iLiving ILG8EF10EX Manual

1
Explosion proof high velocity
warehouse fan
Operation & maintenance Manual

2
1. General
1.1. Scope
Explosion proof high velocity warehouse fan is manufactured as a flameproof
equipment according to requirements of EN60079-0:2012 Explosive atmospheres Part
1: Equipment-General requirements and EN60079-1:2014 Explosive atmospheres Part
2: Equipment protection by flameproof enclosures "d". It is available for use in Zone 1
and Zone 2 area that explosive mixture of group IIA and IIB T1~T4 gases, vapour and
air exists, the rated voltage 120V, frequency 60Hz.
1.2. Model of axial flow fan and explanations:
The protection type of the axial fan should be protected by flameproof enclosure "d"
according to EN60079-0:2012 and EN60079-1:2014, the Ex marking is II2G Ex d
IIB T4 Gb.
The fan consists of enclosure, impeller, impeller shield, explosion proof motor
(hereinafter referred to as "Ex motor") and flame-proof switch (hereinafter referred to
as "Ex switch"). The IP code is IP54. Installation of all Ex components shall comply
with the local safety requirements.
Model of axial flow fan and explanations:
ILG8EF 10 EX
Diameter of impeller: 10 inches
Explosion proof axial flow fan
2: 2poles;
See table 1 for the basic parameters of fan.
Table 1: Basic parameters of fan
Model
Impeller
size
(inch)
Rated
volt.
(V)
Rated
freq.
(Hz)
Rated
rotating
speed (r/min)
Rated
power
(W)
Air volume
(CFM)
Air
pressure
(Pa)
Noise
level
dB(A)
ILG8EF10EX
10
120
60
3300
350
1943
350
66
ILG8EF12EX
12
3300
550
2720
450
69
ILG8EF16EX
16
3300
1100
4240
780
79
ILG8EF20EX
20
1720
900
5830
460
72
Ex marking explanations：
II2G Ex d IIB T4 Gb
Ex: Explosion proof product
D: protection by flameproof enclosure "d"
IIB: used in IIB group gases
T4: temperature class
Gb: equipment protection level
See Figure 1 and 2 for the diagram of the fan.
The main dimensions of the fan see Table 2.

3
Figure 1: Diagram of ILG8EF10EX, ILG8EF12EX
Figure 2: Diagram of ILG8EF16EX, ILG8EF20EX
Table2: The main dimensions of the fan
Model
A
B
C
L
H
Φ1
Φ2
Φ3
ILG8EF10EX
210
175
/
380
375
140
280
325
ILG8EF12EX
225
220
/
380
425
165
330
380
ILG8EF16EX
295
325
575
450
670
218
435
480
ILG8EF20EX
325
425
675
480
770
268
535
580
2. Service condition
a) Ambient temperature: -20℃～+40℃;
b) Height above sea level: ≤ 2000mm;
c) Ambient humidity: ≤ 95% (+25℃);
d) Zone 1 and Zone 2 area that explosive mixture of group IIA and IIB T1~T4 gases,
vapors and air exists;
e) Place where no obvious shake, impact or vibration;
f) In environment without gases or vapors, they may cause insulation breakdown.
2 3
1

4
3. Flame proof structural features of fan
3.1.
The fan consists of Ex motor, impeller, enclosure, shield and Ex switch. Protection
type of the fitted Ex motor and Ex switch is flameproof enclosure. The Ex motor
consist of cast aluminum frame and end caps, axis, stator, rotor, sealing ring,
compression nut and so on. The cable entry is mounted on the rear end cap. Impeller is
made of cast aluminum alloy and fixed by fasten bolts. After finish machining a static
pressure test shall be carried out on the motor, no structure damage, permanently
deformation which may affect the explosion proof performance or drip allowed when
tested by pressure of 1.5Mpa for 10 seconds.
3.2.
Clearance(flame path), length and roughness of flame proof joint shall comply with
associate requirements of GB3836.2-2010; electric clearance and creepage distance
shall comply with associate requirements of GB3836.3-2010
3.3.
Washer is required of every fasten bolts of flameproof enclosure, avoid loosen.
4. Installation, operation and maintenance
4.1. Prepare before installation
4.1.1. Check integrity or any damage of the package before opening;
4.1.2. Clearance the dust and anti-rust coating;
4.1.3. The product is provided with cable glands with setting compound, the permissible cable
diameter is 10-19mm, the compression nut shall be tightened with force of 30.0N.m. Only
spare rubber sealing rings and nut delivered from the manufacturer can be used.
4.1.4. Shaft seals shall be periodically manual checked (minimum every three months),
replacement is required if any abrasion found. contact the manufacturer for the spare part.
4.1.5. The axial flow fan is not allowed to put into use if any inconformity of the following items
found before installation:
a. Ex marking and number of Certificate of Conformity on the nameplate are distinct;
b. All parts of the flameproof enclosure are well assembled, no damage;
c. No crack or defect that may affect the explosion proof performance of all the flameproof
components;
d. The flameproof joint is lubricated with 204-1 anti-rust oil;
e. Lubrication system of the bearing is unobstructed
f. The insulation resistance is no less than 10MΩ.
4.2. Cut off the power supply before installation, choose a proper diameter of sealing
ring to connect the switch, compress the compression device on the sealing ring,
the earthing wire of switch shall be connected to the earthing terminal.
4.3. Check all the fasteners to ensure they are well fastened; the tighten force applied
on cable glands shall be no less than 30N.m.
4.4. Specific condition for sage use:
Repairs of the flameproof joints must be made in compliance with the structural
specifications provided by the manufacturer. Repairs must not be made on the basis of
values specified in tables 1 and 2 of EN/IEC 60079-1
5. Transportation and Storage
5.1. The fan shall be transported with no rain and snow. It shall be kept in a well

5
ventilated warehouse with no corrosive gas, the temperature shall be in the range
of -25 to 45℃, relative humidity no more than 90%(25℃).
5.2. 6.2 The axial flow fan shall be kept in a well ventilated warehouse with no
corrosive gases or vapors may affect the insulation resistance.
6. Warranty
This fan comes with a 1-YEAR LIMITED COMPONENT WARRANTY. If your unit does not
appear to be working properly, please contact our service center by calling 1-800-317-1688. Prior
to your call, we encourage you to visit our service related website www.ilivingusa.com for
troubleshooting tips and service instructions if needed.
WARRANTY INFORMATION
Register your product at our website:
Or visit iLivingUSA.com/register-product
FEEDBACK
LOVE IT? HELP US MAKE THE PRODUCT MORE FOR YOU.
Let us know with a customer review.
Please visit: https://www.amazon.com/review/review-your-purchases#

6
