iLive ICP360 User manual

USER’S GUIDE
V:1730-0303-11
For the most up-to-date version of this User’s Guide, go to www.ilive.net
ICP360
App-enhanced Color Changing Clock
Radio for iPod + iPhone

iLive2
• WARNING:Lithium batteries, like all rechargeable
batteries are recyclable and should be recycled or
disposed of in normal household waste. Contact your
local government for disposal or recycling practices in
your area. They should never be incinerated since they
might explode.
• WARNING: Shock hazard - Do Not Open.
• AVIS: RISQUE DE CHOC ÉLECTRIQUE - NE PAS
OUVRIR
Mains Plug or Direct plug-in adapter is used as disconnect
device and it should remain readily operable during intended
use. In order to disconnect the apparatus from the mains
completely, the Mains Plug or Direct plug-in adapter should
be disconnected from the mains socket outlet completely.
La che d’alimentation ou adaptateur de courant est utilisé
comme dispositif de déconnexion et doit rester accessible
pendant l’utilisation. Pour mettre l’appareil hors tension, la
che ou adaptateur de courant doit être débranché de la prise
de courant.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable
(ni-cad, ni-mh, etc) batteries.
No mezcle baterías viejas y nuevas.
No mezcle baterías alcalinas, estándar (carbono-zinc) o
recargables (ni-cad, ni-mh, etc.).
• CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
• WARNING:To reduce the risk of re or electric shock,
do not expose this apparatus to rain or moisture.
• AVERTISSEMENT: Pour réduire le risque d’incendie
ou de choc électrique, ne pas exposer cet appareil sous la
pluie et l’humidité.
• CAUTION: Use of any controls or adjustments or
performance of procedures other than those herein
specied may result in hazardous radiation exposure.
• WARNING: Changes or modications to this unit
not expressly approved by the party responsible for
compliance could void the user’s authority to operate the
equipment.
• WARNING: Do not place the unit on top of any soft,
porous, or sensitive surfaces to avoid damaging the
surface. Use a protective barrier between the unit and
surface to protect the surface.
• WARNING: Use of this unit near uorescent lighting
may cause interference regarding use of the remote. If
the unit is displaying erratic behavior move away from
any uorescent lighting, as it may be the cause.
• CAUTION:Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
• PRÉCAUTION: Danger d’explosion si les piles sont
remplacées de façon incorrect. Remplacer les piles
seulement par le même type de pile ou l’équivalent.
• WARNING: There is a danger of explosion if you
attempt to charge standard Alkaline batteries in the unit.
Only use rechargeable NiMH batteries.
• WARNING:The battery, batteries, and battery pack
shall not be exposed to excessive heat such as sunshine,
re, or the like.
Warnings and Precautions
The lightning ash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of
sufcient magnitude to constitute a risk of electric
shock to persons.
WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.

Customer Support: 1-888-999-4215 iLive 3
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
WARNING: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• The apparatus shall not be exposed to dripping or splashing and
that no objects lled with liquids, such as vases, shall be placed on
apparatus.
L’appareil ne doit pas être exposé aux écoulements ou aux
éclaboussures et aucun objet ne contenant de liquide, tel qu’un vase,
ne doit être placé sur l’objet.
• Battery shall not be exposed to excessive heat such as sunshine, re
or the like.
Les piles ne doivent pas être exposées à de forte chaleur, tel qu’à la
lumière du soleil, au feu ou autres choses de semblable.
• Caution marking is located at the rear or back of the apparatus.
Attention marquage est situé à l’arrière ou à l’arrière de l’appareil
• The marking information is located at the rear or back of apparatus.
Les informations de marquage est situé à l’arrière ou à l’arrière de
l’appareil.
FCC Warnings
Additional Warnings
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding - type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety.
When the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12.
Important Safety Instructions
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user
accessible parts.
Use only with a cart, stand, tripod,
bracket, or table specied by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
Special note: When placing your unit on a
lacquered or natural nish, protect your furniture
with a cloth or other protective material.

iLive4
• Works with iPhone
• Made for iPod
• Color changing case
• App-enhanced: alarms, weather,
photo slide show, FM radio,
sources
• FM radio
• Station memory presets (20 FM)
• Wire FM antenna
• Last station memory
• Composite video output
• 3.5mm audio input
• DC power input: requires an AC/DC
power adapter (included)
• LCD display
• Digital clock
• Dual alarm
• Gradual wake
• Wake to iPhone/iPod, radio, or
buzzer
• Sleep timer
• Snooze
• Dimmer control
• Bass control
• Supports Universal docking
brackets
• Built-in speakers
• Cloth net speaker grill
• ICP360
• AC/DC power adapter
• Docking brackets for iPod (5)
Color Changing Clock Radio for iPhone and iPod
Features
Included

5
Customer Support: 1-888-999-4215 iLive 5
TABLE OF CONTENTS
Color Changing Clock Radio for iPhone and iPod . . . . 4
• Features
• Included
Introduction . . . . . . . . . . . . . 6
Setup . . . . . . . . . . . . . . . 8
• Power
• Battery Backup
iPod and iPhone . . . . . . . . . . . . 9
• Docking an iPod and iPhone
• Playing an iPod and iPhone
Downloading the App . . . . . . . . . . . 10
App Introduction . . . . . . . . . . . . 11
Clock and Sleep Timer . . . . . . . . . . . 12
• Setting the Clock
• Setting the Sleep Timer
Alarm . . . . . . . . . . . . . . . 13
• Setting the Alarm
FM Radio . . . . . . . . . . . . . . 14
• Tuning the FM Radio
• Saving a Radio Station
• Tuning Preset Radio Stations
Line Input, and Video Output . . . . . . . . . 15
• Using the Line Input
• Using the Video Output
Company Information . . . . . . . . . . . 16
• Green Initiative
• International Supportv
• Contact Information

iLive6
Introduction
DOCK for iPhone/iPod
TIME/BASS
Press to activate the
bass boost.
With the clock radio
powered o, press and
hold to set the clock.
SOURCE
Press to switch between
FM, iPod, and LINE IN
modes.
POWER
Press to power the clock
radio o or on.
VOLUME
Press to adjust the
volume.
PRESET (-/+)
Press to switch between
saved radio stations.
AL1, AL2
With the clock radio
powered o, press and
hold to set alarm 1 or
alarm 2.
Press to activate alarm 1
or 2 to wake to iPod, FM
radio, or the buzzer.
SNOOZE/SLEEP
After the alarm sounds,
press to delay the alarm
for an additional 9
minutes.
With the clock radio
powered on, press
repeatedly to set the
sleep timer.
PLAY/PAUSE
Press to play or pause a
docked iPhone or iPod.
COLOR
Press to have the clock
radio cycle through all
colors. Press again to
pause on the current
color. Press a third time
to turn the internal
lights o.
DIM/MEM
Press repeatedly to
adjust the brightness of
the display.
In FM mode, press and
hold to save the current
station to the clock
radio’s memory.
SKIP/SEARCH
Press to skip between
tracks on a docked
iPhone or iPod. Press
and hold to search
the current track on a
docked iPhone or iPod.
Press to tune the radio
when in radio mode.

7
Customer Support: 1-888-999-4215 iLive 7
RESET
Press to reset the clock
radio to the it’s original
settings.
DC POWER INPUT
LINE INPUT
VIDEO OUTPUT
LCD DISPLAY

iLive8
Plug the included AC/DC power
adapter into the DC POWER INPUT
on the clock radio and a standard AC
power outlet.
Requires 2, AAA size, batteries (not
included)
The battery backup is meant for short
unexpected power outages. The clock
radio cannot function using the backup
battery for a prolonged period.
Power
Battery Backup
Setup

Customer Support: 1-888-999-4215 iLive 9
Docking an iPod and iPhone
Playing an iPod and iPhone
1. Follow the instructions for Docking
an iPod and iPhone.
2. Adjust the POWER button to
power on the clock radio.
3. Press the SOURCE button to
switch to iPod/iPhone mode.
“iPod” will appear on the display.
4. Press the PLAY/PAUSE button
to begin playing music from the
docked iPhone or iPod.
iPod and iPhone
1. Locate the numbered bracket that
ts the iPhone/iPod model that will
be docked.
Each included bracket has a number
on it, indicating which iPhone/iPod
model that bracket is compatible
with. See the separate bracket chart
page to identify which bracket is
needed.
2. Snap the bracket into place over
the iPhone/iPod connector in the
dock for iPhone/iPod.
3. Connect the iPhone or iPod to
the connector inside the Dock for
iPhone/iPod.
When the clock radio is plugged in,
using AC power, the docked iPhone
or iPod will charge.

iLive10
Downloading the App
Manually Downloading the App
1. Go to the App Store on your
iPhone or iPod touch.
2. Search for Dock + App.
3. Download the App.

Customer Support: 1-888-999-4215 iLive 11
App Introduction
Dock + App
CLOCK & CALENDAR
The clock and calendar will
automatically sync with the time on
the iPod or iPhone, so there’s no need
to set it.
ALARM
Add as many alarms as you like using
the settings menu. You can set them to
wake to iPod music or Nature Sounds.
WEATHER
Type in your location and view your
current weather conditions along with
the time on the home page of the app.
PHOTO SLIDE SHOW
Select photos that are already on your
iPod or iPhone and play a slideshow
with your music in the background.
FM RADIO
While docked on the clock radio, use
the Dock + App to tune the FM radio
and save FM radio station as presets.
SOURCES
When docked with the clock radio
you can use the Dock + App to switch
between FM Radio, iPod, and Line
Input modes.

iLive12
Clock and Sleep Timer
Setting the Clock Setting the Sleep Timer
1. Press the POWER button to turn
the clock radio o.
2. Press and hold the TIME button.
3. While holding the TIME button,
press the SKIP/SEARCH buttons to
adjust the hour and minute.
“PM” will appear on the display
when the time is set to the pm.
4. When the correct time is set,
release to the TIME button to
nish setting the clock.
1. Follow the instructions for playing
an iPhone or iPod or playing the
FM radio.
2. Press the SNOOZE/SLEEP button
repeatedly to set the sleep timer
between 10 and 90 minutes, in 10
minute increments.
3. After the set sleep time has
expired, the clock radio will
automatically power o.

Customer Support: 1-888-999-4215 iLive 13
Alarm
Setting the Alarm
1. Press the POWER button to turn
the clock radio o.
2. Press and hold the AL1 or AL2
button.
3. While holding the AL1 or AL2
button, press the SKIP/SEARCH
buttons to adjust the hour and
minute.
“PM” will appear on the display
when the time is set to the pm.
4. When the correct alarm time is set,
release to the AL1 or AL2 button
to nish setting the clock.
5. Press the AL1 or AL2 button
repeatedly to set alarm 1 or alarm
2 to wake to iPod/iPhone, FM radio,
the buzzer, or to turn the alarm o.
6. After the alarm sounds, press the
POWER button to turn the alarm
o.
Wake to Buzzer
Wake to FM Radio
Wake to iPhone or iPod

iLive14
FM Radio
Tuning the FM Radio
Tuning Preset Radio Stations
1. Adjust the POWER button to
power on the clock radio.
2. Press the SOURCE button to
switch to FM radio mode.
“FM” will appear on the display.
3. Press the SKIP/SEARCH buttons to
tune the FM radio.
1. Follow the instructions for Tuning
the FM Radio.
2. Press the PRESET (-/+) buttons
to cycle through saved FM radio
stations.
Saving a Radio Station
1. Follow the instructions for Tuning
the FM Radio.
2. Once the desired radio station is
tuned, press and hold the DIM/
MEM button for 3 seconds.
3. Press the PRESET ± buttons to
select a memory preset, e.g. “P02”,
for the current station.
4. Press the DIM/MEM button to save
the current FM radio station to the
selected memory preset.

Customer Support: 1-888-999-4215 iLive 15
Line Input, and Video Output
Using the Line Input
Requires a 3.5mm audio cable (not
included)
1. Use a 3.5mm audio cable to
connect an MP3 player or other
audio source to the LINE INPUT on
the clock radio.
2. Press the POWER button to power
the clock radio on.
3. Press the SOURCE button to switch
the clock radio to LINE IN mode.
“LINE IN” will appear on the display.
4. Audio played through the
connected MP3 player or other
audio source will now play through
the clock radio’s speakers.
Using the Video Output
Requires an RCA video cable (not
included)
1. Connect a television to the VIDEO
OUTPUT using an RCA cable (not
included).
2. Follow the instructions for Docking
an iPod or iPhone and Playing an
iPod or iPhone.
3. Make sure the docked iPhone or
iPod’s TV out option is turned on.
4. Adjust the connected television to
the correct input setting.
5. Video played through the docked
iPhone or iPod will now play on the
connected television.

© 2009 Digital Products International (DPI, Inc.) | All other trademarks appearing herein are the property of their respective owners.
Specications are subject to change without notice
Environmental Commitment to ‘Protect
for Today and Sustain for Tomorrow’
2009 marked the ocial launch of DPI,
Inc.’s corporate campaign for a greener
and cleaner world. DPI is building upon
environmental initiatives introduced
at all of their facilities to help
formulate and sustain signicant and
important conservation eorts within
its manufacturing and marketing
communities. In addition to targeting
and selecting energy ecient product
features, and structuring ‘green oce’
procedures, other initial program
eorts include:
• Reduction of all packaging sizes
• Recyclable plastics for clamshell
packages, with a plan to eventually
replace plastic with recyclable
paper
• Recycled ber board in place of the
polyfoam in packing boxes
• Recycled plastics in place of
the virgin material in product
construction
Green Initiative International Support
Contact Information
Company Information
To download this User’s Guide in
English, Spanish, or French, visit the
support section at www.ilive.net.
Para transferir esta guía de usuario
en inglés, español, o francés, visite la
sección de la ayuda en www.ilive.net.
Pour télécharger ce guide de
l’utilisateur en anglais, espagnol, ou
français, visitez la section de soutien
chez www.ilive.net.
Phone:
1-888-999-4215
Email:
[email protected]
Parts Email:
[email protected]
Website:
www.ilive.net
