iLive ITB183B v859-04 User manual

USER’S GUIDE
V: 859-01
For the most up-to-date version of this User’s Guide, go to www.iLiveElectronics.com
ITB183B
Bluetooth 32”HD Sound Bar

2
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding - type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety.
When the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12.
The lightning ash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of
sufcient magnitude to constitute a risk of electric
shock to persons.
WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user
accessible parts.
Use only with a cart, stand, tripod,
bracket, or table specied by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
Important Safety Instructions
Warning: Changes or modications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV
technician for help.
FCC Warnings

Customer Support: 1-888-999-4215
3
Warnings and Precautions
Additional Warnings
•CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
•WARNING: To reduce the risk of re or electric shock, do
not expose this apparatus to rain, moisture, dripping, or
splashing.
AVIS:Pour réduire le risque d’incendie ou de choc électrique,
ne pas exposer cet appareil sous la pluie et l’humidité.
•CAUTION: Use of controls or adjustments or performance
of procedures other than those specied may result in
hazardous radiation exposure.
•WARNING: Changes or modications to this unit
not expressly approved by the party responsible for
compliance could void the user’s authority to operate the
equipment.
•WARNING: Do not place this unit directly onto furniture
surfaces with any type of soft, porous, or sensitive nish.
As with any rubber compound made with oils, the feet
could cause marks or staining where the feet reside. We
recommend using a protective barrier such as a cloth or a
piece of glass between the unit and the surface to reduce
the risk of damage and/or staining.
•WARNING: Use of this unit near uorescent lighting may
cause interference regarding use of the remote. If the
unit is displaying erratic behavior move away from any
uorescent lighting, as it may be the cause.
•CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
AVIS: Danger d’explosion si les piles sont remplacées de
façon incorrect. Remplacer les piles seulement par le même
type de pile ou l’équivalent.
•WARNING: There is a danger of explosion if you attempt
to charge standard Alkaline batteries in the unit. Only use
rechargeable NiMH batteries.
•WARNING: The remote control’s button cell battery
contains mercury. Do not put in the trash, instead recycle
or dispose of as hazardous waste
•WARNING: Lithium batteries, like all rechargeable
batteries, are recyclable and should be recycled or
disposed of in normal household waste. Contact your
local government for disposal or recycling practices in
your area. They should never be incinerated since they
might explode.
•WARNING: Shock hazard - Do Not Open.
AVIS: Risque de choc électrique - ne pas ouvrir
•Caution and marking information is located at the rear or
bottom of the apparatus.
Attention et de marquage des informations est situé sur le
paneau arrière ou inférieur de l’unité.
•Objects lled with liquids, such as vases, shall not be
placed on the apparatus.
Objets remplis de liquides, comme des vases, ne doivent pas
être placés sur l’appareil.
•Mains plug is used as disconnect device and it should
remain readily operable during intended use. In order
to disconnect the apparatus from the mains completely,
the mains plug should be disconnected form the mains
socket outlet completely.
La prise du secteur est utilisé pour déconnecter le système.
La prise du secteur ne doit pas être obstruée ou doit être
facilement accessible pendant son utilisation. Pour être
complètement déconnecté de l’alimentation d’entrée, la
prise doit être débranchée du secteur.
•Battery shall not be exposed to excessive heat such as
sunshine, re or the like.
Les piles ne doivent pas être exposées à de forte chaleur,
tel qu’à la lumière du soleil, au feu ou autres choses de
semblable.
•This product is supplied with a coin/button cell battery.
If the coin/button cell battery is swallowed, it can cause
severe internal burns and can lead to death.
Ce produit est livré avec une pile pièce / touche. Si la pile
pièce / bouton est avalé, il peut causer des brûlures internes
graves et peut conduire à la mort.
•Keep new and used batteries away from children. If the
battery compartment does not close securely, stop using
the product and keep it away from children.
Gardez les piles neuves et d’occasion à partir des enfants. Si
le compartiment de la batterie ne pas fermer correctement,
cesser d’utiliser le produit et garder loin des enfants.
•If you think batteries might have been swallowed or
placed inside any part of the body, seek immediate
medical attention.
Si vous pensez que les batteries peuvent avoir été avalé
ou placé à l’intérieur d’une partie du corps, consulter
immédiatement un médecin.
•Do not mix old and new batteries.
Ne pas mélanger vieilles et nouvelles batteries.
•Completely replace all old batteries with new ones.
Remplacer complètement toutes les piles par des neuves.
•Do not mix alkaline, standard (carbon-zinc), or
rechargeable (ni-cad, ni-mh, etc) batteries.
Ne mélangez pas des piles alcalines, standard (carbone-zinc)
ou rechargeables (Ni-Cd, Ni-MH, etc) batteries.
•Batteries should be recycled or disposed of as per state
and local guidelines.
Piles doivent être recyclées ou éliminées selon les directives
étatiques et locales.

4
ITB183B
• 32” length
• Supports Bluetooth
• Supports Bluetooth v3.0
• Supports Enhanced Data Rate
(EDR)
• Supports prole A2DP
(Advanced Audio Distribution
Prole)
• Optical digital audio input
• LED power indicator
• Digital volume control
• LED source indicators
• Built-in stereo speakers
• RCA stereo audio inputs
• 3.5mm audio input
• Remote
• Wireless range: 33 feet
• DC power input: requires
an AC/DC power adapter
(included)
• Remote control: requires a
CR2025 battery (pre-installed)
• RCA stereo audio cable
• Wall-mount hardware and
instructions
• AC/DC power adapter
Features Includes
Setup
AC power input: requires an AC/DC power adapter
(included)
Requires a CR2025 battery (pre-installed)
LITHIUM BATTERY
CR 2025
3V
PUSH
OPEN
LITHIUM BATTERY
CR 2025
3V
CR2025
PUSH
OPEN
Power Remote
Status Indicator
Power O Red Light
Optical Mode Amber Light
Aux In Mode White light
Line In Mode Green Light
Bluetooth Ready Flashing Blue Light
Bluetooth Connected Blue Light
LED Indicators
We recommend having this bar speaker
professionally mounted.
Mounting
4

Customer Support: 1-888-999-4215
5
Table of Contents
Warnings and Precautions ............................................................................ 2
Important Safety Instructions ......................................................................... 3
ITB183B. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features
Setup ................................................................................................ 4
Power
LED Indicators
Remote
Mounting
Includes
Table of Contents..................................................................................... 5
Introduction ......................................................................................... 6
Audio Inputs ......................................................................................... 8
Using the Stereo RCA Inputs
Using the Optical Input
Line In ............................................................................................... 9
Using the Line In
Bluetooth...........................................................................................10
Pairing a Bluetooth Device for the First Time
Bluetooth...........................................................................................11
Playing Audio Wirelessly
Company Information ...............................................................................12
International Support
Contact Information
Warranty
Green Initiative

6
Introduction
PAIRING
Stereo RCA Audio Inputs Optical Input DC Power Input
Power
Press to turn the
unit on or o.
Source
Press to switch
between Optical,
Line In, AUX, and
Bluetooth modes.
Volume
Press to adjust the
volume up or down.
Pairing
Press to begin
pairing with a
Bluetooth device.
Line Input
6

Customer Support: 1-888-999-4215
7
TALK
BT
Press to switch to
Bluetooth Mode.
Mute
Press to mute the volume.
Aux
Press to switch to AUX mode.
Talk
Press to switch to the EQ
optimized for dialogue.
Movie
Press to switch to the EQ
optimized for movie sound.
Volume
Press to adjust the volume.
Power
Press to turn the
unit on or o.
Optical
Press to switch to
Optical mode.
Line
Press to switch to
Line In mode.
Music
Press to switch to the EQ
optimized for music.
Treble
Press to adjust the
treble up or down.
Bass
Press to adjust the
bass up or down

8
Audio Inputs
When connecting two products using an RCA
Cable, match the colored ports with the same
colored connection.
Before use, disconnect any cables connected to the
Line In.
1. Connect the RCA Cable to the RCA Stereo Inputs
located on the back of the unit, and to the audio
outputs on the television.
2. Press the Power button to power on the unit.
3. Press the Source button repeatedly to enter Aux
Mode, indicated by a white light.
4. Audio played through the television will now be
heard through the speakers.
Using the Stereo RCA Inputs
You will need: An audio source with an Optical
Audio Output and a Digital Optical Audio Cable (not
included)
1. Connect the Digital Optical Audio Cable to the
optical output on the audio source and to the
Optical Input on the speaker bar.
2. Press the Power button to power the unit on.
3. Press the Source button repeatedly to switch to
SPDIF Mode, indicated by a amber light.
4. Using the native controls on your connected device,
make sure the audio settings are set to PCM or Optical Audio and are turned On.
5. Audio from the connected audio source will now be played through the speakers.
Important tips:
Use the correct toslink cable and make sure that it is rmly seated in both source and sound bar sockets.
Optical output is activated on the source (they should see a red light emitting from the toslink socket).
It may be labeled SPDIF in the setting menu of the source.
The optical output is set to output PCM and not Dolby Digital.
Using the Optical Input

Customer Support: 1-888-999-4215
9
Line In
1. Plug one end of a 3.5 mm audio input cable into
the Line In on the unit.
3.5 mm audio input cable not included.
Before use, disconnect any cables connected to the
Stereo RCA Inputs.
2. Plug the other end of the cable into the audio
output/headphone output on an MP3 Player or
other audio source.
3. Press the Power button to power the unit on.
4. Press the Source button repeatedly to enter Line
In Mode, indicated by a green light.
5. Audio played through the connected device will
now be heard through the speakers.
Using the Line In

10
Bluetooth
Pairing a Bluetooth Device for the First Time
1. Power on the unit by pressing the Power button.
2. Press the Source button repeatedly to enter
Bluetooth mode, indicated by a blue light.
3. Press the Pairing button on the side of the unit.
The Pairing Indicator will ash blue quickly.
When pairing, remain within 3 feet of the unit.
4. Using the native controls on your Bluetooth
device, select the“ITB183” in your Bluetooth
settings to pair.
If your device requests a password, enter the default
password “ 0 0 0 0 ”.
Refer to the user’s manual for your specic device
for instructions on pairing and connecting
Bluetooth devices.
5. When successfully paired and connected, a
beep will issue from the unit and the Pairing
Indicator will display a solid blue light.
After initial pairing, the unit will stay paired unless
unpaired manually by the user or erased due to a
reset of the device.
If your device should become unpaired or you nd
it is unable to connect, repeat the above steps.

Customer Support: 1-888-999-4215
11
Bluetooth
Playing Audio Wirelessly
1. Follow the instructions for Pairing a Bluetooth
Device.
2. Use the native controls on the connected
Bluetooth Device to select a track.
3. To play, pause or skip the selected track, use
the native controls on the connected Bluetooth
Device.
4. Audio played through the connected Bluetooth
device will now be heard through the speakers.

Copyright © 2012 Digital Products International (DPI, Inc.) | All other trademarks appearing herein are the property of their respective owners.
Specications are subject to change without notice
To download this User’s Guide in English, Spanish,
and French, or to get answers to frequently asked
questions, visit the support section at:
www.iLiveElectronics.com
Para descargar este Manual del Usuario en inglés,
español y francés, o para obtener respuestas a
preguntas frecuentes, visite la sección de apoyo en:
www.iLiveElectronics.com
Pour télécharger ce guide de l’utilisateur en anglais,
espagnol ou français, ou pour obtenir des réponses
à des questions fréquemment posées, consultez la
rubrique d’assistance sur:
www.iLiveElectronics.com
Email Support: [email protected]
Email Parts: partsinf[email protected]
Phone Support: 1-888-999-4215
Website: www.iLiveElectronics.com
Green InitiativeInternational Support
Contact Information
Company Information
Environmental Commitment to‘Protect for Today
and Sustain for Tomorrow’
On a continual basis DPI, Inc. is making eorts
to sustain the environment and improve the
recyclability of its products and packaging.
Focusing on “protecting for today and sustaining
for tomorrow”DPI, Inc. has committed to reducing
packaging size, increasing the usage of recyclable
plastics, and ensuring that packaging and manuals
are made with up to 85% recycled material. In
addition to material consideration, DPI, Inc. has also
focused on the ner details that positively impact
the environment such as employing the usage of
soy-based inks.
DPI, Inc. also ensures that the factories that produce
the company’s wide variety of consumer electronics
adhere to environmentally friendly air and water
restrictions. This is yet another example that every
step of the way DPI, Inc. is making eorts to lessen
any impact on the environment.
In 2011 DPI, Inc. also began conversations with
Energy Star in order to ensure that the consumer
electronics being produced meet high standards
of energy eciency. The ultimate goal is keeping
energy costs for consumers low while providing
quality, feature-rich products.
For Warranty Information and the most up-to-date
version of this User’s Guide, go to:
www.iLiveElectronics.com
Warranty
