Cost for carrying out the initial
installation of the IKEA appliance.
However, if an IKEA service provider or
its authorized service partner repairs or
replaces the appliance under the terms
of this guarantee, the service provider or
its authorized service partner will re-
install the repaired appliance or install
the replacement, if necessary.
This restriction do not apply to fault-free
work carried out by a qualified specialist
using our original parts in order to adapt
the appliance to the technical safety
specifications of another EU country.
How country law applies
The IKEA guarantee gives You specific legal
rights, which covers or exceed local
demands. However these conditions do not
limit in any way consumer rights described
in the local legislation.
Area of validity
For appliances which are purchased in one
EU country and taken to another EU
country, the services will be provided in the
framework of the guarantee conditions
normal in the new country. An obligation to
carry out services in the framework of the
guarantee exists only if the appliance
complies and is installed in accordance
with:
• the technical specifications of the country
in which the guarantee claim is made;
• the Assembly Instructions and User
Manual Safety Information;
The dedicated After Sales Service for
IKEA appliances:
Please do not hesitate to contact IKEA After
Sales Service to:
1. make a service request under this
guarantee;
2. ask for clarification on installation of the
IKEA appliance in the dedicated IKEA
kitchen furniture. The service won’t
provide clarifications related to:
• the overall IKEA kitchen installation;
ENGLISH 15

• connections to electricity (if machine
comes without plug and cable), to
water and to gas since they have to
be executed by an authorized
service engineer.
3. ask for clarification on user manual
contents and specifications of the IKEA
appliance.
To ensure that we provide you with the best
assistance, please read carefully the
Assembly Instructions and/or the User
Manual section of this booklet before
contacting us.
How to reach us if You need our service
Please refer to the last page of this manual
for the full list of IKEA appointed contacts
and relative national phone numbers.
In order to provide You with a
quicker service, we recommend
that You use the specific phone
numbers listed at the end of this
manual. Always refer to the
numbers listed in the booklet of
the specific appliance You need
an assistance for. Before calling
us, assure that You have to hand
the IKEA article number (8 digit
code) and the Serial Number (8
digit code that can be found on
the rating plate) for the
appliance of which you need our
assistance
SAVE THE SALES RECEIPT! It is
Your proof of purchase and
required for the guarantee to
apply. Note that the receipt
reports also the IKEA article
name and number (8 digit code)
for each of the appliances you
have purchased.
Do You need extra help?
For any additional questions not related to
After Sales of your appliances, please
contact our nearest IKEA store call centre.
We recommend you read the appliance
documentation carefully before contacting
us.
ENGLISH 16

Inhaltsverzeichnis
Sicherheitshinweise 17
Sicherheitsanweisungen 19
Montage 22
Elektrischer Anschluss 22
Gerätebeschreibung 24
Täglicher Gebrauch 25
Tipps und Hinweise 25
Reinigung und Pflege 25
Fehlersuche 26
Technische Daten 27
Energieeffizienz 27
Umwelttipps 28
IKEA Garantie 28
Änderungen vorbehalten.
Sicherheitshinweise
Lesen Sie vor der Montage und dem Gebrauch des Geräts
zuerst die Bedienungsanleitung. Der Hersteller ist nicht dafür
verantwortlich, wenn eine fehlerhafte Montage oder
Verwendung Verletzungen oder Schäden verursacht. Bewahren
Sie die Bedienungsanleitung griffbereit auf.
Sicherheit von Kindern und schutzbedürftigen Personen
•Das Gerät kann von Kindern ab 8 Jahren und Personen mit
eingeschränkten physischen, sensorischen oder geistigen
Fähigkeiten oder mit mangelnder Erfahrung und/oder
mangelndem Wissen nur dann verwendet werden, wenn sie
durch eine für ihre Sicherheit zuständige Person beaufsichtigt
werden oder in die sichere Verwendung des Geräts
eingewiesen wurden und die mit dem Gerät verbundenen
Gefahren verstanden haben.
•Kinder zwischen 3 und 8 Jahren und Personen mit schweren
Behinderungen oder Mehrfachbehinderung müssen vom
Gerät ferngehalten werden, wenn sie nicht ständig
beaufsichtigt werden.
•Halten Sie Kinder unter 3 Jahren vom Gerät fern, wenn sie
nicht ständig beaufsichtigt werden.
•Kinder dürfen nicht mit dem Gerät spielen.
DEUTSCH 17

•Halten Sie sämtliches Verpackungsmaterial von Kindern fern
und entsorgen Sie es auf angemessene Weise.
•Halten Sie Kinder und Haustiere während des Betriebs oder
der Abkühlphase vom Gerät fern. Die zugänglichen
Geräteteile werden beim Betrieb sehr heiß.
•Falls Ihr Gerät mit einer Kindersicherung ausgestattet ist,
empfehlen wir, diese einzuschalten.
•Kinder dürfen keine Reinigung und Wartung ohne
Beaufsichtigung durchführen.
Allgemeine Sicherheit
•WARNUNG: Das Gerät und die zugänglichen Geräteteile
werden während des Betriebs heiß. Seien Sie vorsichtig und
berühren Sie niemals die Heizelemente.
•Schalten Sie das Gerät nicht über eine externe Zeitschaltuhr
oder eine separate Fernsteuerung ein.
•WARNUNG: Kochen mit Fett oder Öl auf einem
unbeaufsichtigten Kochfeld ist gefährlich und kann zu einem
Brand führen.
•Versuchen Sie NIEMALS, ein Feuer mit Wasser zu löschen,
sondern schalten Sie das Gerät aus und decken Sie die
Flamme ab, z.B. mit einem Deckel oder einer
Feuerlöschdecke.
•VORSICHT: Der Kochvorgang muss überwacht werden. Ein
kurzer Kochvorgang muss kontinuierlich überwacht werden.
•WARNUNG: Brandgefahr: Legen Sie keine Gegenstände auf
dem Kochfeld ab.
•Legen Sie keine Metallgegenstände wie Messer, Gabeln,
Löffel oder Topfdeckel auf die Oberfläche des Kochfelds, da
diese heiß werden können.
•Verwenden Sie das Gerät nicht, bevor es in den
Einbauschrank gesetzt wird.
•Reinigen Sie das Gerät nicht mit einem Dampfstrahlreiniger.
DEUTSCH 18

•Hat die Glaskeramik-/Glasoberfläche einen Sprung, schalten
Sie das Gerät aus und nehmen Sie es vom Stromnetz. Falls
das Gerät direkt mit dem Stromnetz verbunden ist und nicht
getrennt werden kann, nehmen Sie die Sicherung für den
Anschluss heraus, um die Stromversorgung zu unterbrechen.
Verständigen Sie in jedem Fall den autorisierten
Kundendienst.
•Wenn das Netzkabel beschädigt ist, muss es vom Hersteller,
einem autorisierten Kundenservice oder einer gleichermaßen
qualifizierten Person ausgetauscht werden, um
Gefahrenquellen zu vermeiden.
•WARNUNG: Verwenden Sie nur Schutzabdeckungen des
Herstellers des Kochgeräts, von ihm in der
Bedienungsanleitung als geeignete und empfohlene
Schutzabdeckungen oder die im Gerät enthaltene
Schutzabdeckung. Es besteht Unfallgefahr durch die
Verwendung ungeeigneter Schutzabdeckungen.
Sicherheitsanweisungen
Montage
WARNUNG! Das Gerät muss von
einem autorisierten Installateur
installiert werden.
• Entfernen Sie das gesamte
Verpackungsmaterial.
• Montieren Sie ein beschädigtes Gerät
nicht und benutzen Sie es nicht.
• Halten Sie sich an die mitgelieferte
Montageanleitung.
• Die Mindestabstände zu anderen
Geräten und Küchenmöbeln sind
einzuhalten.
• Seien Sie beim Umsetzen des Gerätes
vorsichtig, da es sehr schwer ist. Tragen
Sie stets Sicherheitshandschuhe und
festes Schuhwerk.
• Dichten Sie die Ausschnittskanten mit
einem Dichtungsmittel ab, um ein
Aufquellen durch Feuchtigkeit zu
verhindern.
• Schützen Sie die Geräteunterseite vor
Dampf und Feuchtigkeit.
• Installieren Sie das Gerät nicht direkt
neben einer Tür oder unter einem
Fenster. So kann heißes Kochgeschirr
nicht herunterfallen, wenn die Tür oder
das Fenster geöffnet wird.
• Wird das Gerät über Schubladen
eingebaut, achten Sie darauf, dass
zwischen dem Geräteboden und der
oberen Schublade ein ausreichender
Abstand für die Luftzirkulation
vorhanden ist.
• Der Boden des Geräts kann heiß
werden. Achten Sie darauf eine
feuerfeste Trennplatte unter dem Gerät
anzubringen, damit der Boden nicht
zugänglich ist.
Siehe die Montageanleitung.
DEUTSCH 19

Elektrischer Anschluss
WARNUNG! Brand- und
Stromschlaggefahr.
• Der elektrische Anschluss muss von einem
autorisierten Installateur ausgeführt
werden.
• Das Gerät muss geerdet sein.
• Vor der Durchführung jeglicher Arbeiten
muss das Gerät von der elektrischen
Stromversorgung getrennt werden.
• Stellen Sie sicher, dass die Daten auf
dem Typenschild mit den elektrischen
Nennwerten der Netzspannung
übereinstimmen.
• Vergewissern Sie sich, dass das Gerät
ordnungsgemäß installiert ist. Lockere
und unsachgemäße Kabel oder Stecker
(falls vorhanden) können die Klemme
überhitzen.
• Stellen Sie sicher, dass Sie das richtige
Kabel für den elektrischen Netzanschluss
verwenden.
• Achten Sie darauf, dass das Netzkabel
nicht lose hängt oder sich verheddert.
• Sorgen Sie dafür, dass ein
Berührungsschutz installiert wird.
• Verwenden Sie die Zugentlastung für
das Kabel.
• Stellen Sie beim elektrischen Anschluss
des Gerätes sicher, dass das Netzkabel
oder ggf. der Netzstecker nicht mit dem
heißen Gerät oder heißem Kochgeschirr
in Berührung kommt.
• Verwenden Sie keine
Mehrfachsteckdosen oder
Verlängerungskabel.
• Achten Sie darauf, Netzstecker (falls
vorhanden) und Netzkabel nicht zu
beschädigen. Wenden Sie sich zum
Austausch eines beschädigten
Netzkabels an unseren autorisierten
Kundendienst oder eine Elektrofachkraft.
• Alle Teile, die gegen direktes Berühren
schützen, sowie die isolierten Teile
müssen so befestigt werden, dass sie
nicht ohne Werkzeug entfernt werden
können.
• Stecken Sie den Netzstecker erst nach
Abschluss der Montage in die Steckdose.
Stellen Sie sicher, dass der Netzstecker
nach der Montage noch zugänglich ist.
• Falls die Steckdose lose ist, schließen Sie
den Netzstecker nicht an.
• Ziehen Sie nicht am Netzkabel, wenn Sie
das Gerät von der Stromversorgung
trennen möchten. Ziehen Sie stets am
Netzstecker.
• Verwenden Sie nur geeignete
Trenneinrichtungen: Überlastschalter,
Sicherungen (Schraubsicherungen
müssen aus dem Halter entfernt werden
können), Fehlerstromschutzschalter und
Schütze.
• Die elektrische Installation muss eine
Trenneinrichtung aufweisen, mit der Sie
das Gerät allpolig von der
Stromversorgung trennen können. Die
Trenneinrichtung muss mit einer
Kontaktöffnungsbreite von mindestens
3 mm ausgeführt sein.
Gebrauch
WARNUNG! Verletzungs-,
Verbrennungs- und
Stromschlaggefahr.
• Entfernen Sie vor dem ersten Gebrauch
das gesamte Verpackungsmaterial, die
Aufkleber und Schutzfolie (falls
vorhanden).
• Dieses Gerät ist ausschließlich zur
Verwendung im Haushalt bestimmt.
• Nehmen Sie keine technischen
Änderungen am Gerät vor.
• Die Lüftungsöffnungen dürfen nicht
abgedeckt werden.
• Lassen Sie das Gerät bei Betrieb nicht
unbeaufsichtigt.
• Schalten Sie die Kochzonen nach jedem
Gebrauch aus.
• Legen Sie kein Besteck und keine
Topfdeckel auf die Kochzonen.
Anderenfalls werden sie sehr heiß.
• Bedienen Sie das Gerät nicht mit
feuchten oder nassen Händen oder
DEUTSCH 20
