IKEA KULINARISK User manual

GB
DE
FR
IT
KULINARISK

ENGLISH 4
DEUTSCH 17
FRANÇAIS 29
ITALIANO 48
2
1345
Please refer to the last page
of this manual for the full list
of IKEA appointed Authorized
Service Centre and relative
national phone number
2
1345
2
1345
Consultare l’ultima pagina
di questo manuale dove è
riportato l’elenco completo
dei Centri Assistenza IKEA
Autorizzati con i relativi numeri
telefonici nazionali.
2
1345
Consultez la dernière page
de ce manuel contenant la
liste complète des services
Après-vente agréés IKEA avec
les numéros de téléphone
nationaux correspondants.
Konsultieren Sie die letzte Seite
dieser Bedienungsanleitung,
auf der die vollständige Liste
der nationalen autorisierten
IKEA Kundendienststellen mit
den entsprechenden Telefon-
nummern aufgelistet ist.

4 ENGLISH
Contents
Safety information 4
Product description 9
Care and cleaning 10
What to do if... 11
Technical data 12
Energy efficiency 13
Environment concerns 14
IKEA GUARANTEE 14
Safety information
For your safety and correct operation of the appliance, read
this manual carefully before installation and use. Always
keep these instructions with the appliance even if you move or
sell it. Users must fully know the operation and safety features
of the appliance.
The wire connection has to be done by specialized
technician.
• The manufacturer will not be held liable for any damages
resulting from incorrect or improper installation.
• The minimum safety distance between the cooker top and
the extractor hood is: for electrical hob 500mm and for gas
hob 650mm.
• If the instructions for installation for the gas hob specify a
greater distance, this must be respected.
• Check that the mains voltage corresponds to that indicated
on the rating plate fixed to the inside of the hood.
• Means for disconnection must be incorporated in the fixed
wiring in accordance with the wiring rules.
• For Class I appliances, check that the domestic power supply
guarantees adequate earthing.
• Connect the extractor to the exhaust flue through a pipe of
minimum diameter 120 mm. The route of the flue must be
as short as possible.
• Do not connect the extractor hood to exhaust ducts carrying
combustion fumes (boilers, fireplaces, etc.).

5 ENGLISH
• If the extractor is used in conjunction with non-electrical
appliances (e.g. gas burning appliances), a sufficient degree
of aeration must be guaranteed in the room in order to
prevent the backflow of exhaust gas. When the cooker hood
is used in conjunction with appliances supplied with energy
other than electric, the negative pressure in the room must
not exceed 0,04 mbar to prevent fumes being drawn back
into the room by the cooker hood.
• The air must not be discharged into a flue that is used for
exhausting fumes from appliances burning gas or other
fuels.
• If the supply cord is damaged, it must be replaced from the
manufacturer or its service agent.
• Connect the plug to a socket complying with current
regulations, located in an accessible place.
• With regards to the technical and safety measures to be
adopted for fume discharging it is importat to closely follow
the regulations provided by the local authorities.
WARNING: Before installing the Hood, remove the
protective films.
• Use only screws and small parts in support of the hood.
WARNING: Failure to install the screws or fixing device in
accordance with these instructions may result in electrical
hazards.
• Connect the hood to the power net by using a bipolar switch
having a contact gap of at least 3 mm.
• Do not look directly at the light through optical devices
(binoculars, magnifying glasses…).
• Do not flambè under the range hood; risk of fire.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning

6 ENGLISH
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
• Children should be supervised to ensure that they do not
play with the appliance.
• The appliance is not to be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction
Accessible parts may become hot when used with cooking
appliances.
• Clean and/or replace the Filters after the specified time
period (Fire hazard).
• There shall be adequate ventilation of the room when the
range hood is used at the same time as appliances burning
gas or other fuels (not applicable to appliances that only
discharge the air back into the room)

7 ENGLISH
Use
• Switch off or unplug the appliance
from the mains supply before
carrying out any maintenance work.
• The top of the hood must not to be used
as a shelf.
• The extractor hood has been
designed exclusively for domestic
use to eliminate kitchen smells.
• Never use the hood for purposes
other than for which it has been
designed.
• Never leave high naked flames under
the hood when it is in operation.
• Adjust the flame intensity to direct
it onto the bottom of the pan only,
making sure that it does not engulf
the sides.
• Deep fat fryers must be continuously
monitored during use: overheated oil
can burst into flames.
Care and cleaning
• Grease filters must be cleaned every
2 months of operation, or more
frequently for particularly heavy
usage, and can be washed in a
dishwasher.
• Clean the hood using a damp cloth
and a neutral liquid detergent.
Care and cleaning long life Charcoal
filter (Green)
• The anti-odour Flter can be washed
and regenerated every 3-4 months
(or more frequently if the hood is
subject to intensive use), up to a
Max. of 8 regeneration cycles (in
case of particularly intensive use it
is recommended that you do not
exceed 5 cycles).
Regeneration procedure:
• Wash in the dishwasher at a MAX
temperature of 70° or hand wash in hot
water without using abrasive sponges
(do not use detergents!)
• Dry in the oven at a MAX temperature
of 70° for 2 hours or dry at room
temperature, standing the Flter in a
vertical position to facilitate drainage.

8 ENGLISH
Installation modes
The hood has been designed to be installed
and used either as a “Exhaust mode”, or as
a “Recirculation mode”.
Exhaust mode (see symbol
9
min 471 mm
max 861 mm
min 569 mm
max 861 mm
min 471 mm
max 861 mm
min 569 mm
max 861 mm
in
installation booklet)
Cooking steam is sucked and
channelled outside the house through
a discharge duct (not supplied), fitted to
the hood steam outlet.
Ensure that the discharge duct is
correctly fitted to the air outlet, unit
using an appropriate connection
system.
Recirculation mode (see symbol
9
min 471 mm
max 861 mm
min 569 mm
max 861 mm
min 471 mm
max 861 mm
min 569 mm
max 861 mm
in installation booklet)
The air is filtered through one or more
the charcoal filters, and then resent into
room.
Important: Ensure appropriate air
circulation around the hood.
Important: If the hood is supplied
without charcoal filters and installed on
recirculation mode, these must be fitted
before the hood can be used. Filters are
available in shops.
The hood should be installed away from
particularly dirty areas, windows, doors
and heat sources.
The accessories for wall fixing are not
included because wall made of different
materials require different types of
fixing accessories. Use fixing systems
suitable for the walls of your home and
the weight of the appliance. For more
details, contact a specialized dealer.
Keep this booklet for future
consultation.
Filters Alarm.
When the filter alarm is activated, the
following messages will appear over
time:
Grease filter must be cleaned:
“A” key flashes once per second. For
maintenance see paragraph Care and
cleaning.
Anti-odour filter must be cleaned:
“A” key flashes twice per second. For
maintenance see paragraph Care and
cleaning.
Once the filters have been regenerated
reset the alarm signal (see paragraph
Control Panel).

9 ENGLISH
Product description
Upper chimney
Lower chimney
Hood body
LED Lighting
Grease filter
Control panel
Control Panel
S0614 (170201)
backlight symbols
112
20 20 20 20
8
S0614 (170201)
backlight symbols
"
#
$
%
&
"
Speed
Turns the motor on/o at speed one.
Attention: the product is with the lter alarm disabled.
Press and hold the button for approximately 2 seconds, with all the loads turned o (Motor+Lights), to turn the grease lter alarm on. LED
(B) ashes twice to conrm.
To turn the alarm o, press the button again and hold for at least 2 seconds. The relevant LED (B) ashes once.
#
Speed
Turns the motor on at speed two / Activate charcoal lter alarm.
Attention: the product is with the lter alarm disabled.
Press and hold the button for approximately 2 seconds, with all the loads turned o (Motor+Lights), to turn the Activated Charcoal Filter
alarm on. LED (A) ashes twice to conrm.
To turn the alarm o, press the button again and hold for at least 2 seconds.The relevant LED ashes once (A). Only for recirculation mode.
$
Speed
Turns the Motor on at speed three / Reset alarm lter saturation.
Press and hold the button for approximately 2 seconds, with all the loads turned o (Motor+Lights), to reset the grease lter
saturation alarm or charcoal lter alarm. LED (A) ashes three times.
%
Speed
Turns the motor on at Booster speed.
This speed is timed to run for 6 minutes. At the end of this time, the system returns automatically to the speed that was set before. If it is
activated with the motor turned o, it will switch to OFF at the end of the time. To deactivate it, press button D or press button A.
&
Light
Press briey: Turns the lighting system on and o at maximum intensity.
Press and hold to change the lighting intensity up or down.

10 ENGLISH
Care and cleaning
Switch off or unplug the appliance
from the mains supply before carrying out
any maintenance work.
IMPORTANT Clean the hood using a damp
cloth and a neutral liquid detergent.
Long Life Charcoal Filter
The anti-odour Filter can be washed and
regenerated every 3-4 months (or more
frequently if the hood is subject to inten-
sive use), up to a Max. of 8 regeneration
cycles (in case of particularly intensive use
it is recommended that you do not exceed
5 cycles).
Grease Filters
Clean or replace the filters continuously
according to below time intervals, to main-
tain good performance of the hood and to
prevent a potential fire hazard, caused by
excessive grease build-up.
The grease filters must be cleaned every 2
months of operation, or more frequently
for particularly heavy usage, and can be
washed in a dishwasher.
Replacing the lamps
For Replacement please contact an Au-
thorized Service Center.
• Switch ON the hood at minimum speed when you start cooking and kept it running for
few minutes after cooking is finished.
• Increase the speed only in case of large amount of smoke and vapour and use boost
speed(s) only in extreme situations.
• Replace the charcoal filter(s) when necessary to maintain a good odour reduction ef-
ficiency.
• Clean the grease filter(s) when necessary to maintain a good grease filter efficiency.
• Use the maximum diameter of the ducting system indicated in this manual to optimize
efficiency and minimize noise.
General hints
