iLive ITB196B User manual

32" HD Sound Bar with Bluetooth Wireless
User’s Guide for Model ITB196B v2295-01
For the most up-to-date version of this User’s Guide, go to www.iLiveElectronics.com

23
Safety Instructions & Warnings
Important Safety Instructions
• Read these Instructions.
• Keep these Instructions.
• Heed all Warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers)
that produce heat.
• Do not defeat the safety purpose of the polarized or
grounding - type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. When the provided
plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
• Only use attachments/accessories specied by the
manufacturer.
• Unplug this apparatus during lightning storms or when
unused for long periods of time.
• Refer all servicing to qualied service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
• Use only with a cart, stand, tripod, bracket,
or table specied by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
WARNING: Never place a television set in an unstable location.
A televisions set may fall, causing serious personal injury or
death. Many injuries, particularly to children can be avoided by
taking simple precautions such as:
• Using cabinets or stands recommended by the manufacturer
of the televisions set.
• Only using furniture that can safely support the television set.
• Ensuring the televisions set is not overhanging the edge of
the supporting furniture.
• Not placing the televisions set on cloth or other materials that
may be located between the televisions set and supporting
furniture.
• Educating children about the dangers of climbing on
furniture to reach the televisions set or its controls.
If your television set is being retained and relocated, the same
considerations as above should be applied.
NOTE: When choosing where to place this TV that there is a
chance of staining and marks on the surface. As with any rubber
compound made with oils, the feet could cause marks or staining
where the feet rest.
FCC Warnings
Warning: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
Battery Warnings
• WARNING: Do not ingest battery, Chemical Burn Hazard.
• If the remote control supplied with this product contains a
coin/button cell battery and the coin/button cell battery is
swallowed, it can cause severe internal burns in just 2 hours
and can lead to death.
• Keep new and used batteries away from children. If the
battery compartment does not close securely, stop using the
product and keep it away from children.
• If you think batteries might have been swallowed or
placed inside any part of the body, seek immediate medical
attention.
• CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
• WARNING: There is a danger of explosion if you attempt
to charge standard Alkaline batteries in the unit. Only use
rechargeable NiMH batteries.
• Battery shall not be exposed to excessive heat such as
sunshine, re, or the like.
• Do not mix old and new batteries.
• Completely replace all old batteries with new ones.
• Do not mix alkaline, standard (carbon-zinc), or rechargeable
(ni-cad, ni-mh, etc) batteries.
• Batteries should be recycled or disposed of as per state and
local guidelines.
WARNING: To reduce the risk of electric
shock, do not remove cover (or back). No
user-serviceable parts inside. Refer servicing
to qualied service personnel.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user accessible
parts.
The lightning ash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of un-insulated
“dangerous voltage” within the product’s
enclosure that may be of sufcient magnitude
to constitute a risk of electric shock to persons.
Additional Warnings and Precautions
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
• Mains plug is used as disconnect device and it should remain
readily operable during intended use. In order to disconnect
the apparatus from the mains completely, the mains plug
should be disconnected from the mains socket outlet
completely.
• CAUTION: Use of controls or adjustments or performance
of procedures other than those specied may result in
hazardous radiation exposure.
• WARNING: Changes or modications to this unit not
expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
• WARNING: Use of this unit near uorescent lighting may
cause interference regarding use of the remote. If the unit is
displaying erratic behavior move away from any uorescent
lighting, as it may be the cause.
• WARNING: Shock hazard - Do Not Open.
• Caution and marking information is located at the rear or
bottom of the apparatus.
• WARNING: To reduce the risk of re or electric shock,
do not expose this apparatus to rain, moisture, dripping, or
splashing.
• Objects lled with liquids, such as vases, shall not be placed
on the apparatus.
WARNING : This product can expose you
to chemicals including lead, which is known
to the State of California to cause cancer and
birth defects or other reproductive harm. For
more information go to www.P65Warnings.
ca.gov. This product meets and complies
with all Federal regulations.

45
OPTICAL IN L RAUX IN SUB OUTLINE IN
DC IN
Features & Specifications
• 32" length
• Supports Bluetooth
• Wireless range: 60 ft.
• 2 channel stereo sound
• Digital volume control
• Full-function remote
• Learning remote control capability
• Optical digital audio input
• Subwoofer output
• Aux In (3.5mm audio input)
• RCA stereo audio inputs
Table of Contents Setup
Includes
• Remote control with CR2025 battery pre-installed
• Optical audio cable
• AC/DC power adapter
• Wall-mount hardware and instructions
Power
Plug the power cord into the DC Input on the back of
the speaker and a standard wall outlet.
Remote Battery
Requires 1 CR2025 battery (pre-installed).
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Features & Specications
Power
Remote Battery
Includes
Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Front View
Speaker Controls (Right Side)
Speaker Inputs (Rear View)
Remote
Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Bluetooth Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Initial Bluetooth Connection and Playing Audio
Previously Connected Devices
What Is the Learn Feature?
Why Use the Learn Feature?
Using the Learn Feature
Audio Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Stereo RCA Inputs (Aux In)
Subwoofer Output
Optical Input
Line In
Stereo RCA Inputs (Aux In) - Detail
Optical Input - Detail
Line In
Line In - Detail
Company Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Contact Information
International Support
Warranty

67
OPTICAL IN L RAUX IN SUB OUTLINE IN
DC IN
Speaker Controls (Right Side)
Speaker Inputs (Rear View)
Remote
Front View
Orientation
Stereo RCA Audio Inputs (AUX IN)
Remote Receiver
Function/Source Indicators: Power | Line In | Optical | Aux In | Bluetooth
Optical Input
DC Power Input
Subwoofer Output
Line In ( 3.5mm audio input)
Power
Press to power
the unit ON or OFF.
Source
Press to switch between
Line In, Optical, AUX, and
Bluetooth modes.
Volume +/-
Press to adjust the
volume up or down.
Pair/Learn
Press and hold to
begin pairing to a
Bluetooth device.
With the unit off,
press to begin using the
Learn function.
SOURCE MODE / STATUS INDICATOR LIGHT
Power OFF Red Light ON
Power ON Red Light OFF
Line In (3.5mm audio input) Green Light ON
Optical Input Orange Light ON
Aux (RCA Stereo input) White Light ON
Bluetooth Pairing Quick Flashing Blue Light
Bluetooth Connected Blue Light ON
VOLUME +
PAIR/LEARN
VOLUME
SOURCE
POWER
Wall Mount Pegs
Treble
Press to adjust the treble
up or down.
Bass
Press to adjust the bass
up or down.
Volume +/-
Press to adjust the
volume.
Power
Press to turn
the unit ON or OFF.
Press to switch
to Bluetooth Mode.
Optical
Press to switch
to Optical mode.
AUX (RCA audio)
Press to switch
to Aux mode.
Line In (3.5mm audio)
Press to switch
to Line In mode.
Music
Press to switch to the
EQ optimized for music.
Movie
Press to switch to the
EQ optimized for movies.
Dialog
Press to switch to the
EQ optimized for dialogue.
Skip
In Bluetooth mode,
press to skip forward
or back one track.
Play/Pause/Pair
Press and hold to pair
Bluetooth.
In Bluetooth mode,
press to play or
pause a track.
Mute
Press to mute the volume.
The indicator will flash.

89
Bluetooth WirelessWall Mounting
Learn Feature
What Is the Learn Feature?
The Learn feature captures remote commands from your television remote, and teaches your sound bar to operate
when these commands are pressed. Power, volume and mute are a few examples of commands that the sound bar can
learn.
Why Use the Learn Feature?
Teaching the sound bar remote commands will reduce the number of remotes needed, save time searching for remote
codes, and improve the ease of operation.
Note: Not all functions of the sound bar will be available through your own remote control. Use the included remote for
these functions. While ITB196 is able to learn most IR protocols, not all can be programmed.
Using the Learn Feature
1. With the power Off, press the Learn button on the unit. An indicator light will begin flashing red.
2. Press the button you desire to be learned on the included remote. For example: Volume +
3. The red light will continue to flash, and another indicator will display a blue light.
4. Press the corresponding button on your remote.
5. The red light will continue to flash, and another indicator will display a green light.
6. Press the Learn button on the unit.
7. The programmed button on your remote will now be able to control your sound bar. Note: It is necessary to
program each button on your remote separately.
8. If the sound bar has failed to learn a command, the indicator will display an orange light. Please try another
remote control.
Wall Mount Bracket Installation
Step 1
Find the mounting bracket holes on the rear
of the sound bar (4 per side).
Step 2
Using a screwdriver,
attach the mounting
brackets to the sound bar.
Installation Complete
Initial Bluetooth Connection and Playing Audio
1. Power on the sound bar by pressing the Power button. A voice will say, "Bluetooth," and the LED indicator will
slowly flash blue. When pairing, remain within 3 feet of the Bluetooth device.
2. Using the controls on your Bluetooth device, select ITB196 in the Bluetooth Settings to pair. If need be, refer to
the user’s manual for your specific device for more information.
3. When successfully paired, a voice will announce, “Bluetooth is connected,” and the LED indicator will turn solid
blue. Audio from the connected Bluetooth device will now be heard through the speaker.
4. Use the controls on the connected Bluetooth device to select and play audio. Use the speaker controls or the
connected Bluetooth device to play, pause, and adjust the volume level.
5. After initial pairing, press the Power button until the voice prompt says,“Power on.”The speaker will power ON
and automatically connect to the last Bluetooth device used. Note: If your device should become unpaired or
you find it is unable to connect, press & hold the Play button to enter to Pairing Mode. A voice will announce,
“Bluetooth is connecting,” and you can connect to the speaker manually.
Note: This sound bar has last function memory. After powering OFF, it will resume the last play mode when powering
ON again. Remember to press the button to switch it to Bluetooth Mode before connecting.
Previously Connected Devices
• The sound bar can remember multiple Bluetooth devices and will always try to re-connect to the last device used.
• To reconnect to a different device, turn off Bluetooth on unwanted devices, then access the Bluetooth settings
menu on the device you wish to use and select ITB196.

10 11
OPTICAL IN L RAUX IN SUB OUTLINE IN
DC IN
OPTICAL IN L RAUX IN SUB OUTLINE IN
DC IN
Stereo RCA Inputs (Aux In) - Detail
Optical Input - Detail
Line In Line In - Detail
Use when connecting a subwoofer
!
Audio Inputs
Stereo RCA Inputs (Aux In)
1. Connect the RCA cables (not included) to the RCA Stereo Inputs located on the back of the unit, and to the audio
outputs on a television or other audio source.
2. Press the Power button to power on the unit.
3. Press the Source button to select Aux In, indicated by a white light.
4. Audio played through the television will now be heard through the speakers.
Subwoofer Output
The sound bar can be connected to a detached subwoofer by using another RCA cable (not included).
1. With the main stereo RCA cables connected, use another RCA cable (not included) to connect an external
subwoofer to the Subwoofer Output.
2. When audio is played through any source, the speaker will automatically use the connected subwoofer.
Line In
Requires 3.5 mm audio input cable (not included).
1. Plug one end of a 3.5 mm audio input cable into the Line In on the unit and plug the other end of the cable into
the audio output/headphone output on an MP3 Player or other audio source.
2. Press the Power button to power the unit on.
3. Press the Source button to select Line In, indicated by a green light.
4. Audio played through the connected device will now be heard through the speakers. Use the controls on the
connected device to play, pause, or skip selected tracks.
OPTICAL IN L RAUX IN SUB OUTLINE IN
DC IN
OPTICAL IN L RAUX IN SUB OUTLINE IN
DC IN
Optical Input
Requires an audio source with an Optical Audio Output and a Digital Optical Audio Cable (included).
1. Using a Digital Optical Audio Cable, connect the Optical Input on the sound bar to the Optical Output on your
audio source (TV, amplifier, etc.).
2. Power ON the sound bar and press Optical on the remote or Source on the sound bar to select Optical Mode.
A voice will announce the source mode and the indicator will turn orange.
3. On the connected audio source (TV, amplifier, etc.), be sure the audio settings are set to PCM or Optical Audio.
4. Audio played through the connected audio source (TV, amplifier, etc.) should now be heard through the speaker.
Important tips for optical audio:
• Use the correct optical audio cable and make sure that it is firmly seated in both source and sound bar sockets.
• Optical audio output is activated from the audio source (a red light should be visible from the optical socket). It
may be labeled SPDIF in the settings menu of the source.
• The optical output source should be set to output PCM and not Dolby Digital.

12
International Support
To download this User’s Guide in English, Spanish, and French, or to get answers to frequently asked questions, visit
the support section at: www.iLiveElectronics.com
Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas frecuentes,
visite la sección de apoyo en: www.iLiveElectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour obtenir des réponses à des
questions fréquemment posées, consultez la rubrique d’assistance sur: www.iLiveElectronics.com
Contact Information
Website: www.iLiveElectronics.com
Email Support: [email protected]
Email Parts: [email protected]
Phone Support: 1-888-999-4215
Warranty
For Warranty Information and the most up-to-date
version of this User’s Guide, go to:
www.iLiveElectronics.com
Company Information
Copyright © 2019 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of
their respective owners. Specifications are subject to change without notice.
Protect for Today
Sustain for Tomorrow
Made
Green
